Querying Complex JSON Objects With SQL

HarperDB’s ARRAY() function is an aggregate function, similar to COUNT, SUM, AVG and COUNT. The difference is that while standard aggregate functions will return computation results. HarperDB can perform these transformations out-of-the-box with a single query. This query effectively performs the job of an ORM without the need for bloated software. Use Cases for the use of the function include a simple example of people with addresses and phone numbers. You can also view the data below to see the data from a single table.
Jacob Cohen Hacker Noon profile picture

@jacobbcohenJacob Cohen

STEM Advocate | Car Guy | SQL Stan | Director of Engineering at HarperDB | Robotics Judge Advisor and Referee

How many times have you run into a situation where you wish you could do a SQL join without getting duplicate rows back? What if we could get a list "column" returned instead? HarperDB’s ARRAY() function enables just that. In this post we’re going to take a look at a basic example of people with addresses and phone numbers.

Use Cases for the ARRAY() Function

Most existing systems have trouble transforming relational data into hierarchical data. Typically large batch processes or ETL jobs exist to perform these data transformations. HarperDB can perform these transformations out-of-the-box with a single SQL query. This query effectively performs the job of an ORM without the need for bloated software. Don’t think this is possible? Keep reading.

How the ARRAY() Function Works

The HarperDB ARRAY() function, forthcoming in a future release, is an aggregate function, similar to COUNT, SUM, AVG. The difference is that while standard aggregate functions will return computation results, ARRAY() returns a list of data as a field. While this may not be intuitive to those, like myself, who have been using SQL for years, it does enable the developer to create complex JSON objects with a single query. Let’s take a look at an example use case…

Example Data

We’ll be working with People, Phone Numbers, and Addresses. Each Address and/or Phone Number links back to a single Person. We have 10 person records, each with one or more phone numbers and addresses for a total of 20 addresses and 24 phone numbers.


Array Example ERD

Connecting Person and Phone Number

Let’s say I want to get all of the phone numbers for a person with ID 1. That’s fairly simple, I just query the phone number table for that person. But what happens if I also want to get the person data? I have to execute two queries and connect the data in my application.

SELECT * FROM person WHERE person_id = 1
SELECT * FROM phone WHERE person_id = 1

Now what happens if I want to get all people and all of their phone numbers. While I’d like to do a simple join, I can’t, because I’d end up with duplicate person data.

SELECT * FROM person LEFT JOIN phone ON person.person_id = phone.person_id

So, again, I have to run two queries and aggregate the data together in my application.

In HarperDB, we have the ARRAY() aggregate function which allows us to return this data, with no duplicates, in a single query. Remember, because ARRAY() is an aggregate function that we need to have a GROUP BY clause specified. In this case, since we are selecting multiple person fields, we need to specify all of them in our GROUP BY clause. Since we included our hash, person_id, we will safely retrieve each person record.

SELECT
  person.person_id,
  person.first_name,
  person.middle_name,
  person.last_name,
  person.saluation,
  person.dob,
  ARRAY({
    type: addr.address_type,
    addressLine1: addr.address_line_1,
    addressLine2: addr.address_line_2,
    city: addr.city,
    state: addr.state,
    zip: addr.zip_code,
  }) as address
FROM
  arr.person AS person
    LEFT JOIN arr.address AS addr
      ON person.person_id = addr.person_id
GROUP BY
  person.person_id,
  person.first_name,
  person.middle_name,
  person.last_name,
  person.saluation,
  person.dob

This returns a list of complex JSON objects where each Person object contains a list of Phone objects. For example, the complex object for person ID 1 would look like this:

{
  "person_id": 1,
  "first_name": "Doug",
  "middle_name": "James",
  "last_name": "Henley",
  "saluation": "Mr.",
  "dob": "8/15/57",
  "address": [
    {
      "type": "MAILING",
      "addressLine1": "94317 Roxbury Court",
      "addressLine2": "Apt 102",
      "city": "Tampa",
      "state": "FL",
      "zip": 33625
    },
    {
      "type": "MAILING",
      "addressLine1": "35 Elgar Court",
      "city": "Arvada",
      "state": "CO",
      "zip": 80005
    }
  ]
}

Connecting Person, Phone Number, and Address

Now that we’ve shown how to aggregate list data from a single table let’s take a look at how we can retrieve multiple lists within our complex JSON objects. Ordinarily, if I wanted to pull data for person, phone, and address, then I would need three SQL queries.

SELECT * FROM person WHERE person_id = 1
SELECT * FROM phone WHERE person_id = 1
SELECT * FROM address WHERE person_id = 1

Now, if I were to put all three of those tables into a JOIN statement, I would receive a lot of duplicate data across all three tables. Take a look, here, at what is returned by the below SQL statement.

SELECT *
FROM person
  LEFT JOIN phone
    ON person.person_id = phone.person_id
  LEFT JOIN address
    ON person.person_id = address.person_id

Moving back to HarperDB we can query with the ARRAY() function to help us out with this. However, because we are joining across multiple tables we may still see some duplicate data in the phone and address lists. This is the inherent nature of SQL JOINS. In order to solve this problem, HarperDB created the DISTINCT_ARRAY() wrapper function. This function can be placed around a standard ARRAY() function call to ensure a distinct (deduplicated) results set is returned. Now to create our complex Person object with lists of both Phone and Address we can write a SQL statement like this:

SELECT
  person.person_id,
  person.first_name,
  person.middle_name,
  person.last_name,
  person.saluation,
  person.dob,
  DISTINCT_ARRAY(ARRAY({
    type: addr.address_type,
    addressLine1: addr.address_line_1,
    addressLine2: addr.address_line_2,
    city: addr.city,
    state: addr.state,
    zip: addr.zip_code,
  })) as address,
  DISTINCT_ARRAY(ARRAY({
    type: phone.phone_type,
    num: phone.number,
    primaryFlag: phone.primary_flag,
  })) as phone
FROM arr.person AS person
  LEFT JOIN arr.address AS addr
    ON person.person_id = addr.person_id
  LEFT JOIN arr.phone AS phone
    ON person.person_id = phone.person_id
GROUP BY
  person.person_id,
  person.first_name,
  person.middle_name,
  person.last_name,
  person.saluation,
  person.dob

The complex object for Person ID 1 returned from the above query looks like this

{
  "person_id": 1,
  "first_name": "Doug",
  "middle_name": "James",
  "last_name": "Henley",
  "saluation": "Mr.",
  "dob": "8/15/57",
  "address": [
    {
      "type": "MAILING",
      "line1": "94317 Roxbury Court",
      "line2": "Apt 102",
      "city": "Tampa",
      "state": "FL",
      "zip": 33625
    },
    {
      "type": "MAILING",
      "line1": "35 Elgar Court",
      "city": "Arvada",
      "state": "CO",
      "zip": 80005
    }
  ],
  "phone": [
    {
      "type": "REFERENCE",
      "num": "926-647-6907",
      "primaryFlag": 1
    },
    {
      "type": "HOME",
      "num": "737-377-6038",
      "primaryFlag": 0
    }
  ]
}

With a single query in HarperDB we were able to transform SQL data into a complex JSON object that can be used in your modern application!

Sample Data

Here are links to CSVs of each table used in the above example. You can also view the data below.


Also published at https://dev.to/harperdb/sql-queries-to-complex-objects-with-array-function-4p6
