Sometimes, you may find yourself in need of dealing with data. In simple words, this is data presented in nodes. Hierarchical Tree Form parent-child In such situations, you might struggle with the complexity of the implementation, especially when dealing with a large amount of data. In this article, I will provide you with one of the possible designs for such cases. However, you need to keep in mind that, as usual, having a generic design can offer abstracted capabilities, but it might lack specific enhancements for certain scenarios. Therefore, I recommend treating the design presented in this article as a mind opener. You should study it, learn from it, gain ideas from it, and ultimately adapt it to your own needs. Main Goals These are the main goals of this design: Represent Hierarchical data into a tree data structure. Have the capability of creating nodes in isolation. Have the capability of attaching and detaching nodes. Have the capability of searching nodes with an appropriate performance. Don’t lose the edge of strongly typed data. Therefore, while moving across our design, we need to keep in mind these requirements. The Design First, we need to keep in mind that the data itself could be any business entity. However, the Hierarchical structure is something else. This is the structure controlling the relation between nodes, how to add, how to remove, how to search,… and so on. Payload namespace HierarchicalData.Abstractions
{
    public abstract class Payload
    {
    }
} What we can notice here: This is the main entity representing the business entity to be wrapped into our Hierarchical structure. We didn’t add here any members but for sure you can add some if you think that this is common between all your business entities. NodeType namespace HierarchicalData.Abstractions
{
    public enum NodeType
    {
        Structural = 1,
        Leaf = 2
    }
} What we can notice here: This is an enum representing the type of the node. We have two node types only; and . Structural Leaf node is the node which only provides info about the Hierarchical structure. In simple words, it is like a folder or a node which would have child node(s). Structural node is the node which would only provide the business data. In simple words, it is the node that wraps the data and would not have any children. Leaf INode namespace HierarchicalData.Abstractions
{
    public interface INode
    {
        string Id { get; }
        string Name { get; }
        string PathPart { get; }
        NodeType Type { get; }
        IStructuralNode Parent { get; set; }
    }
} What we can notice here: This is the interface representing the common members of any node whether it is or . Structural Leaf is the unique identifier of the node. This should be absolute unique. I implemented it as a string but for sure you are free to change it as per your needs. Id is the name of the node. This should at some point be used for the presentation layer. Name is the name to be used to represent the path of the node. PathPart is the parent node. Its type is as it could not be a because . Parent IStructuralNode Leaf a Leaf would never have a child IStructuralNode using System.Collections.Generic;

namespace HierarchicalData.Abstractions
{
    public delegate void ChildNodeAddedEventHandler(object sender, IStructuralNode node, INode added);

    public delegate void ChildNodeRemovedEventHandler(object sender, IStructuralNode node, INode removed);

    public interface IStructuralNode : INode
    {
        event ChildNodeAddedEventHandler ChildNodeAdded;
        event ChildNodeRemovedEventHandler ChildNodeRemoved;

        IReadOnlyCollection<INode> Children { get; }
        new NodeType Type => NodeType.Structural;

        void AddChild(INode child);
        void RemoveChild(INode child);
        IReadOnlyDictionary<string, INode> GetFlatChildren();
    }
} What we can notice here: We defined the delegate to represent a handler of an event to be fired when a node is added as a child under another node. ChildNodeAddedEventHandler We also defined the delegate to represent a handler of an event to be fired when a node is removed from the children of another node. ChildNodeRemovedEventHandler We defined interface which extends . IStructuralNode INode It has the two events; and . ChildNodeAdded ChildNodeRemoved It has a read-only collection of children nodes. Its node type by default would be . Structural It has a method to add child. It has a method to remove child. It also has a method to return a flat collection of all nested child nodes. ILeafNode and ILeafNode<TPayload> namespace HierarchicalData.Abstractions
{
    public interface ILeafNode : INode
    {
        Payload Payload { get; }
        new NodeType Type => NodeType.Leaf;
    }

    public interface ILeafNode<out TPayload> : ILeafNode where TPayload : Payload
    {
        new TPayload Payload { get; }
    }
} What we can notice here: The is extending the . ILeafNode INode It has the property which returns the wrapped data of type . Payload Payload It hides the parent and defaults it to . Type Leaf The hides the parent and defines a typed one. ILeafNode<out TPayload> Payload Node using System.Linq;
using HierarchicalData.Abstractions;

namespace HierarchicalData.Implementations
{
    public abstract class Node : INode
    {
        protected Node(
            string id,
            string name,
            string pathPart,
            NodeType type,
            IStructuralNode parent)
        {
            Id = id;
            Name = name;
            PathPart = pathPart;
            Type = type;
            Parent = parent;
        }

        public string Id { get; }
        public string Name { get; }
        public string PathPart { get; }
        public NodeType Type { get; }
        public IStructuralNode Parent
        {
            get => m_Parent;
            set
            {
                if (m_Parent != value)
                {
                    if (value != null && value.Children.All(c => c.Id != Id))
                    {
                        value.AddChild(this);
                    }
                    else if (value == null)
                    {
                        m_Parent.RemoveChild(this);
                    }

                    m_Parent = value;
                }
            }
        }
    }
} What we can notice here: It implements . INode The implementation is simple. If you like, you can extend this to implement . IEquatable<Node> We also allow the user to set the directly through the property. However, the implementation is delegated to the and methods. Parent Parent AddChild RemoveChild LeafNode<TPayload> using HierarchicalData.Abstractions;

namespace HierarchicalData.Implementations
{
    public class LeafNode<TPayload> : Node, ILeafNode<TPayload> where TPayload : Payload
    {
        public LeafNode(
            string id,
            string name,
            string pathPart,
            IStructuralNode parent,
            TPayload payload) : base(id, name, pathPart, NodeType.Leaf, parent)
        {
            Payload = payload;
            parent?.AddChild(this);
        }

        Payload ILeafNode.Payload => Payload;

        public TPayload Payload { get; }
    }
} What we can notice here: It inherits from and implements . Node ILeafNode<TPayload> Worth to mention here is that in the constructor implementation, if a parent is set, we call the on the parent passing in . AddChild this StructuralNode using System.Collections.Generic;
using System.Linq;
using HierarchicalData.Abstractions;

namespace HierarchicalData.Implementations
{
    public class StructuralNode : Node, IStructuralNode
    {
        private readonly List<INode> m_Children;
        private readonly Dictionary<string, INode> m_Catalog;

        public event ChildNodeAddedEventHandler ChildNodeAdded;
        public event ChildNodeRemovedEventHandler ChildNodeRemoved;

        public StructuralNode(
            string id,
            string name,
            string pathPart,
            IStructuralNode parent = null,
            List<INode> children = null) : base(id, name, pathPart, NodeType.Structural, parent)
        {
            m_Children = new List<INode>();
            m_Catalog = new Dictionary<string, INode>();

            if (children != null && children.Any())
            {
                foreach (var child in children)
                {
                    AddChild(child);
                }
            }

            parent?.AddChild(this);
        }

        public IReadOnlyCollection<INode> Children => m_Children;

        public void AddChild(INode child)
        {
            if (child != null && Children.All(c => c.Id != child.Id))
            {
                child.Parent?.RemoveChild(child);

                m_Catalog.Add(child.Id, child);
                m_Children.Add(child);

                OnDirectChildNodeAdded(child);

                if (child.Type == NodeType.Structural && child is IStructuralNode structuralNode)
                {
                    foreach (var keyValuePair in structuralNode.GetFlatChildren())
                    {
                        m_Catalog.Add(keyValuePair.Key, keyValuePair.Value);
                        OnNestedChildNodeAdded(keyValuePair.Value.Parent, keyValuePair.Value);
                    }

                    structuralNode.ChildNodeAdded += AddHandler;
                    structuralNode.ChildNodeRemoved += RemoveHandler;
                }

                child.Parent = this;
            }
        }

        public void RemoveChild(INode child)
        {
            if (child != null && Children.Any(c => c.Id == child.Id))
            {
                m_Catalog.Remove(child.Id);
                m_Children.Remove(child);

                OnDirectChildNodeRemoved(child);

                if (child.Type == NodeType.Structural && child is IStructuralNode structuralNode)
                {
                    foreach (var keyValuePair in structuralNode.GetFlatChildren())
                    {
                        m_Catalog.Remove(keyValuePair.Key);
                        OnNestedChildNodeRemoved(keyValuePair.Value.Parent, keyValuePair.Value);
                    }

                    structuralNode.ChildNodeAdded -= AddHandler;
                    structuralNode.ChildNodeRemoved -= RemoveHandler;
                }

                child.Parent = null;
            }
        }

        public IReadOnlyDictionary<string, INode> GetFlatChildren()
        {
            return m_Catalog;
        }

        protected void OnDirectChildNodeAdded(INode added)
        {
            ChildNodeAdded?.Invoke(this, this, added);
        }

        protected void OnNestedChildNodeAdded(IStructuralNode node, INode added)
        {
            ChildNodeAdded?.Invoke(this, node, added);
        }

        protected void OnDirectChildNodeRemoved(INode removed)
        {
            ChildNodeRemoved?.Invoke(this, this, removed);
        }

        protected void OnNestedChildNodeRemoved(IStructuralNode node, INode removed)
        {
            ChildNodeRemoved?.Invoke(this, node, removed);
        }

        private void AddHandler(object sender, IStructuralNode node, INode added)
        {
            m_Catalog.Add(added.Id, added);
            OnNestedChildNodeAdded(node, added);
        }

        private void RemoveHandler(object sender, IStructuralNode node, INode removed)
        {
            m_Catalog.Remove(removed.Id);
            OnNestedChildNodeRemoved(node, removed);
        }
    }
} Before analyzing this code, we need to understand how it is going to work. As we said, nodes should be able to be created in isolation. This means that the end user should be able to create a node without setting any parent or even children. Then he should be able to attach this node as a child to another node. Also, he should be able to attach other nodes as children to the children of this node,… and so on. For all these actions, our code should keep the structure and relations between nodes intact. Also, we want to make it easy to search for nodes. A special case would be searching by Id. This should be as fast as we can. Therefore, keeping this in mind, let’s analyze the code. What we can notice here: In the constructor, if a collection of children is set, we call the method passing in each child of the children. AddChild Also, if a parent is set, we call the on the parent passing in . AddChild this To make it easy to search for a node, we defined . This is a catalog where we keep references to all the nodes -even the nested ones- below the current node. Dictionary<string, INode> m_Catalog To keep this catalog always synchronized, the current node subscribes to the and events of every direct child nodes at the moment they are added. ChildNodeAdded ChildNodeRemoved Following the same rule, the current node unsubscribes from the and events of every direct child nodes at the moment they are removed. ChildNodeAdded ChildNodeRemoved Also, we need to keep in mind that whenever a node is added to the current node as a direct child, this node might have other nested subtree. In this case, the current catalog must be updated with all the nested children of the subtree as well. So, having this said, let’s have a look on the implementation of . AddChild(INode child) makes sure that the new child is detached from its old parent before attaching it to the new parent which is the current node. child.Parent?.RemoveChild(child); adds the new child to the catalog. m_Catalog.Add(child.Id, child); adds the child to the collection. m_Children.Add(child); Children fires the event to notify the direct parent that a new child is added and eventually new updates should be applied to its catalog. OnDirectChildNodeAdded(child); ChildNodeAdded Then we check if the new child is a node because in this case we need to listen to the changes that could be applied to it. Structural So, if this is true, we loop on the new child’s flat children, add them one by one to the current catalog and also fire the event but this time with the proper values of and arguments. This is done to notify the direct parent with the nested updates as well. Note that the direct parent, would also do the same and notify its direct parent,… and so on. ChildNodeAdded node added As we said, the current node should subscribe to the and events of the new child so that it is always updated. This is what we do on and . ChildNodeAdded ChildNodeRemoved structuralNode.ChildNodeAdded += AddHandler; structuralNode.ChildNodeRemoved += RemoveHandler; sets the parent of the child node to the current node. child.Parent = this; Now, let’s have a look on the implementation of . RemoveChild(INode child) removes the child from the catalog. m_Catalog.Remove(child.Id); removes the child from the collection. m_Children.Remove(child); Children fires the event to notify the direct parent that a child is removed and eventually new updates should be applied to its catalog. OnDirectChildNodeRemoved(child); ChildNodeRemoved Then we check if the new child is a node because in this case we need to listen to the changes that could be applied to it. Structural So, if this is true, we loop on the child’s flat children, remove them one by one from the current catalog and also fire the event but this time with the proper values of and arguments. This is done to notify the direct parent with the nested updates as well. Note that the direct parent, would also do the same and notify its direct parent,… and so on. ChildNodeRemoved node added As we said, the current node should unsubscribe from the and events of the child to be removed. This is what we do on and . ChildNodeAdded ChildNodeRemoved structuralNode.ChildNodeAdded -= AddHandler; structuralNode.ChildNodeRemoved -= RemoveHandler; resets the parent to null. child.Parent = null; I know that this part was tricky, but, if you just go through it again, you will find it not that complicated. TreeNavigator using System;
using System.Collections.Generic;
using System.Linq;
using HierarchicalData.Abstractions;

namespace HierarchicalData.Implementations
{
    public class TreeNavigator
    {
        public string[] GetNodeFullPath(INode node)
        {
            var result = new List<string> { node.PathPart };

            var parent = node.Parent;

            while (parent != null)
            {
                result.Insert(0, parent.PathPart);
                parent = parent.Parent;
            }

            return result.ToArray();
        }

        public INode SearchById(IStructuralNode root, string id)
        {
            if (root?.GetFlatChildren().ContainsKey(id) ?? false)
            {
                return root.GetFlatChildren()[id];
            }

            return null;
        }

        public IList<INode> Search(IStructuralNode root, Func<INode, bool> predicate)
        {
            var flat = root?.GetFlatChildren();

            if (flat != null)
            {
                return flat
                       .Where(entry => predicate(entry.Value))
                       .Select(entry => entry.Value)
                       .ToList();
            }

            return new List<INode>();
        }

        public int FindNodeDepth(IStructuralNode root, INode node)
        {
            var foundNode = SearchById(root, node.Id);

            if (foundNode != null)
            {
                var depth = 0;
                var parent = node.Parent;

                while (parent != null)
                {
                    depth++;

                    if (parent.Id == root.Id)
                    {
                        break;
                    }

                    parent = parent.Parent;
                }

                return depth;
            }

            return 0;
        }
    }
} This is like a class which provides extra capabilities like searching the nodes, evaluating full paths, finding node depth,… and so on. Helper Internally, it is making a good use of the well defined and established structure we defined on our nodes classes. I didn’t abstract this class but for sure you can do so and you can extend it with as many capabilities as you need. Final Words I was going to write a sample application to show you how efficient our design is, but, after a second thought, I decided to leave this to you as an exercise. So, I know that when you look at this design you might feel that it is too hard to understand. However, you need to keep in mind how complex the job is in the first place. As I said at the beginning, you need to use the design in this article as a mind opener, give it some thought, learn from it, drop what you don’t need, adapt it, enhance it, and finally start using it. This would always be the right way to learn and gain new skills. That’s it, hope you found reading this article as interesting as I found writing it. Also published . here

The code in this story is for educational purposes. The readers are solely responsible for whatever they build with it.
