What Tools Can I Use to Visualize Keras Models? The old cliche "a picture is worth a thousand words" might be even more true when working with complex machine learning models. Unless you are blessed with a photographic memory, you can quickly lose track of the model architecture when just reading through code. Luckily, there are some easy ways to visualize machine learning models. This guide focuses on the visualization of Keras models and it uses the following model (the "test model") for demonstration: def build_model(pad_len, imu_dim, tof_dim, n_classes):
   def time_sum(x):
      return K.sum(x, axis=1)

   def squeeze_last_axis(x):
      return tf.squeeze(x, axis=-1)

   def expand_last_axis(x):
      return tf.expand_dims(x, axis=-1)

   filters_l1 = 64
   kernel_l1 = 3
   filters_l2 = 128
   kernel_l2 = 5
   reduction = 8
   pool_size = 2
   drop = 0.3
   wd = 1e-4

   inp = Input(shape=(pad_len, imu_dim + tof_dim))
   imu = Lambda(lambda t: t[:, :, :imu_dim])(inp)
   tof = Lambda(lambda t: t[:, :, imu_dim:])(inp)

   # First CNN branch
   shortcut_1 = imu
   x1 = Conv1D(filters_l1, kernel_l1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(imu)
   x1 = BatchNormalization()(x1)
   x1 = Activation("relu")(x1)
   x1 = Conv1D(filters_l1, kernel_l1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(x1)
   x1 = BatchNormalization()(x1)
   x1 = Activation("relu")(x1)

   ch = x1.shape[-1]
   se = GlobalAveragePooling1D()(x1)
   se = Dense(ch//reduction, activation="relu")(se)
   se = Dense(ch, activation="sigmoid")(se)
   se = Reshape((1, ch))(se)
   x1 = Multiply()([x1, se])

   if shortcut_1.shape[-1] != filters_l1:
      shortcut_1 = Conv1D(filters_l1, 1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(shortcut_1)
      shortcut_1 = BatchNormalization()(shortcut_1)

   x1 = add([x1, shortcut_1])
   x1 = Activation("relu")(x1)
   x1 = MaxPooling1D(pool_size)(x1)
   x1 = Dropout(drop)(x1)

   shortcut_2 = x1
   x1 = Conv1D(filters_l2, kernel_l2, padding="same", use_bias=False, kernel_regularizer=l2(wd))(x1)
   x1 = BatchNormalization()(x1)
   x1 = Activation("relu")(x1)
   x1 = Conv1D(filters_l2, kernel_l2, padding="same", use_bias=False, kernel_regularizer=l2(wd))(x1)
   x1 = BatchNormalization()(x1)
   x1 = Activation("relu")(x1)

   ch = x1.shape[-1]
   se = GlobalAveragePooling1D()(x1)
   se = Dense(ch//reduction, activation="relu")(se)
   se = Dense(ch, activation="sigmoid")(se)
   se = Reshape((1, ch))(se)
   x1 = Multiply()([x1, se])

   if shortcut_2.shape[-1] != filters_l2:
      shortcut_2 = Conv1D(filters_l2, 1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(shortcut_2)
      shortcut_2 = BatchNormalization()(shortcut_2)

   x1 = add([x1, shortcut_2])
   x1 = Activation("relu")(x1)
   x1 = MaxPooling1D(pool_size)(x1)
   x1 = Dropout(drop)(x1)

   # Second CNN branch
   x2 = Conv1D(filters_l1, kernel_l1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(tof)
   x2 = BatchNormalization()(x2)
   x2 = Activation("relu")(x2)
   x2 = MaxPooling1D(2)(x2)
   x2 = Dropout(0.2)(x2)
   x2 = Conv1D(filters_l2, kernel_l1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(x2)
   x2 = BatchNormalization()(x2)
   x2 = Activation("relu")(x2)
   x2 = MaxPooling1D(2)(x2)
   x2 = Dropout(0.2)(x2)

   merged = Concatenate()([x1, x2])

   xa = Bidirectional(LSTM(128, return_sequences=True, kernel_regularizer=l2(wd)))(merged)
   xb = Bidirectional(GRU(128, return_sequences=True, kernel_regularizer=l2(wd)))(merged)
   xc = GaussianNoise(0.09)(merged)
   xc = Dense(16, activation="elu")(xc)

   x = Concatenate()([xa, xb, xc])
   x = Dropout(0.4)(x)
   score = Dense(1, activation="tanh")(x)
   score = Lambda(squeeze_last_axis)(score)
   weights = Activation("softmax")(score)
   weights = Lambda(expand_last_axis)(weights)
   context = Multiply()([x, weights])
   x = Lambda(time_sum)(context)

   x = Dense(256, use_bias=False, kernel_regularizer=l2(wd))(x)
   x = BatchNormalization()(x)
   x = Activation("relu")(x)
   x = Dropout(0.5)(x)

   x = Dense(128, use_bias=False, kernel_regularizer=l2(wd))(x)
   x = BatchNormalization()(x)
   x = Activation("relu")(x)
   x = Dropout(0.3)(x)

   out = Dense(n_classes, activation="softmax", kernel_regularizer=l2(wd))(x)
   return Model(inp, out) def build_model(pad_len, imu_dim, tof_dim, n_classes):
   def time_sum(x):
      return K.sum(x, axis=1)

   def squeeze_last_axis(x):
      return tf.squeeze(x, axis=-1)

   def expand_last_axis(x):
      return tf.expand_dims(x, axis=-1)

   filters_l1 = 64
   kernel_l1 = 3
   filters_l2 = 128
   kernel_l2 = 5
   reduction = 8
   pool_size = 2
   drop = 0.3
   wd = 1e-4

   inp = Input(shape=(pad_len, imu_dim + tof_dim))
   imu = Lambda(lambda t: t[:, :, :imu_dim])(inp)
   tof = Lambda(lambda t: t[:, :, imu_dim:])(inp)

   # First CNN branch
   shortcut_1 = imu
   x1 = Conv1D(filters_l1, kernel_l1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(imu)
   x1 = BatchNormalization()(x1)
   x1 = Activation("relu")(x1)
   x1 = Conv1D(filters_l1, kernel_l1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(x1)
   x1 = BatchNormalization()(x1)
   x1 = Activation("relu")(x1)

   ch = x1.shape[-1]
   se = GlobalAveragePooling1D()(x1)
   se = Dense(ch//reduction, activation="relu")(se)
   se = Dense(ch, activation="sigmoid")(se)
   se = Reshape((1, ch))(se)
   x1 = Multiply()([x1, se])

   if shortcut_1.shape[-1] != filters_l1:
      shortcut_1 = Conv1D(filters_l1, 1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(shortcut_1)
      shortcut_1 = BatchNormalization()(shortcut_1)

   x1 = add([x1, shortcut_1])
   x1 = Activation("relu")(x1)
   x1 = MaxPooling1D(pool_size)(x1)
   x1 = Dropout(drop)(x1)

   shortcut_2 = x1
   x1 = Conv1D(filters_l2, kernel_l2, padding="same", use_bias=False, kernel_regularizer=l2(wd))(x1)
   x1 = BatchNormalization()(x1)
   x1 = Activation("relu")(x1)
   x1 = Conv1D(filters_l2, kernel_l2, padding="same", use_bias=False, kernel_regularizer=l2(wd))(x1)
   x1 = BatchNormalization()(x1)
   x1 = Activation("relu")(x1)

   ch = x1.shape[-1]
   se = GlobalAveragePooling1D()(x1)
   se = Dense(ch//reduction, activation="relu")(se)
   se = Dense(ch, activation="sigmoid")(se)
   se = Reshape((1, ch))(se)
   x1 = Multiply()([x1, se])

   if shortcut_2.shape[-1] != filters_l2:
      shortcut_2 = Conv1D(filters_l2, 1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(shortcut_2)
      shortcut_2 = BatchNormalization()(shortcut_2)

   x1 = add([x1, shortcut_2])
   x1 = Activation("relu")(x1)
   x1 = MaxPooling1D(pool_size)(x1)
   x1 = Dropout(drop)(x1)

   # Second CNN branch
   x2 = Conv1D(filters_l1, kernel_l1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(tof)
   x2 = BatchNormalization()(x2)
   x2 = Activation("relu")(x2)
   x2 = MaxPooling1D(2)(x2)
   x2 = Dropout(0.2)(x2)
   x2 = Conv1D(filters_l2, kernel_l1, padding="same", use_bias=False, kernel_regularizer=l2(wd))(x2)
   x2 = BatchNormalization()(x2)
   x2 = Activation("relu")(x2)
   x2 = MaxPooling1D(2)(x2)
   x2 = Dropout(0.2)(x2)

   merged = Concatenate()([x1, x2])

   xa = Bidirectional(LSTM(128, return_sequences=True, kernel_regularizer=l2(wd)))(merged)
   xb = Bidirectional(GRU(128, return_sequences=True, kernel_regularizer=l2(wd)))(merged)
   xc = GaussianNoise(0.09)(merged)
   xc = Dense(16, activation="elu")(xc)

   x = Concatenate()([xa, xb, xc])
   x = Dropout(0.4)(x)
   score = Dense(1, activation="tanh")(x)
   score = Lambda(squeeze_last_axis)(score)
   weights = Activation("softmax")(score)
   weights = Lambda(expand_last_axis)(weights)
   context = Multiply()([x, weights])
   x = Lambda(time_sum)(context)

   x = Dense(256, use_bias=False, kernel_regularizer=l2(wd))(x)
   x = BatchNormalization()(x)
   x = Activation("relu")(x)
   x = Dropout(0.5)(x)

   x = Dense(128, use_bias=False, kernel_regularizer=l2(wd))(x)
   x = BatchNormalization()(x)
   x = Activation("relu")(x)
   x = Dropout(0.3)(x)

   out = Dense(n_classes, activation="softmax", kernel_regularizer=l2(wd))(x)
   return Model(inp, out) As you can see, the model above is reasonably complex. It is used to learn patterns from intertial measurement unit ("IMU") and other sensor data. To be clear, I didn't build it. It is referenced from this Kaggle notebook. As you will note, the model definition in the original notebook uses custom objects to encapsulate certain logic that is repeated in the model design. I elected to remove those objects and explicity define the logic "inline" so as to better view the complete structure of the model in my slightly modified implementation. Kaggle notebook This guide discusses the following 3 visualization tools: Netron


The visualkeras Python package


TensorBoard Netron Netron Netron The visualkeras Python package The visualkeras Python package visualkeras TensorBoard TensorBoard TensorBoard 1. Using Netron to Visualize Your Keras Model Netron is arguably the simplest visualization tool available. You simply need to click on the Open Model... button on the home page and then select the model that you want to visualize. Here is a visualization of the first few layers of the test model: Netron Open Model... Once the model is loaded, you can click on nodes in the model graph to view their properties: You can export the model graph in .png and .svg formats by clicking on the main menu icon and selecting the appropriate export option. .png .svg 2. Using visualkeras to Visualize Your Keras Model visualkeras The visualkeras Python package is also very easy to use and offers a convenient way to visualize a model before training. You can install the package for your machine learning project using pip: visualkeras pip pip install visualkeras pip install visualkeras The following Python code demonstrates basic use of the package: # [Imports for your Keras model here...]
import visualkeras

# [Utility function to build your Keras model...]
def build_model(model_params):
   # [Your model definition here...]

# [Build the model...]
model = build_model(model_params)

# [Visualize the model...]
visualkeras.graph_view(model).show() # [Imports for your Keras model here...]
import visualkeras

# [Utility function to build your Keras model...]
def build_model(model_params):
   # [Your model definition here...]

# [Build the model...]
model = build_model(model_params)

# [Visualize the model...]
visualkeras.graph_view(model).show() The graph_view method produces the following graphic of the first few layers of the test model: graph_view The package also offers a layered_view method that produces a graphic of the model layers distinguished by type and size: layered_view visualkeras.layered_view(model, legend=True).show() visualkeras.layered_view(model, legend=True).show() As seen, passing True to the legend parameter generates a legend describing each layer: True legend One advantage of the visualkeras package is the control that it offers over how the graphics are displayed. You can review the parameters used to modify the graphic output on the package documentation page. visualkeras package documentation 3. Using TensorBoard to Visualize a Keras Model TensorBoard TensorBoard is a convenient option for visualization of a Keras model since it is installed along with TensorFlow. With a bit of "massaging", it is also possible to use TensorBoard to visualize the structure of a model before training. TensorBoard TensorFlow TensorBoard 3.1 Installing the jupyter-tensorboard Package jupyter-tensorboard This section uses TensorBoard within the context of a Jupyter notebook. This requires installation of the jupyter-tensorboard package, which in turn has a couple dependencies. Use the following steps to install jupyter-tensorboard: TensorBoard Jupyter notebook jupyter-tensorboard jupyter-tensorboard Install the jupyter package using pip install jupyer.


Use the pip install --upgrade notebook==6.4.12 command to downgrade the notebook package which was installed with the jupyter package installation process. The version of the notebook package installed with jupyter which is 7.4.5 as of this writing is not compatible with jupyter-tensorboard. This downgrade step installs a version of the notebook package that is compatible with jupyter-tensorboard. See this StackOverflow article for more information.


Install the jupyter-tensorboard package using pip install jupyter-tensorboard. Install the jupyter package using pip install jupyer. Install the jupyter package using pip install jupyer. jupyter pip install jupyer Use the pip install --upgrade notebook==6.4.12 command to downgrade the notebook package which was installed with the jupyter package installation process. The version of the notebook package installed with jupyter which is 7.4.5 as of this writing is not compatible with jupyter-tensorboard. This downgrade step installs a version of the notebook package that is compatible with jupyter-tensorboard. See this StackOverflow article for more information. Use the pip install --upgrade notebook==6.4.12 command to downgrade the notebook package which was installed with the jupyter package installation process. The version of the notebook package installed with jupyter which is 7.4.5 as of this writing is not compatible with jupyter-tensorboard. This downgrade step installs a version of the notebook package that is compatible with jupyter-tensorboard. See this StackOverflow article for more information. pip install --upgrade notebook==6.4.12 downgrade notebook jupyter notebook jupyter 7.4.5 jupyter-tensorboard notebook jupyter-tensorboard StackOverflow article Install the jupyter-tensorboard package using pip install jupyter-tensorboard. Install the jupyter-tensorboard package using pip install jupyter-tensorboard. jupyter-tensorboard pip install jupyter-tensorboard 3.2 Setting Up a Jupyter Notebook to Visualize Your Keras Model As mentioned above, you can visualize a Keras model in TensorBoard before training it. The following Jupyter notebook code demonstrates how to do it using the test model from the introductory section: TensorBoard # Cell 1: Imports
import tensorflow as tf
from tensorflow.keras.models import Model, load_model
from tensorflow.keras.layers import (
   Input, Conv1D, BatchNormalization, Activation, add, MaxPooling1D, Dropout,
   Bidirectional, LSTM, GlobalAveragePooling1D, Dense, Multiply, Reshape,
   Lambda, Concatenate, GRU, GaussianNoise
)
from tensorflow.keras.regularizers import l2
from tensorflow.keras import backend as K

# Cell 2: Set logs directory
LOG_DIR = "logs"

# Cell 3: Utility function to build model
# [`build-model` function for test model from introductory section here...]

# Cell 4: Build the model
model = build_model(398, 12, 335, 18)

# Cell 5: Compile the model
model.compile(optimizer="adam", loss="categorical_crossentropy", metrics=["accuracy"])

# Cell 6: Create a TensorBoard callback
tensorboard_callback = tf.keras.callbacks.TensorBoard(
   log_dir=LOG_DIR,
   histogram_freq=1,
   write_graph=True,
   profile_batch=0 # Disable profiling
)

# Cell 7: Create dummy `x` and `y` training inputs that match model input and output shapes
dummy_x_input = tf.random.normal((1, 398, 347)) # Batch size 1, input shape (398,347)
dummy_y_input = tf.random.normal((1, 18)) # Batch size 1, input shape (18, )

# Cell 8: "Train" the model for zero epochs to create a conceptual graph of the model
model.fit(dummy_x_input, dummy_y_input, epochs=0, batch_size=1, callbacks=[tensorboard_callback])

# Cell 9: Load the TensorBoard notebook extension
%load_ext tensorboard

# Cell 10: Launch TensorBoard
%tensorboard --logdir $LOG_DIR --host localhost # Cell 1: Imports
import tensorflow as tf
from tensorflow.keras.models import Model, load_model
from tensorflow.keras.layers import (
   Input, Conv1D, BatchNormalization, Activation, add, MaxPooling1D, Dropout,
   Bidirectional, LSTM, GlobalAveragePooling1D, Dense, Multiply, Reshape,
   Lambda, Concatenate, GRU, GaussianNoise
)
from tensorflow.keras.regularizers import l2
from tensorflow.keras import backend as K

# Cell 2: Set logs directory
LOG_DIR = "logs"

# Cell 3: Utility function to build model
# [`build-model` function for test model from introductory section here...]

# Cell 4: Build the model
model = build_model(398, 12, 335, 18)

# Cell 5: Compile the model
model.compile(optimizer="adam", loss="categorical_crossentropy", metrics=["accuracy"])

# Cell 6: Create a TensorBoard callback
tensorboard_callback = tf.keras.callbacks.TensorBoard(
   log_dir=LOG_DIR,
   histogram_freq=1,
   write_graph=True,
   profile_batch=0 # Disable profiling
)

# Cell 7: Create dummy `x` and `y` training inputs that match model input and output shapes
dummy_x_input = tf.random.normal((1, 398, 347)) # Batch size 1, input shape (398,347)
dummy_y_input = tf.random.normal((1, 18)) # Batch size 1, input shape (18, )

# Cell 8: "Train" the model for zero epochs to create a conceptual graph of the model
model.fit(dummy_x_input, dummy_y_input, epochs=0, batch_size=1, callbacks=[tensorboard_callback])

# Cell 9: Load the TensorBoard notebook extension
%load_ext tensorboard

# Cell 10: Launch TensorBoard
%tensorboard --logdir $LOG_DIR --host localhost If you run the Jupyter notebook code above, the last cell should output Launching TensorBoard. Once the cell execution is complete, you can navigate to http://localhost:6006 to view the TensorBoard dashboard. Launching TensorBoard http://localhost:6006 TensorBoard You can modify the TensorBoard port by passing the --port option to the %tensorboard magic command, e.g. %tensorboard --logdir $LOG_DIR --host localhost --port 8088. You can modify the TensorBoard port by passing the --port option to the %tensorboard magic command, e.g. %tensorboard --logdir $LOG_DIR --host localhost --port 8088. --port %tensorboard %tensorboard --logdir $LOG_DIR --host localhost --port 8088 Tip: I am running on Windows 10 where I have noted some curious behavior with respect to TensorBoard. To get TensorBoard to launch properly each time I run a Jupyter notebook, I have to first delete all temporary files in the C:\Users\[MY_WINDOWS_USERNAME]\AppData\Local\Temp\.tensorboard-info directory. Tip: I am running on Windows 10 where I have noted some curious behavior with respect to TensorBoard. To get TensorBoard to launch properly each time I run a Jupyter notebook, I have to first delete all temporary files in the C:\Users\[MY_WINDOWS_USERNAME]\AppData\Local\Temp\.tensorboard-info directory. Tip: C:\Users\[MY_WINDOWS_USERNAME]\AppData\Local\Temp\.tensorboard-info 3.3 Visualizing Your Keras Model with TensorBoard TensorBoard should automatically open to the Graphs dashboard. If it doesn't, you can click on the Graphs menu option or you can alternatively select Graphs from the drop-down menu. Graphs Graphs Graphs From the Graphs view, select Conceptual graph to view your model's structure. You should initially see a single node representing the entire model. Double-click on the node to see the sub-graph structure. Graphs Conceptual graph You can double-click on individual nodes within the sub-graph structure to view their properties. TensorBoard also allows you to export the model graph in .png format. .png Conclusion Each visualization method discussed above has its pros and cons. Netron is extremely easy to use with trained models whereas visualkeras is arguably the easiest tool to use with untrained models. As seen, TensorBoard can also be used with untrained models, but requires a bit more work to set up properly. visualkeras

This story contains new, firsthand information uncovered by the writer.

The code in this story is for educational purposes. The readers are solely responsible for whatever they build with it.

Walkthroughs, tutorials, guides, and tips. This story will teach you how to do something new or how to do something better.

3 Ways to Easily Visualize Keras Machine Learning Models

About Author

Comments

TOPICS

THIS ARTICLE WAS FEATURED IN

Related Stories

Building Your First Python GUI With Tkinter

Best AI Code Review Tools for Developers 2025

Elon Musk and Local Activists Have A Lot More in Common Than You Think

c/side CEO and Co-founder Simon Wijckmans on The Importance of Browser-side Security

Why Being Likable At Work Matters

Windows Sticky Keys Exploit: The War Veteran That Never Dies

Building Your First Python GUI With Tkinter

Best AI Code Review Tools for Developers 2025

Elon Musk and Local Activists Have A Lot More in Common Than You Think

c/side CEO and Co-founder Simon Wijckmans on The Importance of Browser-side Security

Why Being Likable At Work Matters

Windows Sticky Keys Exploit: The War Veteran That Never Dies

Light-Mode

Classic

Newspaper

Dark-Mode

Neon Noir

Minty

HN StartUps
