Cairo is a practically-efficient Turing-complete STARK-friendly CPU architecture.

In this article, we introduce the CPU architecture of Cairo in terms of instruction structure and state transition, and provide some examples of instruction.

Instruction Structure

The word natively supported by Cairo CPU is a field element, where the field is some fixed finite field of characteristic P>2^63.

Each instruction will occupy 1 or 2 words. If an immediate value（[ap] = “12345678”）follows the instruction, the instruction will occupy 2 words, and the value will be stored in the second word. The first word of each instruction consists of the following elements:

• off_dst[ bit0…15]: destination address offset, representative value

  -2^{15} + ∑_{i = 0}^{15} b_i . 2^i ∈ [-2^{15}, 2^{15});




• off_op0[ bit16…31]: op0 address offset, representative value

-2^{15} + ∑_{i = 0}^{15} b_i . 2^i ∈ [-2^{15}, 2^{15});

• off_op1[ bit32…47]: op1 address offset, representative value

  -2^{15} + ∑_{i = 0}^{15} b_i . 2^i ∈ [-2^{15}, 2^{15});




• dst reg[ bit48]: Base register of destination address offset, ap or fp;




• op0 reg[ bit49]: Base register of op0 address offset, ap or fp;




• op1_src[ bit50…52]: address of op1,




  • Case: 000
    op1=m(op0+off_op1)




  • Case: 001

    op1=m(pc+off_op1)




  • Case: 010
    op1=m(fp+off_op1)




  • Case: 100

    op1=m(ap+off_op1)




• res_logic bit53…54]: computational logic




  • Case: 00
    res = op1




  • Case: 01
    res = op0 + op1




  • Case: 10
    res = op0 ∗ op1




• pc_update[ bit55…57]: the update logic of pc




  • Case: 000 // common
    next_pc = pc + instruction_size




  • Case: 001 // absolute jump
    next_pc = res




  • Case: 010 // relative jump
    next_pc = pc + res




  • Case: 100 // conditional relative jump
    next_pc = pc + op1 (or instruction_size if dst = 0)




• ap_update[ bit58…59]: the update logic of ap




  • Case: 00
    next_ap = ap (or ap+2 if opcode = 1)




  • Case: 01
    next_ap = ap + res




  • Case: 10
    next_ap = ap + 1




• opcode[ bit60…62]: opcode types




  • Case: 000 // jmp




  • Case: 001 // call




  • Case: 010 // ret




  • Case: 100 // assert

State Transition Comment

The state transition function represents a general state transition unit (because it contains the processing logic of all instruction types), and a calculation is usually decomposed into multiple continuously executed instructions.

Therefore, we need to:

1. ensure the content of the instruction and the validity of the states before and after the instruction is executed (e.g., passing a certain range check and state consistency check) and




2. ensure that the executed instruction is valid.

Transition Logic Comment

If the state before and after the instruction execution is consistent, the update of the state must be executed according to the following logic:

#Context: m(.).
    #Input state: (pc, ap, and fp).
    #Output state: (next_pc, next_ap, and next_fp).
    #Compute op0.
If op0_reg == 0: // Judge the basic register of op0 according to the flag value, 0 is ap,1 is fp, and obtain the value of op0.
        op0 = m(ap + off_{op0})
    else:
        op0 = m(fp + off_{op0})
    #Compute op1 and instruction_size.
    switch op1_src: // Obtain the value of op1
        case 0:
            instruction_size = 1 // op1 = m[[ap/fp + off_op0] +off_op1], with two-level imbedding at most.
            op1 = m(op0 + off_{op1})
        case 1:
            instruction_size = 2 // There exist(s) immediate number(s). The instruction size is 2 words.
            op1 = m(pc + off_{op1})//
            #If off_{op1} = 1, we have op1 = immediate_value. // For example,  [ap] = "12345678", op1 = "12345678"
        case 2:
            instruction_size = 1 // op1 = [fp + off_op1]
            op1 = m(fp + off_{op1})
        case 4:
            instruction_size = 1 // op1 = [ap +off_op1]
            op1 = m(ap + off_{op1})
        default:
            Undefined Behavior
    #Compute res.
    if pc_update == 4:  // jnz
        if res_logic == 0 && opcode == 0 && ap_update != 1: // Assign && jump && advanced ap
            res = Unused // Under conditional jump, the values of res_logic, opcode and ap_update flags can only be as shown above.The res variable will not be used on this occasion.
        else:
            Undefined Behavior
    else if pc_update = 0, 1 or 2:
        switch res_logic: // The computational logic of res is:
            case 0: res = op1
            case 1: res = op0 + op1
            case 2: res = op0 * op1
            default: Undefined Behavior
    else: Undefined Behavior
    # Compute dst.
    if dst_reg == 0:
        dst = m(ap + offdst)
    else:
        dst = m(fp + offdst)
    # Compute the new value of pc.
    switch pc_update:
        case 0: # The common case: [ap] = 1
            next_pc = pc + instruction_size
        case 1: # Absolute jump: jmp abs 123
            next_pc = res
        case 2: # Relative jump: jmp rel [ap - 1]
            next_pc = pc + res
        case 4: # Conditional relative jump (jnz): jmp rel [ap - 1] if [fp - 7] = 0
            next_pc =
                if dst == 0: pc + instruction_size // If dst = 0, then pc conducts ordinary updates; otherwise, it is similar to Case 2.
                else: pc + op1 // Under this circumstance, res is Unused, so pc directly conducts + op1, instead of + res.
        default: Undefined Behavior
    # Compute new value of ap and fp based on the opcode.
    if opcode == 1:
        # "Call" instruction.
        assert op0 == pc + instruction_size
        assert dst == fp
        # Update fp.
        next_fp = ap + 2 // [ap] saves the current fp value, [ap + 1] saves the pc after the call instruction; when the ret instruction is executed, it is convenient to reset fp to [ap], and then continue to execute subsequent instructions.
        # Update ap.
        switch ap_update:
            case 0: next_ap = ap + 2 // [ap] saves the value of fp, and [ap+1] saves the instruction address after the call instruction; thus, ap increases by 2.
        default: Undefined Behavior
    else if opcode is one of 0, 2, 4:
        # Update ap.
        switch ap_update:
            case 0: next_ap = ap // [fp + 1] = 5
            case 1: next_ap = ap + res // advanced ap  [ap] += 123
            case 2: next_ap = ap + 1 // normal  [fp + 1] = [ap]; ap++
            default: Undefined Behavior
        switch opcode: // Within the same function, the fp value remains unchanged.
            case 0:
                next_fp = fp
            case 2:
                # "ret" instruction.
                next_fp = dst // The ret instruction goes with the call instruction, and assert dst == fp.
            case 4:
                # "assert equal" instruction.
                assert res = dst
                next_fp = fp
    else: Undefined Behavior

Instruction Verification

As shown in Figure 1, one instruction consists of the following elements:

structure instruction :=
(off_dst : bitvec 16)
(off_op0 : bitvec 16)
(off_op1 : bitvec 16)
(flags : bitvec 15)

Where:

off_dst[ bit0…15], off_op0[ bit16…31], off_op1[ bit32…47] are in range

-2^{15} + ∑_{i = 0}^{15} b_i . 2^i ∈ [-2^{15}, 2^{15})

But in AIR, we convert them into the following form:

˜off∗ = off∗ + 2^15

(Where * represents one of dst, op0 and op1)

So the value range of ˜off∗ should be [0,2^16)

Therefore, for the coding of an instruction, we have:

Note: Instead of allocating 15 virtual columns with a length of NN to the 15-bit flags of the instruction, instead, we use one virtual column.

˜f_i=∑_{j=i}^{14} 2j−i⋅fj

With a length of 16N, which meets the following requirements:

1. ˜f_0 = ∑_{j=0}^{14} 2^{j-0}⋅f_j is a15-bit value




2. ˜f_15 = 0




3. ˜f_i −2˜f_{i+1} = ∑_{j=i}^{14} (2^{j−i}⋅f_j) − 2⋅∑_{j=i+1}^{14}(2^{j−i−1}⋅fj) =∑_{j=1}^{14}(2j−i⋅fj) − ∑{j=i+1}^{14}(2j−i⋅fj)=fi




Therefore, equation (1) can be written as:

inst = ˜off_dst + 2^16⋅˜off_op0 + 2^32⋅˜off_op1 + 2^48⋅˜f0 ∈ [0,263)（2）

Because the finite field’s characteristic P > 2^63, one instruction can only correspond to one valid field element.

Therefore, for the instruction itself, the following constraints should be met:

Instruction： inst= ˜off_dst + 2^16⋅˜off_op0 + 2^32⋅˜off_op1 + 2^48⋅˜f0

Bit： (˜f_i−2˜f_i +1)(˜f_i−2˜f_i+1 −1)=0 for all i ∈ [0,15)

Last value is zero: ˜f_15=0

Offset are in range: virtual column ˜off∗ ∈ [0,2^16), so then off∗ ∈ [2^−15, 2^15)

Instruction Examples

Assert Equal

The assert equal instruction can be expressed in the following syntax:

<left_handle_op> = <right_handle_op>

It ensures that both sides of the formula are equal; otherwise the execution of the program will be rejected.

The left side of the equation often comes from [fp+off_dst] or [ap+off_dst], and the right side has some possible forms(reg_0 and reg_1 can be fp or ap, ∘ can be addition or multiplication, and imm can be any fixed field elements):

• imm




• [reg1+offop1][reg1+offop1]




• [reg0+offop0]∘[reg1+offop1][reg0+offop0]∘[reg1+offop1]




• [reg0+offop0]∘imm[reg0+offop0]∘imm




• [[reg0+offop0+offop1][[reg0+offop0+offop1]




Note2: Division and subtraction can be expressed as multiplication and addition with different operand orders, respectively.

Anassert instruction can be considered as an assignment instruction, in which the value of one side is known, and the other side is unknown.

For example, [ap]=4[ap]=4 can be considered as an assertion that the value of [ap] is 4, or as an assignment setting [ap] to 4, according to the context.

Figure 4 shows some examples of “assert equal” instructions and the flag values for each instruction:

Interpret instruction [fp + 1] = 5:

• assert instruction => opcode = 4




• next_ap = ap => ap_update = 00 = 0




• next_pc = pc + instruction_size => pc_update = 000 = 0




• For op0 and op1, there is no add or mul => res_logic(res) = 00 = 0




• There exists an immediate value => op1_src(op1) = 001 = 1




• The immediate value address instructs that the addresses are adjacent => off_op1 = 1




• The left side of equation [fp + 1] => dst_reg(dst) = 1




• The left side of equation [fp + 1] => off_dst = 1




• op0_reg/ off_op0 => inital value(1/-1) //Because these flags are not used in this instruction, the default value is filled in.

Conditional and Unconditional Jump Comment

The jmp instruction allows changing the value of the program counter pc.

Cairo supports relative jump (its operand represents the offset from the current pcpc）and absolute jump - represented by keywords rel and abs respectively.

The jmp instruction may be conditional. For example, when the value of a memory unit is not 0, the jmp instruction will be triggered.

The syntax of the instruction is as follows:

#Unconditional jumps.
jmp abs <address>
jmp rel <offset>
#Conditional jumps.
jmp rel <offset> if <op> !

Figure 5 shows some examples of the jmp instructions and the corresponding flag values of each instruction:

Interpret instruction jmp rel [ap +1] + [fp - 7]:

• jmp instruction => opcode = 0




• next_ap = ap => ap_update = b00 = 0




• next_pc = pc + res=> pc_update = b010 = 2




• res = op0 + op1 => res_logic(res) = b01 = 1




• op1: [fp - 7] => op1_src(op1) = b010 = 2




• op1: [fp - 7] => off_op1 = -7




• op0: [ap + 1] => op0_src(op0) = 0




• op0: [ap + 1] => off_op0 = 1




• dst_reg/ off_dst => inital value(1/-1) ///Because these flags are not used in this instruction, the default value is filled in.

call and ret

The call and ret instructions allow the implementation of the function stack. The call instruction updates the program counter( pc )and frame pointer( fp )registers.

The update of the program counter is similar to the jmp instruction. The previous value of fp is written to [ap], to allow the ret instruction to reset the value of fp to the value before the call; similarly, the returned pcpc (the address of the instruction after the call instruction) is written to [ap+1], to allow the ret instruction to jump back and continue the execution of the code after the call instruction.

As two memory units were written, ap advanced by 2 and fp is set to the new ap.

The syntax of the instructions are as follows:

call abs <address>
call rel <offset>
ret

Figure 6 shows some examples of call and ret instructions and flag values corresponding to each instruction:

Interpret instruction call abs [fp + 4]:

• call instruction => opcode = 0




• next_ap = ap => ap_update = b00 = 0




• next_pc = res => pc_update = b001 = 1




• res = op1 => res_logic(res) = b00 = 0




• op1: [fp + 4] => op1_src(op1) = b010 = 2




• op1: [fp + 4] => off_op1 = 4




• op0_reg/ off_op0 => inital value(0/1) ///Because these flags are not used in this instruction, the default value is filled in.




• dst_reg/ off_dst => inital value(0/0) ///Because these flags are not used in this instruction, the default value is filled in.

Advancing ap

The instruction ap += <op> increments the value of ap by the given operand.

Comment

Figure 7 shows some examples of the advancing ap instructions and the corresponding flag values of each instruction:

Interpret instruction ap += 123:

• advancing ap instruction => opcode = 0




• next_ap = ap + res => ap_update = b01 = 1




• next_pc = pc + instruction_size => pc_update = b000 = 0




• res = op1 => res_logic(res) = b00 = 0




• op1 = 123 => op1_src(op1) = b001 = 1




• op1 = 123 => off_op1 = 1




• op0_reg/ off_op0 => inital value(1/-1) ///Because these flags are not used in this instruction, the default value is filled in.




• dst_reg/ off_dst => inital value(1/-1) ///Because these flags are not used in this instruction, the default value is filled in.
