Rust 1.77 and 1.78: The Changes That Happened to u128/i128

Rust has long had an inconsistency with C regarding the alignment of 128-bit integers on the x86-32 and x86-64 architectures. This problem has recently been resolved, but the fix comes with some effects that are worth being aware of. As a user, you most likely do not need to worry about these changes unless you are: Assuming the alignment of i128/u128 rather than using align_of Ignoring the improper_ctypes* lints and using these types in FFI Assuming the alignment of i128/u128 rather than using align_of i128 u128 align_of Ignoring the improper_ctypes* lints and using these types in FFI improper_ctypes* There are also no changes to architectures other than x86-32 and x86-64. If your code makes heavy use of 128-bit integers, you may notice runtime performance increases at a possible cost of additional memory use. This post documents what the problem was, what changed to fix it, and what to expect with the changes. If you are already familiar with the problem and only looking for a compatibility matrix, jump to the Compatibility section. Compatibility Background Data types have two intrinsic values that relate to how they can be arranged in memory; size and alignment. A type's size is the amount of space it takes up in memory, and its alignment specifies which addresses it is allowed to be placed at. The size of simple types like primitives is usually unambiguous, being the exact size of the data they represent with no padding (unused space). For example, an i64 always has a size of 64 bits or 8 bytes. i64 Alignment, however, can vary. An 8-byte integer could be stored at any memory address (1-byte aligned), but most 64-bit computers will get the best performance if it is instead stored at a multiple of 8 (8-byte aligned). So, like in other languages, primitives in Rust have this most efficient alignment by default. The effects of this can be seen when creating composite types (playground link): could playground link use core::mem::{align_of, offset_of}; #[repr(C)] struct Foo { a: u8, // 1-byte aligned b: u16, // 2-byte aligned } #[repr(C)] struct Bar { a: u8, // 1-byte aligned b: u64, // 8-byte aligned } println!("Offset of b (u16) in Foo: {}", offset_of!(Foo, b)); println!("Alignment of Foo: {}", align_of:: ()); println!("Offset of b (u64) in Bar: {}", offset_of!(Bar, b)); println!("Alignment of Bar: {}", align_of:: ()); use core::mem::{align_of, offset_of}; #[repr(C)] struct Foo { a: u8, // 1-byte aligned b: u16, // 2-byte aligned } #[repr(C)] struct Bar { a: u8, // 1-byte aligned b: u64, // 8-byte aligned } println!("Offset of b (u16) in Foo: {}", offset_of!(Foo, b)); println!("Alignment of Foo: {}", align_of:: ()); println!("Offset of b (u64) in Bar: {}", offset_of!(Bar, b)); println!("Alignment of Bar: {}", align_of:: ()); Output: Offset of b (u16) in Foo: 2 Alignment of Foo: 2 Offset of b (u64) in Bar: 8 Alignment of Bar: 8 Offset of b (u16) in Foo: 2 Alignment of Foo: 2 Offset of b (u64) in Bar: 8 Alignment of Bar: 8 We see that within a struct, a type will always be placed such that its offset is a multiple of its alignment - even if this means unused space (Rust minimizes this by default when repr(C) is not used). repr(C) These numbers are not arbitrary; the application binary interface (ABI) says what they should be. In the x86-64 psABI (processor-specific ABI) for System V (Unix & Linux), Figure 3.1: Scalar Types tells us exactly how primitives should be represented: psABI Figure 3.1: Scalar Types C type Rust equivalent sizeof Alignment (bytes) char i8 1 1 unsigned char u8 1 1 short i16 2 2 unsigned short u16 2 2 long i64 8 8 unsigned long u64 8 8 C type Rust equivalent sizeof Alignment (bytes) char i8 1 1 unsigned char u8 1 1 short i16 2 2 unsigned short u16 2 2 long i64 8 8 unsigned long u64 8 8 C type Rust equivalent sizeof Alignment (bytes) C type C type Rust equivalent Rust equivalent sizeof sizeof sizeof Alignment (bytes) Alignment (bytes) char i8 1 1 char char char i8 i8 i8 1 1 1 1 unsigned char u8 1 1 unsigned char unsigned char unsigned char u8 u8 u8 1 1 1 1 short i16 2 2 short short short i16 i16 i16 2 2 2 2 unsigned short u16 2 2 unsigned short unsigned short unsigned short u16 u16 u16 2 2 2 2 2 2 long i64 8 8 long long long i64 i64 i64 8 8 8 8 unsigned long u64 8 8 unsigned long unsigned long unsigned long u64 u64 u64 8 8 8 8 8 8 The ABI only specifies C types, but Rust follows the same definitions both for compatibility and for the performance benefits. The Incorrect Alignment Problem If two implementations disagree on the alignment of a data type, they cannot reliably share data containing that type. Rust had inconsistent alignment for 128-bit types: println!("alignment of i128: {}", align_of:: ()); // rustc 1.76.0 alignment of i128: 8 printf("alignment of __int128: %zu\n", _Alignof(__int128)); // gcc 13.2 alignment of __int128: 16 // clang 17.0.1 alignment of __int128: 16 println!("alignment of i128: {}", align_of:: ()); // rustc 1.76.0 alignment of i128: 8 printf("alignment of __int128: %zu\n", _Alignof(__int128)); // gcc 13.2 alignment of __int128: 16 // clang 17.0.1 alignment of __int128: 16 (Godbolt link) Looking back at the psABI, we can see that Rust has the wrong alignment here: Godbolt link psABI C type Rust equivalent sizeof Alignment (bytes) __int128 i128 16 16 unsigned __int128 u128 16 16 C type Rust equivalent sizeof Alignment (bytes) __int128 i128 16 16 unsigned __int128 u128 16 16 C type Rust equivalent sizeof Alignment (bytes) C type C type Rust equivalent Rust equivalent sizeof sizeof sizeof Alignment (bytes) Alignment (bytes) __int128 i128 16 16 __int128 __int128 __int128 i128 i128 i128 16 16 16 16 unsigned __int128 u128 16 16 unsigned __int128 unsigned __int128 unsigned __int128 u128 u128 u128 16 16 16 16 It turns out this isn't because of something that Rust is actively doing incorrectly: layout of primitives comes from the LLVM codegen backend used by both Rust and Clang, among other languages, and it has the alignment fori128 hardcoded to 8 bytes. i128 Clang uses the correct alignment only because of a workaround, where the alignment is manually set to 16 bytes before handing the type to LLVM. This fixes the layout issue but has been the source of some other minor problems.12 Rust does no such manual adjustment, hence the issue reported at https://github.com/rust-lang/rust/issues/54341. 1 2 https://github.com/rust-lang/rust/issues/54341 The Calling Convention Problem There is an additional problem: LLVM does not always do the correct thing when passing 128-bit integers as function arguments. This was a known issue in LLVM, before its relevance to Rust was discovered. known issue in LLVM relevance to Rust was discovered When calling a function, the arguments get passed in registers (special storage locations within the CPU) until there are no more slots, then they get "spilled" to the stack (the program's memory). The ABI tells us what to do here as well, in the section 3.2.3 Parameter Passing: 3.2.3 Parameter Passing Arguments of type __int128 offer the same operations as INTEGERs, yet they do not fit into one general purpose register but require two registers. For classification purposes __int128 is treated as if it were implemented as: typedef struct { long low, high; } __int128; with the exception that arguments of type __int128 that are stored in memory must be aligned on a 16-byte boundary. Arguments of type __int128 offer the same operations as INTEGERs, yet they do not fit into one general purpose register but require two registers. For classification purposes __int128 is treated as if it were implemented as: __int128 __int128 typedef struct { long low, high; } __int128; typedef struct { long low, high; } __int128; with the exception that arguments of type __int128 that are stored in memory must be aligned on a 16-byte boundary. __int128 We can try this out by implementing the calling convention manually. In the below C example, inline assembly is used to call foo(0xaf, val, val, val) with val as 0x11223344556677889900aabbccddeeff. foo(0xaf, val, val, val) val 0x11223344556677889900aabbccddeeff x86-64 uses the registers rdi, rsi, rdx, rcx, r8, and r9 to pass function arguments, in that order (you guessed it, this is also in the ABI). Each register fits a word (64 bits), and anything that doesn't fit gets pushed to the stack. rdi rsi rdx rcx r8 r9 push /* full example at */ /* to see the issue, we need a padding value to "mess up" argument alignment */ void foo(char pad, __int128 a, __int128 b, __int128 c) { printf("%#x\n", pad & 0xff); print_i128(a); print_i128(b); print_i128(c); } int main() { asm( /* load arguments that fit in registers */ "movl $0xaf, %edi \n\t" /* 1st slot (edi): padding char (`edi` is the * same as `rdi`, just a smaller access size) */ "movq $0x9900aabbccddeeff, %rsi \n\t" /* 2nd slot (rsi): lower half of `a` */ "movq $0x1122334455667788, %rdx \n\t" /* 3rd slot (rdx): upper half of `a` */ "movq $0x9900aabbccddeeff, %rcx \n\t" /* 4th slot (rcx): lower half of `b` */ "movq $0x1122334455667788, %r8 \n\t" /* 5th slot (r8): upper half of `b` */ "movq $0xdeadbeef4c0ffee0, %r9 \n\t" /* 6th slot (r9): should be unused, but * let's trick clang! */ /* reuse our stored registers to load the stack */ "pushq %rdx \n\t" /* upper half of `c` gets passed on the stack */ "pushq %rsi \n\t" /* lower half of `c` gets passed on the stack */ "call foo \n\t" /* call the function */ "addq $16, %rsp \n\t" /* reset the stack */ ); } /* full example at */ /* to see the issue, we need a padding value to "mess up" argument alignment */ void foo(char pad, __int128 a, __int128 b, __int128 c) { printf("%#x\n", pad & 0xff); print_i128(a); print_i128(b); print_i128(c); } int main() { asm( /* load arguments that fit in registers */ "movl $0xaf, %edi \n\t" /* 1st slot (edi): padding char (`edi` is the * same as `rdi`, just a smaller access size) */ "movq $0x9900aabbccddeeff, %rsi \n\t" /* 2nd slot (rsi): lower half of `a` */ "movq $0x1122334455667788, %rdx \n\t" /* 3rd slot (rdx): upper half of `a` */ "movq $0x9900aabbccddeeff, %rcx \n\t" /* 4th slot (rcx): lower half of `b` */ "movq $0x1122334455667788, %r8 \n\t" /* 5th slot (r8): upper half of `b` */ "movq $0xdeadbeef4c0ffee0, %r9 \n\t" /* 6th slot (r9): should be unused, but * let's trick clang! */ /* reuse our stored registers to load the stack */ "pushq %rdx \n\t" /* upper half of `c` gets passed on the stack */ "pushq %rsi \n\t" /* lower half of `c` gets passed on the stack */ "call foo \n\t" /* call the function */ "addq $16, %rsp \n\t" /* reset the stack */ ); } Running the above with GCC prints the following expected output: 0xaf 0x11223344556677889900aabbccddeeff 0x11223344556677889900aabbccddeeff 0x11223344556677889900aabbccddeeff 0xaf 0x11223344556677889900aabbccddeeff 0x11223344556677889900aabbccddeeff 0x11223344556677889900aabbccddeeff But running with Clang 17 prints: 0xaf 0x11223344556677889900aabbccddeeff 0x11223344556677889900aabbccddeeff 0x9900aabbccddeeffdeadbeef4c0ffee0 //^^^^^^^^^^^^^^^^ this should be the lower half // ^^^^^^^^^^^^^^^^ look familiar? 0xaf 0x11223344556677889900aabbccddeeff 0x11223344556677889900aabbccddeeff 0x9900aabbccddeeffdeadbeef4c0ffee0 //^^^^^^^^^^^^^^^^ this should be the lower half // ^^^^^^^^^^^^^^^^ look familiar? Surprise! This illustrates the second problem: LLVM expects an i128 to be passed half in a register and half on the stack when possible, but this is not allowed by the ABI. i128 Since the behavior comes from LLVM and has no reasonable workaround, this is a problem in both Clang and Rust. Solutions Getting these problems resolved was a lengthy effort by many people, starting with a patch by compiler team member Simonas Kazlauskas in 2017: D28990. Unfortunately, this wound up reverted. It was later attempted again in D86310 by LLVM contributor Harald van Dijk, which is the version that finally landed in October 2023. D28990 D86310 Around the same time, Nikita Popov fixed the calling convention issue with D158169. Both of these changes made it into LLVM 18, meaning all relevant ABI issues will be resolved in both Clang and Rust that use this version (Clang 18 and Rust 1.78 when using the bundled LLVM). D158169 However, rustc can also use the version of LLVM installed on the system rather than a bundled version, which may be older. To mitigate the chance of problems from differing alignment with the same rustc version, a proposal was introduced to manually correct the alignment like Clang has been doing. This was implemented by Matthew Maurer in #116672. rustc rustc a proposal #116672 Since these changes, Rust now produces the correct alignment: println!("alignment of i128: {}", align_of:: ()); // rustc 1.77.0 alignment of i128: 16 println!("alignment of i128: {}", align_of:: ()); // rustc 1.77.0 alignment of i128: 16 As mentioned above, part of the reason for an ABI to specify the alignment of a datatype is because it is more efficient on that architecture. We actually got to see that firsthand: the initial performance run with the manual alignment change showed nontrivial improvements to compiler performance (which relies heavily on 128-bit integers to work with integer literals). The downside of increasing alignment is that composite types do not always fit together as nicely in memory, leading to an increase in usage. Unfortunately this meant some of the performance wins needed to be sacrificed to avoid an increased memory footprint. initial performance run Compatibility The most important question is how compatibility changed as a result of these fixes. In short, i128 and u128 with Rust using LLVM 18 (the default version starting with 1.78) will be completely compatible with any version of GCC, as well as Clang 18 and above (released March 2024). All other combinations have some incompatible cases, which are summarized in the table below: i128 u128 Compiler 1 Compiler 2 status Rust ≥ 1.78 with bundled LLVM (18) GCC (any version) Fully compatible Rust ≥ 1.78 with bundled LLVM (18) Clang ≥ 18 Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 GCC (any version) Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 Clang ≥ 18 Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 Clang < 18 Storage compatible, has calling bug Rust ≥ 1.77 with LLVM < 18 GCC (any version) Storage compatible, has calling bug Rust ≥ 1.77 with LLVM < 18 Clang (any version) Storage compatible, has calling bug Rust < 1.77__3__ GCC (any version) Incompatible Rust < 1.77__3__ Clang (any version) Incompatible GCC (any version) Clang ≥ 18 Fully compatible GCC (any version) Clang < 18 Storage compatible with calling bug Compiler 1 Compiler 2 status Rust ≥ 1.78 with bundled LLVM (18) GCC (any version) Fully compatible Rust ≥ 1.78 with bundled LLVM (18) Clang ≥ 18 Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 GCC (any version) Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 Clang ≥ 18 Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 Clang < 18 Storage compatible, has calling bug Rust ≥ 1.77 with LLVM < 18 GCC (any version) Storage compatible, has calling bug Rust ≥ 1.77 with LLVM < 18 Clang (any version) Storage compatible, has calling bug Rust < 1.77__3__ GCC (any version) Incompatible Rust < 1.77__3__ Clang (any version) Incompatible GCC (any version) Clang ≥ 18 Fully compatible GCC (any version) Clang < 18 Storage compatible with calling bug Compiler 1 Compiler 2 status Compiler 1 Compiler 1 Compiler 2 Compiler 2 status status Rust ≥ 1.78 with bundled LLVM (18) GCC (any version) Fully compatible Rust ≥ 1.78 with bundled LLVM (18) Rust ≥ 1.78 with bundled LLVM (18) GCC (any version) GCC (any version) Fully compatible Fully compatible Rust ≥ 1.78 with bundled LLVM (18) Clang ≥ 18 Fully compatible Rust ≥ 1.78 with bundled LLVM (18) Rust ≥ 1.78 with bundled LLVM (18) Clang ≥ 18 Clang ≥ 18 Fully compatible Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 GCC (any version) Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 Rust ≥ 1.77 with LLVM ≥ 18 GCC (any version) GCC (any version) Fully compatible Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 Clang ≥ 18 Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 Rust ≥ 1.77 with LLVM ≥ 18 Clang ≥ 18 Clang ≥ 18 Fully compatible Fully compatible Rust ≥ 1.77 with LLVM ≥ 18 Clang < 18 Storage compatible, has calling bug Rust ≥ 1.77 with LLVM ≥ 18 Rust ≥ 1.77 with LLVM ≥ 18 Clang < 18 Clang < 18 Storage compatible, has calling bug Storage compatible, has calling bug Rust ≥ 1.77 with LLVM < 18 GCC (any version) Storage compatible, has calling bug Rust ≥ 1.77 with LLVM < 18 Rust ≥ 1.77 with LLVM < 18 GCC (any version) GCC (any version) Storage compatible, has calling bug Storage compatible, has calling bug Rust ≥ 1.77 with LLVM < 18 Clang (any version) Storage compatible, has calling bug Rust ≥ 1.77 with LLVM < 18 Rust ≥ 1.77 with LLVM < 18 Clang (any version) Clang (any version) Storage compatible, has calling bug Storage compatible, has calling bug Rust < 1.77__3__ GCC (any version) Incompatible Rust < 1.77__3__ Rust < 1.77__3__ 3 GCC (any version) GCC (any version) Incompatible Incompatible Rust < 1.77__3__ Clang (any version) Incompatible Rust < 1.77__3__ Rust < 1.77__3__ 3 Clang (any version) Clang (any version) Incompatible Incompatible GCC (any version) Clang ≥ 18 Fully compatible GCC (any version) GCC (any version) Clang ≥ 18 Clang ≥ 18 Fully compatible Fully compatible GCC (any version) Clang < 18 Storage compatible with calling bug GCC (any version) GCC (any version) Clang < 18 Clang < 18 Storage compatible with calling bug Storage compatible with calling bug Effects & Future Steps As mentioned in the introduction, most users will notice no effects of this change unless you are already doing something questionable with these types. Starting with Rust 1.77, it will be reasonably safe to start experimenting with 128-bit integers in FFI, with some more certainty coming with the LLVM update in 1.78. There is ongoing discussion about lifting the lint in an upcoming version, but we want to be cautious and avoid introducing silent breakage for users whose Rust compiler may be built with an older LLVM. ongoing discussion https://bugs.llvm.org/show_bug.cgi?id=50198 ↩ https://github.com/llvm/llvm-project/issues/20283 ↩ Rust < 1.77 with LLVM 18 will have some degree of compatibility, this is just an uncommon combination. ↩ ↩2 https://bugs.llvm.org/show_bug.cgi?id=50198 ↩ https://bugs.llvm.org/show_bug.cgi?id=50198 ↩ https://github.com/llvm/llvm-project/issues/20283 ↩ https://github.com/llvm/llvm-project/issues/20283 ↩ Rust < 1.77 with LLVM 18 will have some degree of compatibility, this is just an uncommon combination. ↩ ↩2 ↩ ↩ ↩2 ↩2 Trevor Gross on behalf of The Rust Lang Team The Rust Lang Team The Rust Lang Team Also published here here Photo by Suzanne D. Williams on Unsplash Suzanne D. Williams Unsplash
