Last week, I described several approaches to OpenTelemetry on the JVM, their requirements, and their different results. This week, I want to highlight several gotchas found across stacks in the zero-code instrumentation. several approaches to OpenTelemetry on the JVM The Promise of OpenTelemetry Since its inception, OpenTelemetry has unified the 3 pillars of observability. In the distributed tracing space, it replaced proprietary protocols Zipkin and Jaeger. IMHO, it achieved such success for several reasons: First, a huge industry pressure to work across proprietary tools
Zero-code instrumentation, allowing developers to be unconcerned with OpenTelemetry
Easy and unified configuration mechanism via environment variables. First, a huge industry pressure to work across proprietary tools Zero-code instrumentation, allowing developers to be unconcerned with OpenTelemetry Easy and unified configuration mechanism via environment variables. The latter is a boon for the Ops team, as they don't have to know the underlying framework (or stack!) details. They only need to check the Environment Variable Specification, and they are done. Environment Variable Specification Here's a simple snippet to illustrate my point: environment:
  OTEL_EXPORTER_OTLP_ENDPOINT: http://collector:4317             #1
  OTEL_SERVICE_NAME: foobar                                      #2 environment:
  OTEL_EXPORTER_OTLP_ENDPOINT: http://collector:4317             #1
  OTEL_SERVICE_NAME: foobar                                      #2 Configure the endpoint to send data to
Set the component's name Configure the endpoint to send data to Set the component's name From the above, you can't guess what the underlying stack is. On the OpenTelemetry side, different developers contribute to different language libraries. Developers of the Java agent are different from those of the Python library. Moreover, each stack has specific approaches and limitations. Developers of the Java agent those of the Python library It naturally creates differences in the different implementations. Gotchas Here are a couple of gotchas I found out, but the list is not exhaustive. Path or No Path? Let's start easy with a gotcha that exists across stacks. OpenTelemetry offers some configuration parameters for endpoints. A generic one, to use for an OpenTelemetry Collector that accepts all signals: OTEL_EXPORTER_OTLP_ENDPOINT
Parameters specialized for a single signal, e.g., OTEL_EXPORTER_OTLP_TRACES_ENDPOINT A generic one, to use for an OpenTelemetry Collector that accepts all signals: OTEL_EXPORTER_OTLP_ENDPOINT OTEL_EXPORTER_OTLP_ENDPOINT Parameters specialized for a single signal, e.g., OTEL_EXPORTER_OTLP_TRACES_ENDPOINT e.g. OTEL_EXPORTER_OTLP_TRACES_ENDPOINT In the latter case, one can set the root path to the endpoint, e.g, http://collector:4317. The SDK will automatically append the default path, depending on the signal type. For example, it appends /v1/traces for the OTEL_EXPORTER_OTLP_TRACES_ENDPOINT configuration parameter. e.g http://collector:4317 /v1/traces OTEL_EXPORTER_OTLP_TRACES_ENDPOINT Alternatively, one can set the full path to the endpoint, e.g, http://collector:4317/v1/traces. full e.g http://collector:4317/v1/traces The gotcha will catch you when OpenTelemetry evolves to v2 if you didn't use paths. Because the library will automatically append /v1/<xxx>; you'll have to make sure the backend offers both /v1 and /v2 endpoints. /v1/<xxx> /v1 /v2 Python Logging To open the list, here's the first gotcha: by default, the Python library doesn't send logging data. It must be enabled explicitly! environment:
  OTEL_PYTHON_LOGGING_AUTO_INSTRUMENTATION_ENABLED: true         #1
  OTEL_EXPORTER_OTLP_ENDPOINT: http://collector:4317
  OTEL_SERVICE_NAME: foobar environment:
  OTEL_PYTHON_LOGGING_AUTO_INSTRUMENTATION_ENABLED: true         #1
  OTEL_EXPORTER_OTLP_ENDPOINT: http://collector:4317
  OTEL_SERVICE_NAME: foobar Enable logs Enable logs Developers also must be involved: Unlike Traces and Metrics, there is no equivalent Logs API. There is only an SDK. For Python, you use the Python logger library, and then the OTel SDK attaches an OTLP handler to the root logger, turning the Python logger into an OTLP logger. One way to accomplish this is documented in the logs example in the OpenTelemetry Python repository.
-- Logs Auto-Instrumentation Example Unlike Traces and Metrics, there is no equivalent Logs API. There is only an SDK. For Python, you use the Python logger library, and then the OTel SDK attaches an OTLP handler to the root logger, turning the Python logger into an OTLP logger. One way to accomplish this is documented in the logs example in the OpenTelemetry Python repository. logger -- Logs Auto-Instrumentation Example Logs Auto-Instrumentation Example Micrometer Tracing Before OpenTelemetry, Jaeger and Zipkin reigned supreme in the distributed tracing area. In the great Spring tradition, the project created Spring Cloud Sleuth to offer a facade over Zipkin. Over time, it evolved to be compatible with OpenTracing, one of OpenTelemetry's parents, along with OpenCensus. I cannot be sure whether OpenTelemetry was the cause, but Spring Cloud Sleuth evolved into the (badly-named) Micrometer Tracing library. Micrometer Tracing targets Zipkin first, but also supports OpenTelemetry. I find adding the requested libraries a bit complex, but it's manageable. Micrometer Tracing targets Zipkin first However, the configuration doesn't conform to the OpenTelemetry environment variables. It brings its variables: environment:
  MANAGEMENT_OTLP_TRACING_ENDPOINT: http://jaeger:4318/v1/traces #1-2
  OTEL_SERVICE_NAME: foobar                                      #3 environment:
  MANAGEMENT_OTLP_TRACING_ENDPOINT: http://jaeger:4318/v1/traces #1-2
  OTEL_SERVICE_NAME: foobar                                      #3 Non-OpenTelemetry environment variable name
MUST set the full path
Conform to the OpenTelemetry spec since Spring Boot 3.5. Before it, it used spring.application.name Non-OpenTelemetry environment variable name MUST set the full path MUST Conform to the OpenTelemetry spec since Spring Boot 3.5. Before it, it used spring.application.name Spring Boot 3.5 spring.application.name Quarkus Compare with Quarkus, which prefixes regular OpenTelemetry environment variables with QUARKUS_: Quarkus QUARKUS_ environment:
  QUARKUS_OTEL_EXPORTER_OTLP_TRACES_ENDPOINT: http://jaeger:4317
  QUARKUS_OTEL_SERVICE_NAME: foobar environment:
  QUARKUS_OTEL_EXPORTER_OTLP_TRACES_ENDPOINT: http://jaeger:4317
  QUARKUS_OTEL_SERVICE_NAME: foobar It's consistent. And yet, the Quarkus instrumentation has another gotcha: Only the tracing signal is enabled by default. To enable metrics and logs, add the following configuration to your application.properties file:
-- Quarkus instrumentation Only the tracing signal is enabled by default. To enable metrics and logs, add the following configuration to your application.properties file: tracing metrics logs -- Quarkus instrumentation Quarkus instrumentation Meanwhile, if you're an expert at operating OpenTelemetry, these defaults will surprise you. In OpenTelemetry, they are governed by other configuration parameters: environment:
  OTEL_METRICS_EXPORTER: none
  OTEL_LOGS_EXPORTER: none environment:
  OTEL_METRICS_EXPORTER: none
  OTEL_LOGS_EXPORTER: none Summary OpenTelemetry has become a de facto standard in a few years. However, the promise of ubiquitous configuration, if there was ever such a thing, doesn't hold. Operators of OpenTelemetry can't treat services as black boxes. They must consider the underlying stack and framework, and learn how to configure them accordingly. de facto On the JVM, I'd recommend sticking to the Java Agent as much as possible, but if you must cross stacks, there's no magical solution. To go further: To go further: Maven - Introduction to the Dependency Mechanism
Effective Rust - Item 25: Manage your dependency graph Maven - Introduction to the Dependency Mechanism Maven - Introduction to the Dependency Mechanism Effective Rust - Item 25: Manage your dependency graph Effective Rust - Item 25: Manage your dependency graph Originally published at A Java Geek on August 10th, 2025 Originally published at A Java Geek on August 10th, 2025 A Java Geek
