Hydrais in the Database Technology Industry

Hydra

hydra

In my last post I wrote about the first session of from two weeks ago. The twitch stream was an all day event where the first half of the day consisted of a variety of workshops around creative coding topics, while the second half featured performances from various audio visualization artists and creative coders. Unfortunately I could not attend all the events, but I wanted to write in detail about both the Hydra event and P5JS event. You can . Now let’s dive into some live coding visuals! SpacyCloud’s Live Twitch stream read the P5JS post here The Hydra tutorial on SpacyCloud was taught by Zach Krall, a graduate student at Parsons School of Design with an impressive portfolio of projects. Though I had been experimenting with creative coding since college and knew about , the language that P5JS was ported from, I had never heard of Hydra before. Just the fact that it was something new peaked my interest, but when I saw the home page for the I was pretty much sold. Every time you load Hydra, a different visualization appears on the screen, with the code that wrote to make it overlaid on top. You can copy and paste the code, so in a way each new visualization is like its own mini tutorial. Processing Hydra-editor Zach Krall’s personal website It turns out that all of the coding for Hydra happens in the browser, and the background of the entire browser window changes to display the product of your code. Personally I prefer this over the two panel system that most web coding editors use, because when it comes to visualizations you want to be able to see them in as large a display as possible. However I could see some people not liking this, because the code is a bit harder to read, even though it does have a background color applied. Hydra was created by who wanted to build a visualization engine that took its inspiration from analog televisions. It did that and a lot more, because with Hydra you can connect to other machines and each output your own video stream that can then be modified by others. Olivia Jack Probably the hardest thing about starting out with Hydra is wrapping your head around some of the paradigms, which are pretty different from your typical application. In Hydra, you typically start with a basic visual preset or texture, like noise, voronoi, or oscillation. Check out these basic visuals below. Note that while these screenshots are static, within Hydra all of these are moving visualizations. A basic oscillation visualization is drawn to the browser with osc() A basic voronoi visualization is drawn to the browser with voronoi() A basic noise visualization is drawn to the browser with noise() You can also pass values into the function to change it. For example, if I write instead of just the gray matter gets much smaller, like specks of dust rather than blobs. If you pass the specks of dust will start moving around the screen MUCH more quickly. The same can be said for voronoi and oscillation. First number defines the density of shapes, the second defines the speed of movement. Be careful passing in large numbers for the speed, it can be quite painful on the eyeballs. noise(100) noise() noise(100, 100) In order to execute the code you need to hit on the keyboard. You might have noticed the code inside the screenshots include a second function chained on called . This function is basically telling the browser to output everything in front of it in the chain. If you remove nothing will render to the browser and you will only see a black page. Shift + Ctrl + Enter out() out() We’ve covered voronoi, noise, and oscillation. There’s one more basic render and that is . Drawing a shape in Hydra is simple enough. The number you pass into the function defines the number of sides for the polygon. So, is a triangle while is a rectangle, and so on. shape() shape() shape(3) shape(4) You can also specify how large each shape is and how blurred its edges are by passing in 2 more numbers into the function. You might be wondering, what could one possibly do with a simple shape in the middle of the screen? That is hardly interesting to look at. I also thought it was a little bit odd that you couldn’t place multiple shapes or define that border and size of the shape like you can do in most creative coding languages. However, I was pleasantly surprised after some experimenting, as hopefully you will be too. One of the easiest things to do is create a tile pattern with the shape. You can do this by chaining a function, where the numbers you pass into the function define how many times the shape is repeated. repeat() If you write like in the screenshot above, you get the shape repeating ten times both in the vertical and horizontal directions. If you write then you will have the shape repeat ten times in the horizontal direction, but not vertical. This function is one of the geometry functions, which you can . repeat(10,10) repeat(10) read more about in the documentation So how might you apply color to these shapes? If you were using voronoi, noise, or the other automatically generated textures, its very easy. You just chain a function where you pass 3 values corresponding to the amount of red, green, and blue. color() A pure red oscillating texture Because you cannot apply color directly to a shape, the workaround is to use a blending function with and applying color within the blending function. For example, you can blend the red oscillator above with the rectangular tiles in the other screenshot. shape() Now you can see the rectangles are overlaid on top of the oscillating red texture. There are multiple blending functions, and each one has a different effect. I won’t go into detail on all of them because this post is getting lengthy and I am wary of the cognitive burden, Suffice it to say there are 6 blending functions in total, . The other 5 are add, diff, layer, mask, and mult. If you’ve ever experimented with layer effects in Photoshop, some of these should sound familiar. Depending on the complexity of your visualization, these operators will sometimes output the same result. You are most likely to notice differences when using a range of color and texture. called operators in the documentation Let’s take the our oscillator and jazz it up a bit. Rather than using the function to apply a simple red color, you can actually pass 3 values into the function directly. The first still specifies the number of oscillating rows, while the second specifies the speed they move across the screen, and the third specifies the range of color. Let's say we use the operator and also tweak our rectangles by making them a bit larger and blurrier. What might that look like? color() osc() diff() Now we’re cooking with gas. Just a few extra functions and things are much more interesting. There are many variables we can tweak to experiment even with this relatively simple visualization. For example, what happens if we change the oscillator to a voronoi or a noise generator? Alright, so it looks like we lost the cool colors but got a more interesting texture in return. Are there other ways to bring back color besides the ones I showed? Absolutely! The function which brings all sorts of psychedelic fun. It’s the last function I wanted to demonstrate because it can spice up pretty much any visualization, and is probably the quickest to get interesting results with. colorama() I hope by now you have the hydra-editor open in several tabs and have virtually lost interest in this post because you are too busy experimenting. Hydra is seriously one of the most absorbing and exciting creative coding tools I’ve had the pleasure of working with, and the goal of this post was to give you enough knowledge that you can hit the ground running. Of course there is tons of material I couldn’t cover, and for that I want to leave you with a few references: Hydra book is a very detailed guide that goes into pretty much every function Hydra has to offer, with lots of screenshots to help you along the way: https://naotohieda.com/blog/hydra-book/ Olivia Jack’s documentation is also nothing to shake a stick at, and has lots of coding examples that you can copy and paste to experiment with. There are also more Hydra tutorials listed here: https://github.com/ojack/hydra#Getting-Started The Github repo includes a section with a whole list of resources which you can check out here: https://github.com/ojack/hydra/blob/master/examples/README.md If its community you’re craving Hydra also has a facebook group with over 500 members: https://www.facebook.com/groups/1084288351771117 I hope you enjoyed getting your feet wet with live coding visuals. Good luck and happy creative coding! If you enjoyed this article, consider following me on Twitter @nadyaprimak or if you need more tips on breaking into the tech industry, you can read my book “Foot in the Door” in paperback or Kindle now. Previously published at https://www.nadyaprimak.com/blog/programming/getting-a-ui-developer-job/

Hydra Tutorial For Live Coding Visuals

The Hydra is a multi headed serpent from Greek mythology that can regrow any head that was cut off Vitalik Buterin recently made a massive series of where he described his line of thinking regarding Proof of Stake (POS). It was quite technical and filled with a bunch of jargon, and I doubt that the average person interested in cryptocurrencies can decipher a fifth of what he was talking about. The goal of this post is to explain in simple term where his logic falls apart and why POS doesn’t work. tweets As correctly pointed out, there are only three tweets ( ) in Vitalik’s tweet storm that is relevant to the POS discussion. I will summarize here for clarity purposes: Vitalik believes that by imposing 2 additional requirement to Ethereum clients, he can make POS work. The requirements are that “clients log on at least once every four month”, and that new clients download the blockchain “from some trusted source when you sync for the first time”. The 2 requirements are needed to prevent “long range attacks”. In this attack, an alternate blockchain which appears completely legitimate to a POS node is created in order to mislead the user. For those that want a better understanding of this attack, I’d suggest reading Ethereum’s POS FAQ sections on the and . Hugo Nguyen 9–11 nothing at stake problem weak subjectivity Vitalik believes that these 2 additional requirements, which do not exist in Proof of Work blockchains, are not a “big deal”. The purpose of this article is to explain why they are a big deal, by outlining exactly how governments seeking to destroy Ethereum will exploit this weakness. Yes, [we will not find a solution to political problems in cryptography,] but we can win a major battle in the arms race and gain a new territory of freedom for several years. Governments are good at cutting off the heads of a centrally controlled networks like Napster, but pure P2P networks like Gnutella and Tor seem to be holding their own. - Satoshi Nakamoto Satoshi states that governments are good at cutting off the heads of centrally controlled networks. But governments are also good at cutting off heads in a decentralized network. The State will happily play an endless game, where they spend multiple decades and billions/trillions of dollars, trying to cut off as many heads as they can. The war on drugs and the war on terror are good examples of this fact. Governments are generally terrible at killing the thing that they are fighting against but this does not stop them from trying. They can cut off a thousand heads but a robust system will just regrow a thousand new heads (i.e. put a drug dealer in jail and the market creates a new one). Think of a proper decentralized system as the mythical creature Hydra. The Hydra is a mythical many-headed serpent with the ability to regenerate any head that is cut off. A centralized system is just a snake; cut off 1 head and it is dead. To kill the Hydra, you must cut off all of its head, and prevent it from regenerating new heads. In order for a cryptocurrency to be like the Hydra, not only must it have many nodes, it must be easy to create new nodes to replace ones that have died. I will now explain the method that governments would take to attack a POS system, which is quite simple. Firstly, they will start cutting off heads by shutting down individual nodes (this can be done in many ways such as physical raids, DOS attacks, network censorship, etc..). Secondly, they will try compromising various trusted entities in the Ethereum space such as Vitalik, ethereum.org, and Joseph Lubin so that they are either silenced or forced to promote an alternate version of the Ethereum blockchain. And thirdly, they will try to create mass confusion by creating many fake Ethereum websites, social media accounts, and fake news that will lead users onto the alternate Ethereum blockchain. Now when a Ethereum users tries to replace the nodes that were shut down, they will find the task to be impossible because of the two requirements that Vitalik created. If the user has to start a node from scratch without any blockchain data, he cannot because his trusted source has been compromised and he has no way to tell which blockchain is the real one. The same applies to a user who was thrown into jail for 4 months and he has to restart his Ethereum node which is missing 4 months of blockchain data (if in the future, you receive a 4 month jail sentence for running an Ethereum node, you can blame Vitalik for choosing that duration). If new nodes cannot replace the ones that were killed, the system will eventually die. Ethereum has consistently made design decisions that hinders the ability of users to run full nodes so the 2 POS requirements are not unique in this regard (for further reading on this topic, see ). As Ethereum continues along this path, it will eventually be revealed that the system is just a Siamese snake not a Hydra; cut off all of its head and it will be dead because it cannot grow new ones. StopAndDecrypt’s article on the Ethereum blockchain size

Proof of Stake and Ethereum: Hydra or Siamese Snake?

Polkadot has allocated 2 million DOT tokens, equivalent to $14.4 million, to its leading DeFi project, Hydration. The funds are aimed at enhancing liquidity and trading efficiency on Hydration's single-sided liquidity provisioning platform, Omnipool. The allocation of the DOT tokens will be split into two parts. One million DOT will be used over the course of a year to attract new liquidity to the Polkadot ecosystem. Initial rewards for Liquidity Providers (LPs) are expected to exceed 200% APY, with various assets being incentivized, including native stablecoins, DOT, BTC, and several ecosystem coins. The single-sided LP design of the Hydration Omnipool allows users to start receiving rewards after providing a single asset and joining an incentives farm. The remaining one million DOT will be directly injected into the Hydration Omnipool to support the creation of a robust and accessible layer of native liquidity. This liquidity layer is intended to benefit the broader Polkadot 2.0 ecosystem over time, as outlined in Treasury Proposal #730. The capital injection adds to the existing 690k+ DOT (and 560k+ vDOT) already provided as liquidity in the Hydration Omnipool. While the funding is expected to drive significant advancements in liquidity provision and management within the Polkadot ecosystem, it is important to consider the potential implications and challenges that may arise from this initiative. Firstly, the injection of such a large amount of capital into a single DeFi project raises questions about centralization and the concentration of power within the ecosystem. The Polkadot community must ensure that the allocation of funds is transparent, fair, and aligns with the principles of decentralization. Secondly, the sustainability of the high initial rewards for LPs should be carefully evaluated. While attractive APYs can draw in new liquidity, it is essential to consider the long-term viability of these rewards and their potential impact on the overall health of the ecosystem. Moreover, the success of this initiative will depend on the adoption and utilization of the Hydration Omnipool by the Polkadot community. The platform will need to demonstrate its value proposition and attract a significant user base to justify the substantial investment from the Polkadot treasury. Despite these challenges, the allocation of funds to the Hydration project represents a significant step towards the growth and development of the DeFi ecosystem within Polkadot. The single-sided liquidity provisioning model offered by Hydration's Omnipool has the potential to revolutionize how liquidity is provided and managed within the shared blockchain network. As the DeFi space continues to evolve and mature, initiatives like this showcase the commitment of blockchain networks to foster innovation and support the growth of decentralized finance. However, it is crucial for the Polkadot community to actively monitor the progress of this initiative, ensure transparency, and work towards maintaining a balanced and decentralized ecosystem. Final Thoughts While the allocation of $14.4M to the Hydration project is a notable development for the Polkadot DeFi ecosystem, it is essential to approach it with cautious optimism. The success of this initiative will depend on various factors, including the effective utilization of funds, the adoption of the Hydration Omnipool, and the ability to maintain a decentralized and sustainable ecosystem. As the Polkadot network continues to evolve, it will be interesting to observe how this investment shapes the future of DeFi within its ecosystem. Don’t forget to like and share the story! Vested Interest Disclosure: This author is an independent contributor publishing via our business blogging program. HackerNoon has reviewed the report for quality, but the claims herein belong to the author. #DYOR. Polkadot has allocated 2 million DOT tokens, equivalent to $14.4 million, to its leading DeFi project, Hydration. The funds are aimed at enhancing liquidity and trading efficiency on Hydration's single-sided liquidity provisioning platform, Omnipool. The allocation of the DOT tokens will be split into two parts. One million DOT will be used over the course of a year to attract new liquidity to the Polkadot ecosystem. Initial rewards for Liquidity Providers (LPs) are expected to exceed 200% APY, with various assets being incentivized, including native stablecoins, DOT, BTC, and several ecosystem coins. The single-sided LP design of the Hydration Omnipool allows users to start receiving rewards after providing a single asset and joining an incentives farm. The remaining one million DOT will be directly injected into the Hydration Omnipool to support the creation of a robust and accessible layer of native liquidity. This liquidity layer is intended to benefit the broader Polkadot 2.0 ecosystem over time, as outlined in Treasury Proposal #730. The capital injection adds to the existing 690k+ DOT (and 560k+ vDOT) already provided as liquidity in the Hydration Omnipool. While the funding is expected to drive significant advancements in liquidity provision and management within the Polkadot ecosystem, it is important to consider the potential implications and challenges that may arise from this initiative. Firstly, the injection of such a large amount of capital into a single DeFi project raises questions about centralization and the concentration of power within the ecosystem. The Polkadot community must ensure that the allocation of funds is transparent, fair, and aligns with the principles of decentralization. Secondly, the sustainability of the high initial rewards for LPs should be carefully evaluated. While attractive APYs can draw in new liquidity, it is essential to consider the long-term viability of these rewards and their potential impact on the overall health of the ecosystem. Moreover, the success of this initiative will depend on the adoption and utilization of the Hydration Omnipool by the Polkadot community. The platform will need to demonstrate its value proposition and attract a significant user base to justify the substantial investment from the Polkadot treasury. Despite these challenges, the allocation of funds to the Hydration project represents a significant step towards the growth and development of the DeFi ecosystem within Polkadot. The single-sided liquidity provisioning model offered by Hydration's Omnipool has the potential to revolutionize how liquidity is provided and managed within the shared blockchain network. As the DeFi space continues to evolve and mature, initiatives like this showcase the commitment of blockchain networks to foster innovation and support the growth of decentralized finance. However, it is crucial for the Polkadot community to actively monitor the progress of this initiative, ensure transparency, and work towards maintaining a balanced and decentralized ecosystem. Final Thoughts While the allocation of $14.4M to the Hydration project is a notable development for the Polkadot DeFi ecosystem, it is essential to approach it with cautious optimism. The success of this initiative will depend on various factors, including the effective utilization of funds, the adoption of the Hydration Omnipool, and the ability to maintain a decentralized and sustainable ecosystem. As the Polkadot network continues to evolve, it will be interesting to observe how this investment shapes the future of DeFi within its ecosystem. Don’t forget to like and share the story! Vested Interest Disclosure: This author is an independent contributor publishing via our business blogging program. HackerNoon has reviewed the report for quality, but the claims herein belong to the author. #DYOR. Vested Interest Disclosure: This author is an independent contributor publishing via our business blogging program . HackerNoon has reviewed the report for quality, but the claims herein belong to the author. #DYOR. Vested Interest Disclosure: business blogging program business blogging program

Polkadot Allocates $14.4M to Support DeFi Growth through Hydration Project

পোলকাডট হাইড্রেশন প্রজেক্টের মাধ্যমে ডিফাই গ্রোথকে সমর্থন করার জন্য $14.4M বরাদ্দ করেছে

Polkadot stellt 14,4 Millionen US-Dollar zur Unterstützung des DeFi-Wachstums durch das Hydration-Projekt bereit

Polkadot asigna 14,4 millones de dólares para respaldar el crecimiento de DeFi a través de un proyecto de hidratación

Polkadot alloue 14,4 millions de dollars pour soutenir la croissance de DeFi grâce à un projet d'hydratation

पोलकाडॉट ने हाइड्रेशन प्रोजेक्ट के माध्यम से DeFi ग्रोथ का समर्थन करने के लिए $14.4M आवंटित किया

ポルカドット、ハイドレーションプロジェクトを通じてDeFiの成長を支援するために1440万ドルを割り当てる

Polkadot은 수화 프로젝트를 통해 DeFi 성장을 지원하기 위해 1,440만 달러를 할당합니다.

Polkadot aloca US$ 14,4 milhões para apoiar o crescimento do DeFi por meio do projeto de hidratação

Polkadot выделяет 14,4 миллиона долларов на поддержку роста DeFi посредством проекта Hydration

Polkadot, Hidrasyon Projesi Yoluyla DeFi Büyümesini Desteklemek İçin 14,4 Milyon Dolar Ayırdı

Polkadot phân bổ 14,4 triệu đô la để hỗ trợ tăng trưởng DeFi thông qua dự án hydrat hóa

Polkadot 通过 Hydration 项目拨款 1440 万美元支持 DeFi 增长

Scientific American Supplement, No. 365, December 30, 1882 by Various, is part of the HackerNoon Books Series. You can jump to any chapter in this book . RECENT HYDRAULIC EXPERIMENTS. here RECENT HYDRAULIC EXPERIMENTS. At a late meeting of the Institution of Civil Engineers, the paper read was on "Recent Hydraulic Experiments," by Major Allan Cunningham, R.E. This paper was mainly a general account of some extensive experiments on the flow of water in the Ganges Canal, lasting over four years—1874-79. Their principal object was to find a good mode of discharge measurements for large canals, and to test existing formulæ. There are about 50,000 velocity, and 600 surface-slope measurements, besides many special experiments. The Ganges Canal, from its great size, from the variety of its branches abounding in long straight reaches, and from the power of control over the water in it, was eminently suited for such experiments. An important feature was the great range of conditions, and, therefore, also of results obtained. Thus the chief work was done at thirteen sites in brickwork and in earth, some being rectangular and others trapezoidal, and varying from 193 ft. to 13 ft. in breadth, and from 11 ft. to 7 in. in depth, with surface-slopes from 480 to 24 per million, velocities from 7.7 ft. to 0.6 ft. per second, and discharges from 7,364 to 114 cubic feet per second. For all systematic velocity measurements, floats were exclusively used, viz., surface floats, double floats, and loaded rods. Their advantages and disadvantages had been fully discussed in the detailed treatise "Roorkee Hydraulic Experiments"—1881. They measured only "forward velocity," the practically useful part of the actual velocity. The motion of water, even when tranquil to the eye, was found to be technically "unsteady;" it was inferred that there is no definite velocity at any point, and that the velocity varies everywhere largely, both in direction and in magnitude. The average of, say, fifty forward velocity measurements at any one point was pretty constant, so that there must be probably average steady motion. Hence average forward velocity measurements would be the only ones of much practical use. To obtain these would be tedious and costly, and special arrangements would be required to obviate the effects of a change in the state of water, which often occurred in a long experiment, as when velocities at many points were wanted. As to surface-slope its measurement—from nearly 600 trials—was found to be such a delicate operation that the result would be of doubtful utility. This would affect the application of all formulas into which it entered. The water surface was ascertained, on the average of its oscillations, to be sensibly level across, not convex, as supposed by some writers. There were 565 sets of vertical velocity measurements combined into forty-six series. The forty-six average curves were all very flat and convex down stream—except near an irregular bank—and were approximately parabolas with horizontal axes; the data determined the parameters only very roughly; the maximum velocity line was usually below the service, and sank in a rectangular channel, from the center outward down to about mid-depth near the banks. Its depression seemed not to depend on the depth, slope, velocity, or wind; probably the air itself, being a continuous source of surface retardation, would permanently depress the maximum velocity, while wind failed to effect this, owing to its short duration. On any vertical the mid-depth velocity was greater than the mean, and the bed velocity was the least. The details showed that the mid-depth velocity was nearly as variable from instant to instant as any other, instead of being nearly constant, as suggested by the Mississippi experimenters. The measurement of the mean velocity past a vertical was thought to be of fundamental importance. Loaded rods seemed by far the best for both accuracy and convenience in depths under 15 ft. They should be immersed only 0.94 of the full depth. The chief objection to their use, that—from not dipping into the slack water near the bed—they moved too quickly, was thus for the first time removed. A double float with two similar sub-floats at depths of 0.211 and 0.789 of the full depth would also give this mean with more accuracy and convenience than any instrument of its class; this instrument is new. Measurement of the velocity at five eighths depth would also afford a fair approximation. One hundred and fourteen average transverse velocity curves were prepared from 714 separate curves. These average curves were all very flat, and were convex down stream—over a level or concave bed—and nearly symmetric in a symmetric section. The velocity was greatest near the center, or deepest channel, decreased very slowly at first toward both banks, more rapidly with approach to the banks or with shallowing of the depth, very rapidly close to the banks, and was very small at the edges, possibly zero. The figure of the curve was found to be determined by the figure of the bed, a convexity in the bed producing a concavity in the curve and , and more markedly in shallow than in deep water. Curves on the same transversal, at the same site, and with similar conditions, but differing in general velocity, were nearly parallel projections. At the edges there was a strong transverse surface flow from the edge toward mid-channel, decreasing rapidly with distance from the edge. The discussion showed that it was almost hopeless to seek the geometric figure of the curves from mere experiment. vice versa Five hundred and eighty-one cubic discharges were measured under very varied conditions. The process adopted contained three steps: (1) Sounding along about fifteen float courses, scattered across the site in eight cross sections; time, say four hours. (2) Measurement of the mean velocities through the full depths in those float courses, each thrice repeated; time, say four hours. (3) Computation, say two hours. This process was direct and wholly experimental; each step was done in a time which gave some chance of a constant state of water. From an extended comparison of all results under similar conditions, it appeared that the above process yielded, under favorable circumstances, results not likely to differ more than 5 per cent. The sequel showed that in a channel with variable regimen, a discharge table for a given site must be of at least double entry, as dependent on the local gauge-reading, and on the velocity or surface-slope. Special attention was paid to rapid approximations to mean sectional velocity. The mean velocity past the central vertical, the central surface velocity, and Chézy's quasi-velocity—i.e., 100 × √( R × S ) where R=the hydraulic mean depth, and S=surface slope—were tried in detail; thus 100, 76, and 83 average values thereof respectively were taken from 581, 313, and 363 detail values. The ratios of these three velocities to the mean velocity were taken out, and compared in detail with Bazin's and Cutter's coefficients. Other formulæ were contrasted also in slight detail. Kutter's alone seemed to be of general applicability; when the surface slope measurement is good, and the rugosity coefficient known for the site—both doubtful matters—it would probably give results within 7½ per cent. of error. Improvement in formulæ could at present be obtained only by increased complexity, and the tentative research would be excessively laborious. Now the first two ratios varied far less than the third; thus their use would probably involve less error than the third, or approximation would be more likely from direct velocity measurement than from any use of surface slope. The connection between velocities was probably a closer one than between velocity and slope; the former being perhaps only a geometric, and the latter a physical one. The mean velocity past the central vertical was recommended for use, as not being affected by wind; the reduction coefficient could at present only be found by special experiment for each site. Three current meters were tried for some time with a special lift, contrived to grip the meter firmly parallel to the current axis, so as to register only forward velocity, and with a nearly rigid gearing wire. No useful general results were obtained. Ninety specimens of silt were collected, but no connection could be traced between silt and velocity; it seemed that the silt at any point varied greatly from instant to instant, and that the quantity depended not on the mean velocity, but probably on the silt in the supply water. Forty measurements of the evaporation from the canal surface were made in a floating pan, during twenty five months. The average daily evaporation was only about 1/10 in. The smallness of this result seemed to be due to the coldness of the water—only 63 deg. in May, with 165 deg. in the sun and 105 deg. in shade. Lastly, it must suffice to say that great care was taken to insure accuracy in both fieldwork and computation. About HackerNoon Book Series: We bring you the most important technical, scientific, and insightful public domain books. This book is part of the public domain. Various (2006). Scientific American Supplement, No. 365, December 30, 1882. Urbana, Illinois: Project Gutenberg. Retrieved https://www.gutenberg.org/cache/epub/18763/pg18763-images.html This eBook is for the use of anyone anywhere at no cost and with almost no restrictions whatsoever. You may copy it, give it away or re-use it under the terms of the Project Gutenberg License included with this eBook or online at , located at . www.gutenberg.org https://www.gutenberg.org/policy/license.html

RECENT HYDRAULIC EXPERIMENTS

Scientific American Supplement, No. 799, April 25, 1891 by Various, is part of the HackerNoon Books Series. You can jump to any chapter in this book . THE POWER OF WATER, OR HYDRAULICS SIMPLIFIED. here THE POWER OF WATER, OR HYDRAULICS SIMPLIFIED. By G.D. Hiscox. CURRENT WHEELS FOR POWER AND RAISING WATER. The natural flow of water in a current is probably one of the oldest and cheapest of the methods for obtaining power, or the lifting of water within moderate elevations, for a supply for irrigation and domestic purposes; and we propose, apart from the current wheel, to treat only of self-water-raising devices in this chapter. Water wheels of various forms for this purpose have been used from time immemorial in Europe, Asia and Egypt, where the record gives examples of wheels of the noria class from 30 to 90 feet in diameter; the term having been applied to water wheels carrying buckets for raising water; the Spanish having buckets on an endless chain. noria noria Records of a Chinese noria, of 30 feet diameter, made of bamboo, show a lifting capacity of 300 tons of water per day to a height of ¾ of the diameter of the wheel—velocity of current not stated. For less quantity and greater elevation, these forms of wheel may have pumps attached to the shaft, by crank, that will give a fair duty for a high water supply. For power purposes, as in the plain current wheel, Fig. 23, there are two principal factors in the problem of power—the velocity of the current and the area of the buckets or blades. Their efficiency is very low, from 25 to 36 per cent., according to their lightness of make and form of buckets. A slightly curved plate iron bucket gives the highest efficiency, thus ( to the current, and an additional value may also be given by slightly shrouding the ends of the buckets. The relative velocity of the periphery of the wheel to the velocity of the current should be 50 per cent. with curved blades for best effect. The most useful and convenient sizes for power purposes are from 10 to 20 feet, and from 2 to 20 feet wide, although, as before stated, there is scarcely a limit under 100 feet diameter for special purposes. In designing this class of wheels special attention should be given to the concentration and increase of the velocity of the current by wing dams or by the narrowing of shallow streams; always bearing in mind that any increase in the velocity of the current is economy in increased power, as well as in the size and cost of a wheel for a given power. The blades in the smaller size wheels should be 1/4 of the radius in width, and for the larger sizes up to 20 feet, 1/5 to 1/6 of the radius in width and spaced equal to from 1/4 to 1/3 of the radius. They should be completely submerged at the lowest point. For obtaining the horse power of a current wheel, the formula is Area of 1 blade × velocity of the current in ft. per sec.
----------------------------------------------------------
                          400 × by the square of difference of velocities of current and wheel periphery = the horse power; or in which A equals the area of blade in square feet, V and v velocities of current and wheel periphery respectively, in feet per second. Thus, for example, a wheel 10 feet in diameter with blades 6 feet long and 1 foot in width, running in a stream of 5 feet per second—assuming the wheel to be giving as much power as will reduce its velocity to one half that of the stream—the figures will be horse power of the wheel. The total power of the stream due to the area of the blade equals the Square of the velocity of the stream
  ------------------------------------ ×
         Twice gravity (64.33) volume of water in cubic feet per second × 62.5 (weight of 1 C') = the value or gross effect in pounds falling 1 foot per second. This sum divided by 550 = horse power. Thus, as per last example, due to the area of the blades of the water wheel. For the efficiency of this class of wheel, with slightly curved and thin blades, divide the horse power of the wheel by the horse power of the current area, equals the percentage of efficiency. As in the last case, 0.468 /  1.32 = 0.35½ per cent. efficiency of the water wheel. With higher velocities of stream and wheel the efficiency will be from 2 to 3 per cent. less, although the horse power will increase nearly with the increase in velocity of the current. For details of application of various forms of current wheels for power purposes see illustrated description Yagn's and Roman's floating motors in SCIENTIFIC AMERICAN SUPPLEMENT, No. 463. A very good example of a floating motor of the propeller class is Nossian's fluviatile motor, illustrated and described in SCIENTIFIC AMERICAN SUPPLEMENT, No. 656. Fig. 24 represents a very complete floating motor, in which the floats are wedge shaped at the stem, for the purpose of increasing the current between them, the wheel being an ordinary current wheel, as shown in Fig. 23, with a curved shield or gate in front, which can be moved around the periphery of the wheel for the purpose of regulating its speed or stopping its motion by cutting off the stream from the buckets. The float, rising and falling with the stream, is held in position by a braced frame swinging on anchorages within the mill on shore, and parallel with a swiveled shaft. Tide wheels and tidal current wheels have been in use for more than 800 years, and were largely in use in Europe and the United States during the first half of the present century. No less than three were running in the immediate vicinity of New York, in 1840, for milling purposes. Their day seems to be past, except in some special localities. We will also pass them, and illustrate some of the SELF-ACTING WATER-RAISING DEVICES. The tympanum derives its name from its similarity to a drum as made by the Romans, but its origin was Egyptian. It is a current wheel with frame like Fig. 23, to the outside of which a set of chambers or tubes are fixed, radiating spirally, so as to lead the water to the shaft as the wheel revolves, as shown in Fig. 25. It has a lift of a little less than half its diameter, and answers an excellent purpose for the irrigation of rice and cranberry fields, or on streams running through low lands in arid districts. It is still one of the Nile irrigating wheels. The building of these wheels is within the scope of the carpenter and the tinsmith. A short wooden shaft made square or octagonal, as convenient, with gudgeons in the ends and arms of wood bolted across each of the sides of the shaft, or as shown in the cut, will form a frame work upon which a rim may be fastened, to which the blades and tubular buckets can be attached. The directions in regard to the current wheel, Fig. 23, may be followed as to number and form of blades, which must be made in length and width proportional to the velocity of the stream and the quantity of water to be lifted by each tubular arm. The tubes may be made of galvanized sheet iron and attached to the outside of the wheel, as shown in Fig. 25. THE NORIA OR BUCKET WHEEL. This is a simple current wheel with pot buckets, rigid or swinging, arranged on the rim of the wheel, to carry up and discharge the water nearly at the top of the wheel, and through the long ages that it has been in use for irrigation, village water supply, and even for private establishments, has assumed a variety of forms in detail of construction ranging from the bamboo wheels of the Chinese to the light iron wheels of modern construction. We illustrate the most simple of these forms in Figs. 26 and 27, in which the first is a series of boxes or chambers in the rim of the wheel with side openings in the forward part of the box as the wheel revolves, and a lip extending from the inner edge of the opening to direct the outflow into the trough. Another form, Fig. 27, is arranged with swing buckets or pots, pivoted just above their centers, and with the catch trough so fixed as to tip the buckets at the highest point, thus giving this wheel the greatest possible advantage as to height of discharge for a given diameter. The power value of these wheels for raising water is a matter of computation as nearly reliable as for other devices for the same purpose, when the velocity of the current is known at the point of contact with the blades. The horse power of the wheel may be computed as for the current wheel, Fig. 23, and, as the horse power is equal to 33,000 pounds raised one foot high per minute, we may assume a construction of wheel that will allow of discharging at 8 feet above the stream; then 33,000 / 8 = 4,125 pounds of water discharged at 8 feet elevation per horse power per minute. As the net power of the wheel in the last example, for Fig. 23, was 0.468 of a horse power, then 4,125 × 0.468 = 1,930 pounds of water raised 8 ft. per minute by the size of bucket and velocity of current in that case. From this a deduction of 20 per cent. should be made for loss by spill and imperfect construction, so that 1,500 pounds or 176 gallons per minute would be the probable output—over 253,000 gallons per day; or, for irrigating purposes, equal to a rainfall of over 1¼ inches in depth on 50 acres in one week. The proportion of capacity of the lifting buckets for such a wheel becomes of as great importance as its efficiency. If the buckets are too large, the wheel will stall, and if too small, the wheel will not give its full duty. For obtaining the approximate capacity of the lifting buckets, assuming the example as above computed, a 10 foot wheel with the velocity at periphery of 2½ feet per second is 150 feet per minute, or five revolutions per minute, nearly. Then 1,930 lb. per m. / 5 revolutions = 386 pounds water capacity for all of the buckets on the wheel. If such a wheel is constructed with 16 blades and 16 buckets, one between each blade, then 386 / 16 = 24 pounds for each bucket, or 38 / 100 of a cubic foot. The spill from this capacity of bucket being sufficient to compensate for the friction of the shaft journals. The lifting buckets of the noria class, Figs. 26 and 27, can be made of positive dimensions to suit the computations as above; but those of the tympanum class, Fig. 25, should be made of dimensions to conform with the required capacity at the moment of leaving the water, as the water at this point flows into the arm. ( .) To be continued About HackerNoon Book Series: We bring you the most important technical, scientific, and insightful public domain books. This book is part of the public domain. Various (2004). Scientific American Supplement, No. 799, April 25, 1891. Urbana, Illinois: Project Gutenberg. Retrieved https://www.gutenberg.org/cache/epub/11649/pg11649-images.html This eBook is for the use of anyone anywhere at no cost and with almost no restrictions whatsoever. You may copy it, give it away or re-use it under the terms of the Project Gutenberg License included with this eBook or online at , located at . www.gutenberg.org https://www.gutenberg.org/policy/license.html
