What happened? In Apache SeaTunnel version 2.3.9, the Kafka connector implementation contained a potential memory leak risk. When users configured streaming jobs to read data from Kafka, even with a read rate limit (read_limit.rows_per_second) set, the system could still experience continuous memory growth until an OOM (Out Of Memory) occurred. (read_limit.rows_per_second) What's the key issue? In real deployments, users observed the following phenomena: Running a Kafka-to-HDFS streaming job on an 8-core, 12G memory SeaTunnel Engine cluster
Although read_limit.rows_per_second=1 was configured, memory usage soared from 200MB to 5GB within 5 minutes
After stopping the job, memory was not released; upon resuming, memory kept growing until OOM
Ultimately, worker nodes restarted Running a Kafka-to-HDFS streaming job on an 8-core, 12G memory SeaTunnel Engine cluster Although read_limit.rows_per_second=1 was configured, memory usage soared from 200MB to 5GB within 5 minutes read_limit.rows_per_second=1 After stopping the job, memory was not released; upon resuming, memory kept growing until OOM Ultimately, worker nodes restarted Root Cause Analysis Through code review, it was found that the root cause lay in the createReader method of the KafkaSource class, where elementsQueue was initialized as an unbounded queue: createReader KafkaSource elementsQueue elementsQueue = new LinkedBlockingQueue<>(); elementsQueue = new LinkedBlockingQueue<>(); This implementation had two critical issues: Unbounded Queue: LinkedBlockingQueue without a specified capacity can theoretically grow indefinitely. When producer speed far exceeds consumer speed, memory continuously grows.
Ineffective Rate Limiting: Although users configured read_limit.rows_per_second=1, this limit did not actually apply to Kafka data reading, causing data to accumulate in the memory queue. Unbounded Queue: LinkedBlockingQueue without a specified capacity can theoretically grow indefinitely. When producer speed far exceeds consumer speed, memory continuously grows. Unbounded Queue LinkedBlockingQueue Ineffective Rate Limiting: Although users configured read_limit.rows_per_second=1, this limit did not actually apply to Kafka data reading, causing data to accumulate in the memory queue. Ineffective Rate Limiting read_limit.rows_per_second=1 Solution The community resolved this issue via PR #9041. The main improvements include: Introducing a Bounded Queue: Replacing LinkedBlockingQueue with a fixed-size ArrayBlockingQueue
Configurable Queue Size: Adding a queue.size configuration parameter, allowing users to adjust as needed
Safe Default Value: Setting DEFAULT_QUEUE_SIZE=1000 as the default queue capacity Introducing a Bounded Queue: Replacing LinkedBlockingQueue with a fixed-size ArrayBlockingQueue Introducing a Bounded Queue LinkedBlockingQueue ArrayBlockingQueue Configurable Queue Size: Adding a queue.size configuration parameter, allowing users to adjust as needed Configurable Queue Size queue.size Safe Default Value: Setting DEFAULT_QUEUE_SIZE=1000 as the default queue capacity Safe Default Value DEFAULT_QUEUE_SIZE=1000 Core implementation changes: public class KafkaSource {
    private static final String QUEUE_SIZE_KEY = "queue.size";
    private static final int DEFAULT_QUEUE_SIZE = 1000;

    public SourceReader<SeaTunnelRow, KafkaSourceSplit> createReader(
            SourceReader.Context readerContext) {
        int queueSize = kafkaSourceConfig.getInt(QUEUE_SIZE_KEY, DEFAULT_QUEUE_SIZE);
        BlockingQueue<RecordsWithSplitIds<ConsumerRecord<byte[], byte[]>>> elementsQueue =
                 new ArrayBlockingQueue<>(queueSize);
        // ...
    }
} public class KafkaSource {
    private static final String QUEUE_SIZE_KEY = "queue.size";
    private static final int DEFAULT_QUEUE_SIZE = 1000;

    public SourceReader<SeaTunnelRow, KafkaSourceSplit> createReader(
            SourceReader.Context readerContext) {
        int queueSize = kafkaSourceConfig.getInt(QUEUE_SIZE_KEY, DEFAULT_QUEUE_SIZE);
        BlockingQueue<RecordsWithSplitIds<ConsumerRecord<byte[], byte[]>>> elementsQueue =
                 new ArrayBlockingQueue<>(queueSize);
        // ...
    }
} Best Practice Recommendations For users of the SeaTunnel Kafka connector, it is recommended to: Upgrade Version: Use the SeaTunnel version containing this fix
Configure Properly: Set an appropriate queue.size value according to business needs and data characteristics
Monitor Memory: Even with a bounded queue, monitor system memory usage
Understand Rate Limiting: The read_limit.rows_per_second parameter applies to downstream processing, not Kafka consumption Upgrade Version: Use the SeaTunnel version containing this fix Upgrade Version Configure Properly: Set an appropriate queue.size value according to business needs and data characteristics Configure Properly queue.size Monitor Memory: Even with a bounded queue, monitor system memory usage Monitor Memory Understand Rate Limiting: The read_limit.rows_per_second parameter applies to downstream processing, not Kafka consumption Understand Rate Limiting read_limit.rows_per_second Summary This fix not only resolved the memory overflow risk but also improved system stability and configurability. By introducing bounded queues and configurable parameters, users can better control system resource usage and avoid OOM caused by data backlog. It also reflects the virtuous cycle of open-source communities continuously improving product quality through user feedback.

The code in this story is for educational purposes. The readers are solely responsible for whatever they build with it.
