Table of Links Abstract and 1 Introduction 2 Background and 2.1 Transformer-Based Large Language Models 2.2 LLM Service & Autoregressive Generation 2.3 Batching Techniques for LLMs 3 Memory Challenges in LLM Serving 3.1 Memory Management in Existing Systems 4 Method and 4.1 PagedAttention 4.2 KV Cache Manager 4.3 Decoding with PagedAttention and vLLM 4.4 Application to Other Decoding Scenarios 4.5 Scheduling and Preemption 4.6 Distributed Execution 5 Implementation 6 Evaluation and 6.1 Experimental Setup 6.2 Basic Sampling 6.3 Parallel Sampling and Beam Search 6.4 Shared prefix 6.5 Chatbot 7 Ablation Studies 8 Discussion 9 Related Work 10 Conclusion, Acknowledgement and References 8 Discussion Applying the virtual memory and paging technique to other GPU workloads. The idea of virtual memory and paging is effective for managing the KV cache in LLM serving because the workload requires dynamic memory allocation (since the output length is not known a priori) and its performance is bound by the GPU memory capacity. However, this does not generally hold for every GPU workload. For example, in DNN training, the tensor shapes are typically static, and thus memory allocation can be optimized ahead of time. For another example, in serving DNNs that are not LLMs, an increase in memory efficiency may not result in any performance improvement since the performance is primarily compute-bound. In such scenarios, introducing the vLLM’s techniques may rather degrade the performance due to the extra overhead of memory indirection and non-contiguous block memory. However, we would be excited to see vLLM’s techniques being applied to other workloads with similar properties to LLM serving. LLM-specific optimizations in applying virtual memory and paging. vLLM re-interprets and augments the idea of virtual memory and paging by leveraging the application-specific semantics. One example is vLLM’s all-or-nothing swap-out policy, which exploits the fact that processing a request requires all of its corresponding token states to be stored in GPU memory. Another example is the recomputation method to recover the evicted blocks, which is not feasible in OS. Besides, vLLM mitigates the overhead of memory indirection in paging by fusing the GPU kernels for memory access operations with those for other operations such as attention. This paper is available on arxiv under CC BY 4.0 DEED license. Authors:
(1) Woosuk Kwon, UC Berkeley with Equal contribution;
(2) Zhuohan Li, UC Berkeley with Equal contribution;
(3) Siyuan Zhuang, UC Berkeley;
(4) Ying Sheng, UC Berkeley and Stanford University;
(5) Lianmin Zheng, UC Berkeley;
(6) Cody Hao Yu, Independent Researcher;
(7) Cody Hao Yu, Independent Researcher;
(8) Joseph E. Gonzalez, UC Berkeley;
(9) Hao Zhang, UC San Diego;
(10) Ion Stoica, UC Berkeley. Table of Links Abstract and 1 Introduction Abstract and 1 Introduction 2 Background and 2.1 Transformer-Based Large Language Models 2 Background and 2.1 Transformer-Based Large Language Models 2.2 LLM Service & Autoregressive Generation 2.2 LLM Service & Autoregressive Generation 2.3 Batching Techniques for LLMs 2.3 Batching Techniques for LLMs 3 Memory Challenges in LLM Serving 3 Memory Challenges in LLM Serving 3.1 Memory Management in Existing Systems 3.1 Memory Management in Existing Systems 4 Method and 4.1 PagedAttention 4 Method and 4.1 PagedAttention 4.2 KV Cache Manager 4.2 KV Cache Manager 4.3 Decoding with PagedAttention and vLLM 4.3 Decoding with PagedAttention and vLLM 4.4 Application to Other Decoding Scenarios 4.4 Application to Other Decoding Scenarios 4.5 Scheduling and Preemption 4.5 Scheduling and Preemption 4.6 Distributed Execution 4.6 Distributed Execution 5 Implementation 5 Implementation 6 Evaluation and 6.1 Experimental Setup 6 Evaluation and 6.1 Experimental Setup 6.2 Basic Sampling 6.2 Basic Sampling 6.3 Parallel Sampling and Beam Search 6.3 Parallel Sampling and Beam Search 6.4 Shared prefix 6.4 Shared prefix 6.5 Chatbot 6.5 Chatbot 7 Ablation Studies 7 Ablation Studies 8 Discussion 8 Discussion 9 Related Work 9 Related Work 10 Conclusion, Acknowledgement and References 10 Conclusion, Acknowledgement and References 8 Discussion Applying the virtual memory and paging technique to other GPU workloads. The idea of virtual memory and paging is effective for managing the KV cache in LLM serving because the workload requires dynamic memory allocation (since the output length is not known a priori) and its performance is bound by the GPU memory capacity. However, this does not generally hold for every GPU workload. For example, in DNN training, the tensor shapes are typically static, and thus memory allocation can be optimized ahead of time. For another example, in serving DNNs that are not LLMs, an increase in memory efficiency may not result in any performance improvement since the performance is primarily compute-bound. In such scenarios, introducing the vLLM’s techniques may rather degrade the performance due to the extra overhead of memory indirection and non-contiguous block memory. However, we would be excited to see vLLM’s techniques being applied to other workloads with similar properties to LLM serving. Applying the virtual memory and paging technique to other GPU workloads. LLM-specific optimizations in applying virtual memory and paging. vLLM re-interprets and augments the idea of virtual memory and paging by leveraging the application-specific semantics. One example is vLLM’s all-or-nothing swap-out policy, which exploits the fact that processing a request requires all of its corresponding token states to be stored in GPU memory. Another example is the recomputation method to recover the evicted blocks, which is not feasible in OS. Besides, vLLM mitigates the overhead of memory indirection in paging by fusing the GPU kernels for memory access operations with those for other operations such as attention. LLM-specific optimizations in applying virtual memory and paging. This paper is available on arxiv under CC BY 4.0 DEED license. This paper is available on arxiv under CC BY 4.0 DEED license. available on arxiv Authors: (1) Woosuk Kwon, UC Berkeley with Equal contribution; (2) Zhuohan Li, UC Berkeley with Equal contribution; (3) Siyuan Zhuang, UC Berkeley; (4) Ying Sheng, UC Berkeley and Stanford University; (5) Lianmin Zheng, UC Berkeley; (6) Cody Hao Yu, Independent Researcher; (7) Cody Hao Yu, Independent Researcher; (8) Joseph E. Gonzalez, UC Berkeley; (9) Hao Zhang, UC San Diego; (10) Ion Stoica, UC Berkeley. Authors: Authors: (1) Woosuk Kwon, UC Berkeley with Equal contribution; (2) Zhuohan Li, UC Berkeley with Equal contribution; (3) Siyuan Zhuang, UC Berkeley; (4) Ying Sheng, UC Berkeley and Stanford University; (5) Lianmin Zheng, UC Berkeley; (6) Cody Hao Yu, Independent Researcher; (7) Cody Hao Yu, Independent Researcher; (8) Joseph E. Gonzalez, UC Berkeley; (9) Hao Zhang, UC San Diego; (10) Ion Stoica, UC Berkeley.
