Hacking my IP camera

May 2nd 2019 74,266 reads
Read on Terminal Reader
react to story with heart
react to story with light
react to story with boat
react to story with money
Papadopoulos Konstantinos HackerNoon profile picture

Papadopoulos Konstantinos

Deauthentication Attack + Physical Security

DISCLAIMER: All data and information provided in this article are for informational purposes only. The main goal is to increase security awareness, teach about information security, countermeasures and give readers information on how to implement a safe and functional system. If you plan to use the information for illegal purposes, please leave this website now.

A few days ago a friend of mine purchased and installed a new Wifi IP camera at his house. Wanting to know how safe the system really was he asked me to take a look and try to “hack” it if possible.

The truth is that the Internet of Things (IoT) is a really hot trend at the moment and a lot of devices are being distributed into the market, many of which are not that reliable or safe.


IP cameras are a nice example of such devices that have invaded many households (or even small businesses in some cases) as a smart solution for surveillance and security.

Getting to the point now, I tried to hack the cameras using two generic techniques, not focusing on finding a specific software vulnerability. The two methods I used were a Deauthentication Attack and a Physical Security Attack. So let’s take a closer look at them:

Deauthentication Attack

A Wi-Fi deauthentication attack is a type of denial-of-service attack that targets communication between a user and a Wi-Fi wireless access point.

With this attack, one can disconnect a client from the access point that it is connected to. For more details check out the following links: https://en.wikipedia.org/wiki/Wi-Fi_deauthentication_attack and https://www.aircrack-ng.org/~~V:/doku.php?id=deauthentication


Sequence diagram for a WiFi deauthentication attack

The Deauthentication Attack falls under the category of pre-connection attacks, meaning you can disconnect any device from any network before connecting to any of these networks and therefore without the need to know the password for the network.

Having said that, it was possible to disconnect the IP camera from the access point it was connected to (without having the AP password, as I mentioned earlier, since there wasn’t even the need to connect to the network), making it useless.

The camera would on normal occasions detect movement and/or noise and notify the user with an email if something was detected. Instead, during the attack the video feedback of the IP camera app was frozen and no notifications were sent when we triggered the sensors with motion and sound.

Below is the code I used for this simple attack (for a more detailed analysis on how to perform a deauthentication attack there is a great article on Hacker Noon):

Deauthenticating specifically the IP camera (only one client)

aireplay-ng --deauth [number of deauth packets] -a [AP MAC address] -c [IP camera MAC address] [interface]
Ex: aireplay-ng --deauth 1000 -a 11:22:33:44:55:66 -c 00:AA:11:22:33:44 mon0

You can possibly find the MAC address of the IP camera if you know the device’s brand since the first 6-digits of a MAC address identify the manufacturer (https://macvendors.com). You can also try to speculate which is the AP’s MAC address by the name of the SSID. Otherwise, you can use a more wide attack with the code below.

Deauthenticating all clients in a specific network

aireplay-ng --deauth [number of packets] -a [AP MAC address] [interface]

Ex: aireplay-ng --deauth 1000 -a 11:22:33:44:55:66 mon0

That wouldn't be the case of course if the camera app was programmed to periodically check the connection with the router/device and report a lost connection by sending an email to the user for example.

It is also important to point out, that if the IP camera had a wired connection and not a wireless one, this attack would not be possible. When using wireless communication we should always keep in mind that the medium is air and air is accessible to all (thus more “hackable”).

Physical Security Attack

Physical security describes security measures that are designed to deny unauthorized access to facilities, equipment and resources and to protect personnel and property from damage or harm (such as espionage, theft, or terrorist attacks).


Distribution frame

It doesn’t do much if you have top quality security “software-wise”, but the physical devices you are trying to secure are not themselves placed somewhere safe. In our case, the local distribution frame box, where the internet-telephone cables terminate, was in front of my friend's house and unlocked. It would be very easy for someone to intervene in the cabinet, cut the cables and remove internet connection thus disabling the IP camera.

Without an Internet connection, the user would be under the illusion that everything is secure since he wouldn’t get an email notification (like he is supposed to if something is detected), and that his IP camera would alert him as soon as someone tried to invade into his house, while the camera would have just stopped working without any warning.

Below is an extract of a previous article I wrote, “IoT without Internet… how does that affect its functionality?”, proposing a solution to this issue:

That is why I am proposing that IoT devices that are connected to the Internet should all include a basic feature. That feature is to notify when internet connectivity is lost from the device. If at the side of the IoT device there is no internet access, of course, there aren’t any means of sending an alert. That is why I am suggesting that at the client side app there should be monitoring (at a rate that will be determined by the severity of the device’s task and need to be online) of the connection between device and controller app.

In our previous IP camera example, the i.e. smartphone app would have detected the loss of internet connectivity of the home router, the user would have been sent a notification, thus taking the appropriate measures to resolve the problem (calling the ISP, sending someone to check, etc).
