What Is Weaviate And How To Create Data Schemas In It

Weaviate is a search engine that stores data as vectors, with a graph-like data model. A well-defined data Schema is key to meaningful insights of your data. The data schema you need to define is relatively simple and easy to do with a simple class and property. Weaviates uses a class-property structure, inspired by the RDF-inspired RDF Schema, to place data objects into context and derive its meaning. This article is not only a tutorial for creating your own schema, but also explains what a schema is and why you need one.
Laura Ham Hacker Noon profile picture

@laurahamLaura Ham

Community Solution Engineer | DX Developer | Creative tech enthousiast | Curious Mind | Adventurous

What is a schema, why you need one and how to define one to store your own data.

Weaviate is a vector-native database: data is stored as vectors in a high-dimensional space. In order to store and retrieve vector data, Weaviate uses a data schema which is unique per instance. Once you have started up a Weaviate instance (via docker-compose, Kubernetes or using the Weaviate Cluster Service), you need to create a data schema before you can add and query data.

Like most other databases, a database schema defines the structure described in a formal language. It is a sort of blueprint of how the data is structured in a database. The data schema you need to define for Weaviate is relatively simple. It consists of classes and properties definitions and how they are related to each other. Due to Weaviate’s vectorization modules, the classes and properties you add will be automatically placed in context.

This article is not only a tutorial for creating your own schema, but also explains what a schema is and why you need one. Ultimately, understanding what you’re creating a schema for will help you in making your own.

What is a Weaviate data schema and why do you need one?

RDF-inspired

Just like most databases, Weaviate needs a data schema. Weaviate uses a class-property structure, inspired by the RDF Schema. RDF Schemas have classes with properties and relations, and are used as ontology to represent knowledge. Born out of this RDF-like perspective is the Weaviate schema with classes, properties and relations. Weaviate uses the data schema to place data objects into context and derive its meaning. A schema is thus an essential part for Weaviate to understand your data objects. A well-defined schema (read on to learn best practices for creating a schema) is key to meaningful insights of your data.

Graph-like data model

You can make relations between data objects in Weaviate. You can see the data schema with cross references as a graph-like data model. But keep in mind that Weaviate is not a Graph database. Instead, Weaviate is a search engine that stores data as vectors, with a graph-like data model. Typical graph database tasks like shortest path prediction are not part of Weaviate’s features. In Weaviate, data objects, which are nodes in the graph, get a vector position.

Data is thus stored in a space according to its meaning, and can still be connected to other data entities. Storing the (graph) data as vectors has huge advantages when it comes to automatic classification, prediction of data relations, semantic search and deriving insights.

How to define a Weaviate data schema

Class - property structure

Data objects in Weaviate always belong to a class. A class describes the data object in the form of a noun or a verb. Every class is defined in the schema, and can have one or more properties. Properties define the actual data values of the objects in your dataset. Properties have a

name
and a
dataType
. The name may contribute to the object’s semantics, depending on module-specific settings you can also define in the schema. A property’s dataType lists which data formats it accepts (e.g.
string
,
int
, etc). Graph-like relations between data objects are also defined as property dataType.

Schema design example

Let’s make a data schema for an open wine review dataset from Kaggle. This dataset consists of 150k wine reviews scraped from WineEnthusiast. It contains wine titles, descriptions, points (score 0-100 given by the reviewer), prices, designations, regions, provinces, countries, varieties, wineries and reviewers. To keep the example for this tutorial simple, I’m leaving out the regions and reviewers. Now, let’s see how we can design a good data schema.

An obvious first class to create is

Wine
. The metadata list mentioned above can all be seen as properties of the class
Wine
. However, some properties have values which are not unique and shared between data instances of Wine. For example, the country a wine is from will be a country from a limited list of countries.

Similarly, there is a limited set of wine varieties (e.g. Chardonnay, Pinot Noir, etc). The same holds for provinces and wineries. We decide to let these characteristics have their own class. The figure below shows which classes we have now.


Classes

We now have five classes. All classes have a unique name. A class name always starts with a capital letter. A good class name is descriptive of the data objects that you will add to this class. If you want to use multiple words for a class or property name, concatenate the words according to the CamelCase (for class names) or camelCase (for property names) rule. In addition to naming the classes, we can add a

description
(a string for your own reference). The
Wine
class, without properties and module-specific settings could be designed in json as follows:

{
    "class": "Wine",
    "description": "A wine that has been tasted and reviewed",
    "properties": []
}

Properties

Leaving relations between the classes out for now, the class Wine has five properties, while the other four classes only have a unique name. Property names always start with a lowercase letter. Again, in addition to naming the properties, we can add a description. With the original dataset in mind, we define the properties. We extend the Wine class with its properties as follows [1] [2].

{
    "class": "Wine",
    "description": "A wine that has been tasted and reviewed",
    "properties": [
        {
            "name": "title",
            "description": "The name of the wine",
            "dataType": ["text"]
        },
        {
            "name": "description",
            "description": "The review of the wine",
            "dataType": ["text"]
        },
        {
            "name": "designation",
            "description": "The vineyard within the winery where the grapes that made the wine are from",
            "dataType": ["string"]
        },
        {
            "name": "points",
            "description": "Points 0-100 given by the reviewer",
            "dataType": ["int"]
        },
        {
            "name": "price",
            "description": "The price of the wine in dollars",
            "dataType": ["number"]
        }
    ]
}

Cross-references

As mentioned before, the four classes

Variety
,
Province
,
Country
and
Winery
are all related to
Wine
. Thus, we can make cross-relations between those classes and
Wine
. In other words, those four classes are properties of
Wine
, described by a cross-reference. In the next figure it is pictured how those classes can be related. Note that all relations have a single direction; relations between data classes in Weaviate are not automatically bidirectional. That is because relations to other classes (or data objects) are described as property values of a class or data object.


Assuming we have the classes

“Wine”
,
“Variety”
,
“Province”
,
“Country”
and
“Winery”
without references in our schema, we can extend them by adding properties with references. For example, we can extend the class
“Province”
with a property with a cross-reference to
"Country"
. Note that the dataType of the property
“inCountry”
is now the class name
“Country”
:

{
    "class": "Province",
    "description": "A defined region in a country",
    "properties": [
        {
            "name": "name",
            "description": "The name of the province",
            "dataType": ["string"]
        },
        {
            "name": "inCountry",
            "description": "The country the province belongs to",
            "dataType": ["Country"]
        }
    ]
}

Advanced schema configuration

For data classes, you need to define at least the name of the class in

“class”
and at least one property. Additionally, you may add a description, the vector index type and configuration if other than default, the vectorizer (determines which vectorization module is used to vectorize data objects of this class) and its settings in case other than default, and other module-specific settings. For reference, check the documentation of schema configuration or module specific settings

For class properties, defining the

“name”
and
“dataType”
are required. A description and module-specific settings are optional. Module-agnostic is the setting
“indexInverted”
. If this boolean field is set to
false
(default is
true
), the property and its value will be ignored in search and classification. This might come in handy if you explicitly don’t want a value without any semantic value (e.g. a person’s ID number) to influence your classification.

Upload data schema

You can upload an entire data schema to a running Weaviate instance at once using the Python client. Alternatively, you can add classes one by one using other clients or with an HTTP request. Make sure classes exist before you use them in a reference property.

Example of importing a full schema with the Python client to Weaviate running on http://localhost:8080.

import weaviate

client = weaviate.Client("http://localhost:8080")

schema = {
    "classes": [
        {
            "class": "Wine",
            "description": "A wine that has been tasted and reviewed",
            "properties": [
                {
                    "name": "title",
                    "description": "The name of the wine",
                    "dataType": ["text"]
                }, {
                    "name": "description",
                    "description": "The review of the wine",
                    "dataType": ["text"]
                }, {
                    "name": "designation",
                    "description": "The vineyard within the winery where the grapes that made the wine are from",
                    "dataType": ["string"]
                }, {
                    "name": "points",
                    "description": "Points 0-100 given by the reviewer",
                    "dataType": ["int"]
                }, {
                    "name": "price",
                    "description": "The price of the wine in dollars",
                    "dataType": ["number"]
                }, {
                    "dataType": ["Country"],
                    "description": "The country the wine is from",
                    "name": "fromCountry"
                }, {
                    "dataType": ["Province"],
                    "description": "The province or state that the wine is from",
                    "name": "fromProvince"
                }, {
                    "dataType": ["Variety"],
                    "description": "The type of grapes used to make the wine (ie Pinot Noir)",
                    "name": "hasVariety"
                }, {
                    "dataType": ["Winery"],
                    "description": "The winery that made the wine",
                    "name": "fromWinery"
                }
            ]
        }, {
            "class": "Country",
            "description": "A country which produces wine",
            "properties": [
                {
                    "dataType": ["string"],
                    "description": "The name of the country",
                    "name": "name"
                }
            ]
        }, {
            "class": "Province",
            "description": "A defined region or state of a country",
            "properties": [
                {
                    "dataType": ["string"],
                    "description": "The name of the country",
                    "name": "name"
                }, {
                    "dataType": ["Country"],
                    "description": "The country the province lies in",
                    "name": "inCountry"
                }
            ]
        }, {
            "class": "Variety",
            "description": "The type of grapes a wine is made of",
            "properties": [
                {
                    "dataType": ["string"],
                    "description": "The name of the variety, which is the name of the grape",
                    "name": "name"
                }
            ]
        }, {
            "class": "Winery",
            "description": "A wine producer",
            "properties": [
                {
                    "dataType": ["string"],
                    "description": "The name of the winery",
                    "name": "name"
                }, {
                    "dataType": ["Country"],
                    "description": "The country the province lies in",
                    "name": "inCountry"
                }
            ]
        }
    ]
}

client.schema.create(schema)

Conclusion

In this article, you learned what a Weaviate data schema is, why you need one and how to design one. The full example code can be found here. Learn more about module specific schema configuration here, and other property data types like geo-coordinates, phone numbers and dates here. After designing a data schema, you can start uploading data to Weaviate!

  • [1] Note that
    “designation”
    is a
    “string”
    property, while
    “title”
    and
    “description”
    are
    “text”
    properties.
    “string”
    values are indexed as one token, whereas
    “text”
    values are indexed after applying tokenization.
    [email protected]
    as string would be indexed as
    [email protected]
    and also only match that in a GraphQL where filter, whereas as text it would be indexed as
    ['jane', 'doe', 'foobar', 'com']
    and also match the individual words.
  • [2] For more property dataType options, check the documentation.
