This tutorial will teach you how to use Python to build the transaction you need to send to the Uniswap Universal Router (UR) in order to buy or swap tokens. Since there is no better learning method than practising on an actual project, I will walk you through a simple one: buy some with 1 ETH. Ethereum UNI By the end of this tutorial, you will be able to create a transaction to buy some tokens from the latest Uniswap router with Python. Prerequisites This tutorial is intended for developers who are comfortable with Python and the basics of Ethereum (contract, ERC20, transactions, gas, …). Already knowing the library is recommended but not strictly mandatory for this tutorial. Being familiar with the previous routers or at least with the concept of would help but is not necessary. web3.py Uniswap automated market maker You will need the address of a RPC endpoint to request the blockchain. If you don’t have a direct access to a node, you can get a free one from several providers: , , or for examples. Infura QuickNode Alchemy At the moment of writing, the libraries we are going to use support Python 3.8 to 3.11, so be sure to have one of these versions installed on your computer, along with pip, the standard package manager. Libraries and Tools Here is the list of libraries and tools we are going to use in this tutorial. I’ll show you how to install and use them to achieve our goal. Python libraries Web3.py The primary library for Python developers who work with Ethereum compatible blockchains UR Codec The open source library that encodes and decodes the data sent to the Universal Router. Tools You don’t want to learn to swap tokens with actual ones. So you can use either a testnet like or a local fork created with Ganache which is the solution I’ll use in this tutorial. Sepolia CLI Ganache We’ll create a local fork of Ethereum at a given block number so you can get exactly the same results as me. and npm Node.js The JavaScript runtime environment used to run Ganache, and its package manager. Setup So, now that we have set the scene, let’s get our hands dirty! By the end of this section, you’ll have the tools and libraries installed and ready to use. You will also generate a private key which is mandatory to sign transactions. 1. Node.js and npm installation Go to the official and install Node.js accordingly to your OS. download page Installing Node.js should be rather straightforward, but here is a for Linux users. great installation guide At this point, you should be able to get something similar to: $ node -v
v18.16.0

$ npm version
{
  npm: '9.6.2',
  node: '18.16.0',
  ...
} 2. Ganache installation Once Node.js is installed, is as simple as: installing Ganache $ npm install ganache --global 3. Launching Ganache We’re going to launch Ganache and instruct it to locally fork Ethereum at block number "17365005". You can use whatever mined block you wish or the latest one (remove the option in this case), but using the same block number will allow you to get the same results as me. You will also need the address of your RPC endpoint. If you use Infura, that would be something like: https://mainnet.infura.io/v3/xxx where xxx is your API key. Mine is stored in the environment variable , so the command to launch Ganache would be: $RPC_ENDPOINT ganache --fork.url=$RPC_ENDPOINT --fork.blockNumber=17365005 4. Getting a private key from Ganache When Ganache starts, it outputs several useful information which should start with something similar to: As you can see, it generated 10 accounts (= 10 public/private key pairs) for you and fills them up with 1000 ETH! No need to rush to to contemplate your new wealth! 😂 These ethers are only on your local fork! Etherscan Keep one of the private key for later usage. I’ll keep this one: private_key = "0x6c9803151aa5cf420e98dd1afb9db96f0510918cb2249e9858519d47777125c9" Do use these private keys/accounts on Mainnet! Everyone could access your fund! not Also, if you see some tokens in these accounts on Mainnet (or in any account whose private key is on the web), try to get them: a sweeper bot will steal your gas! never 5. Local chain id and rpc endpoint The last part of what Ganache displayed at startup concerns the local chain id and the local rpc address. We’ll use them in our Python code. chain_id = 1337
rpc_endpoint = "http://127.0.0.1:8545" 3. Python libraries installation Now that Ganache is installed and running, let’s do what we, Python developers, love to do: stuff! 😆 pythonic 3.a. Python Virtual Environment And we start with a good practice which is to use . They are great to prevent dependency version conflicts, between all your projects and between them and your OS if it uses some Python. For those who are not familiar with virtual environments, here is a . Python virtual environments tutorial If you really don’t want to bother with using a virtual environment right now, you can skip this part and go directly to the next sub-section. First create a folder for your project and navigate into it. Then, creating a new virtual environment can be done with the following command: $ python3.9 -m venv venv_ur_tutorial Using Python 3.9, we used the built-in module (you could also use ) to create a virtual environment named “venv_ur_tutorial” that we can activate like this for Linux or Mac users: venv virtualenv $ source venv_ur_tutorial/bin/activate or for Windows users: venv_ur_tutorial/Scripts/activate.bat At this step, your virtual environment is activated. It means that what ever dependency you install from this terminal/environment will only be “visible” within it. 3.b. Dependency installation Now we’ll install the latest pip version and the blockchain libraries: $ pip install -U pip

$ pip install web3 uniswap-universal-router-decoder To check you have the correct dependency versions, use the following command: $ pip freeze It will display all installed packages in the virtual environment. Just check it outputs these ones: uniswap-universal-router-decoder==0.8.0
web3==6.4.0 That’s it for the installation! You have everything to continue to the most exciting parts: gathering the information needed for the swap and coding the transaction! Gather the information we need By the end of this section, you will have all the data needed to build a swap transaction. 1. From CoinGecko I’ll use the data aggregator CoinGecko, but you can use or whatever data provider you prefer. CMC A quick look on the gives us the following information: CoinGecko page for the Uniswap token The token is valued around 0.002715 ETH, so 1 ETH would be ~368 UNI Its address on Ethereum is 0x1f9840a85d5af5bf1d1762f925bdaddc4201f984 Its Etherscan link is https://etherscan.io/token/0x1f9840a85d5af5bf1d1762f925bdaddc4201f984 uni_address = Web3.to_checksum_address('0x1f9840a85d5af5bf1d1762f925bdaddc4201f984') Web3 works only with checksum address, so we convert the string into the correct format thanks to the Web3.to_checksum_address() 2. From Etherscan Follow the . Etherscan link It tells you the token number of decimals: 18 Now click on the “Contract” tab, scroll down and copy the contract ABI. uni_abi = '[{"inputs":[{"internalType":"address", ... ,"type":"function"}]' We’ll use it to request the UNI contract. For readability sake, I’ve truncated most of it. If you have a doubt, you can check the . full tutorial code 3. Amounts Using some of the information collected above, let’s calculate the amounts that will be swapped: ETH: In this project, we want to buy for 1 ETH of UNI. The Ethereum native coin is defined with 18 decimals. So the amount of ETH we want to pay (input in the swap) is: amount_in = 1 * 10**18 UNI: We saw that the current value for 1 ETH is about 368 UNI. This price is an aggregation from multiple sources and considering market fluctuations and a possible slippage (well, not really on our local fork, but that could be the case on Mainnet), let’s give a bit of room to the amount we’re happy to receive in order to be sure the swap is successful. Let’s say we don’t want to receive less than 365 UNI for our 1 ETH. The UNI token is also defined with 18 decimals. So the minimum amount of UNI we’re ready to receive out of the swap is: min_amount_out = 365 * 10**18 Path To find automatically the paths, more advanced developers can use the open source library Smart Path We need to instruct the Uniswap protocol on what tokens to swap. ETH is the native coin, but only tokens can be swapped, so we’ll use the which is . wrapped version WETH As an exercise, I let you find its address: weth_address = Web3.to_checksum_address('0xc02aaa39b223fe8d0a0e5c4f27ead9083c756cc2') The path is then simply the list formed by the address of the token we provide and the one we want: path = [weth_address, uni_address] This path is for a Uniswap V2 pool. V3 pools are slightly more complicated and are out of scope for this tutorial. V2 paths can be formed with 3 token addresses when there is no pool for the 2 tokens we swap, which is not the case here. 4. Universal Router Address and ABI Lastly, the is: UR address ur_address = Web3.to_checksum_address("0xEf1c6E67703c7BD7107eed8303Fbe6EC2554BF6B") and the is: UR contract ABI ur_abi = '[{"inputs":[{"components":[{"internalType": ... ,"type":"receive"}]' For readability sake, I’ve truncated most of it. If you have a doubt, you can check the . full tutorial code Coding a Transaction to Buy some UNI from the Uniswap Universal Router By the end of this section, you will know how to create and send a transaction to the UR with Python to buy some tokens. 1. Creating a Python script Now that we have the information we need, let’s put them together in a python file that we call . We’ll start by importing the libraries as follow: buy_token.py from uniswap_universal_router_decoder import FunctionRecipient, RouterCodec
from web3 import Account, Web3 “ ” is the class used to encode and decode the data sent to the UR. RouterCodec “ ” is an that will be used to tell UR functions who is the receiver. It is often either the router itself or the transaction’s sender. FunctionRecipient Enum “ ” is the class used to create an account and sign transactions. Account “ ” is the class used to interact with blockchains. Web3 Then we add the constants we have defined in the previous sections: from uniswap_universal_router_decoder import FunctionRecipient, RouterCodec
from web3 import Account, Web3

private_key = "0x6c9803151aa5cf420e98dd1afb9db96f0510918cb2249e9858519d47777125c9"

chain_id = 1337
rpc_endpoint = "http://127.0.0.1:8545"

uni_address = Web3.to_checksum_address('0x1f9840a85d5af5bf1d1762f925bdaddc4201f984')
uni_abi = '[{"inputs":[{"internalType":"address", ... ,"type":"function"}]'

amount_in = 1 * 10**18
min_amount_out = 365 * 10**18

weth_address = Web3.to_checksum_address('0xc02aaa39b223fe8d0a0e5c4f27ead9083c756cc2')

path = [weth_address, uni_address]

ur_address = Web3.to_checksum_address("0xEf1c6E67703c7BD7107eed8303Fbe6EC2554BF6B")
ur_abi = '[{"inputs":[{"components":[{"internalType": ... ,"type":"receive"}]' Be sure to replace the value of and with their correct value. If you’re not sure, have look into the . uni_abi ur_abi tutorial full code 2. Encoding the transaction input data The input data is the part of the transaction that will be executed by the UR smart contract, resulting in the actual swap. We’ll use the UR codec as follow: First we instantiate it: codec = RouterCodec() Then we use it to encode the input data: encoded_input = (
        codec
        .encode
        .chain()
        .wrap_eth(FunctionRecipient.ROUTER, amount_in)
        .v2_swap_exact_in(FunctionRecipient.SENDER, amount_in, min_amount_out, path, payer_is_sender=False)
        .build(codec.get_default_deadline())
) Ok, but what does it mean ?! What does it do ?! 3. Some explanations Let’s breakdown the command: : tells the codec we want to encode an input data (as opposed to decode). encode : the UR supports several commands chained in a single transaction. initialises the chaining for one or more sub-commands. chain() chain() : the first sub-commands. It asks the router to convert ETH into WETH. wrap_eth() amount_in : the router will receive the WETH converted by . FunctionRecipient.ROUTER wrap_eth() : Instruct the router to use a V2 pool with known input amount (1 WETH in this case). v2_swap_exact_in() : the transaction’s sender will receive the output of FunctionRecipient.SENDER (so the UNI tokens). v2_swap_exact_in() : The UNI received by will not come from the sender. This is because the corresponding UR function receives the WETH generated previously and kept by the router. payer_is_sender=False amount_in v2_swap_exact_in() : If the swap results in less that this amount of UNI, the transaction will be reverted. min_amount_out : the tokens involved in the swap. path : the timestamp after which the transaction will not be valid anymore. codec.get_default_deadline() : This method build and encode the transaction input data. build() 4. Build the transaction dictionary First we need a instance so we can interact with the blockchain: Web3 w3 = Web3(Web3.HTTPProvider(rpc_endpoint)) and a wallet/account using the private key: account = Account.from_key(private_key) And now we’re ready to create the transaction dictionary: trx_params = {
        "from": account.address,
        "to": ur_address,
        "gas": 500_000,
        "maxPriorityFeePerGas": w3.eth.max_priority_fee,
        "maxFeePerGas": 100 * 10**9,
        "type": '0x2',
        "chainId": chain_id,
        "value": amount_in,
        "nonce": w3.eth.get_transaction_count(account.address),
        "data": encoded_input,
} The code is pretty much self-explanatory here. is the maximum amount of gas you’re willing to pay. Everything not used will be refunded. Here is totally arbitrary. “gas” 500_000 : maximum gas price you’re willing to pay. Here 100 Gwei  is totally arbitrary. “maxFeePerGas” Out of scope here, but you may want to have a more subtle gas / maxPriorityFeePerGas / maxFeePerGas computation! : a counter used to distinguish transactions sent from the same account. “nonce“ : contain the previously computed. “data” encoded_input 5. Sign and send the transaction Signing and sending the transaction is as simple as: raw_transaction = w3.eth.account.sign_transaction(trx_params, account.key).rawTransaction
trx_hash = w3.eth.send_raw_transaction(raw_transaction) That’s it ! You have bought some UNI tokens with 1 ETH! Bonus: let’s check how many UNI we got We need first to create a Web3 instance of the UNI contract from its ABI and address: uni_contract = w3.eth.contract(address=uni_address, abi=uni_abi) and call it to get our UNI balance: uni_balance = uni_contract.functions.balanceOf(account.address).call()
print(uni_balance / 10**18) My result is: 368.41333521045374 If you made it up to here, congrats !!! You have learnt: how to set up a Ganache environment what Python libraries to use Encode, build and send a swap to the Uniswap Universal Router Closing words and disclaimer You can find the full code of this tutorial . here Now that you know the basics of the UR codec, you can continue to play with the other functions it supports. : I’m the of the . This open source library is a work in progress and does not support all UR functions yet. If you ever experience any issue with it, please open a ticket Disclaimer author and maintainer UR codec here
