Deploying a Kubernetes Cluster on CentOS

by Vladislav BilayJune 7th, 2023
Read on Terminal Reader
Read this story w/o Javascript
tldt arrow

Too Long; Didn't Read

In this article, we will explore the steps needed to deploy Kubernetes on CentOS. We will install container runtime, install Kubernetes on CentOS, create Kubernetes Cluster, and connect Worker nodes to the cluster.
featured image - Deploying a Kubernetes Cluster on CentOS
Vladislav Bilay HackerNoon profile picture

This article outlines a comprehensive procedure for deploying a Kubernetes cluster on CentOS, focusing on installing container runtime, configuring Kubernetes, creating the cluster, and connecting worker nodes. Kubernetes is an open-source system for automating the deployment, scaling, and management of containerized applications. The deployment process involves setting up necessary prerequisites, installing and configuring software components, and ensuring proper network and system settings for seamless operation.


Kubernetes is a powerful orchestration tool for managing containerized applications across a cluster of nodes, providing high availability and scalability. This article presents a step-by-step guide to deploying a Kubernetes cluster on CentOS, detailing the installation of the container runtime (Containerd), configuring Kubernetes components, and establishing the cluster network.

Prerequisites:

  • At least 2 CentOS servers (in this example we will use 3 servers: 1 master node and 2 worker nodes).
  • User with sudo or root privileges on each server.

Step 1: Install Containerd on Master Node and each Worker Node.

For installing Kubernetes we need to have one of the container runtime services. We will use Containerd.

Containerd is a container runtime that manages the lifecycle of a container virtual machine. It is a process, which creates, starts, stops, and destroys containers. It is also can download container images from container registries, mount storage, and enable networking for a container.


There are no containerd package in the default CentOs repository and because of that, we need to add this package.

To add it we need to execute the following command.


sudo yum-config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo


After adding the containerd package to the repository we can install a containerd service using the “yum” package management tools.

For that, we will run the following command


sudo yum install -y yum-utils containerd.io && rm -I /etc/containerd/config.toml


where “yum-utils” — dependency for correct work containerd.

And after successful installation, we need to remove the auto-generated config file “config.toml”. This is necessary to avoid errors when starting Kubernetes in the feature.

For now, the containerd was successfully installed but it has not yet been launched. Also, we need to enable our service to autostart after a system reboot.

For that, we need to run the following command.


sudo systemctl enable containerd && sudo systemctl start containerd


After executing the previous command we will check that service is active and successfully running.
This command will show you the status of your service.


sudo systemctl status containerd



Step 2: Install and configure Kubernetes on Master Node and each Worker Node.

First of all, we need to add the Kubernetes package to the CentOs directory, because it is also absent in the default CentOS package.

For this, we create a new file (use Vim or Nano text editor) and add the following content to the file. In this example, we will use a Nanotext editor.

First of all install nano editor if it is not already installed and then create the file.


sudo yum install nano -y
sudo nano /etc/yum.repos.d/kubernetes.repo


Paste the following content to the file.


[kubernetes]
name=Kubernetes
baseurl=https://packages.cloud.google.com/yum/repos/kubernetes-el7-x86_64
enabled=1
gpgcheck=1
repo_gpgcheck=1
gpgkey=https://packages.cloud.google.com/yum/doc/yum-key.gpg https://packages.cloud.google.com/yum/doc/rpm-package-key.gpg


Where:


baseurl — URL from where the package manager pulls the Kubernetes packages.
enabled — Indicate that repository is enabled and can be used for package installations and updates.


gpgcheck — Indicate that the package manager will verify the GPG signatures of the packages.
repo_gpgcheck — Ensures that the repository is trusted and gpgkey should be checked.


gpgkey — URLs where the GPG keys are located.

Once pasted, press Ctrl+O, then Enter to save it. Then press Ctrl+X to exit.


After adding the Kubernetes package to the CentOs directory we can now install Kubernetes services.

For that, we need to execute the following command.


sudo yum install -y kubelet kubectl kubeadm


Where kubelet is needed for running and managing containers in the Kubernetes cluster. Kubectl needed to cooperate with a Kubernetes cluster. Kubeadm is needed for bootstrapping the new cluster.

After the execution command, you will see that all three services are successfully installed.



In the next step, we will change our VM's names. This is necessary for a convenient understanding of our hostname.

On Master Node we need to execute the following command:


sudo hostnamectl set-hostname master-node


On Worker Node-1 we need to execute the following command:


sudo hostnamectl set-hostname worker-node-1


On Worker Node-2 we need to execute the following command:


sudo hostnamectl set-hostname worker-node-2


Change your “hosts” file and add the IP address and your new hostname from previous commands to the end of the file.


sudo nano /etc/hosts



To be sure that nothing will interfere with the Kubernetes work, we need to disable the swap. Because Kubernetes will be managing a memory when running containers.


sudo sed -i '/swap/d' /etc/fstab
sudo swapoff -a


Also, we need to disable SELinux to avoid any potential conflicts or issues that may arise during the installation process.

For that execute the following commands.


sudo setenforce 0
sudo sed -i 's/^SELINUX=enforcing$/SELINUX=permissive/' /etc/selinux/config


Update iptables settings. To ensure proper network communication and routing for the Kubernetes cluster we need to update iptables settings.

For this, we need to create a “k8s.conf” file.


sudo nano /etc/sysctl.d/k8s.conf


Add to the file the following rows and save the file.


net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1


To apply this configuration run the following command.


sudo sysctl - system


After the previous command, we need to enable the br_netfilter kernel module so that the packets, that pass through the bridge, will be processed by iptables for filtering and port forwarding, and the Kubernetes pods across the cluster could communicate with each other.


echo '1' > /proc/sys/net/ipv4/ipforward


For persistent communication between virtual machines, pods, and containers, we need to add new firewall rules.

On Master Node:


sudo firewall-cmd --permanent --add-port=6443/tcp
sudo firewall-cmd --permanent --add-port=2379-2380/tcp
sudo firewall-cmd --permanent --add-port=10250/tcp
sudo firewall-cmd --permanent --add-port=10251/tcp
sudo firewall-cmd --permanent --add-port=10252/tcp
sudo firewall-cmd --permanent --add-port=10255/tcp
sudo firewall-cmd --reload



On each Worker Node:

sudo firewall-cmd --permanent --add-port=10251/tcp
sudo firewall-cmd --permanent --add-port=10255/tcp
sudo firewall-cmd --reload


Step 3: Deploy Kubernetes Cluster.

The first thing we have to do is initialize a cluster. On Master Node, execute the following command.


sudo kubeadm init --pod-network-cidr=192.168.0.0/16


Where “-- pod-network-cidr” defines the IP address range that is assigned to individual pods within the cluster.


In this tutorial, we use the Calico virtual network. If 192.168.0.0/16 is already in use within your network or you want to use a custom virtual network, you must select a different pod network CIDR, replacing 192.168.0.0/16 in the above command You can choose it on the official Kubernetes web site.


After executing the command we will see that our Kubernetes control plane has initialized successfully.



Also, we need to enable auto start service after rebooting and check the kubelet status to make sure that the service status is Active.


sudo systemctl enable kubelet && sudo systemctl status kubelet


For managing the Kubernetes cluster we need to create a folder to store Kubernetes configuration files, copy already generated (from the previous command) config file, and then change permissions.

For that, we need to execute the following commands.


mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config && sudo chown $(id -u):$(id -g) $HOME/.kube/config


Where:


mkdir — create new folder


cp — copy configuration file to the folder from the previous command.


chown $(id -u):$(id -g) — set the user and group ownership to the current user.


After adding the configuration file we need to set up the network pod. Pods in the cluster are connected via Pod Network.

For this scenario, we use the Calico pod network.

Use the following commands to download and install Calico Pod Network.


If you use a different virtual network, please change “https://raw.githubusercontent.com/projectcalico/calico/v3.25.1/manifests/calico.yaml -O” and “calico. yaml” in the second command to yours.


curl https://raw.githubusercontent.com/projectcalico/calico/v3.25.1/manifests/calico.yaml -O
sudo kubectl apply -f calico.yaml


After applying the configuration file from the previous command we can check the status of our node.

To verify the status of our node, we will run the following command on Master Node.


sudo kubectl get nodes



Also, let’s confirm that each service has a running status.


sudo kubectl get pods --all-namespaces



As we can see the status of our Master Node is Ready and all our services have running status.

Step 4: Join Worker Node to the Cluster.

We need to generate a join command.

To get it, execute the following command on Master Node.


sudo kubeadm token create --print-join-command



Run the generated join command on each worker node.


As we can see our Worker node is successfully connected. And we can check the status of our Worker node on the Master node.

For that, we need to execute the following command on the Master node.


sudo kubectl get nodes



That’s it, all Worker nodes are successfully connected and have Ready status.


Conclusion: This scenario, provides a detailed methodology for deploying a Kubernetes cluster on CentOS, from installing Containerd and Kubernetes to configuring network settings and joining worker nodes. Proper implementation of these steps ensures a robust and scalable Kubernetes environment.
