Multi-Class Classification: Understanding Activation and Loss Functions in Neural Networks

My formulates the classification problem and splits it into 3 types (binary, multi-class, and multi-label) and answers the question “What activation and loss functions do you need to use to solve a binary classification task?”. previous post In this post, I will answer the same question but for the multi-class classification task and provide you with an . example of pytorch implementation in Google colab What activation and loss functions do you need to use to solve a multi-class classification task? The provided code is largely based on the binary classification implementation since you need to add very few modifications to your code and NN to switch from binary classification to multi-class. The modified code blocks are marked with for easier navigation. (Changed) 1 Why is it important to understand activation function and loss used for multi-class classification? As will be shown later, the activation function used for multi-class classification is the softmax activation. Softmax is broadly used in different NN architectures outside of multi-class classification. For example, softmax is at the core of the multi-head attention block used in Transformer models (see ) due to its ability to convert input values into a probability distribution (see more on that later). Attention Is All You Need If you know the motivation behind applying softmax activation and CE loss to solve multi-class classification problems you will be able to understand and implement much more complicated NN architectures and loss functions. 2 Multi-class classification problem formulation Multi-class classification problem can be represented as a set of samples , where is an m-dimensional vector that contains features of sample and is the class to which belongs. Where the label can assume one of the values, where k is the number of classes higher than 2. The goal is to build a model that predicts the label y_i for each input sample . {(x_1, y_1), (x_2, y_2),...,(x_n, y_n)} x_i i y_i x_i y_i k x_i Examples of tasks that can be treated as multi-class classification problems: medical diagnosis - diagnosing a patient with one of several diseases based on provided data (medical history, test results, symptoms) product categorization - automatic product classification for e-commerce platforms weather prediction - classifying the future weather as sunny, cloudy, rainy, etc categorizing movies, music, and articles into different genres classifying online customer reviews into categories such as product feedback, service feedback, complaints, etc 3 Activation and loss functions for multi-class classification In the multi-class classification you are given: a set of samples {(x_1, y_1), (x_2, y_2),...,(x_n, y_n)} is an m-dimensional vector that contains features of sample x_i i is the class to which belongs and can assume one of the values, where is the number of classes. y_i x_i k k>2 To build a multi-class classification neural network as a probabilistic classifier we need: an output fully connected layer with a size of k output values should be in the range [0,1] the sum of output values should be equal to 1. In multi-class classification, each input can belong to only one class (mutually exclusive classes), hence the sum probabilities of all classes should be 1: x . SUM(p_0,…,p_k)=1 a loss function that has the lowest value when the prediction and the ground truth are the same 3.1 The softmax activation function The final linear layer of a neural network outputs a vector of "raw output values". In the case of classification, the output values represent the model's confidence that the input belongs to one of the classes. As discussed before the output layer needs to have size and the output values should represent probabilities for each of k classes and . k k p_i SUM(p_i)=1 The article on uses sigmoid activation to transform NN output values into probabilities. Let’s try applying sigmoid on output values in the range [-3, 3] and see if sigmoid satisfies previously listed requirements: binary classification k output values should be in the range (0,1), where is the number of classes k k the sum of output values should be equal to 1 k The previous article shows that the sigmoid function maps input values into a range (0,1). Let’s see if the sigmoid activation satisfies the second requirement. In the example table below I processed a vector with size (k=7) with sigmoid activation and sum up all these values - the sum of these 7 values equals 3.5. A straightforward way to fix that would be to divide all values by their sum. k k Input -3 -2 -1 0 1 2 3 SUM sigmoid output 0.04743 0.11920 0.26894 0.50000 0.73106 0.88080 0.95257 3.5000 Another way would be to take the exponent of the input value and divide it by the sum of exponents of all input values: The softmax function transforms a vector of real numbers into a vector of probabilities. Each probability in the result is in the range (0,1), and the sum of the probabilities is 1. Input -3 -2 -1 0 1 2 3 SUM softmax 0.00157 0.00426 0.01159 0.03150 0.08563 0.23276 0.63270 1 There is one thing that you need to be aware of when working with softmax: the output value depends on all values in the input array since we divide it by the sum of exponents of all values. The table below demonstrates this: two input vectors have 3 common values {1, 3, 4}, but the output softmax values differ because the second element is different (2 and 4). p_i Input 1 1 2 3 4 softmax 1 0.0321 0.0871 0.2369 0.6439 Input 2 1 4 3 4 softmax 2 0.0206 0.4136 0.1522 0.4136 3.2 Cross-entropy loss The binary cross entropy loss is defined as: In binary classification, there are two output probabilities and and ground truth values and p_i (1-p_i) y_i (1-y_i). The multi-class classification problem uses the generalization of BCE loss for N classes: cross-entropy loss. N is the number of input samples, is the ground truth, and is the predicted probability of class . y_i p_i i 4 Multi-class classification NN example with PyTorch To implement a probabilistic multi-class classification NN we need: ground truth and predictions should have dimensions where is the number of input samples, is the number of classes - class id needs to be encoded into a vector with size [N,k] N k k the final linear layer size should be k outputs from the final layer should be processed with activation to obtain output probabilities softmax loss should be applied to predicted class probabilities and ground truth values CE find the output class id from the output vector with size k Most of the parts of the code are based on the code from the previous article on binary classification. The changed parts are marked with : (Changed) data preprocessing and postprocessing activation function loss function performance metric confusion matrix Let's code a neural network for multi-class classification with the PyTorch framework. First, install - this package will be used later to compute classification accuracy and confusion matrix. torchmetrics # used for accuracy metric and confusion matrix !pip install torchmetrics Import packages that will be used later in the code from sklearn.datasets import make_classification import numpy as np import torch import torchmetrics import matplotlib.pyplot as plt import seaborn as sn import pandas as pd from sklearn.decomposition import PCA 4.1 Create dataset Set global variable with the number of classes (if you set it to 2 and get binary-classification NN that uses softmax and Cross-Entropy loss) number_of_classes=4 I will use to generate a binary classification dataset: sklearn.datasets.make_classification - is the number of generated samples n_samples - sets the number of dimensions of generated samples X n_features - the number of classes in the generated dataset. In the multi-class classification problem, there should be more than 2 classes n_classes The generated dataset will have X with shape and Y with shape . [n_samples, n_features] [n_samples, ] def get_dataset(n_samples=10000, n_features=20, n_classes=2): # https://scikit-learn.org/stable/modules/generated/sklearn.datasets.make_classification.html#sklearn.datasets.make_classification data_X, data_y = make_classification(n_samples=n_samples, n_features=n_features, n_classes=n_classes, n_informative=n_classes, n_redundant=0, n_clusters_per_class=2, random_state=42, class_sep=4) return data_X, data_y 4.2 Dataset visualization Define functions to visualize and print out dataset statistics. show_dataset function uses to reduce the dimensionality of X from any number down to 2 for simplicity of visualization of input data X in the 2D plot. PCA def print_dataset(X, y): print(f'X shape: {X.shape}, min: {X.min()}, max: {X.max()}') print(f'y shape: {y.shape}') print(y[:10]) def show_dataset(X, y, title=''): if X.shape[1] > 2: X_pca = PCA(n_components=2).fit_transform(X) else: X_pca = X fig = plt.figure(figsize=(4, 4)) plt.scatter(x=X_pca[:, 0], y=X_pca[:, 1], c=y, alpha=0.5) # generate colors for all classes colors = plt.cm.rainbow(np.linspace(0, 1, number_of_classes)) # iterate over classes and visualize them with the dedicated color for class_id in range(number_of_classes): class_mask = np.argwhere(y == class_id) X_class = X_pca[class_mask[:, 0]] plt.scatter(x=X_class[:, 0], y=X_class[:, 1], c=np.full((X_class[:, 0].shape[0], 4), colors[class_id]), label=class_id, alpha=0.5) plt.title(title) plt.legend(loc="best", title="Classes") plt.xticks() plt.yticks() plt.show() 4.3 Dataset scaler Scale the dataset features X to range [0,1] with min max scaler. This is usually done for faster and more stable training. def scale(x_in): return (x_in - x_in.min(axis=0))/(x_in.max(axis=0)-x_in.min(axis=0)) Let's print out the generated dataset statistics and visualize it with the functions from above. X, y = get_dataset(n_classes=number_of_classes) print('before scaling') print_dataset(X, y) show_dataset(X, y, 'before') X_scaled = scale(X) print('after scaling') print_dataset(X_scaled, y) show_dataset(X_scaled, y, 'after') The outputs you should get are below. before scaling X shape: (10000, 20), min: -9.549551632357336, max: 9.727761741276673 y shape: (10000,) [0 2 1 2 0 2 0 1 1 2] after scaling X shape: (10000, 20), min: 0.0, max: 1.0 y shape: (10000,) [0 2 1 2 0 2 0 1 1 2] Min-max scaling does not distort dataset features, it linearly transforms them into the range [0,1]. The “dataset after min-max scaling” figure appears to be distorted in comparison to the previous figure because 20 dimensions are reduced to 2 by the PCA algorithm and the PCA algorithm can be affected by min-max scaling. Create PyTorch data loaders. generates the dataset as two numpy arrays. To create PyTorch dataloaders we need to transform the numpy dataset into torch.tensor with torch.utils.data.TensorDataset. sklearn.datasets.make_classification def get_data_loaders(dataset, batch_size=32, shuffle=True): data_X, data_y = dataset # https://pytorch.org/docs/stable/data.html#torch.utils.data.TensorDataset torch_dataset = torch.utils.data.TensorDataset(torch.tensor(data_X, dtype=torch.float32), torch.tensor(data_y, dtype=torch.float32)) # https://pytorch.org/docs/stable/data.html#torch.utils.data.random_split train_dataset, val_dataset = torch.utils.data.random_split(torch_dataset, [int(len(torch_dataset)*0.8), int(len(torch_dataset)*0.2)], torch.Generator().manual_seed(42)) # https://pytorch.org/docs/stable/data.html#torch.utils.data.DataLoader loader_train = torch.utils.data.DataLoader(train_dataset, batch_size=batch_size, shuffle=shuffle) loader_val = torch.utils.data.DataLoader(val_dataset, batch_size=batch_size, shuffle=shuffle) return loader_train, loader_val Test PyTorch data loaders dataloader_train, dataloader_val = get_data_loaders(get_dataset(n_classes=number_of_classes), batch_size=32) train_batch_0 = next(iter(dataloader_train)) print(f'Batches in the train dataloader: {len(dataloader_train)}, X: {train_batch_0[0].shape}, Y: {train_batch_0[1].shape}') val_batch_0 = next(iter(dataloader_val)) print(f'Batches in the validation dataloader: {len(dataloader_val)}, X: {val_batch_0[0].shape}, Y: {val_batch_0[1].shape}') The output: Batches in the train dataloader: 250, X: torch.Size([32, 20]), Y: torch.Size([32]) Batches in the validation dataloader: 63, X: torch.Size([32, 20]), Y: torch.Size([32]) 4.4 Dataset pre-processing and post-processing (Changed) Create pre and postprocessing functions. As you may have noted before current Y shape is [N], we need it to be [N,number_of_classes]. To do that we need to one-hot encode the values in Y vector. One-hot encoding is a process of converting class indexes into a binary representation where each class is represented by a unique binary vector. In other words: create a zero vector with the size [number_of_classes] and set the element at position class_id to 1, where class_ids {0,1,…,number_of_classes-1}: 0 >> [1. 0. 0. 0.] 1 >> [0. 1. 0. 0.] 2 >> [0. 0. 1. 0.] 2 >> [0. 0. 0. 1.] Pytorch tensors can be processed with torch.nn.functional.one_hot and the numpy implementation is very straightforward. The output vector will have shape [N,number_of_classes]. def preprocessing(y, n_classes): ''' one-hot encoding for input numpy array or pytorch Tensor input: y - [N,] numpy array or pytorch Tensor output: [N, n_classes] the same type as input ''' assert type(y)==np.ndarray or torch.is_tensor(y), f'input should be numpy array or torch tensor. Received input is: {type(categorical)}' assert len(y.shape)==1, f'input shape should be [N,]. Received input shape is: {y.shape}' if torch.is_tensor(y): return torch.nn.functional.one_hot(y, num_classes=n_classes) else: categorical = np.zeros([y.shape[0], n_classes]) categorical[np.arange(y.shape[0]), y]=1 return categorical To convert the one-hot encoded vector back to the class id we need to find the index of the max element in the one-hot encoded vector. It can be done with torch.argmax or np.argmax an below. def postprocessing(categorical): ''' one-hot to classes decoding with .argmax() input: categorical - [N,classes] numpy array or pytorch Tensor output: [N,] the same type as input ''' assert type(categorical)==np.ndarray or torch.is_tensor(categorical), f'input should be numpy array or torch tensor. Received input is: {type(categorical)}' assert len(categorical.shape)==2, f'input shape should be [N,classes]. Received input shape is: {categorical.shape}' if torch.is_tensor(categorical): return torch.argmax(categorical,dim=1) else: return np.argmax(categorical, axis=1) Test the defined pre and postprocessing functions. y = get_dataset(n_classes=number_of_classes)[1] y_logits = preprocessing(y, n_classes=number_of_classes) y_class = postprocessing(y_logits) print(f'y shape: {y.shape}, y preprocessed shape: {y_logits.shape}, y postprocessed shape: {y_class.shape}') print('Preprocessing does one-hot encoding of class ids.') print('Postprocessing does one-hot decoding of class one-hot encoded class ids.') for i in range(10): print(f'{y[i]} >> {y_logits[i]} >> {y_class[i]}') The output: y shape: (10000,), y preprocessed shape: (10000, 4), y postprocessed shape: (10000,) Preprocessing does one-hot encoding of class ids. Postprocessing does one-hot decoding of one-hot encoded class ids. id>>one-hot encoding>>id 0 >> [1. 0. 0. 0.] >> 0 2 >> [0. 0. 1. 0.] >> 2 1 >> [0. 1. 0. 0.] >> 1 2 >> [0. 0. 1. 0.] >> 2 0 >> [1. 0. 0. 0.] >> 0 2 >> [0. 0. 1. 0.] >> 2 0 >> [1. 0. 0. 0.] >> 0 1 >> [0. 1. 0. 0.] >> 1 1 >> [0. 1. 0. 0.] >> 1 2 >> [0. 0. 1. 0.] >> 2 4.5 Creating and training a multi-class classification model This section shows an implementation of all functions required to train a binary classification model. 4.5.1 Softmax activation (Changed) The PyTorch-based implementation of the softmax formula def softmax(x): assert len(x.shape)==2, f'input shape should be [N,classes]. Received input shape is: {x.shape}' # Subtract the maximum value for numerical stability # you can find explanation here: https://www.deeplearningbook.org/contents/numerical.html x = x - torch.max(x, dim=1, keepdim=True)[0] # Exponentiate the values exp_x = torch.exp(x) # Sum along the specified dimension sum_exp_x = torch.sum(exp_x, dim=1, keepdim=True) # Compute the softmax return exp_x / sum_exp_x Let's test softmax: generate numpy array in the range [-10, 11] with step 1 test_input reshape it into a tensor with shape [7,3] process with the implemented function and PyTorch default implementation test_input softmax torch.nn.functional.softmax compare the results (they should be identical) output softmax values and sum for all seven [1,3] tensors test_input = torch.arange(-10, 11, 1, dtype=torch.float32) test_input = test_input.reshape(-1,3) softmax_output = softmax(test_input) print(f'Input data shape: {test_input.shape}') print(f'input data range: [{test_input.min():.3f}, {test_input.max():.3f}]') print(f'softmax output data range: [{softmax_output.min():.3f}, {softmax_output.max():.3f}]') print(f'softmax output data sum along axis 1: [{softmax_output.sum(axis=1).numpy()}]') softmax_output_pytorch = torch.nn.functional.softmax(test_input, dim=1) print(f'softmax output is the same with pytorch implementation: {(softmax_output_pytorch==softmax_output).all().numpy()}') print('Softmax activation changes values in the chosen axis (1) so that they always sum up to 1:') for i in range(softmax_output.shape[0]): print(f'\t{i}. Sum before softmax: {test_input[i].sum().numpy()} | Sum after softmax: {softmax_output[i].sum().numpy()}') print(f'\t values before softmax: {test_input[i].numpy()}, softmax output values: {softmax_output[i].numpy()}') The output: Input data shape: torch.Size([7, 3]) input data range: [-10.000, 10.000] softmax output data range: [0.090, 0.665] softmax output data sum along axis 1: [[1. 1. 1. 1. 1. 1. 1.]] softmax output is the same with pytorch implementation: True Softmax activation changes values in the chosen axis (1) so that they always sum up to 1: 0. Sum before softmax: -27.0 | Sum after softmax: 1.0 values before softmax: [-10. -9. -8.], softmax output values: [0.09003057 0.24472848 0.66524094] 1. Sum before softmax: -18.0 | Sum after softmax: 1.0 values before softmax: [-7. -6. -5.], softmax output values: [0.09003057 0.24472848 0.66524094] 2. Sum before softmax: -9.0 | Sum after softmax: 1.0 values before softmax: [-4. -3. -2.], softmax output values: [0.09003057 0.24472848 0.66524094] 3. Sum before softmax: 0.0 | Sum after softmax: 1.0 values before softmax: [-1. 0. 1.], softmax output values: [0.09003057 0.24472848 0.66524094] 4. Sum before softmax: 9.0 | Sum after softmax: 1.0 values before softmax: [2. 3. 4.], softmax output values: [0.09003057 0.24472848 0.66524094] 5. Sum before softmax: 18.0 | Sum after softmax: 1.0 values before softmax: [5. 6. 7.], softmax output values: [0.09003057 0.24472848 0.66524094] 6. Sum before softmax: 27.0 | Sum after softmax: 1.0 values before softmax: [ 8. 9. 10.], softmax output values: [0.09003057 0.24472848 0.66524094] 4.5.2 Loss function: cross-entropy (Changed) The PyTorch-based implementation of the CE formula def cross_entropy_loss(softmax_logits, labels): # Calculate the cross-entropy loss loss = -torch.sum(labels * torch.log(softmax_logits)) / softmax_logits.size(0) return loss Test CE implementation: generate array with shape [10,5] and values in the range [0,1) with test_input torch.rand generate array with shape [10,] and values in the range [0,4]. test_target one-hot encode array test_target compute loss with the implemented function and PyTorch implementation cross_entropy torch.nn.functional.binary_cross_entropy compare the results (they should be identical) test_input = torch.rand(10, 5, requires_grad=False) test_target = torch.randint(0, 5, (10,), requires_grad=False) test_target = preprocessing(test_target, n_classes=5).float() print(f'test_input shape: {list(test_input.shape)}, test_target shape: {list(test_target.shape)}') # get loss with the cross_entropy_loss implementation loss = cross_entropy_loss(softmax(test_input), test_target) # get loss with the torch.nn.functional.cross_entropy implementation # !!!torch.nn.functional.cross_entropy applies softmax on input logits # !!!pass it test_input without softmax activation loss_pytorch = torch.nn.functional.cross_entropy(test_input, test_target) print(f'Loss outputs are the same: {(loss==loss_pytorch).numpy()}') The expected output: test_input shape: [10, 5], test_target shape: [10, 5] Loss outputs are the same: True 4.5.3 Accuracy metric (changed) I will use implementation to compute accuracy based on model predictions and ground truth. torchmetrics To create a multi-class classification accuracy metric two parameters are required: task type "multiclass" number of classes num_classes # https://torchmetrics.readthedocs.io/en/stable/classification/accuracy.html#module-interface accuracy_metric=torchmetrics.classification.Accuracy(task="multiclass", num_classes=number_of_classes) def compute_accuracy(y_pred, y): assert len(y_pred.shape)==2 and y_pred.shape[1] == number_of_classes, 'y_pred shape should be [N, C]' assert len(y.shape)==2 and y.shape[1] == number_of_classes, 'y shape should be [N, C]' return accuracy_metric(postprocessing(y_pred), postprocessing(y)) 4.5.4 NN model The NN used in this example is a deep NN with 2 hidden layers. Input and hidden layers use ReLU activation and the final layer uses the activation function provided as the class input (it will be the sigmoid activation function that was implemented before). class ClassifierNN(torch.nn.Module): def __init__(self, loss_function, activation_function, input_dims=2, output_dims=1): super().__init__() self.linear1 = torch.nn.Linear(input_dims, input_dims * 4) self.linear2 = torch.nn.Linear(input_dims * 4, input_dims * 8) self.linear3 = torch.nn.Linear(input_dims * 8, input_dims * 4) self.output = torch.nn.Linear(input_dims * 4, output_dims) self.loss_function = loss_function self.activation_function = activation_function def forward(self, x): x = torch.nn.functional.relu(self.linear1(x)) x = torch.nn.functional.relu(self.linear2(x)) x = torch.nn.functional.relu(self.linear3(x)) x = self.activation_function(self.output(x)) return x 4.5.5 Training, evaluation, and prediction The figure above depicts the training logic for a single batch. Later the train_epoch function will be called multiple times (chosen number of epochs). def train_epoch(model, optimizer, dataloader_train): # set the model to the training mode # https://pytorch.org/docs/stable/generated/torch.nn.Module.html#torch.nn.Module.train model.train() losses = [] accuracies = [] for step, (X_batch, y_batch) in enumerate(dataloader_train): ### forward propagation # get model output and use loss function y_pred = model(X_batch) # get class probabilities with shape [N,1] # apply loss function on predicted probabilities and ground truth loss = model.loss_function(y_pred, y_batch) ### backward propagation # set gradients to zero before backpropagation # https://pytorch.org/docs/stable/generated/torch.optim.Optimizer.zero_grad.html optimizer.zero_grad() # compute gradients # https://pytorch.org/docs/stable/generated/torch.Tensor.backward.html loss.backward() # update weights # https://pytorch.org/docs/stable/optim.html#taking-an-optimization-step optimizer.step() # update model weights # calculate batch accuracy acc = compute_accuracy(y_pred, y_batch) # append batch loss and accuracy to corresponding lists for later use accuracies.append(acc) losses.append(float(loss.detach().numpy())) # compute average epoch accuracy train_acc = np.array(accuracies).mean() # compute average epoch loss loss_epoch = np.array(losses).mean() return train_acc, loss_epoch The evaluation function iterates over the provided PyTorch dataloader computes current model accuracy and returns average loss and average accuracy. def evaluate(model, dataloader_in): # set the model to the evaluation mode # https://pytorch.org/docs/stable/generated/torch.nn.Module.html#torch.nn.Module.eval model.eval() val_acc_epoch = 0 losses = [] accuracies = [] # disable gradient calculation for evaluation # https://pytorch.org/docs/stable/generated/torch.no_grad.html with torch.no_grad(): for step, (X_batch, y_batch) in enumerate(dataloader_in): # get predictions y_pred = model(X_batch) # calculate loss loss = model.loss_function(y_pred, y_batch) # calculate batch accuracy acc = compute_accuracy(y_pred, y_batch) accuracies.append(acc) losses.append(float(loss.detach().numpy())) # compute average accuracy val_acc = np.array(accuracies).mean() # compute average loss loss_epoch = np.array(losses).mean() return val_acc, loss_epoch function iterates over the provided dataloader, collects post-processed (one-hot decoded) model predictions and ground truth values into [N,1] PyTorch arrays, and returns both arrays. Later this function will be used to compute the confusion matrix and visualize predictions. predict def predict(model, dataloader): # set the model to the evaluation mode # https://pytorch.org/docs/stable/generated/torch.nn.Module.html#torch.nn.Module.eval model.eval() xs, ys = next(iter(dataloader)) y_pred = torch.empty([0, ys.shape[1]]) x = torch.empty([0, xs.shape[1]]) y = torch.empty([0, ys.shape[1]]) # disable gradient calculation for evaluation # https://pytorch.org/docs/stable/generated/torch.no_grad.html with torch.no_grad(): for step, (X_batch, y_batch) in enumerate(dataloader): # get predictions y_batch_pred = model(X_batch) y_pred = torch.cat([y_pred, y_batch_pred]) y = torch.cat([y, y_batch]) x = torch.cat([x, X_batch]) # print(y_pred.shape, y.shape) y_pred = postprocessing(y_pred) y = postprocessing(y) return y_pred, y, x To train the model we just need to call the function N times, where N is the number of epochs. The function is called to log the current model accuracy on the validation dataset. Finally, the best model is updated based on the validation accuracy. The function returns the best validation accuracy and the training history. train_epoch evaluate model_train def model_train(model, optimizer, dataloader_train, dataloader_val, n_epochs=50): best_acc = 0 best_weights = None history = {'loss': {'train': [], 'validation': []}, 'accuracy': {'train': [], 'validation': []}} for epoch in range(n_epochs): # train on dataloader_train acc_train, loss_train = train_epoch(model, optimizer, dataloader_train) # evaluate on dataloader_val acc_val, loss_val = evaluate(model, dataloader_val) print(f'Epoch: {epoch} | Accuracy: {acc_train:.3f} / {acc_val:.3f} | ' + f'loss: {loss_train:.5f} / {loss_val:.5f}') # save epoch losses and accuracies in history dictionary history['loss']['train'].append(loss_train) history['loss']['validation'].append(loss_val) history['accuracy']['train'].append(acc_train) history['accuracy']['validation'].append(acc_val) # Save the best validation accuracy model if acc_val >= best_acc: print(f'\tBest weights updated. Old accuracy: {best_acc:.4f}. New accuracy: {acc_val:.4f}') best_acc = acc_val torch.save(model.state_dict(), 'best_weights.pt') # restore model and return best accuracy model.load_state_dict(torch.load('best_weights.pt')) return best_acc, history 4.5.6 Get the dataset, create the model, and train it (Changed) Let's put everything together and train the multi-class classification model. ######################################### # Get the dataset X, y = get_dataset(n_classes=number_of_classes) print(f'Generated dataset shape. X:{X.shape}, y:{y.shape}') # change y numpy array shape from [N,] to [N, C] for multi-class classification y = preprocessing(y, n_classes=number_of_classes) print(f'Dataset shape prepared for multi-class classification with softmax activation and CE loss.') print(f'X:{X.shape}, y:{y.shape}') # Get train and validation datal loaders dataloader_train, dataloader_val = get_data_loaders(dataset=(scale(X), y), batch_size=32) # get a batch from dataloader and output intput and output shape X_0, y_0 = next(iter(dataloader_train)) print(f'Model input data shape: {X_0.shape}, output (ground truth) data shape: {y_0.shape}') ######################################### # Create ClassifierNN for multi-class classification problem # input dims: [N, features] # output dims: [N, C] where C is number of classes # activation - softmax to output [,C] probabilities so that their sum(p_1,p_2,...,p_c)=1 # loss - cross-entropy model = ClassifierNN(loss_function=cross_entropy_loss, activation_function=softmax, input_dims=X.shape[1], output_dims=y.shape[1]) ######################################### # create optimizer and train the model on the dataset optimizer = torch.optim.Adam(model.parameters(), lr=0.001) print(f'Model size: {sum([x.reshape(-1).shape[0] for x in model.parameters()])} parameters') print('#'*10) print('Start training') acc, history = model_train(model, optimizer, dataloader_train, dataloader_val, n_epochs=20) print('Finished training') print('#'*10) print("Model accuracy: %.2f%%" % (acc*100)) The expected output should be similar to the one provided below. Generated dataset shape. X:(10000, 20), y:(10000,) Dataset shape prepared for multi-class classification with softmax activation and CE loss. X:(10000, 20), y:(10000, 4) Model input data shape: torch.Size([32, 20]), output (ground truth) data shape: torch.Size([32, 4]) Model size: 27844 parameters ########## Start training Epoch: 0 | Accuracy: 0.682 / 0.943 | loss: 0.78574 / 0.37459 Best weights updated. Old accuracy: 0.0000. New accuracy: 0.9435 Epoch: 1 | Accuracy: 0.960 / 0.967 | loss: 0.20272 / 0.17840 Best weights updated. Old accuracy: 0.9435. New accuracy: 0.9668 Epoch: 2 | Accuracy: 0.978 / 0.962 | loss: 0.12004 / 0.17931 Epoch: 3 | Accuracy: 0.984 / 0.979 | loss: 0.10028 / 0.13246 Best weights updated. Old accuracy: 0.9668. New accuracy: 0.9787 Epoch: 4 | Accuracy: 0.985 / 0.981 | loss: 0.08838 / 0.12720 Best weights updated. Old accuracy: 0.9787. New accuracy: 0.9807 Epoch: 5 | Accuracy: 0.986 / 0.981 | loss: 0.08096 / 0.12174 Best weights updated. Old accuracy: 0.9807. New accuracy: 0.9812 Epoch: 6 | Accuracy: 0.986 / 0.981 | loss: 0.07944 / 0.12036 Epoch: 7 | Accuracy: 0.988 / 0.982 | loss: 0.07605 / 0.11773 Best weights updated. Old accuracy: 0.9812. New accuracy: 0.9821 Epoch: 8 | Accuracy: 0.989 / 0.982 | loss: 0.07168 / 0.11514 Best weights updated. Old accuracy: 0.9821. New accuracy: 0.9821 Epoch: 9 | Accuracy: 0.989 / 0.983 | loss: 0.06890 / 0.11409 Best weights updated. Old accuracy: 0.9821. New accuracy: 0.9831 Epoch: 10 | Accuracy: 0.989 / 0.984 | loss: 0.06750 / 0.11128 Best weights updated. Old accuracy: 0.9831. New accuracy: 0.9841 Epoch: 11 | Accuracy: 0.990 / 0.982 | loss: 0.06505 / 0.11265 Epoch: 12 | Accuracy: 0.990 / 0.983 | loss: 0.06507 / 0.11272 Epoch: 13 | Accuracy: 0.991 / 0.985 | loss: 0.06209 / 0.11240 Best weights updated. Old accuracy: 0.9841. New accuracy: 0.9851 Epoch: 14 | Accuracy: 0.990 / 0.984 | loss: 0.06273 / 0.11157 Epoch: 15 | Accuracy: 0.991 / 0.984 | loss: 0.05998 / 0.11029 Epoch: 16 | Accuracy: 0.990 / 0.985 | loss: 0.06056 / 0.11164 Epoch: 17 | Accuracy: 0.991 / 0.984 | loss: 0.05981 / 0.11096 Epoch: 18 | Accuracy: 0.991 / 0.985 | loss: 0.05642 / 0.10975 Best weights updated. Old accuracy: 0.9851. New accuracy: 0.9851 Epoch: 19 | Accuracy: 0.990 / 0.986 | loss: 0.05929 / 0.10821 Best weights updated. Old accuracy: 0.9851. New accuracy: 0.9856 Finished training ########## Model accuracy: 98.56% 4.5.7 Plot training history def plot_history(history): fig = plt.figure(figsize=(8, 4), facecolor=(0.0, 1.0, 0.0)) ax = fig.add_subplot(1, 2, 1) ax.plot(np.arange(0, len(history['loss']['train'])), history['loss']['train'], color='red', label='train') ax.plot(np.arange(0, len(history['loss']['validation'])), history['loss']['validation'], color='blue', label='validation') ax.set_title('Loss history') ax.set_facecolor((0.0, 1.0, 0.0)) ax.legend() ax = fig.add_subplot(1, 2, 2) ax.plot(np.arange(0, len(history['accuracy']['train'])), history['accuracy']['train'], color='red', label='train') ax.plot(np.arange(0, len(history['accuracy']['validation'])), history['accuracy']['validation'], color='blue', label='validation') ax.set_title('Accuracy history') ax.legend() fig.tight_layout() ax.set_facecolor((0.0, 1.0, 0.0)) fig.show() 4.6 Evaluate the model 4.6.1 Calculate train and validation accuracy acc_train, _ = evaluate(model, dataloader_train) acc_validation, _ = evaluate(model, dataloader_val) print(f'Accuracy - Train: {acc_train:.4f} | Validation: {acc_validation:.4f}') Accuracy - Train: 0.9901 | Validation: 0.9851 4.6.2 Print confusion matrix (Changed) val_preds, val_y, _ = predict(model, dataloader_val) print(val_preds.shape, val_y.shape) multiclass_confusion_matrix = torchmetrics.classification.ConfusionMatrix('multiclass', num_classes=number_of_classes) cm = multiclass_confusion_matrix(val_preds, val_y) print(cm) df_cm = pd.DataFrame(cm) plt.figure(figsize = (6,5), facecolor=(0.0,1.0,0.0)) sn.heatmap(df_cm, annot=True, fmt='d') plt.show() 4.6.3 Plot predictions and ground truth val_preds, val_y, val_x = predict(model, dataloader_val) val_preds, val_y, val_x = val_preds.numpy(), val_y.numpy(), val_x.numpy() show_dataset(val_x, val_y,'Ground Truth') show_dataset(val_x, val_preds, 'Predictions') Conclusion For multi-class classification, you need to use softmax activation and cross-entropy loss. There are a few code modifications required to switch from binary classification to multi-class classification: data preprocessing and postprocessing, activation, and loss functions. Moreover, you can solve binary classification problem by setting the number of classes to 2 with one-hot encoding, softmax, and cross-entropy loss.
