Sample App—Android Unidirectional Data Flow

by Adam HurwitzAugust 15th, 2019

Too Long; Didn't Read

Android Unidirectional Data Flow (UDF) pattern makes the app more readable, easier to develop for, and debug. This post shares both a basic example, and a more complex structure to return multiple processes in one method. For access to features requiring authentication such as saving and dismissing content, you’ll need to implement the 5 easy-ish steps to set up a Firebase project outlined in Coinverse’s Open App — Set Up. The event is processed in the ContentFragment.

People Mentioned

Companies Mentioned

Coin Mentioned

featured image - Sample App—Android Unidirectional Data Flow

Using LiveData in Coinverse

pc — Ned Scher, Waterfall at Yosemite National Park (2015)

Code in the wild is always better to learn from than slide samples. Here I’ll be sharing code from Coinverse’s Open App to showcase a live Unidirectional Data Flow (UDF) pattern which makes the app more readable, easier to develop for, and debug.

The previous post, Android Unidirectional Data Flow with LiveData, outlines the strategy for loading a newsfeed and removing adjacent ads using UDF. This post shares both a basic live example, and a more complex structure to return multiple processes in one method using

MediatorLiveData

By downloading the GitHub project, you can run the code to explore, listen on-the-go, and watch the newsfeed of audiocast and video content. For access to features requiring authentication such as saving and dismissing content, you’ll need to implement the 5 easy-ish steps to set up a Firebase project outlined in Coinverse Open App — Set Up.

pc—My Mom’s Kenya safari (1980s)

Brief UDF OverviewView Events, State, and Effects

Events — Actions created by the user that effect the data displayed, or system level events like the app starting or stopping
State — Info that displays or helps determine a view, created in the business layer of logic
Effects — One time user interface occurrences like navigation, dialogs, and toasts created by the business layer of logic

LiveData

LiveData provides a simple, Android lifecycle aware, toolset to handle automatically updating data for events.

Loading, Content, Error Network Requests

Network requests returned with LCE states wrapped in LiveData objects ensure that the ViewModel business logic layer accounts for the loading, successful content loaded, and error states.


sealed class Lce<T> {
  class Loading<T> : Lce<T>()
  data class Content<T>(val packet: T) : Lce<T>()
  data class Error<T>(val packet: T) : Lce<T>()
}

View Event, State, and Effect — ContentSelected

ContentSelected view event

In this first case when video content is selected in the Adapter it triggers a

ContentSelected

view event in the ContentFragment.kt. The event is processed in the ContentViewModel.kt.

class ContentAdapter(...): PagedListAdapter<Content, ContentAdapter.ViewHolder>(DIFF_CALLBACK) {
    val contentSelected: LiveData<Event<ContentSelected>> get() = _contentSelected
    private val _contentSelected = MutableLiveData<Event<ContentSelected>>()
    private fun createOnClickListener(content: Content) = OnClickListener { view ->
        when (view.id) {
            preview, contentTypeLogo -> _contentSelected.value =
                    Event(ContentSelected(view.getTag(ADAPTER_POSITION_KEY) as Int, content))
        }
    }
}

class ContentFragment : Fragment() {
    private val viewEvent: LiveData<Event<ContentViewEvent>> get() = _viewEvent
    private val _viewEvent = MutableLiveData<Event<ContentViewEvent>>()
    private fun initAdapters() {
        adapter = ContentAdapter(contentViewModel, _viewEvent).apply {
            this.contentSelected.observe(viewLifecycleOwner, EventObserver { contentSelected ->
                _viewEvent.value = Event(ContentSelected(
                        getAdapterPosition(contentSelected.position), contentSelected.content))
            })
        }
    override fun onResume() {
        super.onResume()
        viewEvent.observe(viewLifecycleOwner, EventObserver { event ->
            contentViewModel.processEvent(event)
        })
    }

Because the

contentType

is a video, the ViewModel updates the

contentToPlay

LiveData value of the view state

FeedViewState

with the

ContentToPlay

object containing a video url.

class ContentViewModel(application: Application) : AndroidViewModel(application) {
    fun processEvent(event: ContentViewEvent) {
        when (event) {
            is ContentViewEvent.ContentSelected -> {
                val contentSelected = ContentViewEvent.ContentSelected(event.position, event.content)
                when (contentSelected.content.contentType) {
                    YOUTUBE -> {
                        setContentLoadingStatus(contentSelected.content.id, View.GONE)
                        _viewEffect.value = Event(NotifyItemChanged(contentSelected.position))
                        _feedViewState.value = _feedViewState.value?.copy(contentToPlay =
                        MutableLiveData<Event<ContentResult.ContentToPlay>>().apply {
                            this.value = Event(ContentResult.ContentToPlay(
                                    contentSelected.position, contentSelected.content, "", ""))
                        })
                    }
                }
            }
        }
    }
}

data class FeedViewState(val contentToPlay: LiveData<Event<ContentResult.ContentToPlay>>, ...)


data class ContentToPlay(var position: Int, var content: Content, var filePath: String?,
                             val errorMessage: String) : Parcelable {...}

The Fragment observes the

FeedViewState

contentToPlay

value change, and launches the Fragment to play the video.

class ContentFragment : Fragment() {
    private fun observeViewState() {
        contentViewModel.feedViewState.observe(viewLifecycleOwner, Observer { viewState ->
            viewState.contentToPlay.observe(viewLifecycleOwner, EventObserver { contentToPlay ->
                when (feedType) {
                    MAIN, DISMISSED ->
                        if (childFragmentManager.findFragmentByTag(CONTENT_DIALOG_FRAGMENT_TAG) == null)
                            ContentDialogFragment().newInstance(Bundle().apply {
                                putParcelable(CONTENT_TO_PLAY_KEY, contentToPlay)
                            }).show(childFragmentManager, CONTENT_DIALOG_FRAGMENT_TAG)
                }
            })
        })
    }
}

In addition to the view state being updated in the ViewModel above, a view effect,

NotifyItemChanged

is added and observed in the Fragment to update the RecyclerView cell that has been selected.


class ContentFragment : Fragment() {
    private fun observeViewEffects() {
        contentViewModel.viewEffect.observe(viewLifecycleOwner, EventObserver { effect ->
            when (effect) {
                is ContentViewEffect.NotifyItemChanged -> adapter.notifyItemChanged(effect.position)
            }
        })
    }
}

MediatorLiveData — PlayerLoad

PlayerLoad view event

In the first case the

ContentSelected

event is straightforward because there is a view event and one piece of data, the

ContentToPlay

object, returned in the view state. The

PlayerLoad

event created from the AudioFragment.kt, that retrieves the required information to play an audiocast, is more complicated because it requires two network requests.

class AudioFragment : Fragment() {
    private val viewEvent: LiveData<Event<ContentViewEvent>> get() = _viewEvent
    private val _viewEvent = MutableLiveData<Event<ContentViewEvent>>()
    override fun onCreate(savedInstanceState: Bundle?) {
        ...
        contentToPlay = arguments!!.getParcelable(CONTENT_TO_PLAY_KEY)!!
        if (savedInstanceState == null)
            _viewEvent.value = Event(ContentViewEvent.PlayerLoad(
                    contentToPlay.content.id, contentToPlay.filePath!!,
                    contentToPlay.content.previewImage))
    }
}


class ContentViewModel(application: Application) : AndroidViewModel(application) {
    val playerViewState: LiveData<PlayerViewState> get() = _playerViewState
    private val _playerViewState = MutableLiveData<PlayerViewState>()
    fun processEvent(event: ContentViewEvent) {
        when (event) {
            is ContentViewEvent.PlayerLoad ->
                _playerViewState.value = PlayerViewState(getContentPlayer(
                        event.contentId, event.filePath, event.previewImageUrl))
        }
    }
}

The

PlayerViewState

returned requires retrieving information from two sources for both the mp3 file to play audio, and a converted Bitmap image to display in the notification player.

data class PlayerViewState(val contentPlayer: LiveData<Event<ContentResult.ContentPlayer>>)

sealed class ContentResult {
    data class ContentPlayer(val uri: Uri, val image: ByteArray, val errorMessage: String): ContentResult(), Parcelable {...}
}

The ViewModel could achieve getting both pieces of information by making one network request, waiting for it to return successfully, then make the second request. However, this creates more complicated and nested code. In order for the ViewModel to observe LiveData from the network requests it must be observed by the UI layer in the AudioFragment. The first network request must be observed, then within that method, the second request needs to be observed. This creates nested

LCE

code within the ContentViewModel as well which gets ugly.

A Better Solution With MediatorLiveData

A better solution is to return one LiveData object that contains both the mp3 and Bitmap image using

MediatorLiveData

combineLiveData

takes in two LiveData objects,

getContentUri

returning the mp3, and

bitmapToByteArray

returning the Bitmap image.

combineLiveData

only returns the

ContentPlayer

LiveData once each LiveData item passed into the method has been populated with info, indicated by an emitted boolean in the code below.

class ContentViewModel(application: Application) : AndroidViewModel(application) {
    private fun getContentPlayer(contentId: String, filePath: String, imageUrl: String) =
            getContentUri(contentId, filePath).combineLiveData(bitmapToByteArray(imageUrl)) { a, b ->
                Event(ContentResult.ContentPlayer(a.peekEvent().uri, b.peekEvent().image,
                        getLiveDataErrors(a, b)
                ))
            }
    /**
     * Sets the value to the result of a function that is called when both `LiveData`s have data
     * or when they receive updates after that.
     */
    private fun <T, A, B> LiveData<A>.combineLiveData(other: LiveData<B>, onChange: (A, B) -> T) =
            MediatorLiveData<T>().also { result ->
                var source1emitted = false
                var source2emitted = false
                val mergeF = {
                    val source1Value = this.value
                    val source2Value = other.value
                    if (source1emitted && source2emitted)
                        result.value = onChange.invoke(source1Value!!, source2Value!!)
                }
                result.addSource(this) { source1emitted = true; mergeF.invoke() }
                result.addSource(other) { source2emitted = true; mergeF.invoke() }
            }
    private fun getContentUri(contentId: String, filePath: String) =
            switchMap(repository.getContentUri(contentId, filePath)) { lce ->
                when (lce) {
                    is Lce.Loading -> MutableLiveData()
                    is Lce.Content -> MutableLiveData<Event<ContentResult.ContentUri>>().apply {
                        value = Event(ContentResult.ContentUri(lce.packet.uri, ""))
                    }
                    is Lce.Error -> {
                        Crashlytics.log(Log.ERROR, LOG_TAG, lce.packet.errorMessage)
                        MutableLiveData()
                    }
                }
            }
    private fun bitmapToByteArray(url: String) = liveData {
        emitSource(switchMap(repository.bitmapToByteArray(url)) { lce ->
            when (lce) {
                is Lce.Loading -> liveData {}
                is Lce.Content -> liveData {
                    emit(Event(ContentResult.ContentBitmap(lce.packet.image, lce.packet.errorMessage)))
                }
                is Lce.Error -> liveData {
                    Crashlytics.log(Log.WARN, LOG_TAG,
                            "bitmapToByteArray error or null - ${lce.packet.errorMessage}")
                }
            }
        })
    }
    private fun getLiveDataErrors(a: Event<ContentResult.ContentUri>, b: Event<ContentResult.ContentBitmap>) =
            a.peekEvent().errorMessage.apply { if (this.isNotEmpty()) this }.apply {
                b.peekEvent().errorMessage.also {
                    if (it.isNotEmpty()) this.plus(" " + it)
                }
            }
}

This allows for each of the two methods requiring a network request to handle their LCEs separately, and for one LiveData object to be observed from the

ContentPlayer

in the AudioFragment.

class AudioFragment : Fragment() {
    private lateinit var contentToPlay: ContentResult.ContentToPlay
    private lateinit var contentViewModel: ContentViewModel
    private fun observeViewState() {
        contentViewModel.playerViewState.observe(viewLifecycleOwner, Observer { viewState ->
            viewState?.contentPlayer?.observe(viewLifecycleOwner, EventObserver { contentPlayer ->
                //Launch audiocast!
            })
        })
    }
}

In addition to the live code I’ve created notes on LiveData and the UDF pattern including documentation notes, videos, and samples.
