At VIM AEC we process extremely large architectural models and import meshes and BIM data into game engines (such as Unity), 3D editing tools (such as 3ds Max), and applications running on different devices (such as the Magic Leap). When using FBX as a format for representing large meshes it takes close to four minutes to import a 28 million polygon model in Unity. As an alternative we developed an open format for representing 3D geometry called G3D which reduced import time to just under 6 seconds. Overview The G3D format can represent triangular and quadrilateral meshes, point clouds, line segments, and polygonal meshes along with arbitrary attributes (e.g. normals, UVs, colors, smoothing groups, etc.) associated with different sub-elements of the mesh (vertices, faces, face-corners, polygon groups, or whole object). Our G3D loader is over an order of magnitude faster in our tests than reading OBJ, FBX, or PLY files with the Assimp model import library or importing into Unity. The specification and reference implementation is also considerably simpler than other binary formats such as glTF while supporting a wider range of data attributes. On the G3D Github repo we provide a reference implementation in C# using .NET Standard 2.0 (making it cross-platform) and a Unity test project for importing and exporting G3D meshes. We also have released a Nuget package which we use in our production code. Motivation The common data formats for representing 3D geometry (e.g. OBJ, FBX, Collada, glTF, etc.) generally have one or more shortcomings: poor serialization and deserialization performanceplatform or language specificlack of extensibilitycomplex to implementlimits on number and types of attributes stored Our goal was to design a format that would enable us to quickly and easily implement importers and exporters as plug-ins to different editing tools, game engines, and applications running on different platforms from desktop to WebGL to spatial computing devices like the Magic Leap. We also wanted this format to be able to transport a wide variety of data from different sources without loss. How is G3D so fast? The reason the G3D format is so fast is that it doesn’t have to pre-process data before getting it into a renderable, GPU-friendly, state. Text-based mesh formats such as OBJ, PLY, Collada, etc. require the computer to spend a significant amount of time converting from a text-representation to a binary representation consumable by the converter. Similarly for some binary formats, such as FBX, the mesh vertex data is organized as a vectors of 4 double-precision floating point values. Most rendering contexts expect the vertex position data to be encoded as vectors of 3 single-precision floats, which means that a pre-process step is required to truncate the data and pack it in more convenient format. G3D data buffers are strictly aligned, so that once the entire file is loaded into memory, the individual data buffers can be passed to the GPU as-is with no additional processing or memory allocations. A Primer on 3D Meshes Commonly a 3D mesh consists of a series of points in space (called vertices) and a list of faces that specify how those points are connected to make a faceted surface in 3 dimensional space. Image from Wikipedia licensed under CC-SA-3.0 by RChoetzlien The list of points is often called a vertex buffer, and the list of faces is represented as an index buffer. If the size of each face is fixed (e.g. 3 for triangles or 4 for quads), then every N indices are the indices of the vertices of the corners for a different face. Given this observation it follows naturally that point clouds and line segments are degenerate cases of faces where there are only one or two points per face respectively. Meshes supporting mixed size polygons can be encoded using an additional data array for the sizes of each face. Edges There are two types of edges to consider: undirected edges, and directed edges (also called half-edges). In G3D, like in 3ds Max, the edge refers to the half-edge. Half-edges are so named because two adjacent faces each have a directed half-edge that both share the same vertices, but flow in different directions, completing the full edge that separates the two faces. Enumerating half-edges is simpler, because every face has N half-edges, where N = the number of points in the face. So the half-edge index buffer is exactly the same as the index buffer. Surface or Polygon Group A surface or polygon group is a sequence of contiguous faces which make a continuous surface. Often this surface will share a common material. Consider the case of a cylinder, the curved section can be thought of as one curved face, while the end caps are both surfaces. Having polygon groups enables more compact data representation (e.g. we can have a shared material ID per group, or a single shared normal in the case of a planar surface). Polygon groups can also be used to encode “sub-mesh” data from Unity or a Revit API Face. Attributes The G3D mesh format is based on representing geometry as a collection of strictly aligned binary arrays called attributes. An attribute is an array of scalars or vectors associated with vertices, face corners, faces, or polygon groups. In some cases an attribute is a single value associated with the entire object. Some common examples of attributes include: Vertex colorsUV coordinatesFace or vertex normalsSmoothing group IDsMaterial IdsPer-vertex data (e.g. soft-selection or crease weights)Edge visibilityTangents and binormals Attribute Descriptor String Each attribute in a G3D is associated with a descriptor, which is encoded as a string in the following format: g3d:<association>:<semantic>:<data_type>:<data_arity> The descriptor consists of the following components: association — point, corner, edge, face, group, allprimitive data type — int8, int16, int32, int64, float32, float64arity — number of primitives per data elementsemantic — an identifier that defines the role or purpose of the attribute Multiple attributes may share the same descriptor string, such as the multiple UV channels stored in a Unity mesh. Implementation Details The underlying binary layout of a G3D file conforms to the BFAST serialization format, simple and efficient open binary format for serializing collections of named byte arrays. (See this article on Hackernoon) The first named buffer in the BFAST container is reserved for meta-information about the file encoded in JSON format. It has the name “meta”. There are currently no restrictions or requirements on what data is encoded in the meta JSON object. Each subsequent data buffer stores attribute data, and uses the attribute descriptor string as a name. As per the BFAST specification attribute data is stored in 64-byte aligned data-buffers. Semantic Attributes also have a “semantic” tag which is used to identify what role the attribute has for rendering or processing. An application may use any string it chooses to represent the semantic, however the G3D specification recommends a number of semantics with predefined meanings (see the Github readme.md for the full list). This is intended to make it possible for different applications to exchange, process, and render G3D data in a common manner. Further Reading If you are interested in understanding the design decisions that lead up to the G3D format, it can be useful to read up on how other mesh representations are designed: Assimp Mesh class documentationFBX Mesh class documentation3ds Max Mesh class documentationGLTF SpecificationPaul Bourke’s collection of reference to graphics data formats Final Words At VIM AEC we are very interested in helping others adopt the G3D format, as we believe it can help improve the quality of graphics software for everyone. Please reach out to me via email or the Github issues to ask questions or make suggestions. Disclaimer: I work at VIM AEC as Head of Research. At VIM AEC we process extremely large architectural models and import meshes and BIM data into game engines (such as Unity), 3D editing tools (such as 3ds Max), and applications running on different devices (such as the Magic Leap). VIM AEC When using FBX as a format for representing large meshes it takes close to four minutes to import a 28 million polygon model in Unity. As an alternative we developed an open format for representing 3D geometry called G3D which reduced import time to just under 6 seconds. G3D G3D Overview The G3D format can represent triangular and quadrilateral meshes, point clouds, line segments, and polygonal meshes along with arbitrary attributes (e.g. normals, UVs, colors, smoothing groups, etc.) associated with different sub-elements of the mesh (vertices, faces, face-corners, polygon groups, or whole object). Our G3D loader is over an order of magnitude faster in our tests than reading OBJ, FBX, or PLY files with the Assimp model import library or importing into Unity. The specification and reference implementation is also considerably simpler than other binary formats such as glTF while supporting a wider range of data attributes. Assimp glTF On the G3D Github repo we provide a reference implementation in C# using .NET Standard 2.0 (making it cross-platform) and a Unity test project for importing and exporting G3D meshes. We also have released a Nuget package which we use in our production code. G3D Github repo Nuget package Motivation Motivation The common data formats for representing 3D geometry (e.g. OBJ, FBX, Collada, glTF, etc.) generally have one or more shortcomings: poor serialization and deserialization performance platform or language specific lack of extensibility complex to implement limits on number and types of attributes stored poor serialization and deserialization performance platform or language specific lack of extensibility complex to implement limits on number and types of attributes stored Our goal was to design a format that would enable us to quickly and easily implement importers and exporters as plug-ins to different editing tools, game engines, and applications running on different platforms from desktop to WebGL to spatial computing devices like the Magic Leap. We also wanted this format to be able to transport a wide variety of data from different sources without loss. How is G3D so fast? The reason the G3D format is so fast is that it doesn’t have to pre-process data before getting it into a renderable, GPU-friendly, state. Text-based mesh formats such as OBJ, PLY, Collada, etc. require the computer to spend a significant amount of time converting from a text-representation to a binary representation consumable by the converter. Similarly for some binary formats, such as FBX, the mesh vertex data is organized as a vectors of 4 double-precision floating point values. Most rendering contexts expect the vertex position data to be encoded as vectors of 3 single-precision floats, which means that a pre-process step is required to truncate the data and pack it in more convenient format. G3D data buffers are strictly aligned, so that once the entire file is loaded into memory, the individual data buffers can be passed to the GPU as-is with no additional processing or memory allocations. A Primer on 3D Meshes A Primer on 3D Meshes Commonly a 3D mesh consists of a series of points in space (called vertices) and a list of faces that specify how those points are connected to make a faceted surface in 3 dimensional space. Image from Wikipedia licensed under CC-SA-3.0 by RChoetzlien Wikipedia RChoetzlien The list of points is often called a vertex buffer, and the list of faces is represented as an index buffer. If the size of each face is fixed (e.g. 3 for triangles or 4 for quads), then every N indices are the indices of the vertices of the corners for a different face. Given this observation it follows naturally that point clouds and line segments are degenerate cases of faces where there are only one or two points per face respectively. Meshes supporting mixed size polygons can be encoded using an additional data array for the sizes of each face. Edges There are two types of edges to consider: undirected edges, and directed edges (also called half-edges). In G3D, like in 3ds Max, the edge refers to the half-edge. Half-edges are so named because two adjacent faces each have a directed half-edge that both share the same vertices, but flow in different directions, completing the full edge that separates the two faces. Enumerating half-edges is simpler, because every face has N half-edges, where N = the number of points in the face. So the half-edge index buffer is exactly the same as the index buffer. Surface or Polygon Group A surface or polygon group is a sequence of contiguous faces which make a continuous surface. Often this surface will share a common material. Consider the case of a cylinder, the curved section can be thought of as one curved face, while the end caps are both surfaces. Having polygon groups enables more compact data representation (e.g. we can have a shared material ID per group, or a single shared normal in the case of a planar surface). Polygon groups can also be used to encode “sub-mesh” data from Unity or a Revit API Face . Revit API Face Attributes The G3D mesh format is based on representing geometry as a collection of strictly aligned binary arrays called attributes. An attribute is an array of scalars or vectors associated with vertices, face corners, faces, or polygon groups. In some cases an attribute is a single value associated with the entire object. Some common examples of attributes include: Vertex colors UV coordinates Face or vertex normals Smoothing group IDs Material Ids Per-vertex data (e.g. soft-selection or crease weights) Edge visibility Tangents and binormals Vertex colors UV coordinates Face or vertex normals Smoothing group IDs Material Ids Per-vertex data (e.g. soft-selection or crease weights) Edge visibility Tangents and binormals Attribute Descriptor String Each attribute in a G3D is associated with a descriptor, which is encoded as a string in the following format: g3d:<association>:<semantic>:<data_type>:<data_arity> g3d:<association>:<semantic>:<data_type>:<data_arity> g3d: <association> :<semantic> :<data_type> :<data_arity> g3d: <association> :<semantic> :<data_type> :<data_arity> The descriptor consists of the following components: association — point, corner, edge, face, group, all primitive data type — int8, int16, int32, int64, float32, float64 arity — number of primitives per data element semantic — an identifier that defines the role or purpose of the attribute association — point, corner, edge, face, group, all primitive data type — int8, int16, int32, int64, float32, float64 arity — number of primitives per data element semantic — an identifier that defines the role or purpose of the attribute Multiple attributes may share the same descriptor string, such as the multiple UV channels stored in a Unity mesh. Implementation Details The underlying binary layout of a G3D file conforms to the BFAST serialization format , simple and efficient open binary format for serializing collections of named byte arrays. (See this article on Hackernoon ) BFAST serialization format BFAST serialization format this article on Hackernoon The first named buffer in the BFAST container is reserved for meta-information about the file encoded in JSON format. It has the name “meta”. There are currently no restrictions or requirements on what data is encoded in the meta JSON object. Each subsequent data buffer stores attribute data, and uses the attribute descriptor string as a name. As per the BFAST specification attribute data is stored in 64-byte aligned data-buffers. Semantic Semantic Attributes also have a “semantic” tag which is used to identify what role the attribute has for rendering or processing. An application may use any string it chooses to represent the semantic, however the G3D specification recommends a number of semantics with predefined meanings (see the Github readme.md for the full list). This is intended to make it possible for different applications to exchange, process, and render G3D data in a common manner. the Github readme.md Further Reading If you are interested in understanding the design decisions that lead up to the G3D format, it can be useful to read up on how other mesh representations are designed: Assimp Mesh class documentation FBX Mesh class documentation 3ds Max Mesh class documentation GLTF Specification Paul Bourke’s collection of reference to graphics data formats Assimp Mesh class documentation Assimp Mesh class documentation FBX Mesh class documentation FBX Mesh class documentation 3ds Max Mesh class documentation 3ds Max Mesh class documentation GLTF Specification GLTF Specification Paul Bourke’s collection of reference to graphics data formats Paul Bourke’s collection of reference to graphics data formats Final Words At VIM AEC we are very interested in helping others adopt the G3D format, as we believe it can help improve the quality of graphics software for everyone. Please reach out to me via email or the Github issues to ask questions or make suggestions. me via email Github issues Disclaimer : I work at VIM AEC as Head of Research . Disclaimer Disclaimer : I work at VIM AEC as Head of Research

Polygon

[Deep Dive] What is the G3D Geometry Exchange Format?
