This article will guide you step-by-step on how to start Apache DolphinScheduler using external PostgreSQL and Zookeeper. Whether you're a beginner or an experienced developer, you can easily follow these steps to complete the installation and configuration in a Linux/Unix environment. In addition to the standard installation steps, we also share some cluster deployment tips to help you scale your system with ease. Of course, if you encounter issues such as database connections, Zookeeper connections, or service startup problems, don't worry—this tutorial includes detailed troubleshooting steps to help you resolve them quickly. System Requirements Operating System: Linux/Unix (CentOS 7+ or Ubuntu 16.04+ recommended)
Java Environment: JDK 1.8+
Database: PostgreSQL 9.6+
Distributed Coordination Service: Zookeeper 3.4.6+
Memory: At least 4GB recommended
Disk Space: At least 10GB recommended Operating System: Linux/Unix (CentOS 7+ or Ubuntu 16.04+ recommended) Java Environment: JDK 1.8+ Database: PostgreSQL 9.6+ Distributed Coordination Service: Zookeeper 3.4.6+ Memory: At least 4GB recommended Disk Space: At least 10GB recommended Preparations Install and Configure PostgreSQL Install and Configure PostgreSQL # Install PostgreSQL (CentOS example)
sudo yum install -y postgresql-server postgresql-contrib

# Initialize the database
sudo postgresql-setup initdb

# Start the service
sudo systemctl start postgresql
sudo systemctl enable postgresql

# Create DolphinScheduler database and user
sudo -u postgres psql -c "CREATE USER dolphinscheduler WITH PASSWORD 'yourpassword';"
sudo -u postgres psql -c "CREATE DATABASE dolphinscheduler OWNER dolphinscheduler;"
sudo -u postgres psql -c "GRANT ALL PRIVILEGES ON DATABASE dolphinscheduler TO dolphinscheduler;"

# Modify pg_hba.conf
sudo vi /var/lib/pgsql/data/pg_hba.conf
# Add or modify the following line:
host    all             all             0.0.0.0/0               md5

# Modify postgresql.conf
sudo vi /var/lib/pgsql/data/postgresql.conf
# Change listen_addresses to:
listen_addresses = '*'

# Restart PostgreSQL
sudo systemctl restart postgresql # Install PostgreSQL (CentOS example)
sudo yum install -y postgresql-server postgresql-contrib

# Initialize the database
sudo postgresql-setup initdb

# Start the service
sudo systemctl start postgresql
sudo systemctl enable postgresql

# Create DolphinScheduler database and user
sudo -u postgres psql -c "CREATE USER dolphinscheduler WITH PASSWORD 'yourpassword';"
sudo -u postgres psql -c "CREATE DATABASE dolphinscheduler OWNER dolphinscheduler;"
sudo -u postgres psql -c "GRANT ALL PRIVILEGES ON DATABASE dolphinscheduler TO dolphinscheduler;"

# Modify pg_hba.conf
sudo vi /var/lib/pgsql/data/pg_hba.conf
# Add or modify the following line:
host    all             all             0.0.0.0/0               md5

# Modify postgresql.conf
sudo vi /var/lib/pgsql/data/postgresql.conf
# Change listen_addresses to:
listen_addresses = '*'

# Restart PostgreSQL
sudo systemctl restart postgresql Install and Configure Zookeeper Install and Configure Zookeeper # Download Zookeeper
wget https://downloads.apache.org/zookeeper/zookeeper-3.7.1/apache-zookeeper-3.7.1-bin.tar.gz
tar -xzf apache-zookeeper-3.7.1-bin.tar.gz
mv apache-zookeeper-3.7.1-bin /opt/zookeeper

# Configure Zookeeper
cd /opt/zookeeper/conf
cp zoo_sample.cfg zoo.cfg
vi zoo.cfg
# Set data directory and server configuration (if clustered)
dataDir=/opt/zookeeper/data
# No need to change server settings for standalone mode

# Create data directory
mkdir /opt/zookeeper/data

# Start Zookeeper
/opt/zookeeper/bin/zkServer.sh start # Download Zookeeper
wget https://downloads.apache.org/zookeeper/zookeeper-3.7.1/apache-zookeeper-3.7.1-bin.tar.gz
tar -xzf apache-zookeeper-3.7.1-bin.tar.gz
mv apache-zookeeper-3.7.1-bin /opt/zookeeper

# Configure Zookeeper
cd /opt/zookeeper/conf
cp zoo_sample.cfg zoo.cfg
vi zoo.cfg
# Set data directory and server configuration (if clustered)
dataDir=/opt/zookeeper/data
# No need to change server settings for standalone mode

# Create data directory
mkdir /opt/zookeeper/data

# Start Zookeeper
/opt/zookeeper/bin/zkServer.sh start Install and Configure DolphinScheduler 3.1.9 Download and Extract Download and Extract wget https://downloads.apache.org/dolphinscheduler/3.1.9/apache-dolphinscheduler-3.1.9-bin.tar.gz
tar -xzf apache-dolphinscheduler-3.1.9-bin.tar.gz
mv apache-dolphinscheduler-3.1.9-bin /opt/dolphinscheduler wget https://downloads.apache.org/dolphinscheduler/3.1.9/apache-dolphinscheduler-3.1.9-bin.tar.gz
tar -xzf apache-dolphinscheduler-3.1.9-bin.tar.gz
mv apache-dolphinscheduler-3.1.9-bin /opt/dolphinscheduler Modify Configuration Files Edit common.properties Modify Configuration Files Edit common.properties common.properties vi /opt/dolphinscheduler/conf/common.properties vi /opt/dolphinscheduler/conf/common.properties Make the following changes: # Database config
spring.datasource.driver-class-name=org.postgresql.Driver
spring.datasource.url=jdbc:postgresql://your-postgresql-server:5432/dolphinscheduler
spring.datasource.username=dolphinscheduler
spring.datasource.password=yourpassword

# Zookeeper config
registry.plugin.name=zookeeper
registry.plugin.type=zookeeper
registry.servers=your-zookeeper-server:2181 # Database config
spring.datasource.driver-class-name=org.postgresql.Driver
spring.datasource.url=jdbc:postgresql://your-postgresql-server:5432/dolphinscheduler
spring.datasource.username=dolphinscheduler
spring.datasource.password=yourpassword

# Zookeeper config
registry.plugin.name=zookeeper
registry.plugin.type=zookeeper
registry.servers=your-zookeeper-server:2181 Optional: Modify environment variables vi /opt/dolphinscheduler/conf/env/dolphinscheduler_env.sh vi /opt/dolphinscheduler/conf/env/dolphinscheduler_env.sh Add or update Java environment variables: export JAVA_HOME=/usr/java/jdk1.8.0_291
export PATH=$JAVA_HOME/bin:$PATH export JAVA_HOME=/usr/java/jdk1.8.0_291
export PATH=$JAVA_HOME/bin:$PATH Initialize the Database Initialize the Database /opt/dolphinscheduler/script/create-dolphinscheduler.sh /opt/dolphinscheduler/script/create-dolphinscheduler.sh Start Services Start Master Server Start Services Start Master Server /opt/dolphinscheduler/bin/dolphinscheduler-daemon.sh start master-server /opt/dolphinscheduler/bin/dolphinscheduler-daemon.sh start master-server Start Worker Server /opt/dolphinscheduler/bin/dolphinscheduler-daemon.sh start worker-server /opt/dolphinscheduler/bin/dolphinscheduler-daemon.sh start worker-server Start API Server /opt/dolphinscheduler/bin/dolphinscheduler-daemon.sh start api-server /opt/dolphinscheduler/bin/dolphinscheduler-daemon.sh start api-server Start Alert Server /opt/dolphinscheduler/bin/dolphinscheduler-daemon.sh start alert-server /opt/dolphinscheduler/bin/dolphinscheduler-daemon.sh start alert-server Verify Installation Check process status: Check process status: ps -ef | grep dolphinscheduler ps -ef | grep dolphinscheduler Access the Web UI: Default Port: 12345 Access URL: http://your-server-ip:12345/dolphinscheduler Default username/password: admin/dolphinscheduler123 Access the Web UI: Default Port: 12345 Access URL: http://your-server-ip:12345/dolphinscheduler Default username/password: admin/dolphinscheduler123 http://your-server-ip:12345/dolphinscheduler Cluster Deployment Guide Cluster Mode Deployment Steps If you want to deploy in cluster mode, follow these steps: Deploy Worker Servers on Multiple Nodes Deploy Worker Servers on Multiple Nodes Node Requirements Deploy Worker Servers on at least 3 nodes (odd number recommended)
Each node must have the same package version
Recommended server specs:

CPU: 4 cores or more
Memory: 8GB or more
Disk: 100GB+ (adjust based on data volume) Deploy Worker Servers on at least 3 nodes (odd number recommended) Each node must have the same package version Recommended server specs:

CPU: 4 cores or more
Memory: 8GB or more
Disk: 100GB+ (adjust based on data volume) CPU: 4 cores or more
Memory: 8GB or more
Disk: 100GB+ (adjust based on data volume) CPU: 4 cores or more Memory: 8GB or more Disk: 100GB+ (adjust based on data volume) Example Deployment Plan Node 1 (Primary): Master Server + Worker Server

IP: 192.168.1.101
Role: Master + Worker


Node 2 (Worker): Worker Server

IP: 192.168.1.102
Role: Worker


Node 3 (Worker): Worker Server

IP: 192.168.1.103
Role: Worker Node 1 (Primary): Master Server + Worker Server

IP: 192.168.1.101
Role: Master + Worker IP: 192.168.1.101
Role: Master + Worker IP: 192.168.1.101 Role: Master + Worker Node 2 (Worker): Worker Server

IP: 192.168.1.102
Role: Worker IP: 192.168.1.102
Role: Worker IP: 192.168.1.102 Role: Worker Node 3 (Worker): Worker Server

IP: 192.168.1.103
Role: Worker IP: 192.168.1.103
Role: Worker IP: 192.168.1.103 Role: Worker Installation Notes Run the same installation script on all nodes
Ensure the installation paths are consistent across nodes
Verify network connectivity between nodes (use ping/telnet)
Configure registry.servers Run the same installation script on all nodes Ensure the installation paths are consistent across nodes Verify network connectivity between nodes (use ping/telnet) Configure registry.servers registry.servers Detailed Configuration Steps Edit common.properties on all nodes

File path: /opt/your_app/conf/common.properties


Set registry.servers to your Zookeeper cluster addresses
Example format: Edit common.properties on all nodes

File path: /opt/your_app/conf/common.properties common.properties File path: /opt/your_app/conf/common.properties File path: /opt/your_app/conf/common.properties /opt/your_app/conf/common.properties Set registry.servers to your Zookeeper cluster addresses registry.servers Example format: registry.servers=zk1:2181,zk2:2181,zk3:2181 registry.servers=zk1:2181,zk2:2181,zk3:2181 Configuration Verification Use zkCli.sh to verify Zookeeper config Use zkCli.sh to verify Zookeeper config zkCli.sh ./zkCli.sh -server zk1:2181 ./zkCli.sh -server zk1:2181 Check node registration: Check node registration: ls /your_app/nodes ls /your_app/nodes Time Synchronization Configuration Time Synchronization Configuration Detailed Time Sync Plan All nodes must maintain time sync (within 1-second drift). Recommended steps: Detailed Time Sync Plan NTP Setup NTP Setup Install NTP: Install NTP: yum install -y ntp yum install -y ntp Sync with NTP server (Aliyun example): Sync with NTP server (Aliyun example): ntpdate ntp.aliyun.com ntpdate ntp.aliyun.com Set auto-sync: Set auto-sync: # Enable at startup
systemctl enable ntpd
# Start service
systemctl start ntpd # Enable at startup
systemctl enable ntpd
# Start service
systemctl start ntpd Verify sync: Verify sync: ntpq -p
date ntpq -p
date Alternative Time Sync Option If external NTP server is inaccessible, set up an internal time server: Alternative Time Sync Option Designate one server as the time source
Sync all other nodes with that server
Example config: Designate one server as the time source Sync all other nodes with that server Example config: ntpdate 192.168.1.100 ntpdate 192.168.1.100 Time Sync Notes Time Sync Notes Recommended to set up a crontab job for periodic sync: Recommended to set up a crontab job for periodic sync: */5 * * * * /usr/sbin/ntpdate ntp.aliyun.com >/dev/null 2>&1 */5 * * * * /usr/sbin/ntpdate ntp.aliyun.com >/dev/null 2>&1 For systems sensitive to time (e.g., finance), maintain <100ms drift For systems sensitive to time (e.g., finance), maintain <100ms drift Common Troubleshooting Database Connection Issues PostgreSQL Remote Access Config PostgreSQL Remote Access Config Check pg_hba.conf file and ensure it includes: Check pg_hba.conf file and ensure it includes: pg_hba.conf host    all             all             0.0.0.0/0               md5 host    all             all             0.0.0.0/0               md5 Restart PostgreSQL after changes Restart PostgreSQL after changes Credential Verification Credential Verification Test connection with psql: Test connection with psql: psql -h [host] -U [username] -d [database] psql -h [host] -U [username] -d [database] Ensure password is correct Ensure password is correct Firewall Check Firewall Check Check if port 5432 is open: Check if port 5432 is open: firewall-cmd --list-all firewall-cmd --list-all Open the port if needed: Open the port if needed: firewall-cmd --zone=public --add-port=5432/tcp --permanent
firewall-cmd --reload firewall-cmd --zone=public --add-port=5432/tcp --permanent
firewall-cmd --reload Zookeeper Connection Issues Basic Connection Test Basic Connection Test Use telnet: Use telnet: telnet your-zookeeper-server 2181 telnet your-zookeeper-server 2181 Should show: "Connected to your-zookeeper-server" Should show: "Connected to your-zookeeper-server" Log Check Log Check View Zookeeper logs: View Zookeeper logs: tail -f /var/log/zookeeper/zookeeper.log tail -f /var/log/zookeeper/zookeeper.log Common issues:

Insufficient disk space
Low memory allocation
Improper cluster config Common issues:

Insufficient disk space
Low memory allocation
Improper cluster config Insufficient disk space
Low memory allocation
Improper cluster config Insufficient disk space Low memory allocation Improper cluster config Service Startup Issues Log Analysis Log Analysis Check main log file: Check main log file: tail -n 100 /opt/dolphinscheduler/logs/dolphinscheduler-api.log tail -n 100 /opt/dolphinscheduler/logs/dolphinscheduler-api.log Check other component logs: Check other component logs: /opt/dolphinscheduler/logs/
├── dolphinscheduler-alert-server.log
├── dolphinscheduler-api-server.log
├── dolphinscheduler-master-server.log
└── dolphinscheduler-worker-server.log /opt/dolphinscheduler/logs/
├── dolphinscheduler-alert-server.log
├── dolphinscheduler-api-server.log
├── dolphinscheduler-master-server.log
└── dolphinscheduler-worker-server.log Java Environment Check Java Environment Check Verify Java version: Verify Java version: java -version java -version - Requirement: JDK 1.8+ - Requirement: JDK 1.8+ Check JAVA_HOME: Check JAVA_HOME: echo $JAVA_HOME echo $JAVA_HOME Check memory settings: Check memory settings: jmap -heap <pid> jmap -heap <pid> Port Conflict Check Port Conflict Check Check port usage: Check port usage: netstat -tunlp | grep [port] netstat -tunlp | grep [port] Default ports:

Master Server: 5678
Worker Server: 1234
API Server: 12345 Default ports:

Master Server: 5678
Worker Server: 1234
API Server: 12345 Master Server: 5678
Worker Server: 1234
API Server: 12345 Master Server: 5678 Worker Server: 1234 API Server: 12345
