Writing a Frontend Web Framework with WebAssembly And Go

by Elliot ForbesNovember 4th, 2018
Read on Terminal Reader
Read this story w/o Javascript
tldt arrow

Too Long; Didn't Read

<a href="https://hackernoon.com/tagged/javascript" target="_blank">JavaScript</a> Frontend frameworks have undoubtedly helped to push the boundaries of what was previously possible in the context of a browser. Ever more complex applications have come out built on top of the likes of React, Angular and VueJS to name but a few and there’s the well known joke about how a new frontend <a href="https://hackernoon.com/tagged/framework" target="_blank">framework</a> seems to come out every day.

Companies Mentioned

Mention Thumbnail
Mention Thumbnail
featured image - Writing a Frontend Web Framework with WebAssembly And Go
Elliot Forbes HackerNoon profile picture

JavaScript Frontend frameworks have undoubtedly helped to push the boundaries of what was previously possible in the context of a browser. Ever more complex applications have come out built on top of the likes of React, Angular and VueJS to name but a few and there’s the well known joke about how a new frontend framework seems to come out every day.

However, this pace of development is exceptionally good news for developers around the world. With each new framework, we discover better ways of handling state, or rendering efficiently with things like the shadow DOM.

The latest trend however, seems to be moving towards writing these frameworks in languages other than JavaScript and compiling them into WebAssembly. We’re starting to see major improvements in the way that JavaScript and WebAssembly communicates thanks to the likes of Lin Clark and we’ll undoubtedly see more major improvements as WebAssembly starts to become more prominent in our lives.

Introduction

So, in this tutorial, I thought it would be a good idea to build the base of an incredibly simple frontend framework written in Go that compiles into WebAssembly. At a minimum, this will include the following features:

  • Function Registration
  • Components
  • Super Simplistic-Routing

I’m warning you now though that these are going to be incredibly simple and nowhere near production ready. If this is article is somewhat popular, I’ll hopefully be taking it forward however, and trying to build something that meets the requirements of a semi-decent frontend framework.

Github: The full source code of this project can be found on my github account. If you fancy contributing to the project, feel free, I’d be happy to get any pull requests!


elliotforbes/oak_A Go Based WebAssembly framework for building frontend applications in Go! - elliotforbes/oak_github.com

Starting Point

Right, let’s dive into our editor of choice and start coding! The first thing we’ll want to do is create a really simple index.html that will act as our entry point for our frontend framework:

<!doctype html><!--Copyright 2018 The Go Authors. All rights reserved.Use of this source code is governed by a BSD-stylelicense that can be found in the LICENSE file.--><html><head>	<meta charset="utf-8">	<title>Go wasm</title>	<script src="./static/wasm_exec.js"></script>	<script src="./static/entrypoint.js"></script></head><body>	  <div class="container">    <h2>Oak WebAssembly Framework</h2>  </div></body></html>

You’ll notice these have 2 js files being imported at the top, these allow us to execute our finished WebAssembly binary. The first of which is about 414 lines long so, in the interest of keeping this tutorial readable, I recommend you download it from here: https://github.com/elliotforbes/oak/blob/master/examples/blog/static/wasm_exec.js

The second is our entrypoint.js file. This will fetch and run the lib.wasm that we’ll be building very shortly.

// static/entrypoint.jsconst go = new Go();WebAssembly.instantiateStreaming(fetch("lib.wasm"), go.importObject).then((result) => {    go.run(result.instance);});

Finally, now that we have that out of the way, we can start diving into some Go code! Create a new file called main.go which will contain the entry point to our Oak Web Framework!

// main.gopackage mainfunc main() {	println("Oak Framework Initialized")}

This is as simple as it gets. We’ve created a really simple Go program that should just print out Oak Framework Initialized when we open up our web app. To verify that everything works, we need to compile this using the following command:

$ GOOS=js GOARCH=wasm go build -o lib.wasm main.go

This should then build our Go code and output our lib.wasm file which we referenced in our entrypoint.js file.

Awesome, if everything worked, then we are ready to try it out in the browser! We can use a really simple file server like this:

// server.gopackage mainimport (	"flag"	"log"	"net/http")var (	listen = flag.String("listen", ":8080", "listen address")	dir    = flag.String("dir", ".", "directory to serve"))func main() {	flag.Parse()	log.Printf("listening on %q...", *listen)	log.Fatal(http.ListenAndServe(*listen, http.FileServer(http.Dir(*dir))))}

You can then serve your application by typing go run server.go and you should be able to access your app from [http://localhost:8080](http://localhost:8080.).

Function Registration

Ok, so we’ve got a fairly basic print statement working, but in the grand scheme of things, I don’t quite think that qualifies it as a Web Framework just yet.

Let’s take a look at how we can build functions in Go and register these so we can call them in our index.html. We’ll create a new utility function which will take in both a string which will be the name of our function as well as the Go function it will map to.

Add the following to your existing main.go file:

// main.goimport "syscall/js"// RegisterFunctionfunc RegisterFunction(funcName string, myfunc func(i []js.Value)) {	js.Global().Set(funcName, js.NewCallback(myfunc))}

So, this is where things start to become a bit more useful. Our framework now allows us to register functions so users of the framework can start creating their own functionality.

Other projects using our framework can start to register their own functions that can subsequently be used within their own frontend applications.

Components

So, I guess the next thing we need to consider adding to our framework is the concept of components. Basically, I want to be able to define a components/ directory within a project that uses this, and within that directory I want to be able to build like a home.go component that features all the code needed for my homepage.

So, how do we go about doing this?

Well, React tends to feature classes that feature render() functions which return the HTML/JSX/whatever code you wish to render for said component. Let’s steal this and use it within our own components.

I essentially want to be able to do something like this within a project that uses this framework:

package componentstype HomeComponent struct{}var Home HomeComponentfunc (h HomeComponent) Render() string {	return "<h2>Home Component</h2>"}

So, within my components package, I define a HomeComponent which features a Render() method which returns our HTML.

In order to add components to our framework, we’ll keep it simple and just define an interface to which any components we subsequently define will have to adhere to. Create a new file called components/comopnent.go within our Oak framework:

// components/component.gopackage componenttype Component interface {	Render() string}

What happens if we want to add new functions to our various components? Well, this allows us to do just that. We can use the oak.RegisterFunction call within the init function of our component to register any functions we want to use within our component!

package componentsimport (	"syscall/js"	"github.com/elliotforbes/oak")type AboutComponent struct{}var About AboutComponentfunc init() {	oak.RegisterFunction("coolFunc", CoolFunc)}func CoolFunc(i []js.Value) {	println("does stuff")}func (a AboutComponent) Render() string {	return `<div>						<h2>About Component Actually Works</h2>						<button onClick="coolFunc();">Cool Func</button>					</div>`}

When we combine this with a router, we should be able to see our HTML being rendered to our page and we should be able to click that button which calls coolFunc() and it will print out does stuff within our browser console!

Awesome, let’s see how we can go about building a simple router now.

Building a Router

Ok, so we’ve got the concept of components within our web framework down. We’ve almost finished right?

Not quite, the next thing we’ll likely need is a means to navigate between different components. Most frameworks seem to have a <div> with a particular id that they bind to and render all their components within, so we’ll steal that same tactic within Oak.

Let’s create a router/router.go file within our oak framework so that we can start hacking away.

Within this, we’ll want to map string paths to components, we wont do any URL checking, we’ll just keep everything in memory for now to keep things simple:

// router/router.gopackage routerimport (	"syscall/js"	"github.com/elliotforbes/oak/component")type Router struct {	Routes map[string]component.Component}var router Routerfunc init() {	router.Routes = make(map[string]component.Component)}

So within this, we’ve created a new Router struct which contains Routes which are a map of strings to the components we defined in the previous section.

Routing won’t be a mandatory concept within our framework, we’ll want users to choose when they wish to initialize a new router. So let’s create a new function that will register a Link function and also bind the first route in our map to our <div id="view"/> html tag:

// router/router.go// ...func NewRouter() {	js.Global().Set("Link", js.NewCallback(Link))	js.Global().Get("document").Call("getElementById", "view").Set("innerHTML", "")}func RegisterRoute(path string, component component.Component) {	router.Routes[path] = component}func Link(i []js.Value) {	println("Link Hit")	comp := router.Routes[i[0].String()]	html := comp.Render()	js.Global().Get("document").Call("getElementById", "view").Set("innerHTML", html)}

You should notice, we’ve created a RegisterRoute function which allows us to register a path to a given component.

Our Link function is also pretty cool in the sense that it will allow us to navigate between various components within a project. We can specify really simple <button> elements to allow us to navigate to registered paths like so:

<button onClick="Link('link')">Clicking this will render our mapped Link component</button>

Awesome, so we’ve got a really simple router up and running now, if we wanted to use this in a simple application we could do so like this:

// my-project/main.gopackage mainimport (	"github.com/elliotforbes/oak"	"github.com/elliotforbes/oak/examples/blog/components"	"github.com/elliotforbes/oak/router")func main() {	// Starts the Oak framework	oak.Start()	// Starts our Router	router.NewRouter()	router.RegisterRoute("home", components.Home)	router.RegisterRoute("about", components.About)	// keeps our app running	done := make(chan struct{}, 0)	<-done}

A Full Example

With all of this put together, we can start building really simple web applications that feature components and routing. If you want to see a couple of examples as to how this works, then check out the examples within the official repo: elliotforbes/oak/examples

Challenges Going Forward

The code in this framework is in no way production ready, but I’m hoping this post kicks off good discussion as to how we can start building more production ready frameworks in Go.

If nothing else, it starts the journey of identifying what still has to be done to make this a viable alternative to the likes of React/Angular/VueJS, all of which are phenomenal frameworks that massively speed up developer productivity.

I’m hoping this article motivates some of you to go off and start looking at how you can improve on this incredibly simple starting point.

Conclusion

If you enjoyed this tutorial, then please feel free to share it to your friends, on your twitter, or wherever you feel like, it really helps the site and directly supports me writing more!

I’m also on YouTube, so feel free to subscribe to my channel for more Go content:


The full source code for the Oak framework can be found here: github.com/elliotforbes/oak. Feel free to submit PRs!

Originally published at tutorialedge.net.
