Zoom M3 MicTrak File Recovery: An Adventure Into the World of Data Recovery

How a series of inconspicuous events lead to a journey deep into the binary encoding of RIFF files and this data recovery tool If you're in a hurry, head directly to the GitHub repository. While I'm fortunate enough to develop software for state-of-the-art companies, I've always been the "printer guy", a badge I wear with pride. And maybe that's the reason why, for more than a quarter of a century, people have turned up with storage mediums to salvage. I never did it professionally, it’s just something I enjoy and, more often than not, I’m able to help. The Process My main approach is two-fold: capture what you can from the dying medium try to recreate the data Sometimes, just by adjusting read tolerance, you're able to capture everything from a disk Windows or Mac reject, as the OS times out faster than the dying medium can respond. I've had a disk hooked to a box for 7 months; 100% recovery success! Sometimes, you'll have chunks of data missing, but one of the File Allocation Table/Master File Table/Container superblock/root B-tree is still there, so most data is salvageable with both filenames and tree location. At the extreme, you’re left with nothing but some of the raw data. All you can do is carve it out - essentially reading every byte from the medium, identifying known headers like JPG (FF D8) or MKV (1A 45 DF A3), and proceed to capture all sequential data until the end of the file. If for any reason, the file is fragmented, carving will obviously fail. The Call From Pierre Zago Frankie, this hasn't happened before, I'm generally cautious... I don't know what I was thinking - I've accidentally formatted an SD card with audio for an entire session. Worse, I've saved some files onto it! Pierre is an incredibly talented comedian and an extraordinary actor. While his work is multifaceted, he became widely known for street sketches, some of them absolutely universal. Just check the one below where he simply says "Excuse me." https://www.youtube.com/watch?v=JC-yra6dtzw&embedable=true This sketch’s simplicity and comedic charm create a lighthearted yet universally appealing work of art. With that simple action, Pierre had joined the club. Everyone messes up. Even Pixar. Don't worry, I said, while taking the card, the overwritten contents are gone, but given that it's a microphone-formatted card, even without FAT tables, we should be able to carve out most of whatever you've recorded as data will probably be sequential. Little did I know, this would turn out to be one of the most interesting toy projects I’ve worked on in a while. The last time I had this much fun was rebuilding a hardware RAID-0 that contained the masters for an album by 'Os Azeitonas.' The Echo (Echo, Echo)... As expected, the only way to get data back was by carving it out of the image dump. There's a multitude of tools to choose from, Photorec (open source), Recuva (watch out for bundleware), ReclaiMe (paid), etc... though I'm partial to R-Studio (paid); their results consistently outperform the competition. In this instance, nonetheless, things wouldn't be so simple. Every software tried was able to extract the wav files, but there was something rather wrong with the data as they all had this repetition, an echo of sorts. I'm a bit dull of hearing, so I opened them in Audacity to check what was going on. You can clearly see a pattern here: While the chunks have a pretty similar waveform - there isn't any sort of binary correlation. Besides, there was also something murky, every wav file had what appeared to be 2 consecutive headers. Mind you, at this point, my knowledge of wav files was that the header is 52 49 46 46. Aside from using a mic, I didn't query Pierre on how he had actually recorded the data. However, when I saw the "ZOOM M3" tag in the header, I called the authority on everything sound. Perfect Pitch, a Sort of Wizardry Ed's been on speed dial for the better part of this lifetime. I'm lucky like that. Beyond being an unbelievable composer - just listen to the breathtaking Best Youth - he's also a pitch-perfect, living and breathing, encyclopedia on sound. https://www.youtube.com/watch?v=ZGtOOPJKfYA&embedable=true Zoom? Yes, yes. I have one. They record both wav and raw. Data is mangled? Ah. Sure. Recover? Twisted files? That's going to be an impossible task and, even if it's not, it'll be easier to just re-record. And there he had me. It would definitely be easier to just re-record, even Pierre at one point suggested doing a voice-over, but where would the fun be in that? The Magic Number I didn't even appreciate the concept of a raw wave until Ed explained it, but now I knew the mic saves two simultaneous files, everything fell into place. It's common for digital cameras to store both formats, but a microphone is a different beast. There's no way to determine upfront how long the user will record, which wouldn't be an issue if this were a single stream. As it's storing both tracks, there is quite a bit more play involved. You see, as soon as you hit record, the mic creates two files and continuously flushes the captured data from both onto the card. That, is done in chunks of data. One for the RAW, another for the WAV, repeat. Since we need to isolate those slices of data in order to untangle it, we must know their exact size. And there lies our magic number! My first thought was that the chunks might be aligned with exFAT allocation unit size. In this case, 128 KBytes. Let's test it. The header, clearly states that this is a stereo file (2 channels), recorded at 32 bits per channel, sampled 48k times per second. If you remember from the image above, the chunks repeat at approximately 0.7 seconds. Let's get a rough approximation on the chunk bytes so we know the ballpark. 1 second of data = 2 channels * 32 bits * 48000 samples 1 second of data = 384000 bytes 0.7 seconds ~ 268800 bytes We're looking into chunks of around 268 KBytes. And just like that, the idea that data may be chunked to exFAT AUS of 128 Kbytes is instantly disproved. The next obvious step would be to travel upwards on base 2. Given that 4096 is a good balance for buffers, let's evaluate from there: 4096 * 32 = 131072 (falls short by about 1/2) 4096 * 64 = 262144 (is in the ballpark of what we're expecting) 262144/384000 ~ 0.682 seconds of data 0.682 seconds matched our estimate of 0.7 seconds so perfectly that I immediately knew 262144 was the constant we were after. The Reconstruction Conceptually, the problem was solved. Now, it was just a matter of building the tool. For that, it would be necessary to: Untangle the files directly from the image dump. Since pieces recovered by other carving software would be half the expected size (the data chunk contains two files, so it’s actually double the size reported). Learn how to create a RIFF header. Create a RIFF header with a BEXT chunk to make the recovered files compatible with the "M3 ZOOM Edit & Play" software. All the code is on GitHub! And I'm pretty sure you'll feel more at home there. However, for the sake of Google indexing, I’m leaving the methods that create both the RIFF and BEXT headers here, something I couldn’t find, which unfortunately, made the process take longer than I’d like to admit. public class RiffFile { /** * Creates a RIFF header with BEXT and fmt chunks * * @param sampleRate the sample rate of the audio (8000Hz, 44100Hz, 48000Hz, etc) times per second the audio is sampled * @param bitsPerSample the bits per sample (8bits, 16bits, 32bits, etc) * @param channels the number of channels (1 mono, 2 stereo, etc) * @param audioDataSize the size of the audio data in bytes * @return the RIFF header * @throws IOException if an I/O error occurs */ public static byte[] createRiffHeader(int sampleRate, short bitsPerSample, short channels, int audioDataSize) throws IOException { // calculate the byte rate, block align and file size int byteRate = sampleRate * channels * bitsPerSample / 8; short blockAlign = (short) (bitsPerSample * channels / 8); // stream that will carry the new RIFF file ByteArrayOutputStream byteArrayOutputStream = new ByteArrayOutputStream(); DataOutputStream out = new DataOutputStream(byteArrayOutputStream); // riff header out.writeBytes("RIFF"); out.writeInt(Integer.reverseBytes(0)); out.writeBytes("WAVE"); // 9-12 Format always WAVE // bext chunk writeBextChunk(out); // fmt chunk out.writeBytes("fmt "); // 13-16 chunkID is "fmt " with trailing whitespace out.writeInt(Integer.reverseBytes(16)); // 17-20 size of this chunk, is 16 byts out.writeShort(Short.reverseBytes((short) 3)); // 21-22 (2 bytes) audioFormat (1 PCM integer, 3 IEEE 754 float) out.writeShort(Short.reverseBytes(channels)); // 23-24 (2 bytes) numChannels (1 mono, 2 stereo, 4, etc) out.writeInt(Integer.reverseBytes(sampleRate)); // 25-28 (4 bytes) sampleRate (8000, 44100, 48000, etc) out.writeInt(Integer.reverseBytes(byteRate)); // 29-32 (4 bytes) byteRate (sampleRate * numChannels * bitsPerSample/8) out.writeShort(Short.reverseBytes(blockAlign)); // 33-34 (2 bytes) blockAlign (numChannels * bitsPerSample/8) out.writeShort(Short.reverseBytes(bitsPerSample)); // 35-36 (2 bytes) bitsPerSample (8bits, 16bits, 32bits, etc) // data chunk out.writeBytes("data"); // 37-40 chunkID ID is "data" out.writeInt(Integer.reverseBytes(audioDataSize)); // 41-44 size of this chunk varies out.close(); // write the full size of the file on the 4-8 bytes byte[] outArr = byteArrayOutputStream.toByteArray(); int size = outArr.length - 8; ByteBuffer.wrap(outArr, 4, 4).order(ByteOrder.LITTLE_ENDIAN).putInt(size); return outArr; } private static void writeBextChunk(DataOutputStream out) throws IOException { // bext chunk out.writeBytes("bext"); out.writeInt(Integer.reverseBytes(256 + 32 + 32 + 10 + 8 + 8 + 8 + 2 + 180 + 4 + 4 + 4 + 4 + 4 + 180)); // bext chunk size (fixed size for BWF) // description 256 bytes writeToArray(out, 256, ""); // 256 bytes description writeToArray(out, 32, "ZOOM M3"); // 32 bytes originator writeToArray(out, 32, ""); // 32 bytes originator reference writeToArray(out, 10, "2023-10-01"); // 10 bytes origination date writeToArray(out, 8, "12:00:00"); // 8 bytes origination time writeToArray(out, 8, "12:00:00"); // 8 bytes time reference out.writeLong(Long.reverseBytes(0L)); // 8 bytes time reference out.writeShort(Short.reverseBytes((short) 0)); // 2 bytes version out.write(new byte[180]); // 180 bytes UMID out.writeFloat(0.0f); // 4 bytes loudness value out.writeFloat(0.0f); // 4 bytes loudness range out.writeFloat(0.0f); // 4 bytes max true peak level out.writeFloat(0.0f); // 4 bytes max momentary loudness out.writeFloat(0.0f); // 4 bytes max short term loudness // zoom m3 needs this bit to allow file to be read from "zoom m3 edit & play" writeToArray(out, 180, "A=PCM,F=48000,W=32,M=stereo,T=M3;VERSION=1.00;MSRAW=ON ;"); } } As you may see, there wasn't much effort put into the BEXT chunk; I simply created it to ensure "Zoom M3 Edit & Play" would be compatible. The Tool I hope you had an interesting read. I tried to lift the curtain on the thought process while keeping this engaging. The actual code is hopefully self-explanatory, and you will find it here: https://github.com/wasteofserver/zoom_m3_mic_wav_data_recover/ The challenge wasn't just about recovering lost recordings - it was about understanding why traditional tools failed and developing a method that worked. While it might have been easier to re-record, the thrill of solving the puzzle made the effort worthwhile. In the end, we got a custom-built solution that successfully restores Zoom M3 MicTrak recordings. If you ever find yourself in a similar situation, hopefully, this breakdown helps you out. And if not, well, at least you got to enjoy a little adventure into the world of data recovery. This story was first published on https://wasteofserver.com/zoom-m3-mictrak-file-recovery/. You may want to check it there for latest updates and comments. How a series of inconspicuous events lead to a journey deep into the binary encoding of RIFF files and this data recovery tool How a series of inconspicuous events lead to a journey deep into the binary encoding of RIFF files and this data recovery tool If you're in a hurry, head directly to the GitHub repository. If you're in a hurry, head directly to the GitHub repository . directly to the GitHub repository While I'm fortunate enough to develop software for state-of-the-art companies, I've always been the "printer guy", a badge I wear with pride. And maybe that's the reason why, for more than a quarter of a century, people have turned up with storage mediums to salvage. I never did it professionally, it’s just something I enjoy and, more often than not, I’m able to help. The Process My main approach is two-fold: capture what you can from the dying medium try to recreate the data capture what you can from the dying medium capture what you can from the dying medium try to recreate the data try to recreate the data Sometimes, just by adjusting read tolerance, you're able to capture everything from a disk Windows or Mac reject, as the OS times out faster than the dying medium can respond. I've had a disk hooked to a box for 7 months; 100% recovery success! Sometimes, you'll have chunks of data missing, but one of the File Allocation Table/Master File Table/Container superblock/root B-tree is still there, so most data is salvageable with both filenames and tree location. At the extreme, you’re left with nothing but some of the raw data. All you can do is carve it out - essentially reading every byte from the medium, identifying known headers like JPG ( FF D8 ) or MKV ( 1A 45 DF A3 ), and proceed to capture all sequential data until the end of the file. If for any reason, the file is fragmented, carving will obviously fail. FF D8 1A 45 DF A3 The Call From Pierre Zago Frankie, this hasn't happened before, I'm generally cautious... I don't know what I was thinking - I've accidentally formatted an SD card with audio for an entire session. Worse, I've saved some files onto it! Frankie, this hasn't happened before, I'm generally cautious... I don't know what I was thinking - I've accidentally formatted an SD card with audio for an entire session. Worse, I've saved some files onto it! Pierre is an incredibly talented comedian and an extraordinary actor. While his work is multifaceted, he became widely known for street sketches, some of them absolutely universal. Just check the one below where he simply says "Excuse me." https://www.youtube.com/watch?v=JC-yra6dtzw&embedable=true https://www.youtube.com/watch?v=JC-yra6dtzw&embedable=true This sketch’s simplicity and comedic charm create a lighthearted yet universally appealing work of art. With that simple action, Pierre had joined the club. Everyone messes up. Even Pixar . Don't worry, I said, while taking the card, the overwritten contents are gone, but given that it's a microphone-formatted card, even without FAT tables, we should be able to carve out most of whatever you've recorded as data will probably be sequential. Even Pixar Little did I know, this would turn out to be one of the most interesting toy projects I’ve worked on in a while. The last time I had this much fun was rebuilding a hardware RAID-0 that contained the masters for an album by ' Os Azeitonas .' Os Azeitonas The Echo (Echo, Echo)... As expected, the only way to get data back was by carving it out of the image dump. There's a multitude of tools to choose from, Photorec (open source), Recuva (watch out for bundleware), ReclaiMe (paid), etc... though I'm partial to R-Studio (paid); their results consistently outperform the competition. Photorec Recuva ReclaiMe R-Studio In this instance, nonetheless, things wouldn't be so simple. Every software tried was able to extract the wav files, but there was something rather wrong with the data as they all had this repetition, an echo of sorts. wav I'm a bit dull of hearing, so I opened them in Audacity to check what was going on. You can clearly see a pattern here: Audacity While the chunks have a pretty similar waveform - there isn't any sort of binary correlation. Besides, there was also something murky, every wav file had what appeared to be 2 consecutive headers. wav Mind you, at this point, my knowledge of wav files was that the header is 52 49 46 46 . Aside from using a mic, I didn't query Pierre on how he had actually recorded the data. However, when I saw the "ZOOM M3" tag in the header, I called the authority on everything sound. wav 52 49 46 46 Perfect Pitch, a Sort of Wizardry Ed's been on speed dial for the better part of this lifetime. I'm lucky like that. Beyond being an unbelievable composer - just listen to the breathtaking Best Youth - he's also a pitch-perfect, living and breathing, encyclopedia on sound. Best Youth https://www.youtube.com/watch?v=ZGtOOPJKfYA&embedable=true https://www.youtube.com/watch?v=ZGtOOPJKfYA&embedable=true Zoom? Yes, yes. I have one. They record both wav and raw. Data is mangled? Ah. Sure. Recover? Twisted files? That's going to be an impossible task and, even if it's not, it'll be easier to just re-record. Zoom? Yes, yes. I have one. They record both wav and raw. Data is mangled? Ah. Sure. Recover? Twisted files? That's going to be an impossible task and, even if it's not, it'll be easier to just re-record. And there he had me. It would definitely be easier to just re-record, even Pierre at one point suggested doing a voice-over, but where would the fun be in that? The Magic Number I didn't even appreciate the concept of a raw wave until Ed explained it, but now I knew the mic saves two simultaneous files, everything fell into place. raw It's common for digital cameras to store both formats, but a microphone is a different beast. There's no way to determine upfront how long the user will record, which wouldn't be an issue if this were a single stream. As it's storing both tracks, there is quite a bit more play involved. You see, as soon as you hit record, the mic creates two files and continuously flushes the captured data from both onto the card. That, is done in chunks of data. One for the RAW, another for the WAV, repeat. Since we need to isolate those slices of data in order to untangle it, we must know their exact size . And there lies our magic number ! we must know their exact size our magic number My first thought was that the chunks might be aligned with exFAT allocation unit size. In this case, 128 KBytes . Let's test it. exFAT 128 KBytes The header, clearly states that this is a stereo file (2 channels), recorded at 32 bits per channel, sampled 48k times per second. If you remember from the image above, the chunks repeat at approximately 0.7 seconds. Let's get a rough approximation on the chunk bytes so we know the ballpark. 1 second of data = 2 channels * 32 bits * 48000 samples 1 second of data = 384000 bytes 0.7 seconds ~ 268800 bytes 1 second of data = 2 channels * 32 bits * 48000 samples 1 second of data = 384000 bytes 0.7 seconds ~ 268800 bytes We're looking into chunks of around 268 KBytes. And just like that, the idea that data may be chunked to exFAT AUS of 128 Kbytes is instantly disproved. The next obvious step would be to travel upwards on base 2. Given that 4096 is a good balance for buffers, let's evaluate from there: 4096 * 32 = 131072 (falls short by about 1/2) 4096 * 64 = 262144 (is in the ballpark of what we're expecting) 262144/384000 ~ 0.682 seconds of data 4096 * 32 = 131072 (falls short by about 1/2) 4096 * 64 = 262144 (is in the ballpark of what we're expecting) 262144/384000 ~ 0.682 seconds of data 0.682 seconds matched our estimate of 0.7 seconds so perfectly that I immediately knew 262144 was the constant we were after. 262144 The Reconstruction Conceptually, the problem was solved. Now, it was just a matter of building the tool. For that, it would be necessary to: Untangle the files directly from the image dump. Since pieces recovered by other carving software would be half the expected size (the data chunk contains two files, so it’s actually double the size reported). Untangle the files directly from the image dump. Since pieces recovered by other carving software would be half the expected size (the data chunk contains two files, so it’s actually double the size reported). Untangle the files Learn how to create a RIFF header. Learn how to create a RIFF header . Learn how to create a RIFF header Create a RIFF header with a BEXT chunk to make the recovered files compatible with the "M3 ZOOM Edit & Play" software. Create a RIFF header with a BEXT chunk to make the recovered files compatible with the "M3 ZOOM Edit & Play" software. Create a RIFF header with a BEXT chunk All the code is on GitHub! All the code is on GitHub! All the code is on GitHub ! All the code is on GitHub And I'm pretty sure you'll feel more at home there. However, for the sake of Google indexing, I’m leaving the methods that create both the RIFF and BEXT headers here, something I couldn’t find, which unfortunately, made the process take longer than I’d like to admit. public class RiffFile { /** * Creates a RIFF header with BEXT and fmt chunks * * @param sampleRate the sample rate of the audio (8000Hz, 44100Hz, 48000Hz, etc) times per second the audio is sampled * @param bitsPerSample the bits per sample (8bits, 16bits, 32bits, etc) * @param channels the number of channels (1 mono, 2 stereo, etc) * @param audioDataSize the size of the audio data in bytes * @return the RIFF header * @throws IOException if an I/O error occurs */ public static byte[] createRiffHeader(int sampleRate, short bitsPerSample, short channels, int audioDataSize) throws IOException { // calculate the byte rate, block align and file size int byteRate = sampleRate * channels * bitsPerSample / 8; short blockAlign = (short) (bitsPerSample * channels / 8); // stream that will carry the new RIFF file ByteArrayOutputStream byteArrayOutputStream = new ByteArrayOutputStream(); DataOutputStream out = new DataOutputStream(byteArrayOutputStream); // riff header out.writeBytes("RIFF"); out.writeInt(Integer.reverseBytes(0)); out.writeBytes("WAVE"); // 9-12 Format always WAVE // bext chunk writeBextChunk(out); // fmt chunk out.writeBytes("fmt "); // 13-16 chunkID is "fmt " with trailing whitespace out.writeInt(Integer.reverseBytes(16)); // 17-20 size of this chunk, is 16 byts out.writeShort(Short.reverseBytes((short) 3)); // 21-22 (2 bytes) audioFormat (1 PCM integer, 3 IEEE 754 float) out.writeShort(Short.reverseBytes(channels)); // 23-24 (2 bytes) numChannels (1 mono, 2 stereo, 4, etc) out.writeInt(Integer.reverseBytes(sampleRate)); // 25-28 (4 bytes) sampleRate (8000, 44100, 48000, etc) out.writeInt(Integer.reverseBytes(byteRate)); // 29-32 (4 bytes) byteRate (sampleRate * numChannels * bitsPerSample/8) out.writeShort(Short.reverseBytes(blockAlign)); // 33-34 (2 bytes) blockAlign (numChannels * bitsPerSample/8) out.writeShort(Short.reverseBytes(bitsPerSample)); // 35-36 (2 bytes) bitsPerSample (8bits, 16bits, 32bits, etc) // data chunk out.writeBytes("data"); // 37-40 chunkID ID is "data" out.writeInt(Integer.reverseBytes(audioDataSize)); // 41-44 size of this chunk varies out.close(); // write the full size of the file on the 4-8 bytes byte[] outArr = byteArrayOutputStream.toByteArray(); int size = outArr.length - 8; ByteBuffer.wrap(outArr, 4, 4).order(ByteOrder.LITTLE_ENDIAN).putInt(size); return outArr; } private static void writeBextChunk(DataOutputStream out) throws IOException { // bext chunk out.writeBytes("bext"); out.writeInt(Integer.reverseBytes(256 + 32 + 32 + 10 + 8 + 8 + 8 + 2 + 180 + 4 + 4 + 4 + 4 + 4 + 180)); // bext chunk size (fixed size for BWF) // description 256 bytes writeToArray(out, 256, ""); // 256 bytes description writeToArray(out, 32, "ZOOM M3"); // 32 bytes originator writeToArray(out, 32, ""); // 32 bytes originator reference writeToArray(out, 10, "2023-10-01"); // 10 bytes origination date writeToArray(out, 8, "12:00:00"); // 8 bytes origination time writeToArray(out, 8, "12:00:00"); // 8 bytes time reference out.writeLong(Long.reverseBytes(0L)); // 8 bytes time reference out.writeShort(Short.reverseBytes((short) 0)); // 2 bytes version out.write(new byte[180]); // 180 bytes UMID out.writeFloat(0.0f); // 4 bytes loudness value out.writeFloat(0.0f); // 4 bytes loudness range out.writeFloat(0.0f); // 4 bytes max true peak level out.writeFloat(0.0f); // 4 bytes max momentary loudness out.writeFloat(0.0f); // 4 bytes max short term loudness // zoom m3 needs this bit to allow file to be read from "zoom m3 edit & play" writeToArray(out, 180, "A=PCM,F=48000,W=32,M=stereo,T=M3;VERSION=1.00;MSRAW=ON ;"); } } public class RiffFile { /** * Creates a RIFF header with BEXT and fmt chunks * * @param sampleRate the sample rate of the audio (8000Hz, 44100Hz, 48000Hz, etc) times per second the audio is sampled * @param bitsPerSample the bits per sample (8bits, 16bits, 32bits, etc) * @param channels the number of channels (1 mono, 2 stereo, etc) * @param audioDataSize the size of the audio data in bytes * @return the RIFF header * @throws IOException if an I/O error occurs */ public static byte[] createRiffHeader(int sampleRate, short bitsPerSample, short channels, int audioDataSize) throws IOException { // calculate the byte rate, block align and file size int byteRate = sampleRate * channels * bitsPerSample / 8; short blockAlign = (short) (bitsPerSample * channels / 8); // stream that will carry the new RIFF file ByteArrayOutputStream byteArrayOutputStream = new ByteArrayOutputStream(); DataOutputStream out = new DataOutputStream(byteArrayOutputStream); // riff header out.writeBytes("RIFF"); out.writeInt(Integer.reverseBytes(0)); out.writeBytes("WAVE"); // 9-12 Format always WAVE // bext chunk writeBextChunk(out); // fmt chunk out.writeBytes("fmt "); // 13-16 chunkID is "fmt " with trailing whitespace out.writeInt(Integer.reverseBytes(16)); // 17-20 size of this chunk, is 16 byts out.writeShort(Short.reverseBytes((short) 3)); // 21-22 (2 bytes) audioFormat (1 PCM integer, 3 IEEE 754 float) out.writeShort(Short.reverseBytes(channels)); // 23-24 (2 bytes) numChannels (1 mono, 2 stereo, 4, etc) out.writeInt(Integer.reverseBytes(sampleRate)); // 25-28 (4 bytes) sampleRate (8000, 44100, 48000, etc) out.writeInt(Integer.reverseBytes(byteRate)); // 29-32 (4 bytes) byteRate (sampleRate * numChannels * bitsPerSample/8) out.writeShort(Short.reverseBytes(blockAlign)); // 33-34 (2 bytes) blockAlign (numChannels * bitsPerSample/8) out.writeShort(Short.reverseBytes(bitsPerSample)); // 35-36 (2 bytes) bitsPerSample (8bits, 16bits, 32bits, etc) // data chunk out.writeBytes("data"); // 37-40 chunkID ID is "data" out.writeInt(Integer.reverseBytes(audioDataSize)); // 41-44 size of this chunk varies out.close(); // write the full size of the file on the 4-8 bytes byte[] outArr = byteArrayOutputStream.toByteArray(); int size = outArr.length - 8; ByteBuffer.wrap(outArr, 4, 4).order(ByteOrder.LITTLE_ENDIAN).putInt(size); return outArr; } private static void writeBextChunk(DataOutputStream out) throws IOException { // bext chunk out.writeBytes("bext"); out.writeInt(Integer.reverseBytes(256 + 32 + 32 + 10 + 8 + 8 + 8 + 2 + 180 + 4 + 4 + 4 + 4 + 4 + 180)); // bext chunk size (fixed size for BWF) // description 256 bytes writeToArray(out, 256, ""); // 256 bytes description writeToArray(out, 32, "ZOOM M3"); // 32 bytes originator writeToArray(out, 32, ""); // 32 bytes originator reference writeToArray(out, 10, "2023-10-01"); // 10 bytes origination date writeToArray(out, 8, "12:00:00"); // 8 bytes origination time writeToArray(out, 8, "12:00:00"); // 8 bytes time reference out.writeLong(Long.reverseBytes(0L)); // 8 bytes time reference out.writeShort(Short.reverseBytes((short) 0)); // 2 bytes version out.write(new byte[180]); // 180 bytes UMID out.writeFloat(0.0f); // 4 bytes loudness value out.writeFloat(0.0f); // 4 bytes loudness range out.writeFloat(0.0f); // 4 bytes max true peak level out.writeFloat(0.0f); // 4 bytes max momentary loudness out.writeFloat(0.0f); // 4 bytes max short term loudness // zoom m3 needs this bit to allow file to be read from "zoom m3 edit & play" writeToArray(out, 180, "A=PCM,F=48000,W=32,M=stereo,T=M3;VERSION=1.00;MSRAW=ON ;"); } } As you may see, there wasn't much effort put into the BEXT chunk; I simply created it to ensure "Zoom M3 Edit & Play" would be compatible. The Tool I hope you had an interesting read. I tried to lift the curtain on the thought process while keeping this engaging. The actual code is hopefully self-explanatory, and you will find it here: https://github.com/wasteofserver/zoom_m3_mic_wav_data_recover/ https://github.com/wasteofserver/zoom_m3_mic_wav_data_recover/ https://github.com/wasteofserver/zoom_m3_mic_wav_data_recover/ The challenge wasn't just about recovering lost recordings - it was about understanding why traditional tools failed and developing a method that worked. While it might have been easier to re-record, the thrill of solving the puzzle made the effort worthwhile. In the end, we got a custom-built solution that successfully restores Zoom M3 MicTrak recordings. If you ever find yourself in a similar situation, hopefully, this breakdown helps you out. And if not, well, at least you got to enjoy a little adventure into the world of data recovery. This story was first published on https://wasteofserver.com/zoom-m3-mictrak-file-recovery/. You may want to check it there for latest updates and comments. This story was first published on https://wasteofserver.com/zoom-m3-mictrak-file-recovery/ . You may want to check it there for latest updates and comments. https://wasteofserver.com/zoom-m3-mictrak-file-recovery/
