JavaScript Concurrency Models: The Event Loop

JavaScript has a concurrency model based on an event loop, which is responsible for executing the code, collecting and processing events, and executing queued sub-tasks. This model is quite different from models in other languages like C and Java.

Runtime concepts

The following sections explain a theoretical model. Modern JavaScript engines implement and heavily optimize the described semantics.

Visual representation

Stack

Function calls form a stack of frames.

function foo(b) {
  let a = 10
  return a + b + 11
}

function bar(x) {
  let y = 3
  return foo(x * y)
}

console.log(bar(7)) //returns 42

When calling

bar

bar's

bar

foo

foo

bar

bar

Heap

Objects are allocated in a heap which is just a name to denote a large (mostly unstructured) region of memory.

Queue

A JavaScript runtime uses a message queue, which is a list of messages to be processed. Each message has an associated function which gets called in order to handle the message.

At some point during the event loop, the runtime starts handling the messages on the queue, starting with the oldest one. To do so, the message is removed from the queue and its corresponding function is called with the message as an input parameter. As always, calling a function creates a new stack frame for that function's use.

The processing of functions continues until the stack is once again empty. Then, the event loop will process the next message in the queue (if there is one).

Event loop

The event loop got its name because of how it's usually implemented, which usually resembles:

while (queue.waitForMessage()) {
  queue.processNextMessage()
}

queue.waitForMessage()

"Run-to-completion"

Each message is processed completely before any other message is processed.

This offers some nice properties when reasoning about your program, including the fact that whenever a function runs, it cannot be pre-empted and will run entirely before any other code runs (and can modify data the function manipulates). This differs from C, for instance, where if a function runs in a thread, it may be stopped at any point by the runtime system to run some other code in another thread.

A downside of this model is that if a message takes too long to complete, the web application is unable to process user interactions like click or scroll. The browser mitigates this with the "a script is taking too long to run" dialog. A good practice to follow is to make message processing short and if possible cut down one message into several messages.

Adding messages

In web browsers, messages are added anytime an event occurs and there is an event listener attached to it. If there is no listener, the event is lost. So a click on an element with a click event handler will add a message — likewise with any other event.

The function

setTimeout

0

setTimeout

setTimeout

const s = new Date().getSeconds();

setTimeout(function() {
  // prints out "2", meaning that the callback is not called immediately after 500 milliseconds.
  console.log("Ran after " + (new Date().getSeconds() - s) + " seconds");
}, 500)

while (true) {
  if (new Date().getSeconds() - s >= 2) {
    console.log("Good, looped for 2 seconds")
    break;
  }
}

Zero delays

Zero delay doesn't actually mean the call back will fire-off after zero milliseconds. Calling

setTimeout

0

The execution depends on the number of waiting tasks in the queue. In the example below, the message

''this is just a message''

Basically, the

setTimeout

setTimeout

(function() {

  console.log('this is the start');

  setTimeout(function cb() {
    console.log('Callback 1: this is a msg from call back');
  }); // has a default time value of 0

  console.log('this is just a message');

  setTimeout(function cb1() {
    console.log('Callback 2: this is a msg from call back');
  }, 0);

  console.log('this is the end');

})();

// "this is the start"
// "this is just a message"
// "this is the end"
// "Callback 1: this is a msg from call back"
// "Callback 2: this is a msg from call back"

Several runtimes communicating together

A web worker or a cross-origin

iframe

postMessage

Never blocking

A very interesting property of the event loop model is that JavaScript, unlike a lot of other languages, never blocks. Handling I/O is typically performed via events and callbacks, so when the application is waiting for an IndexedDB query to return or an XHR request to return, it can still process other things like user input.

Legacy exceptions exist like

alert

Specifications

• HTML Living Standard. The definition of 'Event loops' in that specification.
• Node.js Event Loop

Credits

• Source: https://developer.mozilla.org/en-US/docs/Web/JavaScript/EventLoop
• Published under Open CC Attribution ShareAlike 3.0 license
