Step-by-step guide on how to use the .Net Aspire PGSQL component in Visual Studio. Introduction .Net Aspire framework is used to develop cloud and production-ready distributed applications. It consists of components to handle cloud-native concerns such as Redis, Postgres etc. Prerequisites Install .Net 8
Install Visual Studio 2022 version 17 or higher
.Net Aspire Workload
Container runtime such as Docker Desktop
10 Day .Net Aspire Challenge Objectives Learn how to create a starter project using .Net Aspire with the PGSQL EF Core component. Github Sample: The solution structure is divided into the following projects DotnetAspireChallenge.ApiService
DotnetAspireChallenge.AppHost
DotnetAspireChallenge.ServiceDefaults
DotnetAspireChallenge.Web Getting Started Step 1: Install the following NuGet package Install the following Nuget package into the subsequent project “DotnetAspireChallenge.AppHost” dotnet add package Aspire.Hosting.PostgreSQL In the above project, register a server database and customise the PGSQL connection using the following code. var postgres = builder.AddPostgres("postgres")
                          .AddDatabase("pgsqldata");

    var apiService = builder.AddProject<Projects.DotnetAspireChallenge_ApiService>("apiservice")
        .WithReference(postgres); Step 2: Install another NuGet package Install the following Nuget package into the subsequent project “DotnetAspireChallenge.ApiService” dotnet add package Aspire.Npgsql.EntityFrameworkCore.PostgreSQL then register the context into the Program.cs file as follows builder.AddNpgsqlDbContext<PgsqlDbContext>("pgsqldata"); Step 3: Create a “Customer” class public class Customer
    {
        public int Id { get; set; }

        [Required]
        public string Title { get; set; } = string.Empty;

        [Required]
        public string Description { get; set; } = string.Empty;
    } Step 4: Create an extension class Create an extension class and register a minimal API get method to demonstrate the PGSQL context usage in the API Service public static class AspirePgsqlExtension
    {
        public static void MapPgsqlAspireEndpoint(this WebApplication app)
        {
            app.MapGet("/pgsql", async (PgsqlDbContext pgsqlDbContext) =>
            {
                await pgsqlDbContext.CustomersPgsql.AddAsync(new Customer()
                {
                    Title = "test@gmail.com",
                    Description = "sukh"
                });
                int rows = await pgsqlDbContext.SaveChangesAsync();
                if (rows > 0)
                {
                    return await pgsqlDbContext.CustomersPgsql.FirstOrDefaultAsync();
                }
                else
                {
                    return null;
                }
            });
        }
    }


    internal class PgsqlDbContext(DbContextOptions options) : DbContext(options)
    {
        public DbSet<Customer> CustomersPgsql => Set<Customer>();
    } and finally, register in the Program.cs file app.MapPgsqlAspireEndpoint(); Step 5: Hit the GET endpoint Finally, navigate to the GET URL in your browser, as shown below. It will insert the specified customer into the PGSQL database, retrieve the most recently inserted row, and display it as a response. Add additional connection string properties using the JSON syntax {
      "Aspire": {
        "Npgsql": {
          "EntityFrameworkCore": {
            "PostgreSQL": {
              "ConnectionString": "YOUR_CONNECTIONSTRING",
              "DbContextPooling": true,
              "DisableHealthChecks": true,
              "DisableTracing": true,
              "AnotherDbContext": {
                "ConnectionString": "AnotherDbContext_CONNECTIONSTRING",
                "DisableTracing": false
              }
            }
          }
        }
      }
    } Congratulations..!! You’ve successfully integrated the PGSQL component into the .Net Aspire project. View Metrics The .NET Aspire component will produce the following metrics using OpenTelemetry: Microsoft.EntityFrameworkCore ec_Microsoft_EntityFrameworkCore_active_db_contexts
ec_Microsoft_EntityFrameworkCore_total_queries
ec_Microsoft_EntityFrameworkCore_queries_per_second
ec_Microsoft_EntityFrameworkCore_total_save_changes
ec_Microsoft_EntityFrameworkCore_save_changes_per_second
ec_Microsoft_EntityFrameworkCore_compiled_query_cache_hit_rate
ec_Microsoft_Entity_total_execution_strategy_operation_failures
ec_Microsoft_E_execution_strategy_operation_failures_per_second
ec_Microsoft_EntityFramew_total_optimistic_concurrency_failures
ec_Microsoft_EntityF_optimistic_concurrency_failures_per_second Npgsql ec_Npgsql_bytes_written_per_second
ec_Npgsql_bytes_read_per_second
ec_Npgsql_commands_per_second
ec_Npgsql_total_commands
ec_Npgsql_current_commands
ec_Npgsql_failed_commands
ec_Npgsql_prepared_commands_ratio
ec_Npgsql_connection_pools
ec_Npgsql_multiplexing_average_commands_per_batch
ec_Npgsql_multiplexing_average_write_time_per_batch Github Project GitHub - ssukhpinder/DotnetAspireChallenge: 10 Day .Net Aspire Challenge More Cheatsheets Cheat Sheets — .Net C# Programming🚀 Thank you for being a part of the C# community! Before you leave: Follow us: Youtube | X | LinkedIn | Dev.to Visit our other platforms: GitHub More content at C# Programming Step-by-step guide on how to use the .Net Aspire PGSQL component in Visual Studio. Introduction .Net Aspire framework is used to develop cloud and production-ready distributed applications. It consists of components to handle cloud-native concerns such as Redis, Postgres etc. Prerequisites Install .Net 8 Install Visual Studio 2022 version 17 or higher .Net Aspire Workload Container runtime such as Docker Desktop
