Content Overview Keras layers
The build step
Keras models
Saving Keras models
Checkpointing Keras models Keras layers The build step Keras models Saving Keras models Checkpointing Keras models Note that up until this point, there is no mention of Keras. You can build your own high-level API on top of tf.Module, and people have. tf.Module In this section, you will examine how Keras uses tf.Module. A complete user guide to Keras models can be found in the Keras guide. tf.Module Keras guide Keras layers and models have a lot more extra features including: Optional losses
Support for metrics
Built-in support for an optional training argument to differentiate between training and inference use
Saving and restoring python objects instead of just black-box functions
get_config and from_config methods that allow you to accurately store configurations to allow model cloning in Python Optional losses Support for metrics metrics Built-in support for an optional training argument to differentiate between training and inference use training Saving and restoring python objects instead of just black-box functions get_config and from_config methods that allow you to accurately store configurations to allow model cloning in Python get_config from_config These features allow for far more complex models through subclassing, such as a custom GAN or a Variational AutoEncoder (VAE) model. Read about them in the full guide to custom layers and models. full guide Keras models also come with extra functionality that makes them easy to train, evaluate, load, save, and even train on multiple machines. Keras layers tf.keras.layers.Layer is the base class of all Keras layers, and it inherits from tf.Module. tf.keras.layers.Layer tf.Module You can convert a module into a Keras layer just by swapping out the parent and then changing __call__ to call: __call__ call class MyDense(tf.keras.layers.Layer):
  # Adding **kwargs to support base Keras layer arguments
  def __init__(self, in_features, out_features, **kwargs):
    super().__init__(**kwargs)

    # This will soon move to the build step; see below
    self.w = tf.Variable(
      tf.random.normal([in_features, out_features]), name='w')
    self.b = tf.Variable(tf.zeros([out_features]), name='b')
  def call(self, x):
    y = tf.matmul(x, self.w) + self.b
    return tf.nn.relu(y)

simple_layer = MyDense(name="simple", in_features=3, out_features=3) class MyDense(tf.keras.layers.Layer):
  # Adding **kwargs to support base Keras layer arguments
  def __init__(self, in_features, out_features, **kwargs):
    super().__init__(**kwargs)

    # This will soon move to the build step; see below
    self.w = tf.Variable(
      tf.random.normal([in_features, out_features]), name='w')
    self.b = tf.Variable(tf.zeros([out_features]), name='b')
  def call(self, x):
    y = tf.matmul(x, self.w) + self.b
    return tf.nn.relu(y)

simple_layer = MyDense(name="simple", in_features=3, out_features=3) Keras layers have their own __call__ that does some bookkeeping described in the next section and then calls call(). You should notice no change in functionality. __call__ call() simple_layer([[2.0, 2.0, 2.0]]) simple_layer([[2.0, 2.0, 2.0]]) <tf.Tensor: shape=(1, 3), dtype=float32, numpy=array([[1.1688161, 0.       , 0.       ]], dtype=float32)> <tf.Tensor: shape=(1, 3), dtype=float32, numpy=array([[1.1688161, 0.       , 0.       ]], dtype=float32)> The build step build As noted, it's convenient in many cases to wait to create variables until you are sure of the input shape. Keras layers come with an extra lifecycle step that allows you more flexibility in how you define your layers. This is defined in the build function. build build is called exactly once, and it is called with the shape of the input. It's usually used to create variables (weights). build You can rewrite MyDense layer above to be flexible to the size of its inputs: MyDense class FlexibleDense(tf.keras.layers.Layer):
  # Note the added `**kwargs`, as Keras supports many arguments
  def __init__(self, out_features, **kwargs):
    super().__init__(**kwargs)
    self.out_features = out_features

  def build(self, input_shape):  # Create the state of the layer (weights)
    self.w = tf.Variable(
      tf.random.normal([input_shape[-1], self.out_features]), name='w')
    self.b = tf.Variable(tf.zeros([self.out_features]), name='b')

  def call(self, inputs):  # Defines the computation from inputs to outputs
    return tf.matmul(inputs, self.w) + self.b

# Create the instance of the layer
flexible_dense = FlexibleDense(out_features=3) class FlexibleDense(tf.keras.layers.Layer):
  # Note the added `**kwargs`, as Keras supports many arguments
  def __init__(self, out_features, **kwargs):
    super().__init__(**kwargs)
    self.out_features = out_features

  def build(self, input_shape):  # Create the state of the layer (weights)
    self.w = tf.Variable(
      tf.random.normal([input_shape[-1], self.out_features]), name='w')
    self.b = tf.Variable(tf.zeros([self.out_features]), name='b')

  def call(self, inputs):  # Defines the computation from inputs to outputs
    return tf.matmul(inputs, self.w) + self.b

# Create the instance of the layer
flexible_dense = FlexibleDense(out_features=3) At this point, the model has not been built, so there are no variables: flexible_dense.variables flexible_dense.variables [] [] Calling the function allocates appropriately-sized variables: # Call it, with predictably random results
print("Model results:", flexible_dense(tf.constant([[2.0, 2.0, 2.0], [3.0, 3.0, 3.0]]))) # Call it, with predictably random results
print("Model results:", flexible_dense(tf.constant([[2.0, 2.0, 2.0], [3.0, 3.0, 3.0]]))) Model results: tf.Tensor(
[[-2.531786  -5.5550847 -0.4248762]
 [-3.7976792 -8.332626  -0.6373143]], shape=(2, 3), dtype=float32) Model results: tf.Tensor(
[[-2.531786  -5.5550847 -0.4248762]
 [-3.7976792 -8.332626  -0.6373143]], shape=(2, 3), dtype=float32) flexible_dense.variables flexible_dense.variables [<tf.Variable 'flexible_dense/w:0' shape=(3, 3) dtype=float32, numpy=
 array([[-0.77719826, -1.9281565 ,  0.82326293],
        [ 0.85628736, -0.31845194,  0.10916236],
        [-1.3449821 , -0.5309338 , -1.1448634 ]], dtype=float32)>,
 <tf.Variable 'flexible_dense/b:0' shape=(3,) dtype=float32, numpy=array([0., 0., 0.], dtype=float32)>] [<tf.Variable 'flexible_dense/w:0' shape=(3, 3) dtype=float32, numpy=
 array([[-0.77719826, -1.9281565 ,  0.82326293],
        [ 0.85628736, -0.31845194,  0.10916236],
        [-1.3449821 , -0.5309338 , -1.1448634 ]], dtype=float32)>,
 <tf.Variable 'flexible_dense/b:0' shape=(3,) dtype=float32, numpy=array([0., 0., 0.], dtype=float32)>] Since build is only called once, inputs will be rejected if the input shape is not compatible with the layer's variables: build try:
  print("Model results:", flexible_dense(tf.constant([[2.0, 2.0, 2.0, 2.0]])))
except tf.errors.InvalidArgumentError as e:
  print("Failed:", e) try:
  print("Model results:", flexible_dense(tf.constant([[2.0, 2.0, 2.0, 2.0]])))
except tf.errors.InvalidArgumentError as e:
  print("Failed:", e) Failed: Exception encountered when calling layer 'flexible_dense' (type FlexibleDense).

{ {function_node __wrapped__MatMul_device_/job:localhost/replica:0/task:0/device:CPU:0} } Matrix size-incompatible: In[0]: [1,4], In[1]: [3,3] [Op:MatMul] name:

Call arguments received by layer 'flexible_dense' (type FlexibleDense):
  • inputs=tf.Tensor(shape=(1, 4), dtype=float32) Failed: Exception encountered when calling layer 'flexible_dense' (type FlexibleDense).

{ {function_node __wrapped__MatMul_device_/job:localhost/replica:0/task:0/device:CPU:0} } Matrix size-incompatible: In[0]: [1,4], In[1]: [3,3] [Op:MatMul] name:

Call arguments received by layer 'flexible_dense' (type FlexibleDense):
  • inputs=tf.Tensor(shape=(1, 4), dtype=float32) Keras models You can define your model as nested Keras layers. However, Keras also provides a full-featured model class called tf.keras.Model. It inherits from tf.keras.layers.Layer, so a Keras model can be used and nested in the same way as Keras layers. Keras models come with extra functionality that makes them easy to train, evaluate, load, save, and even train on multiple machines. tf.keras.Model tf.keras.layers.Layer You can define the SequentialModule from above with nearly identical code, again converting __call__ to call() and changing the parent: SequentialModule __call__ call() @keras.saving.register_keras_serializable()
class MySequentialModel(tf.keras.Model):
  def __init__(self, name=None, **kwargs):
    super().__init__(**kwargs)

    self.dense_1 = FlexibleDense(out_features=3)
    self.dense_2 = FlexibleDense(out_features=2)
  def call(self, x):
    x = self.dense_1(x)
    return self.dense_2(x)

# You have made a Keras model!
my_sequential_model = MySequentialModel(name="the_model")

# Call it on a tensor, with random results
print("Model results:", my_sequential_model(tf.constant([[2.0, 2.0, 2.0]]))) @keras.saving.register_keras_serializable()
class MySequentialModel(tf.keras.Model):
  def __init__(self, name=None, **kwargs):
    super().__init__(**kwargs)

    self.dense_1 = FlexibleDense(out_features=3)
    self.dense_2 = FlexibleDense(out_features=2)
  def call(self, x):
    x = self.dense_1(x)
    return self.dense_2(x)

# You have made a Keras model!
my_sequential_model = MySequentialModel(name="the_model")

# Call it on a tensor, with random results
print("Model results:", my_sequential_model(tf.constant([[2.0, 2.0, 2.0]]))) Model results: tf.Tensor([[ 0.26034355 16.431221  ]], shape=(1, 2), dtype=float32) Model results: tf.Tensor([[ 0.26034355 16.431221  ]], shape=(1, 2), dtype=float32) All the same features are available, including tracking variables and submodules. Note: A raw tf.Module nested inside a Keras layer or model will not get its variables collected for training or saving. Instead, nest Keras layers inside of Keras layers. Note: A raw tf.Module nested inside a Keras layer or model will not get its variables collected for training or saving. Instead, nest Keras layers inside of Keras layers. Note: tf.Module my_sequential_model.variables my_sequential_model.variables [<tf.Variable 'my_sequential_model/flexible_dense_1/w:0' shape=(3, 3) dtype=float32, numpy=
 array([[ 1.4749854 ,  0.16090827,  2.2669017 ],
        [ 1.6850946 ,  1.1545411 ,  0.1707306 ],
        [ 0.8753734 , -0.13549292,  0.08751986]], dtype=float32)>,
 <tf.Variable 'my_sequential_model/flexible_dense_1/b:0' shape=(3,) dtype=float32, numpy=array([0., 0., 0.], dtype=float32)>,
 <tf.Variable 'my_sequential_model/flexible_dense_2/w:0' shape=(3, 2) dtype=float32, numpy=
 array([[-0.8022977 ,  1.9773549 ],
        [-0.76657015, -0.8485579 ],
        [ 1.6919082 ,  0.49000967]], dtype=float32)>,
 <tf.Variable 'my_sequential_model/flexible_dense_2/b:0' shape=(2,) dtype=float32, numpy=array([0., 0.], dtype=float32)>] [<tf.Variable 'my_sequential_model/flexible_dense_1/w:0' shape=(3, 3) dtype=float32, numpy=
 array([[ 1.4749854 ,  0.16090827,  2.2669017 ],
        [ 1.6850946 ,  1.1545411 ,  0.1707306 ],
        [ 0.8753734 , -0.13549292,  0.08751986]], dtype=float32)>,
 <tf.Variable 'my_sequential_model/flexible_dense_1/b:0' shape=(3,) dtype=float32, numpy=array([0., 0., 0.], dtype=float32)>,
 <tf.Variable 'my_sequential_model/flexible_dense_2/w:0' shape=(3, 2) dtype=float32, numpy=
 array([[-0.8022977 ,  1.9773549 ],
        [-0.76657015, -0.8485579 ],
        [ 1.6919082 ,  0.49000967]], dtype=float32)>,
 <tf.Variable 'my_sequential_model/flexible_dense_2/b:0' shape=(2,) dtype=float32, numpy=array([0., 0.], dtype=float32)>] my_sequential_model.submodules my_sequential_model.submodules (<__main__.FlexibleDense at 0x7f790c7e0e80>,
 <__main__.FlexibleDense at 0x7f790c7e6940>) (<__main__.FlexibleDense at 0x7f790c7e0e80>,
 <__main__.FlexibleDense at 0x7f790c7e6940>) Overriding tf.keras.Model is a very Pythonic approach to building TensorFlow models. If you are migrating models from other frameworks, this can be very straightforward. tf.keras.Model If you are constructing models that are simple assemblages of existing layers and inputs, you can save time and space by using the functional API, which comes with additional features around model reconstruction and architecture. functional API Here is the same model with the functional API: inputs = tf.keras.Input(shape=[3,])

x = FlexibleDense(3)(inputs)
x = FlexibleDense(2)(x)

my_functional_model = tf.keras.Model(inputs=inputs, outputs=x)

my_functional_model.summary() inputs = tf.keras.Input(shape=[3,])

x = FlexibleDense(3)(inputs)
x = FlexibleDense(2)(x)

my_functional_model = tf.keras.Model(inputs=inputs, outputs=x)

my_functional_model.summary() Model: "model"
_________________________________________________________________
 Layer (type)                Output Shape              Param #
=================================================================
 input_1 (InputLayer)        [(None, 3)]               0

 flexible_dense_3 (Flexible  (None, 3)                 12
 Dense)

 flexible_dense_4 (Flexible  (None, 2)                 8
 Dense)

=================================================================
Total params: 20 (80.00 Byte)
Trainable params: 20 (80.00 Byte)
Non-trainable params: 0 (0.00 Byte)
_________________________________________________________________ Model: "model"
_________________________________________________________________
 Layer (type)                Output Shape              Param #
=================================================================
 input_1 (InputLayer)        [(None, 3)]               0

 flexible_dense_3 (Flexible  (None, 3)                 12
 Dense)

 flexible_dense_4 (Flexible  (None, 2)                 8
 Dense)

=================================================================
Total params: 20 (80.00 Byte)
Trainable params: 20 (80.00 Byte)
Non-trainable params: 0 (0.00 Byte)
_________________________________________________________________ my_functional_model(tf.constant([[2.0, 2.0, 2.0]])) my_functional_model(tf.constant([[2.0, 2.0, 2.0]])) <tf.Tensor: shape=(1, 2), dtype=float32, numpy=array([[3.4276495, 2.937252 ]], dtype=float32)> <tf.Tensor: shape=(1, 2), dtype=float32, numpy=array([[3.4276495, 2.937252 ]], dtype=float32)> The major difference here is that the input shape is specified up front as part of the functional construction process. The input_shape argument in this case does not have to be completely specified; you can leave some dimensions as None. input_shape None Note: You do not need to specify input_shape or an InputLayer in a subclassed model; these arguments and layers will be ignored. Note: You do not need to specify input_shape or an InputLayer in a subclassed model; these arguments and layers will be ignored. Note: input_shape InputLayer Saving Keras models Keras models have their own specialized zip archive saving format, marked by the .keras extension. When calling tf.keras.Model.save, add a .keras extension to the filename. For example: .keras tf.keras.Model.save .keras my_sequential_model.save("exname_of_file.keras") my_sequential_model.save("exname_of_file.keras") Just as easily, they can be loaded back in: reconstructed_model = tf.keras.models.load_model("exname_of_file.keras") reconstructed_model = tf.keras.models.load_model("exname_of_file.keras") Keras zip archives — .keras files — also save metric, loss, and optimizer states. .keras This reconstructed model can be used and will produce the same result when called on the same data: reconstructed_model(tf.constant([[2.0, 2.0, 2.0]])) reconstructed_model(tf.constant([[2.0, 2.0, 2.0]])) <tf.Tensor: shape=(1, 2), dtype=float32, numpy=array([[ 0.26034355, 16.431221  ]], dtype=float32)> <tf.Tensor: shape=(1, 2), dtype=float32, numpy=array([[ 0.26034355, 16.431221  ]], dtype=float32)> Checkpointing Keras models Keras models can also be checkpointed, and that will look the same as tf.Module. tf.Module There is more to know about saving and serialization of Keras models, including providing configuration methods for custom layers for feature support. Check out the guide to saving and serialization. guide to saving and serialization What's next If you want to know more details about Keras, you can follow the existing Keras guides here. here Another example of a high-level API built on tf.module is Sonnet from DeepMind, which is covered on their site. tf.module their site Originally published on the TensorFlow website, this article appears here under a new headline and is licensed under CC BY 4.0. Code samples shared under the Apache 2.0 License. Originally published on the TensorFlow website, this article appears here under a new headline and is licensed under CC BY 4.0. Code samples shared under the Apache 2.0 License. TensorFlow TensorFlow
