In this article, I’ll answer how to format a string as Base64 in CSharp. We’ll be exploring C# string format and base64 encoding and how they can be used together to produce meaningful results. I’ll cover the benefits and drawbacks of this approach and best practices for using it in your code! Understanding C# string format and base64 encoding is important because they are commonly used in software engineering, and knowledge of these concepts will allow you to write more efficient and effective code. By using examples, I’ll demonstrate how these concepts can be applied in real-life scenarios, making it easier for you to understand and apply them to your own work. Let’s dive into C# string format and base64 encoding! Overview of C# String Format C# string format is a powerful tool for manipulating strings in code. The format method allows you to insert variable values into a string in a way that is more flexible and readable than simple concatenation. Not only is this beneficial for displaying information to a user, but this can be helpful when formatting strings properly for programmatic consumption as well. Simple C# String Format Examples A basic example of string format looks like this: string name = "John";
int age = 30;
string message = string.Format("My name is {0} and I am {1} years old.", name, age); In this example, we pass the values of the ‘name’ and ‘age’ variables into the string using placeholders, indicated by the ‘{0}’ and ‘{1}’ symbols. The values are then “formatted” into the string when it is printed out. We are also able to use , which are generally significantly more performant. They’re arguably much more readable as well. interpolated strings to do formatting Here’s the same example but done with string interpolation: string name = "John";
int age = 30;
string message = $"My name is {name} and I am {age} years old."; As we discuss string formatting options, what is applicable for will be applicable for interpolated strings as well. So the format string that gets provided for each argument can be used in either scenario! string.Format() Example String Format Options String format provides a variety of options for formatting the values you pass into a string. For example, you can specify the number of decimal places, include leading zeros, or even format numbers as currency or percentage values. The most common formatting options include: , , …, – placeholders for arguments. {0} {1} {N} and – escape curly brackets. {{ }} – optional format specifier. {:formatString} When using the format specifier, you can modify the appearance of the final string. For instance, you might want to format a decimal value with a dollar sign and two decimal places like so: decimal price = 12.3m;
string message = string.Format("The price is {0:C2}.", price); In this example, the format specifier applies a currency format and rounds the value to two decimal places. The result would be “The price is $12.30.” :C2 By leveraging string format, you can create dynamic and highly readable strings in your C# code. With placeholders and format strings, you’ll be equipped to handle virtually any string output scenario. Overview of Base64 Encoding . This allows arbitrary data to be transmitted in channels that might otherwise not accept non-printable characters, such as email or HTML documents. The encoding process involves dividing the input into blocks of three bytes, then converting each 24-bit block into four 6-bit values. These values are then represented as characters from the Base64 alphabet. Base64 encoding is a method of converting binary data into a printable ASCII string format The benefits of using Base64 encoding are numerous. For one, Base64 allows binary data to be transferred as an ASCII string, making it easier to transfer data over text-based channels. Additionally, Base64 is a fairly efficient encoding method, using only 33% more space than the original binary format. Base64 encoding is also commonly used in encoding passwords, sending image data, and encrypting data. In these instances, the use of Base64 makes it possible to pass data in a way that is secure, readable, and easily processed by computers. Base64 encoding has become a standard, accepted method of representing binary data on the web. When you use Base64 encoding, the encoded output is a string. This string consists of ASCII characters that represent the binary data in a way that can be transmitted safely. While the encoded string can sometimes be difficult to read for humans, your computer can easily decode the string back into its original binary format when it receives it. Using C# String Format with Base64 Encoding Combining C# string format with Base64 encoding allows us to build strings with encoded data that can be decoded later when needed. Using this technique can be exceptionally useful when passing data between different parts of an application, or when exchanging data between different applications that need to share information. To encode a string with Base64, we use the Convert.ToBase64String method. This method accepts a byte array and returns a Base64 encoded string. When we want to combine Base64 encoding with C# string format, we substitute our original byte array with the encoded string. Base64 Encoding with String Format Example Here’s an example: string original = "This is my original string.";
byte[] bytes = Encoding.UTF8.GetBytes(original);
string encoded = Convert.ToBase64String(bytes);

string formatted = $"The original string was '{original}', and it's Base64 encoded representation is '{encoded}'.";

Console.WriteLine(formatted); In this example, we first create our original string. We then convert it to a byte array using the UTF8 Encoding class. With the byte array in hand, we encode it using the method to create our Base64 encoded string. Convert.ToBase64String Finally, we into a formatted string. When we call with this formatted string, we get the following output: use C# string interpolation to embed both the original and encoded strings Console.WriteLine The original string was 'This is my original string.', and it's Base64 encoded representation is 'VGhpcyBpcyBteSBvcmlnaW5hbCBzdHJpbmcu'. In this way, combining string interpolation or string format format with Base64 encoding can be a powerful tool for passing and sharing data in your application or across different applications. Decoding Base64 Encoded Strings Once you have a Base64 encoded string, you may need to decode it back into its original binary format. Fortunately, C# provides a variety of ways to perform this task. Using The Convert Static Class One way is to use the method, which accepts a Base64 encoded string as input and returns a byte array. Here’s an example: Convert.FromBase64String string encodedString = "VGhpcyBpcyBhIHRlc3Q=";
byte[] bytes = Convert.FromBase64String(encodedString);
string decodedString = Encoding.UTF8.GetString(bytes);
Console.WriteLine(decodedString); In this example, we start with our Base64 encoded string. We then use the Convert.FromBase64String method to convert the encoded string into a byte array. Finally, we use the Encoding.UTF8.GetString method to convert the byte array back into a string. Using CryptoStream To Decode Base64 Another way to decode Base64 encoded strings is to use the CryptoStream class in the System.Security.Cryptography namespace. This method provides additional security through encryption, and is useful in cases where secure transmission of data is important. Here’s an example: DESCryptoServiceProvider crypto = new DESCryptoServiceProvider();
string encodedString = "VGhpcyBpcyBhIHRlc3Q=";
byte[] bytes = Convert.FromBase64String(encodedString);

using MemoryStream memory = new MemoryStream(bytes);
using CryptoStream decryptor = new CryptoStream(
    memory,
    crypto.CreateDecryptor(),
    CryptoStreamMode.Read);
using StreamReader reader = new StreamReader(decryptor);

string decryptedString = reader.ReadToEnd();
Console.WriteLine(decryptedString); In this example, we first perform the same Base64 decoding with . Then we create a new MemoryStream, where the encrypted data will be written to. After that, we create a new instance of the DESCryptoServiceProvider class, which provides encryption and decryption services using a symmetric algorithm. Convert.FromBase64String With our CryptoStream set up, we decrypt our previously-Base64-encoded string and create a StreamReader object. We can now easily read and display the decrypted string using ! Console.WriteLine Benefits of C# String Format with Base64 Using C# string format with Base64 encoding provides a flexible solution for working with data in your application. One of the key benefits of this approach is that you can embed encoded data in your strings while maintaining the readability of those strings. This can be especially useful when building formatted log messages or generating emails with encoded attachments. Another advantage to using C# string format with Base64 encoding is that it allows you to embed binary data directly into your formatted strings. This can be a major improvement over alternate approaches which require breaking the binary data into smaller pieces or compressing the data before including it in the string. Drawbacks of C# String Format with Base64 As with all things, this approach does also carry some drawbacks. One of the main disadvantages is that it can be more time-consuming to encode and decode strings compared to simpler concatenation approaches. This can lead to longer execution times and may impact the performance of your application if used excessively or in the wrong hardware environment. Additionally, it’s important to keep in mind that the data can increase in size when we base64 encode. Because a byte can be 256 values, Base64 only accounts for 64 values. That means we need additional space so that we don’t lose resolution. Because this will be variable depending on the string, you can assume on average it will be roughly 33% more size used. . Check out this StackOverflow answer for more Now You Know How to Format a String as Base64 in CSharp! Understanding C# string formatting with Base64 can bring many benefits to your . By learning how to use these concepts together, you can create more efficient and effective solutions to many common programming challenges. programming and software development skills Throughout this article, we explored the basics of C# string format and Base64 encoding, how to use C# string format & string interpolation with Base64, and the benefits and drawbacks of this approach. Combining C# string format with Base64 encoding can allow you to more easily encode and decode strings, resulting in more efficient and secure software solutions. I hope that you found something useful in this article! If you’re interested in more learning opportunities, and ! subscribe to my free weekly newsletter check out my YouTube channel Also appears . here

A Beginner's Guide Formatting Strings as Base64 in CSharp

What is the problem? Async await syntax gives us the most straightforward way to write asynchronous code. However, such construction cannot be used in certain scenarios. For instance, using async await keywords is prohibited in constructors. There are many reasons why it is not possible in the existing language version. Probably, one of the obvious ones is that async methods would return or to be able to properly handle exceptions without crashing the process, and trivially to be able to wait until the async operation is completed. Task Task<T> And if we simply take the following class, build the library containing it, and then look at disassembled code. public class MyObject
{
    public MyObject()
    {
        //diligently initializing
    }
} We will see the following line. instance void [System.Runtime]System.Object::.ctor() where the keyword indicates that the method is an instance method, meaning it is called on an instance of the class, not on the class itself (which would be indicated by the static keyword). instance So, technically, it calls some method (constructor) on the already existing object to initialize it. Could it be made asynchronous hypothetically? public class MyObject
{
    public async MyObject()
    {
        await InitializeAsync();
    }
} Of course, yes, everything is possible in our world; it only depends on the price and whether it will solve any real problem without introducing new complications and tradeoffs. I believe that developers have had discussions about it many times, and they clearly understand the feasibility and meaningfulness of incorporating this change. C# language However, even without language in-built such a feature, we can solve this problem. Ways to overcome There are plenty of approaches that could be used to achieve the asynchronous initialization. Async to sync If we are only allowed to have sync operation in constructors, we can intuitively apply the approach. async to sync public class MyBestObject
{
    public MyBestObject()
    {
        InitializeAsync().GetAwaiter().GetResult();
    }

    private async Task InitializeAsync()
    {
        //diligently initializing

        await Task.Delay(100);
    }
} This approach is not so bad if there is no synchronization context in place and the async operation is relatively fast, but in general, it is not a recommended practice since it is based on a lot of assumptions about the executing environment and details of the async operation. It leads to inefficient resource consumption, sudden deadlocks in UI applications, and a common violation of the async programming idea of “async all the way.“ Async factory A quite standard way for solving this problem is to use factories. public class MyBestService
{
    public async Task InitializeAsync()
    {
        //diligently initializing

        await Task.Delay(100);
    }
}

public interface IMyBestServiceFactory
{
    Task<MyBestService> CreateAsync(CancellationToken cancellationToken);
}

public sealed class MyBestServiceFactory : IMyBestServiceFactory
{
    public MyBestServiceFactory()
    {
    }

    public async Task<MyBestService> CreateAsync(CancellationToken cancellationToken)
    {
        var service = new MyBestService();
        await service.InitializeAsync(cancellationToken);
        return service;
    }
} We could either use the static method in class or even specify a dedicated factory for that purpose. The second option is a little bit more compatible with the pattern since you can request in any class and then just call the method. MyBestService Dependency Injection IMyBestServiceFactory CreateAsync The main drawback of this approach is additional coupling since you (any class uses ) need to control the lifetime of a newly created object. IMyBestServiceFactory Additionally, it requires adapting solutions that use reflection ( ) or expressions ( ) to create and initialize instances. Activate.CreateInstace Expression.New Async initialization We could do the following trick to avoid problems with the pattern. Async Factory public class MyBestService
{
    private readonly Task _initializeTask;

    public MyBestService()
    {
        _initializeTask = InitializeAsync();
    }

    public async Task DoSomethingAsync()
    {
        await _initializeTask;

        // Do something async
    }

    private async Task InitializeAsync()
    {
        //diligently initializing

        await Task.Delay(100);
    }
} As you can see, we are beginning asynchronous initialization in the constructor and saving the reference to the started task. Then, before doing any meaningful operation, we check that is completed by simply awaiting it. _initializeTask The using of this approach is very usual both in cases with a self-instantiating way of objects and IoC container. var myBestService = new MyBestService();
await myBestService.DoSomethingAsync(); However, this approach has several drawbacks: Lack of control over the initialization process. For instance, we cannot simply pass . CancellationToken It gives the caller an incompletely instantiated object for a while. Although it does not seem a problem in general, it could lead to more complicated debugging if the initialization operation takes too long. Also, calling operation timeout might be less than the required amount of time for this particular object which apparently will lead to issues during the execution. Real example For applications to access Azure services like storage, key vault, or cognitive services, authenticating with Azure is mandatory, regardless of their deployment environment - on Azure, on-premises, or locally during development. There are several ways it could be achieved, and one of the most secure ones is utilising the approach with the class in .NET DefaultAzureCredential That’s what Microsoft says about it The class provided by the Azure SDK allows apps to use different authentication methods depending on the environment they're run in. This allows apps to be promoted from local development to test environments to production without code changes. You configure the appropriate authentication method for each environment and will automatically detect and use that authentication method. The use of should be preferred over manually coding conditional logic or feature flags to use different authentication methods in different environments. DefaultAzureCredential DefaultAzureCredential DefaultAzureCredential So, in order to securely store PII (Personally Identifiable Information) which can be either Full name, Phone Number, Credit card number, or Social security number, we would like to encrypt it before storing it somewhere and provide viewing original value with only limited access. One of the possible ways is to use AzureKeyVault API for encryption and decryption. Although there is no huge impact of creating every time, to reduce latency and improve efficiency, it is preferable to have a single instance of it for the whole application. DefaultAzureCredential So, to prepare for encryption and decryption API, we need to have the following lines CryptographyClient var tokenCredential = new DefaultAzureCredential();
var keyClient = new KeyClient(new Uri(_configuration.KeyVaultUri), tokenCredential);
KeyVaultKey key = await keyClient.GetKeyAsync(_configuration.KeyName);
_cryptographyClient = new CryptographyClient(key.Id, tokenCredential); To avoid running them on every request, we can utilise described above Async initialisation internal sealed class DefaultAzureVaultAdapter : IAzureVaultAdapter
{
    private readonly AzureVaultConfiguration _configuration;
    private EncryptionAlgorithm _encryptionAlgorithm = EncryptionAlgorithm.RsaOaep256;
    private CryptographyClient _cryptographyClient = null!;
    private Task _initializationTask = null!;

    public DefaultAzureVaultAdapter(AzureVaultConfiguration configuration)
    {
        _configuration = configuration;
        _initializationTask = InitializeAsync();
    }

    public async Task<string> EncryptAsync(string value, CancellationToken cancellationToken)
    {
        await _initializationTask;

        byte[] inputAsByteArray = Encoding.UTF8.GetBytes(value);

        EncryptResult encryptResult = await _cryptographyClient.EncryptAsync(_encryptionAlgorithm, inputAsByteArray, cancellationToken);

        return Convert.ToBase64String(encryptResult.Ciphertext);
    }

    public async Task<string> DecryptAsync(string value, CancellationToken cancellationToken)
    {
        await _initializationTask;

        byte[] inputAsByteArray = Convert.FromBase64String(value);

        DecryptResult decryptResult = await _cryptographyClient.DecryptAsync(_encryptionAlgorithm, inputAsByteArray, cancellationToken);

        return Encoding.Default.GetString(decryptResult.Plaintext);
    }

    private async Task InitializeAsync()
    {
        if (_cryptographyClient is not null)
            return;

        var tokenCredential = new DefaultAzureCredential();
        var keyClient = new KeyClient(new Uri(_configuration.KeyVaultUri), tokenCredential);
        KeyVaultKey key = await keyClient.GetKeyAsync(_configuration.KeyName);
        _cryptographyClient = new CryptographyClient(key.Id, tokenCredential);
    }
} And finally, register our with a singleton in IoC container. AzureVaultAdapter public static class ServiceCollectionExtensions
{
    public static IServiceCollection AddAzureVaultAdapter(this IServiceCollection services)
    {
        services.TryAddSingleton<IAzureVaultAdapter, DefaultAzureVaultAdapter>();
        return services;
    }
} Conclusion In this article, I covered several approaches for asynchronous object initialisation. Understanding requirements is the key to choosing the right approach. You can find the source code used to describe these patterns in this repository. https://github.com/alex-popov-stenn/CSharpAsyncInitPatterns/tree/main Thank you for reading! See you next time!

Asynchronous Initialization in C#: Overcoming Constructor Limitations

A couple of years ago, was all the rage, but it had one big issue: reactive stopped as soon as you accessed a SQL database. You had a nice reactive chain up to the database, defeating the whole purpose. Given the prevalence of SQL databases in existing and new apps, one couldn't enjoy the full benefits of Reactive Programming but still pay the full price of complexity. Reactive Programming Since then, the landscape has changed tremendously. Most importantly, it offers many reactive drivers over popular databases: PostgreSQL, MariaDB and MySQL, Microsoft SQL Server, Oracle, you name it! Even better, some frameworks provide a reactive API over them. Even though I'm not providing consulting services regularly, I wanted to keep up-to-date on accessing data reactively. In this post, I'll describe Hibernate Reactive, Spring Data R2DBC, and jOOQ in no particular order. The base application uses Project Reactor and its types - and . For an added twist, I use Kotlin (without coroutines). Most code snippets have unnecessary type hints for better understanding. Flux Mono The demo model I don't want a complicated demo model, but I don't want it to be too simple. I'll use a single many-to-many relationship and a field with : LocalDate Spring Data R2DBC As far as I remember, the Spring ecosystem was the first to offer a reactive database access API. At first, it was limited to H2 - not very useful in production. However, new reactive drivers were easy to integrate. Spring Data RDBC builds upon the widespread Spring Data JPA. The biggest difference is that there's a single required annotation for entities, . @Id Here's the code for the table: person data class Person(
    @Id val id: Long,
    val firstName: String,
    val lastName: String,
    val birthdate: LocalDate?,
    @Transient
    val addresses: MutableSet<Address> = mutableSetOf()
)

interface PersonRepository : ReactiveCrudRepository<Person, Long> R2DBC repositories look similar to regular Spring Data repositories with one big difference. They integrate Project Reactor's reactive types, and . Note that it's easy to use Kotlin's coroutines with an additional bridge dependency. Mono Flux Now comes the hard problem: mapping the many-to-many relationship with the . Address First, we must tell Spring Data R2DBC to use a specific constructor with an empty set of addresses. data class Person(
    @Id val id: Long,
    val firstName: String,
    val lastName: String,
    val birthdate: LocalDate?,
    @Transient
    val addresses: MutableSet<Address> = mutableSetOf()
) {
    @PersistenceCreator
    constructor(
        id: Long,
        firstName: String,
        lastName: String,
        birthdate: LocalDate? = null
    ) : this(id, firstName, lastName, birthdate, mutableSetOf())
} We also need to define the repository, as well as a query to list all addresses of a person: Address interface AddressRepository : ReactiveCrudRepository<Address, Long> {

    @Query("SELECT * FROM ADDRESS WHERE ID IN (SELECT ADDRESS_ID FROM PERSON_ADDRESS WHERE PERSON_ID = :id)")
    fun findAddressForPersonById(id: Long): Flux<Address>
} Now comes the least tasteful part: Spring Data R2DBC doesn't support many-to-many relationships at the moment. We need a hook that queries the addresses after loading a person. class PersonLoadOfficeListener(@Lazy private val repo: AddressRepository)   //1
  : AfterConvertCallback<Person> {

  override fun onAfterConvert(person: Person, table: SqlIdentifier) =
    repo.findAddressForPersonById(person.id)                                //2
      .mapNotNull {
          person.addresses.add(it)                                          //3
          person
      }.takeLast(1)                                                         //4
      .single(person)                                                       //5
} Annotate with to avoid running into circular dependencies exception during injection @Lazy Use the above query Add each address Reactive trick to wait for the last bit of data Turn into a single Person As far as I can understand, Spring Data R2DBC still needs to execute additional queries, thus leading to the (in)famous . N+1 query problem One configures database access via all available Spring alternatives: properties, YAML, Spring profiles, environment variables, etc. Here's a YAML example: spring.r2dbc:
  url: r2dbc:postgresql://localhost:5432/postgres?currentSchema=people
  username: postgres
  password: root Hibernate Reactive If you're familiar with regular Hibernate, you'll feel right at home with Hibernate Reactive. The mapping is the same in both cases: @Entity
@Table(name = "person", schema = "people")                           //1
class Person(
    @Id var id: Long?,
    @Column(name = "first_name")                                     //2
    var firstName: String?,
    @Column(name = "last_name")                                      //2
    var lastName: String?,
    var birthdate: LocalDate?,
    @ManyToMany
    @JoinTable(                                                      //3
        name = "person_address",
        schema = "people",
        joinColumns = [ JoinColumn(name = "person_id") ],
        inverseJoinColumns = [ JoinColumn(name = "address_id") ]
    )
    val addresses: MutableSet<Address> = mutableSetOf()
) {
    internal constructor() : this(null, null, null, null)            //4
} Define the table and the schema if necessary Define column names, if necessary Define the join column JPA requires a no-argument constructor We also need to configure the database. Hibernate Reactive uses the traditional XML-based JPA approach: <persistence xmlns="https://jakarta.ee/xml/ns/persistence"
           xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
           xsi:schemaLocation="https://jakarta.ee/xml/ns/persistence https://jakarta.ee/xml/ns/persistence/persistence_3_0.xsd"
           version="3.0">
  <persistence-unit name="postgresql">
    <provider>org.hibernate.reactive.provider.ReactivePersistenceProvider</provider>
    <properties>
      <property name="jakarta.persistence.jdbc.url" value="jdbc:postgresql://localhost:5432/postgres?currentSchema=people" />
      <property name="jakarta.persistence.jdbc.user" value="postgres" />
      <property name="jakarta.persistence.jdbc.password" value="root" />
      <property name="jakarta.persistence.schema-generation.database.action" value="validate" />
    </properties>
  </persistence-unit>
</persistence> The only difference so far from the regular Hibernate configuration Here's the source for the query itself: val emf = Persistence.createEntityManagerFactory("postgresql")                            //1
val sessionFactory: Mutiny.SessionFactory = emf.unwrap(Mutiny.SessionFactory::class.java) //2
val people: Mono<MutableList<Person>> = sessionFactory
        .withSession {
            it.createQuery<Person>("SELECT p FROM Person p LEFT JOIN FETCH p.addresses a").resultList
        }.convert().with(UniReactorConverters.toMono())                                   //3 Regular EntityManagerFactory Unwrap the underlying session factory implementation. Because we configured a in the , it's a ReactivePersistenceProvider persistence.xml Mutiny.SessionFactory Hibernate Reactive integrates with , but an extension allows to bridge to Project Reactor if wanted Vert.x Note that Hibernate Reactive is the only library among the three to return a instead of a . In layman's terms, it means you get the whole list at once instead of getting the elements one by one and being able to do something on each one individually. Mono<List<T>> Flux<T> jOOQ Reactive As for the two above frameworks, jOOQ Reactive is similar to its non-reactive version. You first generate the code from the database schema, then use it. <plugin>
    <groupId>org.jooq</groupId>
    <artifactId>jooq-codegen-maven</artifactId>
    <executions>
        <execution>
            <id>jooq-codegen</id>
            <phase>generate-sources</phase>
            <goals>
                <goal>generate</goal>
            </goals>
        </execution>
    </executions>
    <dependencies>
        <dependency>
            <groupId>org.postgresql</groupId>
            <artifactId>postgresql</artifactId>
            <version>42.6.0</version>
        </dependency>
    </dependencies>
    <configuration>
        <generator>
            <name>org.jooq.codegen.KotlinGenerator</name>
            <database>
                <inputSchema>people</inputSchema>
            </database>
            <target>
                <packageName>ch.frankel.blog.reactivedata.jooq</packageName>
            </target>
        </generator>
        <jdbc>
            <driver>org.postgresql.Driver</driver>
            <url>jdbc:postgresql://localhost:5432/postgres</url>
            <user>postgres</user>
            <password>root</password>
        </jdbc>
    </configuration>
</plugin> The version is defined in the parent Spring Boot Starter parent POM Set the necessary database driver(s). Note that one should use the driver non-reactive There's a Kotlin generator! Configure database configuration parameters Once you've generated the code, you can create your data class and design the query. jOOQ class hierarchy integrates with Java's collections, Java's Reactive Streams, and Project Reactor. The code may look complex if you're neither a SQL nor a jOOQ expert. Remember that variable types are unnecessary, but added for documentation purposes: fun findAll(): Flux<PersonWithAddresses> {                       //1
  val people: SelectJoinStep<Record5<Long?, String?, String?, LocalDate?, MutableList<Address>>> = //2
    ctx.select(
      PERSON.ID,
      PERSON.FIRST_NAME,
      PERSON.LAST_NAME,
      PERSON.BIRTHDATE,
      DSL.multiset(                                              //2
        DSL.select(
          PERSON_ADDRESS.ADDRESS_ID,
          PERSON_ADDRESS.address.FIRST_LINE,
          PERSON_ADDRESS.address.SECOND_LINE,
          PERSON_ADDRESS.address.ZIP,
          PERSON_ADDRESS.address.CITY,
          PERSON_ADDRESS.address.STATE,
          PERSON_ADDRESS.address.COUNTRY,
        ).from(PERSON_ADDRESS)
           .where(PERSON_ADDRESS.PERSON_ID.eq(PERSON.ID))
      ).convertFrom { it.map(addressMapper) }                   //3
  ).from(PERSON)
  return Flux.from(people)                                      //4
             .map(personWithAddressesMapper)                    //3
} Return a regular Project Reactor's Flux Use , see below. multiset Convert the row to an ordinary Java object via a function The magic happens here: wrap the regular query in a for is a Project Reactor Flux people Publisher Let's dive a bit into from the point of view of a non-jOOQ expert - me. Initially, I tried to execute a regular SQL query with results I tried to flatten with Project Reactor's API. I failed miserably because of my lack of knowledge of the API, but even if I had succeeded, it would have been the wrong approach. multiset After hours of research, I found via : multiset a post from Vlad Mihalcea The value constructor is one of jOOQ's and standard SQL's most powerful features. It allows for collecting the results of a into a single nested collection value with semantics. MULTISET non scalar subquery MULTISET -- MULTISET value constructor In the above query, we first select all addresses of a person, map each row to an object, and flatten them in a list on the same result row as the person. The second mapper maps the row, including the address list, to a dedicated person with an addresses list. I'm not a SQL master, so is hard at first glance. However, I confirm that it's a powerful feature indeed. multiset Note that . nested collections are fetched eagerly on a per-record basis, whereas top-level records are streamed reactively Conclusion We have browsed the surface of the main three reactive database access: Spring Data R2DBC, Hibernate, and jOOQ. So, which one should one choose? The main deciding factor is whether you already use one of their non-reactive flavors. Use the framework you're familiar with since both reactive and non-reactive usages are similar. I think that jOOQ is extremely powerful but requires a familiarity I currently lack. If you have complex queries that don't map easily to other approaches, it's the way to go. Besides that, I've no strong opinion, though I find Hibernate Reactive's configuration too limited by JPA and its return type puzzling. Mono<List<T>> Thanks for and for their reviews on their respective sections of expertise. Lukas Eder Mark Paluch The complete source code for this post can be found on . GitHub To go further: Hibernate Reactive Reference Documentation Integrating Hibernate Reactive with Spring jOOQ Reactive Fetching How to fetch multiple to-many relationships with jOOQ MULTISET How to Turn a List of Flat Elements into a Hierarchy in Java, SQL, or jOOQ Spring Data R2DBC Comment bien s'entendre avec avec Spring Data R2DBC... ou pas Originally at on July 9th, 2023 published A Java Geek

Reactive Programming - The New Way to Write Apps?

In this article, we’re going to discuss an alternative approach to handling the data access layer in TypeScript with and without ORM. MongoDB Traditionally, developers leverage Object-Relational Mapping (ORM) tools to map between data types in databases and object-oriented programming languages. However, ORM may sometimes lead to performance issues, complex configurations, or inflexibility to read/write data. To circumvent these challenges, we will utilize a method that employs for data validation and type inference, pattern for converting Entities to DTO (Data Transfer Objects), and encapsulating data logic within a Service class. zod companion object Why Schema Validation? Schema validation is a programming process that ensures data conforms to a predefined schema or structure. The schema serves as a blueprint or model that defines permitted data and its organization, often specified in terms of data types, constraints, and relationships. By enforcing schema validation, programs can catch data errors early, enhance data consistency, and prevent potential issues related to incorrect or malformed data. There are two common scenarios in which we need to apply schema validation: When handling input data, such as with API request payloads. In this context, schema validation can help ensure that the submitted data conforms to the expected format and structure. This is especially important for complex data sets that may contain a variety of different fields and data types. When performing read and write operations with a NoSQL database, such as MongoDB. In this context, schema validation can help ensure that the written data conforms to the expected schema, and can also validate retrieved data. This is especially important when data consistency is a concern, or when there are strict requirements for data quality and accuracy. This article is focusing primarily on the second scenario. Why Zod? is a TypeScript-first library designed for schema declaration and validation. It enables developers to construct schemas that validate runtime data and generate TypeScript types, ensuring type safety without additional manual type annotations. By integrating with TypeScript, enhances the language's static typing capabilities with runtime validation, offering features like custom error handling, nested schemas, and transformations. Zod zod Please note that although MongoDB has a “JSON Schema Validation” feature, some MongoDB API-compatible services like AWS DocumentDB do not support it. Furthermore, I believe that the application code should be conscious of and enforce all the data constraints it is operating with. Therefore, I would still prefer to have schema validation as part of the application code, and this is where can be helpful. zod Defining Entity with Zod Let’s consider an example where we’re working with users in a MongoDB database. We’ll start by defining an entity representing how a user is stored in the database. import { z } from "zod";
import { ObjectId } from "mongodb";

export const userEntitySchema = z.object({
  _id: z.instanceof(ObjectId),
  name: z.string(),
  email: z.string().email(),
});

export type UserEntity = z.infer<typeof userEntitySchema>; In the above code, we’re defining a and a type. The schema describes that a user entity has three fields: , , and . The type is inferred directly from the schema. userEntitySchema UserEntity _id name email UserEntity Defining Data Transfer Object (DTO) with Zod Next, we’ll define a DTO that represents how we’re going to use the user data in our application. export const userDTOSchema = z.object({
  id: z.string(),
  name: userEntitySchema.shape.name,
  email: userEntitySchema.shape.email,
});

export type UserDTO = z.infer<typeof userDTOSchema>; Here, we’ve defined a similar schema and type for , but notice that the field has been replaced with , while and are both using the shape from . UserDTO _id id name email userEntitySchema Applying the Companion Object Pattern To convert an entity to a DTO, we’ll apply the companion object pattern. This pattern involves creating a companion object to hold static functions related to the class or type. export const UserDTO = {
  convertFromEntity(entity: UserEntity): UserDTO {
    const candidate: UserDTO = {
      id: entity._id.toHexString(),
      name: entity.name,
      email: entity.email,
    };
    return userDTOSchema.parse(candidate);
  },
}; In the above code, we’ve defined an object called with one function: — this function can convert a object to a object. UserDTO convertFromEntity UserEntity UserDTO To explain it a bit more, TypeScript manages “types” and “concrete object definitions” in different namespaces, that’s why we could define a type as well as a concrete object called the same name. An object defined in this way usually has some util or helper functions that apply to the same-name type, thus it is so-called a “companion object”. UserDTO Please also note that we do not only guarantee the type safety on compile time but also ensure the runtime type safety via — which will make sure that the object meets the schema validation requirement. schema.parse() Encapsulating Data Logic in a Service Class Finally, we will encapsulate our data logic within a service class, which will handle all CRUD operations for the users. This service class will interact directly with MongoDB using the MongoDB Node.js driver. import { MongoClient, Db } from "mongodb";

export class UserService {
  private readonly db: Db;

  constructor(mongoClient: MongoClient) {
    this.db = mongoClient.db();
  }

  private getUsersCollection() {
    return this.db.collection<UserEntity>("users");
  }

  async findUser(id: string): Promise<UserDTO | null> {
    const entity = await this.getUsersCollection().findOne({ _id: new ObjectId(id) });
    return entity ? UserDTO.convertFromEntity(entity) : null;
  }

  async createUser(dto: Omit<UserDTO, "id">): Promise<UserDTO> {
    const candidate = userEntitySchema.parse({
      ...dto,
      _id: new ObjectId(),
    });
    const { insertedId } = await this.getUsersCollection().insertOne(candidate);
    return UserDTO.convertFromEntity({ ...dto, _id: insertedId });
  }

  async updateUser(id: string, dto: Omit<Partial<UserDTO>, "id">): Promise<UserDTO | null> {
    const candidate = userEntitySchema.partial().parse(dto);

    const { value } = await this.getUsersCollection().findOneAndUpdate(
      { _id: new ObjectId(id) },
      { $set: candidate },
      { returnDocument: "after" }
    );
    return value ? UserDTO.convertFromEntity(value) : null;
  }

  async deleteUser(id: string): Promise<void> {
    await this.getUsersCollection().deleteOne({ _id: new ObjectId(id) });
  }
} In this class, we implemented all CRUD operations for users: , , , and . All these methods interact with MongoDB directly through the MongoDB Node.js driver and handle conversions between and . UserService findUser createUser updateUser deleteUser UserEntity UserDTO Please note that this example may not represent real-world business data constraints, but rather an idea to encapsulate the data logic around . User Some people may prefer to enforce the Repository pattern and call it , making the class solely focused on CRUD operations without any business logic, then use inside the . For small to medium-sized projects, I would recommend to start with which should already efficiently fulfill the needs without too much overhead. UserRepository UserRepository UserService Service Bonus: out-of-box IDE support with IntelliSense By define types in the way we described in this blog, IDE will get us covered without need for extra library or plugin. For example, when we try to build query using , IDE or code editor knows what are the fields we can filer on: .findOne() Code snippet for idea verification Here we could have a simple code snippet to verify our idea: import _ from "lodash";

const main = async () => {
  const mongoClient = new MongoClient("mongodb://localhost:27017/data-access-example");

  try {
    await mongoClient.db().dropCollection("users");
  } catch (e) {
    if (_.get(e, "codeName") !== "NamespaceNotFound") {
      throw e;
    }
    console.log(`Collection "users" does not exist, no need to drop`);
  }

  await mongoClient.db().createCollection("users");

  const userService = new UserService(mongoClient);

  const createdUser = await userService.createUser({ name: "example", email: "example@example.com" });
  console.log({ createdUser });

  const updatedUser = await userService.updateUser(createdUser.id, { name: "exampleX" });
  console.log({ updatedUser });

  const foundUser = await userService.findUser(createdUser.id);
  console.log({ foundUser });

  await userService.deleteUser(createdUser.id);
};

main()
  .then(() => {
    process.exit();
  })
  .catch((e) => {
    console.error(e);
    process.exit(1);
  }); Conclusion In this blog post, we’ve discussed an alternative approach to handle the data access layer without ORM when using TypeScript and MongoDB. This method offers flexibility and eliminates potential bottlenecks associated with ORMs, while maintaining the consistency and clarity of our data layer. With the library for data validation and type inference, companion object pattern for conversion operations, and encapsulation within service classes, we're able to keep our code clear, concise, and highly functional. zod Also published here.

Handling ORM-Free Data Access Layer in TypeScript With MongoDB

While full homomorphic encryption (FHE) was originally achieved in 2009, it's starting to receive more attention now that computing power has caught up to its computational demands; however, the goal of homomorphic encryption goes back a decade. A cursory search will find multiple definitions for it. This is the most direct and succinct: A form of encryption that allows computation on ciphertexts generating an encrypted result that, when decrypted, matches the result of the operations as if they had been performed on plaintext. — Massimo Bertaccini ( ) Cryptography Algorithms Consider that statement for a moment. Homomorphic encryption enables operations to be performed on encrypted values such that the decrypted results produce the result of the operations as though they were performed on the original unencrypted values. The earliest mention I found is (1978) in which the authors are attempting to prevent sensitive financial data stored in an on-premise system from being accessed by system programmers using a remote time-sharing service. On Data Banks and Privacy Homomorphisms Sensitive financial data is stored in the data bank. Time-sharing services that compute the data do not implement adequate security. System programmers have access to financial data. The paper states: Use a special privacy homomorphism to encrypt its data so that the time-share computer can operate on the data without the necessity of decrypting it first. To put it another way, I want to delete the of my data without giving away to it. processing access To put it another yet another way, function(A, B) = function (A ) where A are encrypted values of A and B, respectively. This enables third parties to compute encrypted data and provide the results without having any knowledge of the original value. With RSA, two values encrypted with the same key can be multiplied, and the product can be decrypted yielding the product of the encrypted values. , B &nbsp;and B Obtain 5_6 using RSA(5)_ RSA(6): RSA(5) = (5^17) mod 3233 = 3096 RSA(6) = (6^17) mod 3233 = 824 3096*824 = 254864 RSA^-1(254864) = 254864^2753 (mod 3233) = 30 5*6 = 30 However, this does not work for addition. RSA is a Partially Homomorphic Encryption (PHE) scheme in that it supports only multiplication. The timeline below shows the progression from (PHE) schemes through Somewhat Homomorphic Encryption (SHWE) which permits limited combinations of addition and multiplication. These operations could be repeated up to five times before reaching an invalid result. Then along came the first FHE scheme from which enabled repeated addition and multiplication without fidelity loss. Craig Gentry Homomorphic Encryption Libraries Since 2009, FHE schemes and libraries have proliferated. Library Schemes Language License Microsoft SEAL BFV, BGV, CKKS C++/C# Wrapper MIT Open FHE BFV, BGV, CKKS, DM, CGGI C++ BSD 2-Clause License HEAAN CKKS C++ Creative Commons 3.0 TFHE TFHE (Torus) Rust BSD-3-Clause-Clear Concrete TFHE Rust BSD-3-Clause-Clear Lattigo BFV, BGV, CKKS Go Apache 2.0 Intel Homomorphic Encryption Toolkit N/A – Uses SEAL, PALISADE, HLib Python,Docker Apache 2.0 Microsoft SEAL (Simple Encrypted Arithmetic Library) is developed in C++ 17 along with a C# wrapper. Originally released in 2015, it is still under active development. The includes that should be explored if you are interested in diving further. github repo in-depth C# examples These schemes are supported by SEAL and include homomorphic operations for addition, division, subtractions, and exponentiation, but not division. Brakerski-Gentry-Vaikuntanathan (BGV)/Fan-Vercauteren (BFV) Whole numbers (long) Use if precision is a requirement Computation is slower than CKKS Values encrypted with BGV can be used with values encrypted with BFV Values encrypted with BGV/BVF cannot be used with values encrypted with CKKS Revisiting Homomorphic Encryption Schemes for Finite Fields Cheon-Kim-Kim-Song (CKKS) Floating points (double) Use if precision is not required Values encrypted with CKKS cannot be used with values encrypted with BGV/BFV Computation is faster than BFV/BGF Encryption and Computation with Microsoft SEAL These examples use the Nuget package and the CKKS scheme. Health trackers, like FitBit and AppleHeath, require giving up some privacy. They collect personal information like the number of steps and geocoordinates of the wearer's movements, heartbeat frequency, and other vital statistics. With homomorphic encryption, these health metric aggregators can still operate on our data without having access to the raw data. Microsoft.Research.SEALNet In this simple example, the client sends run metrics including distance and time. The server aggregates the encrypted data and computes the average speed. To get started, a public key is created by the client and shared with the server. It is used to encrypt data and also to perform arithmetic operations on encrypted data. Both client and server use an The client generates and retains a private key used for decryption used by the aptly named . Encryptor. Decryptor A malicious party that intercepts the data could use the public key on the encrypted data and return it to the caller by spoofing the server. The server should sign the result and the client should verify the signature to ensure it's being returned from a trusted party. using Microsoft.Research.SEAL;
protected SEALContext _context;
private KeyGenerator _keyGenerator;
private Encryptor _encryptor;
private Decryptor _decryptor;
protected IFitnessTrackerApiClient _apiClient;
. . .
_context = SEALUtils.GetContext(_config.Value.PolyModulusDegree, this.SchemeType);

_keyGenerator = new KeyGenerator(_context);

_keyGenerator.CreatePublicKey(out PublicKey publicKey);
_keyGenerator.CreateRelinKeys(out RelinKeys relinKeys);

_encryptor = new Encryptor(_context, _publicKey);
_decryptor = new Decryptor(_context, _keyGenerator.SecretKey);
. . .
PublicKeyModelCKKS keyModelCKKS = new(
  SEALUtils.KeyToBase64String(_publicKey),
  SEALUtils.KeyToBase64String(relinKeys));
    await _apiClient.SendPublicKeyCKKSAsync(keyModelCKKS); Relinearization keys are passed from client to server. Per Microsoft SEAL, they have no semantic meaning other than to reduce the size of following a multiplication operation. Ciphertext At the command line, the user enters time and distance. Each value is encoded to then encrypted to , and finally encoded to base64 prior to sending it to the server. PlainText, Ciphertext using Microsoft.Research.SEAL;
var plaintext = new Plaintext();
_encoder.Encode(value, _scale, plaintext);

var ciphertext = new Ciphertext();
_encryptor.Encrypt(value, ciphertext);

using (var ms = new MemoryStream())
{
  ciphertext.Save(ms);
  return Convert.ToBase64String(ms.ToArray());
} Since homomorphic encryption schemes don't support division (CKKS is no exception), the client needs to give the server an assist. The formula for speed is: distance/time Another way to write it is, distance * (1/time) So, the client sends: RunItemCKKS metricsRequest = new(
  EncryptBase64(runItem.Distance),
  EncryptBase64(runItem.Time),
  EncryptBase64(1 / runItem.Time));

await _apiClient.AddNewRunningDistanceCKKSAsync(metricsRequest); The server performs a similar bootstrapping function creating a using only the public key and re-linearization keys, then processes the request: SEALContext var distance = SEALUtils.BuildCiphertextFromBase64String(request.Distance, _sealContext);
var time = SEALUtils.BuildCiphertextFromBase64String(request.Time, _sealContext);
var timeReciprocal = SEALUtils.BuildCiphertextFromBase64String(request.TimeReciprocal, _sealContext);
Ciphertext speed = new();

_evaluator.Multiply(distance, timeReciprocal, speed);
_evaluator.RelinearizeInplace(speed, _relinKeys);

_runListCKKS.Add(new EncryptedRunInfoCKKS(distance, time, speed)); A reciprocal of the time is used to calculate the speed for the submitted run and the method reduces the size of the resulting Distance, time, and speed are saved to an in-memory RelinearizeInplace Ciphertext. List. The method aggregates the list and returns: GetMetrics total number of runs total distance total time average speed public SummaryItemCKKS GetMetrics()
{
int count = _runListCKKS.Count;

var totalDistanceCKKS = SumEncryptedValues(_runListCKKS.Select(m => m.Distance));
var totalTimeCKKS = SumEncryptedValues(_runListCKKS.Select(m => m.Time));
var totalSpeed = SumEncryptedValues(_runListCKKS.Select(m => m.Speed));
. . .
protected Ciphertext SumEncryptedValues(IEnumerable<Ciphertext> encryptedData)
{
. . .
Ciphertext encTotal = new();
_evaluator.AddMany(encryptedData, encTotal);
return encTotal;
. . .
} To get the average speed, the reciprocal of the count is used, so rather than using: (sum of speed)/number or runs we use: (sum of speed) * (1/number of runs) Since the server keeps track of the number of run submissions, the total number of runs is not an encrypted value. That unencrypted value can be converted to and used in an operation performed on While this is a simple example, the implications are worth noting. The server can provide additional values used on encrypted data enabling third-party providers to apply proprietary data to computations against customer-provided encrypted data. Plaintext Ciphertext. In the example below, the total count is converted to a reciprocal and added to a CKKS operations expect encrypted list values, even if the list only contains a single value. So, the is encoded to a . The multiplies totalSpeed by (1/number of runs) resulting in the average speed. To conserve space, the result is applied to the totalSpeed and the re-linearization keys reduce the size of the output. List<double>. List<double> PlainText MultiplyPlainInplace Ciphertext Plaintext encodedCountReciprocal = new();
List<double> averagePaceList = new();
double runCountReciprocal = 1 / (double)count;
averagePaceList.Add(runCountReciprocal);
_encoder.Encode(averagePaceList, _scale, encodedCountReciprocal);

_evaluator.MultiplyPlainInplace(totalSpeed, encodedCountReciprocal);
_evaluator.RelinearizeInplace(totalSpeed, _relinKeys); The values are base64 encoded, returned, and decrypted on the client. The client takes the additional step of converting decrypted to . Plaintext List<double> var payload = Convert.FromBase64String(encryptedDistanceText);

using var ms = new MemoryStream(payload);
var ciphertext = new Ciphertext();
ciphertext.Load(_context, ms);

var decryptedText = new Plaintext();
_decryptor.Decrypt(cypherText, decryptedText);

List<double> distanceList = new();
_encoder.Decode(decryptedText, distanceList); Sending the following values yields totals and the average pace calculated by a service that tabulated the total and average without decrypting data sent from the client. Miles Time 2.5 0:35:32.643 2.2 0:32:48.826 2.8 0:34:52.036 The server computes the data and returns the total runs, distance, time, and pace without decrypting any of the data sent. Summary Microsoft SEAL is a Microsoft Research project and is not ready for a production application. All classes implement and used unmanaged resources. Production code would need to protect against a memory leak. The class does not follow the single responsibility principle. It includes methods for both BGV/BVF and CKKS. Further, CKKS supports vector operations, but not vector addition. A single can be encrypted to a single but there is no means of summing the values in a single It can be done with , but that is a suboptimal solution. IDisposable SEALContext List<double> CipherText CipherText. vector rotation This Fitness Tracker code sample is a simple introduction to a complex topic.  There are a number of compelling use cases with more involved logic: Gene marker detection Biometric template protection Secure human monitoring for aging in place Credit card fraud detection Homomorphic encryption has largely been used in academia and in prototypes. Practical applications have been limited by the computing power required by homomorphic encryption schemes. GPU acceleration and ASIC processors will continue to erode this barrier. Intel is developing the , purpose-built for homomorphic encrypt schemes, in collaboration with Microsoft and DARPA. NASDAQ is also funding with machine learning for fraud detection. The FHE.org community is an excellent resource for the most current developments in this space. It has an active . FHE Hardware Accelerator an R&D project using homomorphic encryption Discord server All code samples in this article are available at . For more in-depth Microsoft SEAL example, see these . johniwasz/microsoft-seal-samples .NET examples Also published here.

Microsoft SEAL and the Dawn of Homomorphic Encryption

Microsoft SEAL y el amanecer del cifrado homomórfico

Microsoft SEAL et l'aube du chiffrement homomorphe

Microsoft SEAL और होमोमोर्फिक एन्क्रिप्शन का डॉन

Microsoft SEAL と準同型暗号の夜明け

Microsoft SEAL e o surgimento da criptografia homomórfica

Microsoft SEAL và Bình minh của Mã hóa Đồng hình

Microsoft SEAL 和同态加密的黎明

At , I had a task to fetch some files from GitHub API. Initially, I thought it'd be a simple GET request but soon I realized the work is a headache. The file I needed was quite large and hence the response was telling me to use something different than I already knew. I ended up spending two days on this issue. Hackernoon Now it's time to write an article so that my future self and others don't have to spend so much time on a simple issue. In this article, I'll show you how to get files larger than 1MB from the GitHub API. You will learn about the following topics until the end: Fetching larger files from GitHub API Working with commit's SHA Manipulating blobs and base64 encoded data For the purpose of this article, I am using data from HackerNoon's contest. The data is publicly available on if you want to follow along. Startup of the Year GitHub Get Files Smaller than 1MB Fetching smaller files is simple and you just need to pass three parameters to the API. First is the owner's name, which could be your username. The second is repo, which is the name of the repository where your file is committed. And path is the path to the file from the root. I have created a simple codepen if you want to use working code snippets. For better understanding, I have created four variables to store data at each state. let fileSHA, fileBlob, fileContent, file stores the SHA of the file we want to fetch. fileSHA stores the blob fetched from the API. fileBlob is used to store the decoded string. fileContent has the data that we actually need. file You can find the reference code in the next section, just change the folder path with the actual file path (with file extension) and you're good to go! The Problem with Large Files However, if you fetch a file larger than 1MB, the API would throw an error. This is due to the fact that the above endpoint does not support large files. To retrieve the data, we must instead use the API. Git Database The Git Data API allows you to read and write raw Git objects to and from your Git repository and list, as well as update Git references. This API primarily works with blobs, which is the focus of this article. Git converts a large file into a base64 encoded blob rather than storing the entire file for better performance. As a result, when you request the same file, it expects you to use the Database endpoint, which returns the blob. To retrieve a blob, you need to pass file's SHA. You might ask, what is SHA and how to get it? Every time you commit a new file, git creates a unique ID called hash orSHA to keep a record of changes. This could cause an issue sometimes but we would discuss this at the end of this article. Get SHA of the file For now, we need to figure out a way to get `SHA` of the desired file. GitHub API has an endpoint to interact with the file content that we can use. GET /repos/{owner}/{repo}/contents/{path} In response, we get an array of objects having metadata about every file in the directory. The Metadata contains SHA that we can store and use later. ); }

  getFileBlob(fileSHA)
} const getFileSHA = async () => { try { const response = await fetch( "<https://api.github.com/repos/hackernoon/where-startups-trend/contents/2021/>" const data = await response.json(); console .log(data); fileSHA = data[ 3 ].sha console .log(fileSHA); } catch (error) { console .log(error); has the SHA of , so we store it in for future uses. The console output would look something like this: data[3].sha votes_by_region.json fileSHA Fetch Blob of the file We have the file SHA which is required to get the blob. We need to use a different endpoint to work with blobs. This endpoint is similar to the last one but we have to pass file SHA as the third parameter. GET /repos/{owner}/{repo}/git/blobs/{file_sha} The following function fetches the blob of our file when we provide its SHA as a parameter. ); fileBlob = data.content
  convertBlob(fileBlob) }
} const getFileBlob = async (fileSHA)=> { try { const response = await fetch( `https://api.github.com/repos/hackernoon/where-startups-trend/git/blobs/ ${fileSHA} ` const data = await response.json(); } catch (error) { console .log(error); This request returns a base64 encoded blob. Base64 is an encoding scheme that represents binary data in an ASCII string format. It is useful when we need to store or transfer data without any modification. The console output will look gibberish but it's just how base64 encoded data is. Convert Blob into Useful Data In the final step, we have to convert the base64 encoded blob into something that we can use in our program. This step is quite frustrating because the standard ways don't seem to work in some cases. After spending hours on this single problem, I have found three solutions. I don't guarantee that every solution will work out for you, but I am pretty sure one of them surely will. This is the standard way natively supported by JavaScript. is a Web API interface that decodes base64 encoded data into a plain string. Easiest Way: atob() atob is supposed to be read as ASCII to Binary since it converts ASCII encoded base64 data into binary form. The output will be a decoded string. To convert it into its original data type, we use JSON.parse(). fileContents = atob(blob) file = JSON .parse(fileContents) If the above method throws an error, Node.js provides a method that you can use. It takes the string to be decoded as the first parameter and the encoding technique as the second. Second Way: Buffer.from() } try { const fileContents = Buffer.from(fileBlob, "base64" ).toString() file = JSON .parse(blobToString) console .log(file) } catch (error) { console .log(error) There's a good chance the previous method won't work if you're working on the frontend. In such case, create a function that uses . Final Way: decodeURIComponent }); } // define the function const decodeBase64 = str => { utf8Bytes = decodeURIComponent (str).replace( /%([0-9A-F]{2})/g , function ( match, p1 ) { return String .fromCharCode( '0x' + p1); return atob(utf8Bytes); You can call this function by passing the as the parameter, and get your decoded string! fileBlob fileContents = decodeBase64(fileBlob) file = JSON .parse(fileContents) console .log(file) Nothing Worked? Well, there are two final options that you can try. Either you can use FileReader API or use decodeURIComponent in a different way. : You can find MDN docs FileReader API here : Refer to blog by Rajeev Singh that handles 16bit encoded strings. decodeURIComponent this Alternatively, you can try an NPM package called as well. I have not used it myself so don't have opinions regarding it. js-base64 Restrictions As mentioned earlier, SHA is the unique ID that changes every time you modify the file. Also, since we have a hardcoded object index in the function, API might respond with SHA of a different file if you add or delete files in the directory. getFileSHA() To tackle this, you can use the exact file name instead of the index so you can keep the function unmodified after committing new changes. Summary and TL;DR Git stores larger files in blob format and hence we use GitHub Database API to fetch files larger than 1MB. We need to provide a username, repo name and the file's SHA to get the blob. To get SHA, we provide a folder path to the endpoint and store it in a variable. Later we pass SHA as a parameter to another endpoint and get a base64 encoded blob. The blob must be decoded into a plain string and then converted into its original format using before you can use it. JSON.parse() More references GitHub repositories' contents Git Database Getting started with the Git Database API Do let me know which decoding method worked for you. I am most active on , and ! Twitter LinkedIn Showwcase Happy fetching!

CONVERTFLOW

convertflow.com

-- employees

Since n.d.

COMPANY RANKING

CONVERTFLOW

EVERGREEN INDEX #3278

Representing this company? Click here to claim and customize this page!

ConvertFlow WIKI

Apply to get your Tech Company News Page live on HackerNoon.com today!

CONVERTFLOW

convertflow.com

-- employees

Since n.d.

COMPANY RANKING

CONVERTFLOW

EVERGREEN INDEX #3278

RELATED COMPANIESRANK

STORIES ABOUT CONVERTFLOW

Representing this company? Click here to claim and customize this page!

ConvertFlow WIKI

Apply to get your Tech Company News Page live on HackerNoon.com today!
