We  recently launched Rio, our new framework designed to help you create  web and local applications using just pure Python. The response from our  community has been overwhelmingly positive and incredibly motivating  for us. With the praise has come a wave of curiosity. The most common  question we’ve encountered is, “How does Rio actually work?”  If you’ve been wondering the same thing, you’re in the right place!  Here we’ll explore the inner workings of Rio and uncover what makes it  so powerful. A Fresh Layouting System When  it comes to building modern apps, components are just the beginning,  it’s the layouting that pulls them together into a cohesive,  user-friendly interface. In our last topic, we took a closer look at  components, the essential pieces of any app. Now, let’s shift our focus  to the layout system that arranges them harmoniously. Designing a layout  system isn’t a one-size-fits-all task; different frameworks bring  unique strengths, with CSS often at the center of debate. As we designed  Rio’s layout system, we aimed for something Pythonic, simple, flexible,  and efficient — a system that keeps developers focused on their app’s  function, not the complexities of positioning. Here, we’ll break down  the core principles behind Rio’s two-step approach to layouting, where  each component starts by defining its own natural size before the  available space is thoughtfully distributed. Take a look at our playground (Layouting Quickstart), where you can try out our layout concept firsthand with just a click and receive real-time feedback. What Makes a Great Layout System? Each UI framework approaches layouting differently, all with their own unique strengths and quirks. There’s of course the polarizing incumbent,  CSS, but also the many systems built into popular frameworks like  Flutter, QT, and others. Before we got to designing our own, we took a  step back to understand what makes a great layout system. Here are some  key principles we identified: Pythonic: Rio embraces Python’s simplicity. No numbers encoded as strings or complex unit declarations. For example, width=10 is preferred over width="10px". This isn’t just cleaner, but also aids type checking tools and allows for easy mathematical operations.
Simple: The system should be intuitive, even for developers without a deep background in UI design. Rather than a tangled set of rules and exceptions, it should be governed by a handful of principles that are applied consistently.
Flexible: From basic layouts to complex, nested structures, the system needs to handle them all. Templates and restrictive built-in patterns won’t cut it.
Efficient: Especially when targeting the web, performance is key. A good layouting system should be automatically convertible to CSS, maybe with some JavaScript sprinkled in occasionally for dynamic calculations. Rio’s Approach: Two-Step Layouting We’ve decided on a two-step layouting system that balances simplicity and flexibility. Here’s how it works: Step 1: Natural Size Calculation First, each component determines how much space it needs to fit its content. We call this the component’s “natural size.” For some components this is simple. For example, rio.Switch has a fixed size, so that is also its natural size. But not all components are that simple. Take a rio.Row  for example. The row itself doesn't need any space, but it needs to  request enough space to fit its children. So the natural width of a row  is the sum of the natural widths of its children, plus any spacing  between them. Another more in-depth example is rio.Text. It's size depends on a variety of things, such as its text content, font size, whether the font is bold, etc. This  process starts at the leaves of the component tree, i.e. first  components without any children are calculated, then their parents, and  so on, until the entire tree has computed its natural width &  height. Step 2: Space Distribution Once  each component has determined its natural size, we must decide how to  allocate the available space. For example, in a large window with only a  button, should the button be centered, aligned to one side, or  stretched? There isn’t a real reason to prefer one over the other. We are solving this, by simply giving all  space to the button. If you don’t want for that to happen, you can  explicitly set the button’s alignment, and Rio will take it into  account. Example Imagine a simple rio.Row containing a rio.Text and a rio.Switch.  First, we need to calculate the natural size of all components. We'll  start with components that don't have any children, so in this case the rio.Text and rio.Switch. The rio.Text will calculate its natural size based on its text content, font size, etc. The rio.Switch has a fixed size, so that is also its natural size. Now that all children have had their natural size calculated, the rio.Row  can get to work. It's natural width is the sum of the natural widths of  its children (plus any spacing) and its natural height is the maximum  of the natural heights of its children. Finally,  we need to distribute the available space. Since the window itself  always has a single child, it will pass all available space to that  child — in this case the rio.Row. The row will then distribute the space to its children; But how? Since there’s only so few components in the view there is likely too much space available. Thus, the rio.Row  will have to decide how much space to pass to each child. Since we  always want all components to have enough space to fit their content  ("natural size") we'll allocate each child that much space. Then, if  space is leftover we can distribute that proportionally. Ta-da! All  components now know how large they are. Their positions also follow from  this. Since this is such a common use-case, rio.Row also honors the grow_x and grow_y attributes of components. If a component is marked to grow,  and superfluous space is available, all space will be given to that  component. If there are multiple components that are marked to grow, the  space will be distributed proportionally just between those components. Implementation The  system described above is what we call our reference layouting system.  It isn’t actually implemented like this in code, but rather as a set of  CSS rules, that result in this exact behavior. This allows our layouting  to run at maximum performance, because it relies on the browser’s  native layouting engine. The described algorithm is nonetheless useful,  as it guides Rio developers to how a component should behave. It’s just  that this behavior is then achieved by internal CSS rules rather than  the algorithm itself. Best  of all, you’ll never have to see a single line of CSS. All of this is  handled by Rio internally, so you can focus on building your app. Limitations and Trade-offs While  Rio’s layout system is powerful and flexible, it isn’t perfect. In the  interest of full transparency, we’d like to share some limitations that  we’ve found: Some layouts cannot achieved just using CSS. Notably, when using the proportions attribute of rio.Row or rio.Column, JavaScript jumps into action to help out, because we are not aware of any pure-CSS way to achieve our desired behavior. (If you're a CSS magician and know a way, reach out!)
There are occasional layouts that cannot be realized with this system. One such situation that we’ve found is to have a row containing an icon and text, while that text is both centered and has wrapping enabled.
This sounds like a simple case, but no combination of parameters yields the desired result. Aligning the text to 0.5 (center) won't center the icon. Same when using the justify attribute. Aligning the entire rio.Row will make the row take up as little space as possible, thus squishing the text.
We’ve had some discussions about introducing a “preferred size” that would solve this, but it’s not in Rio yet. Github: https://github.com/rio-labs/rio Website: https://rio.dev/ We  recently launched Rio, our new framework designed to help you create  web and local applications using just pure Python. The response from our  community has been overwhelmingly positive and incredibly motivating  for us. With the praise has come a wave of curiosity. The most common  question we’ve encountered is, “How does Rio actually work?” If you’ve been wondering the same thing, you’re in the right place!  Here we’ll explore the inner workings of Rio and uncover what makes it  so powerful. “How does Rio actually work?” A Fresh Layouting System When  it comes to building modern apps, components are just the beginning,  it’s the layouting that pulls them together into a cohesive,  user-friendly interface. In our last topic, we took a closer look at  components, the essential pieces of any app. Now, let’s shift our focus  to the layout system that arranges them harmoniously. Designing a layout  system isn’t a one-size-fits-all task; different frameworks bring  unique strengths, with CSS often at the center of debate. As we designed  Rio’s layout system, we aimed for something Pythonic, simple, flexible,  and efficient — a system that keeps developers focused on their app’s  function, not the complexities of positioning. Here, we’ll break down  the core principles behind Rio’s two-step approach to layouting, where  each component starts by defining its own natural size before the  available space is thoughtfully distributed. Take a look at our playground ( Layouting Quickstart ), where you can try out our layout concept firsthand with just a click and receive real-time feedback. Layouting Quickstart What Makes a Great Layout System? Each UI framework approaches layouting differently, all with their own unique strengths and quirks. There’s of course the polarizing incumbent ,  CSS, but also the many systems built into popular frameworks like  Flutter, QT, and others. Before we got to designing our own, we took a  step back to understand what makes a great layout system. Here are some  key principles we identified: polarizing incumbent Pythonic: Rio embraces Python’s simplicity. No numbers encoded as strings or complex unit declarations. For example, width=10 is preferred over width="10px". This isn’t just cleaner, but also aids type checking tools and allows for easy mathematical operations. Simple: The system should be intuitive, even for developers without a deep background in UI design. Rather than a tangled set of rules and exceptions, it should be governed by a handful of principles that are applied consistently. Flexible: From basic layouts to complex, nested structures, the system needs to handle them all. Templates and restrictive built-in patterns won’t cut it. Efficient: Especially when targeting the web, performance is key. A good layouting system should be automatically convertible to CSS, maybe with some JavaScript sprinkled in occasionally for dynamic calculations. Pythonic: Rio embraces Python’s simplicity. No numbers encoded as strings or complex unit declarations. For example, width=10 is preferred over width="10px" . This isn’t just cleaner, but also aids type checking tools and allows for easy mathematical operations. Pythonic: width=10 width="10px" Simple: The system should be intuitive, even for developers without a deep background in UI design. Rather than a tangled set of rules and exceptions, it should be governed by a handful of principles that are applied consistently. Simple: Flexible: From basic layouts to complex, nested structures, the system needs to handle them all. Templates and restrictive built-in patterns won’t cut it. Flexible: Efficient: Especially when targeting the web, performance is key. A good layouting system should be automatically convertible to CSS, maybe with some JavaScript sprinkled in occasionally for dynamic calculations. Efficient: Rio’s Approach: Two-Step Layouting We’ve decided on a two-step layouting system that balances simplicity and flexibility. Here’s how it works: Step 1: Natural Size Calculation First, each component determines how much space it needs to fit its content. We call this the component’s “natural size.” For some components this is simple. For example, rio.Switch has a fixed size, so that is also its natural size. But not all components are that simple. Take a rio.Row for example. The row itself doesn't need any space, but it needs to  request enough space to fit its children. So the natural width of a row  is the sum of the natural widths of its children, plus any spacing  between them. rio.Switch rio.Row Another more in-depth example is rio.Text . It's size depends on a variety of things, such as its text content, font size, whether the font is bold, etc. rio.Text This  process starts at the leaves of the component tree, i.e. first  components without any children are calculated, then their parents, and  so on, until the entire tree has computed its natural width &  height. Step 2: Space Distribution Once  each component has determined its natural size, we must decide how to  allocate the available space. For example, in a large window with only a  button, should the button be centered, aligned to one side, or  stretched? There isn’t a real reason to prefer one over the other. We are solving this, by simply giving all space to the button. If you don’t want for that to happen, you can  explicitly set the button’s alignment, and Rio will take it into  account. all Example Imagine a simple rio.Row containing a rio.Text and a rio.Switch .  First, we need to calculate the natural size of all components. We'll  start with components that don't have any children, so in this case the rio.Text and rio.Switch . rio.Row rio.Text rio.Switch rio.Text rio.Switch The rio.Text will calculate its natural size based on its text content, font size, etc. The rio.Switch has a fixed size, so that is also its natural size. rio.Text rio.Switch Now that all children have had their natural size calculated, the rio.Row can get to work. It's natural width is the sum of the natural widths of  its children (plus any spacing) and its natural height is the maximum  of the natural heights of its children. rio.Row Finally,  we need to distribute the available space. Since the window itself  always has a single child, it will pass all available space to that  child — in this case the rio.Row . The row will then distribute the space to its children; But how? rio.Row Since there’s only so few components in the view there is likely too much space available. Thus, the rio.Row will have to decide how much space to pass to each child. Since we  always want all components to have enough space to fit their content  ("natural size") we'll allocate each child that much space. Then, if  space is leftover we can distribute that proportionally. Ta-da! All  components now know how large they are. Their positions also follow from  this. rio.Row Since this is such a common use-case, rio.Row also honors the grow_x and grow_y attributes of components. If a component is marked to grow ,  and superfluous space is available, all space will be given to that  component. If there are multiple components that are marked to grow, the  space will be distributed proportionally just between those components. rio.Row grow_x grow_y grow Implementation The  system described above is what we call our reference layouting system.  It isn’t actually implemented like this in code, but rather as a set of  CSS rules, that result in this exact behavior. This allows our layouting  to run at maximum performance, because it relies on the browser’s  native layouting engine. The described algorithm is nonetheless useful,  as it guides Rio developers to how a component should behave. It’s just  that this behavior is then achieved by internal CSS rules rather than  the algorithm itself. Best  of all, you’ll never have to see a single line of CSS. All of this is  handled by Rio internally, so you can focus on building your app. Limitations and Trade-offs While  Rio’s layout system is powerful and flexible, it isn’t perfect. In the  interest of full transparency, we’d like to share some limitations that  we’ve found: Some layouts cannot achieved just using CSS. Notably, when using the proportions attribute of rio.Row or rio.Column, JavaScript jumps into action to help out, because we are not aware of any pure-CSS way to achieve our desired behavior. (If you're a CSS magician and know a way, reach out!) There are occasional layouts that cannot be realized with this system. One such situation that we’ve found is to have a row containing an icon and text, while that text is both centered and has wrapping enabled. This sounds like a simple case, but no combination of parameters yields the desired result. Aligning the text to 0.5 (center) won't center the icon. Same when using the justify attribute. Aligning the entire rio.Row will make the row take up as little space as possible, thus squishing the text. We’ve had some discussions about introducing a “preferred size” that would solve this, but it’s not in Rio yet. Some layouts cannot achieved just using CSS. Notably, when using the proportions attribute of rio.Row or rio.Column , JavaScript jumps into action to help out, because we are not aware of any pure-CSS way to achieve our desired behavior. (If you're a CSS magician and know a way, reach out!) proportions rio.Row rio.Column There are occasional layouts that cannot be realized with this system. One such situation that we’ve found is to have a row containing an icon and text, while that text is both centered and has wrapping enabled. This sounds like a simple case, but no combination of parameters yields the desired result. Aligning the text to 0.5 (center) won't center the icon. Same when using the justify attribute. Aligning the entire rio.Row will make the row take up as little space as possible, thus squishing the text. 0.5 justify rio.Row We’ve had some discussions about introducing a “preferred size” that would solve this, but it’s not in Rio yet. Github: https://github.com/rio-labs/rio Github: https://github.com/rio-labs/rio https://github.com/rio-labs/rio Website: https://rio.dev/ Website: https://rio.dev/ https://rio.dev/
