Optimizing TensorFlow Input Pipelines for Peak Performance

Content Overview Best practice summary Reproducing the figures The dataset The iteration loop The plotting method Use wrappers for mapped function Pipeline comparisons Optimized Best practice summary Reproducing the figures The dataset The iteration loop The plotting method Use wrappers for mapped function Pipeline comparisons Optimized Best practice summary Here is a summary of the best practices for designing performant TensorFlow input pipelines: Use the prefetch transformation to overlap the work of a producer and consumer Parallelize the data reading transformation using the interleave transformation Parallelize the map transformation by setting the num_parallel_calls argument Use the cache transformation to cache data in memory during the first epoch Vectorize user-defined functions passed in to the map transformation Reduce memory usage when applying the interleave, prefetch, and shuffle transformations Use the prefetch transformation to overlap the work of a producer and consumer prefetch Parallelize the data reading transformation using the interleave transformation interleave Parallelize the map transformation by setting the num_parallel_calls argument map num_parallel_calls Use the cache transformation to cache data in memory during the first epoch cache Vectorize user-defined functions passed in to the map transformation map Reduce memory usage when applying the interleave, prefetch, and shuffle transformations interleave prefetch shuffle Reproducing the figures Note: The rest of this notebook is about how to reproduce the above figures. Feel free to play around with this code, but understanding it is not an essential part of this tutorial. Note: The rest of this notebook is about how to reproduce the above figures. Feel free to play around with this code, but understanding it is not an essential part of this tutorial. Note: To go deeper in the tf.data.Dataset API understanding, you can play with your own pipelines. Below is the code used to plot the images from this guide. It can be a good starting point, showing some workarounds for common difficulties such as: tf.data.Dataset Execution time reproducibility Mapped functions eager execution interleave transformation callable Execution time reproducibility Mapped functions eager execution interleave transformation callable interleave import itertools from collections import defaultdict import numpy as np import matplotlib as mpl import matplotlib.pyplot as plt import itertools from collections import defaultdict import numpy as np import matplotlib as mpl import matplotlib.pyplot as plt The dataset Similar to the ArtificialDataset you can build a dataset returning the time spent in each step. ArtificialDataset class TimeMeasuredDataset(tf.data.Dataset): # OUTPUT: (steps, timings, counters) OUTPUT_TYPES = (tf.dtypes.string, tf.dtypes.float32, tf.dtypes.int32) OUTPUT_SHAPES = ((2, 1), (2, 2), (2, 3)) _INSTANCES_COUNTER = itertools.count() # Number of datasets generated _EPOCHS_COUNTER = defaultdict(itertools.count) # Number of epochs done for each dataset def _generator(instance_idx, num_samples): epoch_idx = next(TimeMeasuredDataset._EPOCHS_COUNTER[instance_idx]) # Opening the file open_enter = time.perf_counter() time.sleep(0.03) open_elapsed = time.perf_counter() - open_enter for sample_idx in range(num_samples): # Reading data (line, record) from the file read_enter = time.perf_counter() time.sleep(0.015) read_elapsed = time.perf_counter() - read_enter yield ( [("Open",), ("Read",)], [(open_enter, open_elapsed), (read_enter, read_elapsed)], [(instance_idx, epoch_idx, -1), (instance_idx, epoch_idx, sample_idx)] ) open_enter, open_elapsed = -1., -1. # Negative values will be filtered def __new__(cls, num_samples=3): return tf.data.Dataset.from_generator( cls._generator, output_types=cls.OUTPUT_TYPES, output_shapes=cls.OUTPUT_SHAPES, args=(next(cls._INSTANCES_COUNTER), num_samples) ) class TimeMeasuredDataset(tf.data.Dataset): # OUTPUT: (steps, timings, counters) OUTPUT_TYPES = (tf.dtypes.string, tf.dtypes.float32, tf.dtypes.int32) OUTPUT_SHAPES = ((2, 1), (2, 2), (2, 3)) _INSTANCES_COUNTER = itertools.count() # Number of datasets generated _EPOCHS_COUNTER = defaultdict(itertools.count) # Number of epochs done for each dataset def _generator(instance_idx, num_samples): epoch_idx = next(TimeMeasuredDataset._EPOCHS_COUNTER[instance_idx]) # Opening the file open_enter = time.perf_counter() time.sleep(0.03) open_elapsed = time.perf_counter() - open_enter for sample_idx in range(num_samples): # Reading data (line, record) from the file read_enter = time.perf_counter() time.sleep(0.015) read_elapsed = time.perf_counter() - read_enter yield ( [("Open",), ("Read",)], [(open_enter, open_elapsed), (read_enter, read_elapsed)], [(instance_idx, epoch_idx, -1), (instance_idx, epoch_idx, sample_idx)] ) open_enter, open_elapsed = -1., -1. # Negative values will be filtered def __new__(cls, num_samples=3): return tf.data.Dataset.from_generator( cls._generator, output_types=cls.OUTPUT_TYPES, output_shapes=cls.OUTPUT_SHAPES, args=(next(cls._INSTANCES_COUNTER), num_samples) ) This dataset provides samples of shape [[2, 1], [2, 2], [2, 3]] and of type [tf.dtypes.string, tf.dtypes.float32, tf.dtypes.int32]. Each sample is: [[2, 1], [2, 2], [2, 3]] [tf.dtypes.string, tf.dtypes.float32, tf.dtypes.int32] ( [("Open"), ("Read")], [(t0, d), (t0, d)], [(i, e, -1), (i, e, s)] ) ( [("Open"), ("Read")], [(t0, d), (t0, d)], [(i, e, -1), (i, e, s)] ) Where: Open and Read are steps identifiers t0 is the timestamp when the corresponding step started d is the time spent in the corresponding step i is the instance index e is the epoch index (number of times the dataset has been iterated) s is the sample index Open and Read are steps identifiers Open Read t0 is the timestamp when the corresponding step started t0 d is the time spent in the corresponding step d i is the instance index i e is the epoch index (number of times the dataset has been iterated) e s is the sample index s The iteration loop Make the iteration loop a little bit more complicated to aggregate all timings. This will only work with datasets generating samples as detailed above. def timelined_benchmark(dataset, num_epochs=2): # Initialize accumulators steps_acc = tf.zeros([0, 1], dtype=tf.dtypes.string) times_acc = tf.zeros([0, 2], dtype=tf.dtypes.float32) values_acc = tf.zeros([0, 3], dtype=tf.dtypes.int32) start_time = time.perf_counter() for epoch_num in range(num_epochs): epoch_enter = time.perf_counter() for (steps, times, values) in dataset: # Record dataset preparation informations steps_acc = tf.concat((steps_acc, steps), axis=0) times_acc = tf.concat((times_acc, times), axis=0) values_acc = tf.concat((values_acc, values), axis=0) # Simulate training time train_enter = time.perf_counter() time.sleep(0.01) train_elapsed = time.perf_counter() - train_enter # Record training informations steps_acc = tf.concat((steps_acc, [["Train"]]), axis=0) times_acc = tf.concat((times_acc, [(train_enter, train_elapsed)]), axis=0) values_acc = tf.concat((values_acc, [values[-1]]), axis=0) epoch_elapsed = time.perf_counter() - epoch_enter # Record epoch informations steps_acc = tf.concat((steps_acc, [["Epoch"]]), axis=0) times_acc = tf.concat((times_acc, [(epoch_enter, epoch_elapsed)]), axis=0) values_acc = tf.concat((values_acc, [[-1, epoch_num, -1]]), axis=0) time.sleep(0.001) tf.print("Execution time:", time.perf_counter() - start_time) return {"steps": steps_acc, "times": times_acc, "values": values_acc} def timelined_benchmark(dataset, num_epochs=2): # Initialize accumulators steps_acc = tf.zeros([0, 1], dtype=tf.dtypes.string) times_acc = tf.zeros([0, 2], dtype=tf.dtypes.float32) values_acc = tf.zeros([0, 3], dtype=tf.dtypes.int32) start_time = time.perf_counter() for epoch_num in range(num_epochs): epoch_enter = time.perf_counter() for (steps, times, values) in dataset: # Record dataset preparation informations steps_acc = tf.concat((steps_acc, steps), axis=0) times_acc = tf.concat((times_acc, times), axis=0) values_acc = tf.concat((values_acc, values), axis=0) # Simulate training time train_enter = time.perf_counter() time.sleep(0.01) train_elapsed = time.perf_counter() - train_enter # Record training informations steps_acc = tf.concat((steps_acc, [["Train"]]), axis=0) times_acc = tf.concat((times_acc, [(train_enter, train_elapsed)]), axis=0) values_acc = tf.concat((values_acc, [values[-1]]), axis=0) epoch_elapsed = time.perf_counter() - epoch_enter # Record epoch informations steps_acc = tf.concat((steps_acc, [["Epoch"]]), axis=0) times_acc = tf.concat((times_acc, [(epoch_enter, epoch_elapsed)]), axis=0) values_acc = tf.concat((values_acc, [[-1, epoch_num, -1]]), axis=0) time.sleep(0.001) tf.print("Execution time:", time.perf_counter() - start_time) return {"steps": steps_acc, "times": times_acc, "values": values_acc} The plotting method Finally, define a function able to plot a timeline given the values returned by the timelined_benchmark function. timelined_benchmark def draw_timeline(timeline, title, width=0.5, annotate=False, save=False): # Remove invalid entries (negative times, or empty steps) from the timelines invalid_mask = np.logical_and(timeline['times'] > 0, timeline['steps'] != b'')[:,0] steps = timeline['steps'][invalid_mask].numpy() times = timeline['times'][invalid_mask].numpy() values = timeline['values'][invalid_mask].numpy() # Get a set of different steps, ordered by the first time they are encountered step_ids, indices = np.stack(np.unique(steps, return_index=True)) step_ids = step_ids[np.argsort(indices)] # Shift the starting time to 0 and compute the maximal time value min_time = times[:,0].min() times[:,0] = (times[:,0] - min_time) end = max(width, (times[:,0]+times[:,1]).max() + 0.01) cmap = mpl.cm.get_cmap("plasma") plt.close() fig, axs = plt.subplots(len(step_ids), sharex=True, gridspec_kw={'hspace': 0}) fig.suptitle(title) fig.set_size_inches(17.0, len(step_ids)) plt.xlim(-0.01, end) for i, step in enumerate(step_ids): step_name = step.decode() ax = axs[i] ax.set_ylabel(step_name) ax.set_ylim(0, 1) ax.set_yticks([]) ax.set_xlabel("time (s)") ax.set_xticklabels([]) ax.grid(which="both", axis="x", color="k", linestyle=":") # Get timings and annotation for the given step entries_mask = np.squeeze(steps==step) serie = np.unique(times[entries_mask], axis=0) annotations = values[entries_mask] ax.broken_barh(serie, (0, 1), color=cmap(i / len(step_ids)), linewidth=1, alpha=0.66) if annotate: for j, (start, width) in enumerate(serie): annotation = "\n".join([f"{l}: {v}" for l,v in zip(("i", "e", "s"), annotations[j])]) ax.text(start + 0.001 + (0.001 * (j % 2)), 0.55 - (0.1 * (j % 2)), annotation, horizontalalignment='left', verticalalignment='center') if save: plt.savefig(title.lower().translate(str.maketrans(" ", "_")) + ".svg") def draw_timeline(timeline, title, width=0.5, annotate=False, save=False): # Remove invalid entries (negative times, or empty steps) from the timelines invalid_mask = np.logical_and(timeline['times'] > 0, timeline['steps'] != b'')[:,0] steps = timeline['steps'][invalid_mask].numpy() times = timeline['times'][invalid_mask].numpy() values = timeline['values'][invalid_mask].numpy() # Get a set of different steps, ordered by the first time they are encountered step_ids, indices = np.stack(np.unique(steps, return_index=True)) step_ids = step_ids[np.argsort(indices)] # Shift the starting time to 0 and compute the maximal time value min_time = times[:,0].min() times[:,0] = (times[:,0] - min_time) end = max(width, (times[:,0]+times[:,1]).max() + 0.01) cmap = mpl.cm.get_cmap("plasma") plt.close() fig, axs = plt.subplots(len(step_ids), sharex=True, gridspec_kw={'hspace': 0}) fig.suptitle(title) fig.set_size_inches(17.0, len(step_ids)) plt.xlim(-0.01, end) for i, step in enumerate(step_ids): step_name = step.decode() ax = axs[i] ax.set_ylabel(step_name) ax.set_ylim(0, 1) ax.set_yticks([]) ax.set_xlabel("time (s)") ax.set_xticklabels([]) ax.grid(which="both", axis="x", color="k", linestyle=":") # Get timings and annotation for the given step entries_mask = np.squeeze(steps==step) serie = np.unique(times[entries_mask], axis=0) annotations = values[entries_mask] ax.broken_barh(serie, (0, 1), color=cmap(i / len(step_ids)), linewidth=1, alpha=0.66) if annotate: for j, (start, width) in enumerate(serie): annotation = "\n".join([f"{l}: {v}" for l,v in zip(("i", "e", "s"), annotations[j])]) ax.text(start + 0.001 + (0.001 * (j % 2)), 0.55 - (0.1 * (j % 2)), annotation, horizontalalignment='left', verticalalignment='center') if save: plt.savefig(title.lower().translate(str.maketrans(" ", "_")) + ".svg") Use wrappers for mapped function To run mapped function in an eager context, you have to wrap them inside a tf.py_function call. tf.py_function def map_decorator(func): def wrapper(steps, times, values): # Use a tf.py_function to prevent auto-graph from compiling the method return tf.py_function( func, inp=(steps, times, values), Tout=(steps.dtype, times.dtype, values.dtype) ) return wrapper def map_decorator(func): def wrapper(steps, times, values): # Use a tf.py_function to prevent auto-graph from compiling the method return tf.py_function( func, inp=(steps, times, values), Tout=(steps.dtype, times.dtype, values.dtype) ) return wrapper Pipelines comparison _batch_map_num_items = 50 def dataset_generator_fun(*args): return TimeMeasuredDataset(num_samples=_batch_map_num_items) _batch_map_num_items = 50 def dataset_generator_fun(*args): return TimeMeasuredDataset(num_samples=_batch_map_num_items) Naive @map_decorator def naive_map(steps, times, values): map_enter = time.perf_counter() time.sleep(0.001) # Time consuming step time.sleep(0.0001) # Memory consuming step map_elapsed = time.perf_counter() - map_enter return ( tf.concat((steps, [["Map"]]), axis=0), tf.concat((times, [[map_enter, map_elapsed]]), axis=0), tf.concat((values, [values[-1]]), axis=0) ) naive_timeline = timelined_benchmark( tf.data.Dataset.range(2) .flat_map(dataset_generator_fun) .map(naive_map) .batch(_batch_map_num_items, drop_remainder=True) .unbatch(), 5 ) @map_decorator def naive_map(steps, times, values): map_enter = time.perf_counter() time.sleep(0.001) # Time consuming step time.sleep(0.0001) # Memory consuming step map_elapsed = time.perf_counter() - map_enter return ( tf.concat((steps, [["Map"]]), axis=0), tf.concat((times, [[map_enter, map_elapsed]]), axis=0), tf.concat((values, [values[-1]]), axis=0) ) naive_timeline = timelined_benchmark( tf.data.Dataset.range(2) .flat_map(dataset_generator_fun) .map(naive_map) .batch(_batch_map_num_items, drop_remainder=True) .unbatch(), 5 ) WARNING:tensorflow:From /tmpfs/tmp/ipykernel_112933/64197174.py:32: calling DatasetV2.from_generator (from tensorflow.python.data.ops.dataset_ops) with output_types is deprecated and will be removed in a future version. Instructions for updating: Use output_signature instead WARNING:tensorflow:From /tmpfs/tmp/ipykernel_112933/64197174.py:32: calling DatasetV2.from_generator (from tensorflow.python.data.ops.dataset_ops) with output_shapes is deprecated and will be removed in a future version. Instructions for updating: Use output_signature instead Execution time: 13.208576904999973 WARNING:tensorflow:From /tmpfs/tmp/ipykernel_112933/64197174.py:32: calling DatasetV2.from_generator (from tensorflow.python.data.ops.dataset_ops) with output_types is deprecated and will be removed in a future version. Instructions for updating: Use output_signature instead WARNING:tensorflow:From /tmpfs/tmp/ipykernel_112933/64197174.py:32: calling DatasetV2.from_generator (from tensorflow.python.data.ops.dataset_ops) with output_shapes is deprecated and will be removed in a future version. Instructions for updating: Use output_signature instead Execution time: 13.208576904999973 Optimized @map_decorator def time_consuming_map(steps, times, values): map_enter = time.perf_counter() time.sleep(0.001 * values.shape[0]) # Time consuming step map_elapsed = time.perf_counter() - map_enter return ( tf.concat((steps, tf.tile([[["1st map"]]], [steps.shape[0], 1, 1])), axis=1), tf.concat((times, tf.tile([[[map_enter, map_elapsed]]], [times.shape[0], 1, 1])), axis=1), tf.concat((values, tf.tile([[values[:][-1][0]]], [values.shape[0], 1, 1])), axis=1) ) @map_decorator def memory_consuming_map(steps, times, values): map_enter = time.perf_counter() time.sleep(0.0001 * values.shape[0]) # Memory consuming step map_elapsed = time.perf_counter() - map_enter # Use tf.tile to handle batch dimension return ( tf.concat((steps, tf.tile([[["2nd map"]]], [steps.shape[0], 1, 1])), axis=1), tf.concat((times, tf.tile([[[map_enter, map_elapsed]]], [times.shape[0], 1, 1])), axis=1), tf.concat((values, tf.tile([[values[:][-1][0]]], [values.shape[0], 1, 1])), axis=1) ) optimized_timeline = timelined_benchmark( tf.data.Dataset.range(2) .interleave( # Parallelize data reading dataset_generator_fun, num_parallel_calls=tf.data.AUTOTUNE ) .batch( # Vectorize your mapped function _batch_map_num_items, drop_remainder=True) .map( # Parallelize map transformation time_consuming_map, num_parallel_calls=tf.data.AUTOTUNE ) .cache() # Cache data .map( # Reduce memory usage memory_consuming_map, num_parallel_calls=tf.data.AUTOTUNE ) .prefetch( # Overlap producer and consumer works tf.data.AUTOTUNE ) .unbatch(), 5 ) @map_decorator def time_consuming_map(steps, times, values): map_enter = time.perf_counter() time.sleep(0.001 * values.shape[0]) # Time consuming step map_elapsed = time.perf_counter() - map_enter return ( tf.concat((steps, tf.tile([[["1st map"]]], [steps.shape[0], 1, 1])), axis=1), tf.concat((times, tf.tile([[[map_enter, map_elapsed]]], [times.shape[0], 1, 1])), axis=1), tf.concat((values, tf.tile([[values[:][-1][0]]], [values.shape[0], 1, 1])), axis=1) ) @map_decorator def memory_consuming_map(steps, times, values): map_enter = time.perf_counter() time.sleep(0.0001 * values.shape[0]) # Memory consuming step map_elapsed = time.perf_counter() - map_enter # Use tf.tile to handle batch dimension return ( tf.concat((steps, tf.tile([[["2nd map"]]], [steps.shape[0], 1, 1])), axis=1), tf.concat((times, tf.tile([[[map_enter, map_elapsed]]], [times.shape[0], 1, 1])), axis=1), tf.concat((values, tf.tile([[values[:][-1][0]]], [values.shape[0], 1, 1])), axis=1) ) optimized_timeline = timelined_benchmark( tf.data.Dataset.range(2) .interleave( # Parallelize data reading dataset_generator_fun, num_parallel_calls=tf.data.AUTOTUNE ) .batch( # Vectorize your mapped function _batch_map_num_items, drop_remainder=True) .map( # Parallelize map transformation time_consuming_map, num_parallel_calls=tf.data.AUTOTUNE ) .cache() # Cache data .map( # Reduce memory usage memory_consuming_map, num_parallel_calls=tf.data.AUTOTUNE ) .prefetch( # Overlap producer and consumer works tf.data.AUTOTUNE ) .unbatch(), 5 ) Execution time: 6.8234945540007175 Execution time: 6.8234945540007175 draw_timeline(naive_timeline, "Naive", 15) draw_timeline(naive_timeline, "Naive", 15) /tmpfs/tmp/ipykernel_112933/2966908191.py:17: MatplotlibDeprecationWarning: The get_cmap function was deprecated in Matplotlib 3.7 and will be removed in 3.11. Use ``matplotlib.colormaps[name]`` or ``matplotlib.colormaps.get_cmap()`` or ``pyplot.get_cmap()`` instead. cmap = mpl.cm.get_cmap("plasma") /tmpfs/tmp/ipykernel_112933/2966908191.py:17: MatplotlibDeprecationWarning: The get_cmap function was deprecated in Matplotlib 3.7 and will be removed in 3.11. Use ``matplotlib.colormaps[name]`` or ``matplotlib.colormaps.get_cmap()`` or ``pyplot.get_cmap()`` instead. cmap = mpl.cm.get_cmap("plasma") draw_timeline(optimized_timeline, "Optimized", 15) draw_timeline(optimized_timeline, "Optimized", 15) /tmpfs/tmp/ipykernel_112933/2966908191.py:17: MatplotlibDeprecationWarning: The get_cmap function was deprecated in Matplotlib 3.7 and will be removed in 3.11. Use ``matplotlib.colormaps[name]`` or ``matplotlib.colormaps.get_cmap()`` or ``pyplot.get_cmap()`` instead. cmap = mpl.cm.get_cmap("plasma") /tmpfs/tmp/ipykernel_112933/2966908191.py:17: MatplotlibDeprecationWarning: The get_cmap function was deprecated in Matplotlib 3.7 and will be removed in 3.11. Use ``matplotlib.colormaps[name]`` or ``matplotlib.colormaps.get_cmap()`` or ``pyplot.get_cmap()`` instead. cmap = mpl.cm.get_cmap("plasma") Originally published on the TensorFlow website, this article appears here under a new headline and is licensed under CC BY 4.0. Code samples shared under the Apache 2.0 License. Originally published on the TensorFlow website, this article appears here under a new headline and is licensed under CC BY 4.0. Code samples shared under the Apache 2.0 License. Originally published on the TensorFlow website, this article appears here under a new headline and is licensed under CC BY 4.0. Code samples shared under the Apache 2.0 License. TensorFlow TensorFlow
