Rendering Markdown Pages with Express and Los Angeles

Node and Express are great for building dynamic websites but often you'll also have some static content too. While its reasonably easy to author these pages in straight HTML a better option for this kind of content is often Markdown.

Los Angeles is a simple, easy to use but flexible Markdown page server for Express.

This post shows how to integrate Los Angeles into an Express app and be up and running with Markdown pages in just a few minutes.

Background

First a little background... I've been using Los Angeles to serve static Markdown content pages in a number of websites for several years now.  Recently I cleaned it up, documented it and published it to NPM as an open source project.

(If you're wondering about the name, it came out of a habit of naming Node projects after synth-wave songs. This project is named after one of my favourites: Los Angeles by The Midnight).

Setup

You might already have an existing Express app that you want to add Markdown support to, but for this walk-through example I'm going to generate an app from scratch.

Let's start by installing the Express generator, generating a new app called "TestLA" and installing the dependent packages:

> npm install -g express-generator
> express --hbs --css less --git TestLA
> cd TestLA
> npm install

Next, install the Los Angeles package:

npm install --save @toptensoftware/losangeles

We now need to integrate the Los Angeles middle-ware into the Express app.  Open the file "app.js" and make the following changes.  First, at the top of the file, import the Los Angeles component:

const la = require('@toptensoftware/losangeles');

Next, look for the line

app.use(express.static(...))

app.use(la.serve({
  contentPath: path.join(__dirname, 'public')
}).middleware);

Finally, we'll need an Express view to render the Markdown page.  In the "views" sub-folder, create a file "page.hbs" like so:

<h1>{{title}}</h1>
{{{body}}}

That's it!  You're now ready to start writing Markdown content pages.

Creating the First Page

Lets create a sub-directory on the site called "guides" that contains the user-guide for this imaginary example web site.  In the "public" folder, create a sub-folder called "guides" and in that folder, create a new file called "index.md":

---
title: User Guide
---
Welcome to the user guides.

* Apples
* Pears
* Bananas

Now with the app running, visit the page

http://localhost:3000/guides

(If you're new to Node/Express, you can start the server by running

npm start

A couple of things to note about the above:

• The file "index.md" is automatically used if the requested URL is a directory.
• The title setting in the ".md" file is reflected in the title tab of the page.
• The Markdown has been rendered correctly.

Other Pages

Obviously you're going to want additional pages besides index pages.

Create a second page in the guides folder called say "gettingStarted.md", add some Markdown content and check it works by visiting

http://localhost:3000/guides/gettingStarted

YAML Front Matter

If you were paying attention to the above you would have noticed that the "index.md" file we created above isn't strictly just Markdown.

The section at the top delimited by the three dash delimiters is called the page's "front-matter" and specifies additional metadata about the page in YAML format.

The front-matter is used for two purposes:

• Special settings that control Los Angeles behaviour.  (See documentation here)
• Anything else you like.  Settings provided here are available to the view that renders the page. (ie: the "page.hbs" file we created earlier).

The

title

{{title}}

Adding Syntax Highlighting

As another example of how to use the custom front-matter settings, let's add support for syntax highlighting using PrismJS - a popular client side syntax highlight library.

To support this we'll let each page declare which syntax languages it needs and we'll update the layout to include the required resources for those languages.

First open the "layout.hbs" file and in the

<head>

{{#if languages}}
    <link rel="stylesheet" type="text/css" href="https://cdnjs.cloudflare.com/ajax/libs/prism/1.16.0/themes/prism-okaidia.min.css" />
    <script src="https://cdnjs.cloudflare.com/ajax/libs/prism/1.16.0/prism.min.js"></script>
{{#each languages}}
    <script src="https://cdnjs.cloudflare.com/ajax/libs/prism/1.16.0/components/prism-{{.}}.min.js"></script>
{{/each}}
{{/if}}

To explain the above:

• The outer

  {{#if}}

   causes the the Prism stuff to only be included if the page declares that is needs any syntax highlighting.
• Inside the

  {{#if}}

   we include the Prism theme file ("prism-okaidia.min.js") and the core Prism JavaScript module ("prism.min.js").
• An inner

  {{#each}}

   includes the Prism JavaScript files for each of the languages that page requires.

Next, update the "index.md" file as follows.  Notice a) the

languages

---
title: User Guide
languages:
  - markup
  - javascript
---
Welcome to the user guides.

* Apples
* Pears
* Bananas

~~~markup
<p>Paragraph</p>
~~~

~~~javascript
for (let i=0; i<10; i++)
    console.log(i);
~~~

Load the page in your browser again and you should see something similar to the following:

Note: the above is intended primarily as another example of how front-matter settings might be used. In practice you might not bother with this approach for syntax highlighting as it's probably easier to just always include the required Prism files in the layout... but that wasn't the point of this example.

Sharing Settings Across Multiple Pages

Often you'll have settings that you want applied to every page in a folder.  Los Angeles provides an easy way to do this with a special file called ".common.page".  Any settings specified in this file will be included in every other page loaded from that folder.

Continuing the above example, suppose we wanted every page in the "guides" folder to have syntax highlighting for those languages.  Instead of specifying those settings in every page we can move them to .common.page.

Try this:

1. Delete the

   languages

   section from the front-matter in "index.md".
2. Create a new file ".common.page" and declare the languages there.
3. Add some fenced code blocks to the "gettingStarted.md" file and confirm they work as expected.

The ".common.page" file should have the front matter delimiters just like any other page.  You might also like to include other common settings... a project name for example:

---
projectName: My Project Guide
languages:
  - markup
  - javascript
---

Note: when loading pages, Los Angeles looks for Markdown files with either a ".md" extension (as shown so in this post) or a ".page" extension.  The common settings file however must have a ".page" extension.

Tip: common settings are also handy for navigation links.  For example, check out the .common.page file for the Los Angeles help topics. (Yes, of course Los Angeles uses itself for its own documentation :).

Using Different Views for Different Pages

At the start of this walk-through, we created a special view called "page.hbs" that's used to render the final page.  If you have pages with very different styling or layout you can use a different view for each page.

Just add a

view

---
title: My Page
view: homePageView
---

You can also set the layout to be used by setting

layout

Choosing a View Engine

For this walk-through I've used Handlebars as the view engine but it should work with any capable Express view engine.

If you're after a bit more flexibility in your views you might like to check out Moe-js - a Javascript enabled, async enabled, Handlebars like view engine that I wrote specifically to work well with Los Angeles.

Wrap Up

The above is a quick introduction to getting started with Los Angeles.  Check out the documentation for details on other features, like caching, image size calculations, URL redirect and rewrite rules, referenced page loading and more...

If you enjoy using Los Angeles or have any suggestions, be sure to let me know.

This post was original published on the Topten Software blog.

Los Angeles is a product developed by I, Brad Robinson, under the Apache 2.0 license. Hope you guys like it. Feedback Welcome.
