In the world of web3 development, we often experience challenges with encoded errors, logs, or data in general. This data, typically presented in an encoded format, is in a lot of different use cases required to be human readable and thus we need libraries to decode it effectively.
featured image - How to Decode Web3 Data into a Human-Readable Format
blocktorch HackerNoon profile picture

In the world of web3 development, we often experience challenges with encoded errors, logs, or data in general. This data, typically presented in an encoded format, is in a lot of different use cases required to be human readable and thus we need libraries to decode it effectively. At blocktorch we came across this need internally, and so we decided to open-source the decoder service we have built.


There are many good reasons why data is encoded, for example, efficiency, integrity, and data security. But, of course, as long as humans are in the loop to work with the data, decoding the data and respective decoder services are indispensable. For example, we triggered a transaction and got this error: 0xf32bec2f . From that encoded data alone it is hard to understand the actual error and consequently fix the issue.


The blocktorch-xyz/decoder simplifies the decoding process of the data into a human-readable format, thereby enhancing efficiency and clarity in your web3 engineering tasks.


How the decoder service works

To use the decoder, all you require is the Application Binary Interfaces (ABIs) of the relevant smart contract in addition to the encoded data.


Using the previously mentioned example (error 0xf32bec2f), we will proceed to decode the data. To accomplish this task, we construct a call to the blocktorch-xyz/decoder containing ABIs associated with the smart contract, and the encoded data. The smart contract we use in our example is the Aggregation Router from 1inch Network on Polygon with address 0x1111111254eeb25477b68fb85ed929f73a960582.


The ABI for verified and published smart contracts can be found on block explorers — for example we are using polygonscan to derive the smart contract ABI: https://polygonscan.com/address/0x1111111254eeb25477b68fb85ed929f73a960582#code


[{"inputs":[{"internalType":"contract IWETH","name":"weth","type":"address"}],"stateMutability":"nonpayable","type":"constructor"},{"inputs":[],"name":"AccessDenied","type":"error"},{"inputs":[],"name":"AdvanceNonceFailed","type":"error"},{"inputs":[],"name":"AlreadyFilled","type":"error"},{"inputs":[],"name":"ArbitraryStaticCallFailed","type":"error"},{"inputs":[],"name":"BadPool","type":"error"},{"inputs":[],"name":"BadSignature","type":"error"},{"inputs":[],"name":"ETHTransferFailed","type":"error"},{"inputs":[],"name":"ETHTransferFailed","type":"error"},{"inputs":[],"name":"EmptyPools","type":"error"},{"inputs":[],"name":"EthDepositRejected","type":"error"},{"inputs":[],"name":"GetAmountCallFailed","type":"error"},{"inputs":[],"name":"IncorrectDataLength","type":"error"},{"inputs":[],"name":"InsufficientBalance","type":"error"},{"inputs":[],"name":"InvalidMsgValue","type":"error"},{"inputs":[],"name":"InvalidMsgValue","type":"error"},{"inputs":[],"name":"InvalidatedOrder","type":"error"},{"inputs":[],"name":"MakingAmountExceeded","type":"error"},{"inputs":[],"name":"MakingAmountTooLow","type":"error"},{"inputs":[],"name":"OnlyOneAmountShouldBeZero","type":"error"},{"inputs":[],"name":"OrderExpired","type":"error"},{"inputs":[],"name":"PermitLengthTooLow","type":"error"},{"inputs":[],"name":"PredicateIsNotTrue","type":"error"},{"inputs":[],"name":"PrivateOrder","type":"error"},{"inputs":[],"name":"RFQBadSignature","type":"error"},{"inputs":[],"name":"RFQPrivateOrder","type":"error"},{"inputs":[],"name":"RFQSwapWithZeroAmount","type":"error"},{"inputs":[],"name":"RFQZeroTargetIsForbidden","type":"error"},{"inputs":[],"name":"ReentrancyDetected","type":"error"},{"inputs":[],"name":"RemainingAmountIsZero","type":"error"},{"inputs":[],"name":"ReservesCallFailed","type":"error"},{"inputs":[],"name":"ReturnAmountIsNotEnough","type":"error"},{"inputs":[],"name":"SafePermitBadLength","type":"error"},{"inputs":[],"name":"SafeTransferFailed","type":"error"},{"inputs":[],"name":"SafeTransferFromFailed","type":"error"},{"inputs":[{"internalType":"bool","name":"success","type":"bool"},{"internalType":"bytes","name":"res","type":"bytes"}],"name":"SimulationResults","type":"error"},{"inputs":[],"name":"SwapAmountTooLarge","type":"error"},{"inputs":[],"name":"SwapWithZeroAmount","type":"error"},{"inputs":[],"name":"TakingAmountExceeded","type":"error"},{"inputs":[],"name":"TakingAmountIncreased","type":"error"},{"inputs":[],"name":"TakingAmountTooHigh","type":"error"},{"inputs":[],"name":"TransferFromMakerToTakerFailed","type":"error"},{"inputs":[],"name":"TransferFromTakerToMakerFailed","type":"error"},{"inputs":[],"name":"UnknownOrder","type":"error"},{"inputs":[],"name":"WrongAmount","type":"error"},{"inputs":[],"name":"WrongGetter","type":"error"},{"inputs":[],"name":"ZeroAddress","type":"error"},{"inputs":[],"name":"ZeroMinReturn","type":"error"},{"inputs":[],"name":"ZeroReturnAmount","type":"error"},{"inputs":[],"name":"ZeroTargetIsForbidden","type":"error"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"maker","type":"address"},{"indexed":false,"internalType":"uint256","name":"newNonce","type":"uint256"}],"name":"NonceIncreased","type":"event"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"maker","type":"address"},{"indexed":false,"internalType":"bytes32","name":"orderHash","type":"bytes32"},{"indexed":false,"internalType":"uint256","name":"remainingRaw","type":"uint256"}],"name":"OrderCanceled","type":"event"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"maker","type":"address"},{"indexed":false,"internalType":"bytes32","name":"orderHash","type":"bytes32"},{"indexed":false,"internalType":"uint256","name":"remaining","type":"uint256"}],"name":"OrderFilled","type":"event"},{"anonymous":false,"inputs":[{"indexed":false,"internalType":"bytes32","name":"orderHash","type":"bytes32"},{"indexed":false,"internalType":"uint256","name":"makingAmount","type":"uint256"}],"name":"OrderFilledRFQ","type":"event"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"previousOwner","type":"address"},{"indexed":true,"internalType":"address","name":"newOwner","type":"address"}],"name":"OwnershipTransferred","type":"event"},{"inputs":[{"internalType":"uint8","name":"amount","type":"uint8"}],"name":"advanceNonce","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"and","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"arbitraryStaticCall","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"}],"name":"cancelOrder","outputs":[{"internalType":"uint256","name":"orderRemaining","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"orderInfo","type":"uint256"}],"name":"cancelOrderRFQ","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"orderInfo","type":"uint256"},{"internalType":"uint256","name":"additionalMask","type":"uint256"}],"name":"cancelOrderRFQ","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"}],"name":"checkPredicate","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"contract IClipperExchangeInterface","name":"clipperExchange","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"uint256","name":"inputAmount","type":"uint256"},{"internalType":"uint256","name":"outputAmount","type":"uint256"},{"internalType":"uint256","name":"goodUntil","type":"uint256"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"}],"name":"clipperSwap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"contract IClipperExchangeInterface","name":"clipperExchange","type":"address"},{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"uint256","name":"inputAmount","type":"uint256"},{"internalType":"uint256","name":"outputAmount","type":"uint256"},{"internalType":"uint256","name":"goodUntil","type":"uint256"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"}],"name":"clipperSwapTo","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"contract IClipperExchangeInterface","name":"clipperExchange","type":"address"},{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"uint256","name":"inputAmount","type":"uint256"},{"internalType":"uint256","name":"outputAmount","type":"uint256"},{"internalType":"uint256","name":"goodUntil","type":"uint256"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"clipperSwapToWithPermit","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[],"name":"destroy","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"value","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"eq","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"bytes","name":"interaction","type":"bytes"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"skipPermitAndThresholdAmount","type":"uint256"}],"name":"fillOrder","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"}],"name":"fillOrderRFQ","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"}],"name":"fillOrderRFQCompact","outputs":[{"internalType":"uint256","name":"filledMakingAmount","type":"uint256"},{"internalType":"uint256","name":"filledTakingAmount","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"}],"name":"fillOrderRFQTo","outputs":[{"internalType":"uint256","name":"filledMakingAmount","type":"uint256"},{"internalType":"uint256","name":"filledTakingAmount","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"fillOrderRFQToWithPermit","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order_","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"bytes","name":"interaction","type":"bytes"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"skipPermitAndThresholdAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"}],"name":"fillOrderTo","outputs":[{"internalType":"uint256","name":"actualMakingAmount","type":"uint256"},{"internalType":"uint256","name":"actualTakingAmount","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"bytes","name":"interaction","type":"bytes"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"skipPermitAndThresholdAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"fillOrderToWithPermit","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"value","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"gt","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"}],"name":"hashOrder","outputs":[{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"view","type":"function"},{"inputs":[],"name":"increaseNonce","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"address","name":"maker","type":"address"},{"internalType":"uint256","name":"slot","type":"uint256"}],"name":"invalidatorForOrderRFQ","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"uint256","name":"value","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"lt","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"","type":"address"}],"name":"nonce","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"makerAddress","type":"address"},{"internalType":"uint256","name":"makerNonce","type":"uint256"}],"name":"nonceEquals","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"or","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[],"name":"owner","outputs":[{"internalType":"address","name":"","type":"address"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"name":"remaining","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"name":"remainingRaw","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"bytes32[]","name":"orderHashes","type":"bytes32[]"}],"name":"remainingsRaw","outputs":[{"internalType":"uint256[]","name":"","type":"uint256[]"}],"stateMutability":"view","type":"function"},{"inputs":[],"name":"renounceOwnership","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"contract IERC20","name":"token","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"}],"name":"rescueFunds","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"simulate","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"contract IAggregationExecutor","name":"executor","type":"address"},{"components":[{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"address payable","name":"srcReceiver","type":"address"},{"internalType":"address payable","name":"dstReceiver","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturnAmount","type":"uint256"},{"internalType":"uint256","name":"flags","type":"uint256"}],"internalType":"struct GenericRouter.SwapDescription","name":"desc","type":"tuple"},{"internalType":"bytes","name":"permit","type":"bytes"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"swap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"},{"internalType":"uint256","name":"spentAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"uint256","name":"time","type":"uint256"}],"name":"timestampBelow","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"uint256","name":"timeNonceAccount","type":"uint256"}],"name":"timestampBelowAndNonceEquals","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"newOwner","type":"address"}],"name":"transferOwnership","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"uniswapV3Swap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"int256","name":"amount0Delta","type":"int256"},{"internalType":"int256","name":"amount1Delta","type":"int256"},{"internalType":"bytes","name":"","type":"bytes"}],"name":"uniswapV3SwapCallback","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"uniswapV3SwapTo","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"uniswapV3SwapToWithPermit","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"unoswap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"unoswapTo","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"unoswapToWithPermit","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"nonpayable","type":"function"},{"stateMutability":"payable","type":"receive"}]


Once you know the data you want to decode, the smart contract address and ABI you can trigger the call to the decoder service.


For our example, we trigger the following call:

POST /api/internal/transaction/decode
{
    "abis": {
        "0x1111111254eeb25477b68fb85ed929f73a960582": {
            "contractAbi": [{"inputs":[{"internalType":"contract IWETH","name":"weth","type":"address"}],"stateMutability":"nonpayable","type":"constructor"},{"inputs":[],"name":"AccessDenied","type":"error"},{"inputs":[],"name":"AdvanceNonceFailed","type":"error"},{"inputs":[],"name":"AlreadyFilled","type":"error"},{"inputs":[],"name":"ArbitraryStaticCallFailed","type":"error"},{"inputs":[],"name":"BadPool","type":"error"},{"inputs":[],"name":"BadSignature","type":"error"},{"inputs":[],"name":"ETHTransferFailed","type":"error"},{"inputs":[],"name":"ETHTransferFailed","type":"error"},{"inputs":[],"name":"EmptyPools","type":"error"},{"inputs":[],"name":"EthDepositRejected","type":"error"},{"inputs":[],"name":"GetAmountCallFailed","type":"error"},{"inputs":[],"name":"IncorrectDataLength","type":"error"},{"inputs":[],"name":"InsufficientBalance","type":"error"},{"inputs":[],"name":"InvalidMsgValue","type":"error"},{"inputs":[],"name":"InvalidMsgValue","type":"error"},{"inputs":[],"name":"InvalidatedOrder","type":"error"},{"inputs":[],"name":"MakingAmountExceeded","type":"error"},{"inputs":[],"name":"MakingAmountTooLow","type":"error"},{"inputs":[],"name":"OnlyOneAmountShouldBeZero","type":"error"},{"inputs":[],"name":"OrderExpired","type":"error"},{"inputs":[],"name":"PermitLengthTooLow","type":"error"},{"inputs":[],"name":"PredicateIsNotTrue","type":"error"},{"inputs":[],"name":"PrivateOrder","type":"error"},{"inputs":[],"name":"RFQBadSignature","type":"error"},{"inputs":[],"name":"RFQPrivateOrder","type":"error"},{"inputs":[],"name":"RFQSwapWithZeroAmount","type":"error"},{"inputs":[],"name":"RFQZeroTargetIsForbidden","type":"error"},{"inputs":[],"name":"ReentrancyDetected","type":"error"},{"inputs":[],"name":"RemainingAmountIsZero","type":"error"},{"inputs":[],"name":"ReservesCallFailed","type":"error"},{"inputs":[],"name":"ReturnAmountIsNotEnough","type":"error"},{"inputs":[],"name":"SafePermitBadLength","type":"error"},{"inputs":[],"name":"SafeTransferFailed","type":"error"},{"inputs":[],"name":"SafeTransferFromFailed","type":"error"},{"inputs":[{"internalType":"bool","name":"success","type":"bool"},{"internalType":"bytes","name":"res","type":"bytes"}],"name":"SimulationResults","type":"error"},{"inputs":[],"name":"SwapAmountTooLarge","type":"error"},{"inputs":[],"name":"SwapWithZeroAmount","type":"error"},{"inputs":[],"name":"TakingAmountExceeded","type":"error"},{"inputs":[],"name":"TakingAmountIncreased","type":"error"},{"inputs":[],"name":"TakingAmountTooHigh","type":"error"},{"inputs":[],"name":"TransferFromMakerToTakerFailed","type":"error"},{"inputs":[],"name":"TransferFromTakerToMakerFailed","type":"error"},{"inputs":[],"name":"UnknownOrder","type":"error"},{"inputs":[],"name":"WrongAmount","type":"error"},{"inputs":[],"name":"WrongGetter","type":"error"},{"inputs":[],"name":"ZeroAddress","type":"error"},{"inputs":[],"name":"ZeroMinReturn","type":"error"},{"inputs":[],"name":"ZeroReturnAmount","type":"error"},{"inputs":[],"name":"ZeroTargetIsForbidden","type":"error"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"maker","type":"address"},{"indexed":false,"internalType":"uint256","name":"newNonce","type":"uint256"}],"name":"NonceIncreased","type":"event"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"maker","type":"address"},{"indexed":false,"internalType":"bytes32","name":"orderHash","type":"bytes32"},{"indexed":false,"internalType":"uint256","name":"remainingRaw","type":"uint256"}],"name":"OrderCanceled","type":"event"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"maker","type":"address"},{"indexed":false,"internalType":"bytes32","name":"orderHash","type":"bytes32"},{"indexed":false,"internalType":"uint256","name":"remaining","type":"uint256"}],"name":"OrderFilled","type":"event"},{"anonymous":false,"inputs":[{"indexed":false,"internalType":"bytes32","name":"orderHash","type":"bytes32"},{"indexed":false,"internalType":"uint256","name":"makingAmount","type":"uint256"}],"name":"OrderFilledRFQ","type":"event"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"previousOwner","type":"address"},{"indexed":true,"internalType":"address","name":"newOwner","type":"address"}],"name":"OwnershipTransferred","type":"event"},{"inputs":[{"internalType":"uint8","name":"amount","type":"uint8"}],"name":"advanceNonce","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"and","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"arbitraryStaticCall","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"}],"name":"cancelOrder","outputs":[{"internalType":"uint256","name":"orderRemaining","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"orderInfo","type":"uint256"}],"name":"cancelOrderRFQ","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"orderInfo","type":"uint256"},{"internalType":"uint256","name":"additionalMask","type":"uint256"}],"name":"cancelOrderRFQ","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"}],"name":"checkPredicate","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"contract IClipperExchangeInterface","name":"clipperExchange","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"uint256","name":"inputAmount","type":"uint256"},{"internalType":"uint256","name":"outputAmount","type":"uint256"},{"internalType":"uint256","name":"goodUntil","type":"uint256"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"}],"name":"clipperSwap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"contract IClipperExchangeInterface","name":"clipperExchange","type":"address"},{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"uint256","name":"inputAmount","type":"uint256"},{"internalType":"uint256","name":"outputAmount","type":"uint256"},{"internalType":"uint256","name":"goodUntil","type":"uint256"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"}],"name":"clipperSwapTo","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"contract IClipperExchangeInterface","name":"clipperExchange","type":"address"},{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"uint256","name":"inputAmount","type":"uint256"},{"internalType":"uint256","name":"outputAmount","type":"uint256"},{"internalType":"uint256","name":"goodUntil","type":"uint256"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"clipperSwapToWithPermit","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[],"name":"destroy","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"value","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"eq","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"bytes","name":"interaction","type":"bytes"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"skipPermitAndThresholdAmount","type":"uint256"}],"name":"fillOrder","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"}],"name":"fillOrderRFQ","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"}],"name":"fillOrderRFQCompact","outputs":[{"internalType":"uint256","name":"filledMakingAmount","type":"uint256"},{"internalType":"uint256","name":"filledTakingAmount","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"}],"name":"fillOrderRFQTo","outputs":[{"internalType":"uint256","name":"filledMakingAmount","type":"uint256"},{"internalType":"uint256","name":"filledTakingAmount","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"fillOrderRFQToWithPermit","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order_","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"bytes","name":"interaction","type":"bytes"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"skipPermitAndThresholdAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"}],"name":"fillOrderTo","outputs":[{"internalType":"uint256","name":"actualMakingAmount","type":"uint256"},{"internalType":"uint256","name":"actualTakingAmount","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"bytes","name":"interaction","type":"bytes"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"skipPermitAndThresholdAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"fillOrderToWithPermit","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"value","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"gt","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"}],"name":"hashOrder","outputs":[{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"view","type":"function"},{"inputs":[],"name":"increaseNonce","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"address","name":"maker","type":"address"},{"internalType":"uint256","name":"slot","type":"uint256"}],"name":"invalidatorForOrderRFQ","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"uint256","name":"value","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"lt","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"","type":"address"}],"name":"nonce","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"makerAddress","type":"address"},{"internalType":"uint256","name":"makerNonce","type":"uint256"}],"name":"nonceEquals","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"or","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[],"name":"owner","outputs":[{"internalType":"address","name":"","type":"address"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"name":"remaining","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"name":"remainingRaw","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"bytes32[]","name":"orderHashes","type":"bytes32[]"}],"name":"remainingsRaw","outputs":[{"internalType":"uint256[]","name":"","type":"uint256[]"}],"stateMutability":"view","type":"function"},{"inputs":[],"name":"renounceOwnership","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"contract IERC20","name":"token","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"}],"name":"rescueFunds","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"simulate","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"contract IAggregationExecutor","name":"executor","type":"address"},{"components":[{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"address payable","name":"srcReceiver","type":"address"},{"internalType":"address payable","name":"dstReceiver","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturnAmount","type":"uint256"},{"internalType":"uint256","name":"flags","type":"uint256"}],"internalType":"struct GenericRouter.SwapDescription","name":"desc","type":"tuple"},{"internalType":"bytes","name":"permit","type":"bytes"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"swap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"},{"internalType":"uint256","name":"spentAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"uint256","name":"time","type":"uint256"}],"name":"timestampBelow","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"uint256","name":"timeNonceAccount","type":"uint256"}],"name":"timestampBelowAndNonceEquals","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"newOwner","type":"address"}],"name":"transferOwnership","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"uniswapV3Swap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"int256","name":"amount0Delta","type":"int256"},{"internalType":"int256","name":"amount1Delta","type":"int256"},{"internalType":"bytes","name":"","type":"bytes"}],"name":"uniswapV3SwapCallback","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"uniswapV3SwapTo","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"uniswapV3SwapToWithPermit","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"unoswap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"unoswapTo","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"unoswapToWithPermit","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"nonpayable","type":"function"},{"stateMutability":"payable","type":"receive"}]
        }
    },
    "transaction": {
        "to": "0x1111111254eeb25477b68fb85ed929f73a960582",
        "input": "0x0502b1c50000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000001158e460913d000000000000000000000000000000000000000000000000000000000000000ea9ac80000000000000000000000000000000000000000000000000000000000000080000000000000000000000000000000000000000000000000000000000000000100000000000000003b6d034055ff76bffc3cdd9d5fdbbc2ece4528ecce45047e10d1df6e",
        "value": "0x01158e460913d00000",
        "error": {
            "data": "0xf32bec2f"
        }
    }
}


The response will be human-readable data. As you can see now in our example the error we received was “ReturnAmountIsNotEnough” in the “unoswap” function.

{
    "transaction": {
        "args": [
            "0x0000000000000000000000000000000000000000",
            {
                "type": "BigNumber",
                "hex": "0x01158e460913d00000"
            },
            {
                "type": "BigNumber",
                "hex": "0xea9ac8"
            },
            [
                {
                    "type": "BigNumber",
                    "hex": "0x3b6d034055ff76bffc3cdd9d5fdbbc2ece4528ecce45047e"
                }
            ]
        ],
        "functionFragment": {
            "type": "function",
            "name": "unoswap",
            "constant": false,
            "inputs": [
                {
                    "name": "srcToken",
                    "type": "address",
                    "indexed": null,
                    "components": null,
                    "arrayLength": null,
                    "arrayChildren": null,
                    "baseType": "address",
                    "_isParamType": true
                },
                {
                    "name": "amount",
                    "type": "uint256",
                    "indexed": null,
                    "components": null,
                    "arrayLength": null,
                    "arrayChildren": null,
                    "baseType": "uint256",
                    "_isParamType": true
                },
                {
                    "name": "minReturn",
                    "type": "uint256",
                    "indexed": null,
                    "components": null,
                    "arrayLength": null,
                    "arrayChildren": null,
                    "baseType": "uint256",
                    "_isParamType": true
                },
                {
                    "name": "pools",
                    "type": "uint256[]",
                    "indexed": null,
                    "components": null,
                    "arrayLength": -1,
                    "arrayChildren": {
                        "name": null,
                        "type": "uint256",
                        "indexed": null,
                        "components": null,
                        "arrayLength": null,
                        "arrayChildren": null,
                        "baseType": "uint256",
                        "_isParamType": true
                    },
                    "baseType": "array",
                    "_isParamType": true
                }
            ],
            "outputs": [
                {
                    "name": "returnAmount",
                    "type": "uint256",
                    "indexed": null,
                    "components": null,
                    "arrayLength": null,
                    "arrayChildren": null,
                    "baseType": "uint256",
                    "_isParamType": true
                }
            ],
            "payable": true,
            "stateMutability": "payable",
            "gas": null,
            "_isFragment": true
        },
        "name": "unoswap",
        "signature": "unoswap(address,uint256,uint256,uint256[])",
        "sighash": "0x0502b1c5",
        "value": {
            "type": "BigNumber",
            "hex": "0x01158e460913d00000"
        }
    },
    "error": {
        "args": [],
        "errorFragment": {
            "type": "error",
            "name": "ReturnAmountIsNotEnough",
            "inputs": [],
            "_isFragment": true
        },
        "name": "ReturnAmountIsNotEnough",
        "signature": "ReturnAmountIsNotEnough()",
        "sighash": "0xf32bec2f"
    }
}


The same will also work in case the smart contract uses a proxy, all you need to do is provide the proxy ABI and the service will decode it for you.


Running the web3 data decoder locally

  1. Clone the repository


git clone [email protected]:blocktorch-xyz/decoder.git


2. Add .env.development file with the following envs (remark: as a general best practice if you push to github please always ensure the files your environment variables are stored in are included in your .gitignore file)


BASIC_AUTH_INTERNAL_USERNAME=username
BASIC_AUTH_INTERNAL_PASSWORD=very-secure-password


3. Install dependencies and run the service


npm i
npm run dev


or


yarn
yarn run dev


That’s it, you can run the following call to test it


curl --location 'http://localhost:8000/api/internal/transaction/decode' \
--header 'Content-Type: application/json' \
--header 'Authorization: Basic dXNlcm5hbWU6dmVyeS1zZWN1cmUtcGFzc3dvcmQ=' \
--data '{
    "abis": {
        "0x1111111254eeb25477b68fb85ed929f73a960582": {
            "contractAbi": [{"inputs":[{"internalType":"contract IWETH","name":"weth","type":"address"}],"stateMutability":"nonpayable","type":"constructor"},{"inputs":[],"name":"AccessDenied","type":"error"},{"inputs":[],"name":"AdvanceNonceFailed","type":"error"},{"inputs":[],"name":"AlreadyFilled","type":"error"},{"inputs":[],"name":"ArbitraryStaticCallFailed","type":"error"},{"inputs":[],"name":"BadPool","type":"error"},{"inputs":[],"name":"BadSignature","type":"error"},{"inputs":[],"name":"ETHTransferFailed","type":"error"},{"inputs":[],"name":"ETHTransferFailed","type":"error"},{"inputs":[],"name":"EmptyPools","type":"error"},{"inputs":[],"name":"EthDepositRejected","type":"error"},{"inputs":[],"name":"GetAmountCallFailed","type":"error"},{"inputs":[],"name":"IncorrectDataLength","type":"error"},{"inputs":[],"name":"InsufficientBalance","type":"error"},{"inputs":[],"name":"InvalidMsgValue","type":"error"},{"inputs":[],"name":"InvalidMsgValue","type":"error"},{"inputs":[],"name":"InvalidatedOrder","type":"error"},{"inputs":[],"name":"MakingAmountExceeded","type":"error"},{"inputs":[],"name":"MakingAmountTooLow","type":"error"},{"inputs":[],"name":"OnlyOneAmountShouldBeZero","type":"error"},{"inputs":[],"name":"OrderExpired","type":"error"},{"inputs":[],"name":"PermitLengthTooLow","type":"error"},{"inputs":[],"name":"PredicateIsNotTrue","type":"error"},{"inputs":[],"name":"PrivateOrder","type":"error"},{"inputs":[],"name":"RFQBadSignature","type":"error"},{"inputs":[],"name":"RFQPrivateOrder","type":"error"},{"inputs":[],"name":"RFQSwapWithZeroAmount","type":"error"},{"inputs":[],"name":"RFQZeroTargetIsForbidden","type":"error"},{"inputs":[],"name":"ReentrancyDetected","type":"error"},{"inputs":[],"name":"RemainingAmountIsZero","type":"error"},{"inputs":[],"name":"ReservesCallFailed","type":"error"},{"inputs":[],"name":"ReturnAmountIsNotEnough","type":"error"},{"inputs":[],"name":"SafePermitBadLength","type":"error"},{"inputs":[],"name":"SafeTransferFailed","type":"error"},{"inputs":[],"name":"SafeTransferFromFailed","type":"error"},{"inputs":[{"internalType":"bool","name":"success","type":"bool"},{"internalType":"bytes","name":"res","type":"bytes"}],"name":"SimulationResults","type":"error"},{"inputs":[],"name":"SwapAmountTooLarge","type":"error"},{"inputs":[],"name":"SwapWithZeroAmount","type":"error"},{"inputs":[],"name":"TakingAmountExceeded","type":"error"},{"inputs":[],"name":"TakingAmountIncreased","type":"error"},{"inputs":[],"name":"TakingAmountTooHigh","type":"error"},{"inputs":[],"name":"TransferFromMakerToTakerFailed","type":"error"},{"inputs":[],"name":"TransferFromTakerToMakerFailed","type":"error"},{"inputs":[],"name":"UnknownOrder","type":"error"},{"inputs":[],"name":"WrongAmount","type":"error"},{"inputs":[],"name":"WrongGetter","type":"error"},{"inputs":[],"name":"ZeroAddress","type":"error"},{"inputs":[],"name":"ZeroMinReturn","type":"error"},{"inputs":[],"name":"ZeroReturnAmount","type":"error"},{"inputs":[],"name":"ZeroTargetIsForbidden","type":"error"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"maker","type":"address"},{"indexed":false,"internalType":"uint256","name":"newNonce","type":"uint256"}],"name":"NonceIncreased","type":"event"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"maker","type":"address"},{"indexed":false,"internalType":"bytes32","name":"orderHash","type":"bytes32"},{"indexed":false,"internalType":"uint256","name":"remainingRaw","type":"uint256"}],"name":"OrderCanceled","type":"event"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"maker","type":"address"},{"indexed":false,"internalType":"bytes32","name":"orderHash","type":"bytes32"},{"indexed":false,"internalType":"uint256","name":"remaining","type":"uint256"}],"name":"OrderFilled","type":"event"},{"anonymous":false,"inputs":[{"indexed":false,"internalType":"bytes32","name":"orderHash","type":"bytes32"},{"indexed":false,"internalType":"uint256","name":"makingAmount","type":"uint256"}],"name":"OrderFilledRFQ","type":"event"},{"anonymous":false,"inputs":[{"indexed":true,"internalType":"address","name":"previousOwner","type":"address"},{"indexed":true,"internalType":"address","name":"newOwner","type":"address"}],"name":"OwnershipTransferred","type":"event"},{"inputs":[{"internalType":"uint8","name":"amount","type":"uint8"}],"name":"advanceNonce","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"and","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"arbitraryStaticCall","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"}],"name":"cancelOrder","outputs":[{"internalType":"uint256","name":"orderRemaining","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"orderInfo","type":"uint256"}],"name":"cancelOrderRFQ","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"orderInfo","type":"uint256"},{"internalType":"uint256","name":"additionalMask","type":"uint256"}],"name":"cancelOrderRFQ","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"}],"name":"checkPredicate","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"contract IClipperExchangeInterface","name":"clipperExchange","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"uint256","name":"inputAmount","type":"uint256"},{"internalType":"uint256","name":"outputAmount","type":"uint256"},{"internalType":"uint256","name":"goodUntil","type":"uint256"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"}],"name":"clipperSwap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"contract IClipperExchangeInterface","name":"clipperExchange","type":"address"},{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"uint256","name":"inputAmount","type":"uint256"},{"internalType":"uint256","name":"outputAmount","type":"uint256"},{"internalType":"uint256","name":"goodUntil","type":"uint256"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"}],"name":"clipperSwapTo","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"contract IClipperExchangeInterface","name":"clipperExchange","type":"address"},{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"uint256","name":"inputAmount","type":"uint256"},{"internalType":"uint256","name":"outputAmount","type":"uint256"},{"internalType":"uint256","name":"goodUntil","type":"uint256"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"clipperSwapToWithPermit","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[],"name":"destroy","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"value","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"eq","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"bytes","name":"interaction","type":"bytes"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"skipPermitAndThresholdAmount","type":"uint256"}],"name":"fillOrder","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"}],"name":"fillOrderRFQ","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes32","name":"r","type":"bytes32"},{"internalType":"bytes32","name":"vs","type":"bytes32"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"}],"name":"fillOrderRFQCompact","outputs":[{"internalType":"uint256","name":"filledMakingAmount","type":"uint256"},{"internalType":"uint256","name":"filledTakingAmount","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"}],"name":"fillOrderRFQTo","outputs":[{"internalType":"uint256","name":"filledMakingAmount","type":"uint256"},{"internalType":"uint256","name":"filledTakingAmount","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"info","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"}],"internalType":"struct OrderRFQLib.OrderRFQ","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"uint256","name":"flagsAndAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"fillOrderRFQToWithPermit","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order_","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"bytes","name":"interaction","type":"bytes"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"skipPermitAndThresholdAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"}],"name":"fillOrderTo","outputs":[{"internalType":"uint256","name":"actualMakingAmount","type":"uint256"},{"internalType":"uint256","name":"actualTakingAmount","type":"uint256"},{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"stateMutability":"payable","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"},{"internalType":"bytes","name":"signature","type":"bytes"},{"internalType":"bytes","name":"interaction","type":"bytes"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"skipPermitAndThresholdAmount","type":"uint256"},{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"fillOrderToWithPermit","outputs":[{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"uint256","name":"","type":"uint256"},{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"value","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"gt","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"components":[{"internalType":"uint256","name":"salt","type":"uint256"},{"internalType":"address","name":"makerAsset","type":"address"},{"internalType":"address","name":"takerAsset","type":"address"},{"internalType":"address","name":"maker","type":"address"},{"internalType":"address","name":"receiver","type":"address"},{"internalType":"address","name":"allowedSender","type":"address"},{"internalType":"uint256","name":"makingAmount","type":"uint256"},{"internalType":"uint256","name":"takingAmount","type":"uint256"},{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"interactions","type":"bytes"}],"internalType":"struct OrderLib.Order","name":"order","type":"tuple"}],"name":"hashOrder","outputs":[{"internalType":"bytes32","name":"","type":"bytes32"}],"stateMutability":"view","type":"function"},{"inputs":[],"name":"increaseNonce","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"address","name":"maker","type":"address"},{"internalType":"uint256","name":"slot","type":"uint256"}],"name":"invalidatorForOrderRFQ","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"uint256","name":"value","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"lt","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"","type":"address"}],"name":"nonce","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"makerAddress","type":"address"},{"internalType":"uint256","name":"makerNonce","type":"uint256"}],"name":"nonceEquals","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"uint256","name":"offsets","type":"uint256"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"or","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[],"name":"owner","outputs":[{"internalType":"address","name":"","type":"address"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"name":"remaining","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"bytes32","name":"orderHash","type":"bytes32"}],"name":"remainingRaw","outputs":[{"internalType":"uint256","name":"","type":"uint256"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"bytes32[]","name":"orderHashes","type":"bytes32[]"}],"name":"remainingsRaw","outputs":[{"internalType":"uint256[]","name":"","type":"uint256[]"}],"stateMutability":"view","type":"function"},{"inputs":[],"name":"renounceOwnership","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"contract IERC20","name":"token","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"}],"name":"rescueFunds","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"address","name":"target","type":"address"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"simulate","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"contract IAggregationExecutor","name":"executor","type":"address"},{"components":[{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"contract IERC20","name":"dstToken","type":"address"},{"internalType":"address payable","name":"srcReceiver","type":"address"},{"internalType":"address payable","name":"dstReceiver","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturnAmount","type":"uint256"},{"internalType":"uint256","name":"flags","type":"uint256"}],"internalType":"struct GenericRouter.SwapDescription","name":"desc","type":"tuple"},{"internalType":"bytes","name":"permit","type":"bytes"},{"internalType":"bytes","name":"data","type":"bytes"}],"name":"swap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"},{"internalType":"uint256","name":"spentAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"uint256","name":"time","type":"uint256"}],"name":"timestampBelow","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"uint256","name":"timeNonceAccount","type":"uint256"}],"name":"timestampBelowAndNonceEquals","outputs":[{"internalType":"bool","name":"","type":"bool"}],"stateMutability":"view","type":"function"},{"inputs":[{"internalType":"address","name":"newOwner","type":"address"}],"name":"transferOwnership","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"uniswapV3Swap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"int256","name":"amount0Delta","type":"int256"},{"internalType":"int256","name":"amount1Delta","type":"int256"},{"internalType":"bytes","name":"","type":"bytes"}],"name":"uniswapV3SwapCallback","outputs":[],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"uniswapV3SwapTo","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"uniswapV3SwapToWithPermit","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"nonpayable","type":"function"},{"inputs":[{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"unoswap","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"}],"name":"unoswapTo","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"payable","type":"function"},{"inputs":[{"internalType":"address payable","name":"recipient","type":"address"},{"internalType":"contract IERC20","name":"srcToken","type":"address"},{"internalType":"uint256","name":"amount","type":"uint256"},{"internalType":"uint256","name":"minReturn","type":"uint256"},{"internalType":"uint256[]","name":"pools","type":"uint256[]"},{"internalType":"bytes","name":"permit","type":"bytes"}],"name":"unoswapToWithPermit","outputs":[{"internalType":"uint256","name":"returnAmount","type":"uint256"}],"stateMutability":"nonpayable","type":"function"},{"stateMutability":"payable","type":"receive"}]
        }
    },
    "transaction": {
        "to": "0x1111111254eeb25477b68fb85ed929f73a960582",
        "input": "0x0502b1c50000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000000001158e460913d000000000000000000000000000000000000000000000000000000000000000ea9ac80000000000000000000000000000000000000000000000000000000000000080000000000000000000000000000000000000000000000000000000000000000100000000000000003b6d034055ff76bffc3cdd9d5fdbbc2ece4528ecce45047e10d1df6e",
        "value": "0x01158e460913d00000",
        "error": {
            "data": "0xf32bec2f"
        }
    }
}'


🥳 Congrats you are now set up to decode EVM transactions locally into human-readable format!


We highly encourage you to contribute to the package by submitting a PR. You can find the GitHub repository here:https://github.com/blocktorch-xyz/decoder


Turning data into human readable format like blocktorch does. Created with ChatGPT4/DALL-E



Also published here.

At Blocktorch we are on a mission to give web3 builders superpowers. Our web3 observability platform provides end-2-end observability like real-time tracing, logging, and monitoring for developers building decentralized applications and smart contracts. We support the full stack of any dApp.
