A Practical Guide to Dynamic Polymorphism in C Programming

Dynamic polymorphism is a programming paradigm that enhances code flexibility and maintainability by allowing objects to be treated uniformly while exhibiting different behaviors. While C is not inherently object-oriented like C++ or Java, dynamic polymorphism can be implemented using function pointers and structures. In this article, we compare multiple implementations of a toy simulation in C to demonstrate the benefits of dynamic polymorphism. Initial Implementation without Polymorphism Here we define a Toy struct with a name field and create three instances representing Barbie and Superman toys. Each toy is initialized, and an array of pointers to these toy instances is created. The main function iterates through the array and prints the sound associated with each toy based on its name. #include #include // Function prototypes for the sounds made by different toys char const* barbieSound(void){return "Love and imagination can change the world.";} char const* supermanSound(void){return "Up, up, and away!";} // Struct definition for Toy with an character array representing the name of the toy typedef struct Toy{ char const* name; }Toy; int main(void){ //Allocate memory for three Toy instances Toy* toy1 = (Toy*)malloc(sizeof(Toy)); Toy* toy2 = (Toy*)malloc(sizeof(Toy)); Toy* toy3 = (Toy*)malloc(sizeof(Toy)); // Initialize the name members of the Toy instances toy1->name = "Barbie"; toy2->name = "Barbie"; toy3->name = "Superman"; // Create an array of pointers to the Toy instances Toy* toys[] = {toy1, toy2, toy3}; // Output the corresponding sound of each toy given its name for(int i=0; i name == "Barbie"){printf("%s\n",toys[i]->name,barbieSound());} if (toys[i]->name == "Superman"){printf("%s\n",toys[i]->name,supermanSound());} } // Free the allocated memory for the Toy instances free(toy1); free(toy2); free(toy3); return 0; } While this is functional, it doesn't scale. Whenever we want to add a new toy we need to update the code to handle a new toy type and its sound function which could raise maintenance issues. Enhanced Implementation of Dynamic Polymorphism: The second code sample uses dynamic polymorphism for a more flexible, scalable application. Here Toy has its function pointer for the sound function. Factory functions(createBarbie(), createSuperMan()) are used to create Barbie and Superman instances, assigning the appropriate sound function to each toy. The makeSound() function demonstrates dynamic polymorphism by calling the appropriate sound function for each toy at run time. #include #include // Function prototypes for the sounds made by different toys char const* barbieSound(void){return "Love and imagination can change the world.";} char const* supermanSound(void){return "Up, up, and away!";} // Struct definition for Toy with a function pointer for the sound function typedef struct Toy { char const* (*makeSound)(); } Toy; // Function to call the sound function of a Toy and print the result // Demonstrates dynamic polymorphism by calling the appropriate function for each toy void makeSound(Toy* self) { printf("%s\n", self->makeSound()); } // Function to create a Superman toy // Uses dynamic polymorphism by assigning the appropriate sound function to the function pointer Toy* createSuperman() { Toy* superman = (Toy*)malloc(sizeof(Toy)); superman->makeSound = supermanSound; // Assigns Superman's sound function return superman; } // Function to create a Barbie toy // Uses dynamic polymorphism by assigning the appropriate sound function to the function pointer Toy* createBarbie() { Toy* barbie = (Toy*)malloc(sizeof(Toy)); barbie->makeSound = barbieSound; // Assigns Barbie's sound function return barbie; } int main(void) { // Create toy instances using factory functions Toy* barbie1 = createBarbie(); Toy* barbie2 = createBarbie(); Toy* superman1 = createSuperman(); // Array of toy pointers Toy* toys[] = { barbie1, barbie2, superman1 }; // Loop through the toys and make them sound // Dynamic polymorphism allows us to treat all toys uniformly // without needing to know their specific types for (int i = 0; i < 3; i++) { makeSound(toys[i]); } // Free allocated memory free(barbie1); free(barbie2); free(superman1); return 0; } By using a function pointer within the Toy struct, the code can easily accommodate new toy types without modifying the core logic. Factory function is a design pattern used to create objects without specifying the exact class or type of the object that will be created. In the context of C programming and especially in embedded software, a factory function helps in managing the creation and initialization of various types of objects (e.g., sensors, peripherals) in a modular and flexible manner. This pattern is particularly useful when dealing with dynamic polymorphism, as it abstracts the instantiation logic and allows the system to treat objects uniformly A function pointer is a variable that stores the address of a function, allowing the function to be called through the pointer. This enables dynamic function calls, which are particularly useful when the function to be executed needs to be determined at runtime. Defining a Function Pointer A function pointer is defined using the following syntax: (* )( ); Example For example, to declare a pointer to a function that returns an int and takes two int parameters, you would write: int (*functionPointer)(int, int); Performance Considerations Memory Overhead: Each structure that uses function pointers requires additional memory to store these pointers. This can slightly increase your program's memory footprint, especially if many such structures are used. Function Call Overhead: Indirect function calls through pointers can introduce a slight performance overhead compared to direct function calls. This is due to the additional level of indirection required to resolve the function pointer at runtime. How the Overheads Occur When a function is called directly, the assembly code typically contains a direct jump to the function's address. For example, let’s take a simple C program: #include void function(){ printf("Hello Barbie"); } int main(void){ function(); return 0; } The assembly code of the C code compiled with an x86-64 GCC 14.1 compiler looks like this: .LC0: .string "Hello Barbie" function: push rbp mov rbp, rsp mov edi, OFFSET FLAT:.LC0 mov eax, 0 call printf nop pop rbp ret main: push rbp # Save the base pointer of the previous stack frame by pushing it on the stack mov rbp, rsp # Set up a new stack frame for the current function mov eax, 0 # Clear the eax register call function # Call the function 'function' mov eax, 0 # Set eax register to 0, indicating the return value of the main function pop rbp # Pop the saved value from stack into rbp, restoring the previous stack frame ret # Return from main function We can see that in this case, calling the function takes only two instructions in the assembly code (call function, mov eax, 0). If we replace function with a function pointer called myFunction to point to the function: int main(void){ void (*myFunction)() = function; // function pointer called myFunction to point to function myFunction(); // calling the function pointed by myFunction pointer return 0; } The assembly code of the main function will look like this: main: push rbp mov rbp, rsp sub rsp, 16 # Allocate 16 bytes on the stack for local variables mov QWORD PTR [rbp-8], OFFSET FLAT:function # Store the address of function into the memory location [rbp-8] mov rdx, QWORD PTR [rbp-8] # Load the function pointer stored at [rbp-8] into rdx register mov eax, 0 # Clear the eax register before the function call call rdx # Call the function stored in rdx mov eax, 0 # Set the return value of main to 0 leave # Release the stack space used by the current stack frame ret We can see that when using a function pointer, we have one additional assembly instruction for storing the function address in the function pointer and three additional instructions for calling the function pointed to by the function pointer. Also, 16 bytes had to be allocated for storing local variables, while only 8 bytes of the stack memory were used by the function pointer. This is because the stack size typically needs to be a multiple of 16, so if we were to use 20 bytes in our function, the compiler would allocate 32 bytes for the stack frame. Virtual tables Let's take for example a scenario where each Toy, instead of having one sound, has multiple sounds, each represented by a separate function: char const* barbieSound1(void) {return "Love and imagination can change the world.";} char const* barbieSound2(void) {return "You can be anything you want to be.";} char const* barbieSound3(void) {return "Every girl can make a difference.";} char const* barbieSound4(void) {return "Dream big and dare to fail.";} char const* supermanSound1(void) {return "Up, up, and away!";} char const* supermanSound2(void) {return "There is a superhero in all of us, we just need the courage to put on the cape.";} char const* supermanSound3(void) {return "Dreams save us. Dreams lift us up and transform us.";} We could try to refactor our Toy structure to have multiple makeSound functions: typedef struct Toy { char const* (*makeSound1)(); char const* (*makeSound2)(); char const* (*makeSound3)(); char const* (*makeSound4)(); } Toy; Toy* createBarbie() { Toy* barbie = (Toy*)malloc(sizeof(Toy)); barbie->makeSound1 = barbieSound1; barbie->makeSound2 = barbieSound2; barbie->makeSound3 = barbieSound3; barbie->makeSound4 = barbieSound4; return barbie; } Toy* createSuperman() { Toy* superman = (Toy*)malloc(sizeof(Toy)); barbie->makeSound1 = supermanSound1; superman->makeSound2 = supermanSound2; superman->makeSound3 = supermanSound3; superman->makeSound4 = NULL; // supermanSound4 is not defined return superman; } As we can see, as the number of functions increases, managing function assignments and function calling becomes difficult and error-prone. One possible solution to that problem are virtual tables. In C++ each class that uses a virtual function has a corresponding virtual table set by the compiler at compile time. Virtual tables (vtables) provide a way to store function pointers in a table, allowing dynamic function calls at runtime. Each structure has a pointer to the vtable, and the vtable contains pointers to the functions that implement the ‘structure’s methods’, in our case the toy structure’s different makeSound functions. #include #include // Barbie sound functions char const* barbieSound1(void) { return "Love and imagination can change the world."; } char const* barbieSound2(void) { return "You can be anything you want to be."; } char const* barbieSound3(void) { return "Every girl can make a difference."; } char const* barbieSound4(void) { return "Dream big and dare to fail."; } // Superman sound functions char const* supermanSound1(void) { return "Up, up, and away!"; } char const* supermanSound2(void) { return "There is a superhero in all of us, we just need the courage to put on the cape."; } char const* supermanSound3(void) { return "Dreams save us. Dreams lift us up and transform us."; } // Define a type for function pointers typedef char const* (*PTRFUN)(); // Vtables for Barbie and Superman PTRFUN barbieVTable[4] = { barbieSound1, barbieSound2, barbieSound3, barbieSound4 }; PTRFUN supermanVTable[3] = { supermanSound1, supermanSound2, supermanSound3 }; // Toy structure with a vtable pointer typedef struct Toy { PTRFUN* vtable; } Toy; // Create a Barbie toy and set its vtable Toy* createBarbie() { Toy* barbie = (Toy*)malloc(sizeof(Toy)); barbie->vtable = barbieVTable; return barbie; } // Create a Superman toy and set its vtable Toy* createSuperman() { Toy* superman = (Toy*)malloc(sizeof(Toy)); superman->vtable = supermanVTable; return superman; } // Function to make a toy produce a sound void makeSound(Toy* self, int num) { // Check if the index is within bounds of the vtable if (self->vtable[num] != NULL) { printf("%s\n", self->vtable[num]()); } else { printf("Invalid sound index.\n"); } } int main(void) { // Create Barbie and Superman toys Toy* barbie = createBarbie(); Toy* superman = createSuperman(); // Make sounds using the vtable makeSound(barbie, 0); // Outputs: "Love and imagination can change the world." makeSound(barbie, 1); // Outputs: "You can be anything you want to be." makeSound(superman, 0); // Outputs: "Up, up, and away!" makeSound(superman, 1); // Outputs: "There is a superhero in all of us, we just need the courage to put on the cape." // Clean up free(barbie); free(superman); return 0; } Virtual tables simplify the management of multiple function pointers, reduce redundancy, and make it easier to extend the system with new behaviors. To show how much the vtable plays a significant role, let’s look at an example where we want to use 10,000 instances of each toy in our program: #include typedef void (*FUNPTR)(); struct Superman { FUNPTR fptr1; FUNPTR fptr2; FUNPTR fptr3; FUNPTR fptr4; FUNPTR fptr5; FUNPTR fptr6; FUNPTR fptr7; FUNPTR fptr8; FUNPTR fptr9; FUNPTR fptr10; }superman; FUNPTR * barbieVTable[10]; struct Barbie { FUNPTR * vtable; }barbie; int main(void){ printf("Size sf Superman struct: %ld bytes.\n", sizeof(superman)); printf("Size of Barbie struct: %ld bytes, size of barbieVTable: %ld.\n", sizeof(barbie), sizeof(barbieVTable)); printf("Alocated memory for 10,000 Superman toys: %ld bytes.\n", 10000 * sizeof(superman)); printf("Alocated memory for 10,000 Barbie toys: %ld bytes.\n", 10000 * sizeof(barbie) + sizeof(barbieVTable)); return 0; } #expected output: Size sf Superman struct: 80 bytes. Size of Barbie struct: 8 bytes, size of barbieVTable: 80. Alocated memory for 10,000 Superman toys: 800000 bytes. Alocated memory for 10,000 Barbie toys: 80080 bytes. Explanation: struct Superman: This struct has ten function pointers (FUNPTR), directly embedded within the struct. Each function pointer typically takes up 8 bytes (on a 64-bit system), resulting in a total size of 80 bytes for each instance of Superman. struct Barbie: This struct has a single pointer to a vtable (barbieVTable), which contains ten function pointers. The size of the Barbie struct is 8 bytes (the size of a single pointer), and the vtable itself is an array of ten function pointers each of size 8 bytes, resulting in 80 bytes total for the vtable. Memory Allocation: For 10,000 Superman instances: Each Superman instance is 80 bytes. Total memory required = 10,000 * 80 bytes = 800,000 bytes. For 10,000 Barbie instances: Each Barbie instance is 8 bytes. Additionally, only one shared vtable of 80 bytes is required. Total memory required = (10,000 * 8 bytes) + 80 bytes = 80,000 + 80 bytes = 80,080 bytes. Conclusion: This demonstration shows how using a vtable can reduce memory usage when creating multiple instances of objects that share the same set of functions. Benefits of Dynamic Polymorphism Flexibility: Allows new types to be added with minimal changes to existing code. Maintainability: Reduces the need for extensive conditional logic. Scalability: Supports the extension of the system by adding new object types and behaviors. Practical Use Cases Dynamic polymorphism is often used in various software design patterns, such as the Strategy Pattern, State Pattern, and Command Pattern. These patterns use polymorphism to allow different behaviors and states to be easily swapped in and out. This makes the code more flexible and easier to maintain. If you have any questions or thoughts on this topic, feel free to leave a comment below! Dynamic polymorphism is a programming paradigm that enhances code flexibility and maintainability by allowing objects to be treated uniformly while exhibiting different behaviors. While C is not inherently object-oriented like C++ or Java, dynamic polymorphism can be implemented using function pointers and structures . In this article, we compare multiple implementations of a toy simulation in C to demonstrate the benefits of dynamic polymorphism. Dynamic polymorphism function pointers structures Initial Implementation without Polymorphism Here we define a Toy struct with a name field and create three instances representing Barbie and Superman toys. Each toy is initialized, and an array of pointers to these toy instances is created. The main function iterates through the array and prints the sound associated with each toy based on its name. Toy name main #include #include // Function prototypes for the sounds made by different toys char const* barbieSound(void){return "Love and imagination can change the world.";} char const* supermanSound(void){return "Up, up, and away!";} // Struct definition for Toy with an character array representing the name of the toy typedef struct Toy{ char const* name; }Toy; int main(void){ //Allocate memory for three Toy instances Toy* toy1 = (Toy*)malloc(sizeof(Toy)); Toy* toy2 = (Toy*)malloc(sizeof(Toy)); Toy* toy3 = (Toy*)malloc(sizeof(Toy)); // Initialize the name members of the Toy instances toy1->name = "Barbie"; toy2->name = "Barbie"; toy3->name = "Superman"; // Create an array of pointers to the Toy instances Toy* toys[] = {toy1, toy2, toy3}; // Output the corresponding sound of each toy given its name for(int i=0; i name == "Barbie"){printf("%s\n",toys[i]->name,barbieSound());} if (toys[i]->name == "Superman"){printf("%s\n",toys[i]->name,supermanSound());} } // Free the allocated memory for the Toy instances free(toy1); free(toy2); free(toy3); return 0; } #include #include // Function prototypes for the sounds made by different toys char const* barbieSound(void){return "Love and imagination can change the world.";} char const* supermanSound(void){return "Up, up, and away!";} // Struct definition for Toy with an character array representing the name of the toy typedef struct Toy{ char const* name; }Toy; int main(void){ //Allocate memory for three Toy instances Toy* toy1 = (Toy*)malloc(sizeof(Toy)); Toy* toy2 = (Toy*)malloc(sizeof(Toy)); Toy* toy3 = (Toy*)malloc(sizeof(Toy)); // Initialize the name members of the Toy instances toy1->name = "Barbie"; toy2->name = "Barbie"; toy3->name = "Superman"; // Create an array of pointers to the Toy instances Toy* toys[] = {toy1, toy2, toy3}; // Output the corresponding sound of each toy given its name for(int i=0; i name == "Barbie"){printf("%s\n",toys[i]->name,barbieSound());} if (toys[i]->name == "Superman"){printf("%s\n",toys[i]->name,supermanSound());} } // Free the allocated memory for the Toy instances free(toy1); free(toy2); free(toy3); return 0; } While this is functional, it doesn't scale. Whenever we want to add a new toy we need to update the code to handle a new toy type and its sound function which could raise maintenance issues. Enhanced Implementation of Dynamic Polymorphism: The second code sample uses dynamic polymorphism for a more flexible, scalable application. Here Toy has its function pointer for the sound function. Factory functions ( createBarbie() , createSuperMan() ) are used to create Barbie and Superman instances, assigning the appropriate sound function to each toy. The makeSound() function demonstrates dynamic polymorphism by calling the appropriate sound function for each toy at run time. Toy function pointer Factory functions createBarbie() createSuperMan() makeSound() #include #include // Function prototypes for the sounds made by different toys char const* barbieSound(void){return "Love and imagination can change the world.";} char const* supermanSound(void){return "Up, up, and away!";} // Struct definition for Toy with a function pointer for the sound function typedef struct Toy { char const* (*makeSound)(); } Toy; // Function to call the sound function of a Toy and print the result // Demonstrates dynamic polymorphism by calling the appropriate function for each toy void makeSound(Toy* self) { printf("%s\n", self->makeSound()); } // Function to create a Superman toy // Uses dynamic polymorphism by assigning the appropriate sound function to the function pointer Toy* createSuperman() { Toy* superman = (Toy*)malloc(sizeof(Toy)); superman->makeSound = supermanSound; // Assigns Superman's sound function return superman; } // Function to create a Barbie toy // Uses dynamic polymorphism by assigning the appropriate sound function to the function pointer Toy* createBarbie() { Toy* barbie = (Toy*)malloc(sizeof(Toy)); barbie->makeSound = barbieSound; // Assigns Barbie's sound function return barbie; } int main(void) { // Create toy instances using factory functions Toy* barbie1 = createBarbie(); Toy* barbie2 = createBarbie(); Toy* superman1 = createSuperman(); // Array of toy pointers Toy* toys[] = { barbie1, barbie2, superman1 }; // Loop through the toys and make them sound // Dynamic polymorphism allows us to treat all toys uniformly // without needing to know their specific types for (int i = 0; i #include // Function prototypes for the sounds made by different toys char const* barbieSound(void){return "Love and imagination can change the world.";} char const* supermanSound(void){return "Up, up, and away!";} // Struct definition for Toy with a function pointer for the sound function typedef struct Toy { char const* (*makeSound)(); } Toy; // Function to call the sound function of a Toy and print the result // Demonstrates dynamic polymorphism by calling the appropriate function for each toy void makeSound(Toy* self) { printf("%s\n", self->makeSound()); } // Function to create a Superman toy // Uses dynamic polymorphism by assigning the appropriate sound function to the function pointer Toy* createSuperman() { Toy* superman = (Toy*)malloc(sizeof(Toy)); superman->makeSound = supermanSound; // Assigns Superman's sound function return superman; } // Function to create a Barbie toy // Uses dynamic polymorphism by assigning the appropriate sound function to the function pointer Toy* createBarbie() { Toy* barbie = (Toy*)malloc(sizeof(Toy)); barbie->makeSound = barbieSound; // Assigns Barbie's sound function return barbie; } int main(void) { // Create toy instances using factory functions Toy* barbie1 = createBarbie(); Toy* barbie2 = createBarbie(); Toy* superman1 = createSuperman(); // Array of toy pointers Toy* toys[] = { barbie1, barbie2, superman1 }; // Loop through the toys and make them sound // Dynamic polymorphism allows us to treat all toys uniformly // without needing to know their specific types for (int i = 0; i < 3; i++) { makeSound(toys[i]); } // Free allocated memory free(barbie1); free(barbie2); free(superman1); return 0; } By using a function pointer within the Toy struct, the code can easily accommodate new toy types without modifying the core logic. Toy Factory function is a design pattern used to create objects without specifying the exact class or type of the object that will be created. In the context of C programming and especially in embedded software, a factory function helps in managing the creation and initialization of various types of objects (e.g., sensors, peripherals) in a modular and flexible manner. This pattern is particularly useful when dealing with dynamic polymorphism, as it abstracts the instantiation logic and allows the system to treat objects uniformly Factory function is a design pattern used to create objects without specifying the exact class or type of the object that will be created. In the context of C programming and especially in embedded software, a factory function helps in managing the creation and initialization of various types of objects (e.g., sensors, peripherals) in a modular and flexible manner. This pattern is particularly useful when dealing with dynamic polymorphism, as it abstracts the instantiation logic and allows the system to treat objects uniformly Factory function is a design pattern A function pointer is a variable that stores the address of a function, allowing the function to be called through the pointer. This enables dynamic function calls, which are particularly useful when the function to be executed needs to be determined at runtime. Defining a Function Pointer A function pointer is defined using the following syntax: (* )( ); Example For example, to declare a pointer to a function that returns an int and takes two int parameters, you would write: int (*functionPointer)(int, int); A function pointer is a variable that stores the address of a function, allowing the function to be called through the pointer. This enables dynamic function calls, which are particularly useful when the function to be executed needs to be determined at runtime. A function pointer Defining a Function Pointer A function pointer is defined using the following syntax: (* )( ); (* )( ); Example For example, to declare a pointer to a function that returns an int and takes two int parameters, you would write: int int int (*functionPointer)(int, int); int (*functionPointer)(int, int); Performance Considerations Memory Overhead: Each structure that uses function pointers requires additional memory to store these pointers. This can slightly increase your program's memory footprint, especially if many such structures are used. Function Call Overhead: Indirect function calls through pointers can introduce a slight performance overhead compared to direct function calls. This is due to the additional level of indirection required to resolve the function pointer at runtime. How the Overheads Occur When a function is called directly, the assembly code typically contains a direct jump to the function's address. For example, let’s take a simple C program: Memory Overhead: Each structure that uses function pointers requires additional memory to store these pointers. This can slightly increase your program's memory footprint, especially if many such structures are used. Memory Overhead : Each structure that uses function pointers requires additional memory to store these pointers. This can slightly increase your program's memory footprint, especially if many such structures are used. Memory Overhead Function Call Overhead: Indirect function calls through pointers can introduce a slight performance overhead compared to direct function calls. This is due to the additional level of indirection required to resolve the function pointer at runtime. How the Overheads Occur When a function is called directly, the assembly code typically contains a direct jump to the function's address. For example, let’s take a simple C program: Function Call Overhead : Indirect function calls through pointers can introduce a slight performance overhead compared to direct function calls. This is due to the additional level of indirection required to resolve the function pointer at runtime. Function Call Overhead How the Overheads Occur When a function is called directly, the assembly code typically contains a direct jump to the function's address. For example, let’s take a simple C program: #include void function(){ printf("Hello Barbie"); } int main(void){ function(); return 0; } #include void function(){ printf("Hello Barbie"); } int main(void){ function(); return 0; } The assembly code of the C code compiled with an x86-64 GCC 14.1 compiler looks like this: .LC0: .string "Hello Barbie" function: push rbp mov rbp, rsp mov edi, OFFSET FLAT:.LC0 mov eax, 0 call printf nop pop rbp ret main: push rbp # Save the base pointer of the previous stack frame by pushing it on the stack mov rbp, rsp # Set up a new stack frame for the current function mov eax, 0 # Clear the eax register call function # Call the function 'function' mov eax, 0 # Set eax register to 0, indicating the return value of the main function pop rbp # Pop the saved value from stack into rbp, restoring the previous stack frame ret # Return from main function .LC0: .string "Hello Barbie" function: push rbp mov rbp, rsp mov edi, OFFSET FLAT:.LC0 mov eax, 0 call printf nop pop rbp ret main: push rbp # Save the base pointer of the previous stack frame by pushing it on the stack mov rbp, rsp # Set up a new stack frame for the current function mov eax, 0 # Clear the eax register call function # Call the function 'function' mov eax, 0 # Set eax register to 0, indicating the return value of the main function pop rbp # Pop the saved value from stack into rbp, restoring the previous stack frame ret # Return from main function We can see that in this case, calling the function takes only two instructions in the assembly code ( call function , mov eax, 0 ). call function mov eax, 0 If we replace function with a function pointer called myFunction to point to the function: myFunction int main(void){ void (*myFunction)() = function; // function pointer called myFunction to point to function myFunction(); // calling the function pointed by myFunction pointer return 0; } int main(void){ void (*myFunction)() = function; // function pointer called myFunction to point to function myFunction(); // calling the function pointed by myFunction pointer return 0; } The assembly code of the main function will look like this: main: push rbp mov rbp, rsp sub rsp, 16 # Allocate 16 bytes on the stack for local variables mov QWORD PTR [rbp-8], OFFSET FLAT:function # Store the address of function into the memory location [rbp-8] mov rdx, QWORD PTR [rbp-8] # Load the function pointer stored at [rbp-8] into rdx register mov eax, 0 # Clear the eax register before the function call call rdx # Call the function stored in rdx mov eax, 0 # Set the return value of main to 0 leave # Release the stack space used by the current stack frame ret main: push rbp mov rbp, rsp sub rsp, 16 # Allocate 16 bytes on the stack for local variables mov QWORD PTR [rbp-8], OFFSET FLAT:function # Store the address of function into the memory location [rbp-8] mov rdx, QWORD PTR [rbp-8] # Load the function pointer stored at [rbp-8] into rdx register mov eax, 0 # Clear the eax register before the function call call rdx # Call the function stored in rdx mov eax, 0 # Set the return value of main to 0 leave # Release the stack space used by the current stack frame ret We can see that when using a function pointer, we have one additional assembly instruction for storing the function address in the function pointer and three additional instructions for calling the function pointed to by the function pointer. Also, 16 bytes had to be allocated for storing local variables, while only 8 bytes of the stack memory were used by the function pointer. This is because the stack size typically needs to be a multiple of 16, so if we were to use 20 bytes in our function, the compiler would allocate 32 bytes for the stack frame. Virtual tables Let's take for example a scenario where each Toy, instead of having one sound, has multiple sounds, each represented by a separate function: char const* barbieSound1(void) {return "Love and imagination can change the world.";} char const* barbieSound2(void) {return "You can be anything you want to be.";} char const* barbieSound3(void) {return "Every girl can make a difference.";} char const* barbieSound4(void) {return "Dream big and dare to fail.";} char const* supermanSound1(void) {return "Up, up, and away!";} char const* supermanSound2(void) {return "There is a superhero in all of us, we just need the courage to put on the cape.";} char const* supermanSound3(void) {return "Dreams save us. Dreams lift us up and transform us.";} char const* barbieSound1(void) {return "Love and imagination can change the world.";} char const* barbieSound2(void) {return "You can be anything you want to be.";} char const* barbieSound3(void) {return "Every girl can make a difference.";} char const* barbieSound4(void) {return "Dream big and dare to fail.";} char const* supermanSound1(void) {return "Up, up, and away!";} char const* supermanSound2(void) {return "There is a superhero in all of us, we just need the courage to put on the cape.";} char const* supermanSound3(void) {return "Dreams save us. Dreams lift us up and transform us.";} We could try to refactor our Toy structure to have multiple makeSound functions: makeSound typedef struct Toy { char const* (*makeSound1)(); char const* (*makeSound2)(); char const* (*makeSound3)(); char const* (*makeSound4)(); } Toy; Toy* createBarbie() { Toy* barbie = (Toy*)malloc(sizeof(Toy)); barbie->makeSound1 = barbieSound1; barbie->makeSound2 = barbieSound2; barbie->makeSound3 = barbieSound3; barbie->makeSound4 = barbieSound4; return barbie; } Toy* createSuperman() { Toy* superman = (Toy*)malloc(sizeof(Toy)); barbie->makeSound1 = supermanSound1; superman->makeSound2 = supermanSound2; superman->makeSound3 = supermanSound3; superman->makeSound4 = NULL; // supermanSound4 is not defined return superman; } typedef struct Toy { char const* (*makeSound1)(); char const* (*makeSound2)(); char const* (*makeSound3)(); char const* (*makeSound4)(); } Toy; Toy* createBarbie() { Toy* barbie = (Toy*)malloc(sizeof(Toy)); barbie->makeSound1 = barbieSound1; barbie->makeSound2 = barbieSound2; barbie->makeSound3 = barbieSound3; barbie->makeSound4 = barbieSound4; return barbie; } Toy* createSuperman() { Toy* superman = (Toy*)malloc(sizeof(Toy)); barbie->makeSound1 = supermanSound1; superman->makeSound2 = supermanSound2; superman->makeSound3 = supermanSound3; superman->makeSound4 = NULL; // supermanSound4 is not defined return superman; } As we can see, as the number of functions increases, managing function assignments and function calling becomes difficult and error-prone. One possible solution to that problem are virtual tables. In C++ each class that uses a virtual function has a corresponding virtual table set by the compiler at compile time. In C++ each class that uses a virtual function has a corresponding virtual table set by the compiler at compile time. In C++ each class that uses a virtual function has a corresponding virtual table set by the compiler at compile time. Virtual tables (vtables) provide a way to store function pointers in a table, allowing dynamic function calls at runtime. Each structure has a pointer to the vtable, and the vtable contains pointers to the functions that implement the ‘structure’s methods’, in our case the toy structure’s different makeSound functions. Virtual tables #include #include // Barbie sound functions char const* barbieSound1(void) { return "Love and imagination can change the world."; } char const* barbieSound2(void) { return "You can be anything you want to be."; } char const* barbieSound3(void) { return "Every girl can make a difference."; } char const* barbieSound4(void) { return "Dream big and dare to fail."; } // Superman sound functions char const* supermanSound1(void) { return "Up, up, and away!"; } char const* supermanSound2(void) { return "There is a superhero in all of us, we just need the courage to put on the cape."; } char const* supermanSound3(void) { return "Dreams save us. Dreams lift us up and transform us."; } // Define a type for function pointers typedef char const* (*PTRFUN)(); // Vtables for Barbie and Superman PTRFUN barbieVTable[4] = { barbieSound1, barbieSound2, barbieSound3, barbieSound4 }; PTRFUN supermanVTable[3] = { supermanSound1, supermanSound2, supermanSound3 }; // Toy structure with a vtable pointer typedef struct Toy { PTRFUN* vtable; } Toy; // Create a Barbie toy and set its vtable Toy* createBarbie() { Toy* barbie = (Toy*)malloc(sizeof(Toy)); barbie->vtable = barbieVTable; return barbie; } // Create a Superman toy and set its vtable Toy* createSuperman() { Toy* superman = (Toy*)malloc(sizeof(Toy)); superman->vtable = supermanVTable; return superman; } // Function to make a toy produce a sound void makeSound(Toy* self, int num) { // Check if the index is within bounds of the vtable if (self->vtable[num] != NULL) { printf("%s\n", self->vtable[num]()); } else { printf("Invalid sound index.\n"); } } int main(void) { // Create Barbie and Superman toys Toy* barbie = createBarbie(); Toy* superman = createSuperman(); // Make sounds using the vtable makeSound(barbie, 0); // Outputs: "Love and imagination can change the world." makeSound(barbie, 1); // Outputs: "You can be anything you want to be." makeSound(superman, 0); // Outputs: "Up, up, and away!" makeSound(superman, 1); // Outputs: "There is a superhero in all of us, we just need the courage to put on the cape." // Clean up free(barbie); free(superman); return 0; } #include #include // Barbie sound functions char const* barbieSound1(void) { return "Love and imagination can change the world."; } char const* barbieSound2(void) { return "You can be anything you want to be."; } char const* barbieSound3(void) { return "Every girl can make a difference."; } char const* barbieSound4(void) { return "Dream big and dare to fail."; } // Superman sound functions char const* supermanSound1(void) { return "Up, up, and away!"; } char const* supermanSound2(void) { return "There is a superhero in all of us, we just need the courage to put on the cape."; } char const* supermanSound3(void) { return "Dreams save us. Dreams lift us up and transform us."; } // Define a type for function pointers typedef char const* (*PTRFUN)(); // Vtables for Barbie and Superman PTRFUN barbieVTable[4] = { barbieSound1, barbieSound2, barbieSound3, barbieSound4 }; PTRFUN supermanVTable[3] = { supermanSound1, supermanSound2, supermanSound3 }; // Toy structure with a vtable pointer typedef struct Toy { PTRFUN* vtable; } Toy; // Create a Barbie toy and set its vtable Toy* createBarbie() { Toy* barbie = (Toy*)malloc(sizeof(Toy)); barbie->vtable = barbieVTable; return barbie; } // Create a Superman toy and set its vtable Toy* createSuperman() { Toy* superman = (Toy*)malloc(sizeof(Toy)); superman->vtable = supermanVTable; return superman; } // Function to make a toy produce a sound void makeSound(Toy* self, int num) { // Check if the index is within bounds of the vtable if (self->vtable[num] != NULL) { printf("%s\n", self->vtable[num]()); } else { printf("Invalid sound index.\n"); } } int main(void) { // Create Barbie and Superman toys Toy* barbie = createBarbie(); Toy* superman = createSuperman(); // Make sounds using the vtable makeSound(barbie, 0); // Outputs: "Love and imagination can change the world." makeSound(barbie, 1); // Outputs: "You can be anything you want to be." makeSound(superman, 0); // Outputs: "Up, up, and away!" makeSound(superman, 1); // Outputs: "There is a superhero in all of us, we just need the courage to put on the cape." // Clean up free(barbie); free(superman); return 0; } Virtual tables simplify the management of multiple function pointers, reduce redundancy, and make it easier to extend the system with new behaviors. To show how much the vtable plays a significant role, let’s look at an example where we want to use 10,000 instances of each toy in our program: #include typedef void (*FUNPTR)(); struct Superman { FUNPTR fptr1; FUNPTR fptr2; FUNPTR fptr3; FUNPTR fptr4; FUNPTR fptr5; FUNPTR fptr6; FUNPTR fptr7; FUNPTR fptr8; FUNPTR fptr9; FUNPTR fptr10; }superman; FUNPTR * barbieVTable[10]; struct Barbie { FUNPTR * vtable; }barbie; int main(void){ printf("Size sf Superman struct: %ld bytes.\n", sizeof(superman)); printf("Size of Barbie struct: %ld bytes, size of barbieVTable: %ld.\n", sizeof(barbie), sizeof(barbieVTable)); printf("Alocated memory for 10,000 Superman toys: %ld bytes.\n", 10000 * sizeof(superman)); printf("Alocated memory for 10,000 Barbie toys: %ld bytes.\n", 10000 * sizeof(barbie) + sizeof(barbieVTable)); return 0; } #include typedef void (*FUNPTR)(); struct Superman { FUNPTR fptr1; FUNPTR fptr2; FUNPTR fptr3; FUNPTR fptr4; FUNPTR fptr5; FUNPTR fptr6; FUNPTR fptr7; FUNPTR fptr8; FUNPTR fptr9; FUNPTR fptr10; }superman; FUNPTR * barbieVTable[10]; struct Barbie { FUNPTR * vtable; }barbie; int main(void){ printf("Size sf Superman struct: %ld bytes.\n", sizeof(superman)); printf("Size of Barbie struct: %ld bytes, size of barbieVTable: %ld.\n", sizeof(barbie), sizeof(barbieVTable)); printf("Alocated memory for 10,000 Superman toys: %ld bytes.\n", 10000 * sizeof(superman)); printf("Alocated memory for 10,000 Barbie toys: %ld bytes.\n", 10000 * sizeof(barbie) + sizeof(barbieVTable)); return 0; } #expected output: Size sf Superman struct: 80 bytes. Size of Barbie struct: 8 bytes, size of barbieVTable: 80. Alocated memory for 10,000 Superman toys: 800000 bytes. Alocated memory for 10,000 Barbie toys: 80080 bytes. #expected output: Size sf Superman struct: 80 bytes. Size of Barbie struct: 8 bytes, size of barbieVTable: 80. Alocated memory for 10,000 Superman toys: 800000 bytes. Alocated memory for 10,000 Barbie toys: 80080 bytes. Explanation: Explanation: struct Superman: This struct has ten function pointers (FUNPTR), directly embedded within the struct. Each function pointer typically takes up 8 bytes (on a 64-bit system), resulting in a total size of 80 bytes for each instance of Superman. struct Barbie: This struct has a single pointer to a vtable (barbieVTable), which contains ten function pointers. The size of the Barbie struct is 8 bytes (the size of a single pointer), and the vtable itself is an array of ten function pointers each of size 8 bytes, resulting in 80 bytes total for the vtable. struct Superman : This struct has ten function pointers (FUNPTR), directly embedded within the struct. Each function pointer typically takes up 8 bytes (on a 64-bit system), resulting in a total size of 80 bytes for each instance of Superman. struct Superman This struct has ten function pointers (FUNPTR), directly embedded within the struct. Each function pointer typically takes up 8 bytes (on a 64-bit system), resulting in a total size of 80 bytes for each instance of Superman. This struct has ten function pointers ( FUNPTR ), directly embedded within the struct. Each function pointer typically takes up 8 bytes (on a 64-bit system), resulting in a total size of 80 bytes for each instance of Superman . FUNPTR Superman struct Barbie : This struct has a single pointer to a vtable (barbieVTable), which contains ten function pointers. The size of the Barbie struct is 8 bytes (the size of a single pointer), and the vtable itself is an array of ten function pointers each of size 8 bytes, resulting in 80 bytes total for the vtable. struct Barbie This struct has a single pointer to a vtable (barbieVTable), which contains ten function pointers. The size of the Barbie struct is 8 bytes (the size of a single pointer), and the vtable itself is an array of ten function pointers each of size 8 bytes, resulting in 80 bytes total for the vtable. This struct has a single pointer to a vtable ( barbieVTable ), which contains ten function pointers. The size of the Barbie struct is 8 bytes (the size of a single pointer), and the vtable itself is an array of ten function pointers each of size 8 bytes, resulting in 80 bytes total for the vtable. barbieVTable Barbie Memory Allocation: Memory Allocation: For 10,000 Superman instances: Each Superman instance is 80 bytes. Total memory required = 10,000 * 80 bytes = 800,000 bytes. For 10,000 Barbie instances: Each Barbie instance is 8 bytes. Additionally, only one shared vtable of 80 bytes is required. Total memory required = (10,000 * 8 bytes) + 80 bytes = 80,000 + 80 bytes = 80,080 bytes. For 10,000 Superman instances : Each Superman instance is 80 bytes. Total memory required = 10,000 * 80 bytes = 800,000 bytes. For 10,000 Superman instances Each Superman instance is 80 bytes. Total memory required = 10,000 * 80 bytes = 800,000 bytes. Each Superman instance is 80 bytes. Superman Total memory required = 10,000 * 80 bytes = 800,000 bytes. For 10,000 Barbie instances : Each Barbie instance is 8 bytes. Additionally, only one shared vtable of 80 bytes is required. Total memory required = (10,000 * 8 bytes) + 80 bytes = 80,000 + 80 bytes = 80,080 bytes. For 10,000 Barbie instances Each Barbie instance is 8 bytes. Additionally, only one shared vtable of 80 bytes is required. Total memory required = (10,000 * 8 bytes) + 80 bytes = 80,000 + 80 bytes = 80,080 bytes. Each Barbie instance is 8 bytes. Barbie Additionally, only one shared vtable of 80 bytes is required. Total memory required = (10,000 * 8 bytes) + 80 bytes = 80,000 + 80 bytes = 80,080 bytes. Conclusion: Conclusion: This demonstration shows how using a vtable can reduce memory usage when creating multiple instances of objects that share the same set of functions. Benefits of Dynamic Polymorphism Flexibility: Allows new types to be added with minimal changes to existing code. Maintainability: Reduces the need for extensive conditional logic. Scalability: Supports the extension of the system by adding new object types and behaviors. Flexibility : Allows new types to be added with minimal changes to existing code. Flexibility Maintainability : Reduces the need for extensive conditional logic. Maintainability Scalability : Supports the extension of the system by adding new object types and behaviors. Scalability Practical Use Cases Dynamic polymorphism is often used in various software design patterns, such as the Strategy Pattern, State Pattern, and Command Pattern. These patterns use polymorphism to allow different behaviors and states to be easily swapped in and out. This makes the code more flexible and easier to maintain. If you have any questions or thoughts on this topic, feel free to leave a comment below!
