Introduction

Angular is a development platform for building WEB, mobile, and desktop applications using HTML, CSS, and TypeScript (JavaScript). Currently, Angular is at version 14, and Google is the main maintainer of the project.

Leaflet is an interactive maps component library that supports mobile devices.

Prerequisites

Before you start, you need to install and configure the tools:

Getting Started

Create and Configure the Account on the Mapbox

1. Let's create the account. Access the site https://www.mapbox.com/ and click on the button Sign up.

Mapbox - Home page

Mapbox - Home page

2. Fill in the fields Username, Email, Password, First name, Last name, click on the checkbox I agree to the Mapbox Terms of Service and Privacy Policy and click on the button Get started.

Mapbox - Sign up

Mapbox - Sign up

3. Check the registered email.

Mapbox - Check email

Mapbox - Check email

4. Click on the link in the email sent.

Mapbox - Confirm email

Mapbox - Confirm email

5. Copy the token displayed in the Dashboard menu and, in my case, the token was displayed pk.eyJ1IjoiYnJhc2thbSIsImEiOiJja3NqcXBzbWoyZ3ZvMm5ybzA4N2dzaDR6In0.RUAYJFnNgOnnZAw because this token will be configured in the Angular application.

Mapbox - Dashboard

Mapbox - Dashboard

6. Ready! Account created and token generated.


Create the Angular application

1. Now let’s create the application with the Angular base structure using the @angular/cli with the route file and the SCSS style format.

ng new angular-leaflet
? Would you like to add Angular routing? Yes
? Which stylesheet format would you like to use? SCSS   [ https://sass-lang.com/documentation/syntax#scss                ]
CREATE angular-leaflet/README.md (1060 bytes)
CREATE angular-leaflet/.editorconfig (274 bytes)
CREATE angular-leaflet/.gitignore (604 bytes)
CREATE angular-leaflet/angular.json (3261 bytes)
CREATE angular-leaflet/package.json (1077 bytes)
CREATE angular-leaflet/tsconfig.json (783 bytes)
CREATE angular-leaflet/.browserslistrc (703 bytes)
CREATE angular-leaflet/karma.conf.js (1432 bytes)
CREATE angular-leaflet/tsconfig.app.json (287 bytes)
CREATE angular-leaflet/tsconfig.spec.json (333 bytes)
CREATE angular-leaflet/src/favicon.ico (948 bytes)
CREATE angular-leaflet/src/index.html (300 bytes)
CREATE angular-leaflet/src/main.ts (372 bytes)
CREATE angular-leaflet/src/polyfills.ts (2820 bytes)
CREATE angular-leaflet/src/styles.scss (80 bytes)
CREATE angular-leaflet/src/test.ts (788 bytes)
CREATE angular-leaflet/src/assets/.gitkeep (0 bytes)
CREATE angular-leaflet/src/environments/environment.prod.ts (51 bytes)
CREATE angular-leaflet/src/environments/environment.ts (658 bytes)
CREATE angular-leaflet/src/app/app-routing.module.ts (245 bytes)
CREATE angular-leaflet/src/app/app.module.ts (393 bytes)
CREATE angular-leaflet/src/app/app.component.scss (0 bytes)
CREATE angular-leaflet/src/app/app.component.html (24617 bytes)
CREATE angular-leaflet/src/app/app.component.spec.ts (1100 bytes)
CREATE angular-leaflet/src/app/app.component.ts (220 bytes)
✔ Packages installed successfully.
    Successfully initialized git.


2. Install and configure the Bootstrap CSS framework. Complete steps 2 and 3 of the post Adding the Bootstrap CSS framework to an Angular application.


3. Configure the Mapbox token in the src/environments/environment.ts and src/environments/environment.prod.ts files as below.

mapbox: {
  accessToken: 'pk.eyJ1IjoiYnJhc2thbSIsImEiOiJja3NqcXBzbWoyZ3ZvMm5ybzA4N2dzaDR6In0.RUAYJFnNgOnn80wXkrV9ZA',
},


4. Create the src/assets/images folder and copy the marker-icon.png and marker-shadow.png files.

Marker Icon

Marker Icon

Marker Shadow

Marker Shadow

5. Install the leaflet and @types/leaflet libraries.

npm install leaflet @types/leaflet


6. Configure the leaflet library. Change the angular.json file and add the leaflet.css file as below.

"styles": [
  "node_modules/bootstrap/scss/bootstrap.scss",
  "node_modules/bootstrap-icons/font/bootstrap-icons.css",
  "node_modules/leaflet/dist/leaflet.css",
  "src/styles.scss"
],


7. Remove the contents of the AppComponent class from the src/app/app.component.ts file. Import the leaflet service and create the getCurrentPosition, loadMap methods as shown below.

import { AfterViewInit, Component } from '@angular/core';
import { Observable, Subscriber } from 'rxjs';
import * as L from 'leaflet';

import { environment } from '../environments/environment';

@Component({
  selector: 'app-root',
  templateUrl: './app.component.html',
  styleUrls: ['./app.component.scss'],
})
export class AppComponent implements AfterViewInit {

  map: any;

  constructor() {
  }

  public ngAfterViewInit(): void {
    this.loadMap();
  }

  private getCurrentPosition(): any {
    return new Observable((observer: Subscriber<any>) => {
      if (navigator.geolocation) {
        navigator.geolocation.getCurrentPosition((position: any) => {
          observer.next({
            latitude: position.coords.latitude,
            longitude: position.coords.longitude,
          });
          observer.complete();
        });
      } else {
        observer.error();
      }
    });
  }

  private loadMap(): void {
    this.map = L.map('map').setView([0, 0], 1);
    L.tileLayer('https://api.mapbox.com/styles/v1/{id}/tiles/{z}/{x}/{y}?access_token={accessToken}', {
      attribution: 'Map data &copy; <a href="https://www.openstreetmap.org/copyright">OpenStreetMap</a> contributors, Imagery © <a href="https://www.mapbox.com/">Mapbox</a>',
      maxZoom: 18,
      id: 'mapbox/streets-v11',
      tileSize: 512,
      zoomOffset: -1,
      accessToken: environment.mapbox.accessToken,
    }).addTo(this.map);

    this.getCurrentPosition()
    .subscribe((position: any) => {
      this.map.flyTo([position.latitude, position.longitude], 13);

      const icon = L.icon({
        iconUrl: 'assets/images/marker-icon.png',
        shadowUrl: 'assets/images/marker-shadow.png',
        popupAnchor: [13, 0],
      });

      const marker = L.marker([position.latitude, position.longitude], { icon }).bindPopup('Angular Leaflet');
      marker.addTo(this.map);
    });
  }

}


8. Remove the contents of the src/app/app.component.html file. Add the map div tag as shown below.

<div class="container-fluid py-3">
  <h1>Angular Leaflet</h1>

  <div id="map"></div>
</div>


9. Add the style in the src/app/app.component.scss file as shown below.

#map {
  height: 400px;
  width: 100%;
  max-width: 600px;
}


10. Run the application with the command below.

npm start

> angular-leaflet@1.0.0 start
> ng serve

✔ Browser application bundle generation complete.

Initial Chunk Files | Names         |      Size
vendor.js           | vendor        |   2.81 MB
styles.css          | styles        | 280.54 kB
polyfills.js        | polyfills     | 128.51 kB
scripts.js          | scripts       |  76.67 kB
main.js             | main          |  12.03 kB
runtime.js          | runtime       |   6.63 kB

                    | Initial Total |   3.30 MB

Build at: 2021-08-20T10:40:47.188Z - Hash: 030dfe6c9ea7ff5d80c2 - Time: 12256ms

** Angular Live Development Server is listening on localhost:4200, open your browser on http://localhost:4200/ **


✔ Compiled successfully.


11. Ready! Access the URL http://localhost:4200/ and check if the application is working. Check that the application is working on GitHub Pages and Stackblitz.

Angular Leaflet

Angular Leaflet

The application repository is available at https://github.com/rodrigokamada/angular-leaflet.
