Make yourself a Go web server with MongoDb. Go on, Go on, Go on…

by Eamonn McEvoyMarch 12th, 2017
Read on Terminal Reader
Read this story w/o Javascript
tldt arrow

Too Long; Didn't Read

I mostly program in c# and node.js, this article is a result of my recent dabbling in go. I set out to create a simple web back end in go to see how it compares with node. I like node because it allows me to create apis extremely quickly, but on the downside most projects depend heavily on external libraries leading to huge code bloat and <a href="https://hackernoon.com/im-harvesting-credit-card-numbers-and-passwords-from-your-site-here-s-how-9a8cb347c5b5" target="_blank">potentially malicious code</a>.

People Mentioned

Mention Thumbnail

Company Mentioned

Mention Thumbnail
featured image - Make yourself a Go web server with MongoDb. Go on, Go on, Go on…
Eamonn McEvoy HackerNoon profile picture

I mostly program in c# and node.js, this article is a result of my recent dabbling in go. I set out to create a simple web back end in go to see how it compares with node. I like node because it allows me to create apis extremely quickly, but on the downside most projects depend heavily on external libraries leading to huge code bloat and potentially malicious code.

I have created a small app to demonstrate setting up a rest api, testing, hashing user passwords, and storing data in MongoDb, the full code can be viewed here:


eamonnmcevoy/go_rest_api_go_rest_api - Go web server with mongoDb_github.com

  1. Create and retrieve users from mongoDb
  2. Salted passwords
  3. REST API — creating and retrieving users
  4. The cmd folder — link it all up
  5. Authentication (sort of)

Package layout

In this project I have tried to follow the ‘Standard package layout’ described by Ben Johnson.

Here’s what this looks like:

go_rest_api  /cmd    /app      -app.go      -main.go  /pkg    /mongo    /server    /mock    -user.go

In the /cmd folder we have our main application code, this is simply used to wire up our dependencies and start the server.

The /pkg folder is where the bulk of our code lives. At the root level we define our domain types and interfaces, our root package will not depend on any other package.

Part 0 — Environment Setup

If you haven’t already installed Go, go do that: Install guide

If you haven’t already learned the basics of Go, go do that: Go tour

Ensure your GOPATH directory is layed out in this format:




GOPATH//bin (to output your built executable files)/pkg (to store your projects dependencies)/src (your code goes here)

We will use a few external dependencies in this project so lets download them all now. Run the following commands in your GOPATH dir.



//requiredgo get gopkg.in/mgo.v2 //MongoDb drivergo get golang.org/x/crypto/bcrypt //password hashing




//could live withoutgo get github.com/gorilla/mux //http routergo get github.com/gorilla/handlers //http request logginggo get github.com/google/uuid //generate password salt

We could implement this project without Gorilla thanks to Go’s fantastic built in http library. However, once your rest api starts to increase in complexity a more fully featured routing toolkit like Gorilla will come in very handy.

Last but not least, install a version of MongoDb and start the server by running mongod on the command line.

https://docs.mongodb.com/manual/installation/

Part 1 — Create and retrieve users from Mongo

Lets get started, the first thing we need is a User data type. In the pkg folder create the file user.go and define the type and service interface.

Next we need to implement our UserService, since we have decided to use MongoDb as our database lets create a mongo package and implement the service in that.

Create a folder pkg/mongo, and add two files user_model.go, and user_service.go

In this file we define 3 important things

  1. The document structure we will be inserting into Mongo — userModel. We are not using root.Model here so that we can keep our dependency on gopkg/mgo.v2/bson confined to the mongo package.
  2. The index to be applied to our user collection. This index allows us to quickly query Mongo on the Username field and prevents duplicate Username's.
  3. newUserModel and toRootUser functions to convert between userModel and root.User

You may have noticed the obvious security flaw in this model, we are storing passwords in plain text; Don’t worry we will address this with a salted hash in part 2.

This is the basis for our UserService implementation. The constructor gets a collection from the session parameter and sets up the user index.

Implementing our interface is very simple. The Create function is pretty self explanatory, convert root.User to userModel and insert into our collection. GetByUsername performs a Mongo find operation for a single user with a matching username.

Lastly, we will create a session.go file to manage the connection to Mongo.

This file defines three simple functions to create, access, and close a Mongo session, as well as get a pointer to a collection from that session.

That’s it, we have fully implemented our UserService as defined in the root package, and exported functions for creating and maintaining a Mongo session; time to write some tests and see if it works. Create another new file in the Mongo package mongo_test.go

In this integration test we insert a single user into our database, verify that 1 user exists in the collection, and that they matches our test data. Head to the command line and run the test


➜ go test ./src/go_rest_api/pkg/mongo/ok go_rest_api/pkg/mongo 0.145s

Success!

…or is it? You’ll notice that, if we run the test a second time we get an error.

2017/03/14 22:58:04 Unable to create user: E11000 duplicate key error collection: test_db.user index: username_1 dup key: { : "integration_test_user" }

We need a way to clean up the test database after ourselves, lets extend session.go to provide a function to drop a database. Open up session.go and add the following function:

Then modify the defer statement in mongo_test.go

Now we run the tests to our hearts content!

Part 2 — Salted passwords

In part 1 we implemented a service to store user documents in MongoDb; however we are storing the user password in plain text. Lets introduce a new go package to allow us to generate and compare salted hashes.

Define an interface for our hash functions in the root package:

And the implementation, in /pkg/crypto/hash.go

Our implementation generates a hash with the format {hash}||{salt}, this make storing the the hash-salt combination slightly more convenient as we only in a single database field instead of two. We now need to test our implementation to see if it works, we’ll test that we can successfully compare a generated hash to an input string, detect when an incorrect attempt is made, and that a generated hash produces a different result each time it is called.

Now that we know our cryto package is working lets modify user_service.go to store hashed passwords instead of plain text. Extend the NewUserService function to accept an instance of root.Hash, then use it to generated a hashed password in Create.

So far so good, but the Mongo tests are now broken due to the added parameter. We’ll need to create a mock Hash implementation in order to maintain the separation between packages. Create a very simple mock in pkg/mock/hash.go

Then, in mongo_test.go simply instantiate the UserService instance with the mock Hash implementation.

That’s it, in this section we have created a crypto packing to handle password salting, added interaction between packages, and created the first mock implementation

Part 3 — REST API for creating and retrieving users

The next major component in the system is the http router, we’ll be using the Gorrilla mux package to configure our rest endpoints. This package will consist of three files:




go_web_server/pkg/server/server.go -- configure router & starts listeningresponse.go -- helper functions for sending responsesuser_router.go -- routes for our user service

The NewServer function initialises the server and user subrouter, this allows us to direct all requests beginning with /user into the user_router.go file. Start simply starts our server on port 8080, we are additionally passing all requests through the gorilla LoggingHandler to provide automatic request logging to stdout.

The user router exposes two rest endpoints for interacting with the Mongo service.

  1. PUT /users/ for adding new users to the db.
  2. GET /users/{username} for searching for users with a given username.

You will notice a few unusal function calls to Json and Error, these are helper functions defined in response.go

Part 4 — The cmd folder, link it all up

Now that the server mongo and crypto packages are working we can wire them up into a functioning web server. Create the folder go_web_server/cmd/app and add main.go

Now we can compile and run the server:



➜ go install ./src/go_web_server/cmd/app➜ ./bin/app.exe2017/04/25 13:50:35 Listening on port 8080

Using postman we can easily test the server endpoints.

We now have a working server, at this point we could hook it up to a web front-end or mobile app and develop a user registration form. The next major piece of functionality we need is the ability to authenticate users and protect endpoints. (of course, you shouldn’t actually return the users password here).

Part 5 — User authentication (sort of)

I won’t create a full user authentication system here, just an endpoint to verify user credentials. In my next post I’ll show how you can offload this responsibility to the fantastic kong api gateway.

Following the same patterns we used in the previous sections I’ve added a simple endpoint to accept a username / password combo, and find a user in the database with matching credentials. If a user is found, return them, otherwise return an error.

After all that work we’ve created a fairly useless api, but its ours and we love it.

I recommend this article if you want to be persuaded to learn go: https://medium.com/@kevalpatel2106/why-should-you-learn-go-f607681fad65

This article to read more about the folder structure I used in this project: https://medium.com/@benbjohnson/standard-package-layout-7cdbc8391fc1
