Moving Logic Out of Pods: Extending the Argo Workflows Controller

In this article, I'll show how the Argo Workflows Executor Plugin lets you extend the Argo Workflows controller without maintaining your own fork—simply by implementing a small HTTP server in any language. As a bonus, this same mechanism reduces the number of extra pods in your DAGs and lightens the load on the Kubernetes scheduler. If you're new to Argo, I'll briefly cover the architecture and where plugins fit in. We'll finish with practical examples and key configuration details. Argo Workflows Executor Plugin Argo Workflows Motivation I decided to write this article about the Argo Workflows Executor Plugin while working on a Kubernetes Enhancement Proposal (KEP) for Kubeflow Pipelines, where I needed a deeper understanding of its security model, capabilities, and limitations. Argo Workflows Executor Plugin TL;DR: Argo Workflows Before diving into Executor Plugins, let’s quickly recap what Argo Workflows is and how it executes workflows. What is a Workflow? Workflow A workflow is a sequence of tasks executed in a defined order and typically described in YAML. It can be a simple linear chain or a complex DAG with parallel steps and dependencies. Workflows are common in CI/CD, data processing, ML pipelines, and any scenario that requires coordinating multiple tasks reliably. Argo Workflows is a Kubernetes-native engine that takes these YAML-defined workflows and executes each task in its own pod. This provides parallelism, explicit dependencies, and precise resource control, while leveraging Kubernetes scaling, scheduling, and reliability. With this model, Argo can orchestrate anything from simple automation to full CI/CD and ML pipelines. Argo Argo Workflows Workflows Inside Argo Workflows: Architecture Overview Let’s look at a simple three-step YAML from the official docs to see how Argo Workflows is structured and how its components interact. YAML Interactions with Argo Workflows typically start via the Argo CLI. Argo CLI Argo CLI For example, if I’ve downloaded a workflow YAML description called hello.yaml. I can create an Argo Workflow from it by running:: YAML argo submit hello.yaml argo submit hello.yaml Under the hood, the CLI sends the YAML definition to the Kubernetes API, which creates an Argo Workflow Custom Resource (CR). Argo Workflow Custom Resource (CR) Once Kubernetes creates a Workflow CR, the Workflow Controller starts managing its lifecycle, as shown below. At a high level, the WorkflowController in Argo Workflows v3.7.3 operates with two informers: one for Workflow CRDs and one for the Pods created during workflow execution. Both informers push keys into their respective queues for reconciliation. one one one one WorkflowInformer → WorkflowQueue: The controller processes Workflow changes and creates/manages the necessary Pods.PodInformer → WorkflowQueue: It watches the workflow Pods, and Pod status changes generate events that update the Workflow and trigger another reconciliation cycle. WorkflowInformer → WorkflowQueue: The controller processes Workflow changes and creates/manages the necessary Pods. WorkflowInformer → WorkflowQueue: creates/manages PodInformer → WorkflowQueue: It watches the workflow Pods, and Pod status changes generate events that update the Workflow and trigger another reconciliation cycle. PodInformer → WorkflowQueue: Every Workflow Step Is a Kubernetes Pod (until you introduce an Executor Plugin) This design comes with a lot of benefits. Since each step runs in its own pod, you can fully leverage the Kubernetes scheduler, pre-allocate or limit resources for individual tasks, and take advantage of pod restart for reliability. You also have full access to Kubernetes primitives, such as volumes, networking, and other resources, giving you complete control over workflow execution. On top of that, you get out-of-the-box access to logs, since each pod’s logs can be inspected directly. This setup is especially ideal for heavy or relatively long-running tasks, where visibility, resource control, and fault isolation are crucial for keeping the cluster stable and preventing interference with other workloads. But how does this work in practice? In a workflow, each step is based on a template. Let’s look at an example from the official documentation: apiVersion: argoproj.io/v1alpha1 kind: Workflow metadata: generateName: steps- spec: entrypoint: hello-hello-hello # This spec contains two templates: hello-hello-hello and print-message templates: - name: hello-hello-hello # Instead of just running a container # This template has a sequence of steps steps: - - name: hello1 # hello1 is run before the following steps template: print-message arguments: parameters: - name: message value: "hello1" - - name: hello2a # double dash => run after previous step template: print-message arguments: parameters: - name: message value: "hello2a" - name: hello2b # single dash => run in parallel with previous step template: print-message arguments: parameters: - name: message value: "hello2b" # This is the same template as from the previous example - name: print-message inputs: parameters: - name: message container: image: busybox command: [echo] args: ["{{inputs.parameters.message}}"] apiVersion: argoproj.io/v1alpha1 kind: Workflow metadata: generateName: steps- spec: entrypoint: hello-hello-hello # This spec contains two templates: hello-hello-hello and print-message templates: - name: hello-hello-hello # Instead of just running a container # This template has a sequence of steps steps: - - name: hello1 # hello1 is run before the following steps template: print-message arguments: parameters: - name: message value: "hello1" - - name: hello2a # double dash => run after previous step template: print-message arguments: parameters: - name: message value: "hello2a" - name: hello2b # single dash => run in parallel with previous step template: print-message arguments: parameters: - name: message value: "hello2b" # This is the same template as from the previous example - name: print-message inputs: parameters: - name: message container: image: busybox command: [echo] args: ["{{inputs.parameters.message}}"] Here we can see template:container, which means a pod will be created for all steps, as shown below. template:container kubectl -n argo get po kubectl -n argo get po NAMEREADYSTATUSRESTARTS AGEsteps-6zjdt-print-message-227836356 0/2Completed0 60ssteps-6zjdt-print-message-3558628268 0/2Completed0 50ssteps-6zjdt-print-message-3608961125 0/2Completed0 50s NAMEREADYSTATUSRESTARTS AGEsteps-6zjdt-print-message-227836356 0/2Completed0 60ssteps-6zjdt-print-message-3558628268 0/2Completed0 50ssteps-6zjdt-print-message-3608961125 0/2Completed0 50s NAMEREADYSTATUSRESTARTS AGEsteps-6zjdt-print-message-227836356 0/2Completed0 60s NAMEREADYSTATUSRESTARTS AGE NAME READY STATUS RESTARTS AGE steps-6zjdt-print-message-227836356 0/2Completed0 60s steps-6zjdt-print-message-227836356 0/2 Completed 0 60s steps-6zjdt-print-message-3558628268 0/2Completed0 50ssteps-6zjdt-print-message-3608961125 0/2Completed0 50s steps-6zjdt-print-message-3558628268 0/2Completed0 50s steps-6zjdt-print-message-3558628268 0/2 Completed 0 50s steps-6zjdt-print-message-3608961125 0/2Completed0 50s steps-6zjdt-print-message-3608961125 0/2 Completed 0 50s Pods Come with Overhead Pods Come with Overhead However, if some of our tasks are lightweight or execute very quickly, the “one pod per task” approach has drawbacks. Pod Overhead – Each pod consumes additional resources beyond the container itself, including networking, cgroups, and filesystem overheadStartup Latency – For very fast tasks, a pod may take longer to start than the task itself, introducing noticeable time overheadScheduler Load – Many pods increase scheduler load, and resources may not be available immediately, causing scheduling delaysResource Inefficiency – Pods reserve resources even for short tasks, which can lead to over-provisioning Pod Overhead – Each pod consumes additional resources beyond the container itself, including networking, cgroups, and filesystem overhead Pod Overhead Pod Overhead Startup Latency – For very fast tasks, a pod may take longer to start than the task itself, introducing noticeable time overhead Startup Latency Scheduler Load – Many pods increase scheduler load, and resources may not be available immediately, causing scheduling delays Scheduler Load Scheduler Load Resource Inefficiency – Pods reserve resources even for short tasks, which can lead to over-provisioning Resource Inefficiency In practice, this means you want separate pods for long‑running or heavy steps, while lightweight tasks are better off sharing a long‑lived pod that can be reused across many steps. So, How Do We Reduce Pod Creation Overhead? Executor Plugin was introduced to address exactly this class of problems: they let you move step execution out of per‑step pods into a reusable agent pod, without modifying the core controller or maintaining a fork. Executor Plugin Executor Plugin At a high level, instead of creating a new pod for each step with template: container, a template: plugin creates a single agent pod that is reused for all steps using that plugin while the workflow is running. template: container template: plugin Why run user code in a separate agent pod instead of the Workflow Controller? Running user code in a separate agent pod has several benefits: Protecting the Controller: The workflow controller is a critical component. Isolating user tasks prevents crashes, hangs, or resource spikes in user code from affecting the controller itself.Flexible extensibility: This setup allows implementing additional behavior in any programming language. You can extend it simply by providing a container image that runs a small server responding to /api/v1/template.execute. Protecting the Controller: The workflow controller is a critical component. Isolating user tasks prevents crashes, hangs, or resource spikes in user code from affecting the controller itself. Protecting the Controller: Flexible extensibility: This setup allows implementing additional behavior in any programming language. You can extend it simply by providing a container image that runs a small server responding to /api/v1/template.execute. Flexible extensibility: /api/v1/template.execute Prerequisites for the Executor Plugin Simply changing a template from container to plugin isn’t enough - some preparation is required beforehand. container plugin Let’s look at a high-level overview of how the Executor Plugin works. Components specific to the Executor Plugin are highlighted in green on the diagram: To get your plugin up and running, you need to follow a few key high-level steps. Details for each step are provided below: Details for each step are provided below Configure the Argo Workflow Controller and enable the Executor Plugin by setting the environment variable ARGO_EXECUTOR_PLUGINS=trueImplement a server (in any programming language) that exposes the /api/v1/template.execute endpoint - this is the component that will implement your plugin’s logic - and package it as a Docker image.Create a ConfigMap that stores the plugin’s settings by its name - for example, specifying the Docker image you built in the previous step.Add additional RBAC permissions (such as create/patch for WorkflowTaskSet) to the ServiceAccount that Argo uses to run your Workflow.Secure your plugin - for example, by restricting access to the agent pod from anything outside the Argo Workflow Controller.Add additional ServiceAccount permissions if needed - for example, granting access to the Kubernetes API. Configure the Argo Workflow Controller and enable the Executor Plugin by setting the environment variable ARGO_EXECUTOR_PLUGINS=true Configure the Argo Workflow Controller ARGO_EXECUTOR_PLUGINS=true Implement a server (in any programming language) that exposes the /api/v1/template.execute endpoint - this is the component that will implement your plugin’s logic - and package it as a Docker image. Implement a server /api/v1/template.execute Create a ConfigMap that stores the plugin’s settings by its name - for example, specifying the Docker image you built in the previous step. Create a ConfigMap Add additional RBAC permissions (such as create/patch for WorkflowTaskSet) to the ServiceAccount that Argo uses to run your Workflow. Add additional RBAC permissions WorkflowTaskSet Secure your plugin - for example, by restricting access to the agent pod from anything outside the Argo Workflow Controller. Secure your plugin Add additional ServiceAccount permissions if needed - for example, granting access to the Kubernetes API. Add additional ServiceAccount permissions First, here’s a link to the repository where I implemented all these steps in Argo Workflows so the plugin can be used. I’ll be using examples from this repo in the sections below. First, here’s a link to the repository where I implemented all these steps in Argo Workflows so the plugin can be used. I’ll be using examples from this repo in the sections below. link link Configure the Argo Workflow Controller Configure the Argo Workflow Controller By default, the Argo Workflow Executor Plugin is disabled in the Workflow Controller. As a result, the Workflow Controller ignores any plugin configurations that were added to the cluster. To enable it, simply add the environment variable ARGO_EXECUTOR_PLUGINS=true. ARGO_EXECUTOR_PLUGINS=true In my demo repository, I do this by patching the Workflow Controller as shown below: patching patching apiVersion: apps/v1 kind: Deployment metadata: name: workflow-controller namespace: argo spec: template: spec: containers: - name: workflow-controller env: # Enable the Executor Plugin. # The Executor Plugin is disabled by default. # Without this environment variable, the workflow-controller # will not register any executor plugins. - name: ARGO_EXECUTOR_PLUGINS value: "true" apiVersion: apps/v1 kind: Deployment metadata: name: workflow-controller namespace: argo spec: template: spec: containers: - name: workflow-controller env: # Enable the Executor Plugin. # The Executor Plugin is disabled by default. # Without this environment variable, the workflow-controller # will not register any executor plugins. - name: ARGO_EXECUTOR_PLUGINS value: "true" Once enabled, the Workflow Controller uses a special informer to watch all new or updated ConfigMaps containing plugin settings. special informer ConfigMaps It automatically registers any Executor Plugins defined in these ConfigMaps, based on the following label: kubectl get cm -l workflows.argoproj.io/configmap-type=ExecutorPlugin kubectl get cm -l workflows.argoproj.io/configmap-type=ExecutorPlugin Implement a server Implement a server Logic of a plugin is implemented in a server. Plugin it is the extending point for the Argo Workflow Controller. Argo Workflow Controller communicates with a plugin via the API contract. API contract Here is the brief explanation of the contract. The server must respond to the /api/v1/template.execute endpoint.The server should respond with a JSON object like this: The server must respond to the /api/v1/template.execute endpoint. The server should respond with a JSON object like this: { "node": { "phase": "Succeeded", // Use "Failed" to mark the step as failed // other parameters, e.g., outputs } } { "node": { "phase": "Succeeded", // Use "Failed" to mark the step as failed // other parameters, e.g., outputs } } Important: To mark a step as failed, the server should return "phase": "Failed". HTTP errors are treated as unexpected issues by the controller and split into transient (retried) and non-transient categories. For more details, refer to the documentation. Important: To mark a step as failed, the server should return "phase": "Failed". HTTP errors are treated as unexpected issues by the controller and split into transient (retried) and non-transient categories. For more details, refer to the documentation. Important: "phase": "Failed" unexpected issues documentation Here’s an example of a simple server implementation written in Python: from fastapi import FastAPI, Request, HTTPException import uvicorn app = FastAPI() @app.post("/api/v1/template.execute") async def execute(request: Request): data = await request.json() print_message_plugin_request = data.get("template", {}).get("plugin", {}).get("print-message-plugin") if print_message_plugin_request is None: return None if print_message_plugin_request.get('args') is None: raise HTTPException(status_code=400, detail=f"invalid request body. " f"Expecting template.plugin.print-message-plugin.args, found: f{data}") message = print_message_plugin_request.get('args') print(f"PRINT: {message}" if message else "No message") return { "node": { "phase": "Succeeded", "outputs": { "parameters": [{"name": "result", "value": f'{message} processed by print-message-plugin'}] } } } if __name__ == "__main__": uvicorn.run(app, host="0.0.0.0", port=8080) from fastapi import FastAPI, Request, HTTPException import uvicorn app = FastAPI() @app.post("/api/v1/template.execute") async def execute(request: Request): data = await request.json() print_message_plugin_request = data.get("template", {}).get("plugin", {}).get("print-message-plugin") if print_message_plugin_request is None: return None if print_message_plugin_request.get('args') is None: raise HTTPException(status_code=400, detail=f"invalid request body. " f"Expecting template.plugin.print-message-plugin.args, found: f{data}") message = print_message_plugin_request.get('args') print(f"PRINT: {message}" if message else "No message") return { "node": { "phase": "Succeeded", "outputs": { "parameters": [{"name": "result", "value": f'{message} processed by print-message-plugin'}] } } } if __name__ == "__main__": uvicorn.run(app, host="0.0.0.0", port=8080) It simply prints a message and returns a string in the output, which can be used as an input parameter for the next steps or DAG tasks. This is essentially our extension point About the Request Parameter About the Request Parameter If you submit the following Argo Workflow: apiVersion: argoproj.io/v1alpha1 kind: Workflow metadata: generateName: steps-plugin- spec: entrypoint: hello-hello-hello templates: - name: hello-hello-hello steps: - - name: hello1 template: print-message arguments: parameters: - name: message value: "hello1" - name: print-message inputs: parameters: - name: message plugin: print-message-plugin: args: ["{{inputs.parameters.message}}"] apiVersion: argoproj.io/v1alpha1 kind: Workflow metadata: generateName: steps-plugin- spec: entrypoint: hello-hello-hello templates: - name: hello-hello-hello steps: - - name: hello1 template: print-message arguments: parameters: - name: message value: "hello1" - name: print-message inputs: parameters: - name: message plugin: print-message-plugin: args: ["{{inputs.parameters.message}}"] The request body sent to the plugin according to the template will be: template.plugin.print-message-plugin.args: template.plugin.print-message-plugin.args: Explanation: template.plugin – constant part of the request structure.print-message-plugin – the name of the plugin being called.args – the parameter(s) defined in the template.value – can be a simple type (string, number) or a JSON object. template.plugin – constant part of the request structure. template.plugin print-message-plugin – the name of the plugin being called. print-message-plugin args – the parameter(s) defined in the template. args value – can be a simple type (string, number) or a JSON object. value Inject the Plugin Server Implementation into an Argo Workflow Here, everything is simple and follows the standard Argo Workflow approach: Build a Docker image from your plugin server. A demo example is provided in this repository.Create a ConfigMap in the cluster specifying this image and other plugin parameters (user, ServiceAccount, resources, etc.). Build a Docker image from your plugin server. A demo example is provided in this repository. Build a Docker image provided Create a ConfigMap in the cluster specifying this image and other plugin parameters (user, ServiceAccount, resources, etc.). Create a ConfigMap According to the documentation, you can build the ConfigMap as follows: Create a plugin.yaml file. Create a plugin.yaml file. plugin.yaml Sample for the print-message-plugin: print-message-plugin apiVersion: argoproj.io/v1alpha1 kind: ExecutorPlugin metadata: name: print spec: sidecar: container: image: print-message-plugin:latest name: print-message-plugin ports: - containerPort: 8080 securityContext: runAsNonRoot: false runAsUser: 65534 # nobody resources: requests: memory: "64Mi" cpu: "250m" limits: memory: "128Mi" cpu: "500m" apiVersion: argoproj.io/v1alpha1 kind: ExecutorPlugin metadata: name: print spec: sidecar: container: image: print-message-plugin:latest name: print-message-plugin ports: - containerPort: 8080 securityContext: runAsNonRoot: false runAsUser: 65534 # nobody resources: requests: memory: "64Mi" cpu: "250m" limits: memory: "128Mi" cpu: "500m" Build the ConfigMap using the Argo CLI (make sure it is installed): Build the ConfigMap using the Argo CLI (make sure it is installed): Argo CLI Argo CLI argo executor-plugin build . argo executor-plugin build . This command creates a ConfigMap and a README explaining how to apply it. This command creates a ConfigMap and a README explaining how to apply it. The Workflow Controller will pick up the plugin automatically. When an Argo Workflow runs, it will execute our plugin image inside a dedicated agent pod. Add additional RBAC permissions for WorkflowTaskSet WorkflowTaskSet This is necessary for updating workflow statuses. Official Documentation Sample in my demo project Official Documentation Official Documentation Official Documentation Sample in my demo project Sample in my demo project Secure the plugin to only accept requests from the Argo Workflow Controller As noted, our plugin runs as a sidecar container inside a dedicated pod. It exposes an HTTP endpoint externally. This means that, in theory, any workload in the cluster could send HTTP requests to the plugin sidecar, so it is important to add basic access controls instead of relying on defaults. The minimal change we need to make in plugin.yaml plugin.yaml apiVersion: argoproj.io/v1alpha1 kind: ExecutorPlugin metadata: name: print spec: sidecar: container: #... securityContext: #... runAsUser: 1000 # A user is now required to access the token from the sidecar container; we can no longer use a non-root user. #... apiVersion: argoproj.io/v1alpha1 kind: ExecutorPlugin metadata: name: print spec: sidecar: container: #... securityContext: #... runAsUser: 1000 # A user is now required to access the token from the sidecar container; we can no longer use a non-root user. #... By default (without extra customization): The Argo Workflow Controller mounts the /var/run/argo volume into the agent-pod (which hosts the plugin sidecar). This volume contains a token. /var/run/argo The Argo Workflow Controller includes the same token in the Authorization Bearer header of each execution request. The Argo Workflow Controller includes the same token in the Authorization Bearer header of each execution request. Additionally: Inside the plugin, you need to read the token from /var/run/argo/token and compare it with the token from the request header. /var/run/argo/token with open("/var/run/argo/token") as f: token = f.read().strip() def do_POST(self): if self.headers.get("Authorization") != "Bearer " + token: self.forbidden() with open("/var/run/argo/token") as f: token = f.read().strip() def do_POST(self): if self.headers.get("Authorization") != "Bearer " + token: self.forbidden() Mount the ServiceAccount to the agent pod Kubernetes uses a default-deny model for API access. If your plugin needs to call the Kubernetes API (for example, to list pods or create resources), you must mount a ServiceAccount into the sidecar container and grant it the minimal required RBAC permissions. If your plugin needs to call the Kubernetes API Let’s walk through a simple example: writing a plugin that calls the Kubernetes API and prints the list of pods in the namespace specified in the request. Here is an example server implementation. from fastapi import FastAPI, Request, HTTPException import uvicorn import os from kubernetes import config, client app = FastAPI() config.load_incluster_config() k8s = client.CoreV1Api() def list_pods_in_namespace(namespace: str): # This is where we query the Kubernetes API to list pods. # The ServiceAccount must be mounted into the pod and have the required RBAC permissions # to list pods in the specified namespace. pods = k8s.list_namespaced_pod(namespace=namespace) return [p.metadata.name for p in pods.items] @app.post("/api/v1/template.execute") async def execute(request: Request): data = await request.json() plugin_request = data.get("template", {}).get("plugin", {}).get("list-pods-plugin") if plugin_request is None: return None if plugin_request.get('namespace') is None: raise HTTPException(400, 'namespace parameter is missing') namespace = plugin_request.get('namespace') print(f'namespace: {namespace}') pod_list = list_pods_in_namespace(namespace) return { "node": { "phase": "Succeeded", "outputs": { "parameters": [{"name": "result", "value": f'pods in ns {namespace}: {",".join(pod_list)}'}] } } } if __name__ == "__main__": uvicorn.run(app, host="0.0.0.0", port=8082) from fastapi import FastAPI, Request, HTTPException import uvicorn import os from kubernetes import config, client app = FastAPI() config.load_incluster_config() k8s = client.CoreV1Api() def list_pods_in_namespace(namespace: str): # This is where we query the Kubernetes API to list pods. # The ServiceAccount must be mounted into the pod and have the required RBAC permissions # to list pods in the specified namespace. pods = k8s.list_namespaced_pod(namespace=namespace) return [p.metadata.name for p in pods.items] @app.post("/api/v1/template.execute") async def execute(request: Request): data = await request.json() plugin_request = data.get("template", {}).get("plugin", {}).get("list-pods-plugin") if plugin_request is None: return None if plugin_request.get('namespace') is None: raise HTTPException(400, 'namespace parameter is missing') namespace = plugin_request.get('namespace') print(f'namespace: {namespace}') pod_list = list_pods_in_namespace(namespace) return { "node": { "phase": "Succeeded", "outputs": { "parameters": [{"name": "result", "value": f'pods in ns {namespace}: {",".join(pod_list)}'}] } } } if __name__ == "__main__": uvicorn.run(app, host="0.0.0.0", port=8082) For mounting the ServiceAccount into the executor plugin sidecar, automountServiceAccountToken must be set to true. automountServiceAccountToken Here is an example YAML showing how to mount the ServiceAccount token into the executor plugin sidecar: apiVersion: argoproj.io/v1alpha1 kind: ExecutorPlugin metadata: name: print spec: sidecar: automountServiceAccountToken: true container: image: list-pods-plugin:latest name: list-pods-plugin ports: - containerPort: 8082 securityContext: runAsNonRoot: false runAsUser: 1001 resources: requests: memory: "64Mi" cpu: "250m" limits: memory: "128Mi" cpu: "500m" apiVersion: argoproj.io/v1alpha1 kind: ExecutorPlugin metadata: name: print spec: sidecar: automountServiceAccountToken: true container: image: list-pods-plugin:latest name: list-pods-plugin ports: - containerPort: 8082 securityContext: runAsNonRoot: false runAsUser: 1001 resources: requests: memory: "64Mi" cpu: "250m" limits: memory: "128Mi" cpu: "500m" Reminder: to obtain the ConfigMap required to add the plugin to the cluster, you need to run the following command. argo executor-plugin build . argo executor-plugin build . Afterwards, apply the created ConfigMap to the cluster. The executor plugin then runs with its own dedicated ServiceAccount, separate from the one used by the Argo Workflow. This approach improves security by allowing fine-grained control over the permissions granted to the executor plugin. The ServiceAccount name is predefined and cannot be customized. It is always set to: -executor-plugin (for example, list-pods-plugin-executor-plugin in this case). set to -executor-plugin list-pods-plugin-executor-plugin With the token mounted, the executor plugin can authenticate with the Kubernetes API and perform actions allowed by its ServiceAccount. RBAC details are not included here. For everything needed to try out the plugins, see my demo repo with instructions: here. here here Handling Multiple Plugins When multiple Executor Plugins are installed in the cluster (for example, from different teams), the Argo Workflow Controller calls them sequentially until one handles the task. sequentially Always check the plugin name in your server: Always check the plugin name in your server: @app.post("/api/v1/template.execute") async def execute(request: Request): data = await request.json() # Check if this is OUR plugin my_plugin_request = data.get("template", {}).get("plugin", {}).get("print-message-plugin") if my_plugin_request is None: return None # ← Pass to the next plugin # Execute logic only for our plugin name # ... @app.post("/api/v1/template.execute") async def execute(request: Request): data = await request.json() # Check if this is OUR plugin my_plugin_request = data.get("template", {}).get("plugin", {}).get("print-message-plugin") if my_plugin_request is None: return None # ← Pass to the next plugin # Execute logic only for our plugin name # ... Why this matters: Why this matters: Without the check, your plugin might unexpectedly process tasks meant for othersreturn None tells the controller: "not my request, try the next plugin"The first plugin returning phase: "Succeeded" or phase: "Failed" completes execution Without the check, your plugin might unexpectedly process tasks meant for others return None tells the controller: "not my request, try the next plugin" return None The first plugin returning phase: "Succeeded" or phase: "Failed" completes execution phase: "Succeeded" phase: "Failed" See the discussion here. here Final Example: One Pod Instead of Three Now that the plugin is properly installed and configured, let's run the same steps workflow - but using our plugin. apiVersion: argoproj.io/v1alpha1 kind: Workflow metadata: generateName: steps-plugin- spec: entrypoint: hello-hello-hello templates: - name: hello-hello-hello steps: - - name: hello1 template: print-message arguments: parameters: - name: message value: "hello1" - - name: hello2a template: print-message arguments: parameters: - name: message value: "hello2a" - name: hello2b template: print-message arguments: parameters: - name: message value: "hello2b" - name: print-message inputs: parameters: - name: message plugin: print-message-plugin: args: ["{{inputs.parameters.message}}"] apiVersion: argoproj.io/v1alpha1 kind: Workflow metadata: generateName: steps-plugin- spec: entrypoint: hello-hello-hello templates: - name: hello-hello-hello steps: - - name: hello1 template: print-message arguments: parameters: - name: message value: "hello1" - - name: hello2a template: print-message arguments: parameters: - name: message value: "hello2a" - name: hello2b template: print-message arguments: parameters: - name: message value: "hello2b" - name: print-message inputs: parameters: - name: message plugin: print-message-plugin: args: ["{{inputs.parameters.message}}"] Before (standard template: container): Before template: container : kubectl -n argo get po kubectl -n argo get po NAME READY STATUS RESTARTS AGE steps-6zjdt-print-message-2278363560/2Completed060ssteps-6zjdt-print-message-35586282680/2Completed050ssteps-6zjdt-print-message-36089611250/2Completed050s NAME READY STATUS RESTARTS AGE steps-6zjdt-print-message-2278363560/2Completed060ssteps-6zjdt-print-message-35586282680/2Completed050ssteps-6zjdt-print-message-36089611250/2Completed050s NAME READY STATUS RESTARTS AGE steps-6zjdt-print-message-2278363560/2Completed060ssteps-6zjdt-print-message-35586282680/2Completed050ssteps-6zjdt-print-message-36089611250/2Completed050s NAME READY STATUS RESTARTS AGE NAME READY STATUS RESTARTS AGE steps-6zjdt-print-message-2278363560/2Completed060s steps-6zjdt-print-message-227836356 0/2 Completed 0 60s steps-6zjdt-print-message-35586282680/2Completed050s steps-6zjdt-print-message-3558628268 0/2 Completed 0 50s steps-6zjdt-print-message-36089611250/2Completed050s steps-6zjdt-print-message-3608961125 0/2 Completed 0 50s After (using template: plugin): After template: plugin kubectl -n argo get po kubectl -n argo get po NAME READY STATUS RESTARTS AGEsteps-plugin-7fkgk-1340600742-agent 4/4Running019s NAME READY STATUS RESTARTS AGEsteps-plugin-7fkgk-1340600742-agent 4/4Running019s NAME READY STATUS RESTARTS AGEsteps-plugin-7fkgk-1340600742-agent 4/4Running019s NAME READY STATUS RESTARTS AGE NAME READY STATUS RESTARTS AGE steps-plugin-7fkgk-1340600742-agent 4/4Running019s steps-plugin-7fkgk-1340600742-agent 4/4 Running 0 19s The same workflow now runs all three steps on a single reusable agent pod, reducing pod creation overhead and scheduler load. all three steps on a single reusable agent pod HTTP Template (Bonus Alternative) There's also the http template - a simpler alternative to full plugins when you just need to make an HTTP request and use the full response. http template Works exactly like plugins but without custom server code: Works exactly like plugins but without custom server code: Single agent pod handles all template: http steps/tasksNo plugin implementation needed - just point to any HTTP endpointFull response (JSON, status, headers) flows back as workflow outputs Single agent pod handles all template: http steps/tasks template: http No plugin implementation needed - just point to any HTTP endpoint Full response (JSON, status, headers) flows back as workflow outputs When NOT to Use Executor Plugins Executor Plugins aren't always needed. Stick with standard pods for the classic Argo Workflows use case: long-running or resource-heavy tasks where you want Kubernetes to precisely control scheduling, resource allocation, and isolation per step.Plugins also unnecessary for tasks Argo already handles natively, like notifications. Executor Plugins aren't always needed. Stick with standard pods for the classic Argo Workflows use case: long-running or resource-heavy tasks where you want Kubernetes to precisely control scheduling, resource allocation, and isolation per step. Plugins also unnecessary for tasks Argo already handles natively, like notifications. notifications Real-World Use Cases from Community Proposing an "http" step type in Argo to delegate task execution via HTTP instead of spinning up a container, improving efficiency and enabling integration with systems like Brigade.Official Argo Plugin Directory In my KEP, plugin checks cache first - reuses outputs or executes + caches. Ideal for ms-fast schema validation vs. 5-10s pod startup. Proposing an "http" step type in Argo to delegate task execution via HTTP instead of spinning up a container, improving efficiency and enabling integration with systems like Brigade. "http" Official Argo Plugin Directory Official Argo Plugin Directory Official Argo Plugin Directory In my KEP, plugin checks cache first - reuses outputs or executes + caches. Ideal for ms-fast schema validation vs. 5-10s pod startup. KEP KEP Conclusion Executor Plugins powerfully extend Argo Workflows without controller forks, enabling seamless integration with external systems via HTTP and eliminating pod fluctuations for lightweight tasks. Useful Links Argo Workflows ArchitectureArgo CLI ReferenceExecutor Plugins DocumentationPlugin DirectoryMy Demo Repo - Minikube-ready manifests, Dockerfiles, workflows used in this article, and step-by-step deployment guide Argo Workflows Architecture Argo Workflows Architecture Argo CLI Reference Argo CLI Reference Executor Plugins Documentation Executor Plugins Documentation Plugin Directory Plugin Directory My Demo Repo - Minikube-ready manifests, Dockerfiles, workflows used in this article, and step-by-step deployment guide My Demo Repo Featured image: Photo by Ian Taylor on Unsplash Featured image: Photo by Ian Taylor on Unsplash Featured image Ian Taylor Ian Taylor Unsplash
