How To Setup Caching in Node.js using Redis

In this article, we are going to implement caching in a node js
application using Redis, but, before we delve into the implementation
details, let’s explore what caching is and how it can help the
performance of our application.

What is caching?

Caching is the process of storing copies of files in a cache or a
temporary storage location so that they can be accessed more quickly. - Cloudflare

Now that we understand what caching is, let’s explore the reason for caching

Why do we cache?

Given many super fast services and options available for users on the
Internet today, you don’t want your application to take too long to
respond to users’ requests or you risk the chance of your users dumping
your service for a competitor and keep your bounce-rate growing instead
of your revenue.

Below are a few of the reasons we cache:

• To save cost. Such as paying for bandwidth or even volume of data sent over the network.
• To reduce app response time.

In general, caching done the right way will improve the performance
of our application and lead to a win-win situation for us and our users.

Prerequisites

To follow through this tutorial you must have the following installed on your computer

• Node JS
• NPM
• Postman/Web Browser
• Code Editor (VsCode)

If you don’t have Node.js installed just head on to the official Node.js website to get a copy of Node.js for your platform. Once you install node.js you will automatically have npm installed.

Getting Started

To get started, create a new directory for the application by running the following command on the terminal:

cd desktop && mkdir node-caching && cd node-caching

The commands above

cd desktop - navigate to the desktop directory

mkdir node-caching - create a new directory named “node-caching”

cd node-caching - navigate into the newly created node-caching directoryInitialize the directory to create a package.json file by running

npm init -y

Install dependencies

For this project we will be using Redis, axios and Express Framework for Node.js, so let’s install them by running the following:

npm install express redis axios

Open the newly created folder in your editor of choice. Your folder structure should now look like the one below:

Create a simple Express server as shown below:

const express = require('express');

const app = express();

const port = 3000;

app.listen(port, () => {
  console.log(`Server running on port ${port}`);
});

module.exports = app;

We are going to be making request to a public API for various food items recipe provided by http://www.recipepuppy.com

In index.js file paste the following code:

const express = require('express');

const app = express();

const port = 3000;

const axios = require('axios');

app.get('/recipe/:fooditem', async (req, res) => {
 try {
   const fooditem = req.params.fooditem;
   const recipe = await axios.get(`http://www.recipepuppy.com/api/?q=${fooditem}`);
    return res.status(200).send({
     error: false,
     data: recipe.data.results
   });

 } catch (error) {
     console.log(error)
 }
});

app.listen(port, () => {
 console.log(`Server running on port ${port}`);
});


module.exports = app;

Start the server by running node index.js and open postman to make a request to the recipe endpoint

As we can see, the request completed in 615ms which is quite a long time to fetch data that doesn't change often. We will improve this by implementing caching using Redis.

To be able to take full advantage of Redis offerings, we need to get
Redis by compiling it directly from source. To do this kindly run the
following command on your terminal:

wget http://download.redis.io/redis-stable.tar.gz
tar xvzf redis-stable.tar.gz
cd redis-stable
make

Confirm installation by running

make test

You can then copy redis to your path by running

sudo make install

To confirm that redis has been properly setup, start the redis server by running

redis-server

from your terminal. Then, open a new terminal tab/window and run

redis-cli ping

you should get PONG back as response. For detailed setup instruction, visit the official guide on the website here https://redis.io/topics/quickstart

Now that we have correctly setup redis, the next thing is to use it
in our application to improve it by reducing the turn around time of
request and response.

Add the following changes to index.js file

const express = require('express');
const axios = require('axios');
const redis = require('redis');

const app = express();

const port = 3000;

// make a connection to the local instance of redis
const client = redis.createClient(6379);

client.on("error", (error) => {
 console.error(error);
});

app.get('/recipe/:fooditem', (req, res) => {
 try {
   const foodItem = req.params.fooditem;

   // Check the redis store for the data first
   client.get(foodItem, async (err, recipe) => {
     if (recipe) {
       return res.status(200).send({
         error: false,
         message: `Recipe for ${foodItem} from the cache`,
         data: JSON.parse(recipe)
       })
     } else { // When the data is not found in the cache then we can make request to the server

         const recipe = await axios.get(`http://www.recipepuppy.com/api/?q=${foodItem}`);

         // save the record in the cache for subsequent request
         client.setex(foodItem, 1440, JSON.stringify(recipe.data.results));

         // return the result to the client
         return res.status(200).send({
           error: false,
           message: `Recipe for ${foodItem} from the server`,
           data: recipe.data.results
         });
     }
   })
 } catch (error) {
     console.log(error)
 }
});

app.listen(port, () => {
 console.log(`Server running on port ${port}`);
});


module.exports = app;

Explaining the cache process

First we created a redis client and link it with the local redis instance using the default redis port (6379)

const client = redis.createClient(6379);

Then, in the /recipe route handler, we tried to get the appropriate matching data to serve the request by checking for the key in our redis store. If found, the result is served to the requesting client from our cache and then we don’t have to make the server request anymore.

// Check the redis store for the data first
   client.get(foodItem, async (err, recipe) => {
     if (recipe) {
       return res.status(200).send({
         error: false,
         message: `Recipe for ${foodItem} from the cache`,
         data: JSON.parse(recipe)
       })
     }

But if the key is not found in our redis store, a request is made to the server and and once the response is available, we store the result using a unique key in the redis store:

const recipe = await axios.get(`http://www.recipepuppy.com/api/?q=${foodItem}`);

         // save the record in the cache for subsequent request
         client.setex(foodItem, 1440, JSON.stringify(recipe.data.results));

Hence, subsequent requests to the same endpoint with the same parameter will always be fetched from the cache so long the cached data has not expired.

The setex method of the redis client is used to set the key to hold a string value in the store for a particular number of seconds
which in this case is 1440 (24 minutes).

Full list of available redis commands and options can be found here: https://redis.io/commands

Testing the application

Now let’s test the application after implementing cache. Open postman and make a request to the same endpoint as before.

Again, because the key is not found in the cache the request is sent to the server which takes 566 ms to complete. Since the key didn’t exist in the cache before, it is now saved in the cache and subsequent requests with the same data will be fetched from the cache which makes it faster, and also reduces the load on the server.

Below is the response time after the cache:

As we can see above, it took a blazing 3ms for the request to be completed because it was fetched from the cache.

Now tell me, don’t you want to start caching already?

Kindly note that this is just a tip of the iceberg of what we can do with redis and I recommend that you consult the official documentation https://redis.io/documentation to enjoy full capabilities of this amazing data store.

Complete code can be found here https://github.com/iMichaelOwolabi/node-redis-caching-tut

Previously published at https://dev.to/imichaelowolabi/caching-in-node-js-using-redis-o1b
