In this article, we will explore the basics of setting up an extension and how to use Flutter in it. has become a very popular choice for mobile developers; its style of UI code and the fact that it renders the same on both platforms makes it a strong choice. One of the limitations Flutter did have was with iOS app extensions. Flutter If you are not aware, are a way for you to “extend” your functionality outside of your own app and allow users to interact with it through other apps on their devices. This could be the browser, notes app, or pretty much any other app. One problem with Flutter was that you would still need to develop the functionality and the UI of your extension using native code while the majority of your app was in Flutter code. This may not be a problem for some of us, but I think we can all admit that it is annoying to still have to maintain this native code. iOS app extensions Well, Flutter 3.16 changed all this, and you can now have your extension UI built with Flutter! What we will be building Our goal in this article will be rather simple: Users will select some text from anywhere on their device and share it Our app should be displayed in the list of choices in the share sheet the OS shows When the user selects our app, they should be shown a simple screen that displays the text they selected Adding a Share Extension to your Flutter app Alright, so this part is the same whether you were using Flutter or just plain iOS, so I won’t go into too much detail but just cover the overall steps you need to take: Open the file from inside your folder. This should launch Xcode. Use from Xcode’s menu, and you should be presented with something like this: Runner.xcworkspace PROJECT/ios File -> New -> Target Either find or search for and press next. Share Extension Set the product name to what you want the extension to be called and press “Finish.” After this point, you should see a new target in Xcode. Xcode will generate some boilerplate for your extension, and at this point, you should be able to test it out by running it in a simulator (or device) and trying to share something. A few gotchas If you see an error similar to when running your app navigate to your main target’s build phases and make sure the step is immediately after the step. Error (Xcode): Cycle inside Runner Embed Foundation Extensions Copy Bundle Resources If Xcode prompts you to “Activate” your extension after you create it, opt in to activate it. Opting out can result in errors that are unclear. Using Flutter UI in the iOS app extension Now that we have our extension boilerplate setup, we need to make it use Flutter for its UI instead of the Storyboard that it currently uses. First, we need to copy the Flutter framework into our extension. If you navigate to you will find a package. Copy this into the frameworks for your extension in Xcode, and make sure that the option is set to . FLUTTER_SDK_LOCATION/bin/cache/artifacts/engine/ios/extension_safe Flutter.xcframework Embed Embed & Sign Now modify the file for your extension to look similar to: info.plist tells the OS which class to use as the root UI controller for this extension. It uses the format . Note that by default there should be an entry for the main storyboard file, you will need to remove that entry to make this work. NSExtensionPrincipalClass ExtensionName.ClassName informs the OS about when this extension should be included in the share sheet. Setting it to the string makes it always be included, but you can filter this further to only be included for specific types (for example, images only). To learn more about how to configure this, visit the . NSExtensionActivationRule TRUEPREDICATE official documentation Configuring the View Controller to use Flutter Now let’s modify our to not use the boilerplate code and use Flutter instead. Replace all of its contents with this: ShareViewController import UIKit
import Flutter
import UniformTypeIdentifiers

class ShareViewController: UIViewController {
    override func viewDidLoad() {
         super.viewDidLoad()
         showFlutter()
     }

     func showFlutter() {
         let flutterViewController = FlutterViewController(
            project: nil,
            initialRoute: "/share",
            nibName: nil,
            bundle: nil
          )
         addChild(flutterViewController)
         view.addSubview(flutterViewController.view)
         flutterViewController.view.frame = view.bounds
     }
} is now a simple that loads a as its child. The property let’s us configure what route the Flutter app should open on launch, without this it would default to whatever the home or main route you have configured for your app. ShareViewController UIViewController FlutterViewController initialRoute Now let's modify our Flutter app to account for this and modify the main function to return something similar to this: return MaterialApp(
  // ...
  routes: {
    '/': (context) => const MyHomePage(title: 'Flutter Demo Home Page'),
    "/share": (_) => const ShareWidget(),
  },
); I have omitted the boilerplate that Flutter adds during app creation, but we added a route for the /share route that we configured on the Swift side of things. This will make sure that when the extension launches the Flutter engine, the user sees our share widget instead of the app's landing screen. For now, our share widget is a simple Widget with some text in the center. import 'package:flutter/material.dart';

class ShareWidget extends StatefulWidget {
  const ShareWidget({super.key});

  @override
  State<ShareWidget> createState() => _ShareWidgetState();
}

class _ShareWidgetState extends State<ShareWidget> {
  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: Center(
        child: Text("Hello!"),
      ),
    );
  }
} Displaying the text from the share extension in Flutter Next, we want to take the text the user shared and display it in our . First, we need to read the text in our Swift class. ShareWidget Reading shared text inside the share extension view controller if let item: NSExtensionItem = self.extensionContext?.inputItems[0] as? NSExtensionItem, let itemProvider: NSItemProvider = item.attachments?[0] {
     if itemProvider.hasItemConformingToTypeIdentifier(UTType.text.identifier) {
         itemProvider.loadItem(forTypeIdentifier: UTType.text.identifier) {result,error in
             if error == nil {
                // TODO: Send data to Flutter
             }
         }
     }
 } This code gets the text data from the and, for now, does nothing. Eventually, we will add logic here to send it to the Flutter side of things. extensionContext Note: This piece of code works for this example, but it is not the safest way of writing this. Ideally, you want to iterate all items in instead of assuming it’s always just one item. self.extensionContext?.inputItems Sending data from share extension view controller to Flutter If you have worked with passing data between Flutter and Native you know that one of the go-to methods is to use a . Let’s start by setting it up on the Swift side: MethodChannel func showFlutter() {
     let flutterViewController = FlutterViewController(project: nil, initialRoute: "/share", nibName: nil, bundle: nil)

     let methodChannel = FlutterMethodChannel(name: "examples.share", binaryMessenger: flutterViewController.binaryMessenger)

     if let item: NSExtensionItem = self.extensionContext?.inputItems[0] as? NSExtensionItem, let itemProvider: NSItemProvider = item.attachments?[0] {
         if itemProvider.hasItemConformingToTypeIdentifier(UTType.text.identifier) {
             itemProvider.loadItem(forTypeIdentifier: UTType.text.identifier) {result,error in
                 if error == nil {
                     methodChannel.invokeMethod("setData", arguments: result as! String)
                 }
             }
         }
     }

     addChild(flutterViewController)
     view.addSubview(flutterViewController.view)
     flutterViewController.view.frame = view.bounds
 } We create a with the name , this name is important because its value needs to match exactly with the name configured on the channel in Flutter. We then use to call a function and send the text to it as an argument. FlutterMethodChannel examples.share invokeMethod setData Next, lets modify our in Flutter: ShareWidget import 'package:flutter/material.dart';
import 'package:flutter/services.dart';

class ShareWidget extends StatefulWidget {
  // ...
}

class _ShareWidgetState extends State<ShareWidget> {
  var methodChannel = const MethodChannel('examples.share');
  var text = "";

  @override
  void initState() {
    methodChannel.setMethodCallHandler((call) async {
      if (call.method == "setData") {
        setState(() {
          text = call.arguments as String;
        });
      }
    });
    super.initState();
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      body: Center(
        child: Text(text),
      ),
    );
  }
} We introduced a variable in the state so we can render the text being sent from Swift. We create a method channel with the name and then we add a method call handler. This handler will get invoked every time native tries to call a method on the , but in this example, we only need to worry about the function. To keep this example simple, we just take the arguments (we know there is only one in this case) and set the value of to it. text examples.share MethodChannel setData text And that’s it! You now have a share extension set on iOS that uses Flutter for its UI instead of Swift. If you like this article, be sure to check out my other work. Also, it always helps if you share this with other people. You can also follow me on or check out . Twitter my website
