When I decided to build an open-source earlier this year and to build it in C# I needed a template for building the transport layer of the server. I was particularly happy when I checked out the TechEmpower benchmarks in which ASP.NET Kestrel currently ranks 3rd in plaintext benchmark scores with 7,023,107 responses per second. In this post, I will demonstrate how a high-performance TCP server can be built and I will do so by borrowing some ideas from Kestrel. Telegram Server The code presented leverages low allocation asynchronous programming patterns and pooling to be blazing fast. Socket operations in .NET are described by which is a reusable object that provides a callback-based asynchronous pattern. First this pattern needs to be wrapped with an async one by implementing the interface so that allocations for the asynchronous path can be avoided. SocketAsyncEventArgs IValueTaskSource AwaitableEventArgs.cs //From: https://github.com/dotnet/aspnetcore/blob/main/src/Servers/Kestrel/Transport.Sockets/src/Internal/SocketAwaitableEventArgs.cs#L10-L77
public class AwaitableEventArgs : SocketAsyncEventArgs, IValueTaskSource<int>
{
    private ManualResetValueTaskSourceCore<int> _source;

    public AwaitableEventArgs() :
        base(unsafeSuppressExecutionContextFlow: true)
    {
    }

    protected override void OnCompleted(SocketAsyncEventArgs args)
    {
        if (SocketError != SocketError.Success)
        {
            _source.SetException(new SocketException((int)SocketError));
        }

        _source.SetResult(BytesTransferred);
    }

    public int GetResult(short token)
    {
        int result = _source.GetResult(token);
        _source.Reset();
        return result;
    }

    public ValueTaskSourceStatus GetStatus(short token)
    {
        return _source.GetStatus(token);
    }

    public void OnCompleted(Action<object?> continuation, object? state, short token,
        ValueTaskSourceOnCompletedFlags flags)
    {
        _source.OnCompleted(continuation, state, token, flags);
    }
} This is rewritten from the original implementation and the main difference is this version uses for the sake of simplicity while the original one uses a thinner custom implementation of the interface. here ManualResetValueTaskSourceCore IValueTaskSource Needed and implementations are derived from the above. They first set the buffer for the and then call the respective or method of the which returns true if the I/O operation is pending in which case can be the for the returned as the base class implements the interface. When is fired, awaited will either return the bytes received/sent or throw an . However if the above call returns false it means the I/O operation completed synchronously and synchronous path needs to be handled. Receiver Sender AwaitableEventArgs SocketAsyncEventArgs SendAsync ReceiveAsync Socket Receiver/Sender source ValueTask OnCompleted(SocketAsyncEventArgs args) ValueTask Exception Receiver.cs //From: https://github.com/dotnet/aspnetcore/blob/main/src/Servers/Kestrel/Transport.Sockets/src/Internal/SocketReceiver.cs
public class Receiver : AwaitableEventArgs
{
   private short _token;
   public ValueTask<int> ReceiveAsync(Socket socket, Memory<byte> memory)
   {
      SetBuffer(memory);
      if (socket.ReceiveAsync(this))
      {
         return new ValueTask<int>(this, _token++);
      }

      var transferred = BytesTransferred;
      var err = SocketError;
      return err == SocketError.Success
         ? new ValueTask<int>(transferred)
         : ValueTask.FromException<int>(new SocketException((int)err));
   }
} also needs to handle the buffer being a as it will be the case. Sender ReadOnlySequence<byte> Sender.cs //From: https://github.com/dotnet/aspnetcore/blob/main/src/Servers/Kestrel/Transport.Sockets/src/Internal/SocketSender.cs
public class Sender: AwaitableEventArgs
{
    private short _token;
    private List<ArraySegment<byte>>? _buffers;
    public ValueTask<int> SendAsync(Socket socket, in ReadOnlyMemory<byte> data)
    {
        SetBuffer(MemoryMarshal.AsMemory(data));
        if (socket.SendAsync(this))
        {
            return new ValueTask<int>(this, _token++);
        }

        var transferred = BytesTransferred;
        var err = SocketError;
        return err == SocketError.Success
            ? new ValueTask<int>(transferred)
            : ValueTask.FromException<int>(new SocketException((int)err));
    }
    public ValueTask<int> SendAsync(Socket socket, in ReadOnlySequence<byte> data)
    {
        if (data.IsSingleSegment)
        {
            return SendAsync(socket, data.First);
        }
        _buffers ??= new List<ArraySegment<byte>>();
        foreach (var buff in data)
        {
            if (!MemoryMarshal.TryGetArray(buff, out var array))
            {
                throw new InvalidOperationException("Buffer is not backed by an array.");
            }

            _buffers.Add(array);
        }

        BufferList = _buffers;

        if (socket.SendAsync(this))
        {
            return new ValueTask<int>(this, _token++);
        }

        var transferred = BytesTransferred;
        var err = SocketError;
        return err == SocketError.Success
            ? new ValueTask<int>(transferred)
            : ValueTask.FromException<int>(new SocketException((int)err));
    }
    public void Reset()
    {
        if (BufferList != null)
        {
            BufferList = null;

            _buffers?.Clear();
        }
        else
        {
            SetBuffer(null, 0, 0);
        }
    }
} A lightweight implementation is also needed. This is backed by a and leverages for keeping a cheaper atomic count. SenderPool ConcurrentQueue Interlocked SenderPool.cs //From: https://github.com/dotnet/aspnetcore/blob/main/src/Servers/Kestrel/Transport.Sockets/src/Internal/SocketSenderPool.cs
public class SenderPool : IDisposable
{
    private readonly int MaxNumberOfSenders;
    private int _count;
    private readonly ConcurrentQueue<Sender> _senders = new();
    private bool _disposed = false;

    public SenderPool(int maxNumberOfSenders = 128)
    {
        MaxNumberOfSenders = maxNumberOfSenders;
    }

    public Sender Rent()
    {
        if (_senders.TryDequeue(out var sender))
        {
            Interlocked.Decrement(ref _count);
            sender.Reset();
            return sender;
        }

        return new Sender();
    }

    public void Return(Sender sender)
    {
        if (_disposed || _count >= MaxNumberOfSenders)
        {
            sender.Dispose();
        }
        else
        {
            Interlocked.Increment(ref _count);
            _senders.Enqueue(sender);
        }
    }

    public void Dispose()
    {
        if (_disposed) return;
        _disposed = true;
        while (_senders.TryDequeue(out var sender))
        {
            sender.Dispose();
        }
    }
} Now this is the part things start to get more fun. Writing a TCP server requires buffering and parsing streaming data which is a complex task and can be tedious and hard to get right the first time around. Luckily is designed exactly for this problem. It reduces code complexity and allows high performance parsing of streaming data. I highly recommend anyone reading this to read the original as well to get a better grasp. Next piece of code will leverage this library. System.IO.Pipelines article Connection.cs //From: https://github.com/dotnet/aspnetcore/blob/main/src/Servers/Kestrel/Transport.Sockets/src/Internal/SocketConnection.cs
public class Connection : IAsyncDisposable
{
    private const int MinBuffSize = 1024;
    private readonly Socket _socket;
    private readonly Receiver _receiver;
    private Sender? _sender;
    private readonly SenderPool _senderPool;
    private Task? _receiveTask;
    private Task? _sendTask;
    private readonly Pipe _transportPipe;
    private readonly Pipe _applicationPipe;
    private readonly object _shutdownLock = new object();
    private volatile bool _socketDisposed;
    public PipeWriter Output { get;}
    public PipeReader Input { get;}

    public Connection(Socket socket, SenderPool senderPool)
    {
        _socket = socket;
        _receiver = new Receiver();
        _senderPool = senderPool;
        _transportPipe = new Pipe();
        Output = _transportPipe.Writer;
        _applicationPipe = new Pipe();
        Input = _applicationPipe.Reader;
    }

    public void Start()
    {
        try
        {
            _sendTask = SendLoop();
            _receiveTask = ReceiveLoop();
        }
        catch (Exception e)
        {
            Console.WriteLine(e);
            throw;
        }
    }
    private async Task SendLoop()
    {
        try
        {
            while (true)
            {
                var result = await _transportPipe.Reader.ReadAsync();
                if (result.IsCanceled)
                {
                    break;
                }
                var buff = result.Buffer;
                if (!buff.IsEmpty)
                {
                    _sender = _senderPool.Rent();
                    await _sender.SendAsync(_socket, result.Buffer);
                    _senderPool.Return(_sender);
                    _sender = null;
                }
                _transportPipe.Reader.AdvanceTo(buff.End);
                if (result.IsCompleted)
                {
                    break;
                }
            }
        }
        catch (Exception e)
        {
            Console.WriteLine(e);
            throw;
        }
        finally
        {
            _applicationPipe.Writer.Complete();
            Shutdown();
        }
    }
    private async Task ReceiveLoop()
    {
        try
        {
            while (true)
            {
                var buff = _applicationPipe.Writer.GetMemory(MinBuffSize);
                var bytes = await _receiver.ReceiveAsync(_socket, buff);
                if (bytes == 0)
                {
                    break;
                }
                _applicationPipe.Writer.Advance(bytes);
                var result = await _applicationPipe.Writer.FlushAsync();
                if (result.IsCanceled || result.IsCompleted)
                {
                    break;
                }
            }
        }
        catch (Exception e)
        {
            Console.WriteLine(e);
            throw;
        }
        finally
        {
            _applicationPipe.Writer.Complete();
            Shutdown();
        }
    }

    public async ValueTask DisposeAsync()
    {
        _transportPipe.Reader.Complete();
        _applicationPipe.Writer.Complete();
        try
        {
            if (_receiveTask != null)
            {
                await _receiveTask;
            }

            if (_sendTask != null)
            {
                await _sendTask;
            }
        }
        finally
        {
            _receiver.Dispose();
            _sender?.Dispose();
        }
    }
    public void Shutdown()
    {
        lock (_shutdownLock)
        {
            if (_socketDisposed)
            {
                return;
            }
            _socketDisposed = true;
            try
            {
                _socket.Shutdown(SocketShutdown.Both);
            }
            finally
            {
                _socket.Dispose();
            }
        }
    }
} The class has: Connection a for the connection Receiver references to the and the Socket SenderPool a for transport and another one for the application Pipe and finally two loops for sending and receiving. So how do we send/receive data? The for the transport pipe is exposed as the public property and the polls for data written to this pipe renting a before every send operation returning it to the pool after completion. The for the application pipe is exposed as the public property and the basically gets a buffer from this pipe and receives into it. Then there is some cleanup code. This again is a simplified version of the original Kestrel implementation. PipeWriter Output SendLoop Sender PipeReader Input ReceiveLoop TCP Echo At this point a TCP Echo server needs just a few more lines of code. Following simply copies back the received bytes: Program.cs var senderPool = new SenderPool(1024);
var listenSocket = new Socket(SocketType.Stream, ProtocolType.Tcp);
listenSocket.Bind(new IPEndPoint(IPAddress.Loopback, 8989));
listenSocket.Listen(128);
while (true)
{
    var socket = await listenSocket.AcceptAsync();
    var connection = new Connection(socket, senderPool);
    _ = ProcessConnection(connection);
}

static async Task ProcessConnection(Connection connection)
{
    connection.Start();
    while (true)
    {
        var result = await connection.Input.ReadAsync();
        if (result.IsCanceled)
        {
            break;
        }
        var buff = result.Buffer;
        if (!buff.IsEmpty)
        {
            if (buff.IsSingleSegment)
            {
                await connection.Output.WriteAsync(buff.First);
            }
            else
            {
                foreach (var mem in buff)
                {
                    await connection.Output.WriteAsync(mem);
                }
            }
        }
        connection.Input.AdvanceTo(buff.End, buff.End);
        if (result.IsCompleted)
        {
            break;
        }
    }
    connection.Shutdown();
    await connection.DisposeAsync();
} This will serve as a base for a High Performance TCP Server but of course more measurements and optimizations might be necessary. Code above omits some more advanced implementation details for the sake of simplicity. Some of them are outlined below. schedule-me-not When creating a , it’s possible to specify a and ‘s for the reader and the writer via the and Kestrel uses a custom here along with a lock-free . implementation as well supports a as to have fine-grained control where the I/O happens. Following pseudo-code tries to simplify and outline how Kestrel utilizes schedulers. Pipe MemoryPool<byte> PipeScheduler PipeOptions PinnedBlockMemoryPool IOQueue SocketAwaitableEventArgs PipeScheduler var memoryPool = new PinnedBlockMemoryPool();
var applicationScheduler = PipeScheduler.ThreadPool;
var transportScheduler = new IOQueue();
var socketScheduler = transportScheduler;

var receiver = new SocketReceiver(socketScheduler);

var InputOptions = new PipeOptions(memoryPool,
        applicationScheduler, transportScheduler,
        maxReadBufferSize, maxReadBufferSize / 2,
        useSynchronizationContext: false),

var OutputOptions = new PipeOptions(memoryPool,
        transportScheduler, applicationScheduler,
        maxWriteBufferSize, maxWriteBufferSize / 2,
        useSynchronizationContext: false),

var SocketSenderPool = new SocketSenderPool(PipeScheduler.Inline), It can also be seen above and is used for flow control. This is when processing data is more complicated than simply sending it back in which case the reader would allocate more and more memory. When is set however and if the amount of data in the pipe is more than set value will not be completed until it is less than again. PauseWriterThreshold ResumeWriterThreshold PauseWriterThreshold PipeWriter.FlushAsync ResumeWriterThreshold Where to go from here? As I was writing the code for this post some preliminary benchmarks showed that the code presented is actually somewhat slower than a basic Echo Server. Netty would reach 115000 requests per second while code above would reach 110000. It however is a well-established framework, so it shouldn’t be too surprising. This just shows that some proper benchmarks are needed along with profiling and optimization. Netty The full source can be viewed at . the GitHub repo
