You know what’s cooler than using an image when building a website? How about making something with HTML and CSS that looks and acts like an image? And you know what, this is super easy now with container queries. In this post, we’re going to make an ad, that looks like an image, with HTML and CSS. Then we’re going to make it act like an image as it gets squished, expanded, and moved to other locations within the document. Ok, let’s check it out! https://youtu.be/5ugwp7HlpGs?embedable=true Ok, so we have this Vans ad in the sidebar of the site that we are building, and it’s currently an image. This makes it difficult to edit; a designer would need to update it and provide us with a new image if something needed to change. Also, we’d probably need multiple versions to use with the source set so that it will look crisp on both high-density and low-resolution displays. So, we’re tasked with converting it to HTML; how can we do this? Some Downsides to Using Images and Viewport Units Well, we could probably use viewport units, but we’d need to add extra code if we were to put the ad in different locations where its dimensions would be different since everything would be based off the viewport and not the container dimensions. So, we could pull it off, but it could get a little messy. Instead, we could use container queries and container query units. Container queries are a little like media queries but based off the dimensions of any given container in the page instead of the overall viewport. Setting up a Container With the CSS Property container-type Ok, let’s check out what we’re starting with. So, it looks pretty good right here but, how does it do as it responds? Uh, the text and borders don’t change size, so it needs some love cause it’s pretty broken as it stands. Now, one thing we’re already doing here is, we’re using an which allows the container to respond as an image would so, that’s all good. aspect-ratio figure {
    aspect-ratio: 1 / 1.5;
} We just need to change all the dimensions for the content to make it respond correctly too. The first step here is to provide a container to monitor our dimensions. This will be our figure element. To use container queries here, we need to define what is known as a containment context. We can do this with the property. For this example, we can use a value of inline size. container-type figure {
    ...
    container-type: inline-size;
} This is going to set up a container that will size things based off its inline size which, in this case, will be the width of the figure. Alright, so now we have a container to monitor, so we’re now free to use container query units. And, there’s lots to choose from. We can use any of these unit values: cqw cqh cqi cqb cqmin cqmax Here, we’re going to use which, I believe, stands for container query inline. One unit is equal to one percent of the width of the container. Ok, that’s all we need; from here, we’re just setting units as needed. cqi cqi Here, we have a couple of custom properties that are used on several elements within this ad. figure {
    ...
    --frameInset: 0.5rem;
    --frameStyle: solid 0.25rem currentColor;
} Let’s start with the amount this frame is inset from the outer edge of the container. Let’s make it three . cqi figure {
    ...
    --frameInset: 3cqi;
} Next, let’s set the thickness of the borders here. In this case, I’m going to use the function to prevent the borders from ever-shrinking under one pixel, but I want them to be dynamic as long as they are larger than that one-pixel value. max So, the first value is one pixel, then the second is the dynamic value. Let’s make it one . cqi figure {
    ...
    --frameStyle: solid max(1px, 1cqi) currentColor;
} Now, for the element, which is the main title, the "Vans" text, let’s make it twenty-five . And, for the space underneath the title, let’s make it three . strong cqi cqi strong {
    font-size: 25cqi;
    padding-bottom: 3cqi;
} Now, let’s move to the "Off the Wall" subtitle. It should be about half the size of the main title, so let’s try twelve . And, for the space above the text, let’s go with three again. cqi cqi em {
    font-size: 12cqi;
    padding-top: 3cqi;
} Alright, for the last piece, the "Since 1966" label, let’s go with a font size of six . And, for the space above and below, we’re using the logical property for which takes up to two values. The first value is the value above the text, and the second value is for the space below. cqi padding-block So, let’s go with two above. And, in our calculation, we’ll leave the as is, but we’ll go with five of additional space. cqi --frameInset cqi time {
    font-size: 6cqi;
    padding-block: 2cqi calc(5cqi + var(--frameInset));
} Ok cool, this looks good. Let’s take a look at how it responds. As we squeeze it, everything is properly responding uniformly like we wanted. It looks a lot like an image. It looks pretty good even when it’s small, and you can see that the borders never shrink below one pixel. Then, when we get into really narrow widths it gets wider, and everything still looks great. How cool is this? One set of styles, and it just works all the way through. As we scale it back and forth, it looks great. Now, what’s even more cool is that we can take our ad mark-up, move it to or main column region here, and everything continues to work just like it would if it were an image. <header><h1>A Brief History of Vans</h1></header>
<div class="content">
    <main>
        <figure>
            <svg viewBox="0 0 256 256">
                <path d="M90.4,67.9C88,69,87.1,70.6,83,80c-4.4,10.2-4.8,12.3-3.1,15"/>
                <path d="M97.4,95.2c-0.6,0.6-1.2,1.7-1.2,2.3s0"/>
            </svg>
            <figcaption>
                <strong>Vans</strong>
                <em>Off the Wall</em>
                <time>Since 1966</time>
            </figcaption>
        </figure>
        ...
    </main>
</div> This is just so nice and so cool. Remember, there’s only one set of styles to pull all of this off. And, zero media queries were involved. There’s quite a bit more to container queries as a whole, so be on the lookout for future posts where I cover different aspects. Want to See It in Action? Check out the demo code and examples of these techniques in the Codepen example below. If you have any questions or thoughts, don’t hesitate to leave a comment. https://codepen.io/brianmtreese/pen/poGegXB?embedable=true
