2.2 Fragmentation and PagedAttention

To improve serving throughput, production systems rely on batching which requires careful allocation of GPU memory. This is challenging because the total context length of a request is not known in advance. Serving systems worked around this challenge by pre-reserving KV-cache space assuming that each context is as long as the maximum length supported by the model (e.g.,200K for Yi-6B-200K). vLLM shows that this strategy is prone to severe internal fragmentation. In fact, vLLM showed that prior reservation wastes memory even if the context lengths are known in advance. This is because the per-request KV-cache grows one token at a time and hence prior reservation wastes memory over the entire lifetime of a request.

Inspired by the OS-based virtual memory systems, vLLM proposed PagedAttention to mitigate fragmentation by dynamically allocating memory for the KV-cache. PagedAttention splits KV-cache into fixed-sized blocks and allocates memory for one block at a time. This way, vLLM allocates only as much memory as a request needs, and only when required – not ahead-of-time. Figure 1 shows an example of how reservation-based systems such as Orca [47] can waste significant memory due to fragmentation and how vLLM avoids it with dynamic memory allocation.
