The Shape of Data: Broadcasting, Indexing, and Encoding with RaggedTensors

Content Overview Indexing Indexing examples: 2D ragged tensor Indexing examples: 3D ragged tensor Tensor type conversion Evaluating ragged tensors Ragged shapes Static shape Dynamic shape Broadcasting RaggedTensor encoding Multiple ragged dimensions Ragged rank and flat values Uniform inner dimensions Uniform non-inner dimensions Indexing Indexing examples: 2D ragged tensor Indexing examples: 3D ragged tensor Tensor type conversion Evaluating ragged tensors Ragged shapes Static shape Dynamic shape Broadcasting RaggedTensor encoding Multiple ragged dimensions Ragged rank and flat values Uniform inner dimensions Uniform non-inner dimensions Indexing Ragged tensors support Python-style indexing, including multidimensional indexing and slicing. The following examples demonstrate ragged tensor indexing with a 2D and a 3D ragged tensor. Indexing examples: 2D ragged tensor queries = tf.ragged.constant( [['Who', 'is', 'George', 'Washington'], ['What', 'is', 'the', 'weather', 'tomorrow'], ['Goodnight']]) queries = tf.ragged.constant( [['Who', 'is', 'George', 'Washington'], ['What', 'is', 'the', 'weather', 'tomorrow'], ['Goodnight']]) print(queries[1]) # A single query print(queries[1]) # A single query tf.Tensor([b'What' b'is' b'the' b'weather' b'tomorrow'], shape=(5,), dtype=string) tf.Tensor([b'What' b'is' b'the' b'weather' b'tomorrow'], shape=(5,), dtype=string) print(queries[1, 2]) # A single word print(queries[1, 2]) # A single word tf.Tensor(b'the', shape=(), dtype=string) tf.Tensor(b'the', shape=(), dtype=string) print(queries[1:]) # Everything but the first row print(queries[1:]) # Everything but the first row print(queries[:, :3]) # The first 3 words of each query print(queries[:, :3]) # The first 3 words of each query print(queries[:, -2:]) # The last 2 words of each query print(queries[:, -2:]) # The last 2 words of each query Indexing examples: 3D ragged tensor rt = tf.ragged.constant([[[1, 2, 3], [4]], [[5], [], [6]], [[7]], [[8, 9], [10]]]) rt = tf.ragged.constant([[[1, 2, 3], [4]], [[5], [], [6]], [[7]], [[8, 9], [10]]]) print(rt[1]) # Second row (2D RaggedTensor) print(rt[1]) # Second row (2D RaggedTensor) print(rt[3, 0]) # First element of fourth row (1D Tensor) print(rt[3, 0]) # First element of fourth row (1D Tensor) tf.Tensor([8 9], shape=(2,), dtype=int32) tf.Tensor([8 9], shape=(2,), dtype=int32) print(rt[:, 1:3]) # Items 1-3 of each row (3D RaggedTensor) print(rt[:, 1:3]) # Items 1-3 of each row (3D RaggedTensor) print(rt[:, -1:]) # Last item of each row (3D RaggedTensor) print(rt[:, -1:]) # Last item of each row (3D RaggedTensor) RaggedTensors support multidimensional indexing and slicing with one restriction: indexing into a ragged dimension is not allowed. This case is problematic because the indicated value may exist in some rows but not others. In such cases, it's not obvious whether you should (1) raise an IndexError; (2) use a default value; or (3) skip that value and return a tensor with fewer rows than you started with. Following the guiding principles of Python ("In the face of ambiguity, refuse the temptation to guess"), this operation is currently disallowed. RaggedTensor IndexError guiding principles of Python Tensor type conversion The RaggedTensor class defines methods that can be used to convert between RaggedTensors and tf.Tensors or tf.SparseTensors: RaggedTensor RaggedTensor tf.Tensor tf.SparseTensors ragged_sentences = tf.ragged.constant([ ['Hi'], ['Welcome', 'to', 'the', 'fair'], ['Have', 'fun']]) ragged_sentences = tf.ragged.constant([ ['Hi'], ['Welcome', 'to', 'the', 'fair'], ['Have', 'fun']]) # RaggedTensor -> Tensor print(ragged_sentences.to_tensor(default_value='', shape=[None, 10])) # RaggedTensor -> Tensor print(ragged_sentences.to_tensor(default_value='', shape=[None, 10])) tf.Tensor( [[b'Hi' b'' b'' b'' b'' b'' b'' b'' b'' b''] [b'Welcome' b'to' b'the' b'fair' b'' b'' b'' b'' b'' b''] [b'Have' b'fun' b'' b'' b'' b'' b'' b'' b'' b'']], shape=(3, 10), dtype=string) tf.Tensor( [[b'Hi' b'' b'' b'' b'' b'' b'' b'' b'' b''] [b'Welcome' b'to' b'the' b'fair' b'' b'' b'' b'' b'' b''] [b'Have' b'fun' b'' b'' b'' b'' b'' b'' b'' b'']], shape=(3, 10), dtype=string) # Tensor -> RaggedTensor x = [[1, 3, -1, -1], [2, -1, -1, -1], [4, 5, 8, 9]] print(tf.RaggedTensor.from_tensor(x, padding=-1)) # Tensor -> RaggedTensor x = [[1, 3, -1, -1], [2, -1, -1, -1], [4, 5, 8, 9]] print(tf.RaggedTensor.from_tensor(x, padding=-1)) #RaggedTensor -> SparseTensor print(ragged_sentences.to_sparse()) #RaggedTensor -> SparseTensor print(ragged_sentences.to_sparse()) SparseTensor(indices=tf.Tensor( [[0 0] [1 0] [1 1] [1 2] [1 3] [2 0] [2 1]], shape=(7, 2), dtype=int64), values=tf.Tensor([b'Hi' b'Welcome' b'to' b'the' b'fair' b'Have' b'fun'], shape=(7,), dtype=string), dense_shape=tf.Tensor([3 4], shape=(2,), dtype=int64)) SparseTensor(indices=tf.Tensor( [[0 0] [1 0] [1 1] [1 2] [1 3] [2 0] [2 1]], shape=(7, 2), dtype=int64), values=tf.Tensor([b'Hi' b'Welcome' b'to' b'the' b'fair' b'Have' b'fun'], shape=(7,), dtype=string), dense_shape=tf.Tensor([3 4], shape=(2,), dtype=int64)) # SparseTensor -> RaggedTensor st = tf.SparseTensor(indices=[[0, 0], [2, 0], [2, 1]], values=['a', 'b', 'c'], dense_shape=[3, 3]) print(tf.RaggedTensor.from_sparse(st)) # SparseTensor -> RaggedTensor st = tf.SparseTensor(indices=[[0, 0], [2, 0], [2, 1]], values=['a', 'b', 'c'], dense_shape=[3, 3]) print(tf.RaggedTensor.from_sparse(st)) Evaluating ragged tensors To access the values in a ragged tensor, you can: Use tf.RaggedTensor.to_list to convert the ragged tensor to a nested Python list. Use tf.RaggedTensor.numpy to convert the ragged tensor to a NumPy array whose values are nested NumPy arrays. Decompose the ragged tensor into its components, using the tf.RaggedTensor.values and tf.RaggedTensor.row_splits properties, or row-partitioning methods such as tf.RaggedTensor.row_lengths and tf.RaggedTensor.value_rowids. Use Python indexing to select values from the ragged tensor. Use tf.RaggedTensor.to_list to convert the ragged tensor to a nested Python list. tf.RaggedTensor.to_list Use tf.RaggedTensor.numpy to convert the ragged tensor to a NumPy array whose values are nested NumPy arrays. tf.RaggedTensor.numpy Decompose the ragged tensor into its components, using the tf.RaggedTensor.values and tf.RaggedTensor.row_splits properties, or row-partitioning methods such as tf.RaggedTensor.row_lengths and tf.RaggedTensor.value_rowids. tf.RaggedTensor.values tf.RaggedTensor.row_splits tf.RaggedTensor.row_lengths tf.RaggedTensor.value_rowids Use Python indexing to select values from the ragged tensor. rt = tf.ragged.constant([[1, 2], [3, 4, 5], [6], [], [7]]) print("Python list:", rt.to_list()) print("NumPy array:", rt.numpy()) print("Values:", rt.values.numpy()) print("Splits:", rt.row_splits.numpy()) print("Indexed value:", rt[1].numpy()) rt = tf.ragged.constant([[1, 2], [3, 4, 5], [6], [], [7]]) print("Python list:", rt.to_list()) print("NumPy array:", rt.numpy()) print("Values:", rt.values.numpy()) print("Splits:", rt.row_splits.numpy()) print("Indexed value:", rt[1].numpy()) Python list: [[1, 2], [3, 4, 5], [6], [], [7]] NumPy array: [array([1, 2], dtype=int32) array([3, 4, 5], dtype=int32) array([6], dtype=int32) array([], dtype=int32) array([7], dtype=int32)] Values: [1 2 3 4 5 6 7] Splits: [0 2 5 6 6 7] Indexed value: [3 4 5] Python list: [[1, 2], [3, 4, 5], [6], [], [7]] NumPy array: [array([1, 2], dtype=int32) array([3, 4, 5], dtype=int32) array([6], dtype=int32) array([], dtype=int32) array([7], dtype=int32)] Values: [1 2 3 4 5 6 7] Splits: [0 2 5 6 6 7] Indexed value: [3 4 5] Ragged Shapes The shape of a tensor specifies the size of each axis. For example, the shape of [[1, 2], [3, 4], [5, 6]] is [3, 2], since there are 3 rows and 2 columns. TensorFlow has two separate but related ways to describe shapes: [[1, 2], [3, 4], [5, 6]] [3, 2] static shape: Information about axis sizes that is known statically (e.g., while tracing a tf.function). May be partially specified. dynamic shape: Runtime information about the axis sizes. static shape: Information about axis sizes that is known statically (e.g., while tracing a tf.function). May be partially specified. static shape static shape tf.function dynamic shape: Runtime information about the axis sizes. dynamic shape dynamic shape Static shape A Tensor's static shape contains information about its axis sizes that is known at graph-construction time. For both tf.Tensor and tf.RaggedTensor, it is available using the .shape property, and is encoded using tf.TensorShape: tf.Tensor tf.RaggedTensor .shape tf.TensorShape x = tf.constant([[1, 2], [3, 4], [5, 6]]) x.shape # shape of a tf.tensor x = tf.constant([[1, 2], [3, 4], [5, 6]]) x.shape # shape of a tf.tensor TensorShape([3, 2]) TensorShape([3, 2]) rt = tf.ragged.constant([[1], [2, 3], [], [4]]) rt.shape # shape of a tf.RaggedTensor rt = tf.ragged.constant([[1], [2, 3], [], [4]]) rt.shape # shape of a tf.RaggedTensor TensorShape([4, None]) TensorShape([4, None]) The static shape of a ragged dimension is always None (i.e., unspecified). However, the inverse is not true -- if a TensorShape dimension is None, then that could indicate that the dimension is ragged, or it could indicate that the dimension is uniform but that its size is not statically known. None TensorShape None or Dynamic shape A tensor's dynamic shape contains information about its axis sizes that is known when the graph is run. It is constructed using the tf.shape operation. For tf.Tensor, tf.shape returns the shape as a 1D integer Tensor, where tf.shape(x)[i] is the size of axis i. tf.shape tf.Tensor tf.shape Tensor tf.shape(x)[i] i x = tf.constant([['a', 'b'], ['c', 'd'], ['e', 'f']]) tf.shape(x) x = tf.constant([['a', 'b'], ['c', 'd'], ['e', 'f']]) tf.shape(x) However, a 1D Tensor is not expressive enough to describe the shape of a tf.RaggedTensor. Instead, the dynamic shape for ragged tensors is encoded using a dedicated type, tf.experimental.DynamicRaggedShape. In the following example, the DynamicRaggedShape returned by tf.shape(rt) indicates that the ragged tensor has 4 rows, with lengths 1, 3, 0, and 2: Tensor tf.RaggedTensor tf.experimental.DynamicRaggedShape DynamicRaggedShape tf.shape(rt) rt = tf.ragged.constant([[1], [2, 3, 4], [], [5, 6]]) rt_shape = tf.shape(rt) print(rt_shape) rt = tf.ragged.constant([[1], [2, 3, 4], [], [5, 6]]) rt_shape = tf.shape(rt) print(rt_shape) Dynamic shape: operations DynamicRaggedShapes can be used with most TensorFlow ops that expect shapes, including tf.reshape, tf.zeros, tf.ones. tf.fill, tf.broadcast_dynamic_shape, and tf.broadcast_to. DynamicRaggedShape tf.reshape tf.zeros tf.ones tf.fill tf.broadcast_dynamic_shape tf.broadcast_to print(f"tf.reshape(x, rt_shape) = {tf.reshape(x, rt_shape)}") print(f"tf.zeros(rt_shape) = {tf.zeros(rt_shape)}") print(f"tf.ones(rt_shape) = {tf.ones(rt_shape)}") print(f"tf.fill(rt_shape, 9) = {tf.fill(rt_shape, 'x')}") print(f"tf.reshape(x, rt_shape) = {tf.reshape(x, rt_shape)}") print(f"tf.zeros(rt_shape) = {tf.zeros(rt_shape)}") print(f"tf.ones(rt_shape) = {tf.ones(rt_shape)}") print(f"tf.fill(rt_shape, 9) = {tf.fill(rt_shape, 'x')}") tf.reshape(x, rt_shape) = tf.zeros(rt_shape) = tf.ones(rt_shape) = tf.fill(rt_shape, 9) = tf.reshape(x, rt_shape) = tf.zeros(rt_shape) = tf.ones(rt_shape) = tf.fill(rt_shape, 9) = Dynamic shape: indexing and slicing DynamicRaggedShape can be also be indexed to get the sizes of uniform dimensions. For example, we can find the number of rows in a raggedtensor using tf.shape(rt)[0] (just as we would for a non-ragged tensor): DynamicRaggedShape tf.shape(rt)[0] rt_shape[0] rt_shape[0] However, it is an error to use indexing to try to retrieve the size of a ragged dimension, since it doesn't have a single size. (Since RaggedTensor keeps track of which axes are ragged, this error is only thrown during eager execution or when tracing a tf.function; it will never be thrown when executing a concrete function.) RaggedTensor tf.function try: rt_shape[1] except ValueError as e: print("Got expected ValueError:", e) try: rt_shape[1] except ValueError as e: print("Got expected ValueError:", e) Got expected ValueError: Index 1 is not uniform Got expected ValueError: Index 1 is not uniform DynamicRaggedShapes can also be sliced, as long as the slice either begins with axis 0, or contains only dense dimensions. DynamicRaggedShape 0 rt_shape[:1] rt_shape[:1] Dynamic shape: encoding DynamicRaggedShape is encoded using two fields: DynamicRaggedShape inner_shape: An integer vector giving the shape of a dense tf.Tensor. row_partitions: A list of tf.experimental.RowPartition objects, describing how the outermost dimension of that inner shape should be partitioned to add ragged axes. inner_shape: An integer vector giving the shape of a dense tf.Tensor. inner_shape tf.Tensor row_partitions: A list of tf.experimental.RowPartition objects, describing how the outermost dimension of that inner shape should be partitioned to add ragged axes. row_partitions tf.experimental.RowPartition For more information about row partitions, see the "RaggedTensor encoding" section below, and the API docs for tf.experimental.RowPartition. tf.experimental.RowPartition Dynamic shape: construction DynamicRaggedShape is most often constructed by applying tf.shape to a RaggedTensor, but it can also be constructed directly: DynamicRaggedShape tf.shape RaggedTensor tf.experimental.DynamicRaggedShape( row_partitions=[tf.experimental.RowPartition.from_row_lengths([5, 3, 2])], inner_shape=[10, 8]) tf.experimental.DynamicRaggedShape( row_partitions=[tf.experimental.RowPartition.from_row_lengths([5, 3, 2])], inner_shape=[10, 8]) If the lengths of all rows are known statically, DynamicRaggedShape.from_lengths can also be used to construct a dynamic ragged shape. (This is mostly useful for testing and demonstration code, since it's rare for the lengths of ragged dimensions to be known statically). DynamicRaggedShape.from_lengths tf.experimental.DynamicRaggedShape.from_lengths([4, (2, 1, 0, 8), 12]) tf.experimental.DynamicRaggedShape.from_lengths([4, (2, 1, 0, 8), 12]) Broadcasting Broadcasting is the process of making tensors with different shapes have compatible shapes for elementwise operations. For more background on broadcasting, refer to: NumPy: Broadcasting tf.broadcast_dynamic_shape tf.broadcast_to NumPy: Broadcasting NumPy: Broadcasting tf.broadcast_dynamic_shape tf.broadcast_dynamic_shape tf.broadcast_to tf.broadcast_to The basic steps for broadcasting two inputs x and y to have compatible shapes are: x y If x and y do not have the same number of dimensions, then add outer dimensions (with size 1) until they do. For each dimension where x and y have different sizes: If x and y do not have the same number of dimensions, then add outer dimensions (with size 1) until they do. x y For each dimension where x and y have different sizes: x y If x or y have size 1 in dimension d, then repeat its values across dimension d to match the other input's size. Otherwise, raise an exception (x and y are not broadcast compatible). If x or y have size 1 in dimension d, then repeat its values across dimension d to match the other input's size. x y 1 d d Otherwise, raise an exception (x and y are not broadcast compatible). x y Where the size of a tensor in a uniform dimension is a single number (the size of slices across that dimension); and the size of a tensor in a ragged dimension is a list of slice lengths (for all slices across that dimension). Broadcasting examples # x (2D ragged): 2 x (num_rows) # y (scalar) # result (2D ragged): 2 x (num_rows) x = tf.ragged.constant([[1, 2], [3]]) y = 3 print(x + y) # x (2D ragged): 2 x (num_rows) # y (scalar) # result (2D ragged): 2 x (num_rows) x = tf.ragged.constant([[1, 2], [3]]) y = 3 print(x + y) # x (2d ragged): 3 x (num_rows) # y (2d tensor): 3 x 1 # Result (2d ragged): 3 x (num_rows) x = tf.ragged.constant( [[10, 87, 12], [19, 53], [12, 32]]) y = [[1000], [2000], [3000]] print(x + y) # x (2d ragged): 3 x (num_rows) # y (2d tensor): 3 x 1 # Result (2d ragged): 3 x (num_rows) x = tf.ragged.constant( [[10, 87, 12], [19, 53], [12, 32]]) y = [[1000], [2000], [3000]] print(x + y) # x (3d ragged): 2 x (r1) x 2 # y (2d ragged): 1 x 1 # Result (3d ragged): 2 x (r1) x 2 x = tf.ragged.constant( [[[1, 2], [3, 4], [5, 6]], [[7, 8]]], ragged_rank=1) y = tf.constant([[10]]) print(x + y) # x (3d ragged): 2 x (r1) x 2 # y (2d ragged): 1 x 1 # Result (3d ragged): 2 x (r1) x 2 x = tf.ragged.constant( [[[1, 2], [3, 4], [5, 6]], [[7, 8]]], ragged_rank=1) y = tf.constant([[10]]) print(x + y) # x (3d ragged): 2 x (r1) x (r2) x 1 # y (1d tensor): 3 # Result (3d ragged): 2 x (r1) x (r2) x 3 x = tf.ragged.constant( [ [ [[1], [2]], [], [[3]], [[4]], ], [ [[5], [6]], [[7]] ] ], ragged_rank=2) y = tf.constant([10, 20, 30]) print(x + y) # x (3d ragged): 2 x (r1) x (r2) x 1 # y (1d tensor): 3 # Result (3d ragged): 2 x (r1) x (r2) x 3 x = tf.ragged.constant( [ [ [[1], [2]], [], [[3]], [[4]], ], [ [[5], [6]], [[7]] ] ], ragged_rank=2) y = tf.constant([10, 20, 30]) print(x + y) Here are some examples of shapes that do not broadcast: # x (2d ragged): 3 x (r1) # y (2d tensor): 3 x 4 # trailing dimensions do not match x = tf.ragged.constant([[1, 2], [3, 4, 5, 6], [7]]) y = tf.constant([[1, 2, 3, 4], [5, 6, 7, 8], [9, 10, 11, 12]]) try: x + y except tf.errors.InvalidArgumentError as exception: print(exception) # x (2d ragged): 3 x (r1) # y (2d tensor): 3 x 4 # trailing dimensions do not match x = tf.ragged.constant([[1, 2], [3, 4, 5, 6], [7]]) y = tf.constant([[1, 2, 3, 4], [5, 6, 7, 8], [9, 10, 11, 12]]) try: x + y except tf.errors.InvalidArgumentError as exception: print(exception) Condition x == y did not hold. Indices of first 3 different values: [[1] [2] [3]] Corresponding x values: [ 4 8 12] Corresponding y values: [2 6 7] First 3 elements of x: [0 4 8] First 3 elements of y: [0 2 6] Condition x == y did not hold. Indices of first 3 different values: [[1] [2] [3]] Corresponding x values: [ 4 8 12] Corresponding y values: [2 6 7] First 3 elements of x: [0 4 8] First 3 elements of y: [0 2 6] # x (2d ragged): 3 x (r1) # y (2d ragged): 3 x (r2) # ragged dimensions do not match. x = tf.ragged.constant([[1, 2, 3], [4], [5, 6]]) y = tf.ragged.constant([[10, 20], [30, 40], [50]]) try: x + y except tf.errors.InvalidArgumentError as exception: print(exception) # x (2d ragged): 3 x (r1) # y (2d ragged): 3 x (r2) # ragged dimensions do not match. x = tf.ragged.constant([[1, 2, 3], [4], [5, 6]]) y = tf.ragged.constant([[10, 20], [30, 40], [50]]) try: x + y except tf.errors.InvalidArgumentError as exception: print(exception) Condition x == y did not hold. Indices of first 2 different values: [[1] [3]] Corresponding x values: [3 6] Corresponding y values: [2 5] First 3 elements of x: [0 3 4] First 3 elements of y: [0 2 4] Condition x == y did not hold. Indices of first 2 different values: [[1] [3]] Corresponding x values: [3 6] Corresponding y values: [2 5] First 3 elements of x: [0 3 4] First 3 elements of y: [0 2 4] # x (3d ragged): 3 x (r1) x 2 # y (3d ragged): 3 x (r1) x 3 # trailing dimensions do not match x = tf.ragged.constant([[[1, 2], [3, 4], [5, 6]], [[7, 8], [9, 10]]]) y = tf.ragged.constant([[[1, 2, 0], [3, 4, 0], [5, 6, 0]], [[7, 8, 0], [9, 10, 0]]]) try: x + y except tf.errors.InvalidArgumentError as exception: print(exception) # x (3d ragged): 3 x (r1) x 2 # y (3d ragged): 3 x (r1) x 3 # trailing dimensions do not match x = tf.ragged.constant([[[1, 2], [3, 4], [5, 6]], [[7, 8], [9, 10]]]) y = tf.ragged.constant([[[1, 2, 0], [3, 4, 0], [5, 6, 0]], [[7, 8, 0], [9, 10, 0]]]) try: x + y except tf.errors.InvalidArgumentError as exception: print(exception) Condition x == y did not hold. Indices of first 3 different values: [[1] [2] [3]] Corresponding x values: [2 4 6] Corresponding y values: [3 6 9] First 3 elements of x: [0 2 4] First 3 elements of y: [0 3 6] Condition x == y did not hold. Indices of first 3 different values: [[1] [2] [3]] Corresponding x values: [2 4 6] Corresponding y values: [3 6 9] First 3 elements of x: [0 2 4] First 3 elements of y: [0 3 6] RaggedTensor encoding Ragged tensors are encoded using the RaggedTensor class. Internally, each RaggedTensor consists of: RaggedTensor RaggedTensor A values tensor, which concatenates the variable-length rows into a flattened list. A row_partition, which indicates how those flattened values are divided into rows. A values tensor, which concatenates the variable-length rows into a flattened list. values A row_partition, which indicates how those flattened values are divided into rows. row_partition The row_partition can be stored using four different encodings: row_partition row_splits is an integer vector specifying the split points between rows. value_rowids is an integer vector specifying the row index for each value. row_lengths is an integer vector specifying the length of each row. uniform_row_length is an integer scalar specifying a single length for all rows. row_splits is an integer vector specifying the split points between rows. row_splits value_rowids is an integer vector specifying the row index for each value. value_rowids row_lengths is an integer vector specifying the length of each row. row_lengths uniform_row_length is an integer scalar specifying a single length for all rows. uniform_row_length An integer scalar nrows can also be included in the row_partition encoding to account for empty trailing rows with value_rowids or empty rows with uniform_row_length. nrows row_partition value_rowids uniform_row_length rt = tf.RaggedTensor.from_row_splits( values=[3, 1, 4, 1, 5, 9, 2], row_splits=[0, 4, 4, 6, 7]) print(rt) rt = tf.RaggedTensor.from_row_splits( values=[3, 1, 4, 1, 5, 9, 2], row_splits=[0, 4, 4, 6, 7]) print(rt) The choice of which encoding to use for row partitions is managed internally by ragged tensors to improve efficiency in some contexts. In particular, some of the advantages and disadvantages of the different row-partitioning schemes are: Efficient indexing: The row_splits encoding enables constant-time indexing and slicing into ragged tensors. Efficient concatenation: The row_lengths encoding is more efficient when concatenating ragged tensors, since row lengths do not change when two tensors are concatenated together. Small encoding size: The value_rowids encoding is more efficient when storing ragged tensors that have a large number of empty rows, since the size of the tensor depends only on the total number of values. On the other hand, the row_splits and row_lengths encodings are more efficient when storing ragged tensors with longer rows, since they require only one scalar value for each row. Compatibility: The value_rowids scheme matches the segmentation format used by operations, such as tf.segment_sum. The row_limits scheme matches the format used by ops such as tf.sequence_mask. Uniform dimensions: As discussed below, the uniform_row_length encoding is used to encode ragged tensors with uniform dimensions. Efficient indexing: The row_splits encoding enables constant-time indexing and slicing into ragged tensors. Efficient indexing row_splits Efficient concatenation: The row_lengths encoding is more efficient when concatenating ragged tensors, since row lengths do not change when two tensors are concatenated together. Efficient concatenation row_lengths Small encoding size: The value_rowids encoding is more efficient when storing ragged tensors that have a large number of empty rows, since the size of the tensor depends only on the total number of values. On the other hand, the row_splits and row_lengths encodings are more efficient when storing ragged tensors with longer rows, since they require only one scalar value for each row. Small encoding size value_rowids row_splits row_lengths Compatibility: The value_rowids scheme matches the segmentation format used by operations, such as tf.segment_sum. The row_limits scheme matches the format used by ops such as tf.sequence_mask. Compatibility value_rowids segmentation tf.segment_sum row_limits tf.sequence_mask Uniform dimensions: As discussed below, the uniform_row_length encoding is used to encode ragged tensors with uniform dimensions. Uniform dimensions uniform_row_length Multiple ragged dimensions A ragged tensor with multiple ragged dimensions is encoded by using a nested RaggedTensor for the values tensor. Each nested RaggedTensor adds a single ragged dimension. RaggedTensor values RaggedTensor rt = tf.RaggedTensor.from_row_splits( values=tf.RaggedTensor.from_row_splits( values=[10, 11, 12, 13, 14, 15, 16, 17, 18, 19], row_splits=[0, 3, 3, 5, 9, 10]), row_splits=[0, 1, 1, 5]) print(rt) print("Shape: {}".format(rt.shape)) print("Number of partitioned dimensions: {}".format(rt.ragged_rank)) rt = tf.RaggedTensor.from_row_splits( values=tf.RaggedTensor.from_row_splits( values=[10, 11, 12, 13, 14, 15, 16, 17, 18, 19], row_splits=[0, 3, 3, 5, 9, 10]), row_splits=[0, 1, 1, 5]) print(rt) print("Shape: {}".format(rt.shape)) print("Number of partitioned dimensions: {}".format(rt.ragged_rank)) Shape: (3, None, None) Number of partitioned dimensions: 2 Shape: (3, None, None) Number of partitioned dimensions: 2 The factory function tf.RaggedTensor.from_nested_row_splits may be used to construct a RaggedTensor with multiple ragged dimensions directly by providing a list of row_splits tensors: tf.RaggedTensor.from_nested_row_splits row_splits rt = tf.RaggedTensor.from_nested_row_splits( flat_values=[10, 11, 12, 13, 14, 15, 16, 17, 18, 19], nested_row_splits=([0, 1, 1, 5], [0, 3, 3, 5, 9, 10])) print(rt) rt = tf.RaggedTensor.from_nested_row_splits( flat_values=[10, 11, 12, 13, 14, 15, 16, 17, 18, 19], nested_row_splits=([0, 1, 1, 5], [0, 3, 3, 5, 9, 10])) print(rt) Ragged rank and flat values A ragged tensor's ragged rank is the number of times that the underlying values tensor has been partitioned (i.e. the nesting depth of RaggedTensor objects). The innermost values tensor is known as its flat_values. In the following example, conversations has ragged_rank=3, and its flat_values is a 1D Tensor with 24 strings: ragged rank ragged rank values RaggedTensor values flat_values flat_values conversations flat_values Tensor # shape = [batch, (paragraph), (sentence), (word)] conversations = tf.ragged.constant( [[[["I", "like", "ragged", "tensors."]], [["Oh", "yeah?"], ["What", "can", "you", "use", "them", "for?"]], [["Processing", "variable", "length", "data!"]]], [[["I", "like", "cheese."], ["Do", "you?"]], [["Yes."], ["I", "do."]]]]) conversations.shape # shape = [batch, (paragraph), (sentence), (word)] conversations = tf.ragged.constant( [[[["I", "like", "ragged", "tensors."]], [["Oh", "yeah?"], ["What", "can", "you", "use", "them", "for?"]], [["Processing", "variable", "length", "data!"]]], [[["I", "like", "cheese."], ["Do", "you?"]], [["Yes."], ["I", "do."]]]]) conversations.shape TensorShape([2, None, None, None]) TensorShape([2, None, None, None]) assert conversations.ragged_rank == len(conversations.nested_row_splits) conversations.ragged_rank # Number of partitioned dimensions. assert conversations.ragged_rank == len(conversations.nested_row_splits) conversations.ragged_rank # Number of partitioned dimensions. 3 3 conversations.flat_values.numpy() conversations.flat_values.numpy() array([b'I', b'like', b'ragged', b'tensors.', b'Oh', b'yeah?', b'What', b'can', b'you', b'use', b'them', b'for?', b'Processing', b'variable', b'length', b'data!', b'I', b'like', b'cheese.', b'Do', b'you?', b'Yes.', b'I', b'do.'], dtype=object) array([b'I', b'like', b'ragged', b'tensors.', b'Oh', b'yeah?', b'What', b'can', b'you', b'use', b'them', b'for?', b'Processing', b'variable', b'length', b'data!', b'I', b'like', b'cheese.', b'Do', b'you?', b'Yes.', b'I', b'do.'], dtype=object) Uniform inner dimensions Ragged tensors with uniform inner dimensions are encoded by using a multidimensional tf.Tensor for the flat_values (i.e., the innermost values). tf.Tensor values rt = tf.RaggedTensor.from_row_splits( values=[[1, 3], [0, 0], [1, 3], [5, 3], [3, 3], [1, 2]], row_splits=[0, 3, 4, 6]) print(rt) print("Shape: {}".format(rt.shape)) print("Number of partitioned dimensions: {}".format(rt.ragged_rank)) print("Flat values shape: {}".format(rt.flat_values.shape)) print("Flat values:\n{}".format(rt.flat_values)) rt = tf.RaggedTensor.from_row_splits( values=[[1, 3], [0, 0], [1, 3], [5, 3], [3, 3], [1, 2]], row_splits=[0, 3, 4, 6]) print(rt) print("Shape: {}".format(rt.shape)) print("Number of partitioned dimensions: {}".format(rt.ragged_rank)) print("Flat values shape: {}".format(rt.flat_values.shape)) print("Flat values:\n{}".format(rt.flat_values)) Shape: (3, None, 2) Number of partitioned dimensions: 1 Flat values shape: (6, 2) Flat values: [[1 3] [0 0] [1 3] [5 3] [3 3] [1 2]] Shape: (3, None, 2) Number of partitioned dimensions: 1 Flat values shape: (6, 2) Flat values: [[1 3] [0 0] [1 3] [5 3] [3 3] [1 2]] Uniform non-inner dimensions Ragged tensors with uniform non-inner dimensions are encoded by partitioning rows with uniform_row_length. uniform_row_length rt = tf.RaggedTensor.from_uniform_row_length( values=tf.RaggedTensor.from_row_splits( values=[10, 11, 12, 13, 14, 15, 16, 17, 18, 19], row_splits=[0, 3, 5, 9, 10]), uniform_row_length=2) print(rt) print("Shape: {}".format(rt.shape)) print("Number of partitioned dimensions: {}".format(rt.ragged_rank)) rt = tf.RaggedTensor.from_uniform_row_length( values=tf.RaggedTensor.from_row_splits( values=[10, 11, 12, 13, 14, 15, 16, 17, 18, 19], row_splits=[0, 3, 5, 9, 10]), uniform_row_length=2) print(rt) print("Shape: {}".format(rt.shape)) print("Number of partitioned dimensions: {}".format(rt.ragged_rank)) Shape: (2, 2, None) Number of partitioned dimensions: 2 Shape: (2, 2, None) Number of partitioned dimensions: 2 Originally published on the TensorFlow website, this article appears here under a new headline and is licensed under CC BY 4.0. Code samples shared under the Apache 2.0 License. Originally published on the TensorFlow website, this article appears here under a new headline and is licensed under CC BY 4.0. Code samples shared under the Apache 2.0 License. Originally published on the TensorFlow website, this article appears here under a new headline and is licensed under CC BY 4.0. Code samples shared under the Apache 2.0 License. TensorFlow TensorFlow
