How We Set Up a Production Ready CI Workflow Using GitHub Actions

Author profile picture

@mertron-paMerlin

I write about developer innovation and new technologies at Project A.

Recently, we started a new project and it decided it was a good time to try GitHub’s newish CI/CD tools which became generally available in November last year.

Our experience with GitHub actions has been mostly positive, so I thought I’d share how we use it in production.

This article is the first part of two — one article for each workflow.

So, let’s start with the continuous integration process:

Workflow Overview

Our continuous integration workflow has two jobs:

  1. Lint the code with Flake8 and test the application with Pytest.
  2. Build a Docker Image and publish it to Google’s container registry.

Project Overview

These instructions will make more sense if you understand how our project is set up.

It’s a web app for a major property tech startup. It consists of four sub-applications which interact with each other as well as several external services.

A basic overview of the platform architecture

Aside from the front end, all apps need to interact with Google Pub/Sub message queues (which explains why we use a Google Pub/Sub emulator in our workflow).

For example, when someone changes customer contact details in the frontend, the following events are triggered:

  • The back end database is immediately updated.
  • In the background, a message is placed in the queue for the middleware — our own open source project called “Herbie”.
  • Herbie pulls the message from the queue and validates the message against a stored data schema (in this case, for the business entity “customer”).
  • Herbie then transforms the message into a format that Salesforce can understand, and puts it in a queue for the Salesforce push worker.
  • The Salesforce push worker pulls the message from the queue and pushes the change to Salesforce.
  • That way, customer details are always up-to-date in both the Web app and Salesforce — which makes the salespeople happy.

    In the following section, I’m going to describe how we set up CI for the back end app. However, the workflows for each app essentially follow the same structure.

    To follow along, you first need to create a workflow file.

    Create a workflow file

    This is easy to do in GitHub’s user interface.

    In your repo, go to the Actions tab and click New Workflow. In the following screen, click “set up a workflow yourself”. This creates a commented workflow file which we can then edit.

    Define the triggering event

    We wanted workflow to happen whenever someone pushed to any branch. So we updated our workflow file as follows.

    name: CI

    on:
      push:
        branches:
          - '**'

    For more information on the trigger syntax, see GitHub’s official doc on events.

    Define the jobs

    After each push, we wanted to test the app, take a snapshot of it, and archive it as a Docker image in our container registry (just in case we needed to roll back to an earlier iteration of the app).

    For this purpose, we defined two jobs:

    • Job 1: Run the tests
    • Job 2: Build and publish the Docker image

    If the first job fails, there’s no need to run the second job. We only want to archive working versions of the app.

    Job #1: Run the tests

    As mentioned, we want to lint the code with Flake8 and test the application with Pytest — but we need to set up the environment and install all the dependencies first.

    Define the environment and service containers

    To run our tests, we install most of the dependencies directly on the virtual machine.

    But there are a few components that would be excessively complex to set up if we were to install them directly, such as:

  • The database: The backend uses a PostgreSQL database.
  • The Pub/Sub emulator: This is Google’s tool to emulate their Pub/Sub messaging service locally.
    • Normally the back end would push to a queue running another app (Herbie) but we don’t need the real queue for testing.
    • We just want to test that the back end interacts correctly with a queue.

    For these components, we can Docker containers instead. We defined these as “Service Containers” with the following syntax:


    jobs:
      tests: # Job ID
        name: Tests # Name of the job displayed on GitHub.
        runs-on: ubuntu-latest # OS for the GitHub-hosted virtual machine
        services: # Define Docker containers to use for this job.
          backend-db: # Container ID for our database container
            image: postgres:12.1 # Image to pull from Docker Hub
            env:
              POSTGRES_USER: user
              POSTGRES_PASSWORD: password
              POSTGRES_DB: backend_db
            ports:
            - 5432:5432 # TCP port to expose on Docker container and host environment
          backend-gcloud-pubsub: # Container ID for our Pub/Sub container
            image: 'knarz/pubsub-emulator' # Image to pull from Docker Hub
            ports:
              - '8085:8085' # TCP port to expose on Docker container and host environment

    When the workflow is triggered, GithHub pulls the following images from Docker Hub:

    Define the steps and actions

    Next, we start defining the steps in our job. Many of the steps use what GitHub calls “actions” which are essentially small predefined scripts that execute one specific task. GitHub provides their own built-in actions and there’s a marketplace for actions that other users have contributed. You can also build your own actions — I’ll describe how we did this in a companion article about our continuous deployment workflow.

    But for this guide, we just use actions from the GitHub marketplace.

    1) Check out the working branch and Set up SSH credentials

    We need to check out our working branch on our virtual machine, but instead of running git checkout, we just use a built-in GitHub checkout action.

    Next, we set up the ssh credentials on the virtual machine. In this step, we get the SSH key from a secret.

       steps:
        - name: Checkout working branch
          uses: actions/checkout@v1

        - name: Setup ssh
          run: |
            mkdir ~/.ssh/
            echo "${{ secrets.SSH_PRIVATE_KEY }}" > ~/.ssh/id_rsa
            chmod 600 ~/.ssh/id_rsa
            touch ~/.ssh/known_hosts
            ssh-keyscan github.com >> ~/.ssh/known_hosts

    Secrets are environment variables that are encrypted and only exposed to selected actions. You create these secrets in the repository settings. In our case we’re using the private key for our GitHub machine user.

    We need an SSH key so that the machine user can authenticate with Github and clone some of our other private repositories to the virtual machine.

    2) Set up Python and install the PostgreSQL client

    Next, we use with another built-in action to set up our required Python version. Then we install the PostgreSQL client. We have our database running in a docker container, but we need a client to access it.

       - name: Set up Python 3.8
          uses: actions/setup-python@v1
          with:
            python-version: 3.8

       - name: Install PostgreSQL 11 client
          run: |
            sudo apt-get -yqq install libpq-dev

    3) Set up caching

    We cache the dependencies that we have installed from previous runs so that we don’t have to keep installing them over again.

    We set up caching using the built-in cache action.

    It checks any file where dependencies are defined (such as Python’s “requirements.txt”) to see if it has been updated. If not, it loads the dependencies from the cache.

    However, we don’t use “requirements.txt”. However, we don’t use “requirements.txt”. Instead, we use a tool called Poetry to manage Python dependencies. With this tool, you define your dependencies in a file called “pyproject.toml”, which we’ve committed to our repo. When you initialize or update a Poetry project, a Poetry automatically generates a “poetry.lock” file based on the contents of the .toml file.

    So we configure the cache action to check for changes to our poetry.lock file instead. It does this by comparing the file hashes for the cached and incoming versions of the lock file.

       - name: Cache Poetry
          uses: actions/cache@v1
          id: cache
          with:
            path: ~/.cache/pip
            key: ${{ runner.os }}-pip-${{ hashFiles('**/poetry.lock') }}
            restore-keys: |
              ${{ runner.os }}-pip-

    4) Install dependencies

    Next, we upgrade pip and install Poetry.

    Once Poetry is installed, we use it to install the dependencies listed in our poetry.lock file. These dependencies include the linting and testing tools which we’ll use in the following steps.

       - name: Install dependencies, config poetry virtualenv
          run: |
            python -m pip install --upgrade pip
            pip install poetry
            poetry config virtualenvs.create false
            poetry install --no-interaction

    5) Lint the code

    Next we lint the Python code to make sure it adheres to our style guide. For this, we use the Flake8 Tool which we run here.

       - name: Lint with flake8
          run: |
            # stop the build if there are Python syntax errors or undefined names
            flake8 . --count --select=E9,F63,F7,F82 --show-source --statistics
            # exit-zero treats all errors as warnings. The GitHub editor is 127 chars wide
            flake8 . --count --exit-zero --max-complexity=10 --max-line-length=127 --statistics

    6) Run the tests

    We’re going to test for any issues with the localizations so we’ll need the GNU gettext utilities which we install in a preparation step. In the main test step, we first compile the localization messages, then run our tests with pytest.

    We provide pytest with a whole bunch of environment variables which mostly have dummy values. Not all of the variables are used in the tests but they need to be present when building the app container that we’ll use for testing.

    - name: Install gettext for translations
          run: |
            sudo apt-get update && sudo apt-get install -y gettext
       - name: Test with pytest
          run: |
            python manage.py compilemessages
            pytest --verbose
          env:
            CLUSTER_ENV: test
            RUN_DEV: 0
            POSTGRES_DB: backend_db
            POSTGRES_USER: user
            POSTGRES_PASSWORD: password
            POSTGRES_DB_PORT: 5432
            POSTGRES_DB_HOST: localhost
            SECRET_KEY: thisisasecret
            SENDGRID_API_KEY: 'test-key'
            PUBSUB_EMULATOR_HOST: localhost:8085
            GCLOUD_PUBSUB_PROJECT_ID: 'test-project'
            HERBIE_TOKEN: 'random-key'
            HERBIE_HOST: 'http://localhost:8000'

    OK, so that’s it for the tests. If you want to see the job in its entirety, check out this gist of our workflow file. If the tests all pass, we run the next job.

    Job #2: Build the Docker image and publish it to a registry

    Assuming the tests have passed, we build and archive our app image in a private container registry. In our cases, it’s a Google Container Registry.

    Define the run conditions

    As with last time, we set the job ID “docker-image”, give it a name and define the host operating system.

    We also specify that we need the previous job to have returned a success error code, using the “needs” syntax.

      docker-image:
          name: Build & Publish Docker Image
          needs: [tests]
          runs-on: ubuntu-latest

    Define the job steps

    1) Check out the branch and set environment variables

    The first step is the “check out branch” action which I described in the first job. We have to do this again because data is not persisted from job to job (unless you explicitly configure “job artifacts”).

    After the check out step, we define specific environment variables:

    • The Google Container Registry URL - here we set “‘eu.gcr.io” which is for images hosted in the European Union.
    • The Docker image name which uses the registry URL as a prefix and in this case resolves to “eu.gcr.io/acme-555555/backend” (the middle part of the path is the Google customer name and customer ID).
       steps:
        - name: Checkout working branch
          uses: actions/checkout@v1

        - name: Set Docker Registry
          run: echo ::set-env name=DOCKER_REGISTRY::eu.gcr.io

        - name: Set Docker Image
          run: echo ::set-env name=DOCKER_IMAGE::${{ env.DOCKER_REGISTRY }}/acme-555555/backend

    2) Log in to the Google Container Registry, then build and Push the image

    For this task, we use two user-contributed actions to log in to the container registry and push the Docker image to the registry. GitHub’s virtual machines include a lot of preinstalled software, such as the Google Cloud SDK — which our “login” and “push” actions use.

    To log in to Google Cloud, we use another secret — “‘secrets.GCLOUD_KEY”, which is the service account key for our Google Cloud project. Again, this is secret defined in the repository settings.

    When the login step completes, the GitHub action outputs the username and password for the container registry — which we then use in the “build and push”step.

       - name: Login to gcloud registry
          id: gcloud
          uses: elgohr/gcloud-login-action@0.2
          with:
            account_key: ${{ secrets.GCLOUD_KEY }}

        - name: Publish Docker Image
          uses: elgohr/Publish-Docker-Github-Action@2.14
          env:
            SSH_PRIVATE_KEY: ${{ secrets.SSH_PRIVATE_KEY }}
          with:
            name: ${{ env.DOCKER_IMAGE }}
            username: ${{ steps.gcloud.outputs.username }}
            password: ${{ steps.gcloud.outputs.password }}
            registry: ${{ env.DOCKER_REGISTRY }}
            buildargs: SSH_PRIVATE_KEY
    • The secret “secrets.SSH_PRIVATE_KEY” is our machine user’s SSH key, which is then passed in as a build argument for the Docker image. This enables the container to perform operations that need SSH credentials such as cloning private git repositories (which we need to do for a couple of our dependencies).
    • The username and password arguments come from the previous step using the outputs mechanism.

    By default, the “publish” action tags the Docker image name of the branch.

    Each branch is prefixed with a JIRA ticket number so that JIRA can automatically detect it and link it to the ticket. In the Docker registry our images look something like this:

    Name: 8cd6851d850b Tag: XYZ-123_add_special_field_todo_magic

    I mention this only because the action provides other ways to tag the image. In my article about our deployment workflow, I’ll show you a different method.

    And that is the end of the workflow. If you want to see the workflow file in its entirety, check out this gist.

    A note about container storage

    One day in the distant future our container registry is going to get quite large.

    If we’re storing a 333 MB image on every push, we could reach up to 1 GB after three pushes. A GB of container storage costs $0.026 every month so it’s not exactly going to break the bank. Nevertheless, you’re using another container registry, you might want to manage your storage capacity and clean up older images.

    Luckily there are scripts out there to do this, such as this one.

    Summary

    As you can see, workflows are pretty easy to set up. Plus they don’t cost anything extra. We have a GitHub Enterprise license but they’re also available for all other GitHub Products. Just be aware that there are limitations on the number of minutes that actions can consume, and these limits differ according to your GitHub license.

    Obviously, your repos have to be in GitHub and you can’t test the workflows locally — they have to run on GitHub’s servers. But what you can do is use your own virtual machine to run specific jobs.

    For future projects, we’ll probably stick with GitHub CI/CD workflows since we found that they were easier to use than other tools such as Jenkins or Travis.

    If you found this walkthrough useful, check out my companion article about our deployment workflow.
