Scientific American Supplement, No. 392, July 7, 1883 by Various, is part of the HackerNoon Books Series. You can jump to any chapter in this book . IMPROVED WATER METER. here IMPROVED WATER METER. We annex illustrations of a meter designed by Mr. A. Schmid, of Zürich, and which, according to , is now considerably used on the Continent, not only for measuring water, but the sirup in sugar factories, in breweries, etc. It consists of a cast iron body containing two gun-metal-lined cylinders, and connected by an intermediate chamber. Round the body are formed two channels, one for the entrance and the other for the discharge of the water, etc., to be measured. Within the cylinder are placed two long pistons, provided with openings in such a way that each piston serves as a slide valve to the other, the flow being maintained through the ports in the connecting chamber. The arrangement of openings in the piston is shown in Figs. 5, 6, 7, and the intermediate passages in Figs. 1, 2, and 3. To the upper side of each piston is attached a cross-head working on a disk placed at each end of a horizontal shaft. To one of the disks is added a short connecting rod that drives the spindle of a counter. Engineering About HackerNoon Book Series: We bring you the most important technical, scientific, and insightful public domain books. This book is part of the public domain. Various (2005). Scientific American Supplement, No. 392, July 7, 1883. Urbana, Illinois: Project Gutenberg. Retrieved https://www.gutenberg.org/cache/epub/8742/pg8742-images.html This eBook is for the use of anyone anywhere at no cost and with almost no restrictions whatsoever. You may copy it, give it away or re-use it under the terms of the Project Gutenberg License included with this eBook or online at , located at . www.gutenberg.org https://www.gutenberg.org/policy/license.html
