The Application of ML Models in User Recognition via Keystroke Dynamics

by Bogdan TudoracheOctober 10th, 2023
Read on Terminal Reader
Read this story w/o Javascript

Too Long; Didn't Read

This article explores the use of machine learning models for user recognition based on keystroke dynamics, a behavioral biometric method. The process involves analyzing keystroke data to extract typing patterns and build three machine learning models: Support Vector Machine (SVM), Random Forest, and Extreme Gradient Boosting (XGBoost). The data is first processed to calculate features like hold time, press-press time, release-release time, and release-press time. These features are then used to train the ML models. Code examples for each model's training are provided. The article also discusses the importance of feature extraction and provides additional resources for further reading
featured image - The Application of ML Models in User Recognition via Keystroke Dynamics
Bogdan Tudorache HackerNoon profile picture

ML models for User Recognition using Keystroke Dynamics

The keystroke dynamics that are used in this article’s machine learning models for user recognition are behavioral biometrics. Keystroke dynamics use the distinctive way that each person types to confirm their identity. This is accomplished by analyzing the 2 keystroke events on Key-Press and Key-Release — that make up a keystroke on computer keyboards to extract typing patterns.


This article will examine how these patterns can be applied to create 3 precise machine-learning models for user recognition.


The goal of this article will be split into two parts, building and training Machine Learning models (1. SVM 2. Random Forest 3. XGBoost) and deploying the model in a real live single point API capable of predicting the user based on 5 input parameters: the ML model and 4 keystroke times.




1. Building Models

The problem

The objective of this part is to build ML models for user recognition based on their keystroke data. keystroke dynamics is a behavioral biometric that utilizes the unique way a person types to verify the identity of an individual.


Typing patterns are predominantly extracted from computer keyboards. the patterns used in keystroke dynamics are derived mainly from the two events that make up a keystroke: the Key-Press and Key-Release.


The Key-Press event takes place at the initial depression of a key and the Key-Release occurs at the subsequent release of that key.


In this step, a dataset of keystroke information of users is given with the following information:


  • keystroke.csv: in this dataset, the keystroke data from 110 users are collected.
  • All users are asked to type a 13-length constant string 8 times and the keystroke data (key-press time and key-release time for each key) are collected.
  • The data set contains 880 rows and 27 columns.
  • The first column indicates UserID and the rest shows the press and release time for the first to 13th character.


You should do the following:

  1. Usually, the raw data is not informative enough, and it is needed to extract informative features from raw data to build a good model.


In this regard, four features:


  • Hold Time “HT”

  • Press-Press time “PPT”

  • Release-Release Time “RRT”

  • Release-Press time “RPT”


are introduced and the definitions of each of them are described above.


2. For each row in keystroke.csv, you should generate these features for each two consecutive keys.


3. After completing the previous step, you should calculate the mean and standard deviation for each feature per row. As a result, you should have 8 features (4 mean and 4 standard deviations) per row. → process_csv()



def calculate_mean_and_standard_deviation(feature_list):
    from math import sqrt
    # calculate the mean
    mean = sum(feature_list) / len(feature_list)

    # calculate the squared differences from the mean
    squared_diffs = [(x - mean) ** 2 for x in feature_list]

    # calculate the sum of the squared differences
    sum_squared_diffs = sum(squared_diffs)

    # calculate the variance
    variance = sum_squared_diffs / (len(feature_list) - 1)

    # calculate the standard deviation
    std_dev = sqrt(variance)

    return mean, std_dev



def process_csv(df_input_csv_data):
    data = {
        'user': [],
        'ht_mean': [],
        'ht_std_dev': [],
        'ppt_mean': [],
        'ppt_std_dev': [],
        'rrt_mean': [],
        'rrt_std_dev': [],
        'rpt_mean': [],
        'rpt_std_dev': [],
    }

    # iterate over each row in the dataframe
    for i, row in df_input_csv_data.iterrows():
        # iterate over each pair of consecutive presses and releases
        # print('user:', row['user'])

        # list of hold times
        ht_list = []
        # list of press-press times
        ppt_list = []
        # list of release-release times
        rrt_list = []
        # list of release-press times
        rpt_list = []

        # I use the IF to select only the X rows  of the csv
        if i < 885:
            for j in range(12):
                # calculate the hold time: release[j]-press[j]
                ht = row[f"release-{j}"] - row[f"press-{j}"]
                # append hold time to list of hold times
                ht_list.append(ht)

                # calculate the press-press time: press[j+1]-press[j]
                if j < 11:
                    ppt = row[f"press-{j + 1}"] - row[f"press-{j}"]
                    ppt_list.append(ppt)

                # calculate the release-release time: release[j+1]-release[j]
                if j < 11:
                    rrt = row[f"release-{j + 1}"] - row[f"release-{j}"]
                    rrt_list.append(rrt)

                # calculate the release-press time: press[j+1] - release[j]
                if j < 10:
                    rpt = row[f"press-{j + 1}"] - row[f"release-{j}"]
                    rpt_list.append(rpt)

            # ht_list, ppt_list, rrt_list, rpt_list are a list of calculated values for each feature -> feature_list
            ht_mean, ht_std_dev = calculate_mean_and_standard_deviation(ht_list)
            ppt_mean, ppt_std_dev = calculate_mean_and_standard_deviation(ppt_list)
            rrt_mean, rrt_std_dev = calculate_mean_and_standard_deviation(rrt_list)
            rpt_mean, rpt_std_dev = calculate_mean_and_standard_deviation(rpt_list)
            # print(ht_mean, ht_std_dev)
            # print(ppt_mean, ppt_std_dev)
            # print(rrt_mean, rrt_std_dev)
            # print(rpt_mean, rpt_std_dev)

            data['user'].append(row['user'])
            data['ht_mean'].append(ht_mean)
            data['ht_std_dev'].append(ht_std_dev)
            data['ppt_mean'].append(ppt_mean)
            data['ppt_std_dev'].append(ppt_std_dev)
            data['rrt_mean'].append(rrt_mean)
            data['rrt_std_dev'].append(rrt_std_dev)
            data['rpt_mean'].append(rpt_mean)
            data['rpt_std_dev'].append(rpt_std_dev)

        else:
            break
    data_df = pd.DataFrame(data)
    return data_df


All the code you can find on my GitHub in the KeystrokeDynamics repository:


Train the MLs

Now that we have parsed the data we can start building the models by training the MLs.


Support Vector Machine


def train_svm(training_data, features):
    import joblib
    from sklearn.svm import SVC

    """
    SVM stands for Support Vector Machine, which is a type of machine learning algorithm used:
    for classification and regression analysis.

    SVM algorithm aims to find a hyperplane in an n-dimensional space that separates the data into two classes.
    The hyperplane is chosen in such a way that it maximizes the margin between the two classes,
    making the classification more robust and accurate.

    In addition, SVM can also handle non-linearly separable data by mapping the original features to a
     higher-dimensional space, where a linear hyperplane can be used for classification.

    :param training_data:
    :param features:
    :return: ML Trained model
    """

    # Split the data into features and labels
    X = training_data[features]
    y = training_data['user']

    # Train an SVM model on the data
    svm_model = SVC()
    svm_model.fit(X, y)

    # Save the trained model to disk
    svm_model_name = 'models/svm_model.joblib'
    joblib.dump(svm_model, svm_model_name)


Additional reading:


Random Forest


def train_random_forest(training_data, features):
    """
    Random Forest is a type of machine learning algorithm that belongs to the family of ensemble learning methods.
    It is used for classification, regression, and other tasks that involve predicting an output value based on
    a set of input features.

    The algorithm works by creating multiple decision trees, where each tree is built using a random subset of the
    input features and a random subset of the training data. Each tree is trained independently,
    and the final output is obtained by combining the outputs of all the trees in some way, such as taking the average
    (for regression) or majority vote (for classification).


    :param training_data:
    :param features:
    :return: ML Trained model
    """
    import joblib
    from sklearn.ensemble import RandomForestClassifier

    # Split the data into features and labels
    X = training_data[features]
    y = training_data['user']

    # Train a Random Forest model on the data
    rf_model = RandomForestClassifier()
    rf_model.fit(X, y)

    # Save the trained model to disk
    rf_model_name = 'models/rf_model.joblib'
    joblib.dump(rf_model, rf_model_name)


Additional reading:



Extreme Gradient Boosting


def train_xgboost(training_data, features):
    import joblib
    import xgboost as xgb
    from sklearn.preprocessing import LabelEncoder
    """
    XGBoost stands for Extreme Gradient Boosting, which is a type of gradient boosting algorithm used for classification and regression analysis.
    XGBoost is an ensemble learning method that combines multiple decision trees to create a more powerful model.
    Each tree is built using a gradient boosting algorithm, which iteratively improves the model by minimizing a loss function.
    XGBoost has several advantages over other boosting algorithms, including its speed, scalability, and ability to handle missing values.

    :param training_data:
    :param features:
    :return: ML Trained model
    """

    # Split the data into features and labels
    X = training_data[features]
    label_encoder = LabelEncoder()
    y = label_encoder.fit_transform(training_data['user'])

    # Train an XGBoost model on the data
    xgb_model = xgb.XGBClassifier()
    xgb_model.fit(X, y)

    # Save the trained model to disk
    xgb_model_name = 'models/xgb_model.joblib'
    joblib.dump(xgb_model, xgb_model_name)


Additional reading:
