As part of my personal development, I've created a personal health platform that uses various different microservices (Built using Azure Functions) that extract data from my Fitbit account and store them in an Azure Cosmos DB database. I have other microservices that pass messages between different services via Azure Service Bus. For this project, I use Azure DevOps to build my artifacts, run my unit tests and deploy my microservices to Azure. The great thing about DevOps is that we can do all of this within the YAML pipeline. Yes I said YAML. Honestly, I don't know what the fuss is all about 😂 In a previous post, I talked about how we can deploy NuGet packages to a private feed in Azure Artifacts using YAML pipelines. If you haven't read that post yet, you can check it out below! https://dev.to/willvelida/publishing-nuget-packages-to-a-private-azure-artifacts-feed-with-yaml-build-files-3bnb In this article, we will turn our attention to building and deploying C# Azure Functions using a single build file. What we'll cover We've got quite a bit to cover, so I'll break down my YAML file and talk about each stage in the following order: Triggering a Build 👷‍♂️👷‍♀️ Using User-Defined Variables in our pipelines 👨‍🔬👩‍🔬 Defining Stages 💻 Building our project 🔨 Running our tests 🧪 Getting code coverage 🧾 Producing a Build Artifact 🏠 Using Secrets from Key Vault 🔑 Deploying our Function to Azure ⚡ Running our build pipeline 🚀 Triggering a Build 👷‍♂️👷‍♀️ In our build pipelines, we can use triggers to run our pipelines. We can use different types of triggers, ranging from triggering a build when we push our code to a defined branch, to . scheduled triggers based on a CRON schedule For this project, I'm just triggering my build every time I push to the main branch. To do so, I define this in my YAML file like so: trigger:
  - main Now if I wanted to do this properly, we could define multiple branch names to trigger builds from like so: trigger:
  - feature/*
  - bugfix/* This would trigger the builds when we push code to either our feature or bugfix branch. When we raise Pull Requests in DevOps, we can create policies on our PR to only be eligible to merge back into our main branch provided that the build was successful. This helps us increase our confidence that the code we are merging (and deploying) is of high quality, particularly if we are running tests as part of our build pipeline. To enable build validation on your branch policies, check out this documentation Using User-Defined Variables in our pipelines 👨‍🔬👩‍🔬 We can use user-defined variables in our YAML files to use throughout our pipeline. Doing this gives us the benefit of re-using common values across various stages and tasks in our pipeline, and it allows us to track changes to them over time using version control. We can define variables within out file with the following scope: , making it available to all jobs in our pipeline. At the root level , making it available to a specific stage in our pipeline. At the stage level , making it available to a specific job in our pipeline. At the job level In my case, I'm going to be re-using these variables throughout my pipeline, so I'm defining them at the root level. variables:
  buildConfiguration: 'Release'
  vmImageName: 'vs2017-win2016'
  functionAppName: 'famyhealthfitbitbody'
  azureSubscription: '<azureSubscription-id-or-name>'
  workingDirectory: '$(System.DefaultWorkingDirectory)/MyHealth.Fitbit.Body'
  projectName: 'MyHealth.Fitbit.Body' We're not just limited to user-defined variables in YAML pipelines! We can use System and Environment variables as well. To learn more about defining variables in YAML pipelines, check out this article Defining Stages 💻 Within our YAML pipelines, we can organize our jobs into Stages. These divide our pipeline into logical....well, stages that perform certain tasks, such as 'build the app', 'deploy to production'. In this example, I just have a stage and deploy stage. Every YAML pipeline has at least one stage even if we don't define it. As I have done in my file, we can also run stages depending on whether the previous stage has succeeded or not, like so: stages:
  - stage: Build
    displayName: Build Stage

    jobs:
      - job: Build
        displayName: Build MyHealth.Fitbit.Body
        pool:
          vmImage: $(vmImageName) Using YAML pipelines, we can define multiple stages of our pipeline and store it as code. Check out the if you want to learn more about how Stages work in YAML pipelines. documentation Building our project 🔨 Let's turn our attention to our Function. First up, I want to restore and build my .csproj files. In our YAML pipelines, we can se .NET Core tasks to run dotnet commands against our artifacts. To build my project, I'll and . restore build I'm using a custom NuGet feed hosted on Azure Artifacts, so I will need to point to this feed when restoring. For the build task, I want to build a release package, so I'll pass in the variable as an argument when running the command. buildConfiguration build For both commands, I'm going to point to all .csproj files in my repository. steps:
- task: DotNetCoreCLI@2
  displayName: Restore
  inputs:
   command: 'restore'
   feedsToUse: 'select'
   vstsFeed: '<feed-id>'
   projects: '**/*.csproj'

- task: DotNetCoreCLI@2
  displayName: Build
  inputs:
   command: 'build'
   projects: '**/*.csproj'
   arguments: --configuration $(buildConfiguration) Running our tests 🧪 Alongside my function code, I have a project for my Unit Tests. As part of my build, I want to run my unit tests to make sure that my changes haven't broken any of our tests and that they still pass. If any of my tests fail, I want the build to fail. To run our tests, we can use a .NET Core task that runs the command and point the task at our Unit Test .csproj file. test I also want to collect code coverage metrics with Coverlet. Coverlet is .NET tool that allows us to get unit test coverage for line, branch and method coverage. In our arguments parameters, I'm telling my task to run Coverlet to get the code coverage and then publish the test results to the */TestResults/Coverage folder on my build agent: - task: DotNetCoreCLI@2
  displayName: Run Unit Tests
  inputs:
   command: 'test'
   projects: '**/*UnitTests/*.csproj'
   arguments: '--configuration $(buildConfiguration) /p:CollectCoverage=true /p:CoverletOutputFormat=cobertura /p:CoverletOutput=$(Build.SourcesDirectory)/TestResults/Coverage/'
   publishTestResults: true Getting code coverage 🧾 Once we've generated our coverage report, we can publish it to see the results. I've got two tasks within my pipeline to achieve this. First, I'm using a bash script task to install the report generator onto the Build agent. Once that's installed, I'm creating the xml report into my TestResults/Coverage folder on the agent. We can also specify the report type that we want to generate, but for this tutorial I'm just generating an inline HTML report. If you want to use a task for this instead of running an inline script, you can try installing the following onto your DevOps organisation. task Once we have generated a report, I've got a second task that publishes the code coverage report. - script: |
    dotnet tool install -g dotnet-reportgenerator-globaltool
    reportgenerator -reports:$(Build.SourcesDirectory)/TestResults/Coverage/coverage.cobertura.xml -targetdir:$(Build.SourcesDirectory)/CodeCoverage -reporttypes:HtmlInline_AzurePipelines;Cobertura
    displayName: Create Code coverage report

- task: PublishCodeCoverageResults@1
  displayName: 'Publish Code Coverage'
  inputs:
    codeCoverageTool: Cobertura
    summaryFileLocation: '$(Build.SourcesDirectory)/**/coverage.cobertura.xml'
    reportDirectory: '$(Build.SourcesDirectory)/TestResults/Coverage/' When our build finishes, we can review our code coverage report within DevOps! It should look similar to this: Producing a Build Artifact 🏠 We've built our project and our tests pass! We now need to produce a build artifact that we will deploy as our Function. Starting with publish, all we need here is a .NET Core task that runs the command, publishes our project as a 'Release' package, zip it and then publish it to our Artifact Staging Directory on our build agent. publish We then use a to publish an artifact called 'drop' into our staging directory. Publish Build Artifact task - task: DotNetCoreCLI@2
  displayName: Publish
  inputs:
    command: 'publish'
    publishWebProjects: false
    projects: '**/*.csproj'
    arguments: '--configuration $(buildConfiguration) --output $(build.artifactstagingdirectory)'
    zipAfterPublish: True

- task: PublishBuildArtifacts@1
  displayName: 'Publish Artifact'
  inputs:
    PathtoPublish: '$(build.artifactstagingdirectory)' Just a mini-recap before we move onto deployment. In our Build Stage we have: Built our .NET Projects Run our Unit Tests to ensure our build is a quality build Generate and publish a code test coverage report. Publish a build artifact to deploy to Azure. With that achieved, we are now ready to move onto our deployment stage! Deploying our Function Stage For our deployment stage, we'll need to create a new stage in our YAML file. In this case, I've added a and property to our Stage YAML block. In the YAML file, I'm saying that the 'Deploy' stage our 'Build' stage and that the 'Deploy' stage will only run on the condition that the 'Build' Stage has succeeded. condition dependsOn depends on - stage: Deploy
    displayName: 'Deploy MyHealth.Fitbit.Body'
    dependsOn: Build
    condition: succeeded()

    jobs:
      - deployment: Deploy
        displayName: Deploy MyHealth.Fitbit.Body
        environment: Production
        pool:
          vmImage: $(vmImageName) When we use multiple stages in a pipeline, they will run in the order that we define them in the YAML file. We can add dependencies to our stages using the parameter. dependsOn We can control which stages run by specifying the condition of that Stage. In my case, I'm stating that the 'Deploy' stage will only run provided that the 'Build' stage has run successfully. To learn more about how conditions work in YAML pipelines, check out the following . documentation Using Secrets from Key Vault 🔑 In my function, I'm doing performing a variety of tasks such as sending messages to Service Bus Queues and Topics, calling APIs using Access tokens etc. etc. In order to make these operations, I need to use connection strings and secrets that I'm storing in a Azure Key Vault. Because these are secrets and I don't want to expose them, I need to use a Azure Key Vault task within my pipeline. For this purpose, I can use the to download the secrets I need. Azure Key Vault task As a pre-requisite for this task, I need to create a that's linked to my Azure Subscription and I need a Key Vault that contains my secrets. Azure Resource Manager service connection Once I have this setup, I can use the following snippet in my pipeline: steps:
  - task: AzureKeyVault@1
    inputs:
      azureSubscription: '$(azureSubscription)'
      KeyVaultName: '<key-vault-name>'
      SecretsFilter: '*'
      RunAsPreJob: false Here, we are defining the subscription that contains our Key Vault with our secrets, and we are retrieving all of the secrets in our Key Vault. We could filter these out to use a comma-separated list of the secret names we want to download, but for now I'm just downloading everything. Deploying our Function to Azure ⚡ We're finally ready to deploy our Function! ⚡ For this I'm going to use a Azure App Service Deploy Task We can use this task to deploy a variety of different app service types, but in my YAML snippet, I'm specifying as our type. functionApp As a pre-req for this task, you'll need an App Service instance to deploy your code to. I'm also passing the package that we built earlier as our , using the variable for the name of our Function and then passing in key-values for our App Settings. I can pass in the secrets I need for my Function since we downloaded them in our Key Vault task. package $functionAppName - task: AzureRmWebAppDeployment@4
  displayName: 'Deploy Azure Function'
  inputs:
    azureSubscription: '$(azureSubscription)'
    appType: functionApp
    WebAppName: $(functionAppName)
    package: '$(Pipeline.Workspace)/drop/MyHealth.Fitbit.Body.zip'
    appSettings: '-FUNCTIONS_WORKER_RUNTIME "dotnet" -FUNCTIONS_EXTENSION_VERSION "~3" -KeyVaultName "<key-vault-name>" -AccessTokenName "<secret-name>" -ServiceBusConnectionString "$(<secret-value>)" -APPINSIGHTS_INSTRUMENTATIONKEY "<some-key>" -ExceptionQueue "myhealthexceptionqueue" -BodyTopic "myhealthbodytopic" -WEBSITE_TIME_ZONE "New Zealand Standard Time"'
    enableCustomDeployment: true
    RemoveAdditionalFilesFlag: true Our full YAML file Before we finish, here's my full YAML build pipeline: trigger:
  - main

variables:
  buildConfiguration: 'Release'
  vmImageName: 'vs2017-win2016'
  functionAppName: 'famyhealthfitbitbody'
  azureSubscription: '<azureSubscription-id-or-name>'
  workingDirectory: '$(System.DefaultWorkingDirectory)/MyHealth.Fitbit.Body'
  projectName: 'MyHealth.Fitbit.Body'

stages:
  - stage: Build
    displayName: Build Stage

    jobs:
      - job: Build
        displayName: Build MyHealth.Fitbit.Body
        pool:
          vmImage: $(vmImageName)

        steps:
          - task: DotNetCoreCLI@2
            displayName: Restore
            inputs:
              command: 'restore'
              feedsToUse: 'select'
              vstsFeed: '<artifact-feed-id>'
              projects: '**/*.csproj'

          - task: DotNetCoreCLI@2
            displayName: Build
            inputs:
              command: 'build'
              projects: '**/*.csproj'
              arguments: --configuration $(buildConfiguration)

          - task: DotNetCoreCLI@2
            displayName: Run Unit Tests
            inputs:
              command: 'test'
              projects: '**/*UnitTests/*.csproj'
              arguments: '--configuration $(buildConfiguration) /p:CollectCoverage=true /p:CoverletOutputFormat=cobertura /p:CoverletOutput=$(Build.SourcesDirectory)/TestResults/Coverage/'
              publishTestResults: true

          - script: |
              dotnet tool install -g dotnet-reportgenerator-globaltool
              reportgenerator -reports:$(Build.SourcesDirectory)/TestResults/Coverage/coverage.cobertura.xml -targetdir:$(Build.SourcesDirectory)/CodeCoverage -reporttypes:HtmlInline_AzurePipelines;Cobertura
            displayName: Create Code coverage report

          - task: PublishCodeCoverageResults@1
            displayName: 'Publish Code Coverage'
            inputs:
              codeCoverageTool: Cobertura
              summaryFileLocation: '$(Build.SourcesDirectory)/**/coverage.cobertura.xml'
              reportDirectory: '$(Build.SourcesDirectory)/TestResults/Coverage/'

          - task: DotNetCoreCLI@2
            displayName: Publish
            inputs:
              command: 'publish'
              publishWebProjects: false
              projects: '**/*.csproj'
              arguments: '--configuration $(buildConfiguration) --output $(build.artifactstagingdirectory)'
              zipAfterPublish: True

          - task: PublishBuildArtifacts@1
            displayName: 'Publish Artifact'
            inputs:
              PathtoPublish: '$(build.artifactstagingdirectory)'

  - stage: Deploy
    displayName: 'Deploy MyHealth.Fitbit.Body'
    dependsOn: Build
    condition: succeeded()

    jobs:
      - deployment: Deploy
        displayName: Deploy MyHealth.Fitbit.Body
        environment: Production
        pool:
          vmImage: $(vmImageName)

        strategy:
          runOnce:
            deploy:

              steps:
                - task: AzureKeyVault@1
                  inputs:
                    azureSubscription: '$(azureSubscription)'
                    KeyVaultName: '<key-vault-name>'
                    SecretsFilter: '*'
                    RunAsPreJob: false

                - task: AzureRmWebAppDeployment@4
                  displayName: 'Deploy Azure Function'
                  inputs:
                    azureSubscription: '$(azureSubscription)'
                    appType: functionApp
                    WebAppName: $(functionAppName)
                    package: '$(Pipeline.Workspace)/drop/MyHealth.Fitbit.Body.zip'
                    appSettings: '-FUNCTIONS_WORKER_RUNTIME "dotnet" -FUNCTIONS_EXTENSION_VERSION "~3" -KeyVaultName "<key-vault-name>" -AccessTokenName "<secret-name>" -ServiceBusConnectionString "$(<secret-value>)" -APPINSIGHTS_INSTRUMENTATIONKEY "<some-key>" -ExceptionQueue "myhealthexceptionqueue" -BodyTopic "myhealthbodytopic" -WEBSITE_TIME_ZONE "New Zealand Standard Time"'
                    enableCustomDeployment: true
                    RemoveAdditionalFilesFlag: true Running our build pipeline 🚀 We've successfully created a build pipeline in YAML that will be triggered every time we push to our branch. We can view the status of our build in Azure DevOps, which looks like this: main As you can see at the bottom of the image, we can see the result of each stage within our pipeline. If a particular stage had failed, we could use this to re-run a particular stage instead of having to push our code again to . main Wrapping Up Multi-Stage Build pipelines are awesome for defining our build and release process all within the same file. By using source control, we can track changes to our build process over time. We can also do useful things like generate and publish code coverage reports, download secrets from key vault and deploy apps all within one file! Hopefully, you found this article useful! As always, if you have any questions, feel free to comment below or ask me on ! Twitter Happy Coding! 💻👨‍💻👩‍💻 Also published on: https://dev.to/willvelida/building-and-deploying-c-azure-functions-using-multi-stage-pipelines-in-azure-devops-3ne9
