It's been a few weeks since I've done this, but while looking at my new stats, I saw one of my old Vue.js posts getting some activity: Reading Image Sizes and Dimensions with Vue.js. In that blog post, I showed how to take a user-selected file and check the file size and dimensions of an image. As I've been slowly going through my Vue.js posts and creating Aline.js versions, I thought this would be a perfect fit.

I'm not going to repeat everything from the previous entry, but let me recap the highlights.


  • Obviously, your client-side code can't go into the user's machine and read ad hoc files. What it can do is get information about a user selected file. This can be done with an input tag using type=file.
  • Immediately after selecting the file, your code has access to the file size.
  • To get the dimensions though, you need to do a bit of work. First, create a new Image object.
  • You need to set the source of the image to the contents of the file. This can be done by using a data URL.
  • Once the image is loaded (remember, images have an onload event), you can then check the dimensions.


Ok, so given the above, let's build a quick demo. First, the HTML. I'm just going to have the input field and a place to print out details about the image.


<div x-data="app">

    <input type="file" x-ref="myFile" x-on:change="selectedFile" accept="image/*"><br/>

    <template x-if="imageLoaded">
        <p>
        Image size is <span x-text="image.size"></span><br/>
        Image width and height is <span x-text="image.width"></span> / <span x-text="image.height"></span>
        </p>
  </template>
</div>


A few things to note here. Like Vue, we sometimes need to reach out to the DOM, and like Vue, this is done via refs. You can see my setting x-ref="myFile" to gain access to the input field directly. Also, note I'm using the change event. This will fire when the user selects a file. Now let's look at the code.


document.addEventListener('alpine:init', () => {
  Alpine.data('app', () => ({
        imageLoaded:false,
        image: {
            size:null,
            width:null,
            height:null
        },
        selectedFile() {
            this.imageLoaded = false;

            let file = this.$refs.myFile.files[0];
            if(!file || file.type.indexOf('image/') !== 0) return;

            this.image.size = file.size;

            let reader = new FileReader();
            reader.readAsDataURL(file);

            reader.onload = evt => {
                let img = new Image();
                img.onload = () => {
                    this.image.width = img.width;
                    this.image.height = img.height;
                    this.imageLoaded = true;
                }
                img.src = evt.target.result;
            }

            reader.onerror = evt => {
                console.error(evt);
            }

        }

    }))
});


My Alpine app has two main variables, imageLoaded and image. The only real logic is in selectedFile. This will use $refs to grab the input field and the selected image. I then use a FileReader object to read in the bits, set it to the image, and when onload is fired, I can update my variables to the front-end displays. Given this source image for example:



If I select it, I'll see this:


You can test this yourself using the CodePen below:



Ok, so as I did in the previous post, let's consider a simple example that adds validation. Specifically - a max file size, a max width, and a max height. The HTML is mostly the same except now I show an error on a validation failure:


<div x-data="app">

    <input type="file" x-ref="myFile" x-on:change="selectedFile" accept="image/*"><br/>

    <template x-if="imageError">
    <p class="imageError" x-text="imageError">
    </p>
    </template>
</div>


In the JavaScript, I added constants for my max values:


const MAX_SIZE = 100000;
const MAX_WIDTH = 500;
const MAX_HEIGHT = 300;


And here's the Alpine app itself:


document.addEventListener('alpine:init', () => {
    Alpine.data('app', () => ({
        imageError:'',
        image: {
            size:null,
            width:null,
            height:null
        },
        selectedFile() {
            this.imageError = '';

            let file = this.$refs.myFile.files[0];
            if(!file || file.type.indexOf('image/') !== 0) return;

            this.image.size = file.size;
            if(this.image.size > MAX_SIZE) {
                this.imageError = `The image file size (${this.image.size}) is too much (max is ${MAX_SIZE}).`;
                return;
            }

            let reader = new FileReader();
            reader.readAsDataURL(file);

            reader.onload = evt => {
                let img = new Image();

                img.onload = () => {
                    this.image.width = img.width;
                    this.image.height = img.height;

                    if(this.image.width > MAX_WIDTH) {
                        this.imageError = `The image width (${this.image.width}) is too much (max is ${MAX_WIDTH}).`;
                        return;
                    }
                    if(this.image.height > MAX_HEIGHT) {
                        this.imageError = `The image height (${this.image.height}) is too much (max is ${MAX_HEIGHT}).`;
                        return;
                    }

                }
                img.src = evt.target.result;
            }

            reader.onerror = evt => {
                console.error(evt);
            }
        }
    }))
});


For the most part, this is the same, with the only change being that now I check the various properties and set a new variable, imageError, when something fails validation. You can test this below:


I'll repeat myself, which my readers know I like to do, but the more I use Alpine, the more it just clicks with me.
