The Skull of the Frog (and the vertebrate skull generally)

Section 22. We have already given a description of the mammalian skull, and we have stated where the origin of the several bones was in membrane, and where in cartilage; but a more complete comprehension of the mammalian skull becomes possible with the handling of a lower type. We propose now, first to give some short account of the development and structure of the skull of the frog, and then to show briefly how its development and adult arrangement demonstrate the mammalian skull to be a fundamentally similar structure, complicated and disguised by further development and re-adjustment.

Section 23. Figure 1,I. Sheet 14, shows a dorsal view of a young tadpole cranium; the brain has been removed, and it is seen that it was supported simply upon two cartilaginous rods, the trabeculae cranii (tr.c.). Behind these trabeculae comes the notochord (n.c.), and around its anterior extremity is a paired tract of cartilage, the parachordals (p.c.). These structures, underlying the skull, are all that appear[s] at first of the brain box. In front, and separate from the cranium, are the nasal organs (n.c.); the eyes lie laterally to the trabeculae, and laterally to the parachordals are two tracts of cartilage enclosing the internal ear, the otic capsules.

Section 24. Figure 1, II., is a more advanced, phase of the same structures. The trabeculae have met in front and sent forward a median (c.t.) and lateral parts (a.o.) to support the nasal organs. They have also flattened, out very considerably, and have sent up walls on either side of the brain to meet above it and form an incomplete roof (t.) over it. The parachordals have similarly grown up round, the hind-brain and formed a complete ring, the roof of which is indicated, by b. Further, the otic capsules are fusing with the brain-case. With certain differences of form these elements-- the trabeculae, the parachordals, and the otic capsules, are also the first formed structures of the mammalian cranium.

Section 25. In Figures 1,I. and II., there appears beneath the eye a bar of cartilage (p.p.), the palato-pterygoid cartilage, which is also to be seen from the side in Figures 8,I. and III. It will be learnt from these latter that this bar is joined in front to the cranium behind the nasal organ, and behind to the otic capsule. The cartilaginous bar from the palato-pterygoid to the otic capsule is called the quadrate, and at the point of junction, at the postero-ventral angle of the palato-pterygoid, articulates with the cartilaginous bar which is destined to form the substratum of the lower jaw-- Meckel's cartilage (M.c. in Figure 8,I.).

Section 26. Figure 2 shows a dorsal view of these structures in a young frog. The parts corresponding to these in 1,II. will be easily made out, but now ossification has set in at various points of this cartilaginous cranium. In front of the otic capsule is the paired pro-otic bone (p.o.); behind it at the sides of the parachordal ring is the paired ex-occipital (e.o.); in front of the cranium box, and behind the nasal capsules, is a ring of bone, the (median, but originally paired) sphenethmoid (s.e.). -A paired ossification appears in the palato-pterygoid cartilage the pterygoid bone (pt.), while- A splint of bone, the quadrato-jugal, appears at the angle of articulation with the lower jaw. These are all the cartilage bones that appear in the cranium and upper jaw of the frog.

Section 27. But another series of bones, developed first chiefly in dermal connective tissue, and coming to plate over the cranium of cartilage, are not shown in Figure 2. They are, however, in Figure 3. These membrane bones are: along the dorsal middle line, the parieto-frontals (p.f.), originally two pairs of bones which fuse in development, and the nasals (na.). Round the edge of the jaw, and bearing the teeth, are pre-maxillae (p.m.), and maxillae (mx.), and overlying the quadrate cartilage and lateral to the otic capsules are the T-shaped squamosal bones (sq.). In the ventral view of the skull (Figure 4) we see a pair of vomers (vo.) bearing teeth, a pair of palatines (pal.), [and a pair of pterygoids (pt.)] (which [palatines and pterygoids, we may note,] unlike those of the rabbit, are -stated to be- membrane bones), and a great median dagger-shaped para-sphenoid (p.sp.). These two Figures, and 5, which shows the same bones in side view, should be carefully mastered before the student proceeds with this chapter. The cartilage bones are distinguished from membrane bones by cross-shading.

Section 28. Turning now to Figure 8,I., we have a side view of a tadpole's skull. On the ventral side of the head is a series of vertical cartilaginous bars, the visceral arches supporting the walls of the tadpole's gill slits. The first of these is called the hyoid arch (c.h.), and the four following this, the first (br.1), second, third, and fourth (br.4), branchial arches. Altogether there are four gill slits and between the hyoid arch and the jaw arch, as it is called (= Meckel's cartilage + the palato-pterygoid), is "an imperforate slit," which becomes the ear-drum.* The frog no longer breathes by gills, but by lungs, and the gills are lost, the gill slits closed, and the branchial arches consequently much reduced. Figures 8, II., and 8, III., show stages in this reduction. The hyoid arch becomes attached, to the otic capsule, and its median ventral plate, including also the vestiges of the first, second, and fourth branchial arches, is called the hyoid apparatus. In Figure 5, the apparatus is seen from the side; c.h. is called the (right) anterior cornu** of the hyoid. The function of the hyoid apparatus in the frog is to furnish, a basis of attachment to the tongue muscles; it remains cartilaginous, with the exception of the relic of one branchial arch, which ossifies as the thyro-hyal (Figure 7 th.h.). It will be noted that, as development proceeds, the angle of the jaw swings backward, and the hyoid apparatus, shifts relatively forward. These changes of position are indicated in Figure 8, III., by little arrow-heads.

* We may note here that, comparing the ear of the frog with that of the rabbit, there is no external ear. There is, moreover, no bulla supporting the middle ear, and the tympanic membrane stretches between the squamosal in front and the anterior cornu of the hyoid behind. A rod-like columella auris replaces the chain of ear ossicles, and may, or may not, answer to the stapes alone, or even possibly to the entire series. In the internal ear there is no cochlea, and the otic mass is largely cartilaginous instead of entirely bony.

** Plural cornua.

Section 29. Before proceeding to the comparison of the mammalian skull with this, we would strongly recommend the student thoroughly to master this portion of the work, and in no way can he do this more thoroughly and quickly than by taking a parboiled frog, picking off the skin, muscle, and connective tissue from its skull, and making out the various bones with the help of our diagrams.

Section 30. Figure 9 represents, in the most diagrammatic way, the main changes in form of the essential constituents of the cranio-facial apparatus, as we pass from the amphibian to the mammalian skull. F. is the frog from the side and behind; b.c. is the brain-case, o.c. the otic capsule, e. the eye, n.c. the nasal capsule, p.p. the palato-pterygoid cartilage, mx. the maxillary membrane bones, sq. the squamosal, and mb. the mandible. The student should compare with Figure 5, and convince himself that he appreciates the diagrammatic rendering of these parts. Now all the distinctive differences in form, from this of the dog's skull (D.), are reducible to two primary causes--

(1) The brain is enormously larger, and the brain-case is vastly
inflated, so that--
(2) The maxilla anteriorly and the palatine posteriorly send down palatine plates that grow in to form the bony palate, cutting off a nasal passage (n.p.) from the mouth cavity (m.p.), and carrying the posterior nares from the front part of the mouth, as they are in the frog, to the pharynx. Hence the vomers of the dog lie, not in the ceiling of the mouth, but in the floor of this nasal passage.

Section 31. The quadrate cartilage of the frog is superseded by the squamosal as the suspensorium of the lower jaw. It is greatly reduced, therefore; but it is not entirely absent. In the young mammal, a quadrate cartilage can be traced, connected with the palato-pterygoid cartilage, and articulating with Meckel's cartilage. Its position is, of course, beneath the squamosal, and just outside the otic capsule. As development proceeds, the increase in size of the quadrate, does not keep pace with that of the skull structures. It loses its connection with the palato-pterygoid, and apparently ossifies as a small ossicle-- the incus of the middle ear. A small nodule of cartilage, cut off from the proximal end of Meckel's cartilage, becomes the malleus. The stapes would appear to be derived from the hyoid arch. Hence these small bones seem to be the relics of the discarded jaw suspensorium of the frog utilized in a new function. Considerable doubt, however, attaches to this interpretation-- doubt that, if anything, is gaining ground.

Section 32. The tympanic bulla of the dog is not indicated in Diagram 9, and it would appear to be a new structure (neomorph), not represented in the frog.

Section 33. Besides these great differences in form, there are important differences in the amount and distribution of centres of ossification of the skull of frog and mammal. There is no parasphenoid in the mammal*; and, instead, a complete series of ossifications, the median-, basi-, and pre-sphenoids, and the lateral ali- and orbito-sphenoids occur. The points can be rendered much more luminously in a diagram than in the text, and we would counsel the student to compare this very carefully with that of the Rabbit.

* Faint vestigial indications occur in the developing skulls of some insectivora.

Section 34.

-Cranium_
-Upper Jaw_
<-Lower Jaw_

Section 35. -Points especially- [Additional points] to be noticed are:

(1) The otic capsule (= periotic bone) of the dog ossifies from a number of centres, one of which is equivalent to the frog's prootic.

(2) The several constituents of the lower jaw are not to be distinguished in the adult mammal.

(3) The frog has no lachrymal bone.

Section 36. We are now in a position to notice, without any danger of misconception, what is called the segmental theory of the skull. Older anatomists, working from adult structure only, conceived the idea that the brain-case of the mammal represented three inflated vertebrae. The most anterior had the pre-sphenoid for its body, the orbito-sphenoids for its neural processes, and the arch was completed above by the frontals (frontal segment). Similarly, the basi-sphenoids, ali-sphenoids, and parietals formed a second arch (parietal segment), and the ex-, basi-, and supra-occipitals a third (occipital segment). If this were correct, in the frog, which is a more primitive rendering of the vertebrate plan, we should find the vertebral characters more distinct. But, as a matter of fact, as the student will perceive, frontal segment, parietal segment, and occipital segment, can no longer be traced; and the mode of origin from trabeculae and para-chordals show very clearly the falsity of this view. The vertebrate cranium is entirely different in nature from vertebrae. The origin of the parietals and frontals as paired bones in membrane reinforces this conclusion.

Section 37. But as certainly as we have no such metameric segmentation, as this older view implies, in the brain-case of the frog, so quite as certainly is metameric segmentation evident in its branchial arches. We have the four gill slits of the tadpole and their bars repeating one another; the hyoid bar in front of these is evidently of a similar nature; and that the ear drum is derived from an imperforate gill slit is enforced by the presence of an open slit (the spiracle) in the rays and dog-fish in an entirely equivalent position. Does the mouth answer to a further pair of gill slits, and is the jaw arch (palato-pterygoid + Meckel's cartilage) equivalent to the arches that come behind it? This question has been asked, and answered in the affirmative, by many morphologists, but not by any means by all. The cranial nerves have a curious similarity of arrangement with regard to the gill slits and the mouth; the fifth nerve forks over the mouth, the seventh forks over the ear drum, the ninth, in the tadpole and fish, forks over the first branchial slit, and the tenth is, as it were, a leash of nerves, each forking over one of the remaining gill slits. But this matter will be more intelligible when the student has worked over a fish type, and need not detain us any further now.

Section 38. See also Section 13 again, in which is the suggestion that the occipital part of the skull is possibly a fusion of vertebrae, a new view with much in its favour, and obviously an entirely different one from the old "segmental" view of the entire skull, discussed in Section 36.
