REDUCTION OF OXIDIZED IRON BY CARBONIC OXIDE

by Scientific American Public Domain MaterialsNovember 23rd, 2023

Too Long; Didn't Read

IT is well known that when the heat is sufficient, carbonic oxide reduces the oxide of iron to metal with the production of carbon dioxide (carbonic acid). On the other hand, at lower temperatures carbon dioxide oxidizes metallic iron, forming carbonic oxide. J. Lowthian Bell's celebrated researches (see SCIENTIFIC AMERICAN, p. 199, March 31, 1883) established the point of equilibrium where in the presence of both monoxide and dioxide the reducing action of the one just counterbalances the oxidizing action of the other. At the suggestion of Prof. R. Akermann, of Stockholm, C.G. Särnstrom has conducted a similar series of forty-five experiments, the expense being borne by the Jernkontor. About 1 gramme of oxide of iron was placed in a porcelain boat, and slid in a porcelain tube 18 millimeters (¾ inch) in diameter and 635 millimeters long (25 inches). This was exposed to the action of a current of mixed carbon dioxide and monoxide made by heating oxalic acid and concentrated sulphuric acid. It was mixed with carbon dioxide as required, then analyzed, and preserved in gasometers holding 66 liters. Before using, it is passed over phosphorus and chloride of calcium, and through sulphuric acid. The porcelain tube and boat were heated to from 300° to 600° C. (572° to 1,652° Fahr.) while the gases were passing, and then the state of oxidation determined. It was found that the larger the quantity of dioxide the higher the degree of oxidation, and the larger the proportion of monoxide the lower the degree of oxidation. The details of the experiment indicate that a saving of fuel in the blast furnace could best be accomplished by the use of a very hot blast, introducing some carbon monoxide into the blast, provided, of course, that this gas can be made outside of the blast furnace more cheaply than inside of it. Nevertheless, 643 lb. of carbon must be burned to every 1,000 lb. of iron reduced, if carbonic oxide is exclusively employed.--Stahl und Eisen.

featured image - REDUCTION OF OXIDIZED IRON BY CARBONIC OXIDE

Scientific American Supplement, No. 392, July 7, 1883 by Various, is part of the HackerNoon Books Series. You can jump to any chapter in this book here. REDUCTION OF OXIDIZED IRON BY CARBONIC OXIDE.

REDUCTION OF OXIDIZED IRON BY CARBONIC OXIDE.

At the suggestion of Prof. R. Akermann, of Stockholm, C.G. Särnstrom has conducted a similar series of forty-five experiments, the expense being borne by the Jernkontor. About 1 gramme of oxide of iron was placed in a porcelain boat, and slid in a porcelain tube 18 millimeters (¾ inch) in diameter and 635 millimeters long (25 inches). This was exposed to the action of a current of mixed carbon dioxide and monoxide made by heating oxalic acid and concentrated sulphuric acid. It was mixed with carbon dioxide as required, then analyzed, and preserved in gasometers holding 66 liters. Before using, it is passed over phosphorus and chloride of calcium, and through sulphuric acid. The porcelain tube and boat were heated to from 300° to 600° C. (572° to 1,652° Fahr.) while the gases were passing, and then the state of oxidation determined. It was found that the larger the quantity of dioxide the higher the degree of oxidation, and the larger the proportion of monoxide the lower the degree of oxidation.

The details of the experiment indicate that a saving of fuel in the blast furnace could best be accomplished by the use of a very hot blast, introducing some carbon monoxide into the blast, provided, of course, that this gas can be made outside of the blast furnace more cheaply than inside of it. Nevertheless, 643 lb. of carbon must be burned to every 1,000 lb. of iron reduced, if carbonic oxide is exclusively employed.--Stahl und Eisen.
