Why You Should Break Your App with Chaos Proxy

Chaos Engineering is a practice where you introduce controlled failures into your system to test its resilience and improve its reliability. It's a fun concept that can help you identify weaknesses in your application and infrastructure, but probably not something that you do every day - not everyone has the luxury of a Netflix-scale engineering team to manage a Netflix-scale infrastructure. But the concept is valid and useful even for small teams and projects. In this article, we'll explore how to use the principles of Chaos Engineering to test UI loading states. We will use a simple tool called Chaos Proxy to implement and test a delayed loading indicator in a Network.js application. Chaos Proxy The Application Imagine you're working for a company in the music streaming space. A small (but important) part of your application is a playlist feature that shows users their playlists and the songs within them. The app is built with Next.js and uses React Query for data fetching. It has a few API routes to get playlists and songs, and two main pages: one for listing all playlists and another for showing the details of a selected playlist. Next.js React Query The code for the app is available on GitHub. Feel free to clone it and follow along: GitHub git clone https://github.com/gkoos/article-chaos-proxy.git cd article-chaos-proxy npm install npm run dev git clone https://github.com/gkoos/article-chaos-proxy.git cd article-chaos-proxy npm install npm run dev The app (well more like a stub) has the following features: API Routes:

GET /api/playlists - Returns all playlists (id, name) GET /api/playlists/:id - Returns playlist details (id, name, description) GET /api/playlists/:id/songs - Returns songs in a playlist ([{order, songId}]) GET /api/song/:id - Returns song details (id, artist, title)

Pages:

/ - Lists all playlists, clickable to /playlist/:playlistId /playlist/:playlistId - Shows playlist details and ordered songs API Routes:

GET /api/playlists - Returns all playlists (id, name) GET /api/playlists/:id - Returns playlist details (id, name, description) GET /api/playlists/:id/songs - Returns songs in a playlist ([{order, songId}]) GET /api/song/:id - Returns song details (id, artist, title) API Routes GET /api/playlists - Returns all playlists (id, name) GET /api/playlists/:id - Returns playlist details (id, name, description) GET /api/playlists/:id/songs - Returns songs in a playlist ([{order, songId}]) GET /api/song/:id - Returns song details (id, artist, title) GET /api/playlists - Returns all playlists (id, name) GET /api/playlists GET /api/playlists/:id - Returns playlist details (id, name, description) GET /api/playlists/:id GET /api/playlists/:id/songs - Returns songs in a playlist ([{order, songId}]) GET /api/playlists/:id/songs GET /api/song/:id - Returns song details (id, artist, title) GET /api/song/:id Pages:

/ - Lists all playlists, clickable to /playlist/:playlistId /playlist/:playlistId - Shows playlist details and ordered songs Pages / - Lists all playlists, clickable to /playlist/:playlistId /playlist/:playlistId - Shows playlist details and ordered songs / - Lists all playlists, clickable to /playlist/:playlistId / /playlist/:playlistId /playlist/:playlistId - Shows playlist details and ordered songs /playlist/:playlistId It uses React Query for data fetching. Cypress is set up for end-to-end testing and a few basic e2e tests are included. In our very sloppy setup, to run Cypress, make sure the app is running and then run: Cypress npx cypress open npx cypress open The Problem So you've built this app, and you're moderately happy with it. (I mean both the code quality and the DX are both meh, I'm sure you could do better, but for the sake of this article, let's say it's good enough.) You're about to grab a mocha latte, or a plant based cappuccino, when your manager comes to you and says: "Hey, I got a great idea! Let's add a loading indicator to the playlist page. You know, like a spinner or something. But not always, only when the network is slow. Like, after 2 seconds or so. And while the data is loading, we should show a skeleton screen. You know, those grey boxes that look like the content but aren't. It'll be super cool and modern! Can you do that?" "Hey, I got a great idea! Let's add a loading indicator to the playlist page. You know, like a spinner or something. But not always, only when the network is slow. Like, after 2 seconds or so. And while the data is loading, we should show a skeleton screen. You know, those grey boxes that look like the content but aren't. It'll be super cool and modern! Can you do that?" Well, sure, you're an engineer. You can do that. But how do you test it? How do you simulate a slow network? You could use the browser's dev tools to throttle the network, but that's manual and tedious. You could use a library like msw to mock the API responses, but that's a bit overkill for this simple app. You could even modify the API routes to introduce artificial delays, but that would be messy and not very elegant. Or use something like toxiproxy to simulate network conditions, but that's also a bit heavy for this use case. msw toxiproxy Essentially, your problem is two-fold: you have to simulate a slow network for both development and testing (and here doesn't even matter which one you do first, this is not a TDD-focused article). For testing, you want to be able to run your tests in CI/CD pipelines, where you can't rely on manual network throttling. You could mock the API calls and use fake timers, but that gets you to a point where your tests are more complex than your code and not even testing the real behavior of the app. For development, you want to be able to see the loading indicator in action without having to change your code or the API routes. The Solution: Chaos Proxy Between ridiculously complex chaos engineering tools (like Gremlin and Chaos Monkey) and convoluted, overengineered testing techniques, you want something lightweight and easy that covers both your development and testing needs. Gremlin Chaos Monkey That's where Chaos Proxy comes in. It's a simple reverse proxy that adds latency, drops requests, and simulates other network conditions. As a chaos engineering tool, it's barely a child's toy, but for this particular use case, it's perfect. It can be used to simulate a slow network for both development and testing, without modifying the app or the API routes. Chaos Proxy Implementing the Skeleton and the Loading Indicator This is where some of you raise their eyebrows and say "Wait, shouldn't we start with the tests first?" Sure, you can do that. In fact, everything in this article stays valid if you do TDD. But for the sake of simplicity, let's just quickly implement the feature first and then test it. Before you roll up your sleeves and start coding, let's see what your manager actually wants: A skeleton screen that shows up while the data is loading. A loading indicator that shows up after 2 seconds of waiting for the API response. A skeleton screen that shows up while the data is loading. A loading indicator that shows up after 2 seconds of waiting for the API response. The Skeleton Screen You decide to start with the skeleton screen. It's usually implemented as a set of grey boxes that mimic the layout of the content. You can use a library like react-loading-skeleton to easily create skeleton screens. react-loading-skeleton You install the library: npm install react-loading-skeleton npm install react-loading-skeleton And then you modify the playlist page to show the skeleton screen while the data is loading: // pages/playlist/[playlistId].js import Skeleton from 'react-loading-skeleton'; import 'react-loading-skeleton/dist/skeleton.css';

...

if (loadingPlaylist || loadingSongs || songQueries.some(q => q.isLoading)) { return ( {Array.from({ length: 5 }).map((_, i) => ( ))} ); }

... // pages/playlist/[playlistId].js import Skeleton from 'react-loading-skeleton'; import 'react-loading-skeleton/dist/skeleton.css';

...

if (loadingPlaylist || loadingSongs || songQueries.some(q => q.isLoading)) { return ( {Array.from({ length: 5 }).map((_, i) => ( ))} ); }

... The full code for this chapter is available on the improve-playlist-ui branch: improve-playlist-ui git checkout improve-playlist-ui git checkout improve-playlist-ui If you run the app now, you'll see the skeleton screen while the data is loading. But since your network is fast, it loads almost instantly, and you don't get to see the skeleton screen for more than a split second. Also, note that react-query has a built-in caching mechanism, so if you navigate away and back to the playlist page, it will show the cached data immediately without showing the skeleton screen again (until you refresh the page or restart the app). Setting Up Chaos Proxy So far so good, the skeleton screen seems to be working as expected. But for the loading indicator, even if your implementation is correct, you won't be able to see it in action without a slow network. This is the right time to set up Chaos Proxy and simulate a slow network. First, install it as a dev dependency: npm install --save-dev chaos-proxy npm install --save-dev chaos-proxy Then create a chaos.yaml file in the root of your project with the following content: chaos.yaml port: 8080 target: http://localhost:3000

routes: /api: - latency: ms: 2000 - cors: {} port: 8080 target: http://localhost:3000

routes: /api: - latency: ms: 2000 - cors: {} This configuration tells Chaos Proxy to listen on port 8080 and forward requests to your Next.js app running on port 3000. It also adds a latency of 2000 milliseconds (2 seconds) to all /api/*requests. Last but not least, it enables CORS for the API endpoints, which is important because your app will be making requests to a different origin (localhost:8080 instead of localhost:3000)! /api/* Now you can start Chaos Proxy in a separate terminal window: npx chaos-proxy npx chaos-proxy With Chaos Proxy running, you can now access your app through the proxy by navigating to http://localhost:8080 in your browser. This way, all requests to your app will go through Chaos Proxy and will have the added latency. http://localhost:8080 Make sure the app is running (npm run dev), then try to curl the playlists API through the proxy to see the delay in action: npm run dev curl http://localhost:8080/api/playlists curl http://localhost:8080/api/playlists You should see that the response takes about 2 seconds to arrive. Now you want to make sure your app uses the proxy for API requests. Currently, the app is configured to read the base API URL from an environment variable called NEXT_PUBLIC_BASE_API_URL. You can set this variable to point to the proxy URL when running the app. NEXT_PUBLIC_BASE_API_URL NEXT_PUBLIC_BASE_API_URL=http://localhost:8080/api npm run dev NEXT_PUBLIC_BASE_API_URL=http://localhost:8080/api npm run dev And now, if you navigate to http://localhost:3000 in your browser, you should see the app working through the proxy. When you go to a playlist page, you should see the skeleton screen for 2 seconds before the data loads. http://localhost:3000 The Loading Indicator Now that you have the skeleton screen working and the slow network simulation set up, you can implement the loading indicator. You decide to use a simple text-based indicator that says "Retrieving data..." for simplicity. You can bet your manager will want to change it later. // pages/playlist/[playlistId].js import React from "react"; import { useQuery, useQueries } from "@tanstack/react-query"; import { useRouter } from "next/router"; import Skeleton from "react-loading-skeleton"; import "react-loading-skeleton/dist/skeleton.css";

export default function PlaylistPage() { const router = useRouter(); const { playlistId } = router.query;

const { data: playlist, isLoading: loadingPlaylist } = useQuery({ queryKey: ["playlist", playlistId], queryFn: () => fetchPlaylist(playlistId), enabled: !!playlistId, }); const { data: songOrders, isLoading: loadingSongs } = useQuery({ queryKey: ["playlistSongs", playlistId], queryFn: () => fetchPlaylistSongs(playlistId), enabled: !!playlistId, });

const songQueries = useQueries({ queries: (songOrders || []).map(({ songId }) => ({ queryKey: ["song", songId], queryFn: () => fetchSong(songId), enabled: !!songId, })), });

// Delayed loading indicator state const [showDelayedIndicator, setShowDelayedIndicator] = React.useState(false); const anySongLoading = songQueries.some((q) => q.isLoading); React.useEffect(() => { let timer; if (loadingPlaylist || loadingSongs || anySongLoading) { timer = setTimeout(() => setShowDelayedIndicator(true), 2000); } else { setShowDelayedIndicator(false); } return () => clearTimeout(timer); }, [loadingPlaylist, loadingSongs, anySongLoading]);

if (loadingPlaylist || loadingSongs || anySongLoading) { return ( {showDelayedIndicator && ( Retrieving data... )} {Array.from({ length: 5 }).map((_, i) => ( ))} ); }

if (!playlist) return ( Playlist not found );

return ( &larr; Back to playlists {playlist.name} {playlist.description}

Songs {songQueries.map((q, i) => ( {q.isLoading ? ( "" ) : q.data ? ( <> {q.data.title} by{" "} {q.data.artist} ) : ( "Not found" )} ))} ); } // pages/playlist/[playlistId].js import React from "react"; import { useQuery, useQueries } from "@tanstack/react-query"; import { useRouter } from "next/router"; import Skeleton from "react-loading-skeleton"; import "react-loading-skeleton/dist/skeleton.css";

export default function PlaylistPage() { const router = useRouter(); const { playlistId } = router.query;

const { data: playlist, isLoading: loadingPlaylist } = useQuery({ queryKey: ["playlist", playlistId], queryFn: () => fetchPlaylist(playlistId), enabled: !!playlistId, }); const { data: songOrders, isLoading: loadingSongs } = useQuery({ queryKey: ["playlistSongs", playlistId], queryFn: () => fetchPlaylistSongs(playlistId), enabled: !!playlistId, });

const songQueries = useQueries({ queries: (songOrders || []).map(({ songId }) => ({ queryKey: ["song", songId], queryFn: () => fetchSong(songId), enabled: !!songId, })), });

// Delayed loading indicator state const [showDelayedIndicator, setShowDelayedIndicator] = React.useState(false); const anySongLoading = songQueries.some((q) => q.isLoading); React.useEffect(() => { let timer; if (loadingPlaylist || loadingSongs || anySongLoading) { timer = setTimeout(() => setShowDelayedIndicator(true), 2000); } else { setShowDelayedIndicator(false); } return () => clearTimeout(timer); }, [loadingPlaylist, loadingSongs, anySongLoading]);

if (loadingPlaylist || loadingSongs || anySongLoading) { return ( {showDelayedIndicator && ( Retrieving data... )} {Array.from({ length: 5 }).map((_, i) => ( ))} ); }

if (!playlist) return ( Playlist not found );

return ( &larr; Back to playlists {playlist.name} {playlist.description}

Songs {songQueries.map((q, i) => ( {q.isLoading ? ( "" ) : q.data ? ( <> {q.data.title} by{" "} {q.data.artist} ) : ( "Not found" )} ))} ); } Remember, the file is in the repo. And that's it! You now have a skeleton screen that shows up immediately while the data is loading, and a loading indicator that shows up after 2 seconds if the data is still loading. You can see both in action by running the app through Chaos Proxy. The latency injected by Chaos Proxy will ensure that the loading indicator appears after two seconds. Testing with Cypress Now that you have the feature implemented and working, it's time to test it (well, maybe you should have done that first, but let's not split hairs). You can use Cypress to write end-to-end tests for the playlist page, including the loading states. The code for the tests is available on the adding-tests branch. Make sure to check it out: adding-tests git checkout adding-tests git checkout adding-tests One way to test both features is to write a test that navigates to a playlist page and checks for the presence of the skeleton screen and the loading indicator. Here's an example: // cypress/e2e/playlist.cy.js describe('Playlist page loading states', () => { it('shows skeleton and delayed loading indicator', () => { cy.visit('/playlist/1');

// Skeleton should be visible immediately cy.get('.react-loading-skeleton').should('exist');

// Delayed loading indicator should appear after ~2s cy.contains('Retrieving data...').should('not.exist'); cy.wait(2100); // Wait slightly longer than proxy latency cy.contains('Retrieving data...').should('exist');

// After data loads, both skeleton and indicator disappear cy.get('.react-loading-skeleton', { timeout: 5000 }).should('not.exist'); cy.contains('Retrieving data...').should('not.exist'); }); }); // cypress/e2e/playlist.cy.js describe('Playlist page loading states', () => { it('shows skeleton and delayed loading indicator', () => { cy.visit('/playlist/1');

// Skeleton should be visible immediately cy.get('.react-loading-skeleton').should('exist');

// Delayed loading indicator should appear after ~2s cy.contains('Retrieving data...').should('not.exist'); cy.wait(2100); // Wait slightly longer than proxy latency cy.contains('Retrieving data...').should('exist');

// After data loads, both skeleton and indicator disappear cy.get('.react-loading-skeleton', { timeout: 5000 }).should('not.exist'); cy.contains('Retrieving data...').should('not.exist'); }); }); To run the end to end tests, you have to make sure both the app and Chaos Proxy are running. Build the app with npm run build and then create a new file called start-next-chaos.js in the root of your project with the following content: npm run build start-next-chaos.js // start-next-chaos.js // Programmatically start Next.js and Chaos Proxy in one process (no child processes) const next = require('next'); const http = require('http'); const { startServer } = require('chaos-proxy/dist/index.js');

const NEXT_PORT = 3000; const CHAOS_PORT = 8080;

// Set env var for Next.js to use the proxy process.env.NEXT_PUBLIC_BASE_API_URL = `http://localhost:${CHAOS_PORT}/api`;

// Start Next.js (production mode) const app = next({ dev: false, port: NEXT_PORT }); const handle = app.getRequestHandler();

app.prepare() .then(() => { http.createServer((req, res) => handle(req, res)).listen(NEXT_PORT, (err) => { if (err) { console.error('Failed to start Next.js:', err); process.exit(1); } console.log(`Next.js ready on http://localhost:${NEXT_PORT}`);

// Start Chaos Proxy programmatically startServer({ port: CHAOS_PORT, target: `http://localhost:${NEXT_PORT}`, global: [ { latency: { ms: 2000 } }, { cors: {} } ] }, { verbose: true });

console.log(`Chaos Proxy ready on http://localhost:${CHAOS_PORT}`);

// Keep the process alive setInterval(() => {}, 1000 * 60 * 60); }); }) .catch((err) => { console.error('Error preparing Next.js app:', err); process.exit(1); }); // start-next-chaos.js // Programmatically start Next.js and Chaos Proxy in one process (no child processes) const next = require('next'); const http = require('http'); const { startServer } = require('chaos-proxy/dist/index.js');

const NEXT_PORT = 3000; const CHAOS_PORT = 8080;

// Set env var for Next.js to use the proxy process.env.NEXT_PUBLIC_BASE_API_URL = `http://localhost:${CHAOS_PORT}/api`;

// Start Next.js (production mode) const app = next({ dev: false, port: NEXT_PORT }); const handle = app.getRequestHandler();

app.prepare() .then(() => { http.createServer((req, res) => handle(req, res)).listen(NEXT_PORT, (err) => { if (err) { console.error('Failed to start Next.js:', err); process.exit(1); } console.log(`Next.js ready on http://localhost:${NEXT_PORT}`);

// Start Chaos Proxy programmatically startServer({ port: CHAOS_PORT, target: `http://localhost:${NEXT_PORT}`, global: [ { latency: { ms: 2000 } }, { cors: {} } ] }, { verbose: true });

console.log(`Chaos Proxy ready on http://localhost:${CHAOS_PORT}`);

// Keep the process alive setInterval(() => {}, 1000 * 60 * 60); }); }) .catch((err) => { console.error('Error preparing Next.js app:', err); process.exit(1); }); Build the app with with BASE_API_URL pointing to the proxy: BASE_API_URL NEXT_PUBLIC_BASE_API_URL=http://localhost:8080/api npm run build NEXT_PUBLIC_BASE_API_URL=http://localhost:8080/api npm run build Then run both the app and Chaos Proxy: node start-next-chaos.js node start-next-chaos.js And then in another terminal, you can finally run the tests with the following command: npx cypress run npx cypress run And there you have it! The tests should pass, confirming that both the skeleton screen and the delayed loading indicator work as expected. Now this setup is more than messy. In a real-world scenarion you'd probably containerize everything or for the very least use something like concurrently to run both processes in parallel. But my aim was only to show how you can run chaos-proxy both from the command line and programmatically from Node.js (in start-next-chaos.js). concurrently chaos-proxy start-next-chaos.js Conclusion Of course, you can use Chaos Proxy as a lightweight chaos engineering tool to test other failure scenarios, like dropped requests or random errors. You can also use it to simulate different network conditions, like high latency or low bandwidth. But where it really can be useful is simpler use cases like this one, where you just want deterministic end-to-end tests and a better development experience without the overhead of complex tools or convoluted testing techniques.
