Use Database Transaction Logs to Implement Observer Pattern

Design patterns help you solve common problems and keep your code maintainable, and extensible. The observer pattern is used when a change in an object should trigger changes in the observing objects. Using Transaction Logs to implement Observer Pattern is the most common way to implement this pattern in web apps. There are many ways this pattern can be implemented, such as using Web Framework’s Observers and using periodic jobs to trigger the observer code based on the type of events. Using a simple background job to scan through the database tables and based on changes the observers code is run synchronously or asynchronously.
Amrit Singh HackerNoon profile picture

Amrit Singh

Cloud Software Engineer | Product Development | I write about Tech and Travel | Profile https://bit.ly/3dNxaiK

Having an observer in the application is not good

“To understand is to perceive patterns” — Isaiah Berlin

Design patterns help you solve common problems and keep your code maintainable, and extensible.


The observer pattern is one such pattern.


A set of observers keep watching a change in an object. On any change in the object, the observers are notified of the change. This pattern is used when a change in an object should trigger changes in the observing objects.


In the case of web applications, all state is maintained in the database entries and tables. There are many scenarios when you need to post-process an entry or trigger a job on data change in a table. The observer pattern is used for this purpose.

How does the Observer Pattern work?


Observer pattern


Essentially what happens is observers subscribe to changes in the subject. When there is a change in the subject it notifies the observers. Observers subscribe to these events to take actions based on specific changes in the subject.


Once the observers receive this notification, they take the action they are supposed to take.

Ways to implement Observer Pattern in Web apps

There are many ways this pattern can be implemented. Here are the most common ways I have personally witnessed —

Utilizing Web Framework’s Observers

Many web frameworks have this pattern built-in or there are libraries that bring in its functionality. You can simply add observers in model code that get triggered on record creation, update, or deletion.


A typical observer in web frameworks looks like this. Example shows how Ruby on Rails provides the feature to implement observers.


Drawbacks — As the project grows it becomes hard to maintain the observers. You tend to create multiple services and applications. What if a service needs to trigger a job in another service, inbuilt observer patterns can complicate the code. And keeping track of observers in all projects can be a nightmare.

Periodic jobs

This is the most common approach I have seen programmers take, primarily because of time constraints. A simple background job is run to scan through the database tables and based on the changes the observer code is run either synchronously or asynchronously.


Drawbacks — This approach is an expensive one. Database scans take time and since the jobs are run periodically the changes done by these jobs are delayed. Moreover, these jobs become a single point of failure.

Using Transaction Logs to implement Observer Pattern


Observer pattern using transaction logs of DB

Transaction logs are generated by the database master. These logs help the slave to catch up with the changes. In this design, DB transaction logs are read to find changes in various tables, and observers are triggered based on the type of events. Queues can be used to solve the producer-consumer problem.

Why use this design?

There are many advantages to this design, here are a few of them —

  • It's easy to maintain observers in one place.
  • This design helps you to maintain the observers irrespective of the frameworks you use for your apps.
  • Avoids spaghetti in your applications and services.
  • Observers can be scaled independently.
  • Almost instantaneous triggering of observers.

Final Words

We had a spaghetti of code that was triggering observers in different web services. Implementing this scheme took us some time but it was worth it. We use this pipeline to denormalize objects, maintain audit logs, push data to analytics, etc.
