1. Introduction King Kong, the Movie, was released on the 28th of April, 1933. Fast-forward and Donkey Kong, the Video Game, was released on the 14th of June, 1994. Kong seems to have a really nice association with Gorillas. Gorillaz, the virtual band, was founded in 1998. They have nothing to do with this article, but I love their music. Finally, the Kong framework was released much later. Their first release came out in October 2017. The story of Kong begins in 2007 by Augustu Marietti, the current CEO (2022), in a garage in Milan. There he founded MemboxX which became one of the first data storage service providers in Europe. Two years later, Marietti confounded Mashape, which was, at its core, a "Mash"-up of functions provided together with an application server. The company moved quickly to the US in San Francisco. In 2015, the company launched an open-source project called Kong which led to the company rebranding to Kong Inc. in 2017. Nowadays (2021), Kong is a brand most widely known for its API gateway function. However, Kong is also a brand for other products like Kong-Mesh, Imsonia, and Konnect. The first time I heard about Kong was a few years ago (today is 2021), and back then, I would see Kong-related code when I searched for IT stuff on the web. I saw their advertising and read something about them, but I never really had to use it, or I never understood exactly what it was for. With a bit of motivation, this year, I was able to spend some time with this to figure out what I could do with it. Then I found out that Kong is implemented to be used as a gateway to a system. The system in this case can be anything. In our case, we are going to use it as a gateway to a network created by docker-compose. Kong works as a sort of proxy where we can change several properties to detect patterns of access to our applications inside such a network. In this article, we are going to see how to implement the API gateway, what can it do for us, and how we can use it in real-life scenarios with the rate-limiting plugin. 2. Case The concept of the work that I’ve created in order to do this, revolves around an application created to reserve tickets for a concert. In this case, we are going to implement a concept that I call a Yucca concert concept. The idea is to pass data around to allow resources to be released as soon as possible in order to receive more data. The idea is to make a system as reactive as possible to allow the creation of tickets to a concert. In this Yucca concept, the idea is that we have some sort of queue to receive data and then let our system handle that in the background. By doing so, we release the application so that more requests can be placed in the queue and then processed later in an asynchronous way. By allowing a system to be reactive, we also need to make sure that it can detect abuse. Abuse of a system can take many forms, and if you are familiar with ethical hacking or software security concepts, you know that one of the biggest threats to reactive systems (actually any system, but probably even more so to reactive systems) is a DDoS attack. DDoS attack means a Distributed Denial of Service attack. The way to prevent such a thing is by using Software Gateway services like Kong or relying on the shared services of your provider, which can limit your work flexibility and not allow you to install certain types of software. But, before further digressing, let’s talk about what we want to achieve. The idea about reserving a ticket in this case is to see a show. In this Yucca concept, the ticket comes associated with a mandatory one or more concert days, optional one or more drinks, optional one or more meals, and optional parking. Customers get immediately a reservation reference and then later, the registration is complete. Since most of the concerts provided by Yucca are online, and the expected attendance is massive, It becomes impossible to fulfill registrations as customers register their tickets online in real-time or at the ticket office. We know thus, that we’ll have different maximum rates for the different segments of the tickets. We also know that above a certain rate, the odds of it being a DDoS attack also increase. By the same principle, we also know that some people will reserve the ticket, but not actually complete the request, there may also be cancellations. Whatever maximum rate we calculate to be for the ticket requests, the odds are that people will also reserve a meal and a drink. This means that we get a rate that is double the value of the ticket rate. A concert usually lasts around 3 days, so in this case, we can consider roughly a triple rate value of the ticket requests. Finally, since the car parking places are quite limited, the rate limit should be much lower. So what should we do, if, after deployment, the rate is surpassed? Kong allows us to block further requests for a while and according to criteria, we may define according to our expectations. We can avoid DDoS attacks in this way. 2.1. Architecture For the implementation, the first question that popped into my mind was: "In what language do I want to implement this application?" Given the current hype around this newcomer into the JVM scene, Kotlin, I decided to give it a further go at it. Since it’s been going significantly strong since last year (2021), it made sense to me to check it out and how I could combine my research in Kotlin and Micronaut. For this specific case, I also wanted to try something new, just to see how it works and what I could take out of using a new framework. So, once established that I wanted to use Kotlin and Micronaut, I was still missing some sort of stream managing system, queues, or whatever. I just wanted something where I could inject some requests, reply back to the client, and release resources. Effectively, I wanted to make every single endpoint as reactive as possible. And so I added Redis and implemented a Publisher-Subscriber system, typically used in Reactive Engineering. "Why not Kafka?" I have already an advancement on this question because Kafka is a mega framework in the IT world, and it seems like it’s really all we know these days. That and Akka streams. So, just for the sake of doing something radically new to me, I chose Redis. But I still wasn’t satisfied because I still had to choose, which reactive programming model to choose from. As I explored before, Spring has webflux, but in this, I am using Micronaut. Another mega hype in the IT world these days is coroutines. This is what some people call a blatant copy of Project Loom. Anyway, since I had never used this before, I decided to actually use it. For the rest, I’m using the very traditional Docker/Docker-compose way of launching containers locally, nothing fancy, just because that would be too much out of scope for this article if I would add more advanced ways of launching containers. Leveling up in the settlement of our architecture, I decided that every different request type would run on its own service. Here, I try to follow some very, very basic microservices architecture, where every service has its own responsibility. In the following sequence diagram, we can see what are we going to have a look at in terms of code: So, in this diagram, we can spot a few players, but the only player open to the public is the yucca-api. This application is responsible for the generation of a receipt ID (a UUID), which is immediately returned to the client. Unannounced to the client, or the buyer, the ticket hasn’t actually been processed yet, and it’s not even in the database yet. Let me ask you a question. Have you ever received an email where it says something like "Your request is being processed. Within an hour you’ll receive your tickets. Keep this reference number if you need to call our help desk." Well, this is exactly what is happening. You just get a purchase confirmation, but further, you get nothing else. In the meantime, the yucca-api has picked up your request and assigned a reference number of the receipt that has just been persisted to the database to your ticket request. Then it will be shipped to Redis. The listeners in the backend will now fetch this request back and ship it via REST to the yucca-ticket. This makes it possible to process the rest of the ticket in a fully asynchronous way. The yucca-ticket runs exactly in the same way, except that now, when it gets picked up by the listener, it will break the ticket into three parts: concert data, parking data, and catering data. To be precise, it will actually break the request into four parts. The catering data, if you haven’t noticed, is divided into drinks and meals. Once this is done, four rest calls are going to be performed to three different APIs. These are the yucca-catering, yucca-concert and yucca-parking. These services provide thus 4 endpoints. All of them have no provision for REST calls since they are the last requests performed per ticket. They do, however, process these last requests also in a reactive way, by responding immediately after receiving the different payloads and only spending time setting them up to the Pub-Sub system provided by Redis. At this point, we have concluded the ticket request and the user would only then receive an email. This last bit is well off the scope of this article. We can see this whole process in action in the following sequence diagram: Please check the home of the project for a better visualization of this sequence diagram. In order to understand how this all plays out in the database, it is also important to have a good look at the ER model: This will allow us to collect all the data that is sent in the initial payload. 3. Implementation Implementing this system did involve a lot of research, but I was able to implement a few things. One is the codecs that is necessary to provide the payload both for our REST requests and the data streaming in and out of the Redis Pub-Sub system. Because I wanted to make it as generic as possible I’ve created it with reified types. This was just made for convenience and to explore the Kotlin programming language too. We’ll see later why this could be a terrible idea to do: abstract class BuyOycType( open val type: AuditLogType = RECEIPT ) : Serializable abstract class BuyOycCodec<T> : RedisCodec<String, T> { override fun decodeKey(byteBuffer: ByteBuffer): String { return Charset.defaultCharset().decode(byteBuffer).toString() } override fun decodeValue(byteBuffer: ByteBuffer): T = ObjectInputStream( ByteArrayInputStream(byteArrayCodec.decodeValue(byteBuffer)) ).use { readCodecObject(it) } abstract fun readCodecObject(it: ObjectInputStream): T override fun encodeKey(key: String): ByteBuffer { return Charset.defaultCharset().encode(key) } override fun encodeValue(ticketDto: T): ByteBuffer = ByteArrayOutputStream().use { baos -> ObjectOutputStream(baos).use { oos -> oos.writeObject(ticketDto) byteArrayCodec.encodeValue(baos.toByteArray()) } } companion object { val byteArrayCodec = ByteArrayCodec() } } inline fun <reified T : Any> ObjectInputStream.readTypedObject(): T = readObject() as T As we can see, there are two important interfaces that our DTO types need to follow. They need to be Serializable, and they also need to be of type BuyOycType. This is just so that we can serialize them to Redis. The Serializable interface is normally not needed for just REST controllers. For those of you who don’t know what use is, this is an extremely sugary version of the try with resources in Java. If you use this in Kotlin, you might not even be aware that this is what use is doing, so beware if you don’t already know. Since we are also having a look at how the data model is created in Micronaut, it is important also to have a look at a few of the entities created. In this case, we’ll have a look at how some of the relations have been implemented by starting with the TicketReservation entity: @MappedEntity(namingStrategy = UnderScoreSeparatedLowerCase::class) data class TicketReservation( @field: Id @field: AutoPopulated var id: UUID? = null, val reference: UUID? = UUID.randomUUID(), val name: String, val address: String, val birthDate: LocalDate, val parkingReservation: ParkingReservation? = null, @field:DateCreated val createdAt: LocalDateTime? = LocalDateTime.now(), ) The MappedEntity annotation allows us to create entities. In short, entities represent the way we handle tables via code. Micronaut has provisions like this, and if you know Hibernate, you are probably already familiar with Entity. For our purpose in this article, they are quite the same. Given that we are looking at a reactive model, actual database relations, especially complex ones like many-to-many, many-to-one, one-to-one and one-to-many make almost no sense. However, we can do something else using the Join annotation which seems to work quite well. One TicketReservation is personal, and so we can only associate one ParkingReservation with it. This is in every sense of the word a one-to-one relation. Once the car parking is reserved, only one customer can access it and only one parking can be used by one customer. This is a logic requirement because that way we can promise fair car parking usage to the attendees. Let’s look at the ParkingReservation implementation: @MappedEntity(namingStrategy = UnderScoreSeparatedLowerCase::class) data class ParkingReservation( @field: Id @field: AutoPopulated var id: UUID? = null, val reference: UUID? = UUID.randomUUID(), var carParking: CarParking? = null, @field:DateCreated val createdAt: LocalDateTime? = LocalDateTime.now() ) In this case, the ParkingReservation is just a middleware table leading up to the actual CarParking table which defines the parking number. This is how we are allocating the parking space. The actual relation between tables is maintained with the Join annotation: @R2dbcRepository(dialect = Dialect.POSTGRES) interface ParkingReservationRepository : CoroutineCrudRepository<ParkingReservation, UUID>, CoroutineJpaSpecificationExecutor<ParkingReservation> { @Join(value = "carParking", type = Join.Type.FETCH) override suspend fun findById(id: UUID): ParkingReservation } If you noticed, the ticket reservation entity itself does not have any reference to the drinks, meals or concert days reserved. This would be the case of a many ticket reservation to many concerts, many ticket reservation to many drinks, and many ticket reservations to many meals. It’s the many keyword in these relations that do not work well with the reactive architecture. In a blocking architecture, we would have defined a list of meals, a list of drinks and a list of concert days, defining thus many-to-many relations bound with each other seamlessly with a join table. Drinks and Meals are actually fixed items in a menu and what we really need is their reservation counterparts. While the relation between ticket reservation and drinks is a many-to-many relation, a relation between a ticket reservation and a drink reservation is a one-to-many relation. In other words, for each ticket reservation we have, we can make many drink reservations, but all of those reservations can only be associated to one ticket reservation, hence one to many. We can apply the same reasoning to the meal reservation and the concert reservation. In this project, we create the database using scripts that do use foreign keys, although in our code, we actually do not use and perform joins instead in an eager fashion. The following is an example of this: CREATE TABLE IF NOT EXISTS ticket.ticket_reservation ( id UUID NOT NULL, reference UUID NOT NULL UNIQUE, name varchar, address varchar, birth_date date, parking_reservation_id UUID NULL, created_at TIMESTAMP NOT NULL DEFAULT LOCALTIMESTAMP, PRIMARY KEY (id), FOREIGN KEY (parking_reservation_id) REFERENCES ticket.parking_reservation (id) ); In Micronaut’s terms, just as in spring, a table is also called a relation. If you have noticed, all the important tables contain a reference field. This reference field keeps the number given to the customer in the ticket where they can retrieve the vouchers and tickets at the entrance when the concert starts. This is not implemented in this project, but it is important to mention its intention. The past table is therefore not used in this first instance. This is just an example to show the table styles being used. 4. Setting Up Kong After learning a bit on how the application is set up, we can finally start looking at the way Kong is set up. I’ve learned on a first instance to start Kong using a PostgreSQL database for persistence, a Kong migration image and finally the Kong service. Let’s look at a code snippet from the actual docker-compose.yaml file located at the root of the project: services: kong-migrations-up: container_name: kong-migrations image: "${KONG_DOCKER_TAG:-kong:latest}" command: kong migrations bootstrap && kong migrations up && kong migrations finish depends_on: yucca-db: condition: service_healthy environment: <<: *kong-env secrets: - kong_postgres_password networks: - yucca-net kong: hostname: kong container_name: kong image: "${KONG_DOCKER_TAG:-kong:latest}" depends_on: yucca-db: condition: service_healthy buy-oyc-api: condition: service_healthy buy-oyc-ticket: condition: service_healthy buy-oyc-concert: condition: service_healthy buy-oyc-catering: condition: service_healthy buy-oyc-parking: condition: service_healthy kong-migrations-up: condition: service_completed_successfully user: "${KONG_USER:-kong}" environment: <<: *kong-env KONG_ADMIN_ACCESS_LOG: /dev/stdout KONG_ADMIN_ERROR_LOG: /dev/stderr KONG_PROXY_LISTEN: "${KONG_PROXY_LISTEN:-0.0.0.0:8000}" KONG_ADMIN_LISTEN: "${KONG_ADMIN_LISTEN:-0.0.0.0:8001}" KONG_PROXY_ACCESS_LOG: /dev/stdout KONG_PROXY_ERROR_LOG: /dev/stderr KONG_PREFIX: ${KONG_PREFIX:-/var/run/kong} KONG_ADMIN_GUI_URL: "http://0.0.0.0:8002" KONG_PORTAL_GUI_HOST: "0.0.0.0:8003" KONG_PORTAL: "on" KONG_LUA_PACKAGE_PATH: "./?.lua;./?/init.lua;" restart: on-failure secrets: - kong_postgres_password ports: - "127.0.0.1:8001:8001/tcp" - "127.0.0.1:8444:8444/tcp" - "8002:8002" - "8003:8003" healthcheck: test: [ "CMD", "kong", "health" ] interval: 10s timeout: 10s retries: 20 start_period: 0s volumes: - ./kong_prefix_vol:${KONG_PREFIX:-/var/run/kong} - ./kong_tmp_vol:/tmp - ./kong:/opt/kong - ./kong/kong-migration.sh:/opt/kong/kong-migration.sh security_opt: - no-new-privileges networks: yucca-net: kong-deck: hostname: kong-deck container_name: kong-deck image: kong/deck:v1.16.1 volumes: - ${PWD}/kong:/deck command: "--kong-addr http://kong:8001 -s /deck/kong.yaml sync" networks: yucca-net: depends_on: kong: condition: service_healthy yucca-db: condition: service_healthy buy-oyc-api: condition: service_healthy buy-oyc-ticket: condition: service_healthy buy-oyc-concert: condition: service_healthy buy-oyc-catering: condition: service_healthy buy-oyc-parking: condition: service_healthy kong-migrations-up: condition: service_completed_successfully yucca-db: hostname: yucca-db container_name: yucca-db image: postgres # user: ${YUCCA_USER_DB} command: postgres -c listen_addresses='*' -c 'max_connections=400' -c 'shared_buffers=100MB' environment: POSTGRES_DB: ${KONG_PG_DATABASE:-kong} POSTGRES_USER: ${KONG_PG_USER:-kong} POSTGRES_PASSWORD_FILE: /run/secrets/kong_postgres_password POSTGRES_MULTIPLE_DATABASES: yucca secrets: - kong_postgres_password healthcheck: test: [ "CMD", "pg_isready", "-U", "${KONG_PG_USER:-kong}" ] interval: 30s timeout: 30s retries: 10 start_period: 0s restart: on-failure stdin_open: true tty: true expose: - 5432 volumes: - ./kong_data_vol:/var/lib/postgresql/data - ./docker-images/docker-psql:/docker-entrypoint-initdb.d - ./docker-images/docker-psql/multiple:/docker-entrypoint-initdb.d/multiple networks: yucca-net: buy-oyc-ticket: hostname: buy-oyc-ticket container_name: buy-oyc-ticket depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-ticket-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db KONG_SERVICE_IP: kong networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8084/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-concert: hostname: buy-oyc-concert container_name: buy-oyc-concert depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-concert-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8085/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-parking: hostname: buy-oyc-parking container_name: buy-oyc-parking depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-parking-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8086/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-catering: hostname: buy-oyc-catering container_name: buy-oyc-catering depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-catering-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8087/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-api: hostname: buy-oyc-api container_name: buy-oyc-api depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-api-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db KONG_SERVICE_IP: kong networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8088/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-nginx: hostname: buy-oyc-nginx container_name: buy-oyc-nginx build: context: ./buy-odd-yucca-gui/. ports: - "8080:8080" restart: on-failure environment: - KONG_SERVICE_IP=kong deploy: resources: limits: memory: 300M reservations: memory: 300M networks: yucca-net: depends_on: kong: condition: service_healthy redis: container_name: redis image: redis ports: - "6379:6379" networks: yucca-net: secrets: kong_postgres_password: file: ./password When Kong starts, we need to let it run the mode we prefer. Since I want the setup to be loaded at the startup of docker-compose, I have no choice but to say that I do not want to use the persistence model of Kong. The excerpt above is from the docker-compose-it.yaml, that I use exclusively for the integration tests. So, from top to bottom, we see firstly the declaration of the docker-migrations-up service. This is actually another Kong image that we are using as a runnable to perform migrations to the database. As mentioned before, this isn’t technically necessary for the integration tests. The second service is another Kong container that we are using to actually run Kong. There is really much to talk about in this setup, but for this article let’s just focus on port 8000. This port is what we are going to use to access all of our application APIs. Kong uses this port (or whatever we want to configure) as the gateway access-point to redirect all traffic to the destination API. If you noticed on the previous diagrams, there is never direct access to any of the APIs on any occasion. We’ll talk shortly about the other different ports available in Kong. But first, we look into the env variables. The specific Kong variables allow for several configurations. The ones that allow automatic setup loading are: KONG_DATABASE="off" KONG_DECLARATIVE_CONFIG="/opt/kong/kong.yaml For the KONG_DECLARATIVE_CONFIG, I’m getting the configuration there using volume ./kong:/opt/kong. Finally, we find the database. In this case, the volumes created allow the database to be initialised with this startup script available originally on: https://github.com/mrts/docker-postgresql-multiple-databases/blob/master/create-multiple-postgresql-databases.sh' #!/bin/bash # Credits to https://github.com/mrts/docker-postgresql-multiple-databases/blob/master/create-multiple-postgresql-databases.sh # This is an improvement of that file # To create an image, this file follows some rules # It is inspired by the way Spring scans for script and data files # The root folder of all script files must be docker-entrypoint-initdb.d/multiple/ # `multiple` is a choice. # Originally, the docker entrypoint located in /user/local/bin looks for all .sql, .gz and .xz files to import on docker-entrypoint-initdb.d/. # There is not clean way around this. Check the entrypoint details on https://github.com/docker-library/postgres/blob/master/docker-entrypoint.sh. # This script will search for sql files in the root folder docker-entrypoint-initdb.d/multiple/ prepended like schema-<database>.sql and data-<database>.sql # You can disable this by setting variable POSTGRES_SCAN_DISABLED to true # Databases are declared in POSTGRES_MULTIPLE_DATABASES as a comma separated string of database tags # You can specify a bundle of scripts to execute in a certain folder per database like so <database>:<folder> as one of these elements # If you wish to use folders with the same name as the database and don't want to use this notation then you have to set POSTGRES_FOLDER_MAPPING to true # To specify the database user use POSTGRES_USER # To specify the database password use POSTGRES_PASSWORD # The script creates a user with the given name who has the given password # It also creates another user with the database name and the given password per database created # If both match, then only one user is created with the database name and the given password # This script is available to download in a small example I've created in https://github.com/jesperancinha/project-signer/tree/master/docker-templates/docker-psql set -e set -u POSTGRES_SCAN_DISABLED="${POSTGRES_SCAN_DISABLED:-false}" POSTGRES_FOLDER_MAPPING="${POSTGRES_FOLDER_MAPPING:-false}" function create_user_and_database() { database=$(echo "$command" | awk -F':' '{print $1}') echo " Creating user and database '$database'" psql -v ON_ERROR_STOP=1 --username "$POSTGRES_USER" -tc "SELECT 1 FROM pg_user WHERE usename = '$database'" | grep -q 1 || psql -v ON_ERROR_STOP=1 --username "$POSTGRES_USER" <<-EOSQL CREATE USER $database with PASSWORD '$POSTGRES_PASSWORD'; CREATE DATABASE $database; GRANT ALL PRIVILEGES ON DATABASE $database TO $database; EOSQL } function import_file_to_database() { echo "Importing file $2 to database $1..." psql -U "$POSTGRES_USER" -d "$1" -f "$2" } function import_files_from_folder() { directory=$1 database=$2 echo "Database bundle $directory for database $database requested" if [ -d "$directory" ]; then for script in "$directory"/*.sql; do echo "Request importing file $script to database $database" import_file_to_database "$database" "$script" done else echo "WARNING: No script bundle directory found for database $database" fi } function create_and_import_files() { local rootDir="docker-entrypoint-initdb.d/multiple/" if [ -n "$POSTGRES_MULTIPLE_DATABASES" ]; then echo "Multiple database creation requested: $POSTGRES_MULTIPLE_DATABASES" for command in $(echo "$POSTGRES_MULTIPLE_DATABASES" | tr ',' ' '); do create_user_and_database "$command" if [[ "$command" == *":"* ]]; then database=$(echo "$command" | awk -F':' '{print $1}') directory=$rootDir$(echo "$command" | awk -F':' '{print $2}') import_files_from_folder "$directory" "$database" elif [ "$POSTGRES_FOLDER_MAPPING" == true ]; then if [[ "$command" != *":"* ]]; then import_files_from_folder "$rootDir$database" "$database" fi fi if [ "$POSTGRES_SCAN_DISABLED" != true ]; then database=$(echo "$command" | awk -F':' '{print $1}') echo "Auto-scanning files for database $database" echo "Auto-scanning schema files" schema_file=$rootDir"schema-$database.sql" if [ -f "$schema_file" ]; then import_file_to_database "$database" "$schema_file" echo "Auto-scanning data files" schema_data=$rootDir"data-$database.sql" if [ -f "$schema_data" ]; then import_file_to_database "$database" "$schema_data" else echo "WARNING: No data file detected for database $database" fi else echo "WARNING: No schema file detected for database $database" fi fi done echo "Multiple databases created" fi } create_and_import_files This script essentially allows for the creation of different databases based on their different names and folder names and use different data.sql and schema.sql scripts. It makes the code cleaner and easier to use. The file I am using has been developed from this one. Finally, we can look at the Kong file, kong.yaml, which sets up the ports, the URLs, and the mappings: _format_version: "3.0" _transform: true services: # Ticket Service - url: http://buy-oyc-ticket:8084/api/yucca-ticket/swagger/views/swagger-ui/res name: buy-oyc-ticket-swagger-ui protocol: http routes: - name: buy-oyc-ticket-service-route-swagger-ui paths: - /api/yucca-ticket/swagger-ui/res strip_path: true - url: http://buy-oyc-ticket:8084/api/yucca-ticket/swagger name: buy-oyc-ticket-swagger protocol: http routes: - name: buy-oyc-ticket-service-route-swagger paths: - /api/yucca-ticket/swagger strip_path: true - url: http://buy-oyc-ticket:8084/api/yucca-ticket/api name: buy-oyc-ticket protocol: http routes: - name: buy-oyc-ticket-service-route paths: - /api/yucca-ticket/api strip_path: true - url: http://buy-oyc-ticket:8084/api/yucca-ticket name: buy-oyc-ticket-rest protocol: http routes: - name: buy-oyc-ticket-service-route-root paths: - /api/yucca-ticket strip_path: true # Concert Service - url: http://buy-oyc-concert:8085/api/yucca-concert/swagger/views/swagger-ui/res name: buy-oyc-concert-swagger-ui protocol: http routes: - name: buy-oyc-concert-service-route-swagger-ui paths: - /api/yucca-concert/swagger-ui/res strip_path: true - url: http://buy-oyc-concert:8085/api/yucca-concert/swagger name: buy-oyc-concert-swagger protocol: http routes: - name: buy-oyc-concert-service-route-swagger paths: - /api/yucca-concert/swagger strip_path: true - url: http://buy-oyc-concert:8085/api/yucca-concert/api name: buy-oyc-concert protocol: http routes: - name: buy-oyc-concert-service-route paths: - /api/yucca-concert/api strip_path: true - url: http://buy-oyc-concert:8085/api/yucca-concert name: buy-oyc-concert-rest protocol: http routes: - name: buy-oyc-concert-service-route-root paths: - /api/yucca-concert strip_path: true # Parking Service - url: http://buy-oyc-parking:8086/api/yucca-parking/swagger/views/swagger-ui/res name: buy-oyc-parking-swagger-ui protocol: http routes: - name: buy-oyc-parking-service-route-swagger-ui paths: - /api/yucca-parking/swagger-ui/res strip_path: true - url: http://buy-oyc-parking:8086/api/yucca-parking/swagger name: buy-oyc-parking-swagger protocol: http routes: - name: buy-oyc-parking-service-route-swagger paths: - /api/yucca-parking/swagger strip_path: true - url: http://buy-oyc-parking:8086/api/yucca-parking/api name: buy-oyc-parking protocol: http routes: - name: buy-oyc-parking-service-route paths: - /api/yucca-parking/api strip_path: true - url: http://buy-oyc-parking:8086/api/yucca-parking name: buy-oyc-parking-rest protocol: http routes: - name: buy-oyc-parking-service-route-root paths: - /api/yucca-parking strip_path: true # Catering Service - url: http://buy-oyc-catering:8087/api/yucca-catering/swagger/views/swagger-ui/res name: buy-oyc-catering-swagger-ui protocol: http routes: - name: buy-oyc-catering-service-route-swagger-ui paths: - /api/yucca-catering/swagger-ui/res strip_path: true - url: http://buy-oyc-catering:8087/api/yucca-catering/swagger name: buy-oyc-catering-swagger protocol: http routes: - name: buy-oyc-catering-service-route-swagger paths: - /api/yucca-catering/swagger strip_path: true - url: http://buy-oyc-catering:8087/api/yucca-catering/api name: buy-oyc-catering protocol: http routes: - name: buy-oyc-catering-service-route paths: - /api/yucca-catering/api strip_path: true - url: http://buy-oyc-catering:8087/api/yucca-catering name: buy-oyc-catering-rest protocol: http routes: - name: buy-oyc-catering-service-route-root paths: - /api/yucca-catering strip_path: true # API Service - url: http://buy-oyc-api:8088/api/yucca-api/swagger/views/swagger-ui/res name: buy-oyc-api-swagger-ui protocol: http routes: - name: buy-oyc-api-service-route-swagger-ui paths: - /api/yucca-api/swagger-ui/res strip_path: true - url: http://buy-oyc-api:8088/api/yucca-api/swagger name: buy-oyc-api-swagger protocol: http routes: - name: buy-oyc-api-service-route-swagger paths: - /api/yucca-api/swagger strip_path: true - url: http://buy-oyc-api:8088/api/yucca-api/api name: buy-oyc-api protocol: http routes: - name: buy-oyc-api-service-route paths: - /api/yucca-api/api strip_path: true - url: http://buy-oyc-api:8088/api/yucca-api name: buy-oyc-api-rest protocol: http routes: - name: buy-oyc-api-service-route-root paths: - /api/yucca-api strip_path: true This mapping is loaded directly with the integration tests. If we just run our setup locally, we then use a different approach. First, we use docker-compose up. This starts up everything and all the containers until it stabilizes. Once the start-up has finished, we need to inject this configuration file manually into Kong. For that, Kong, makes a small utility available to install called deck. Please check their website to find out more about how to install it. In the Makefile, I’ve created, there is an instruction we can use to do this automatically, where I’m using a small bash polling trick to find out if Kong has started or not. The polling itself is located in the kong_wait.sh file: #!/bin/bash function checkServiceByNameAndMessage() { name=$1 message=$2 printf "%s." "$name" docker-compose logs "$name" &> "logs" string=$(cat logs) echo "$string" counter=0 while [[ "$string" != *"$message"* ]] do printf "." docker-compose logs "$name" &> "logs" string=$(cat logs) sleep 1 counter=$((counter+1)) if [ $counter -eq 200 ]; then echo "Failed after $counter tries! Cypress tests mail fail!!" echo "$string" exit 1 fi if [[ "$string" = *"[PostgreSQL error] failed to retrieve PostgreSQL"* ]]; then echo "Failed PostgreSQL connection after $counter tries! Cypress tests mail fail!!" echo "$string" exit 1 fi done counter=$((counter+1)) echo "succeeded $name Service after $counter tries!" } checkServiceByNameAndMessage kong 'init_worker_by_lua' Finally, in the Makefile we can see this snipped, which calls it: create-folders: mkdir -p kong_prefix_vol kong_tmp_vol kong_data_vol set-permissions: if [[ -d kong_data_vol ]]; then sudo chmod -R 777 kong_data_vol; else mkdir kong_data_vol && sudo chmod -R 777 kong_data_vol; fi if [[ -d kong_tmp_vol ]]; then sudo chmod -R 777 kong_tmp_vol; else mkdir kong_tmp_vol && sudo chmod -R 777 kong_tmp_vol; fi if [[ -d kong_prefix_vol ]]; then sudo chmod -R 777 kong_prefix_vol; else mkdir kong_prefix_vol && sudo chmod -R 777 kong_prefix_vol; fi docker: create-folders set-permissions docker-compose up -d --build --remove-orphans What’s important to know is that the kong.yaml file is a configuration file for the endpoints. In terms of rate limiting, we can use REST calls. 5. Running Kong As I mentioned before, port 8000 is crucial, in order to access the different APIs and allow Kong to perform gateway filtration on the requests. In this whole project, we are looking at rate-limiting. Rate-limiting can be applied to paths and the different APIs individually. We can see every definition of these APIs using individually another Kong API. This API is opened, and following our own configuration, on port 8001. In this section, we are going to run our application, so for now, please run this command at the root: make docker This will run the docker command we have seen earlier. If all runs smoothly, you should get all containers running. Once this is done, please open your browser on http://localhost:8001. Here, you’ll find a list of all sorts of configurations inside Kong. This is just a warmup look. Now, please have a look at this URL: http://localhost:8001/plugins. You should see a list of plugins. One of them could be something similar to this: This means that rate-limiting is active, and in this case, we have a limitation of 1 request per second and 10000 requests per hour. It is also important to know at this point that Kong will not allow you to make overlapping configurations. For example, if you only allow to make 1 request per hour, this means that you can only make 60 * 60 = 3600 request per second. If you configure any more than that for seconds, then Kong will rightfully let you know that the second limitation conflicts with the hour limitation, and it will return a message like this one: But for now, we have no plugin configured, so let’s start. In your command line, please run the following: curl -i -X POST http://localhost:8001/services/buy-oyc-ticket-service/plugins \ --data "name=rate-limiting" \ --data "config.second=1" \ --data "config.hour=10000" \ --data "config.policy=local" \ --data "config.fault_tolerant=true" \ --data "config.hide_client_headers=false" This just means that the API now has a plugin that in practice, only allows up to 1 request per second to be pushed through the gateway. Essentially, we are limiting our concerts to be created at the rate of 1 per second. All others will be getting an error. We want, in this case, to be as transparent as possible in our analysis and how we go about evaluating the requests. This is why we set up the default values of local, true, and false to config.policy, config.fault_tolerant and config.hide_client_headers respectively. Now, we are ready to start locus. On another command line, please run the following: make locust-start This will start locust. If you do not know locust, this is essentially a benchmark tool. Find out how to install it directly at the source. We aren’t interested in making performance tests. Instead, we want to see in practice how rate-limiting is working in practice. Perhaps now is a good idea to have a look at our test cases. Let’s first have a look at the task script in Python located at /locust/welcome: import requests from locust import HttpUser, task, constant_throughput class BuyOddYuccaConcert(HttpUser): wait_time = constant_throughput(1) @task def yucca_ticket_welcome_message(self): send_payload( name="будинок", address="будинок Адреса", birth_date="1979-01-01", concert_id="5359A368-CA49-4027-BC25-F375E3EA2463", drink_id="B2A5E349-76E7-4CD6-8105-308D1BC94953", meal_id="59B97053-37CF-4FAF-AB50-E77CEF8E8CC8") send_payload( name="Home", address="Home Address", birth_date="1979-01-01", concert_id="2E4522B1-D9FF-4B2B-9FFA-052CBAD9D5F2", drink_id="B2A5E349-76E7-4CD6-8105-308D1BC94953", meal_id="59B97053-37CF-4FAF-AB50-E77CEF8E8CC8") These IDs are references to data in our database. I am fixing the request to perform minimally one time per second. In locust terms, this means that every locust performs this task once per second. Since the task performs two post requests, this means that we are minimally making 2 requests per second. The requests are fixed. The function that is being called, makes a call to the API: def send_payload(name, address, birth_date, concert_id, drink_id, meal_id): payload = { "name": name, "address": address, "birthDate": birth_date, "concertDays": [ { "concertId": concert_id } ], "meals": [ { "mealId": meal_id } ], "drinks": [ { "drinkId": drink_id } ], "parkingReservation": [ { "carParkingId": 1 } ] } r = requests.post('http://localhost:8000/api/yucca-api/api', json=payload) print( f"Person: {name} living in {address} born on {birth_date}, " f"just reserved concert {concert_id} with drink {drink_id} and meal {meal_id}, " f"Status Code: {r.status_code}, " f"Response: {r.json()}") The payload is just a representation of the general format for one person who makes a reservation for one drink, one meal, one parking space, and one concert day. We are going to use this data in order to make sure we can perform our tests: insert into ticket.car_parking (id, parking_number) values ('E3BB8287-8F4F-477B-AFDF-44D78665A08C', 1); insert into ticket.car_parking (id, parking_number) values ('23745A3C-9426-4E92-A940-89E07C2ED24D', 2); insert into ticket.car_parking (id, parking_number) values ('27728F31-244A-4469-81AC-86B332E7BD1B', 3); insert into ticket.car_parking (id, parking_number) values ('0892A233-4973-4477-A6DA-91E44E1386D3', 4); insert into ticket.car_parking (id, parking_number) values ('61BF1E61-A7C2-4D6E-951A-8E97BD4E4FB3', 5); insert into ticket.concert_day(id, name, description, concert_date) values ('5359A368-CA49-4027-BC25-F375E3EA2463', 'Jamala', '', now()); insert into ticket.concert_day(id, name, description, concert_date) values ('2E4522B1-D9FF-4B2B-9FFA-052CBAD9D5F2', 'Kalush Orchestra', '', now()); insert into ticket.drink(id, name, width, height, shape, volume, price) values ('2377198D-9E41-4134-8E89-ABD66FE0C59B', 'Varenukha', 10, 10, 10, 10, 10); insert into ticket.drink(id, name, width, height, shape, volume, price) values ('B2A5E349-76E7-4CD6-8105-308D1BC94953', 'Uzvar', 10, 10, 10, 10, 10); insert into ticket.meal(id, coupon , box_type, discount, price, processed) values ('59B97053-37CF-4FAF-AB50-E77CEF8E8CC8', gen_random_uuid(), 'XS', 10, 10, false); insert into ticket.meal(id, coupon , box_type, discount, price, processed) values ('4581DECF-7740-44E8-8B2C-B7EC0FEE31C3', gen_random_uuid(), 'XS', 10, 10, false); Now, we are ready to fire our locust tests. If you noticed, you have in your command line logs like this one: If you are running a good terminal, you should be able to click on the link, and go straight to http://localhost:8089: Just let it be the way it is. It will start with one user, and it will spawn more users at a rate of 1 per second. This means that, since we configured Kong to make requests at a rate of 1 request per second max, on the yucca-api gateway, we are just barely on the edge of sending requests to the gateway. We will get errors. Our logs will look like this: So Kong, now configured to accept only one request per second, won’t be able to accept 2 requests per second, which, if you noticed from before, is exactly what our locust task does. Let’s leave locust running. In our command line, you should have gotten something like this when you ran the first request: What this means is that we have activated a plugin, and we named it rate-limiting. This is also a key to the map of plugins that we could activate for Kong. We now want to change the rate, so we need to remove this plugin and create a new one. For this case, we need to indicate the ID of the plugin we want to remove. In our case, it is: 0ff09073–3e16–4442-ac78–428b25818b7f: curl -X DELETE http://localhost:8081/plugins/0ff09073–3e16–4442-ac78–428b25818b7f Now, I’ll show you how we can change this live on the fly. Just make sure that Locust is still running. Run this command now: curl -i -X POST http://localhost:8001/services/buy-oyc-ticket-service/plugins \ --data "name=rate-limiting" \ --data "config.second=2" \ --data "config.hour=10000" \ --data "config.policy=local" \ --data "config.fault_tolerant=true" \ --data "config.hide_client_headers=false" You should not be getting any errors now: From this point onwards, you should understand how to change the rate to other requests. Feel free to give it a go and try different combinations on all sub-requests. 6. Questions and Answers "How do we know when the ticket is complete in the back end?" Since we process the ticket asynchronously, there is actually no way of knowing this in an asynchronous way. The last thing we want is to join all of these processes and wait for them to finish somewhere. It is also not something possible, since the different services should be allowed to work on different machines, areas, regions, and domains, making multithread control impossible. What can be done is some sort of polling system to check when all the database elements have been received and persisted correctly into the database. It should be made in a separate service that would crawl through the database and verify this information. 7. Conclusion Thanks for following this project with me and for being open to seeing how everything works. I hope to have given you a good introduction to the basics of rate-limiting in Kong. Using Kong, we can do much more than just rate-limiting. There are endless choices and possibilities using Kong. Regarding Micronaut, I truly believe that it is a great competitor to Spring, and I especially like the idea that it brings me focus to engineering problems rather than the current hype around code beauty. This is something I didn’t really experience with Spring. With Micronaut, just as an example I was forced to think about annotation processors and select which one of them was important for my development. This is something I have not seen in other Enterprise frameworks. Where Micronaut forces us to think about what we do on a very low level, other frameworks seem to do a lot of things for us, which can be a bittersweet present. Regarding Kotlin, this project led me to further deepen my doubts about this new language and what seems to be a technology sweeping everyone off their feet. I have to be honest here, if I compare the way Java has been developing and the way Kotlin has burst into the IT scene, I think my soul remains divided. Although there is a lot of beauty related to this new language, it is starting to look more like the Beauty of the JVM world rather than an engineering-oriented language. I can say that using things like by, reified and not having to think if I’m implementing or extending has also removed quite a bit of the lexicon of the language, and we need lexicon and semantics in our thought process. This whole philosophy brought by Kotlin about "not having to" also spread to the use of utility functions that we now make as extension functions. Sometimes, you see them in interfaces, classes, companion objects, or wherever they can be, and you’ll find them very much compliant with Murphy’s Law for the good or the worse. Now, is there a problem with this? Not directly, but I have already witnessed too many style discussions in the Kotlin world that I didn’t see in the Java world. For example, using findById()? is "so ugly, how could you do that?", because "findByIdOrNull is more Kotlin-like." There are studies that show that shortcuts and fragmenting a language (not just programming) can potentially impair the way we think because it limits our expression choices. But hey, I’m just not allowing myself to jump into the idea that Java is worse than Kotlin. In this project, there is a lot that I did that made my life easier. But I noticed, that for example, I didn’t even have to think about primitives. No int, no long, no float, not double. It’s just a dynamic that since I’ve been working in Kotlin for my projects, I don’t even think about. But I know what they are. Because of this, I always have this question. If I didn’t have a background in Java, would I understand what I do now about Kotlin? I have more and more the feeling that I wouldn’t. I am, however, impressed with the idea of coroutines, but with Project Loom lingering for years and coming out now, what should I conclude about the very similar ideas that the two have with each other? As a final note, I have to say that I am extremely pleased to have studied Micronaut and Kong for this article. I’m not sure what to think about Kotlin, though. I think my next project will be in the latest Java version, and maybe then, I’ll compare Java back to Kotlin. Using Redis as a lifeboat for a sort of quick solution for my project with a queue system worked like a charm, and I am very happy with it. 8. References https://youtu.be/z3Y4NQgjGLE?embedable=true https://www.youtube.com/watch?v=20rOdqag4Dw&embedable=true https://www.youtube.com/watch?v=sJEID1xEZMg&embedable=true Compose V2 Kong Gateway for Beginners: Adding a Service, Route and Plugins Kong Gateway Tutorial | API Gateway For Beginners How to Use Kong Gateway JWT Plugin Developing Micronaut Applications with IntelliJ IDEA Micronaut Deep Dive by Graeme Rocher Introduction to Micronaut • Graeme Rocher • GOTO 2019 What is Rate Limiting / API Throttling? | System Design Concepts API Gateway Plugins for Kubernetes Ingress Controller Installing Kong's API Gateway with Docker DevOps Is More Than Configuration Management DynamoDB Partitions - How they work - AWS Service Deep Dive Working with DynamoDB Tables - Partition Key and Sort Key - Dynamo Deep Dive AWS re:Invent 2018: Amazon DynamoDB Deep Dive: Advanced Design Patterns for DynamoDB (DAT401) What is a DynamoDB GSI (Global Secondary Index) ? Permission issue with PostgreSQL in docker container What kinds of bot attacks are stopped by rate limiting? Using Micronaut Data, JDBC, R2DBC, TestContainers, and Flyway with multiple schemas Realtime Testing: Micronaut, Postgres and Testcontainer Entity-Relationship Diagram Symbols and Notation MICRONAUT 1.0 RC1 AND THE POWER OF AHEAD-OF-TIME COMPILATION From Spring Boot to Micronaut Create a New React App Micronaut: A five-minute introduction Micronaut CLI CREATING YOUR FIRST MICRONAUT APPLICATION Micronaut Deploy an Enterprise License Kong Gateway Licensing @ Kong Docs How To Enable the Dev Portal @ Kong Docs Kong /docker-kong 🦍 (sounds like Donkey Kong!) Kong Gateway MemboxX Kong Inc. Wikipedia Repubished 5 questions for Kong CEO Augusto Marietti Author: Augusto Marietti Years after crashing on Travis Kalanick’s couch, this founder has raised $18M for his startup, Mashape Mashape Rebrands as Kong Inc., Declares Monolithic Application Dead Kong Inc. Redhwan Nacef's Kong Tutorial On GitHub Lorem Picsum Phosots Thank you! I hope you enjoyed this article as much as I did making it! Please leave a review, comments, or any feedback you want to give on any of the socials in the links below. I’m very grateful if you want to help me make this article better. I have placed all the source code of this application on GitHub.Thank you for reading! 1. Introduction King Kong , the Movie, was released on the 28th of April, 1933 . Fast-forward and Donkey Kong , the Video Game, was released on the 14th of June, 1994. Kong seems to have a really nice association with Gorillas. Gorillaz , the virtual band, was founded in 1998 . They have nothing to do with this article, but I love their music. Finally, the Kong framework was released much later. Their first release came out in October 2017 . King Kong 28th of April, 1933 Fast-forward Donkey Kong the Video Game, Gorillaz 1998 Kong framework October 2017 The story of Kong begins in 2007 by Augustu Marietti , the current CEO ( 2022 ), in a garage in Milan . There he founded MemboxX which became one of the first data storage service providers in Europe. Two years later, Marietti confounded Mashape , which was, at its core, a "Mash"-up of functions provided together with an application server. The company moved quickly to the US in San Francisco. Augustu Marietti CEO 2022 garage Milan MemboxX Marietti Mashape In 2015, the company launched an open-source project called Kong which led to the company rebranding to Kong Inc. in 2017. Nowadays (2021), Kong is a brand most widely known for its API gateway function. However, Kong is also a brand for other products like Kong-Mesh , Imsonia , and Konnect . Kong-Mesh Imsonia Konnect The first time I heard about Kong was a few years ago (today is 2021), and back then, I would see Kong-related code when I searched for IT stuff on the web. I saw their advertising and read something about them, but I never really had to use it, or I never understood exactly what it was for. With a bit of motivation, this year, I was able to spend some time with this to figure out what I could do with it. Then I found out that Kong is implemented to be used as a gateway to a system. The system in this case can be anything. In our case, we are going to use it as a gateway to a network created by docker-compose. Kong works as a sort of proxy where we can change several properties to detect patterns of access to our applications inside such a network. In this article, we are going to see how to implement the API gateway, what can it do for us, and how we can use it in real-life scenarios with the rate-limiting plugin. 2. Case The concept of the work that I’ve created in order to do this, revolves around an application created to reserve tickets for a concert. In this case, we are going to implement a concept that I call a Yucca concert concept. The idea is to pass data around to allow resources to be released as soon as possible in order to receive more data. The idea is to make a system as reactive as possible to allow the creation of tickets to a concert. In this Yucca concept, the idea is that we have some sort of queue to receive data and then let our system handle that in the background. By doing so, we release the application so that more requests can be placed in the queue and then processed later in an asynchronous way. By allowing a system to be reactive, we also need to make sure that it can detect abuse. Abuse of a system can take many forms, and if you are familiar with ethical hacking or software security concepts, you know that one of the biggest threats to reactive systems (actually any system, but probably even more so to reactive systems) is a DDoS attack. DDoS attack means a Distributed Denial of Service attack. The way to prevent such a thing is by using Software Gateway services like Kong or relying on the shared services of your provider, which can limit your work flexibility and not allow you to install certain types of software. But, before further digressing, let’s talk about what we want to achieve. The idea about reserving a ticket in this case is to see a show. In this Yucca concept, the ticket comes associated with a mandatory one or more concert days, optional one or more drinks, optional one or more meals, and optional parking. Customers get immediately a reservation reference and then later, the registration is complete. Since most of the concerts provided by Yucca are online, and the expected attendance is massive, It becomes impossible to fulfill registrations as customers register their tickets online in real-time or at the ticket office. We know thus, that we’ll have different maximum rates for the different segments of the tickets. We also know that above a certain rate, the odds of it being a DDoS attack also increase. By the same principle, we also know that some people will reserve the ticket, but not actually complete the request, there may also be cancellations. Whatever maximum rate we calculate to be for the ticket requests, the odds are that people will also reserve a meal and a drink. This means that we get a rate that is double the value of the ticket rate. A concert usually lasts around 3 days, so in this case, we can consider roughly a triple rate value of the ticket requests. Finally, since the car parking places are quite limited, the rate limit should be much lower. So what should we do, if, after deployment, the rate is surpassed? Kong allows us to block further requests for a while and according to criteria, we may define according to our expectations. We can avoid DDoS attacks in this way. 2.1. Architecture For the implementation, the first question that popped into my mind was: "In what language do I want to implement this application?" Given the current hype around this newcomer into the JVM scene, Kotlin, I decided to give it a further go at it. Since it’s been going significantly strong since last year (2021), it made sense to me to check it out and how I could combine my research in Kotlin and Micronaut. For this specific case, I also wanted to try something new, just to see how it works and what I could take out of using a new framework. So, once established that I wanted to use Kotlin and Micronaut, I was still missing some sort of stream managing system, queues, or whatever. I just wanted something where I could inject some requests, reply back to the client, and release resources. Effectively, I wanted to make every single endpoint as reactive as possible. And so I added Redis and implemented a Publisher-Subscriber system, typically used in Reactive Engineering. "Why not Kafka?" I have already an advancement on this question because Kafka is a mega framework in the IT world, and it seems like it’s really all we know these days. That and Akka streams. So, just for the sake of doing something radically new to me, I chose Redis. But I still wasn’t satisfied because I still had to choose, which reactive programming model to choose from. As I explored before, Spring has webflux, but in this, I am using Micronaut. Another mega hype in the IT world these days is coroutines. This is what some people call a blatant copy of Project Loom. Anyway, since I had never used this before, I decided to actually use it. For the rest, I’m using the very traditional Docker/Docker-compose way of launching containers locally, nothing fancy, just because that would be too much out of scope for this article if I would add more advanced ways of launching containers. Leveling up in the settlement of our architecture, I decided that every different request type would run on its own service. Here, I try to follow some very, very basic microservices architecture, where every service has its own responsibility. In the following sequence diagram, we can see what are we going to have a look at in terms of code: So, in this diagram, we can spot a few players, but the only player open to the public is the yucca-api. This application is responsible for the generation of a receipt ID (a UUID), which is immediately returned to the client. Unannounced to the client, or the buyer, the ticket hasn’t actually been processed yet, and it’s not even in the database yet. Let me ask you a question. Have you ever received an email where it says something like "Your request is being processed. Within an hour you’ll receive your tickets. Keep this reference number if you need to call our help desk." Well, this is exactly what is happening. You just get a purchase confirmation, but further, you get nothing else. In the meantime, the yucca-api has picked up your request and assigned a reference number of the receipt that has just been persisted to the database to your ticket request. Then it will be shipped to Redis. The listeners in the backend will now fetch this request back and ship it via REST to the yucca-ticket. This makes it possible to process the rest of the ticket in a fully asynchronous way. The yucca-ticket runs exactly in the same way, except that now, when it gets picked up by the listener, it will break the ticket into three parts: concert data, parking data, and catering data. To be precise, it will actually break the request into four parts. The catering data, if you haven’t noticed, is divided into drinks and meals. Once this is done, four rest calls are going to be performed to three different APIs. These are the yucca-catering , yucca-concer t and yucca-parking . yucca-catering yucca-concer yucca-parking These services provide thus 4 endpoints. All of them have no provision for REST calls since they are the last requests performed per ticket. They do, however, process these last requests also in a reactive way, by responding immediately after receiving the different payloads and only spending time setting them up to the Pub-Sub system provided by Redis. At this point, we have concluded the ticket request and the user would only then receive an email. This last bit is well off the scope of this article. We can see this whole process in action in the following sequence diagram: Please check the home of the project for a better visualization of this sequence diagram . sequence diagram In order to understand how this all plays out in the database, it is also important to have a good look at the ER model: This will allow us to collect all the data that is sent in the initial payload. 3. Implementation Implementing this system did involve a lot of research, but I was able to implement a few things. One is the codecs that is necessary to provide the payload both for our REST requests and the data streaming in and out of the Redis Pub-Sub system. Because I wanted to make it as generic as possible I’ve created it with reified types. This was just made for convenience and to explore the Kotlin programming language too. We’ll see later why this could be a terrible idea to do: Redis Pub-Sub abstract class BuyOycType( open val type: AuditLogType = RECEIPT ) : Serializable abstract class BuyOycCodec<T> : RedisCodec<String, T> { override fun decodeKey(byteBuffer: ByteBuffer): String { return Charset.defaultCharset().decode(byteBuffer).toString() } override fun decodeValue(byteBuffer: ByteBuffer): T = ObjectInputStream( ByteArrayInputStream(byteArrayCodec.decodeValue(byteBuffer)) ).use { readCodecObject(it) } abstract fun readCodecObject(it: ObjectInputStream): T override fun encodeKey(key: String): ByteBuffer { return Charset.defaultCharset().encode(key) } override fun encodeValue(ticketDto: T): ByteBuffer = ByteArrayOutputStream().use { baos -> ObjectOutputStream(baos).use { oos -> oos.writeObject(ticketDto) byteArrayCodec.encodeValue(baos.toByteArray()) } } companion object { val byteArrayCodec = ByteArrayCodec() } } inline fun <reified T : Any> ObjectInputStream.readTypedObject(): T = readObject() as T abstract class BuyOycType( open val type: AuditLogType = RECEIPT ) : Serializable abstract class BuyOycCodec<T> : RedisCodec<String, T> { override fun decodeKey(byteBuffer: ByteBuffer): String { return Charset.defaultCharset().decode(byteBuffer).toString() } override fun decodeValue(byteBuffer: ByteBuffer): T = ObjectInputStream( ByteArrayInputStream(byteArrayCodec.decodeValue(byteBuffer)) ).use { readCodecObject(it) } abstract fun readCodecObject(it: ObjectInputStream): T override fun encodeKey(key: String): ByteBuffer { return Charset.defaultCharset().encode(key) } override fun encodeValue(ticketDto: T): ByteBuffer = ByteArrayOutputStream().use { baos -> ObjectOutputStream(baos).use { oos -> oos.writeObject(ticketDto) byteArrayCodec.encodeValue(baos.toByteArray()) } } companion object { val byteArrayCodec = ByteArrayCodec() } } inline fun <reified T : Any> ObjectInputStream.readTypedObject(): T = readObject() as T As we can see, there are two important interfaces that our DTO types need to follow. They need to be Serializable , and they also need to be of type BuyOycType . This is just so that we can serialize them to Redis . The Serializable interface is normally not needed for just REST controllers. For those of you who don’t know what use is, this is an extremely sugary version of the try with resources in Java. If you use this in Kotlin, you might not even be aware that this is what use is doing, so beware if you don’t already know. DTO Serializable BuyOycType Redis Serializable Since we are also having a look at how the data model is created in Micronaut, it is important also to have a look at a few of the entities created. In this case, we’ll have a look at how some of the relations have been implemented by starting with the TicketReservation entity: @MappedEntity(namingStrategy = UnderScoreSeparatedLowerCase::class) data class TicketReservation( @field: Id @field: AutoPopulated var id: UUID? = null, val reference: UUID? = UUID.randomUUID(), val name: String, val address: String, val birthDate: LocalDate, val parkingReservation: ParkingReservation? = null, @field:DateCreated val createdAt: LocalDateTime? = LocalDateTime.now(), ) @MappedEntity(namingStrategy = UnderScoreSeparatedLowerCase::class) data class TicketReservation( @field: Id @field: AutoPopulated var id: UUID? = null, val reference: UUID? = UUID.randomUUID(), val name: String, val address: String, val birthDate: LocalDate, val parkingReservation: ParkingReservation? = null, @field:DateCreated val createdAt: LocalDateTime? = LocalDateTime.now(), ) The MappedEntity annotation allows us to create entities. In short, entities represent the way we handle tables via code. Micronaut has provisions like this, and if you know Hibernate, you are probably already familiar with Entity . For our purpose in this article, they are quite the same. Given that we are looking at a reactive model, actual database relations, especially complex ones like many-to-many , many-to-one , one-to-one and one-to-many make almost no sense. MappedEntity Entity many-to-many many-to-one one-to-one However, we can do something else using the Join annotation which seems to work quite well. One TicketReservation is personal, and so we can only associate one ParkingReservation with it. This is in every sense of the word a one-to-one relation. Once the car parking is reserved, only one customer can access it and only one parking can be used by one customer. This is a logic requirement because that way we can promise fair car parking usage to the attendees. Let’s look at the ParkingReservation implementation: TicketReservation ParkingReservation ParkingReservation @MappedEntity(namingStrategy = UnderScoreSeparatedLowerCase::class) data class ParkingReservation( @field: Id @field: AutoPopulated var id: UUID? = null, val reference: UUID? = UUID.randomUUID(), var carParking: CarParking? = null, @field:DateCreated val createdAt: LocalDateTime? = LocalDateTime.now() ) @MappedEntity(namingStrategy = UnderScoreSeparatedLowerCase::class) data class ParkingReservation( @field: Id @field: AutoPopulated var id: UUID? = null, val reference: UUID? = UUID.randomUUID(), var carParking: CarParking? = null, @field:DateCreated val createdAt: LocalDateTime? = LocalDateTime.now() ) In this case, the ParkingReservation is just a middleware table leading up to the actual CarParking table which defines the parking number. This is how we are allocating the parking space. The actual relation between tables is maintained with the Join annotation: ParkingReservation CarParking @R2dbcRepository(dialect = Dialect.POSTGRES) interface ParkingReservationRepository : CoroutineCrudRepository<ParkingReservation, UUID>, CoroutineJpaSpecificationExecutor<ParkingReservation> { @Join(value = "carParking", type = Join.Type.FETCH) override suspend fun findById(id: UUID): ParkingReservation } @R2dbcRepository(dialect = Dialect.POSTGRES) interface ParkingReservationRepository : CoroutineCrudRepository<ParkingReservation, UUID>, CoroutineJpaSpecificationExecutor<ParkingReservation> { @Join(value = "carParking", type = Join.Type.FETCH) override suspend fun findById(id: UUID): ParkingReservation } If you noticed, the ticket reservation entity itself does not have any reference to the drinks, meals or concert days reserved. This would be the case of a many ticket reservation to many concerts, many ticket reservation to many drinks, and many ticket reservations to many meals. It’s the many keyword in these relations that do not work well with the reactive architecture. In a blocking architecture, we would have defined a list of meals, a list of drinks and a list of concert days, defining thus many-to-many relations bound with each other seamlessly with a join table. Drinks and Meals are actually fixed items in a menu and what we really need is their reservation counterparts. Drinks While the relation between ticket reservation and drinks is a many-to-many relation, a relation between a ticket reservation and a drink reservation is a one-to-many relation. In other words, for each ticket reservation we have, we can make many drink reservations, but all of those reservations can only be associated to one ticket reservation, hence one to many. We can apply the same reasoning to the meal reservation and the concert reservation. In this project, we create the database using scripts that do use foreign keys, although in our code, we actually do not use and perform joins instead in an eager fashion. The following is an example of this: CREATE TABLE IF NOT EXISTS ticket.ticket_reservation ( id UUID NOT NULL, reference UUID NOT NULL UNIQUE, name varchar, address varchar, birth_date date, parking_reservation_id UUID NULL, created_at TIMESTAMP NOT NULL DEFAULT LOCALTIMESTAMP, PRIMARY KEY (id), FOREIGN KEY (parking_reservation_id) REFERENCES ticket.parking_reservation (id) ); CREATE TABLE IF NOT EXISTS ticket.ticket_reservation ( id UUID NOT NULL, reference UUID NOT NULL UNIQUE, name varchar, address varchar, birth_date date, parking_reservation_id UUID NULL, created_at TIMESTAMP NOT NULL DEFAULT LOCALTIMESTAMP, PRIMARY KEY (id), FOREIGN KEY (parking_reservation_id) REFERENCES ticket.parking_reservation (id) ); In Micronaut’s terms, just as in spring, a table is also called a relation. If you have noticed, all the important tables contain a reference field. This reference field keeps the number given to the customer in the ticket where they can retrieve the vouchers and tickets at the entrance when the concert starts. This is not implemented in this project, but it is important to mention its intention. The past table is therefore not used in this first instance. This is just an example to show the table styles being used. 4. Setting Up Kong After learning a bit on how the application is set up, we can finally start looking at the way Kong is set up. I’ve learned on a first instance to start Kong using a PostgreSQL database for persistence, a Kong migration image and finally the Kong service. Let’s look at a code snippet from the actual docker-compose.yaml file located at the root of the project: Kong PostgreSQL Kong services: kong-migrations-up: container_name: kong-migrations image: "${KONG_DOCKER_TAG:-kong:latest}" command: kong migrations bootstrap && kong migrations up && kong migrations finish depends_on: yucca-db: condition: service_healthy environment: <<: *kong-env secrets: - kong_postgres_password networks: - yucca-net kong: hostname: kong container_name: kong image: "${KONG_DOCKER_TAG:-kong:latest}" depends_on: yucca-db: condition: service_healthy buy-oyc-api: condition: service_healthy buy-oyc-ticket: condition: service_healthy buy-oyc-concert: condition: service_healthy buy-oyc-catering: condition: service_healthy buy-oyc-parking: condition: service_healthy kong-migrations-up: condition: service_completed_successfully user: "${KONG_USER:-kong}" environment: <<: *kong-env KONG_ADMIN_ACCESS_LOG: /dev/stdout KONG_ADMIN_ERROR_LOG: /dev/stderr KONG_PROXY_LISTEN: "${KONG_PROXY_LISTEN:-0.0.0.0:8000}" KONG_ADMIN_LISTEN: "${KONG_ADMIN_LISTEN:-0.0.0.0:8001}" KONG_PROXY_ACCESS_LOG: /dev/stdout KONG_PROXY_ERROR_LOG: /dev/stderr KONG_PREFIX: ${KONG_PREFIX:-/var/run/kong} KONG_ADMIN_GUI_URL: "http://0.0.0.0:8002" KONG_PORTAL_GUI_HOST: "0.0.0.0:8003" KONG_PORTAL: "on" KONG_LUA_PACKAGE_PATH: "./?.lua;./?/init.lua;" restart: on-failure secrets: - kong_postgres_password ports: - "127.0.0.1:8001:8001/tcp" - "127.0.0.1:8444:8444/tcp" - "8002:8002" - "8003:8003" healthcheck: test: [ "CMD", "kong", "health" ] interval: 10s timeout: 10s retries: 20 start_period: 0s volumes: - ./kong_prefix_vol:${KONG_PREFIX:-/var/run/kong} - ./kong_tmp_vol:/tmp - ./kong:/opt/kong - ./kong/kong-migration.sh:/opt/kong/kong-migration.sh security_opt: - no-new-privileges networks: yucca-net: kong-deck: hostname: kong-deck container_name: kong-deck image: kong/deck:v1.16.1 volumes: - ${PWD}/kong:/deck command: "--kong-addr http://kong:8001 -s /deck/kong.yaml sync" networks: yucca-net: depends_on: kong: condition: service_healthy yucca-db: condition: service_healthy buy-oyc-api: condition: service_healthy buy-oyc-ticket: condition: service_healthy buy-oyc-concert: condition: service_healthy buy-oyc-catering: condition: service_healthy buy-oyc-parking: condition: service_healthy kong-migrations-up: condition: service_completed_successfully yucca-db: hostname: yucca-db container_name: yucca-db image: postgres # user: ${YUCCA_USER_DB} command: postgres -c listen_addresses='*' -c 'max_connections=400' -c 'shared_buffers=100MB' environment: POSTGRES_DB: ${KONG_PG_DATABASE:-kong} POSTGRES_USER: ${KONG_PG_USER:-kong} POSTGRES_PASSWORD_FILE: /run/secrets/kong_postgres_password POSTGRES_MULTIPLE_DATABASES: yucca secrets: - kong_postgres_password healthcheck: test: [ "CMD", "pg_isready", "-U", "${KONG_PG_USER:-kong}" ] interval: 30s timeout: 30s retries: 10 start_period: 0s restart: on-failure stdin_open: true tty: true expose: - 5432 volumes: - ./kong_data_vol:/var/lib/postgresql/data - ./docker-images/docker-psql:/docker-entrypoint-initdb.d - ./docker-images/docker-psql/multiple:/docker-entrypoint-initdb.d/multiple networks: yucca-net: buy-oyc-ticket: hostname: buy-oyc-ticket container_name: buy-oyc-ticket depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-ticket-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db KONG_SERVICE_IP: kong networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8084/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-concert: hostname: buy-oyc-concert container_name: buy-oyc-concert depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-concert-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8085/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-parking: hostname: buy-oyc-parking container_name: buy-oyc-parking depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-parking-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8086/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-catering: hostname: buy-oyc-catering container_name: buy-oyc-catering depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-catering-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8087/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-api: hostname: buy-oyc-api container_name: buy-oyc-api depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-api-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db KONG_SERVICE_IP: kong networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8088/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-nginx: hostname: buy-oyc-nginx container_name: buy-oyc-nginx build: context: ./buy-odd-yucca-gui/. ports: - "8080:8080" restart: on-failure environment: - KONG_SERVICE_IP=kong deploy: resources: limits: memory: 300M reservations: memory: 300M networks: yucca-net: depends_on: kong: condition: service_healthy redis: container_name: redis image: redis ports: - "6379:6379" networks: yucca-net: secrets: kong_postgres_password: file: ./password services: kong-migrations-up: container_name: kong-migrations image: "${KONG_DOCKER_TAG:-kong:latest}" command: kong migrations bootstrap && kong migrations up && kong migrations finish depends_on: yucca-db: condition: service_healthy environment: <<: *kong-env secrets: - kong_postgres_password networks: - yucca-net kong: hostname: kong container_name: kong image: "${KONG_DOCKER_TAG:-kong:latest}" depends_on: yucca-db: condition: service_healthy buy-oyc-api: condition: service_healthy buy-oyc-ticket: condition: service_healthy buy-oyc-concert: condition: service_healthy buy-oyc-catering: condition: service_healthy buy-oyc-parking: condition: service_healthy kong-migrations-up: condition: service_completed_successfully user: "${KONG_USER:-kong}" environment: <<: *kong-env KONG_ADMIN_ACCESS_LOG: /dev/stdout KONG_ADMIN_ERROR_LOG: /dev/stderr KONG_PROXY_LISTEN: "${KONG_PROXY_LISTEN:-0.0.0.0:8000}" KONG_ADMIN_LISTEN: "${KONG_ADMIN_LISTEN:-0.0.0.0:8001}" KONG_PROXY_ACCESS_LOG: /dev/stdout KONG_PROXY_ERROR_LOG: /dev/stderr KONG_PREFIX: ${KONG_PREFIX:-/var/run/kong} KONG_ADMIN_GUI_URL: "http://0.0.0.0:8002" KONG_PORTAL_GUI_HOST: "0.0.0.0:8003" KONG_PORTAL: "on" KONG_LUA_PACKAGE_PATH: "./?.lua;./?/init.lua;" restart: on-failure secrets: - kong_postgres_password ports: - "127.0.0.1:8001:8001/tcp" - "127.0.0.1:8444:8444/tcp" - "8002:8002" - "8003:8003" healthcheck: test: [ "CMD", "kong", "health" ] interval: 10s timeout: 10s retries: 20 start_period: 0s volumes: - ./kong_prefix_vol:${KONG_PREFIX:-/var/run/kong} - ./kong_tmp_vol:/tmp - ./kong:/opt/kong - ./kong/kong-migration.sh:/opt/kong/kong-migration.sh security_opt: - no-new-privileges networks: yucca-net: kong-deck: hostname: kong-deck container_name: kong-deck image: kong/deck:v1.16.1 volumes: - ${PWD}/kong:/deck command: "--kong-addr http://kong:8001 -s /deck/kong.yaml sync" networks: yucca-net: depends_on: kong: condition: service_healthy yucca-db: condition: service_healthy buy-oyc-api: condition: service_healthy buy-oyc-ticket: condition: service_healthy buy-oyc-concert: condition: service_healthy buy-oyc-catering: condition: service_healthy buy-oyc-parking: condition: service_healthy kong-migrations-up: condition: service_completed_successfully yucca-db: hostname: yucca-db container_name: yucca-db image: postgres # user: ${YUCCA_USER_DB} command: postgres -c listen_addresses='*' -c 'max_connections=400' -c 'shared_buffers=100MB' environment: POSTGRES_DB: ${KONG_PG_DATABASE:-kong} POSTGRES_USER: ${KONG_PG_USER:-kong} POSTGRES_PASSWORD_FILE: /run/secrets/kong_postgres_password POSTGRES_MULTIPLE_DATABASES: yucca secrets: - kong_postgres_password healthcheck: test: [ "CMD", "pg_isready", "-U", "${KONG_PG_USER:-kong}" ] interval: 30s timeout: 30s retries: 10 start_period: 0s restart: on-failure stdin_open: true tty: true expose: - 5432 volumes: - ./kong_data_vol:/var/lib/postgresql/data - ./docker-images/docker-psql:/docker-entrypoint-initdb.d - ./docker-images/docker-psql/multiple:/docker-entrypoint-initdb.d/multiple networks: yucca-net: buy-oyc-ticket: hostname: buy-oyc-ticket container_name: buy-oyc-ticket depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-ticket-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db KONG_SERVICE_IP: kong networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8084/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-concert: hostname: buy-oyc-concert container_name: buy-oyc-concert depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-concert-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8085/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-parking: hostname: buy-oyc-parking container_name: buy-oyc-parking depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-parking-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8086/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-catering: hostname: buy-oyc-catering container_name: buy-oyc-catering depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-catering-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8087/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-api: hostname: buy-oyc-api container_name: buy-oyc-api depends_on: yucca-db: condition: service_healthy build: context: buy-oyc-api-service/. environment: REDIS_HOST: redis POSTGRESQL_HOST: yucca-db KONG_SERVICE_IP: kong networks: yucca-net: healthcheck: test: ["CMD", "curl", "--silent", "http://127.0.0.1:8088/swagger/views/swagger-ui/index.html"] interval: 5s timeout: 240s retries: 60 buy-oyc-nginx: hostname: buy-oyc-nginx container_name: buy-oyc-nginx build: context: ./buy-odd-yucca-gui/. ports: - "8080:8080" restart: on-failure environment: - KONG_SERVICE_IP=kong deploy: resources: limits: memory: 300M reservations: memory: 300M networks: yucca-net: depends_on: kong: condition: service_healthy redis: container_name: redis image: redis ports: - "6379:6379" networks: yucca-net: secrets: kong_postgres_password: file: ./password When Kong starts, we need to let it run the mode we prefer. Since I want the setup to be loaded at the startup of docker-compose , I have no choice but to say that I do not want to use the persistence model of Kong. The excerpt above is from the docker-compose-it.yaml , that I use exclusively for the integration tests. So, from top to bottom, we see firstly the declaration of the docker-migrations-up service. This is actually another Kong image that we are using as a runnable to perform migrations to the database. As mentioned before, this isn’t technically necessary for the integration tests. The second service is another Kong container that we are using to actually run Kong. There is really much to talk about in this setup, but for this article let’s just focus on port 8000 . docker-compose docker-compose-it.yaml Kong 8000 This port is what we are going to use to access all of our application APIs . Kong uses this port (or whatever we want to configure) as the gateway access-point to redirect all traffic to the destination API. If you noticed on the previous diagrams, there is never direct access to any of the APIs on any occasion. We’ll talk shortly about the other different ports available in Kong. But first, we look into the env variables. The specific Kong variables allow for several configurations. The ones that allow automatic setup loading are: APIs APIs KONG_DATABASE="off" KONG_DECLARATIVE_CONFIG="/opt/kong/kong.yaml KONG_DATABASE="off" KONG_DECLARATIVE_CONFIG="/opt/kong/kong.yaml For the KONG_DECLARATIVE_CONFIG , I’m getting the configuration there using volume ./kong:/opt/kong . Finally, we find the database. In this case, the volumes created allow the database to be initialised with this startup script available originally on: https://github.com/mrts/docker-postgresql-multiple-databases/blob/master/create-multiple-postgresql-databases.sh ' KONG_DECLARATIVE_CONFIG ./kong:/opt/kong https://github.com/mrts/docker-postgresql-multiple-databases/blob/master/create-multiple-postgresql-databases.sh #!/bin/bash # Credits to https://github.com/mrts/docker-postgresql-multiple-databases/blob/master/create-multiple-postgresql-databases.sh # This is an improvement of that file # To create an image, this file follows some rules # It is inspired by the way Spring scans for script and data files # The root folder of all script files must be docker-entrypoint-initdb.d/multiple/ # `multiple` is a choice. # Originally, the docker entrypoint located in /user/local/bin looks for all .sql, .gz and .xz files to import on docker-entrypoint-initdb.d/. # There is not clean way around this. Check the entrypoint details on https://github.com/docker-library/postgres/blob/master/docker-entrypoint.sh. # This script will search for sql files in the root folder docker-entrypoint-initdb.d/multiple/ prepended like schema-<database>.sql and data-<database>.sql # You can disable this by setting variable POSTGRES_SCAN_DISABLED to true # Databases are declared in POSTGRES_MULTIPLE_DATABASES as a comma separated string of database tags # You can specify a bundle of scripts to execute in a certain folder per database like so <database>:<folder> as one of these elements # If you wish to use folders with the same name as the database and don't want to use this notation then you have to set POSTGRES_FOLDER_MAPPING to true # To specify the database user use POSTGRES_USER # To specify the database password use POSTGRES_PASSWORD # The script creates a user with the given name who has the given password # It also creates another user with the database name and the given password per database created # If both match, then only one user is created with the database name and the given password # This script is available to download in a small example I've created in https://github.com/jesperancinha/project-signer/tree/master/docker-templates/docker-psql set -e set -u POSTGRES_SCAN_DISABLED="${POSTGRES_SCAN_DISABLED:-false}" POSTGRES_FOLDER_MAPPING="${POSTGRES_FOLDER_MAPPING:-false}" function create_user_and_database() { database=$(echo "$command" | awk -F':' '{print $1}') echo " Creating user and database '$database'" psql -v ON_ERROR_STOP=1 --username "$POSTGRES_USER" -tc "SELECT 1 FROM pg_user WHERE usename = '$database'" | grep -q 1 || psql -v ON_ERROR_STOP=1 --username "$POSTGRES_USER" <<-EOSQL CREATE USER $database with PASSWORD '$POSTGRES_PASSWORD'; CREATE DATABASE $database; GRANT ALL PRIVILEGES ON DATABASE $database TO $database; EOSQL } function import_file_to_database() { echo "Importing file $2 to database $1..." psql -U "$POSTGRES_USER" -d "$1" -f "$2" } function import_files_from_folder() { directory=$1 database=$2 echo "Database bundle $directory for database $database requested" if [ -d "$directory" ]; then for script in "$directory"/*.sql; do echo "Request importing file $script to database $database" import_file_to_database "$database" "$script" done else echo "WARNING: No script bundle directory found for database $database" fi } function create_and_import_files() { local rootDir="docker-entrypoint-initdb.d/multiple/" if [ -n "$POSTGRES_MULTIPLE_DATABASES" ]; then echo "Multiple database creation requested: $POSTGRES_MULTIPLE_DATABASES" for command in $(echo "$POSTGRES_MULTIPLE_DATABASES" | tr ',' ' '); do create_user_and_database "$command" if [[ "$command" == *":"* ]]; then database=$(echo "$command" | awk -F':' '{print $1}') directory=$rootDir$(echo "$command" | awk -F':' '{print $2}') import_files_from_folder "$directory" "$database" elif [ "$POSTGRES_FOLDER_MAPPING" == true ]; then if [[ "$command" != *":"* ]]; then import_files_from_folder "$rootDir$database" "$database" fi fi if [ "$POSTGRES_SCAN_DISABLED" != true ]; then database=$(echo "$command" | awk -F':' '{print $1}') echo "Auto-scanning files for database $database" echo "Auto-scanning schema files" schema_file=$rootDir"schema-$database.sql" if [ -f "$schema_file" ]; then import_file_to_database "$database" "$schema_file" echo "Auto-scanning data files" schema_data=$rootDir"data-$database.sql" if [ -f "$schema_data" ]; then import_file_to_database "$database" "$schema_data" else echo "WARNING: No data file detected for database $database" fi else echo "WARNING: No schema file detected for database $database" fi fi done echo "Multiple databases created" fi } create_and_import_files #!/bin/bash # Credits to https://github.com/mrts/docker-postgresql-multiple-databases/blob/master/create-multiple-postgresql-databases.sh # This is an improvement of that file # To create an image, this file follows some rules # It is inspired by the way Spring scans for script and data files # The root folder of all script files must be docker-entrypoint-initdb.d/multiple/ # `multiple` is a choice. # Originally, the docker entrypoint located in /user/local/bin looks for all .sql, .gz and .xz files to import on docker-entrypoint-initdb.d/. # There is not clean way around this. Check the entrypoint details on https://github.com/docker-library/postgres/blob/master/docker-entrypoint.sh. # This script will search for sql files in the root folder docker-entrypoint-initdb.d/multiple/ prepended like schema-<database>.sql and data-<database>.sql # You can disable this by setting variable POSTGRES_SCAN_DISABLED to true # Databases are declared in POSTGRES_MULTIPLE_DATABASES as a comma separated string of database tags # You can specify a bundle of scripts to execute in a certain folder per database like so <database>:<folder> as one of these elements # If you wish to use folders with the same name as the database and don't want to use this notation then you have to set POSTGRES_FOLDER_MAPPING to true # To specify the database user use POSTGRES_USER # To specify the database password use POSTGRES_PASSWORD # The script creates a user with the given name who has the given password # It also creates another user with the database name and the given password per database created # If both match, then only one user is created with the database name and the given password # This script is available to download in a small example I've created in https://github.com/jesperancinha/project-signer/tree/master/docker-templates/docker-psql set -e set -u POSTGRES_SCAN_DISABLED="${POSTGRES_SCAN_DISABLED:-false}" POSTGRES_FOLDER_MAPPING="${POSTGRES_FOLDER_MAPPING:-false}" function create_user_and_database() { database=$(echo "$command" | awk -F':' '{print $1}') echo " Creating user and database '$database'" psql -v ON_ERROR_STOP=1 --username "$POSTGRES_USER" -tc "SELECT 1 FROM pg_user WHERE usename = '$database'" | grep -q 1 || psql -v ON_ERROR_STOP=1 --username "$POSTGRES_USER" <<-EOSQL CREATE USER $database with PASSWORD '$POSTGRES_PASSWORD'; CREATE DATABASE $database; GRANT ALL PRIVILEGES ON DATABASE $database TO $database; EOSQL } function import_file_to_database() { echo "Importing file $2 to database $1..." psql -U "$POSTGRES_USER" -d "$1" -f "$2" } function import_files_from_folder() { directory=$1 database=$2 echo "Database bundle $directory for database $database requested" if [ -d "$directory" ]; then for script in "$directory"/*.sql; do echo "Request importing file $script to database $database" import_file_to_database "$database" "$script" done else echo "WARNING: No script bundle directory found for database $database" fi } function create_and_import_files() { local rootDir="docker-entrypoint-initdb.d/multiple/" if [ -n "$POSTGRES_MULTIPLE_DATABASES" ]; then echo "Multiple database creation requested: $POSTGRES_MULTIPLE_DATABASES" for command in $(echo "$POSTGRES_MULTIPLE_DATABASES" | tr ',' ' '); do create_user_and_database "$command" if [[ "$command" == *":"* ]]; then database=$(echo "$command" | awk -F':' '{print $1}') directory=$rootDir$(echo "$command" | awk -F':' '{print $2}') import_files_from_folder "$directory" "$database" elif [ "$POSTGRES_FOLDER_MAPPING" == true ]; then if [[ "$command" != *":"* ]]; then import_files_from_folder "$rootDir$database" "$database" fi fi if [ "$POSTGRES_SCAN_DISABLED" != true ]; then database=$(echo "$command" | awk -F':' '{print $1}') echo "Auto-scanning files for database $database" echo "Auto-scanning schema files" schema_file=$rootDir"schema-$database.sql" if [ -f "$schema_file" ]; then import_file_to_database "$database" "$schema_file" echo "Auto-scanning data files" schema_data=$rootDir"data-$database.sql" if [ -f "$schema_data" ]; then import_file_to_database "$database" "$schema_data" else echo "WARNING: No data file detected for database $database" fi else echo "WARNING: No schema file detected for database $database" fi fi done echo "Multiple databases created" fi } create_and_import_files This script essentially allows for the creation of different databases based on their different names and folder names and use different data.sql and schema.sql scripts. It makes the code cleaner and easier to use. The file I am using has been developed from this one. Finally, we can look at the Kong file, kong.yaml , which sets up the ports, the URLs, and the mappings: kong.yaml _format_version: "3.0" _transform: true services: # Ticket Service - url: http://buy-oyc-ticket:8084/api/yucca-ticket/swagger/views/swagger-ui/res name: buy-oyc-ticket-swagger-ui protocol: http routes: - name: buy-oyc-ticket-service-route-swagger-ui paths: - /api/yucca-ticket/swagger-ui/res strip_path: true - url: http://buy-oyc-ticket:8084/api/yucca-ticket/swagger name: buy-oyc-ticket-swagger protocol: http routes: - name: buy-oyc-ticket-service-route-swagger paths: - /api/yucca-ticket/swagger strip_path: true - url: http://buy-oyc-ticket:8084/api/yucca-ticket/api name: buy-oyc-ticket protocol: http routes: - name: buy-oyc-ticket-service-route paths: - /api/yucca-ticket/api strip_path: true - url: http://buy-oyc-ticket:8084/api/yucca-ticket name: buy-oyc-ticket-rest protocol: http routes: - name: buy-oyc-ticket-service-route-root paths: - /api/yucca-ticket strip_path: true # Concert Service - url: http://buy-oyc-concert:8085/api/yucca-concert/swagger/views/swagger-ui/res name: buy-oyc-concert-swagger-ui protocol: http routes: - name: buy-oyc-concert-service-route-swagger-ui paths: - /api/yucca-concert/swagger-ui/res strip_path: true - url: http://buy-oyc-concert:8085/api/yucca-concert/swagger name: buy-oyc-concert-swagger protocol: http routes: - name: buy-oyc-concert-service-route-swagger paths: - /api/yucca-concert/swagger strip_path: true - url: http://buy-oyc-concert:8085/api/yucca-concert/api name: buy-oyc-concert protocol: http routes: - name: buy-oyc-concert-service-route paths: - /api/yucca-concert/api strip_path: true - url: http://buy-oyc-concert:8085/api/yucca-concert name: buy-oyc-concert-rest protocol: http routes: - name: buy-oyc-concert-service-route-root paths: - /api/yucca-concert strip_path: true # Parking Service - url: http://buy-oyc-parking:8086/api/yucca-parking/swagger/views/swagger-ui/res name: buy-oyc-parking-swagger-ui protocol: http routes: - name: buy-oyc-parking-service-route-swagger-ui paths: - /api/yucca-parking/swagger-ui/res strip_path: true - url: http://buy-oyc-parking:8086/api/yucca-parking/swagger name: buy-oyc-parking-swagger protocol: http routes: - name: buy-oyc-parking-service-route-swagger paths: - /api/yucca-parking/swagger strip_path: true - url: http://buy-oyc-parking:8086/api/yucca-parking/api name: buy-oyc-parking protocol: http routes: - name: buy-oyc-parking-service-route paths: - /api/yucca-parking/api strip_path: true - url: http://buy-oyc-parking:8086/api/yucca-parking name: buy-oyc-parking-rest protocol: http routes: - name: buy-oyc-parking-service-route-root paths: - /api/yucca-parking strip_path: true # Catering Service - url: http://buy-oyc-catering:8087/api/yucca-catering/swagger/views/swagger-ui/res name: buy-oyc-catering-swagger-ui protocol: http routes: - name: buy-oyc-catering-service-route-swagger-ui paths: - /api/yucca-catering/swagger-ui/res strip_path: true - url: http://buy-oyc-catering:8087/api/yucca-catering/swagger name: buy-oyc-catering-swagger protocol: http routes: - name: buy-oyc-catering-service-route-swagger paths: - /api/yucca-catering/swagger strip_path: true - url: http://buy-oyc-catering:8087/api/yucca-catering/api name: buy-oyc-catering protocol: http routes: - name: buy-oyc-catering-service-route paths: - /api/yucca-catering/api strip_path: true - url: http://buy-oyc-catering:8087/api/yucca-catering name: buy-oyc-catering-rest protocol: http routes: - name: buy-oyc-catering-service-route-root paths: - /api/yucca-catering strip_path: true # API Service - url: http://buy-oyc-api:8088/api/yucca-api/swagger/views/swagger-ui/res name: buy-oyc-api-swagger-ui protocol: http routes: - name: buy-oyc-api-service-route-swagger-ui paths: - /api/yucca-api/swagger-ui/res strip_path: true - url: http://buy-oyc-api:8088/api/yucca-api/swagger name: buy-oyc-api-swagger protocol: http routes: - name: buy-oyc-api-service-route-swagger paths: - /api/yucca-api/swagger strip_path: true - url: http://buy-oyc-api:8088/api/yucca-api/api name: buy-oyc-api protocol: http routes: - name: buy-oyc-api-service-route paths: - /api/yucca-api/api strip_path: true - url: http://buy-oyc-api:8088/api/yucca-api name: buy-oyc-api-rest protocol: http routes: - name: buy-oyc-api-service-route-root paths: - /api/yucca-api strip_path: true _format_version: "3.0" _transform: true services: # Ticket Service - url: http://buy-oyc-ticket:8084/api/yucca-ticket/swagger/views/swagger-ui/res name: buy-oyc-ticket-swagger-ui protocol: http routes: - name: buy-oyc-ticket-service-route-swagger-ui paths: - /api/yucca-ticket/swagger-ui/res strip_path: true - url: http://buy-oyc-ticket:8084/api/yucca-ticket/swagger name: buy-oyc-ticket-swagger protocol: http routes: - name: buy-oyc-ticket-service-route-swagger paths: - /api/yucca-ticket/swagger strip_path: true - url: http://buy-oyc-ticket:8084/api/yucca-ticket/api name: buy-oyc-ticket protocol: http routes: - name: buy-oyc-ticket-service-route paths: - /api/yucca-ticket/api strip_path: true - url: http://buy-oyc-ticket:8084/api/yucca-ticket name: buy-oyc-ticket-rest protocol: http routes: - name: buy-oyc-ticket-service-route-root paths: - /api/yucca-ticket strip_path: true # Concert Service - url: http://buy-oyc-concert:8085/api/yucca-concert/swagger/views/swagger-ui/res name: buy-oyc-concert-swagger-ui protocol: http routes: - name: buy-oyc-concert-service-route-swagger-ui paths: - /api/yucca-concert/swagger-ui/res strip_path: true - url: http://buy-oyc-concert:8085/api/yucca-concert/swagger name: buy-oyc-concert-swagger protocol: http routes: - name: buy-oyc-concert-service-route-swagger paths: - /api/yucca-concert/swagger strip_path: true - url: http://buy-oyc-concert:8085/api/yucca-concert/api name: buy-oyc-concert protocol: http routes: - name: buy-oyc-concert-service-route paths: - /api/yucca-concert/api strip_path: true - url: http://buy-oyc-concert:8085/api/yucca-concert name: buy-oyc-concert-rest protocol: http routes: - name: buy-oyc-concert-service-route-root paths: - /api/yucca-concert strip_path: true # Parking Service - url: http://buy-oyc-parking:8086/api/yucca-parking/swagger/views/swagger-ui/res name: buy-oyc-parking-swagger-ui protocol: http routes: - name: buy-oyc-parking-service-route-swagger-ui paths: - /api/yucca-parking/swagger-ui/res strip_path: true - url: http://buy-oyc-parking:8086/api/yucca-parking/swagger name: buy-oyc-parking-swagger protocol: http routes: - name: buy-oyc-parking-service-route-swagger paths: - /api/yucca-parking/swagger strip_path: true - url: http://buy-oyc-parking:8086/api/yucca-parking/api name: buy-oyc-parking protocol: http routes: - name: buy-oyc-parking-service-route paths: - /api/yucca-parking/api strip_path: true - url: http://buy-oyc-parking:8086/api/yucca-parking name: buy-oyc-parking-rest protocol: http routes: - name: buy-oyc-parking-service-route-root paths: - /api/yucca-parking strip_path: true # Catering Service - url: http://buy-oyc-catering:8087/api/yucca-catering/swagger/views/swagger-ui/res name: buy-oyc-catering-swagger-ui protocol: http routes: - name: buy-oyc-catering-service-route-swagger-ui paths: - /api/yucca-catering/swagger-ui/res strip_path: true - url: http://buy-oyc-catering:8087/api/yucca-catering/swagger name: buy-oyc-catering-swagger protocol: http routes: - name: buy-oyc-catering-service-route-swagger paths: - /api/yucca-catering/swagger strip_path: true - url: http://buy-oyc-catering:8087/api/yucca-catering/api name: buy-oyc-catering protocol: http routes: - name: buy-oyc-catering-service-route paths: - /api/yucca-catering/api strip_path: true - url: http://buy-oyc-catering:8087/api/yucca-catering name: buy-oyc-catering-rest protocol: http routes: - name: buy-oyc-catering-service-route-root paths: - /api/yucca-catering strip_path: true # API Service - url: http://buy-oyc-api:8088/api/yucca-api/swagger/views/swagger-ui/res name: buy-oyc-api-swagger-ui protocol: http routes: - name: buy-oyc-api-service-route-swagger-ui paths: - /api/yucca-api/swagger-ui/res strip_path: true - url: http://buy-oyc-api:8088/api/yucca-api/swagger name: buy-oyc-api-swagger protocol: http routes: - name: buy-oyc-api-service-route-swagger paths: - /api/yucca-api/swagger strip_path: true - url: http://buy-oyc-api:8088/api/yucca-api/api name: buy-oyc-api protocol: http routes: - name: buy-oyc-api-service-route paths: - /api/yucca-api/api strip_path: true - url: http://buy-oyc-api:8088/api/yucca-api name: buy-oyc-api-rest protocol: http routes: - name: buy-oyc-api-service-route-root paths: - /api/yucca-api strip_path: true This mapping is loaded directly with the integration tests. If we just run our setup locally, we then use a different approach. First, we use docker-compose up. This starts up everything and all the containers until it stabilizes. Once the start-up has finished, we need to inject this configuration file manually into Kong . For that, Kong , makes a small utility available to install called deck. Please check their website to find out more about how to install it. In the Makefile , I’ve created, there is an instruction we can use to do this automatically, where I’m using a small bash polling trick to find out if Kong has started or not. The polling itself is located in the kong_wait.sh file: docker-compose start-up Kong Kong Makefile kong_wait.sh #!/bin/bash function checkServiceByNameAndMessage() { name=$1 message=$2 printf "%s." "$name" docker-compose logs "$name" &> "logs" string=$(cat logs) echo "$string" counter=0 while [[ "$string" != *"$message"* ]] do printf "." docker-compose logs "$name" &> "logs" string=$(cat logs) sleep 1 counter=$((counter+1)) if [ $counter -eq 200 ]; then echo "Failed after $counter tries! Cypress tests mail fail!!" echo "$string" exit 1 fi if [[ "$string" = *"[PostgreSQL error] failed to retrieve PostgreSQL"* ]]; then echo "Failed PostgreSQL connection after $counter tries! Cypress tests mail fail!!" echo "$string" exit 1 fi done counter=$((counter+1)) echo "succeeded $name Service after $counter tries!" } checkServiceByNameAndMessage kong 'init_worker_by_lua' #!/bin/bash function checkServiceByNameAndMessage() { name=$1 message=$2 printf "%s." "$name" docker-compose logs "$name" &> "logs" string=$(cat logs) echo "$string" counter=0 while [[ "$string" != *"$message"* ]] do printf "." docker-compose logs "$name" &> "logs" string=$(cat logs) sleep 1 counter=$((counter+1)) if [ $counter -eq 200 ]; then echo "Failed after $counter tries! Cypress tests mail fail!!" echo "$string" exit 1 fi if [[ "$string" = *"[PostgreSQL error] failed to retrieve PostgreSQL"* ]]; then echo "Failed PostgreSQL connection after $counter tries! Cypress tests mail fail!!" echo "$string" exit 1 fi done counter=$((counter+1)) echo "succeeded $name Service after $counter tries!" } checkServiceByNameAndMessage kong 'init_worker_by_lua' Finally, in the Makefile we can see this snipped, which calls it: Makefile create-folders: mkdir -p kong_prefix_vol kong_tmp_vol kong_data_vol set-permissions: if [[ -d kong_data_vol ]]; then sudo chmod -R 777 kong_data_vol; else mkdir kong_data_vol && sudo chmod -R 777 kong_data_vol; fi if [[ -d kong_tmp_vol ]]; then sudo chmod -R 777 kong_tmp_vol; else mkdir kong_tmp_vol && sudo chmod -R 777 kong_tmp_vol; fi if [[ -d kong_prefix_vol ]]; then sudo chmod -R 777 kong_prefix_vol; else mkdir kong_prefix_vol && sudo chmod -R 777 kong_prefix_vol; fi docker: create-folders set-permissions docker-compose up -d --build --remove-orphans create-folders: mkdir -p kong_prefix_vol kong_tmp_vol kong_data_vol set-permissions: if [[ -d kong_data_vol ]]; then sudo chmod -R 777 kong_data_vol; else mkdir kong_data_vol && sudo chmod -R 777 kong_data_vol; fi if [[ -d kong_tmp_vol ]]; then sudo chmod -R 777 kong_tmp_vol; else mkdir kong_tmp_vol && sudo chmod -R 777 kong_tmp_vol; fi if [[ -d kong_prefix_vol ]]; then sudo chmod -R 777 kong_prefix_vol; else mkdir kong_prefix_vol && sudo chmod -R 777 kong_prefix_vol; fi docker: create-folders set-permissions docker-compose up -d --build --remove-orphans What’s important to know is that the kong.yaml file is a configuration file for the endpoints. In terms of rate limiting, we can use REST calls. kong.yaml 5. Running Kong As I mentioned before, port 8000 is crucial, in order to access the different APIs and allow Kong to perform gateway filtration on the requests. In this whole project, we are looking at rate-limiting. Rate-limiting can be applied to paths and the different APIs individually. We can see every definition of these APIs using individually another Kong API . This API is opened, and following our own configuration, on port 8001. In this section, we are going to run our application, so for now, please run this command at the root: 8000 APIs APIs APIs Kong API API make docker make docker This will run the docker command we have seen earlier. If all runs smoothly, you should get all containers running. Once this is done, please open your browser on http://localhost:8001 . Here, you’ll find a list of all sorts of configurations inside Kong. This is just a warmup look. Now, please have a look at this URL: http://localhost:8001/plugins . You should see a list of plugins. One of them could be something similar to this: http://localhost:8001 http://localhost:8001/plugins This means that rate-limiting is active, and in this case, we have a limitation of 1 request per second and 10000 requests per hour. It is also important to know at this point that Kong will not allow you to make overlapping configurations. For example, if you only allow to make 1 request per hour, this means that you can only make 60 * 60 = 3600 request per second. If you configure any more than that for seconds, then Kong will rightfully let you know that the second limitation conflicts with the hour limitation, and it will return a message like this one: rate-limiting 10000 60 * 60 = 3600 But for now, we have no plugin configured, so let’s start. In your command line, please run the following: curl -i -X POST http://localhost:8001/services/buy-oyc-ticket-service/plugins \ --data "name=rate-limiting" \ --data "config.second=1" \ --data "config.hour=10000" \ --data "config.policy=local" \ --data "config.fault_tolerant=true" \ --data "config.hide_client_headers=false" curl -i -X POST http://localhost:8001/services/buy-oyc-ticket-service/plugins \ --data "name=rate-limiting" \ --data "config.second=1" \ --data "config.hour=10000" \ --data "config.policy=local" \ --data "config.fault_tolerant=true" \ --data "config.hide_client_headers=false" This just means that the API now has a plugin that in practice, only allows up to 1 request per second to be pushed through the gateway. Essentially, we are limiting our concerts to be created at the rate of 1 per second. All others will be getting an error. We want, in this case, to be as transparent as possible in our analysis and how we go about evaluating the requests. This is why we set up the default values of local, true, and false to config.policy , config.fault_tolerant and config.hide_client_headers respectively. Now, we are ready to start locus. On another command line, please run the following: config.policy config.fault_tolerant config.hide_client_headers make locust-start make locust-start This will start locust. If you do not know locust, this is essentially a benchmark tool. Find out how to install it directly at the source. We aren’t interested in making performance tests. Instead, we want to see in practice how rate-limiting is working in practice. Perhaps now is a good idea to have a look at our test cases. Let’s first have a look at the task script in Python located at /locust/welcome : /locust/welcome import requests from locust import HttpUser, task, constant_throughput class BuyOddYuccaConcert(HttpUser): wait_time = constant_throughput(1) @task def yucca_ticket_welcome_message(self): send_payload( name="будинок", address="будинок Адреса", birth_date="1979-01-01", concert_id="5359A368-CA49-4027-BC25-F375E3EA2463", drink_id="B2A5E349-76E7-4CD6-8105-308D1BC94953", meal_id="59B97053-37CF-4FAF-AB50-E77CEF8E8CC8") send_payload( name="Home", address="Home Address", birth_date="1979-01-01", concert_id="2E4522B1-D9FF-4B2B-9FFA-052CBAD9D5F2", drink_id="B2A5E349-76E7-4CD6-8105-308D1BC94953", meal_id="59B97053-37CF-4FAF-AB50-E77CEF8E8CC8") import requests from locust import HttpUser, task, constant_throughput class BuyOddYuccaConcert(HttpUser): wait_time = constant_throughput(1) @task def yucca_ticket_welcome_message(self): send_payload( name="будинок", address="будинок Адреса", birth_date="1979-01-01", concert_id="5359A368-CA49-4027-BC25-F375E3EA2463", drink_id="B2A5E349-76E7-4CD6-8105-308D1BC94953", meal_id="59B97053-37CF-4FAF-AB50-E77CEF8E8CC8") send_payload( name="Home", address="Home Address", birth_date="1979-01-01", concert_id="2E4522B1-D9FF-4B2B-9FFA-052CBAD9D5F2", drink_id="B2A5E349-76E7-4CD6-8105-308D1BC94953", meal_id="59B97053-37CF-4FAF-AB50-E77CEF8E8CC8") These IDs are references to data in our database. I am fixing the request to perform minimally one time per second. In locust terms, this means that every locust performs this task once per second. Since the task performs two post requests, this means that we are minimally making 2 requests per second. The requests are fixed. The function that is being called, makes a call to the API : API def send_payload(name, address, birth_date, concert_id, drink_id, meal_id): payload = { "name": name, "address": address, "birthDate": birth_date, "concertDays": [ { "concertId": concert_id } ], "meals": [ { "mealId": meal_id } ], "drinks": [ { "drinkId": drink_id } ], "parkingReservation": [ { "carParkingId": 1 } ] } r = requests.post('http://localhost:8000/api/yucca-api/api', json=payload) print( f"Person: {name} living in {address} born on {birth_date}, " f"just reserved concert {concert_id} with drink {drink_id} and meal {meal_id}, " f"Status Code: {r.status_code}, " f"Response: {r.json()}") def send_payload(name, address, birth_date, concert_id, drink_id, meal_id): payload = { "name": name, "address": address, "birthDate": birth_date, "concertDays": [ { "concertId": concert_id } ], "meals": [ { "mealId": meal_id } ], "drinks": [ { "drinkId": drink_id } ], "parkingReservation": [ { "carParkingId": 1 } ] } r = requests.post('http://localhost:8000/api/yucca-api/api', json=payload) print( f"Person: {name} living in {address} born on {birth_date}, " f"just reserved concert {concert_id} with drink {drink_id} and meal {meal_id}, " f"Status Code: {r.status_code}, " f"Response: {r.json()}") The payload is just a representation of the general format for one person who makes a reservation for one drink, one meal, one parking space, and one concert day. We are going to use this data in order to make sure we can perform our tests: insert into ticket.car_parking (id, parking_number) values ('E3BB8287-8F4F-477B-AFDF-44D78665A08C', 1); insert into ticket.car_parking (id, parking_number) values ('23745A3C-9426-4E92-A940-89E07C2ED24D', 2); insert into ticket.car_parking (id, parking_number) values ('27728F31-244A-4469-81AC-86B332E7BD1B', 3); insert into ticket.car_parking (id, parking_number) values ('0892A233-4973-4477-A6DA-91E44E1386D3', 4); insert into ticket.car_parking (id, parking_number) values ('61BF1E61-A7C2-4D6E-951A-8E97BD4E4FB3', 5); insert into ticket.concert_day(id, name, description, concert_date) values ('5359A368-CA49-4027-BC25-F375E3EA2463', 'Jamala', '', now()); insert into ticket.concert_day(id, name, description, concert_date) values ('2E4522B1-D9FF-4B2B-9FFA-052CBAD9D5F2', 'Kalush Orchestra', '', now()); insert into ticket.drink(id, name, width, height, shape, volume, price) values ('2377198D-9E41-4134-8E89-ABD66FE0C59B', 'Varenukha', 10, 10, 10, 10, 10); insert into ticket.drink(id, name, width, height, shape, volume, price) values ('B2A5E349-76E7-4CD6-8105-308D1BC94953', 'Uzvar', 10, 10, 10, 10, 10); insert into ticket.meal(id, coupon , box_type, discount, price, processed) values ('59B97053-37CF-4FAF-AB50-E77CEF8E8CC8', gen_random_uuid(), 'XS', 10, 10, false); insert into ticket.meal(id, coupon , box_type, discount, price, processed) values ('4581DECF-7740-44E8-8B2C-B7EC0FEE31C3', gen_random_uuid(), 'XS', 10, 10, false); insert into ticket.car_parking (id, parking_number) values ('E3BB8287-8F4F-477B-AFDF-44D78665A08C', 1); insert into ticket.car_parking (id, parking_number) values ('23745A3C-9426-4E92-A940-89E07C2ED24D', 2); insert into ticket.car_parking (id, parking_number) values ('27728F31-244A-4469-81AC-86B332E7BD1B', 3); insert into ticket.car_parking (id, parking_number) values ('0892A233-4973-4477-A6DA-91E44E1386D3', 4); insert into ticket.car_parking (id, parking_number) values ('61BF1E61-A7C2-4D6E-951A-8E97BD4E4FB3', 5); insert into ticket.concert_day(id, name, description, concert_date) values ('5359A368-CA49-4027-BC25-F375E3EA2463', 'Jamala', '', now()); insert into ticket.concert_day(id, name, description, concert_date) values ('2E4522B1-D9FF-4B2B-9FFA-052CBAD9D5F2', 'Kalush Orchestra', '', now()); insert into ticket.drink(id, name, width, height, shape, volume, price) values ('2377198D-9E41-4134-8E89-ABD66FE0C59B', 'Varenukha', 10, 10, 10, 10, 10); insert into ticket.drink(id, name, width, height, shape, volume, price) values ('B2A5E349-76E7-4CD6-8105-308D1BC94953', 'Uzvar', 10, 10, 10, 10, 10); insert into ticket.meal(id, coupon , box_type, discount, price, processed) values ('59B97053-37CF-4FAF-AB50-E77CEF8E8CC8', gen_random_uuid(), 'XS', 10, 10, false); insert into ticket.meal(id, coupon , box_type, discount, price, processed) values ('4581DECF-7740-44E8-8B2C-B7EC0FEE31C3', gen_random_uuid(), 'XS', 10, 10, false); Now, we are ready to fire our locust tests. If you noticed, you have in your command line logs like this one: If you are running a good terminal, you should be able to click on the link, and go straight to http://localhost:8089 : http://localhost:8089 Just let it be the way it is. It will start with one user, and it will spawn more users at a rate of 1 per second. This means that, since we configured Kong to make requests at a rate of 1 request per second max, on the yucca-api gateway, we are just barely on the edge of sending requests to the gateway. We will get errors. Our logs will look like this: So Kong, now configured to accept only one request per second, won’t be able to accept 2 requests per second, which, if you noticed from before, is exactly what our locust task does. Let’s leave locust running. In our command line, you should have gotten something like this when you ran the first request: What this means is that we have activated a plugin, and we named it rate-limiting. This is also a key to the map of plugins that we could activate for Kong. We now want to change the rate, so we need to remove this plugin and create a new one. For this case, we need to indicate the ID of the plugin we want to remove. In our case, it is: 0ff09073–3e16–4442-ac78–428b25818b7f : 0ff09073–3e16–4442-ac78–428b25818b7f curl -X DELETE http://localhost:8081/plugins/0ff09073–3e16–4442-ac78–428b25818b7f curl -X DELETE http://localhost:8081/plugins/0ff09073–3e16–4442-ac78–428b25818b7f Now, I’ll show you how we can change this live on the fly. Just make sure that Locust is still running. Run this command now: curl -i -X POST http://localhost:8001/services/buy-oyc-ticket-service/plugins \ --data "name=rate-limiting" \ --data "config.second=2" \ --data "config.hour=10000" \ --data "config.policy=local" \ --data "config.fault_tolerant=true" \ --data "config.hide_client_headers=false" curl -i -X POST http://localhost:8001/services/buy-oyc-ticket-service/plugins \ --data "name=rate-limiting" \ --data "config.second=2" \ --data "config.hour=10000" \ --data "config.policy=local" \ --data "config.fault_tolerant=true" \ --data "config.hide_client_headers=false" You should not be getting any errors now: From this point onwards, you should understand how to change the rate to other requests. Feel free to give it a go and try different combinations on all sub-requests. 6. Questions and Answers "How do we know when the ticket is complete in the back end?" Since we process the ticket asynchronously, there is actually no way of knowing this in an asynchronous way. The last thing we want is to join all of these processes and wait for them to finish somewhere. It is also not something possible, since the different services should be allowed to work on different machines, areas, regions, and domains, making multithread control impossible. What can be done is some sort of polling system to check when all the database elements have been received and persisted correctly into the database. It should be made in a separate service that would crawl through the database and verify this information. 7. Conclusion Thanks for following this project with me and for being open to seeing how everything works. I hope to have given you a good introduction to the basics of rate-limiting in Kong. Using Kong, we can do much more than just rate-limiting. There are endless choices and possibilities using Kong. Regarding Micronaut, I truly believe that it is a great competitor to Spring, and I especially like the idea that it brings me focus to engineering problems rather than the current hype around code beauty. This is something I didn’t really experience with Spring . Spring With Micronaut , just as an example I was forced to think about annotation processors and select which one of them was important for my development. This is something I have not seen in other Enterprise frameworks. Where Micronaut forces us to think about what we do on a very low level, other frameworks seem to do a lot of things for us, which can be a bittersweet present. Regarding Kotlin , this project led me to further deepen my doubts about this new language and what seems to be a technology sweeping everyone off their feet. Micronaut Kotlin I have to be honest here, if I compare the way Java has been developing and the way Kotlin has burst into the IT scene, I think my soul remains divided. Although there is a lot of beauty related to this new language, it is starting to look more like the Beauty of the JVM world rather than an engineering-oriented language. I can say that using things like by, reified and not having to think if I’m implementing or extending has also removed quite a bit of the lexicon of the language, and we need lexicon and semantics in our thought process. Kotlin This whole philosophy brought by Kotlin about "not having to" also spread to the use of utility functions that we now make as extension functions. Sometimes, you see them in interfaces, classes, companion objects, or wherever they can be, and you’ll find them very much compliant with Murphy’s Law for the good or the worse. Now, is there a problem with this? Not directly, but I have already witnessed too many style discussions in the Kotlin world that I didn’t see in the Java world. Kotlin For example, using findById()? is "so ugly, how could you do that?", because "findByIdOrNull is more Kotlin-like." There are studies that show that shortcuts and fragmenting a language (not just programming) can potentially impair the way we think because it limits our expression choices. But hey, I’m just not allowing myself to jump into the idea that Java is worse than Kotlin . Kotlin In this project, there is a lot that I did that made my life easier. But I noticed, that for example, I didn’t even have to think about primitives. No int, no long, no float, not double. It’s just a dynamic that since I’ve been working in Kotlin for my projects, I don’t even think about. But I know what they are. Because of this, I always have this question. If I didn’t have a background in Java , would I understand what I do now about Kotlin? I have more and more the feeling that I wouldn’t. Kotlin Java I am, however, impressed with the idea of coroutines , but with Project Loom lingering for years and coming out now, what should I conclude about the very similar ideas that the two have with each other? As a final note, I have to say that I am extremely pleased to have studied Micronaut and Kong for this article. I’m not sure what to think about Kotlin , though. coroutines Project Loom Micronaut Kong Kotlin I think my next project will be in the latest Java version, and maybe then, I’ll compare Java back to Kotlin . Using Redis as a lifeboat for a sort of quick solution for my project with a queue system worked like a charm, and I am very happy with it. Java Java Kotlin 8. References https://youtu.be/z3Y4NQgjGLE?embedable=true https://youtu.be/z3Y4NQgjGLE?embedable=true https://www.youtube.com/watch?v=20rOdqag4Dw&embedable=true https://www.youtube.com/watch?v=20rOdqag4Dw&embedable=true https://www.youtube.com/watch?v=sJEID1xEZMg&embedable=true https://www.youtube.com/watch?v=sJEID1xEZMg&embedable=true Compose V2 Kong Gateway for Beginners: Adding a Service, Route and Plugins Kong Gateway Tutorial | API Gateway For Beginners How to Use Kong Gateway JWT Plugin Developing Micronaut Applications with IntelliJ IDEA Micronaut Deep Dive by Graeme Rocher Introduction to Micronaut • Graeme Rocher • GOTO 2019 What is Rate Limiting / API Throttling? | System Design Concepts API Gateway Plugins for Kubernetes Ingress Controller Installing Kong's API Gateway with Docker DevOps Is More Than Configuration Management DynamoDB Partitions - How they work - AWS Service Deep Dive Working with DynamoDB Tables - Partition Key and Sort Key - Dynamo Deep Dive AWS re:Invent 2018: Amazon DynamoDB Deep Dive: Advanced Design Patterns for DynamoDB (DAT401) What is a DynamoDB GSI (Global Secondary Index) ? Permission issue with PostgreSQL in docker container What kinds of bot attacks are stopped by rate limiting? Using Micronaut Data, JDBC, R2DBC, TestContainers, and Flyway with multiple schemas Realtime Testing: Micronaut, Postgres and Testcontainer Entity-Relationship Diagram Symbols and Notation MICRONAUT 1.0 RC1 AND THE POWER OF AHEAD-OF-TIME COMPILATION From Spring Boot to Micronaut Create a New React App Micronaut: A five-minute introduction Micronaut CLI CREATING YOUR FIRST MICRONAUT APPLICATION Micronaut Deploy an Enterprise License Kong Gateway Licensing @ Kong Docs How To Enable the Dev Portal @ Kong Docs Kong /docker-kong 🦍 (sounds like Donkey Kong!) Kong Gateway MemboxX Kong Inc. Wikipedia Repubished 5 questions for Kong CEO Augusto Marietti Author: Augusto Marietti Years after crashing on Travis Kalanick’s couch, this founder has raised $18M for his startup, Mashape Mashape Rebrands as Kong Inc., Declares Monolithic Application Dead Kong Inc. Redhwan Nacef's Kong Tutorial On GitHub Lorem Picsum Phosots Compose V2 Compose V2 Kong Gateway for Beginners: Adding a Service, Route and Plugins Kong Gateway for Beginners: Adding a Service, Route and Plugins Kong Gateway Tutorial | API Gateway For Beginners Kong Gateway Tutorial | API Gateway For Beginners How to Use Kong Gateway JWT Plugin How to Use Kong Gateway JWT Plugin Developing Micronaut Applications with IntelliJ IDEA Developing Micronaut Applications with IntelliJ IDEA Micronaut Deep Dive by Graeme Rocher Micronaut Deep Dive by Graeme Rocher Introduction to Micronaut • Graeme Rocher • GOTO 2019 Introduction to Micronaut • Graeme Rocher • GOTO 2019 What is Rate Limiting / API Throttling? | System Design Concepts What is Rate Limiting / API Throttling? | System Design Concepts API Gateway Plugins for Kubernetes Ingress Controller API Gateway Plugins for Kubernetes Ingress Controller Installing Kong's API Gateway with Docker Installing Kong's API Gateway with Docker DevOps Is More Than Configuration Management DevOps Is More Than Configuration Management DynamoDB Partitions - How they work - AWS Service Deep Dive DynamoDB Partitions - How they work - AWS Service Deep Dive Working with DynamoDB Tables - Partition Key and Sort Key - Dynamo Deep Dive Working with DynamoDB Tables - Partition Key and Sort Key - Dynamo Deep Dive AWS re:Invent 2018: Amazon DynamoDB Deep Dive: Advanced Design Patterns for DynamoDB (DAT401) AWS re:Invent 2018: Amazon DynamoDB Deep Dive: Advanced Design Patterns for DynamoDB (DAT401) What is a DynamoDB GSI (Global Secondary Index) ? What is a DynamoDB GSI (Global Secondary Index) ? Permission issue with PostgreSQL in docker container Permission issue with PostgreSQL in docker container What kinds of bot attacks are stopped by rate limiting? What kinds of bot attacks are stopped by rate limiting? Using Micronaut Data, JDBC, R2DBC, TestContainers, and Flyway with multiple schemas Using Micronaut Data, JDBC, R2DBC, TestContainers, and Flyway with multiple schemas Realtime Testing: Micronaut, Postgres and Testcontainer Realtime Testing: Micronaut, Postgres and Testcontainer Entity-Relationship Diagram Symbols and Notation Entity-Relationship Diagram Symbols and Notation MICRONAUT 1.0 RC1 AND THE POWER OF AHEAD-OF-TIME COMPILATION MICRONAUT 1.0 RC1 AND THE POWER OF AHEAD-OF-TIME COMPILATION From Spring Boot to Micronaut From Spring Boot to Micronaut Create a New React App Create a New React App Micronaut: A five-minute introduction Micronaut: A five-minute introduction Micronaut CLI Micronaut CLI CREATING YOUR FIRST MICRONAUT APPLICATION CREATING YOUR FIRST MICRONAUT APPLICATION Micronaut Micronaut Deploy an Enterprise License Deploy an Enterprise License Kong Gateway Licensing @ Kong Docs Kong Gateway Licensing @ Kong Docs How To Enable the Dev Portal @ Kong Docs How To Enable the Dev Portal @ Kong Docs Kong /docker-kong 🦍 (sounds like Donkey Kong!) Kong /docker-kong 🦍 (sounds like Donkey Kong!) Kong Gateway Kong Gateway MemboxX MemboxX Kong Inc. Wikipedia Repubished Kong Inc. Wikipedia Repubished 5 questions for Kong CEO Augusto Marietti 5 questions for Kong CEO Augusto Marietti Author: Augusto Marietti Author: Augusto Marietti Years after crashing on Travis Kalanick’s couch, this founder has raised $18M for his startup, Mashape Years after crashing on Travis Kalanick’s couch, this founder has raised $18M for his startup, Mashape Mashape Rebrands as Kong Inc., Declares Monolithic Application Dead Mashape Rebrands as Kong Inc., Declares Monolithic Application Dead Kong Inc. Kong Inc. Redhwan Nacef's Kong Tutorial On GitHub Redhwan Nacef's Kong Tutorial On GitHub Lorem Picsum Phosots Lorem Picsum Phosots Thank you! I hope you enjoyed this article as much as I did making it! Please leave a review, comments, or any feedback you want to give on any of the socials in the links below. I’m very grateful if you want to help me make this article better. I have placed all the source code of this application on GitHub. Thank you for reading! GitHub.
