How to Use Gitlab CI/CD to Build, Test and Deploy a Spring Boot Web App

In this article, we're going to be looking at how to use Gitlab CI/CD to build, test and deploy a Spring Boot web application to a server instance. Gitlab has a generous offering of unlimited free private repositories and 2000 minutes of CI/CD runner. \ We will be using Gitlab as our cloud Git repository in this article and we encourage you to [create an account](https://gitlab.com/) if you don't already have one. \ ## **Application Setup** For the purpose of this article, we will create a simple Spring Boot application using [Spring Initializr](https://start.spring.io/#!type=maven-project&language=java&platformVersion=2.5.4&packaging=jar&jvmVersion=11&groupId=com.smattme&artifactId=gitlab-ci-demo&name=gitlab-ci-demo&description=Demo%20project%20for%20Spring%20Boot%20deployment%20via%20Gitlab%20CI%2FCD&packageName=com.smattme.gitlab-ci-demo&dependencies=web). After downloading the generated project, the *pom.xml* should look like this: \ ``` org.springframework.boot spring-boot-starter-web org.springframework.boot spring-boot-starter-test test ``` \ Next, let's create a controller mapping for the index endpoint. The endpoint will simply return a hello world string concatenated with the current timestamp: \ ```java @Controller public class IndexController { @GetMapping("/") @ResponseBody public String index() { return "Hello World " + LocalDateTime.now(); } } ``` \ We can test the new endpoint by starting the application and visiting from our browser, we should see the hello world string. Now that we have a working application, we need to create a new project on Gitlab, commit our code locally and push it to the remote repo using the project URL generated by Gitlab. \ Let's execute the following commands from the project's root directory on our local machine: \ ``` git init git add . git commit -m "initial commit" git remote add origin https://gitlab.com/SeunMatt/gitlab-ci-demo.git git push origin master ``` \ Note that your project URL will be slightly different depending on the chosen username and project name. \ ## **Server Setup** For this tutorial, we will create a new [DigitalOcean droplet](https://m.do.co/c/6deb5685e85d), install JRE (Java Runtime Environment) and Nginx on it. \ Nginx will serve as a reverse proxy server that will run on port 80 and forward HTTP traffic to our Spring Boot application that will be running on port 8080 internally. \ We'll be using the Terraform configuration files from [another article](https://smattme.com/blog/technology/how-to-create-a-digitalocean-droplet-for-hosting-spring-boot-app-using-terraform) to provision the droplet. \ ## **Gitlab CI/CD** In this section, we're going to see how we can configure Gitlab to auto-deploy our Spring Boot application whenever we push new changes. \ We'll start by adding .gitlab-ci.yml to our project, then create a new CI/CD user on the server and finally define our pipeline with the necessary scripts. \ ## **Application Building** **In order for us to use Gitlab CI/CD, we need to add a *.gitlab-ci.yml* file to the root of our project directory**. \ The *.gitlab-ci.yml* is a simple plaintext file that defines the jobs we want to execute and what scripts we want to run in each job. Let's create a *.gitlab-ci.yml* file in our project's root directory with the following content: \ ```yaml stages: - build - deploy ``` \ The snippet above defines two stages that should run in the order they appear. We can see stages as a grouping of one or more jobs. The combination of different stages makes a pipeline. \ The name of each stage should reflect the type of job(s) in it. For example, the *build* stage will have jobs that test and package our application as a jar file, whereas the *deploy* stage will contain jobs that copy the generated jar file to the server. \ Let's define a job that will run the Maven package command and generate a single jar file. We will call the job *maven-build*: \ ```yaml maven-build: image: maven:3-jdk-11 stage: build script: "mvn package -B" artifacts: paths: - target/gitlab-ci-demo.jar ``` \ In the snippet above, we configured the job to use a docker container that contains Maven version 3 and JDK 11. \ The *stage* keyword indicates that this job belongs to the *build* stage, and the *script* keyword indicates what command to execute in the docker container once it's ready. \ Another special keyword to take note of is *artifacts*. It instructs Gitlab CI/CD runner to preserve the end result of our *script* command so we can use it in subsequent jobs. In this case, we're keeping the final jar file so we can reference it in the coming sections. \ The complete *.gitlab-ci.yml* file looks like this: \ ```yaml stages: - build - deploy maven-build: image: maven:3-jdk-11 stage: build script: "mvn package -B" artifacts: paths: - target/gitlab-ci-demo.jar ``` \ \ To see this in action, let's commit and push our changes to Gitlab. Gitlab will auto-detect the *.gitlab-ci.yml* file and trigger Gitlab CI/CD runner. **We can monitor the progress of the running jobs on Gitlab by going to the CI/CD menu >> Jobs**: \ ![](https://cdn.hackernoon.com/images/HYXeuI5GYigoQDqgTacbQnweuk72-i5134si.png) We can click on the running button to see the live output from the different commands. Once the build is complete, the running button will change to green and the text will now be *passed*: \ ![](https://cdn.hackernoon.com/images/HYXeuI5GYigoQDqgTacbQnweuk72-ah234k5.png) ## **Application Deployment** For our deployment process, we will first create a CI/CD user on our server, then use the *scp* command to copy the jar file from Gitlab to our server. \ Once the jar file is on our server, we will ssh to the server, move the jar file to the appropriate directory and restart the application service using *systemctl*. \ Let's SSH into the server instance we provisioned earlier and execute the following commands to create and configure the CI/CD user: \ ```bash adduser --quiet --shell $SHELL --disabled-password --gecos 'GitlabCI User' gitlab-ci usermod -a -G sudo gitlab-ci echo 'gitlab-ci:changemepassword' | chpasswd printf 'Match User gitlab-ci\n\tPasswordAuthentication yes\n' >> /etc/ssh/sshd_config systemctl restart sshd echo 'gitlab-ci ALL=(ALL) NOPASSWD: /bin/mv, NOPASSWD: /usr/bin/systemctl, NOPASSWD: /bin/cp' | sudo EDITOR='tee -a' visudo ``` \ First, we created a new user *gitlab-ci* and then we change the user's password to *changemepassword*. Then we updated the *ssh_config* file to allow our new user to authenticate via password and we restart the *sshd* service. \ **The last command is very important, it disables prompting for *sudo* password when we execute any of the following commands: *mv*, *systemtctl* and *cp*.** We need to set this because we'll be using the user in an automated process devoid of human intervention to supply a *sudo* password. \ We need to add *gitlab-ci*'s password as an environment variable on Gitlab so that we can reference it, securely, in our *.gitlab-ci.yml* file. To do that, we need to login to our ***Gitlab account >> Settings >> CI/CD >> Variables***. \ Once we expand the *Variables* section, we will see the button to add a new variable, we should click on it to add the variable: \ ![](https://cdn.hackernoon.com/images/HYXeuI5GYigoQDqgTacbQnweuk72-p7334hl.png) Now that we have created our user and added the user's password to CI/CD variable on Gitlab, let's update our .*gitlab-ci.yml* file with the *deploy* job: \ ```yaml deploy-master: before_script: - apt-get update -qq && apt-get install -y -qq sshpass stage: deploy script: - sshpass -V - export SSHPASS=$CI_USER_PASS - sshpass -e scp -o StrictHostKeyChecking=no target/gitlab-ci-demo.jar gitlab-ci@167.172.188.139:/home/gitlab-ci - sshpass -e ssh -tt -o StrictHostKeyChecking=no gitlab-ci@167.172.188.139 sudo mv /home/gitlab-ci/gitlab-ci-demo.jar /opt/java/webapps - sshpass -e ssh -tt -o StrictHostKeyChecking=no gitlab-ci@167.172.188.139 sudo systemctl restart gitlab-ci-demo.service ``` \ \ In this job definition, we use *before_script* to specify what command should be executed on the server before executing other commands in the script tag. Additionally, in the *script* section, we exported the password for the CI user into the current environment as *SSHPASS*. \ By so doing, *sshpass* will auto-respond to password prompts from *ssh* and *scp* commands with the value of the environment variable *SSHPASS.* \ The SSH commands we executed are pretty straightforward, we first use *scp* to copy the file to the server and then we move the file to the right directory and finally restarted the service using *systemtctl*. \ The complete .*gitlab-ci.yml* fill will have the following contents: \ ```yaml stages: - build - deploy maven-build: image: maven:3-jdk-11 stage: build script: "mvn package -B" artifacts: paths: - target/gitlab-ci-demo.jar deploy-master: before_script: - apt-get update -qq && apt-get install -y -qq sshpass stage: deploy script: - sshpass -V - export SSHPASS=$CI_USER_PASS - sshpass -e scp -o StrictHostKeyChecking=no target/gitlab-ci-demo.jar gitlab-ci@167.172.188.139:/home/gitlab-ci - sshpass -e ssh -tt -o StrictHostKeyChecking=no gitlab-ci@167.172.188.139 sudo mv /home/gitlab-ci/gitlab-ci-demo.jar /opt/java/webapps - sshpass -e ssh -tt -o StrictHostKeyChecking=no gitlab-ci@167.172.188.139 sudo systemctl restart gitlab-ci-demo.service ``` \ \ Let's commit our changes and push. As usual, Gitlab will start the runner automatically and we can monitor the progress of the pipeline. Once the pipeline has passed, we can navigate to our domain/IP address and see our web application running. \ ## **Addendum** \ With what we've set up so far, every time we push to our git repository, Gitlab will build and deploy. What if we want Gitlab to only deploy if we push to master? We can easily achieve that by adding a *rules* tag to the *deploy-master*: \ ```yaml deploy-master: rules: - if: '$CI_COMMIT_BRANCH =~ /^master$/' before_script: - apt-get update -qq && apt-get install -y -qq sshpass stage: deploy script: - sshpass -V - export SSHPASS=$CI_USER_PASS - sshpass -e scp -o StrictHostKeyChecking=no target/gitlab-ci-demo.jar gitlab-ci@167.172.188.139:/home/gitlab-ci - sshpass -e ssh -tt -o StrictHostKeyChecking=no gitlab-ci@167.172.188.139 sudo mv /home/gitlab-ci/gitlab-ci-demo.jar /opt/java/webapps - sshpass -e ssh -tt -o StrictHostKeyChecking=no gitlab-ci@167.172.188.139 sudo systemctl restart gitlab-ci-demo.service ``` \ \ This way, if we push to any other branch other than *master*, only the *maven-build* job will run. However, if we merge or push to the *master* branch both *maven-build* and *deploy-master* will run. \ ## **Conclusion** In this article, we've looked at the basics of setting up a CI/CD pipeline on Gitlab and in the process we deployed a simple Spring Boot application. \ Gitlab CI/CD has more capabilities and features than those mentioned, I encourage you to read the [official documentation](https://docs.gitlab.com/ee/ci/quick_start/) to know more. The complete source code is [available on Gitlab](https://gitlab.com/SeunMatt/gitlab-ci-demo.git). \ :::tip You can follow me on Twitter to see more of my articles and tech musings ::: \ *Also published on: *
