Using 7Zip to View Archive in Browser with JavaScript

7zip is a tool to open archives in the browser. You can use this example if you don't have a 7zip archive. We would use a WebAssembly port of a tool and create a wrapper around it to make it easier for a user to use it. The tool would use libarchivejs to look inside the archive. It would show us the folder tree on the left side and file content on the right side. The last thing before we go back to JavaScript code is to add CSS.
Matvii Hodovaniuk Hacker Noon profile picture

@matviihodovaniukMatvii Hodovaniuk

Software Developer. Collecting and sharing knowledge.

Tl;DR

You want to go to unzip and play with it. You can use this example if you don't have a 7zip archive.

I'll show you how to build this tool below.

Intro

We would answer some questions first.

What is 7zip.html?

It is a tool to open archives in your browser. Your data wouldn't leave your machine.

Why do we need this?

Sometimes you just need to have a look at a specific file in your archive and you don't want to install additional software to do this.

How would we do this?

We would use a WebAssembly port of a tool. We would create a wrapper around it to make it easier for a user.

Core

We would use libarchivejs to look inside the archive. Let's try the code from their example.

We need to setup libarchivejs to run in the browser.

Run libarchivejs in the browser

Let us start with webpack environment that would pack everything for us. You can see details in webpack folder here.

We need to add an input to start working with files.

<input id="fileInput" type="file" />

Then we need to add libarchivejs and event listener.

import {
    Archive
} from 'libarchive.js/main.js';

Archive.init({
    workerUrl: 'public/worker-bundle.js',
});

const fileInput = document.getElementById('fileInput');

fileInput.addEventListener('change', async (e) => {
    const file = e.currentTarget.files[0];
    const archive = await Archive.open(file);
    let obj = await archive.extractFiles();

    console.log(obj);
});

As a result, we would see similar output:

{
    ".gitignore": {File},
    "addon": {
        "addon.py": {File},
        "addon.xml": {File}
    },
    "README.md": {File}
}

Now we want to add functions and components to show folder tree and text file content.

We would have two columns element. It would show us the folder tree on the left side and file content on the right side.

<div class="twoColumn">
  <div class="column">
    <ul id="treeView"><i>No archive chosen</i></ul>
  </div>
  <div class="column">
    <textarea id="fileOutput"></textarea>
  </div>
</div>

The last thing before we go back to JavaScript code is to add CSS.

body {
  font-size: 16px;
  font-family: Courier, sans-serif;
  margin-left: auto;
  margin-right: auto;
  background-color: #f6f6f6;
  width: 800px;
  height: 100%;
}

.twoColumn {
  margin-top: 3em;
  display: flex;
  flex-direction: row;
  justify-content: space-between;
}

.column {
  width: 100%;
  max-width: 400px;
  overflow: hidden;
  margin-right: 5px;
  padding: 5px;
  background-color: #d3d0ba;
}

/* Hide the nested list */
.nested {
  display: none;
}

/* Show the nested list when the user clicks on the caret/arrow (with JavaScript) */
.active {
  display: block;
}

Now we are ready to add functions to show the folder tree.

We would add more const first.

const textarea = document.getElementById('fileOutput');
const fileInput = document.getElementById('fileInput');
const treeView = document.getElementById('treeView');

We need to add some helper functions before our next step.

We add uuid. We would use it to give tree nodes uniq ids.

import {
    v4 as uuidv4
} from 'uuid';

And we add `isASCII` to filter binary files.

function isASCII(str) {
    return /^[\x00-\x7F]*$/.test(str);
}

Then we would work on a walk function that would go through the tree recursive and create html elements.

We receive the node and check if it is a file or folder. We add elements to html in both cases. If it is a file then we add an event listener to open its content on the right-side panel. If it is a folder then we add an event listener to show/hide its content. Then we give a folder to a walk function to step into it and check its files. And we have nothing that we show `Empty folder`.

function walk({
    node,
    liId,
    name
}) {
    const root = document.getElementById(liId);
    if (!(node instanceof File)) {
        const newUlId = uuidv4();
        const newUl = document.createElement('ul');
        newUl.classList.add('nested');
        newUl.id = newUlId;
        const newLi = document.createElement('li');
        root.appendChild(newLi);
        newLi.classList.add('folder');
        newLi.addEventListener("click", function(e) {
            e.preventDefault();
            e.stopPropagation();
            newLi.childNodes.forEach(c => {
                if (c.classList.contains('nested')) {
                    c.classList.toggle("active");
                }
            });
        });

        const span = document.createElement('span');
        span.innerText = name;
        newLi.appendChild(span);
        newLi.appendChild(newUl);
        const keys = Object.keys(node);
        if (keys.length > 0) {
            keys.forEach((key) => {
                walk({
                    node: node[key],
                    liId: newUlId,
                    name: key
                });
            });
        } else {
            const span = document.createElement('span');
            span.innerHTML = '<i>Empty folder</i>';
            root.appendChild(span);
        }
    } else {
        const li = document.createElement('li');
        li.innerText = node.name;
        li.addEventListener('click', (e) => {
            e.stopPropagation();
            const reader = new FileReader();
            reader.onload = function(event) {
                if (isASCII(event.target.result)){
                    textarea.textContent = event.target.result;
                } else {
                    textarea.textContent = "Sorry, we cannot display binary files";
                }
            };
            reader.readAsText(node);
        });
        root.appendChild(li);
    }
}

That is it. Now we can open the archive in the browser and have a look at the file content.

How we can improve it? What are your thoughts?

I value your feedback, so let me know what you think!

Previously published at https://matvii.hodovani.uk/posts/how-to-create-7ziphtml.html
