Automating SwaggerHub User Management with Azure AD, Microsoft Graph, and Azure Functions

\ :::tip If you’re not using SwaggerHub but have other solutions that you need to automate user management from Azure AD, then you can still follow along and just swap out SwaggerHub APIs for your specific solution user management APIs ::: ## Key Takeaways * Microsoft Graph Change Notifications can be used to get events on created, updated, or deleted resources across Microsoft 365 * Combine change notifications, Azure Functions, and the SwaggerHub User Management API to have automated user management between Azure Active Directory (AD) and SwaggerHub (or your solution) * Easily deploy an automated solution to Azure with ARM templates and GitHub Actions * User Management API for SwaggerHub supports several operations to help organizations automate the provisioning and management of users ## Intro The API industry is accelerating as organizations increase their participation in the digital economy. Most organizations see software delivery as a core competency. The prevalence of microservices and as-a-service value propositions are fueling the shift from monolithic systems to a more distributed and composable architecture. All of this leads to a proliferation of APIs. \ APIs are the cornerstone for value exchange both inside and outside of the enterprise. API quality and developer experience (DX) is no longer optional. An API First approach must be backed by tools and processes to empower teams to automate standards, governance, and quality throughout the delivery of an API product. This is crucial for meeting customer expectations and accommodating scalability requirements on the producer side. \ SwaggerHub is a popular solution for managing API design, collaboration, and development. Until recently, management of API designers, owners, and collaborators had to be performed entirely within the SwaggerHub user interface. Now, with the recent delivery of the [User Management API](https://app.swaggerhub.com/apis-docs/swagger-hub/user-management-api/v1), management can be automated and integrated more holistically with existing identity and access management practices. \ As API estates increase across the enterprise landscape, so do the number of stakeholders involved in the API lifecycle. This highlights the importance of effective license and user management. Left unmanaged, organizations risk unauthorized access to their API artifacts, and potential cost implications. ## Use Case – SwaggerHub User Management via Azure AD Many organizations use Azure AD identity and access management for authentication and as a way to control employee access to resources and applications. Many businesses require that application access be centrally provisioned from the Azure AD tenant or via an HR system linked to the identity tenant. \ In this article, I demonstrate how to automate SwaggerHub user management based on the employee assignment to Azure AD groups. This eliminates the need to perform user management for API stakeholders directly within SwaggerHub. \ **Benefits this brings:** * Onboarded users will automatically get access to SwaggerHub, assuming the appropriate Azure AD group membership is applied * Users leaving the company are automatically removed from SwaggerHub once their group memberships are revoked * Users changing roles, or moving between departments or teams, will have their SwaggerHub access modified based on the changes in Azure AD group assignments * Improved security by reducing the likelihood of unauthorized access to your APIs caused by dual user management (e.g., if a user who left the organization was not removed from SwaggerHub) * Improved license management \ ## Solution Component Overview As we’re dealing with Azure AD, I provide an automation solution that leverages other Microsoft components. ![Figure 1 - High-level component architecture](https://cdn.hackernoon.com/images/PpopDh7l1CQ6N7nMbjq72sFVAUf1-zb239xm.png) \ The main components used in the solution are: * [Microsoft Azure AD](https://azure.microsoft.com/en-us/services/active-directory/#overview) – a universal platform to manage and secure identities which provides single sign-on and multi-factor authentication. * [Microsoft Graph](https://docs.microsoft.com/en-us/graph/overview) – a gateway to data and intelligence across the Microsoft suite, using REST APIs and client libraries. * [Azure Functions](https://docs.microsoft.com/en-us/azure/azure-functions/) – Microsoft’s serverless compute service. * [SwaggerHub](https://swagger.io/tools/swaggerhub/) - the collaborative design and documentation platform for teams and individuals working with the OpenAPI Specification * [SwaggerHub User Management API](https://support.smartbear.com/swaggerhub/docs/api/user-management.html) – an administrative API that allows organizations to automate the on-boarding and off-boarding of users \ The solution consists of two Azure Functions which interact with the Microsoft Graph API and the SwaggerHub User Management API. The first function, `SubscriptionManager`**,** manages subscriptions to Microsoft Graph change notifications. \ ![Figure 2 - Subscription creation and renewal flow](https://cdn.hackernoon.com/images/PpopDh7l1CQ6N7nMbjq72sFVAUf1-d933903.png) \ The second function, `SwaggerHubUserManager`, receives notifications (or events) from the Microsoft Graph and parses them. When appropriate, it will interact with the SwaggerHub User Management API to create, update, or delete users. ![Figure 3 - Flow showing how SwaggerHub will be updated based on AD changes](https://cdn.hackernoon.com/images/PpopDh7l1CQ6N7nMbjq72sFVAUf1-wu439co.png) \ :::info Before we jump into the details of the solution, let’s understand Microsoft Graph Change Notifications. ::: ### Microsoft Graph Change Notifications The Microsoft Graph REST API uses a webhook mechanism to deliver change notifications to a subscribed client. When the resource/entity subscribed for is created, updated, or deleted, Microsoft Graph submits an HTTP POST to the specified client endpoint. The client endpoint listens for these messages and acts on them by executing logic defined based on business requirements. \ A client application can get notifications about messages, events, contacts, users, groups, conversations, OneDrive files, alerts, etc. In many cases, it’s beneficial to trigger application behavior based on changes or events, and it removes the need for other implementations like polling. \ A client application must have a valid subscription in order to receive a change notification. Subscriptions to change notifications expire, and [subscription lifetimes](https://docs.microsoft.com/en-us/graph/api/resources/subscription?view=graph-rest-1.0) vary. Subscription lifecycles need to be managed to ensure that client applications continue to receive notifications. \ ## Azure Application and AD Group Setup :::info To deploy or run the solution locally, you need to have an *Azure subscription* and an *Azure AD tenant* setup. ::: To ensure the Azure Functions can interact with the Microsoft Graph API, you need to register an application within your Azure subscription and assign the necessary Microsoft Graph API permission. ### Register Azure Application To register an application within the Azure portal: 1. Login to the [Azure Portal](https://portal.azure.com/) 2. Search for **App Registrations** using the global search bar (or via *Menu > All services > App Registrations*) 3. Click **New Registration** 4. Set a **Name** for your application (e.g., MSGraph Notifications for SwaggerHub) 5. Depending on your multi-tenancy requirements, choose the **supported account types**. If unsure, choose the *Accounts in this organizational directory only* option 6. Set a **Redirect URI** (e.g., `http://localhost`) 7. Click **Register** :::tip Be sure to record your **Application (client) ID** and **Directory (tenant) ID** from the application overview section as you'll need them later. ::: ### Grant Permission on Microsoft Graph You want this application to receive *change notifications* from the Microsoft Graph when the *Groups* resource changes, and to be able to retrieve information on the *users* added/removed from a group. To do this, the following permissions are required: * `Group.Read.All` - Read all groups * `User.Read.All` - Read all users' full profiles \ To add the permissions to your registered app: 1. Navigate to the **API permissions** menu option beneath the *Manage* section of the left-hand navigation menu 2. Click **Add a permission** 3. Choose **Microsoft Graph** from the *Microsoft APIs > Commonly used Microsoft APIs* section 4. Choose **Application permissions** as your application will be invoking these APIs using the *client_credentials* flow and not on behalf of a user 5. Under Group permissions, select `Group.Read.All` 6. Under User permissions, select `User.Read.All` 7. Click **Add permissions** 8. Click **Grant admin consent for** and click **Yes** on the Grant admin consent confirmation dialog ### Azure AD Group Structures Granting or revoking certain group memberships within Azure AD should add, update, or remove users from SwaggerHub. For this to work, you need to configure the representative groups within your Azure AD tenant. \ The AD Group creation strategy will change, depending on how many SwaggerHub organizations you have. This solution supports both single and multi-organization setups. #### Single SwaggerHub Organization If you have a single SwaggerHub organization, the recommended group setup is to create an AD Group per SwaggerHub role. | **SwaggerHub Organization** | **SwaggerHub Role** | **AD Group Name (*example only - follow your own naming conventions*)** | **Description** | |----|----|----|----| | **Org 1** | CONSUMER | ADG-SWAGGERHUB-CONSUMERS | AD Group for consumers that will get access to SwaggerHub | | **Org 1** | DESIGNERS | ADG-SWAGGERHUB-DESIGNERS | AD Group for designers that will get access to SwaggerHub | | **Org 1** | OWNERS | ADG-SWAGGERHUB-OWNERS | AD Group for owners that will get access to SwaggerHub | #### Multiple SwaggerHub Organizations If you have multiple organizations within SwaggerHub, you have a few options for structuring your organizational groups. You can linearly extend the examples above and be very clear about setting up your groups per organizations - for instance, including the SwaggerHub organization name in the Azure AD Group name (e.g., **ADG-SwaggerHub- - **). \ Assuming you have two organizations, resulting in six AD groups: | **SwaggerHub Organization** | **SwaggerHub Role** | **AD Group Name (*example only - follow your own naming conventions*)** | **Description** | |----|----|----|----| | **Org 1** | CONSUMER | ADG-SWAGGERHUB-ORG1-CONSUMERS | AD Group for consumers that will get access to SwaggerHub | | **Org 1** | DESIGNERS | ADG-SWAGGERHUB-ORG1-DESIGNERS | AD Group for designers that will get access to SwaggerHub | | **Org 1** | OWNERS | ADG-SWAGGERHUB-ORG1-OWNERS | AD Group for owners that will get access to SwaggerHub | | **Org 2** | CONSUMER | ADG-SWAGGERHUB-ORG2-CONSUMERS | AD Group for consumers that will get access to SwaggerHub | | **Org 2** | DESIGNERS | ADG-SWAGGERHUB-ORG2-DESIGNERS | AD Group for designers that will get access to SwaggerHub | | **Org 2** | OWNERS | ADG-SWAGGERHUB-ORG2-OWNERS | AD Group for owners that will get access to SwaggerHub | Alternatively, you can define your own group structures based on your organizational domains, and map them to the existing SwaggerHub Orgs which can be less verbose and more intuitive. Other configuration examples for multiple organization setups can be found in the [GitHub](https://github.com/frankkilcommins/AzureAD-SwaggerHub-UserManagement) repo. Your Azure AD administrator can set up the appropriate AD groups based on your chosen strategy. ## Solution Walkthrough The full source code for the solution ([here](https://github.com/frankkilcommins/AzureAD-SwaggerHub-UserManagement/tree/main/src)) can be deployed to your Azure subscription using the deployment options described below. \ The `.NET 5` solution, predominately consists of two Azure functions with some `Models` and supporting `Services` for interacting with the Microsoft Graph API and the SwaggerHub User Management API. ### SubscriptionManager Azure Function This is a `TimerTrigger` function which runs daily at noon based on the configured [CRON expression](https://en.wikipedia.org/wiki/Cron) `‘0 0 12 * * *’`. It manages the change notification subscription lifecycle with the Microsoft Graph. It creates a new subscription if one does not exist; otherwise, it will renew an existing subscription if it’s due to expire within seven days, which means our `SwaggerHubUserManager` function won’t miss any change notifications. ![Figure 4 - Class diagram representing the Subscription Manager Function and Services](https://cdn.hackernoon.com/images/PpopDh7l1CQ6N7nMbjq72sFVAUf1-5153988.png) \ Interaction with the Microsoft Graph API is through the [GraphService](https://github.com/frankkilcommins/AzureAD-SwaggerHub-UserManagement/blob/main/src/Services/GraphService.cs) class, which is a trimmed version of MS Graph SDK capabilities for the needs of the solution. It initializes a `GraphServiceClient` instance and takes care of obtaining the OAuth 2.0 token which is required to invoke the MS Graph endpoints. \ As visible in Figure 4 above, the service offers methods to manage the lifecycle of the subscription, and the `SubscriptionManager` function interacts with the service methods accordingly (see snippet below): ```csharp try { // Get subscriptions var longestToLiveSubscription = await _graphService.GetSubscriptionWithLongestTimeToLive(); // if no subscription then create subscription if(longestToLiveSubscription == null) { logger.LogInformation($"No subscription found >> creating new subscription..."); await _graphService.CreateChangeNotificationSubscription(); } else { // if subscription will expire in less than a week renew the subscription if(DateTime.UtcNow.AddDays(7) > longestToLiveSubscription.ExpirationDateTime) { logger.LogInformation($"Subscription {longestToLiveSubscription.Id} will expire within 7 days >> renewing subscription..."); await _graphService.RenewSubscription(longestToLiveSubscription); } else { logger.LogInformation($"Subscription {longestToLiveSubscription.Id} will expire at [{longestToLiveSubscription.ExpirationDateTime}] >> no need to renew at this time..."); } } } catch(Exception ex) { logger.LogError($"Exception thrown: {ex.Message}"); } ``` \ Alternatively, you could perform similar subscription management manually by invoking the MS Graph APIs and repeating this activity prior to subscription expiry. \ **Get Subscriptions** ``` curl --location --request GET 'https://graph.microsoft.com/v1.0/subscriptions/' \ --header 'Content-Type: application/json' \ --header 'Authorization: Bearer PUT_YOUR_TOKEN_HERE' ``` **Create Subscriptions** ```javascript curl --location --request GET 'https://graph.microsoft.com/v1.0/subscriptions/' \ --header 'Content-Type: application/json' \ --header 'Authorization: Bearer PUT_YOUR_TOKEN_HERE' \ --data-raw '{ "changeType": "updated,deleted", "notificationUrl": "URL to endpoint that will receive events", "resource": "groups", "expirationDateTime": "2021-12-30T22:19:41.561Z", "clientState": "*someSecretKnownByPubandSub*" }' ``` **Update Subscriptions** ```javascript curl --location -g --request GET 'https://graph.microsoft.com/v1.0/subscriptions/{id}' \ --header 'Content-Type: application/json' \ --header 'Authorization: Bearer PUT_YOUR_TOKEN_HERE' \ --data-raw '{ "expirationDateTime": "2021-12-01T22:19:41.561Z" }' ``` ### SwaggerHubUserManager Azure Function This `HTTPTrigger` function is the heart of the solution and is called by the Microsoft Graph webhook anytime there is a *change* to group memberships within the Azure AD tenant. The function parses the received change notification and determines if it’s required to process the change notification. To decide, it leverages the tenant specific configuration that’s set up in the `GroupConfiguration.json` file. If the received change notification relates to a group referenced in the configuration file, it goes back to the Microsoft Graph to retrieve specific details on the users which were added to or removed from the AD group membership. Then it calls the SwaggerHub User Management API to ensure that changes are automatically reflected in the appropriate SwaggerHub organizations. ![Figure 5 - Class diagram representing the SwaggerHubUserManager function and underlying services](https://cdn.hackernoon.com/images/PpopDh7l1CQ6N7nMbjq72sFVAUf1-9w6392s.png) Interaction with the SwaggerHub User Management API is through the [SwaggerHubUserManagementService](https://github.com/frankkilcommins/AzureAD-SwaggerHub-UserManagement/blob/main/src/Services/SwaggerHubUserManagementService.cs) class. This service prepares the requests to, and handles the responses from, the [SwaggerHubRepository](https://github.com/frankkilcommins/AzureAD-SwaggerHub-UserManagement/blob/main/src/Repositories/SwaggerHubRepository.cs) class. This class is a wrapper around an `HTTPClient` exposing generic `GET`, `POST`, `PATCH`, and `DELETE` methods and sets some base SwaggerHub settings like apiKey, base URL, API path, and API version. This repository class simplifies the API calls for the upper service layer, so that it doesn’t need to negotiate an HTTP request. :::info It’s worth also noting that any endpoint registered to receive change notification webhook calls from the Microsoft Graph must be able to acknowledge the subscription registration request within 200ms. Additionally, it MUST return the validation code which was issued in the verification request. ::: \ The following snippet demonstrates how the `SwaggerHubUserManagerFunction` acknowledges the verification request based on the existence of a `validationToken` query parameter. The `validationToken` received must be returned in plain text. ```csharp // basic validation of request var query = System.Web.HttpUtility.ParseQueryString(req.Url.Query); string token = query["validationToken"]; if(!string.IsNullOrEmpty(token)) { //acknowledge back with validation token logger.LogInformation($"Validation Token: {token}"); var ackResponse = req.CreateResponse(HttpStatusCode.OK); ackResponse.Headers.Add("Content-Type", "text/plain; charset=utf-8"); ackResponse.WriteString(token); return ackResponse; } ``` \ The solution can support single SwaggerHub organization configurations, as well as complex multi-organizational setups as discussed in the “Azure AD Group Structures” section above. Once you have finalized the appropriate setup, you need to populate the `GroupConfiguration.json` file to reflect the setup. This acts as a link between your Azure AD tenant and your SwaggerHub organization, and it’s leveraged by the Azure function to: * determine the list of Azure AD groups that it reacts to when a *notification* is received from MS Graph * determine what SwaggerHub *organization* and *role* combination to use when creating or modifying a user in SwaggerHub \ A sample configuration file representing a three group single organization setup might look like: ```json { "GroupConfiguration": { "activeDirectoryGroups": [ { "objectId": "bc9ae6d5-1ccf-45dd-b56f-9ca020348802", "name": "ADG-SWAGGERHUB-DESIGNERS", "swaggerHubRole": "DESIGNER", "organizations": [ { "name": "frank-kilcommins" } ] }, { "objectId": "afd8b023-331d-4fc4-84f7-f5a4654cbbbd", "name": "ADG-SWAGGERHUB-CONSUMERS", "swaggerHubRole": "CONSUMER", "organizations": [ { "name": "frank-kilcommins" } ] }, { "objectId": "126f28b7-a2b6-4a87-af23-edb61af80317", "name": "ADG-SWAGGERHUB-OWNERS", "swaggerHubRole": "CONSUMER", "organizations": [ { "name": "frank-kilcommins" } ] } ] } } ``` The main object configured is the `activeDirectoryGroup` object which stores the mapping details, allowing the solution to manage SwaggerHub organization(s) based on a particular Azure AD Group. | **Property** | **Property (nested)** | **Required** | **Description** | |----|----|----|----| | **objectId** | | yes | The objectId of the AD Group as autogenerated by the tenant | | **name** | | no | The name of the AD Group as set within the tenant | | **swaggerHubRole** | | yes | The role that will be set in SwaggerHub for users receiving membership to the AD Group referenced by the objectId. Allowed options are CONSUMER, DESIGNER or OWNER | | **organizations** | | yes | The SwaggerHub organizations mapped or linked to the AD Group referenced by the objectId | | | name | yes | The **name** of the organization as created within SwaggerHub | :::info The solution comes with a built-in [JSONSchema](https://github.com/frankkilcommins/AzureAD-SwaggerHub-UserManagement/blob/main/src/GroupConfiguration.schema.json) to validate the `GroupConfiguration.json` and the configuration is validated against the schema during startup. ::: ## Deployment Options The solution is almost turnkey and gives you two main options for deployment. **Option 1** Leverage the “Deploy to Azure” button to deploy the required Azure infrastructure to your Azure subscription. \ **Note:** You still need to publish the code manually to your resources. Follow the Setting Up Locally section in the GitHub repo and deploy your code to your Azure environment. \ **Option 2** Fork the source code to your own repo and create the following GitHub action: ```yaml on: [workflow_dispatch] # change the triggering mechanism to suit your needs (manual run by default) name: AzureAD-SwaggerHub-UserManagement-Setup-and-Deploy env: AZURE_FUNCTIONAPP_PACKAGE_PATH: 'src' # set this to the path to your web app project, defaults to the repository root DOTNET_VERSION: '5.0.402' # set this to the dotnet version to use jobs: # use ARM templates to set up the Azure Infra deploy-infrastructure: runs-on: ubuntu-latest # set outputs needed by subsequent jobs outputs: azFunctionAppName: ${{ steps.armdeploy.outputs.functionAppName }} steps: # check out code - uses: actions/checkout@main # login to Azure - uses: azure/login@v1 with: creds: ${{ secrets.AzureAD_SwaggerHub_CREDENTIALS }} # deploy ARM template to setup azure resources (group & sub defined in credentials) - name: Run ARM deploy id: armdeploy uses: azure/arm-deploy@v1 with: subscriptionId: ${{ secrets.AZURE_SUBSCRIPTION }} resourceGroupName: ${{ secrets.AZURE_RG }} template: ./azuredeploy.json parameters: ./azuredeploy.parameters.json # build and deploy our Azure functions for SwaggerHub + Azure AD user mgmt build-and-deploy: needs: [deploy-infrastructure] runs-on: windows-latest environment: prd steps: # check out code - name: 'Checkout code' uses: actions/checkout@main # login to Azure - uses: azure/login@v1 with: creds: ${{ secrets.AzureAD_SwaggerHub_CREDENTIALS }} enable-AzPSSession: true # get publish profile - name: Get publish profile id: fncapp uses: azure/powershell@v1 with: inlineScript: | $profile = "" $profile = Get-AzWebAppPublishingProfile -ResourceGroupName ${{ secrets.AZURE_RG }} -Name ${{ needs.deploy-infrastructure.outputs.azFunctionAppName }} $profile = $profile.Replace("`r", "").Replace("`n", "") Write-Output "::set-output name=profile::$profile" azPSVersion: "latest" # setup donet environments - name: Setup DotNet Environments uses: actions/setup-dotnet@v1 with: dotnet-version: | 3.1.x ${{ env.DOTNET_VERSION }} # build project - name: 'Resolve dependencies and build' shell: pwsh run: | pushd './${{ env.AZURE_FUNCTIONAPP_PACKAGE_PATH }}' dotnet restore dotnet build --configuration Release --output ./output popd # publish azure function - name: 'Run Azure Functions Action' uses: Azure/functions-action@v1 id: fa with: app-name: ${{ needs.deploy-infrastructure.outputs.azFunctionAppName }} package: '${{ env.AZURE_FUNCTIONAPP_PACKAGE_PATH }}/output' publish-profile: ${{ steps.fncapp.outputs.profile }} ``` The GitHub action above, needs the following secrets configured: * `Azure_SUBSCRIPTION` - your Azure subscription ID * `Azure_RG` - the name of the Azure Resource Group that you want to deploy this solution into * `AZUREAD_SWAGGERHUB_CREDENTIALS` - the credentials for a Service Principal with contributor access for the resource group. See how to get the [Service Principal credentials](https://docs.microsoft.com/en-us/azure-stack/user/ci-cd-github-action-login-cli?view=azs-2108). \ Both options above leverage the [Azure Resource Manager (ARM)](https://github.com/frankkilcommins/AzureAD-SwaggerHub-UserManagement/blob/main/azuredeploy.json) Template to deploy the following resources to a named Azure Resource Group: * Azure App Service Plan * Azure Function App * Azure Storage Account Alternatively, you can create the resources manually using the Azure portal or Azure CLI, and deploy the code using whatever process works well for your organization. ## Conclusion Organizations around the world are adopting APIs to enable digitalization and improve connectivity, but they face increasing challenges in managing the API sprawl. One such challenge is how to manage the ways in which teams and individuals access their API tooling, especially if each tool mandates user management directly within its own management UI. \ Thankfully, the User Management API for SwaggerHub has many ways to help organizations automate the provisioning and management of users, maintain secure access to their proprietary APIs, and maximize their licenses allocations. :::info The API is available for organizations on Enterprise and Enterprise Trial plans, as well as for SwaggerHub On-Premise customers. ::: By applying the solutions explained in this article, you can help your organization take advantage of the new user-management APIs offered by SwaggerHub. These work in seamless combination with your Azure AD Identity and Access Management suite. The result is less headache and more efficiency when it comes to taming your API program. \ Even if you’re not using SwaggerHub, then I hope you can benefit from some of the techniques laid out above to leverage Azure AD, Change Notifications and Azure Functions in combination with your own application APIs for improved user management automation.
